Volkswagen CC (2015 year). Instruction

Opening or closing power windows

Fig. 39 In the driver door: Switches for the power windows.

Please first read and note the introductory information and

heed the WARNINGS

Switches in the driver door
Key to

fig. 39

(1)

For the windows in the front doors.

(2)

For the windows in the rear doors.

(3)

Safety switch.

Opening or closing windows

Function

Action

Opening:

Press the

switch.

Closing:

Pull the

switch.

Stopping automatic
movement:

Press/pull the respective
switch again.

The safety switch

(3)

deac-

tivates the power windows in
the rear doors. The yellow
indicator light in the switch
comes on.

You can still use the power windows for several minutes after the igni-
tion is switched off as long as the driver or front passenger door has
not been opened. When the vehicle key has been removed from the

ignition and the driver door has been opened, the power windows
cannot be opened or closed.

A separate button for controlling the window is located in the front

passenger door.

Power windows – features

Please first read and note the introductory information and

heed the WARNINGS

Automatic lowering of the windows
Closed windows in the doors will go down slightly when the vehicle is
unlocked, the door handle is pulled, and after the vehicle key has
been removed from the ignition

⇒ .

For vehicles with the single door unlocking function activated,
only the window in the driver door will go down slightly when the vehi-
cle is unlocked from the outside. The windows in the other doors will
also go down slightly if the vehicle is unlocked a second time.
If no doors are opened, the windows will close again after several
seconds. The windows will also close if the door is closed or the vehi-
cle is locked.
The windows can freeze to the seals at low outside temperatures and
prevent the windows from going down when the vehicle is unlocked
or the door is opened. Do not open the door if the window does
not go down slightly

⇒ .

Lock the vehicle again.
Remove the ice with deicing spray.
Unlock the vehicle and retry the function.
If necessary, repeat until the windows are fully operational.

One-touch opening and closing
The one-touch feature automatically opens/closes a power window all
the way. The window switch does not have to be held down/up.
For one-touch opening: Press the switch for the window down brief-
ly as far as it goes.

For one-touch closing: Pull the switch for the window up briefly as
far as it goes.
Stopping automatic movement: Pull/press the switch again.

Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not
completely closed, the one-touch feature will not work and must be
reactivated:

Switch on the ignition.
Close all windows and doors.
Pull up the switch for the respective window and hold it for at least

2 seconds in this position.

Release the switch, pull up and hold again. The one-touch feature

is now reactivated.
The one-touch feature can be reactivated for one or more windows at
the same time.

Convenience closing
The convenience closing feature lets you close the windows and the
power sunroof as follows:

On vehicles with Keyless Access, using the door handle sensors

⇒

Power locking and closing system.

From inside the vehicle, pull up and hold the switch for the driver

window until all windows and the sunroof are closed

⇒ Power locking

and closing system.
Convenience closing first closes the windows and then the power
sunroof. All turn signals blink once to confirm that the windows and
power sunroof are closed.

WARNING

Improper use of power windows can result in serious personal
injury.

Never let anyone get in the way of a power window when

closing it.

When locking the vehicle from the outside, make sure that no

one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.

Always take the key with you when you leave the vehicle. You

can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.

Always use the safety switch when children are in the back

seat to disable the rear power windows and keep them from be-
ing opened and closed.

NOTICE

The windows must go down slightly when you unlock the vehi-
cle. Otherwise the windows and seals could be damaged when
opening the doors.

If the power windows malfunction, the one-touch feature, as well

as pinch protection may not work properly. See an authorized
Volkswagen dealer or authorized Volkswagen Service Facility right
away.

Power window pinch protection

Please first read and note the introductory information and

heed the WARNINGS

Pinch protection can help reduce the risk of pinching injuries when
closing a power window

⇒ . If one-touch window closing meets

resistance or there is something in the way, the window will stop and
go down again.

Check why the window did not close.
Try one-touch window closing again.

If the window meets resistance a second time, so that it stops and

goes back down, one-touch closing is deactivated for about
10 seconds.

If you pull the power window button up all the way and hold it dur-

ing this 10 second interval, the window will close without pinch pro-
tection

⇒ .

Closing the window without pinch protection

Try to close the window again within 10 seconds by holding the

switch. Pinch protection is turned off for a short distance in the
window track!

