5-2. Driving procedures

5-2.Driving procedures

Pull the parking brake switch
to check that the parking
brake is set. (



P.191)

The parking brake indicator will

come on.

Firmly depress the brake
pedal.

and a message will be dis-

played on the multi-information dis-

play.

If it is not displayed, the fuel cell

system cannot be started.
When the shift position is N, the

fuel cell system cannot start. Shift

the shift position to P when starting

the fuel cell system. (



P.185)

Press the power switch
shortly and firmly.

When operating the power switch,

one short, firm press is enough. It is

not necessary to press and hold the

switch.
If the “READY” indicator turns on,

the fuel cell system will operate nor-

mally.
Continue depressing the brake

pedal until the “READY” indicator is

illuminated.
The fuel cell system can be started

from any power switch mode.

Check that the “READY” indi-
cator is illuminated.

The vehicle cannot be driven if the

“READY” indicator is off.

■

Starting the fuel cell system in

cold temperatures

●

When the fuel cell system is

started during cold temperatures,

the fuel cell stack quickly warms

up using waste heat during power

generation. Operation noises will

be louder than usually, but this is

not a malfunction. Depending on

the situation, the operation noises

may also continue for a fixed

period of time after the “READY”

indicator is turned on. (



P.77)

●

When the temperatures are cold,

it may take more time than usual

until the “READY” indicator turns

on. In those cases, the progress

state is displayed in the multi-

information display.

“FCV System is Warmed Up
Waiting...”

●

When starting the fuel cell system

during cold weather, “FCV System

Power switch

Performing the following
operations when carrying
the electronic key on your
person starts the fuel cell
system or changes power
switch modes.

Starting the fuel cell sys-
tem

181

5-2. Driving procedures

ing

Shutdown Due to Freezing Stop in

a Safe Place See Owner’s Man-

ual” may be displayed in the multi-

information display.

The fuel cell system is frozen and
cannot be started. Contact your Toy-
ota dealer.

●

The power output will be tempo-

rarily limited until the fuel cell sys-

tem reaches full operating

temperature.

●

When the traction battery is

extremely cold (below approxi-

mately -22˚F [-30˚C]) under the

influence of outside temperature,

it may not be possible to start the

fuel cell system. In this case, try to

start the fuel cell system again

after the temperature of the trac-

tion battery increases due to the

outside temperature increase etc.

■

If the fuel cell system does not

start

●

The immobilizer system may not

have been deactivated. (



P.70)

Contact your Toyota dealer.

●

If a message related to start-up is

shown on the multi-information

display, read the message and fol-

low the instructions.

●

Check that the fuel door is closed.

When the fuel door is open, the

fuel cell system cannot be started.

Close the fuel door before starting

the system. (



P.212)

■

Sounds and vibrations specific

to a fuel cell electric vehicle



P.77

■

If the 12-volt battery is dis-

charged

The fuel cell system cannot be

started using the smart key system.

Refer to P.485to restart the fuel cell

system.

■

Electronic key battery depletion



P.124

■

Conditions affecting operation



P.138

■

Notes for the entry function



P.138

■

If “Smart Key System Malfunc-

tion See Owner’s Manual” is

displayed on the multi-informa-

tion display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer immediately.

■

If the “READY” indicator does

not come on

In the event that the “READY” indi-

cator does not come on even after

performing the proper procedures

for starting the vehicle, contact your

Toyota dealer immediately.

■

If the fuel cell system is mal-

functioning



P.464

■

Electronic key battery



P.436

■

Operation of the power switch

●

If the switch is not pressed shortly

and firmly, the power switch mode

may not change or the fuel cell

system may not start.

●

If attempting to restart the fuel cell

system immediately after turning

the power switch off, the fuel cell

system may not start in some

cases. After turning the power

switch off, please wait a few sec-

onds before restarting the fuel cell

system.

■

Customization

If the smart key system has been

deactivated in a customized setting,

refer to P.482.

182

5-2. Driving procedures

Stop the vehicle completely.

Set the parking brake.
(



P.191)

Press the P position switch.
(



P.185)

Check that the shift position indica-

tor shows P and the parking brake

indicator is illuminated.

Press the power switch.

The fuel cell system will stop, and

the meter display will be extin-

guished (the shift position indicator

will be extinguished a few seconds

after the meter display).

Release the brake pedal and
check that “ACCESSORY” or
“IGNITION ON” is not shown
on the meter.

