Toyota Supra (2023 year). Manual in english

185

3-1. CONTROLS

CON

ROLS

The menu for the Toyota Supra
Safety system is displayed.
If all Toyota Supra Safety sys-
tems were switched off, all sys-
tems are now switched on.
"Customize Settings": depend-
ing on the equipment version,
the Toyota Supra Safety sys-
tems can be individually config-
ured. The individual settings are
activated and stored. As soon
as a setting is changed on the
menu, all settings of the menu
are activated.

The following settings are
switched between:
"ALL ON": all Toyota Supra
Safety systems are switched on.
Basic settings are activated for
the subfunctions.
"Customize": the Toyota Supra
Safety systems are switched on
according to the individual set-
tings.
Some Toyota Supra Safety sys-
tems cannot be individually
switched off.

All Toyota Supra Safety systems
are switched off.

If a collision with a pedestrian or
a cyclist is imminent, a warning
symbol appears on the instru-
ment cluster and in the Head-up
Display.

Intervene immediately by brak-

Switching on/off manually

Press the button.

Press the button repeat-
edly.

Press and hold this button.

Button

Status

Indicator lights up
green: all Toyota Supra
Safety systems are
switched on.

Indicator lights up
orange: some Toyota
Supra Safety systems
are switched off or cur-
rently unavailable.

Indicator does not light
up: all Toyota Supra
Safety systems are
switched off.

Warning with braking
function

Display

The red symbol is dis-
played and a signal
sounds.

Alternatively, depending
on the vehicle equipment,
a red warning triangle
lights up in the instrument
cluster.

186

3-1. CONTROLS

ing or make an evasive maneu-
ver.

The warning prompts the driver
to intervene. When the brake
pedal is pressed quickly and
hard, the maximum braking
force of the vehicle is used.
If there is a risk of collision, the
system may also assist with
brake intervention.
When the vehicle is traveling at
a low speed, the vehicle may
come to a complete stop.
Manual transmission: during a
brake intervention up to a com-
plete stop, the engine may be
shut down.
The braking intervention can be
interrupted by stepping on the
accelerator pedal with sufficient
force or by actively moving the
steering wheel.

The system responds to pedes-
trians and cyclists when the
speed of the vehicle is below
approx. 53 mph/85 km/h.

The system's detection potential
is limited.
Thus, a warning might not be
issued or be issued late.
The following situations may not
be detected, for instance:



Partially covered pedestrians.



Pedestrians that are not
detected as such because of
the viewing angle or contour.



Pedestrians outside of the
detection range.



Pedestrians having a body
size less than 32 in/80 cm.

Braking intervention

System limits

Safety information

WARNING

The system is designed to oper-

ate in certain conditions and cir-

cumstances. Due to conditions or

other factors, the system may not

respond. There may be a risk of

accident or risk of damage to

property. Actively intervene as

warranted. Refer to the informa-

tion in this Owner’s Manual

regarding the scope of the sys-

tem’s operation and limitations.

Upper speed limit

Detection range

187

3-1. CONTROLS

CON

ROLS

Additional information:
• Cameras, refer to page 42.
• Radar sensors, refer to page

43.

The system may not be fully
functional or may not be avail-
able in the following situations:



If the driving stability control
systems are deactivated, for
instance VSC OFF.



Up to 10 seconds after the
start of the engine via the
Start/Stop button.

The lane departure warning
alerts when the vehicle is about
to run off the road or exit the
lane.

This camera-based system
warns starting at a minimum
speed.
The minimum speed is coun-
try-specific and is displayed in
the menu for the Toyota Supra
Safety systems.
Warnings are issued by means
of a steering wheel vibration.

The severity of the steering
wheel vibration can be adjusted.
The system does not provide a
warning if the turn signal is set in
the respective direction before
leaving the lane.
Depending on the equipment
version, if in the speed range up
to 155 mph/250 km/h a lane
marking is crossed, the system
may intervene with a brief active
steering intervention in addition
to vibrating. The system thus
helps keep the vehicle in the
lane.

System limits of the sensors

Functional limitations

Lane departure warning

Concept

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing road and

traffic safety. There is a risk of an

accident. Adjust driving style to

traffic conditions. Watch traffic

closely and actively intervene

where appropriate. Do not jerk the

steering wheel in response to a

warning.