If closing takes longer than about 10 seconds, pinch protection is

turned on again. The window stops again if there is resistance.

If the window still will not close, please see an authorized

Volkswagen dealer or an authorized Volkswagen Service Facility.

WARNING

Without pinch protection, power windows will close with
enough force to cause serious personal injury.

Always be careful when closing power windows.
Always make sure that no one is in the way when overriding

pinch protection to close power windows!

Pinch protection cannot prevent fingers or other parts of the

body from being pressed against the window frame; injuries
may result.

Pinch protection is also active during convenience closing of the

windows and the power sunroof

⇒ Power windows – features.

Power sunroof

Introduction

In this section you’ll find information about:
Opening or closing the power sunroof
Power sunroof – convenience closing feature
Pinch protection for the power sunroof

Depending on equipment, the vehicle may be equipped with a Pano-
ramic tilting sunroof.

More information:

Volkswagen Information System
Power locking and closing system
Emergency closing and opening

WARNING

Improper use of the power sunroof can result in serious per-
sonal injury.

Always make sure that no one is in the way of the power sun-

roof when it is closing.

Always take the key with you when you leave the vehicle.
Never leave children or disabled persons in the vehicle – par-

ticularly if they have access to the vehicle key. Unsupervised
use of the remote control vehicle key makes it possible to lock
the vehicle, start the engine, turn on the ignition and operate
the sunroof.

You can still open or close the power sunroof for several

minutes after you switch off the ignition, as long as the driver
or front passenger door has not been opened.

NOTICE

To help prevent damage, remove ice and snow from the sun-

roof before opening or tilting it in winter weather.

Always close the sunroof before leaving the vehicle or if it be-

gins raining. If the sunroof is open or tilted, rain could enter the

vehicle interior and cause extensive damage to the electrical
system. This could result in further vehicle damage.

Remove leaves and other objects from the sunroof guiderails

regularly either by hand or using a vacuum cleaner.

If the power sunroof malfunctions, pinch protection may not func-

tion properly. See an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.

Opening or closing the power sunroof

Fig. 40 In the headliner: Switch for the power sunroof.

Please first read and note the introductory information and

heed the WARNINGS

Function

Action

To tilt fully:

Briefly press the

switch.

To stop the one-touch
feature:

Briefly press the

switch again.

To close fully:

Briefly pull the

switch.

To set an intermediate
position:

Hold the

switch until the desired position

is reached.

You must switch on the ignition to operate the power sunroof. After
switching off the ignition, you can still open or close the power sun-

roof for a short time as long as the driver or front passenger door has
not been opened.

Sliding headliner
Use the handle in the front area of the roof opening to move the slid-
ing headliner to the desired position.

Power sunroof – convenience closing feature

Please first read and note the introductory information and

heed the WARNINGS

Convenience closing
The convenience closing feature lets you close the power sunroof as
follows:

Remove the cover cap from the concealed lock cylinder on the

driver door

⇒ Manually unlocking and locking the driver door.

Turn the vehicle key bit in the lock of the driver door to the closing

position and hold it there

⇒ Power locking and closing system. The

power sunroof now closes. Release the vehicle key in order to stop
the process.

On vehicles with Keyless Access, use the door handle sensors

⇒

Power locking and closing system.
Convenience closing first closes the windows and then the power
sunroof.

Convenience closing of the power sunroof from the outside re-

quires removing the cover cap of the lock cylinder on the driver door.
The cover cap must be reinserted when the vehicle is locked

⇒ Man-

ually unlocking and locking the driver door.

Pinch protection for the power sunroof

Please first read and note the introductory information and

heed the WARNINGS

Pinch protection can help reduce the risk of pinching injuries when
closing the power sunroof

⇒ . If the power sunroof closing meets

resistance or there is something in the way, the power sunroof opens
again immediately.

Check why the power sunroof did not close.
Try to close the power sunroof again by pulling the

switch brief-

ly.

If the power sunroof still cannot close, the power sunroof will stop

where the resistance is located. The power sunroof will close the next
time without pinch protection.

Closing the power sunroof without pinch protection

Within 5 seconds after the pinch protection was triggered, pull the

switch

⇒

fig. 40

until the power sunroof closes completely.