■

Stopping the fuel cell system in

cold temperatures

●

When the power switch is pressed

and the fuel cell system is stopped

during cold temperatures, the time

for water purge from the tailpipe

may be longer than usual to pre-

vent liquid in the fuel cell stack

from freezing.

●

If the “FCV System Purge in Prog-

ress Purge will Stop Automati-

cally” is displayed in the multi-

information display, however it is

no problem to exit the vehicle.

●

The water purge time may also be

long if the system is stopped

before fuel cell system warm-up is

completed.

●

It is normal to hear hissing and

other sounds during purge.

(



P.77)

●

It is not a problem to do refueling

operations while the system is

purging.

The purging process is carried out

automatically after several min-

utes and a white mist may be

emitted, however this is not a mal-

function.

■

Parking the vehicle during cold

weather

●

Water may automatically purge

from the tailpipe, even when the

fuel cell system is off, in order to

prevent liquid in the fuel cell stack,

hydrogen pipelines, etc., from

freezing. Also, water vapor may

be purged, but this is not malfunc-

tion.

●

It is normal to hear hissing and

other sounds during purge.

WARNING

■

When starting the fuel cell

system

Always start the fuel cell system

while sitting in the driver’s seat.

Do not depress the accelerator

pedal while starting the fuel cell

system under any circumstances.

Doing so may cause an accident

resulting in death or serious injury.

NOTICE

■

When starting the fuel cell

system

If the fuel cell system becomes

difficult to start, have your vehicle

checked by your Toyota dealer

immediately.

■

Symptoms indicating a mal-

function with the power

switch

If the power switch seems to be

operating somewhat differently

than usual, such as the switch

sticking slightly, there may be a

malfunction. Contact your Toyota

dealer immediately.

Stopping the fuel cell sys-
tem

183

5-2. Driving procedures

ing

(



P.77)

■

Automatic fuel cell system shut

off feature

●

The vehicle is equipped with a

feature that automatically shuts off

the fuel cell system when the shift

position is in P with the fuel cell

system operating for an extended

period.

●

The fuel cell system will automati-

cally shut off after approximately 1

hour if it has been left running

while the shift position is in P.

●

The timer for the automatic fuel

cell system shut off feature will

reset if the brake pedal is

depressed or if the shift position is

in a position other than P.

●

After the vehicle is parked, if the

door is locked with the door lock

switch (



P.130) from the inside or

the mechanical key from the out-

side, the automatic fuel cell sys-

tem shut off feature will be

disabled. The timer for the auto-

matic fuel cell system shut off fea-

ture will be re-enabled if the

driver’s door is opened.

■

When the shift control system

malfunctions

When attempting to turn the power

switch off while there is a malfunc-

tion in the shift control system, the

power switch mode may change to

ACC. In this case, ACC may be

turned off by applying the parking

brake and pressing the power

switch again.
If there is a malfunction in the sys-

tem, have the vehicle inspected by

your Toyota dealer immediately.

■

Automatic P position selection

function



P.187

■

Water release (H

O switch)



P.196

Modes can be changed by
pressing the power switch with
the brake pedal released. (The
mode changes each time the
switch is pressed.)

WARNING

■

Stopping the fuel cell system

in an emergency

●

If you want to stop the fuel cell

system in an emergency while

driving the vehicle, press and

hold the power switch for more

than 2 seconds, or press it

briefly 3 times or more in suc-

cession. (



P.446)

However, do not touch the

power switch while driving

except in an emergency. Turn-

ing the fuel cell system off while

driving will not cause loss of

steering or braking control, how-

ever, power assist to the steer-

ing will be lost. This will make it

more difficult to steer smoothly,

so you should pull over and stop

the vehicle as soon as it is safe

to do so.

●

If the power switch is operated

while the vehicle is running, a

warning message will be shown

on the multi-information display

and a buzzer sounds.

●

When restarting the fuel cell

system after an emergency

shutdown, press the power

switch.

Changing power switch
modes

184

5-2. Driving procedures

“ACCESSORY”

“IGNITION ON”

OFF

The emergency flashers can be
used.

ACC

Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the meter.

All electrical components can be
used.
“IGNITION ON” will be displayed on
the meter.

■

Auto power off function

If the vehicle is left in ACC for more

than 20 minutes or ON (with fuel cell

system not operating) for more than

an hour with the shift position in P,

the power switch will automatically

turn off. However, this function can-

not entirely prevent the 12-volt bat-

tery discharge. Do not leave the

vehicle with the power switch in

ACC or ON for long periods of time

when the fuel cell system is not

operating.