WARNING

Indicators and warnings cannot

serve as a substitute for the

driver’s personal judgment. Due

to its limits, the system might not

output warnings or reactions or

these might be output late, incor-

rectly. There is a risk of an acci-

dent. Adjust driving style to traffic

conditions. Watch traffic closely

and actively intervene where

appropriate.

188

3-1. CONTROLS

The system is controlled by the
following sensors:
• Cameras behind the wind-

shield.

Additional information:
Sensors of the vehicle, refer to
page 42.

The camera must detect the
lane markings for the lane
departure warning to be active.

Depending on the national-mar-
ket version, the system is auto-
matically active after every

driving off.

Overview

Button in the vehicle

Toyota Supra Safety

Sensors

Functional requirements

Turning on/off

Turning on automatically

Switching on/off manually

Press the button.

Press the button repeat-
edly.

189

3-1. CONTROLS

CON

ROLS

All Toyota Supra Safety systems
are switched off.

Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Toyota Supra Safety"

"Lane Departure Warn."

Select desired setting:



"Early": the system promptly
issues a warning whenever a
hazardous situation is
detected.



"Medium": the system meets
the standardized safety
requirements.



"Reduced": some warnings
are suppressed depending on

the situation, for instance
during passing without a turn
signal or when purposely driv-
ing over lane markings in
curves.



"Off": no warnings are issued.

Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Steering wheel vibration"

Select the desired setting.

The steering intervention can be
switched on and off separately
for Blind spot monitor and lane
departure warning.
Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Toyota Supra Safety"

"Steering intervention"

Depending on the national-market

version, the steering intervention is

automatically active after every

driving off.

Press and hold this button.

Button

Status

Indicator lights up
green: all Toyota Supra
Safety systems are
switched on.

Indicator lights up
orange: some Toyota
Supra Safety systems
are switched off or cur-
rently unavailable.

Indicator does not light
up: all Toyota Supra
Safety systems are
switched off.

Setting the warning time

Setting the intensity of the
steering wheel vibration

Switching steering interven-
tion on/off

190

3-1. CONTROLS

If you leave the lane and if a
lane marking has been
detected, the steering wheel
vibrates in accordance with the
steering wheel vibration setting.
When the turn signal is switched
on in the corresponding direc-
tion before changing the lane, a
warning is not issued.

If, in the speed range up to 130
mph/210 km/h a lane boundary
is crossed, the system may
intervene with a brief active
steering intervention in addition
to vibrating. The steering inter-
vention helps keep the vehicle in
the lane. The steering interven-
tion can be noticed on the steer-
ing wheel and can be manually

overridden at any time. During
an active steering intervention,
the display in the instrument
cluster will blink.
For instance, the steering inter-
vention will be suppressed in the
following situations:



With accelerating or braking
hard.



When the turn signal indicator
is blinking.



With hazard warning system
switched on.



In driving situation with high
driving dynamics.



The Vehicle Stability Control
VSC adjusts.



Immediately following a steer-
ing intervention by the vehi-
cle systems.



When actively merging back
to your own lane after pass-
ing.

Depending on the equipment, in
the event of multiple active
steering interventions by the
system within 3 minutes without
the driver's intervention at the
steering wheel, an acoustic
warning will sound. A short
warning signal will sound at the
second steering intervention.
Beginning with the third steering
intervention, an continuous
warning will sound.

Display in the instrument
cluster

The icon is illuminated
green: the system is
turned on. A lane bound-
ary has been detected on
at least one side of the
vehicle and the system is
ready to intervene. Warn-
ings will be issued.
Icon flashes green: the
system is performing a
steering intervention.

Warning function

If you leave the lane

Steering intervention

Warning signal

191

3-1. CONTROLS

CON

ROLS

In addition, a vehicle message is
displayed.
The warning signal and vehicle
message are an encouragement
to pay closer attention to the
lane.

For instance, the warning will be
canceled in the following situa-
tions:



Automatically after a few sec-
onds.



When returning to your own
lane.



When braking hard.



When using the turn signal.



If VSC Vehicle Stability Con-
trol System intervenes.

Additional information:

• Cameras, refer to page 45.