The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized

Volkswagen dealer or an authorized Volkswagen Service Facility.

WARNING

Careless or unsupervised use of the sunroof can cause serious
injuries.

Always make sure that no one is in the way of the power sun-

roof when it is closing.

Always take all vehicle keys with you when leaving the vehi-

cle.

Never leave children or persons requiring assistance unat-

tended in the vehicle, especially if they have access to the ve-
hicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and
operate the sunroof.

The sunroof can still be opened or closed for a short period

after the ignition has been switched off, as long as the driver or
passenger door is not opened.

WARNING

Without pinch protection, the power sunroof will close with
enough force to cause serious personal injury.

Always be careful when closing the power sunroof.
Always make sure that no one is in the way when overriding

the pinch protection to close the power sunroof!

Pinch protection cannot prevent fingers or other parts of the

body from being pressed against the edge of the roof; injuries
may result.

Pinch protection is also active during convenience closing of the

windows and the power sunroof

⇒ Convenience closing.

If the power sunroof malfunctions, pinch protection may not func-

tion properly. See an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility for assistance.

HomeLink

Universal Transmitter

Introduction

In this section you’ll find information about:
Programming the HomeLink

Universal Transmitter

Operating the HomeLink

Universal Transmitter

Depending on vehicle equipment, the vehicle may be equipped with a
Homelink

Universal Transmitter.

The HomeLink

Universal Transmitter in your vehicle can be used to

open/close an automatic garage door or gate, activate a house alarm,
or control a lighting system or other devices. Such devices usually
come with a hand-held remote control that sends a signal to a control-
ler to operate the device.
These instructions will help you program the HomeLink

Universal

Transmitter in your vehicle so that you will not have to use the hand-
held remote control that was supplied with the garage door opener or
other device, inside your vehicle.

Fixed code or rolling code
The garage door opener or other device may work with either a fixed
or rolling code. For garage door openers or other devices with rolling
codes, the HomeLink

Universal Transmitter must be synchronized

after programming the device

⇒ Programming the HomeLink® Uni-

versal Transmitter.

Compatibility
Volkswagen recommends that you consult an authorized Volkswagen
dealer or authorized Volkswagen Service Facility about compatible
devices before you buy a garage door opener or other device that
you want to control with the HomeLink

Universal Transmitter.

The HomeLink

Universal Transmitter can be programmed to the

radio frequency codes of most current hand-held remote controls.
Safety switches are mandatory for garage door openers.
A Declaration of Compliance with the United States FCC and Industry
Canada regulations is found on

⇒ Declaration of Compliance, Tele-

communications and Electronic Systems.

DANGER

20 mm button cells and other lithium batteries will cause seri-
ous personal injury and even death within a short time if swal-
lowed.

Always keep hand-held remote control devices with batteries,

spare batteries, as well as dead button cell and larger 20 mm
batteries out of the reach of children.

Get medical attention immediately if you suspect that a bat-

tery has been swallowed.

WARNING

Improper use of the HomeLink

Universal Transmitter can

cause serious or even fatal personal injury.

Garage doors operate with enough force to cause serious

personal injury.

Never let anyone get in the way of a garage door when it is

opening or closing.

When programming the HomeLink

Universal Transmitter,

you may be operating a garage door or estate gate. Always
make sure that people and objects are out of the way to help
prevent serious personal injury or property damage.

When operating the “training” button on a garage door open-

er with a rolling code, you will need to stand on a ladder or
step-stool. Always take extra precautions to prevent falls and
serious injury.

Never use the HomeLink

Universal Transmitter with any gar-

age door opener that does not have the safety stop-and-reverse
feature, as required by federal safety standards. This includes
any garage door opener model manufactured before April 1,
1982.

A garage door opener that cannot detect an object, signaling

the door to stop and reverse, does not meet current federal
safety standards. Using a garage door opener without these
features increases the risk of serious injury or death.

Follow the installation manual and the included safety infor-

mation from the manufacturer when using the remote-
controlled garage door opener or electrical drive.

Programming the HomeLink

Universal Transmitter

Fig. 41 In the driver side sun visor: The remote control and buttons
for the HomeLink Universal Transmitter.

