Volkswagen CC (2015 year). Instruction

Use a thin object to pry the battery out of the battery compartment

⇒

fig. 24

Position the new battery in as shown

⇒

fig. 24

and press it into the

battery compartment (opposite to direction of the arrow)

⇒ .

Position the cover as shown

⇒

fig. 23

and press it down (opposite

to direction of the arrow) until you hear it click into place.

NOTICE

Changing the battery improperly can damage the remote con-

trol vehicle key.

Using the wrong battery can damage the remote control vehi-

cle key. Replace a dead battery with a new one that has the same
voltage, size, and specifications.

Make sure the plus and minus poles of the battery are correct-

ly positioned.

Dispose of old batteries in an environmentally responsible man-

ner and keep them out of the reach of children.

Batteries of the type used in your remote control vehicle key may

contain Perchlorate Material. Special handling may apply – see
http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding handling and disposal of these batteries. Au-
thorized Volkswagen dealers and authorized Volkswagen Service
Facilities are familiar with the requirements, and we recommend that
you have them perform this service for you.

Synchronizing the remote control vehicle key

Please first read and note the introductory information and

heed the WARNINGS

If the button is pressed often while outside the operating range, it is
possible that the vehicle cannot be locked or unlocked anymore with
the remote control vehicle key. Synchronize the vehicle key as fol-
lows:

Unfold the key bit on the remote control vehicle key

⇒ Remote

control vehicle keys.

Remove the cap from the door handle on the driver door

⇒ Emer-

gency closing and opening.

Press the button on the remote control vehicle key. Stand imme-

diately next to vehicle while doing so.

Manually unlock the vehicle using the key bit within 1 minute. The

synchronization is complete.

Reinstall the cap.

Doors

Introduction

In this section you’ll find information about:
Display
Child safety lock

More information:

Exterior views
Vehicle key set
Power locking and closing system
Power windows
Emergency closing and opening

WARNING

A door that is not closed properly may open suddenly when the
vehicle is moving and cause severe injuries.

Stop immediately and close the door.
Make sure that the door is safely and completely latched

when closed. The closed door must be flush with the surround-
ing auto body parts.

Open or close doors only if no one is in the way.

WARNING

A door kept open with the door stop may close in strong winds
or on inclines and cause injuries.

Always hold doors by the door handle while opening and

closing.

NOTICE

Check to make sure that the windows go down slightly when you
unlock the vehicle. Otherwise the windows and seals could be
damaged when opening the door.

Display

Please first read and note the introductory information and

heed the WARNINGS

Lights up

Possible cause

Proper response

Icon appears in

the display

At least one vehicle
door is open or im-
properly closed.

Stop!

Open and close the door
again.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
If a door is not closed properly, the vehicle icon appears in the in-
strument cluster display showing an open door

⇒

fig. 10

⇒

fig. 11

Depending on your vehicle's equipment and options, the icon may still
be displayed even after the ignition is switched off as long as the key
has not been taken out of the ignition. The icon in the instrument clus-
ter display goes out about 15 seconds after the vehicle has been
locked.

Child safety lock

Fig. 31 In the left rear door: Child safety lock A deactivated, B acti-
vated.

Fig. 32 In the right rear door: Child safety lock A deactivated, B acti-
vated.

Please first read and note the introductory information and

heed the WARNINGS

The child safety lock keeps the rear doors from being opened from
the inside, so that children cannot open them accidentally. When the
child safety lock is engaged, the rear doors can only be opened from
the outside.

Engaging or disengaging child safety lock

Unlock the vehicle and open the respective rear door.
Using the emergency key, move the slot into the desired position.

Slot position

⇒

fig. 31

⇒

fig. 32

(A)

Child safety lock disengaged.

(B)

Child safety lock engaged.

WARNING

When the child safety lock is engaged, that rear door cannot be
opened from the inside.

Never leave children, disabled persons, or anyone who can-

not help themselves, in the vehicle when locking the doors.
This could result in people being locked in the vehicle. This
could result in people being trapped in the vehicle in an emer-
gency. Depending on the time of year, people trapped in the
vehicle can be exposed to very high or very low temperatures.

A closed vehicle can become very hot or very cold, depend-

ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.

Luggage compartment lid

Introduction

In this section you’ll find information about:
Display
Opening the luggage compartment lid
Opening the luggage compartment lid
Closing the luggage compartment lid
Sensor-controlled luggage compartment lid opener (Easy Open)

More information:

Exterior views
Power locking system
Transporting
Emergency closing and opening

WARNING

Accidents and severe personal injuries can result if you unlock,
open, or close the luggage compartment lid when someone is
in the way.

Only open or close the luggage compartment lid if no one is

in the way.