The system may not be fully
functional in the following situa-
tions:



In the event of missing, worn,
poorly visible, merging,
diverging, or multiple lane
markings such as in construc-
tion areas.



When lane markings are cov-
ered in snow, ice, dirt or
water.



In tight curves or on narrow
lanes.



When lane markings are cov-
ered by objects.



When driving very close to the
vehicle in front of you.



Up to 10 seconds after the
start of the engine via the
Start/Stop button.

A vehicle message may be dis-
played when the system is not
fully functional.

: if equipped

Blind spot monitor detects vehi-
cles in the blind spot or vehicles
approaching from behind in the
adjacent lane. A warning is
issued in various gradations in

End of warning

System limits

Safety information

WARNING

The system is designed to oper-

ate in certain conditions and cir-

cumstances. Due to conditions or

other factors, the system may not

respond. There may be a risk of

accident or risk of damage to

property. Actively intervene as

needed. Refer to the information

in this Owner’s Manual regarding

the scope of the system’s opera-

tion and limitations.

System limits of the sensors

Functional limitations

Blind spot monitor*

Concept

192

3-1. CONTROLS

these situations.

Radar sensors monitor the area
behind and next to the vehicle
when traveling faster than a
minimum speed.
The minimum speed is coun-
try-specific and is displayed in
the menu for the Toyota Supra
Safety systems.
The system indicates whether
there are vehicles in the blind
spot, arrow

, or approaching

from behind in the adjacent
lane, arrow

The light in the exterior mirror
lights up dimmed.
Before you change lanes after
setting the turn signal, the sys-
tem issues a warning in the situ-
ations described above.
The light in the exterior mirror
flashes and the steering wheel
vibrates.

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

situation. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of accident.

Adjust driving style to traffic condi-

tions. Watch the surrounding traf-

fic situation closely, be ready to

take over steering and braking at

any time, and actively intervene

where appropriate.

WARNING

Indicators and warnings cannot

serve as a substitute for the

driver’s personal judgment. Due

to its limits, the system might not

output warnings or reactions or

these might be output late, incor-

rectly. There is a risk of an acci-

dent. Adjust driving style to traffic

conditions. Watch traffic closely

and actively intervene where

appropriate.

Overview

Button in the vehicle

193

3-1. CONTROLS

CON

ROLS

The system is controlled by the
following sensors:
• Radar sensors, side, rear.
Additional information:
Sensors of the vehicle, refer to
page 42.

The Blind spot monitor is auto-
matically activated after depar-
ture if the function was switched
on at the end of the last trip.

menu, all settings of the menu
are activated.

The following settings are
switched between:
"ALL ON": all Toyota Supra
Safety systems are switched on.
Basic settings are activated for
the subfunctions.
"Customized": the Toyota Supra
Safety systems are switched on
according to the individual set-
tings.
Some Toyota Supra Safety sys-
tems cannot be individually
switched off.

All Toyota Supra Safety systems
are switched off.

Toyota Supra Safety

Sensors

Switching on/off

Switching on automatically

Switching on/off manually

Press the button.

Press the button repeat-
edly.

Press and hold this button.

Button

Status

Indicator lights up
green: all Toyota Supra
Safety systems are
switched on.

Indicator lights up
orange: some Toyota
Supra Safety systems
are switched off or cur-
rently unavailable.

Indicator does not light
up: all Toyota Supra
Safety systems are
switched off.

194

3-1. CONTROLS

Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Toyota Supra Safety"

"Blind spot monitor"

Select the desired setting.

"Off": with this setting, no warning is

output.

Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Steering wheel vibration"

Select the desired setting.

The dimmed light in the exterior
mirror indicates when there are
vehicles in the blind spot or

approaching from behind.

If the turn signal is switched on
while a vehicle is in the critical
zone, the steering wheel
vibrates briefly and the light in
the exterior mirror flashes
brightly.
The warning stops when the
other vehicle has left the critical
area or after deactivation of the
turn signal.

A flashing of the light during
vehicle unlocking serves as sys-
tem self-test.

If the vehicle speed exceeds
approx. 155 mph/250 km/h, the

Setting the warning time

Setting the force of the steer-
ing wheel vibration

Warning function

Light in the exterior mirror

Prewarning

Acute warning

Flashing of the light

System limits

Safety information

WARNING

The system is designed to oper-

ate in certain conditions and cir-

cumstances. Due to conditions or

other factors, the system may not

respond. There may be a risk of

accident or risk of damage to

property. Actively intervene as

needed. Refer to the information

in this Owner’s Manual regarding

the scope of the system’s opera-

tion and limitations.

