Toyota Prius (2024 year). Manual in english

449

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca



Type A

Normal fuse
Blown fuse



Type B

Normal fuse
Blown fuse



Type C

Normal fuse
Blown fuse

■

After a fuse is replaced

●

When installing the lid, make sure

that the tab is installed securely.

●

If the lights do not turn on even

after the fuse has been replaced,

a lights may need replacement.

(



P.451)

●

If the replaced fuse blows again,

have the vehicle inspected by

your Toyota dealer.

■

If there is an overload in a cir-

cuit

The fuses are designed to blow,

protecting the wiring harness from

damage.

■

When replacing an electronic

component, such as a lights,

etc.

Toyota recommends that you use

genuine Toyota products designed

for this vehicle.

Because certain electronic compo-

nents are connected to circuits

designed to prevent overload, non-

genuine parts not designed for this

vehicle may be unusable.

WARNING

■

To prevent system break-

downs and vehicle fire

Observe the following precau-

tions.

Failure to do so may cause dam-

age to the vehicle, and possibly a

fire or injury.

●

Never use a fuse of a higher

amperage rating than that indi-

cated, or use any other object in

place of a fuse.

●

Always use a genuine Toyota

fuse or equivalent.

Never replace a fuse with a

wire, even as a temporary fix.

●

Do not modify the fuses or fuse

boxes.

450

6-3. Do-it-yourself maintenance

Adjustment bolt A
Adjustment bolt B



Make sure the vehicle has a

full tank of gasoline and the

area around the headlight is

not deformed.



Park the vehicle on level

ground.



Make sure the tire inflation

pressure is at the specified

level.



Have someone sit in the

driver’s seat.



Bounce the vehicle several

times.

NOTICE

■

Before replacing fuses

Have the cause of electrical over-

load determined and repaired by

your Toyota dealer as soon as

possible.

■

To prevent damage to the

engine compartment fuse box

cover

When opening the fuse box, com-

pletely release the claw locks

before lifting up the cover. Other-

wise, the claws may be damaged.

Headlight aim

Vertical movement adjust-

ing bolts

Before checking the head-

light aim

451

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

Using a Phillips-head screw-
driver, turn bolt A in either
direction.

Remember the turning direction
and the number of turns.

Turn bolt B the same number
of turns and in the same
direction as step

If the headlight cannot be adjusted
using this procedure, take the vehi-
cle to your Toyota dealer to adjust
the headlight aim.

■

LED lights

The lights consist of a number of
LEDs. If any of the LEDs burn out,
take your vehicle to your Toyota
dealer to have the light replaced.

■

Condensation build-up on the
inside of the lens

Temporary condensation build-up
on the inside of the light lens does
not indicate a malfunction. Contact
your Toyota dealer for more infor-
mation in the following situations:

●

Large drops of water have built up
on the inside of the lens.

●

Water has built up inside the light.

■

When replacing an electronic
component, such as a lights,
etc.



P.449

Adjusting the headlight
aim

Exterior lights

If any exterior light does not
turn on, have it replaced by
your Toyota dealer.

453

Whe

ouble

rises

When trouble arises

7-1. Essential information

Emergency flashers ....

454

If your vehicle has to be

stopped in an emergency

..................................

455

If the vehicle is submerged

or water on the road is ris-
ing .............................

456

7-2. Steps to take in an emer-

gency

If your vehicle needs to be

towed.........................

458

If you think something is

wrong ........................

462

If a warning light turns on or

a warning buzzer sounds

..................................

464

If a warning message is dis-

played........................

476

If you have a flat tire (vehi-

cles without spare tire)

..................................

484

If you have a flat tire (vehi-

cles with spare tire) ...

496

If the hybrid system will not

start ...........................

504

If you lose your keys ...

505

If the electronic key does

not operate properly ..

506

If the 12-volt battery is dis-

charged .....................

508

If your vehicle overheats

..................................

513

If the vehicle becomes

stuck ..........................

516

454

7-1. Essential information

7-1.Essential information

Press the switch.

All the turn signal lights will flash.

To turn them off, press the switch
once again.

■

Emergency flashers

●

If the emergency flashers are
used for a long time while the
hybrid system is not operating
(while the “READY” indicator is
not illuminated), the 12-volt bat-
tery may discharge.