Fig. 42 To program: Simultaneously press the buttons for the
HomeLink Universal Transmitter and the remote control.

Please first read and note the introductory information and

heed the WARNINGS

Getting ready to program

Please read the product manufacturer's instructions before pro-

gramming the garage door opener or other device.

Safely park the vehicle within range of the device to be pro-

grammed.

Switch the ignition on, but do not start the engine.

The buttons 1, 2, and 3 on the keypad in the sun visor can operate
up to 3 separate devices (for example, a gate and garage door,
house alarm or lighting system).

Please carry out each step only in the order specified:

For first time programming only: Press and hold the two

outer HomeLink buttons 1 and 3 at the same time for about 20
seconds, releasing only when the HomeLink indicator light
above button 2 begins to flash.
This step deletes any old settings. Do not perform this step
when programming the additional HomeLink buttons.

Position the hand-held transmitter for your remote control de-

vice 1-3 inches (25-75 mm) away from the HomeLink keypad
on the driver side sun visor, keeping the HomeLink indicator
light in view, as shown

⇒

fig. 41

Using both hands, simultaneously press and hold both the

HomeLink button you want to program (1, 2, or 3) and the
hand-held transmitter button, as shown

⇒

fig. 42

. Do not re-

lease the buttons until the HomeLink indicator light flash-
es slowly and then rapidly. When the indicator light flashes
rapidly, release both buttons. The rapid flashing indicates suc-
cessful programming.

Press and hold the programmed HomeLink button and watch
the indicator light.
If the indicator light comes on and does not flash, programming
is complete and your garage door opener or other device
should activate when the HomeLink button is pressed and re-
leased.
If the indicator light blinks rapidly for 2 seconds and then stays
on, proceed with the following programming instructions for a
rolling code device. A second person may make the following
steps quicker and easier. Please use a ladder or other device.
Do not stand on your vehicle to perform the next steps

⇒ in

Operating the HomeLink® Universal Transmitter

Please carry out each step only in the order specified:

At the garage door opener receiver (overhead unit) in the gar-
age, locate the “learn” or “training” button. The name and color
of the button may vary by manufacturer. This button is usually
located near the hanging antenna wire attachment point on the
unit. If you cannot locate the “training” button, refer to the gar-
age door opener’s user manual.

Press and release the “training” button.

Once the button is pressed, you have 30 seconds to initi-
ate the next step.

Return to the vehicle. Firmly press and hold the programmed

HomeLink button for 2 seconds and release.

Repeat the “press/hold/release” sequence up to 3 times to
complete the programming process for that button.

Repeat the steps to program the other buttons for the HomeLink

Universal Transmitter on the sun visor keypad to control other devic-
es.

Deleting programming for all buttons
Be sure to delete programming on all buttons on the sun visor keypad
before selling the vehicle or turning it over to people you do not know.

Complete the programming preparation steps described above.
Press and hold buttons 1 and 3 at the same time, for about 20

seconds.

When the indicator light above button 2 begins to flash, immediate-

ly release buttons 1 and 3. This step deletes all old settings.

After programming
Test the garage door opener

Operating the HomeLink

Universal Transmitter

Please first read and note the introductory information and

heed the WARNINGS

The vehicle must be in operating range of the garage or outer gate

drives.

With ignition turned on or engine running, press the appropriate

button on the sun visor

⇒ .

The range of the HomeLink

Universal Transmitter roughly corre-

sponds to the range of the original remote control of the device or the
electrical drive. If the garage door or the electrical drive does not
work, this could be for one of the following reasons:

Malfunction

Possible cause

Possible remedy

Garage door or
electrical drive
does not work.

Distance or trans-
mission angle too
great.

Try different distances and
angles to the receiver.

Garage door or
electrical drive not
compatible.

May not comply with legal
requirements and may have
to be replaced.

Incorrect
programming.

Reprogram the garage door
opener.

DANGER

20 mm button cells and other lithium batteries will cause seri-
ous personal injury and even death within a short time if swal-
lowed.

Always keep hand-held remote control devices with batteries,

spare batteries, as well as dead button cell and larger 20 mm
batteries out of the reach of children.

Get medical attention immediately if you suspect that a bat-

tery has been swallowed.

Volkswagen CC (2015 year). Instruction - part 6