NOTICE

■

To prevent 12-volt battery dis-

charge

●

Do not leave the power switch

in ACC or ON for long periods of

time without the fuel cell system

on.

●

If “ACCESSORY” or “IGNITION

ON” is displayed on the meter,

the power switch is not off. Exit

the vehicle after turning the

power switch off.

185

5-2. Driving procedures

ing

Br mode is not a shift position.
(



P.189)

■

If a message about a shift oper-

ation is shown

To prevent the shift position from

being selected incorrectly or the

vehicle from moving unexpectedly,

the shift position may be changed

automatically or operating the shift

lever may be required. In this case,

change the shift position following

the messages on the multi-informa-

tion display.

Shift lever

Operate the shift lever gently and

Shift position

Select the shift position
depending on your pur-
pose and situation.

Shift position purpose
and functions

Shift posi-

tion

Objective or function

Parking the vehi-

cle/starting the fuel cell

system

Reversing

Neutral

Normal driving

NOTICE

■

Situations where shift control

system malfunctions are pos-

sible

If any of the following situations

occurs, shift control system mal-

functions are possible.

Immediately stop the vehicle in a

safe place on level ground, apply

the parking brake, and then con-

tact your Toyota dealer.

●

When the warning message

indicating the shift control sys-

tem appears on the multi-infor-

mation display. (



P.464)

●

The display indicates that no

shift position is selected for

more than a few seconds.

Shift position display and
how to change the shift
position

186

5-2. Driving procedures

securely in the direction of the
arrow on the shift position indicator.
To shift to N, slide the shift lever in
the direction of the arrow and hold
it.
Release the shift lever after each
shifting operation to allow it to

return to its regular position (

Shifting to Br mode is only possible
when the shift position is in D.
When shifting from P to N, D or R,
from N, D, Br mode or R to P, from
D or Br mode to R, or from R to D,
ensure that the brake pedal is being
depressed and the vehicle is sta-
tionary.

Shift position indicator

Meter display:
The current shift position is high-
lighted.
When any shift position other than
D position or Br mode is selected,
the Br mode indicator are displayed
in gray.

P position switch

Fully stop the vehicle and set the
parking brake, and then press the P
position switch.
When the shift position is changed
to P, the switch illuminates.
Check that the shift position indica-
tor shows P.

■

Changing the shift position in

each power switch mode

●

The shift position cannot be

changed when the power switch is

in ACC or off.

●

When the power switch is in ON, if

the READY indicator is not illumi-

nated, the shift position can only

be changed to N.

●

When the READY indicator is illu-

minated, the shift position can be

changed from P to D, N, or R.

●

When the READY indicator is

flashing, the shift position cannot

be changed from P to any other

position, even if the shift lever is

operated. Operate the shift lever

again after the READY indicator

changes from flashing to illumi-

nated.

■

Shifting the shift position from

P to other positions

●

While depressing the brake pedal

firmly, operate the shift lever. If the

shift lever is operated without

depressing the brake pedal, the

buzzer will sound and the shifting

operation will be disabled.

●

When selecting the shift position,

make sure that the shift position

has been changed to the desired

position by checking the shift posi-

tion indicator provided on the

instrument cluster.

●

The shift position cannot be

changed from P to Br mode

directly.

■

The shift position cannot be

changed when

In the following situations, a buzzer

will sound to inform you that the shift

position cannot be changed. Use

the appropriate operation to attempt

to change the shift position again.

●

When attempting to change the

shift position from P with the brake

pedal not depressed

●

When attempting to change the

shift position from P with the

accelerator pedal depressed

●

When attempting to change the

shift position from N while stopped

or driving at an extremely low

speed with the brake pedal not

depressed

●

When attempting to change the

shift position from N while stopped

or driving at an extremely low

187

5-2. Driving procedures

ing

speed with the accelerator pedal

depressed

●

When attempting to change the

shift position from P or N to Br

mode

●

When the P position switch is

pressed while driving

When driving at an extremely low
speed, the shift position may
change to P.

■

The shift position automatically

changes to N when

In the following situations, a buzzer

will sound to inform you that the shift

position has been changed to N.

Use the appropriate operation to

attempt to change the shift position

again.

●

When attempting to change the

shift position to R while the vehicle

is moving forward

When driving at a low speed, the
shift position may change to R.

●

When attempting to change the

shift position to D while the vehicle

is moving backward

When driving at a low speed, the
shift position may change to D.