●

If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the emergency flash-
ers will turn on automatically.
The emergency flashers will turn
off automatically after operating
for approximately 20 minutes. To
manually turn the emergency
flashers off, press the switch
twice. (The emergency flashers
may not turn on automatically
depending on the force of the
impact and conditions of the colli-

sion.)

Emergency flashers

The emergency flashers are
used to warn other drivers
when the vehicle has to be
stopped in the road due to a
breakdown, etc.

Operating instructions

455

7-1. Essential information

tro

le a

ris

Steadily step on the brake

pedal with both feet and

firmly depress it.

Do not pump the brake pedal

repeatedly as this will increase the

effort required to slow the vehicle.

Shift the shift position to N.



If the shift position is shifted to

After slowing down, stop the

vehicle in a safe place by the

road.

Stop the hybrid system.



If the shift position cannot be

shifted to N

Keep depressing the brake

pedal with both feet to reduce

vehicle speed as much as

possible.

To stop the hybrid system,

press and hold the power

switch for 2 consecutive sec-

onds or more, or press it

briefly 3 times or more in suc-

cession.

Stop the vehicle in a safe

place by the road.

■

If emergency stopped

The functions of the air conditioning,

etc. may be partially limited in order

to reduce the power consumption of

the 12-volt battery.

If your vehicle has to

be stopped in an emer-

gency

Only in an emergency, such

as if it becomes impossible

to stop the vehicle in the

normal way, stop the vehi-

cle using the following pro-

cedure:

Stopping the vehicle

WARNING

■

If the hybrid system has to be

turned off while driving

Turning the hybrid system off

while driving will not cause loss of

steering or braking control. How-

ever, power assist for the steering

wheel may be lost making it diffi-

cult to steer smoothly before stop-

ping the vehicle depending on the

remaining charge in the 12-volt

battery or usage conditions.

Decelerate as much as possible

before turning off the hybrid sys-

tem.

456

7-1. Essential information



If the door can be opened,
open the door and exit the
vehicle.



If the door cannot be opened,
open the window using the
power window switch and
ensure an escape route.



If the window can be opened,
exit the vehicle through the
window.



If the door and window cannot
be opened due to the rising
water, remain calm, wait until
the water level inside the
vehicle rises to the point that
the water pressure inside of
the vehicle equals the water
pressure outside of the vehi-
cle and then open the door
after waiting for the rising
water to enter the vehicle, and
exit the vehicle.

When the outside water level
exceeds half the height of the door,
the door cannot be opened from the
inside due to water pressure.

■

Water level exceeds the floor

When the water level exceeds the
floor and time has passed, the elec-
trical equipment will get damaged,
the power windows will not operate,
the engine and motor stop, and the
vehicle may not be able to get mov-
ing.

■

Using an emergency escape
hammer

Laminated glass

is used in the

windshield and the windows on this
vehicle.

Laminated glass cannot be shat-
tered with an emergency hammer

: Contact your Toyota dealer or

aftermarket accessory manufac-
turer for further information about
an emergency hammer.

: If equipped

■

How to distinguish laminated
glass

When looking from the cross-sec-
tional view point, laminated glass is
two sheets of glass pasted together.

Laminated glass

Tempered glass

If the vehicle is sub-

merged or water on

the road is rising

This vehicle is not designed
to be able to drive on roads
that are deeply flooded with
water. Do not drive on roads
where the roads may be
submerged or the water
may be rising. It is danger-
ous to remain in the vehicle,
if it is anticipated that the
vehicle will be flooded or
set adrift. Remain calm and
follow the following.

458

7-2. Steps to take in an emergency

7-2.Steps to take in an emergency

In the following situations, it is
not possible to be towed by
another vehicle using cables or
chains, as the front wheels may
be locked due to the parking
lock. Contact your Toyota dealer
or commercial towing service.



There is a malfunction in the
shift control system.
(



P.182)



There is a malfunction in the
immobilizer system. (



P.79)



There is a malfunction in the
smart entry & start system.
(



P.506)



The 12-volt battery is dis-
charged. (



P.508)

The following may indicate a
problem with your transmission.
Contact your Toyota dealer or
commercial towing service
before towing.