Upper speed limit

195

3-1. CONTROLS

CON

ROLS

system is deactivated temporar-
ily.
If the vehicle speed falls below
approx. 155 mph/250 km/h, the
system once again responds
according to the setting.

Additional information:
• Radar sensors, refer to page

42.

The system may not be fully
functional in the following situa-
tions:



When a vehicle is approach-
ing at a speed much faster
than your own.



In heavy fog, wet conditions,
or snowfall.



In tight curves or on narrow
lanes.



If the bumper is dirty, iced up,
or covered, for instance by
stickers.



After improperly performed
work on the vehicle paint.



If cargo protrudes.

A vehicle message is displayed
when the system is not fully
functional.

Depending on the selected

warning settings, e.g., warning
time, more or fewer warnings
can be displayed. However,
there may also be an excess of
premature warnings of critical
situations.

Depending on the equipment
and national-market version, the
rear-end collision preparation
can react to vehicles approach-
ing from behind.

Radar sensors monitor the area
behind the vehicle.
When a vehicle approaches
from the rear at a certain speed,
the system can react as as fol-
lows:



Where applicable, the hazard
warning flashers will be
switched on.



Where applicable, the Pre-

System limits of the sensors

Functional limitations

Displaying warnings

Rear-end collision prepa-
ration

Principle

General

196

3-1. CONTROLS

Crash functions are triggered.

The system is controlled by the
following sensors:
• Radar sensors, side, rear.
Additional information:
Sensors of the vehicle, refer to
page 42.

The system is automatically
active when the vehicle is turned
on.
The system is deactivated in the
following situations:



When driving in reverse.

Additional information:
• Radar sensors, refer to page

P.43.

The system may not be fully
functional in the following situa-
tions:



When a vehicle is approach-
ing at a speed much faster
than your own.



The approaching vehicle is
approaching slowly.

In the event of an accident, the
system can bring the vehicle to
a halt automatically without
intervention by the driver in cer-
tain situations. This can reduce
the risk of a further collision and

Safety information

WARNING

The system cannot serve as a

substitute for the driver's personal

judgment in assessing the traffic

situation. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of accident.

Adjust driving style to traffic condi-

tions. Watch the surrounding traf-

fic situation closely, be ready to

take over steering and braking at

any time, and actively intervene

where appropriate.

WARNING

Indicators and warnings cannot

serve as a substitute for the

driver’s personal judgment. Due

to its limits, the system may not

issue warnings or reactions, or

these may be issued late or in a

manner that is not consistent with

their normal use. There is a risk of

accident. Adjust driving style to

traffic conditions. Watch traffic

closely and actively intervene

where appropriate.

Overview

Sensors

Switching on/off

System limits

System limits of the sensors

Functional limitations

Autonomous Emergency
Braking

Concept

197

3-1. CONTROLS

CON

ROLS

the consequences thereof.

After coming to a halt, the brake
is released automatically.

It can be necessary to bring the
vehicle in certain situations to a
halt quicker.
To do this, for a short time the
braking pressure applied when
stepping on the brake pedal
must be higher than the braking
pressure achieved by the auto-
matic braking function. This
interrupts automatic braking.

It can be necessary to interrupt
automatic braking in certain situ-
ations, for instance for an eva-
sive maneuver.
Interrupt automatic braking:



By pressing the brake pedal.



By pressing the accelerator
pedal.

The system can detect decreas-
ing alertness or fatigue of the
driver during long, monotonous

trips, for instance on highways.
In this situation, it is recom-
mended that the driver takes a
break.

The system is switched on each
time drive-ready state is
switched on.
After travel has begun, the sys-
tem monitors certain aspects of
the driver's behavior, so that
decreasing alertness or fatigue
can be detected.
This procedure takes the follow-
ing criteria into account:



Personal driving style, for
instance steering behavior.



Driving conditions, for
instance length of trip.

Starting at approx. 43 mph/70
km/h, the system is active and
can also display a recommenda-
tion to take a break.