After closing the luggage compartment lid, always make sure

that it is properly closed and locked so that it cannot open sud-
denly when the vehicle is moving. The closed luggage com-
partment lid must be flush with the surrounding auto body
parts.

Always keep the luggage compartment lid closed while driv-

ing to help keep poisonous exhaust gas from being drawn into
the vehicle.

Never open the luggage compartment lid when a luggage

rack is installed and loaded. If, for example, there are bicycles
on a carrier on the luggage compartment lid, it is possible that
the lid will not be able to open automatically. An open luggage
compartment lid may fall on its own because of the additional
weight. If necessary, prop open the luggage compartment lid.
Remove the weight from the luggage rack first.

Close and lock the luggage compartment lid and all doors

when the vehicle is not in use. First, make sure that no one is
left inside the vehicle.

Never leave your vehicle unattended or let children play

around your vehicle, especially when the luggage compartment
lid is open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to
get out. A closed vehicle can become very hot or very cold, de-
pending on the season. Particularly in the summer, heat
buildup in the passenger and luggage compartment of a parked
vehicle can result in temperatures in the vehicle that are much
higher than the outside temperatures. Temperatures can quick-
ly reach levels that can cause unconsciousness and death, par-
ticularly to small children.

Never leave children or anyone who cannot help themselves

behind in the vehicle. They may lock the vehicle with the vehi-
cle key or the power locking button and lock themselves in.

NOTICE

Before opening or closing the luggage compartment lid, make
sure there is enough room to do so, for example, when the vehi-
cle has a trailer or is in a garage.

NOTICE

Never use the gas strut to hold or clamp a load in place. This can
damage the luggage compartment lid and make it impossible to
close.

Display

Please first read and note the introductory information and

heed the WARNINGS

Lights up

Possible cause

Proper response

Icon appears in

the display

Luggage compart-
ment lid open or im-
properly closed.

Stop!

Open the luggage com-
partment lid and then
close it again.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
If the luggage compartment lid is not closed properly, the vehicle icon
appears in the instrument cluster display showing an open luggage
compartment lid

⇒

fig. 10

⇒

fig. 11

WARNING

If the luggage compartment lid is not closed properly, it may
open suddenly when the vehicle is moving and cause severe
injuries.

Stop immediately and close the luggage compartment lid.
Always make sure the luggage compartment lid is securely

latched after you close it.

Opening the luggage compartment lid

Fig. 33 A: In the remote control vehicle key: Button to unlock and
open the luggage compartment lid. B: In the driver door: Switch to
unlock and open the luggage compartment lid.

Fig. 34 Opening luggage compartment lid from the outside.

Please first read and note the introductory information and

heed the WARNINGS

Always remove any item(s) being transported on the luggage com-
partment lid before opening it

⇒ .

Unlocking and opening with the vehicle key

Press and hold the

button on the remote control vehicle key

⇒

fig. 33

A to unlatch and automatically open the luggage compart-

ment lid.

Unlocking and opening with the unlock switch in the driver door

Pull up the

switch on the driver door

⇒

fig. 33

B until the luggage

compartment lid opens automatically.
The switch in the driver door also works when the ignition is switched
off.

Unlocking and opening with the sensor-controlled luggage
compartment lid opener (Easy Open)
If your vehicle has Keyless Access, it may also be equipped with the
Easy Open feature. With Easy Open, the luggage compartment lid
can be opened with a motion sensor in the area below the rear
bumper

⇒ Sensor-controlled luggage compartment lid opener (Easy

Open).

Opening with the Volkswagen emblem

Unlock the vehicle or the luggage compartment lid, or open a door.
Using your thumb, press the top of the Volkswagen emblem

⇒

fig. 34

and move the top of the emblem down. The luggage com-

partment lid opens automatically.

WARNING

Improper or unsupervised unlocking or opening of the luggage
compartment lid can cause severe injuries. Never open the lug-
gage compartment lid when someone is in the way.

If a bicycle or luggage rack is installed on the luggage com-

partment lid, it may be hard to see that the luggage compart-
ment lid is unlatched. An unlatched luggage compartment lid
may open suddenly when the vehicle is moving.

At temperatures below +32 °F (0 °C), the luggage compartment

lid may not open automatically after you unlock it. It will be necessary
to lift it by hand.

Closing the luggage compartment lid

Fig. 37 Opened luggage compartment lid: Recessed grips for closing.

Please first read and note the introductory information and

heed the WARNINGS

Closing the luggage compartment lid

Grasp one of the recessed grips in the trim of the luggage com-

partment lid

⇒

fig. 37

(arrows).

Pull the luggage compartment lid down and close it securely so that

the latch engages.

Check the luggage compartment lid to make sure it is securely

latched.