The hybrid system warning
message is shown on the
multi-information display and
the vehicle does not move.



The vehicle makes an abnor-
mal sound.



From the front (FF vehicles)

Release the parking brake.

Turn automatic mode off.
(



P.194)

If your vehicle needs

to be towed

If towing is necessary, we
recommend having your
vehicle towed by your
Toyota dealer or commer-
cial towing service, using a
wheel-lift type truck or flat-
bed truck.

Use a safety chain system
for all towing, and abide by
all state/provincial and local
laws.

Situations when it is not
possible to be towed by
another vehicle

Situations when it is nec-
essary to contact dealers
before towing

Towing with a wheel-lift
type truck

459

7-2. Steps to take in an emergency

tro

le a

ris



From the front (AWD vehi-

cles)

Use a towing dolly under the

rear wheels.



From the rear

Use a towing dolly under the

front wheels.

WARNING

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

■

When towing the vehicle



FF vehicles

Be sure to transport the vehicle

with the front wheels raised or

with all four wheels raised off the

ground. If the vehicle is towed

with the front wheels contacting

the ground, the drivetrain and

related parts may be damaged or

electricity generated by the opera-

tion of the motor may cause a fire

to occur depending on the nature

of the damage or malfunction.

460

7-2. Steps to take in an emergency

When using a flat-bed truck to

transport the vehicle, use tire

strapping belts. Refer to the

owner’s manual of the flat-bed

truck for the tire strapping

method.

In order to suppress vehicle move-

ment during transportation, set the

parking brake and turn the power

switch off.

If a tow truck is not available in

an emergency, your vehicle may

be temporarily towed using

cables or chains secured to the

emergency towing eyelets.
This should only be attempted

on hard surfaced roads for short

distances at under 18 mph (30

km/h).
A driver must be in the vehicle to

steer and operate the brakes.

The vehicle’s wheels, drive

train, axles, steering and brakes

WARNING



AWD vehicles

Be sure to transport the vehicle

with all four wheels raised off the

ground. If the vehicle is towed

with the tires contacting the

ground, the drivetrain or related

parts may be damaged, the vehi-

cle may fly off the truck, or elec-

tricity generated by the operation

of the motor may cause a fire to

occur depending on the nature of

the damage or malfunction.

NOTICE

■

To prevent damage to the

vehicle when towing using a

wheel-lift type truck

When raising the vehicle, ensure

adequate ground clearance for

towing at the opposite end of the

raised vehicle. Without adequate

clearance, the vehicle could be

damaged while being towed.

■

Towing with a sling-type

truck

Do not tow with a sling-type truck

to prevent body damage.

Using a flatbed truck

Emergency towing

461

7-2. Steps to take in an emergency

Whe

ouble

rises

must be in good condition.

To have your vehicle towed by
another vehicle, the towing eye-
let must be installed to your
vehicle. Install the towing eyelet
using the following procedure.

Take out the wheel nut
wrench (if equipped) and
towing eyelet. (



P.485, 497)

Remove the eyelet cover
using a flathead screwdriver.

To protect the bodywork, place a
rag between the screwdriver and
the vehicle body as shown in the
illustration.

Insert the towing eyelet into
the hole and tighten partially
by hand.

Tighten down the towing eye-
let securely using a wheel nut
wrench or hard metal bar.

Securely attach cables or
chains to the towing eyelet.

Take care not to damage the vehi-
cle body.

Enter the vehicle being towed
and start the hybrid system.

Turn off the Parking Support Brake
function. (if equipped): (



P.305)

If the hybrid system does not start,
turn the power switch to ON.

Shift the shift position to N
and release the parking
brake.

Turn automatic mode off. (



P.194)

■

While towing

If the hybrid system is off, the power
assist for the brakes and steering
will not function, making steering
and braking more difficult.

■

Wheel nut wrench

●

Vehicles with wheel nut wrench:
Wheel nut wrench is installed in
luggage compartment. (



P.485,

497)

●

Vehicles without wheel nut
wrench: Wheel nut wrench can be
purchased at your Toyota dealer.

Emergency towing proce-
dure

462

7-2. Steps to take in an emergency



Fluid leaks under the vehicle

(Water dripping from the air

conditioning after use is nor-

mal.)