At standstill

Harder vehicle braking

Interrupting automatic
braking

Driver attention control

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing one's

physical state. An increasing lack

of alertness or fatigue may not be

detected or not be detected in

time. There is a risk of an acci-

dent. Make sure that the driver is

rested and alert. Adjust driving

style to traffic conditions.

Function

198

3-1. CONTROLS

The break recommendation can
also be switched on or off and
adjusted via Toyota Supra Com-
mand.
Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Driver attention control"

Select desired setting:



"Standard": the break recom-
mendation is made with a
defined value.



"Sensitive": the break recom-
mendation is issued earlier.



"Off": no break recommenda-
tion is made.

If the driver becomes less alert
or fatigued, a message is dis-
played in the Control Display
with the recommendation to
take a break.
During the display, the following
settings can be selected:



"Do not ask again"



"Places to stop"



"Remind me later"

The break recommendation is
repeated after 20 minutes.

After a break, another recom-

mendation to take a break can-
not be displayed until after
approximately 45 minutes.

The function may be limited in
the following situations and may
be output an incorrect warning
or no warning at all.



When the clock is set incor-
rectly.



When the vehicle speed is
mainly below about 43
mph/70 km/h.



With a sporty driving style,
such as during rapid accelera-
tion or when cornering fast.



In active driving situations,
such as when changing lanes
frequently.



When the road surface is
poor.



In the event of strong side
winds.

The system is reset approx. 45
minutes after parking the vehi-
cle, for instance in the case of a
break during longer trips on
highways.

Break recommendation

Settings

Display

System limits

199

3-1. CONTROLS

CON

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

ABS prevents locking of the
wheels during braking.
The vehicle maintains its steer-
ing power even during full brake
applications, which increases
the active safety.
ABS is operational every time
you start the engine.
Situations which the ABS can-
not operate sufficiently:



When entering a curve at an
excessively high rate of speed

In this case, even if the ABS oper-
ates, it cannot operate sufficiently
to avoid a possible dangerous situ-
ation. The driver is solely responsi-
ble for understanding their
surroundings and driving at a safe
speed.

The brake assistant automati-
cally applies maximum braking
assistance when the brake
pedal is depressed quickly. It
reduces the braking distance to
a minimum during emergency
braking. The advantages of the
Antilock Braking System are
thereby utilized.
Do not reduce the pressure on
the brake pedal during full brak-
ing.

The Adaptive Brake Assist,
together with Dynamic radar
cruise control, ensures that the
brake responds even faster in
critical situations when braking.

Driving stability con-

trol systems

Vehicle features and
options

Anti-lock Braking System
ABS

Brake assist

Adaptive brake assist

200

3-1. CONTROLS

This system supports driving off
on uphill grades.

Hold the vehicle in place with
the foot brake.

Release the foot brake and
drive off without delay.

After the foot brake is released,
the vehicle is held in place for
approx. 2 seconds.
Depending on the vehicle load-
ing, the vehicle may roll back
slightly.
In order to prevent rolling back
when driving off, use the parking
brake.

Pull and release switch

before driving off.
The parking brake is set.

Step on the accelerator pedal
sufficiently to drive off.

Within the physical limits, the
system helps to keep the vehicle
on a steady course by reducing
engine speed and by braking

the individual wheels.

VSC detects the following unsta-
ble driving conditions, for
instance:



Fishtailing, which can lead to
oversteering.



Loss of traction of the front
wheels, which can lead to
understeering.

Hill-start assist control

Concept

Driving off

VSC Vehicle Stability Con-
trol System

Concept

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing the traffic

situation. Based on the limits of

the system, it cannot inde-

pendently react to all traffic situa-

tions. There is a risk of accident.

Adjust driving style to traffic condi-

tions. Watch the surrounding traf-

fic situation closely, be ready to

take over steering and braking at

any time, and actively intervene

where appropriate.

WARNING

When driving with a roof load, for

instance with roof-mounted lug-

gage rack, the vehicle's center of

gravity is higher, which increases

the risk of the vehicle tipping in

critical driving situations. There is

a risk of accidents or risk of dam-

age to property. Do not deactivate

VSC Vehicle Stability Control Sys-

tem when driving with roof load.

Toyota Supra (2023 year). Manual in english - page 12