Locking the luggage compartment lid
If you unlock the vehicle with the vehicle key, but do not open either a
door or the luggage compartment lid in about the next 30 seconds,
the vehicle is automatically locked again. This feature helps prevent
you from leaving the vehicle unlocked unintentionally.
It is only possible to lock the luggage compartment lid when it is se-
curely closed and latched.

The power locking system also locks the luggage compartment lid.
If the luggage compartment lid of a locked vehicle is unlocked with

the

button on the remote control vehicle key, it will lock about

20 seconds after it is closed. The anti-theft alarm system is activated
after the vehicle is locked

A closed but unlocked luggage compartment lid automatically locks

at speeds above about 5 mph (10 km/h).

The luggage compartment lid can also be locked manually with the

emergency key via the key switch in the driver door

⇒ Driver door

overview. When the luggage compartment lid has been locked manu-
ally with the emergency key, it cannot be opened using the

button

on the remote control vehicle key or the

switch inside the driver

door.

WARNING

Improper or unsupervised closing of the luggage compartment
lid can cause severe injuries. Never close the luggage com-
partment lid when someone is in the way.

Never leave your vehicle unattended or let children play

around your vehicle, especially with the luggage compartment
lid left open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to
get out. A closed vehicle can become very hot or very cold de-
pending on the season. Temperatures can quickly reach levels
that can cause unconsciousness or death, particularly to small
children.

Make sure that the remote control vehicle key is not in the lug-

gage compartment before closing the luggage compartment lid.

Sensor-controlled luggage compartment lid opener (Easy Open)

Fig. 38 Keyless Access locking and starting system: Opening the
sensor-controlled luggage compartment lid (Easy Open), if equipped.

Please first read and note the introductory information and

heed the WARNINGS

If your vehicle has Keyless Access, it may also be equipped with the
Easy Open feature.
When a valid vehicle key is within range of the luggage compartment
lid

⇒

fig. 27

, the luggage compartment lid can be unlocked and

opened by moving your foot within the sensor’s range

⇒

fig. 38

below

the rear bumper.

Switch off the ignition.
Stand behind the middle of the rear bumper.
Quickly move your foot and shin as close to the bumper as possi-

ble. Your shin must be in the upper part of the sensor’s range and
your foot in the lower part

⇒

fig. 38

(1)

Quickly move your shin out of range

⇒

fig. 38

(2)

. The luggage

compartment lid opens automatically.
If the luggage compartment lid does not open, wait a few seconds
and try again.
The high-mounted brake light flashes once to show that the Easy
Open feature is opening the luggage compartment lid.
The luggage compartment lid locks automatically after closing if the
vehicle was locked before and a valid vehicle key is not inside the
vehicle.
Easy Open may not work properly or at all in the following situations
(examples):

If the rear bumper is very dirty.
If the rear bumper has salty water on it after driving on salted

roads.

If a trailer hitch has been retrofit on the vehicle.

Easy Open may be automatically deactivated in heavy rain to help
prevent unintentional deployment caused by water running down the
vehicle, for example.
The Easy Open feature may be turned on and off in the Settings –
Convenience menu

⇒ Volkswagen Information System.

WARNING

Careless use of the Easy Open feature can cause falls and seri-
ous personal injury.

Always make sure you have firm footing when using the Easy

Open feature, and that the surface you are standing on is not
uneven or slippery.

Never use Easy Open feature unless you can use it safely.

CAUTION

If a valid vehicle key is within range of the luggage compart-
ment lid, the Easy Open feature can deploy unintentionally in
some cases and open the luggage compartment lid: for exam-
ple, when sweeping the ground or floor below the rear bumper,
if there is a strong stream of water or steam, or when carrying
out maintenance or repairs around the rear bumper. If the lug-
gage compartment lid opens unintentionally, it can injure any-
one or damage anything in its way.

Never leave a valid vehicle key within range of the luggage

compartment lid unattended.

Always turn off the Easy Open feature through the

Volkswagen Information System

⇒ Volkswagen Information

System in the following situations:
– Before carrying out any maintenance or repairs on the ve-

hicle.

– Before washing the vehicle.
– Before mounting a bicycle rack or connecting a trailer hitch

to the vehicle.

Power windows

Introduction

In this section you’ll find information about:
Opening or closing power windows
Power windows – features
Power window pinch protection

More information:

Volkswagen Information System
Power locking and closing system

WARNING

Improper use of power windows can result in serious personal
injury.

Never let anyone get in the way of a power window when

closing it.

When locking the vehicle from the outside, make sure that no

one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.

Always take the key with you when you leave the vehicle. You

can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.

Always use the safety switch when children are in the back

seat to disable the rear power windows and keep them from be-
ing opened and closed.

NOTICE

If you leave the windows open, rain or other precipitation may
enter the vehicle from outside and can damage the vehicle inte-
rior.

Volkswagen CC (2015 year). Instruction - part 5