Flat-looking tires or uneven

tire wear



High coolant temperature

warning light flashes or

comes on



Changes in exhaust sound



Excessive tire squeal when

cornering



Strange noises related to the

suspension system



Pinging or other noises

related to the hybrid system



Engine missing, stumbling or

running roughly



Appreciable loss of power



Vehicle pulls heavily to one

WARNING

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

■

While towing

●

When towing using cables or

chains, avoid sudden starts, etc.

which place excessive stress on

the towing eyelets, cables or

chains. The towing eyelets,

cables or chains may become

damaged, broken debris may hit

people, and cause serious dam-

age.

●

Do not turn the power switch off.

This may lead to an accident as

the front wheels will be locked by

the parking lock.

■

Installing towing eyelets to

the vehicle

Make sure that towing eyelets are

installed securely. If not securely

installed, towing eyelets may

come loose during towing.

NOTICE

■

To prevent damage to the

vehicle during emergency

towing

Do not secure cables or chains to

the suspension components.

If you think something

is wrong

If you notice any of the fol-

lowing symptoms, your

vehicle probably needs

adjustment or repair. Con-

tact your Toyota dealer as

soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

464

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

If a warning light turns on or a warning buzzer

sounds

Calmly perform the following actions if any of the warning
lights comes on or flashes. If a light comes on or flashes, but
then goes off, this does not necessarily indicate a malfunc-
tion in the system. However, if this continues to occur, have
the vehicle inspected by your Toyota dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(Canada)

(red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe
place and contact your Toyota dealer.
Continuing to drive the vehicle may be
dangerous.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in:



The parking brake system;



The regenerative braking system; or



The electronically controlled brake system



Have the vehicle inspected by your Toyota
dealer immediately.

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging
system



Immediately stop the vehicle in a safe
place and contact your Toyota dealer.

465

7-2. Steps to take in an emergency

Whe

ouble

rises

■

High coolant temperature warning light (warning buzzer)

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Hybrid system overheat warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Malfunction indicator lamp

Warning light

Details/Actions

Indicates that the engine is overheating



Immediately stop the vehicle in a safe
place.
Handling method (



P.513)

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe
place and contact your Toyota dealer.
(



P.417)

Warning light

Details/Actions

Indicates that the hybrid system has overheated



Stop the vehicle in a safe place. Handling
method (



P.514)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The hybrid system;



The electronic engine control system;



The electronic throttle control system; or



The emission control system (if equipped)



Have the vehicle inspected by your Toyota
dealer immediately.

466

7-2. Steps to take in an emergency

■

SRS warning light (warning buzzer)

This warning light indicates problems with the following:



Airbag sensor assembly



Front impact sensors



Side impact sensors (front door)



Front passenger occupant classification sensors



Front passenger’s seat belt buckle switch



SRS warning light



“PASSENGER AIR BAG ON” indicator light



“PASSENGER AIR BAG OFF” indicator light



SRS airbags



SRS system related wiring harnesses and power sources

■

ABS warning light (warning buzzer)

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by your Toyota
dealer immediately.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by your Toyota
dealer immediately.

467

7-2. Steps to take in an emergency

Whe

ouble

rises

■

Electric power steering system warning light (warning
buzzer)

■

PCS warning light (warning buzzer)

■

LTA indicator (warning buzzer)

■

LDA indicator (warning buzzer)

Warning light

Details/Actions

(red)

(yellow)

Indicates a malfunction in the EPS (Electric
Power Steering) system



Have the vehicle inspected by your Toyota
dealer immediately.

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Colli-
sion System).



Follow the instructions displayed on the
multi-information display.

If the PCS (Pre-Collision System) or VSC (Vehi-
cle Stability Control) system is disabled, the
PCS warning light will illuminate.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the LTA (Lane Trac-
ing Assist)



Follow the instructions displayed on the
multi-information display.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the LDA (Lane Depar-
ture Alert)



Follow the instructions displayed on the
multi-information display.

468

7-2. Steps to take in an emergency

■

PDA indicator (warning buzzer)

■

Cruise control indicator (warning buzzer)

■

Dynamic radar cruise control indicator (warning buzzer)

■

Driving assist information indicator

Warning light

Details/Actions

(orange)

Indicates a malfunction in the PDA (Proactive
Driving Assist).



Follow the instructions displayed on the
multi-information display.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the cruise control sys-
tem.



Follow the instructions displayed on the
multi-information display.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the dynamic radar
cruise control system.



Follow the instructions displayed on the
multi-information display.

Warning light

Details/Actions

Indicates one of the following systems is mal-
functioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Follow the instructions displayed on the
multi-information display.

Indicates one of the following systems is mal-
functioning or disabled.



PKSB (Parking Support Brake) (if equipped)



RCD (Rear Camera Detection) (if equipped)



BSM (Blind Spot Monitor) (if equipped)



RCTA (Rear cross traffic alert) (if equipped)



Safe Exit Assist (if equipped)



Follow the instructions displayed on the
multi-information display.

469

7-2. Steps to take in an emergency

Whe

ouble

rises

■

Intuitive parking assist OFF indicator (warning buzzer)

■

Slip indicator light

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

Warning light

Details/Actions

When a buzzer sounds:
Indicates a malfunction in the Intuitive parking
assist function



Have the vehicle inspected by your Toyota
dealer immediately.

When a buzzer does not sound:
Indicates that the system is temporarily unavail-
able, possibly due to a sensor being dirty or cov-
ered with ice, etc.



Follow the instructions displayed on the
multi-information display. (



P.476)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota
dealer immediately.

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



Follow the instructions displayed on the
multi-information display.

When a buzzer does not sound:

Brake Override System is operating.



Release the accelerator pedal and
depress the brake pedal.

470

7-2. Steps to take in an emergency

■

Brake hold operated indicator (warning buzzer)

■

Parking brake indicator (warning buzzer)

■

Tire pressure warning light (warning buzzer)

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Toyota
dealer immediately.

Warning light

Details/Actions

(U.S.A.)

(Flashes)

(Canada)
(Flashes)

It is possible that the parking brake is not fully
engaged or released



Operate the parking brake switch once
again.

This light comes on when the parking brake is
not released. If the light turns off after the park-
ing brake is fully released, the system is operat-
ing normally.

Warning light

Details/Actions

When the light comes on after blinking for
approximately 1 minute (a buzzer does not
sounds):

Malfunction in the tire pressure warning system



Have the system checked by your Toyota
dealer.

When the light comes on (a buzzer sounds):



Low tire inflation pressure from natural causes



After the temperature of the tires has low-
ered sufficiently, check the inflation pres-
sure of each tire and adjust them to the
specified level.



Low tire inflation pressure from flat tire



Immediately stop the vehicle in a safe
place and perform the necessary actions.

471

7-2. Steps to take in an emergency

Whe

ouble

rises

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warn-
ing buzzer

)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the power switch is turned to ON, the
buzzer sounds. If the seat belt is still unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain
speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time
after the vehicle reaches a certain speed.

■

Rear passengers’ seat belt reminder light

(warning

buzzer

)

: Regardless of whether or not a rear passenger is present, this light will

Warning light

Details/Actions



AWD models

Indicates that remaining fuel is approximately
6.0 L (1.7 gal., 1.4 Imp. gal.) or less



2WD models

Indicates that remaining fuel is approximately
6.4 L (1.6 gal., 1.3 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fas-
ten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied,
the front passenger’s seat belt also needs
to be fastened to make the warning light
(warning buzzer) turn off.

Warning light

Details/Actions

Warns the rear passengers to fasten their seat
belts



Fasten the seat belt.

472

7-2. Steps to take in an emergency

also illuminate for a certain period of time after the rear door is opened
and closed.

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear
passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time,
after the seat belt is fastened and unfastened and the vehicle reaches a
certain speed.

■

Warning buzzer

In some cases, the buzzer may not
be heard because of noisy place or
an audio sound.

■

Front passenger detection sen-
sor, seat belt reminder and
warning buzzer

●

If luggage is placed on the front
passenger seat, the front passen-
ger detection sensor may cause
the warning light to flash and the
warning buzzer to sound even if a
passenger is not sitting in the
seat.

●

If a cushion is placed on the seat,
the sensor may not detect a pas-
senger, and the warning light may
not operate properly.

■

If the malfunction indicator
lamp comes on while driving

First check the following:

●

Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several
driving trips.

If the light does not go off even after
several trips, contact your Toyota
dealer as soon as possible.

■

Electric power steering system
warning light (warning buzzer)

When the 12-volt battery charge
becomes insufficient or the voltage
temporarily drops, the electric power
steering system warning light may

come on and the warning buzzer
may sound.

At this time, the functions of the air
conditioning, etc. may be partially
limited in order to reduce the power
consumption of the 12-volt battery.

■

When the tire pressure warning
light comes on

Inspect the tires to check if a tire is
punctured.

If a tire is punctured:



P.496, 484

If none of the tires are punctured:

Turn the power switch off then turn it
to ON.

Check if the tire pressure warning
light comes on or blinks.



If the tire pressure warning light
blinks for approximately 1 minute
then stays on

There may be a malfunction in the
tire pressure warning system. Have
the vehicle inspected by your
Toyota dealer immediately.



If the tire pressure warning light
comes on

After the temperature of the tires
has lowered sufficiently, check the
inflation pressure of each tire and
adjust them to the specified level.

If the warning light does not turn off
even after several minutes have
elapsed, check that the inflation
pressure of each tire is at the speci-
fied level and perform the tire infla-
tion pressure setting procedure.
(



P.436)

473

7-2. Steps to take in an emergency

tro

le a

ris

If the warning light does not turn off

even after several minutes have

elapsed since performing the tire

inflation pressure setting proce-

dure, have the vehicle inspected by

your Toyota dealer as soon as pos-

sible.

■

The tire pressure warning light

may come on due to natural

causes

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a

compact spare tire (vehicles

with compact spare tire)

The compact spare tire is not

equipped with a tire pressure warn-

ing valve and transmitter. If a tire

goes flat, the tire pressure warning

light will not turn off even though the

flat tire has been replaced with the

spare tire. Replace the spare tire

with the standard tire and adjust the

tire inflation pressure. The tire pres-

sure warning light will go off after a

few minutes.

■

Conditions that the tire pres-

sure warning system may not

function properly



P.428

WARNING

■

If a warning light comes on or

a warning buzzer sounds

when a warning message is

shown on the multi-informa-

tion display

Check and follow the message

shown on the multi-information

display.
Failure to do so may result in

death or serious injury.

: Warning lights illuminate in red

or yellow and the warning

buzzer beeps once or sounds

continuously.

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

If the steering wheel becomes

heavier than usual when operat-

ing, hold firmly and operate using

more force than usual.

■

If the tire pressure warning

light comes on

Be sure to observe the following

precautions. Failure to do so

could cause a loss of vehicle con-

trol and result in death or serious

injury.

●

Stop your vehicle in a safe

place as soon as possible.

Adjust the tire inflation pressure

immediately.

474

7-2. Steps to take in an emergency

WARNING

●

If the tire pressure warning light

comes on even after tire infla-

tion pressure adjustment, it is

probable that you have a flat

tire. Check the tires. If a tire is

flat, change it with the spare tire

and have the flat tire repaired by

the nearest Toyota dealer.

●

Avoid abrupt maneuvering and

braking. If the vehicle tires dete-

riorate, you could lose control of

the steering wheel or the

brakes.

■

If a blowout or sudden air

leakage should occur

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)

As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly under-

inflated. Accordingly, when the

low tire pressure telltale (tire pres-

sure warning light) illuminates,

you should stop and check your

tires as soon as possible, and

inflate them to the proper pres-

sure. Driving on a significantly

under-inflated tire causes the tire

to overheat and can lead to tire

failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping abil-

ity.
Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).

475

7-2. Steps to take in an emergency

tro

le a

ris

WARNING

Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.
TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly

Do not install tires with different

specifications or manufacturers

as the tire pressure warning sys-

tem may not operate properly.

477

7-2. Steps to take in an emergency

Whe

ouble

rises

: A buzzer sounds the first time a message is shown on the multi-informa-

tion display.

■

Warning messages

The warning messages explained
below may differ from the actual
messages according to operation
conditions and vehicle specifica-
tions.

■

If a message about an operation
is shown

●

If a message about an operation
of the accelerator pedal or brake
pedal is shown

• A warning message about an

operation of the brake pedal may
be shown while the driving assist
systems such as PCS (Pre-Colli-
sion system) or the dynamic radar
cruise control is operating. If a
warning message is shown, be
sure to decelerate the vehicle or
follow an instruction shown on the
multi-information display.

• A warning message is shown

when Brake Override System
operates. (



P.168, 483)

• A warning message is shown

when Drive-Start Control or Park-
ing Support Brake (if equipped)
(



P.173, 303) operates. Follow

the instructions on the multi-infor-
mation display.

●

If a message about an operation
of the power switch is shown

An instruction for operation of the
power switch is shown when the
incorrect procedure for starting the
hybrid system is performed or the
power switch is operated incorrectly.
Follow the instructions shown on the
multi-information display to operate
the power switch again.

●

If a message that indicates the
need for the shift lever operation
is displayed

Warning light

Warning

buzzer

Warning



Sounds



Indicates an important situation, such as
when a system related to driving is mal-
functioning or that danger may result if
the correction procedure is not per-
formed



Indicates a situation, such as when dam-
age to the vehicle or danger may result

Comes on or

flashes

Sounds

Indicates an important situation, such as
when the systems shown on the multi-
information display may be malfunctioning



Does not

sound



Indicates a condition, such as malfunc-
tion of electrical components, their con-
dition, or indicates the need for
maintenance



Indicates a situation, such as when an
operation has been performed incor-
rectly, or indicates how to perform an
operation correctly

478

7-2. Steps to take in an emergency

To prevent the shift lever from being
operated incorrectly or the vehicle
from moving unexpectedly, a mes-
sage that requires shifting the shift
position may be displayed on the
multi-information display.

In that case, follow the instruction of
the message and shift the shift posi-
tion.

●

If a message or image about an
open/close state of a part or
replenishment of a consumable is
shown

Confirm the part indicated by the
multi-information display or a warn-
ing light, and then perform the cop-
ing method such as closing the
open door or replenishing a con-
sumable.

■

If a message that indicates the
need for visiting your Toyota
dealer is displayed

The system or part shown on the
multi-information display is malfunc-
tioning. Have the vehicle inspected
by your Toyota dealer immediately.

■

If a message that indicates the
need for referring to Owner’s
Manual is displayed

●

If “Engine Coolant Temp High” is
shown, follow the instructions,
accordingly. (



P.513)

●

If the following messages are
shown, there may be a malfunc-
tion. Immediately have the vehi-
cle inspected by your Toyota
dealer.

• “Hybrid System Malfunction”
• “Check Engine”
• “Traction battery system malfunc-

tion”

• “Accelerator System Malfunction”
• “Smart Key System Malfunction”
• “Shift System Malfunction Apply

Parking Brake Securely When
Parking See Owner’s Manual”

• “P Switch Malfunction Apply Park-

ing Brake Securely When Parking

See Owner’s Manual”

• “Shift System Unavailable Apply

Parking Brake Securely When
Parking See Owner’s Manual”

• “Shift System Malfunction See

Owner’s Manual”

• “Shift System Malfunction Stop in

a Safe Place See Owner’s Man-
ual”

• “Battery Low Shifting Unavailable

See Owner’s Manual”

●

If the following messages are
shown, there may be a malfunc-
tion. Immediately stop the vehicle
in a safe place and contact your
Toyota dealer. Continuing to drive
the vehicle may be dangerous.

• “Oil pressure low”
• “Braking Power Low”

●

If any of the following messages
are shown on the multi-informa-
tion display, the vehicle may have
run out of fuel. Stop the vehicle in
a safe place and, if the fuel level is
low, refuel the vehicle.

• “Hybrid system stopped”
• “Engine stopped”

●

If “Maintenance Required for Trac-
tion Battery Cooling Parts See
Owner’s Manual” is shown, the fil-
ter may be clogged, the air intake
vent may be blocked, or there may
be a gap in the duct. Therefore,
perform the following correction
procedure.

• Cleaning the hybrid battery (trac-

tion battery) air intake vent
(



P.443)

If the warning message is shown
even if the vent is cleaned, have the
vehicle inspected by your Toyota
dealer.

●

If “12-Volt Battery Charging Sys-
tem Malfunction Stop in a Safe
Place See Owner’s Manual” is
shown

Indicates a malfunction in the vehi-
cle’s charging system. Pull over and
stop the vehicle as soon as it is safe
to do so.

479

7-2. Steps to take in an emergency

Whe

ouble

rises

While the message is displayed, the
functions of the air conditioning, etc.
may be partially limited in order to
reduce the power consumption of
the 12-volt battery.

■

If “Hybrid System Overheated
Output Power Reduced” is
shown

The message may be shown when
driving under severe operating con-
ditions. (For example, when driving
up a long steep hill or driving up a
steep hill in reverse.)

Coping method:



P.514

■

If “Traction Battery Needs to be
Protected Refrain from the Use
of N Position” is shown

This message may be displayed
when the shift position is in N.

As the hybrid battery (traction bat-
tery) can not be charged when the
shift position is in N, shift the shift
position to P when the vehicle is
stopped.

■

If “Traction Battery Needs to be
Protected Shift into P to
Restart” is shown

This message is displayed when the
hybrid battery (traction battery)
charge has become extremely low
because the shift position has been
left in N for a certain amount of time.

When operating the vehicle, shift to
P and restart the hybrid system.

■

If “Shift is in N Release Acceler-
ator Before Shifting” is shown

Message is displayed when the
accelerator pedal has been
depressed and the shift position is in
N. Release the accelerator pedal
and shift the shift position to D or R.

■

If “Press Brake when Vehicle is
Stopped Hybrid System may
Overheat” is shown

Message is displayed when the
accelerator pedal is depressed to
maintain the vehicle position when

stopped on a upward slope, etc.

If this continues, the hybrid system
may overheat.

Release the accelerator pedal and
depress the brake pedal.

■

If “Shift System Malfunction
Shifting Unavailable Drive to a
Safe Place and Stop” or “Shift
System Malfunction Driving
Unavailable” is displayed

There is a malfunction in the shift
control system. Have the vehicle
inspected by your Toyota dealer
immediately.

■

If “Auto Power OFF to Conserve
Battery” is shown

Power was turned off due to the
automatic power off function.

Next time when starting the hybrid
system, operate the hybrid system
for approximately 5 minutes to
recharge the 12-volt battery.

■

If “Parking Assist Unavailable
Low Visibility See Owner’s Man-
ual” is displayed

Indicates one of the following sys-
tems is disabled.

●

RCD (Rear Camera Detec-

tion) (if equipped)

●

PKSB (Parking Support

Brake) (if equipped)

Remove any dirt or foreign matter
from the rear cameras.

■

If “System Malfunction Visit
Your Dealer” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist) (if

equipped)

●

AHB (Automatic High Beam)

480

7-2. Steps to take in an emergency

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

Safe Exit Assist (if equipped)

●

Intuitive Parking Assist

●

PKSB (Parking Support

Brake) (if equipped)

●

RCD (Rear Camera Detec-

tion) (if equipped)

Have the vehicle inspected by your
Toyota dealer immediately.

■

If “System Stopped See
Owner’s Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist) (if

equipped)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

Safe Exit Assist (if equipped)

●

Intuitive Parking Assist

●

PKSB (Parking Support

Brake) (if equipped)

●

RCD (Rear Camera Detec-

tion) (if equipped)

Follow the following correction
methods.
• Check the voltage of the battery
• Check the sensors that the Toyota

Safety Sense 3.0 uses for foreign
matter covering them. Remove
them if any. (



P.216)

• Vehicles with RCD (Rear Camera

Detection): Check if the back door
is open.

Indicates the sensors may not be
operating properly. (



P.219, 279,

283, 287, 297, 301)
• Check the rear bumper around the

sensors used by the BSM (if
equipped), RCTA (if equipped) or
Safe Exit Assist (if equipped) for
foreign matter covering them.
Remove them if any. (



P.276)

• Check the sensors including cam-

era sensors used by the Intuitive
parking assist, PKSB (if
equipped), or RCD (if equipped)
for foreign matter covering them.
Remove them if any. (



P.284)

• When problems are solved and

the sensors are operational, this
indication may disappear by itself.

■

If “System Stopped Front Cam-
era Low Visibility See Owner’s
Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

LCA (Lane Change Assist) (if

equipped)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Toyota Prius (2024 year). Manual in english - page 15