●

When attempting to change the

shift position from R to Br mode

■

If the N shift position is selected

while driving

If the shift lever is moved to N while

driving above a certain speed, the

shift position will change to N with-

out holding the shift lever in the N

position. In this situation, a buzzer

will sound and a message will be

displayed on the multi-information

display to inform you that the shift

position has been changed to N.

■

Automatic P position selection

function

In the following situations, the shift

position is automatically changed to

●

When pressing the power switch

with the vehicle stopped while the

power switch is in ON and the shift

position is in a position other than

P (after the shift position has

changed to P, the power switch
will turn off)

●

If the driver’s door is opened and

all of the following conditions are

met, while the shift position is in a

position other than P

• The power switch is in ON.

• The driver is not wearing the seat

belt.

• The brake pedal is not depressed.
To start off the vehicle after the shift
position is changed to P, operate the
shift lever again.

●

When the vehicle is stopped after

the fuel cell system has been

stopped in an emergency while

driving

●

When voltage of the 12-volt bat-

tery drops while the shift position

is in a position other than P

: When the power switch is pressed

while driving at extremely slow
speeds, such as immediately
before stopping the vehicle, the
shift position may automatically
change to P. Make sure that the
vehicle is completely stopped
before pressing the power switch.

■

If the shift position cannot be

shifted from P

There is a possibility that the 12-volt

battery is discharged. Check the 12-

volt battery in this situation.

(



P.485)

188

5-2. Driving procedures



By performing the following
operation, the shift position
can be held in N until the shift
position switches to P without
activating the automatic P
position selection function.

Operate the shift lever and
change the shift position to N
when the fuel cell system is
operating.

Return the shift lever to its

regular position (

Operate the shift lever to N
and hold it there until the
buzzer sounds.

Press the power switch within
5 seconds after the buzzer
sounds.

The fuel cell system stops with the
shift position in N.

Make sure to check that the buzzer

sounds and “Holding N Push P

Switch When Done” is displayed on

the multi-information display.



In order to shift to a position
other than N, first press the P
position switch to change the

WARNING

■

For the shift lever

●

Do not remove the shift lever

knob or use anything but a gen-

uine TOYOTA shift lever knob.

Also, do not hang anything on

the shift lever. Doing so could

prevent the shift lever from

returning to position, causing

unexpected accidents to occur

when the vehicle is in motion.

●

In order to prevent the shift

position from accidentally being

changed, do not touch the shift

lever when not using them.

■

P position switch

●

Do not press the P position

switch while the vehicle is mov-

ing.

If the P position switch is

pressed when driving at very

low speeds (for example,

directly before stopping the

vehicle), the vehicle may stop

suddenly when the shift position

switches to P, which could lead

to an accident.

●

In order to prevent the shift

position from accidentally being

changed, do not touch the P

position switch when not using

them.

NOTICE

■

Notes regarding shift lever

and P position switch opera-

tion

Avoid repeatedly operating the

shift lever and P position switch in

quick succession. The system

protection function may activate

and it will not be temporarily pos-

sible to shift the shift position

other than P. If this happens,

please wait for a while before

attempting to change the shift

position again.

■

When exiting the vehicle

(driver’s seat only)

Check that the shift position indi-

cator shows P and that the park-

ing brake indicator is illuminated

before opening the door and exit-

ing the vehicle.

Keeping the shift position
in N without activating the
automatic P position
selection function

189

5-2. Driving procedures

ing

shift position to P.



Make sure to operate the shift
lever with the fuel cell system
is operating.
If the fuel cell system is not
operating, it may not be possi-
ble to hold the shift position in
N.

: To keep this state, do not operate

the power switch. If the power
switch is operated repeatedly, the
power switch will turn off after the
shift position has automatically
changed to P.

■

Driving mode



P.320

■

Snow mode



P.321

■

Br mode

Suitable for driving that requires
strong deceleration force, such
as down-hill driving, etc.

To select Br mode, shift the shift
lever down.
The Br mode indicator will illumi-
nate on the meter.
To return to normal driving mode,
depress the accelerator pedal or
select the D position again with the
shift lever.

■

Br mode

Depending on the condition of the

traction battery, Br mode may not be

available. In that case, a message is

displayed on the multi-information

display.

■

Sounds when in Br mode



P.77

Selecting the driving
mode

190

5-2. Driving procedures

Right turn

Lane change to the right
(move the lever partway and
release it)

The right hand signals will flash 3
times.

Lane change to the left
(move the lever partway and
release it)

The left hand signals will flash 3
times.

Left turn

■

Turn signals can be operated

when

The power switch is in ON.

■

If the indicator flashes faster

than usual

Check that a light bulb in the front or

rear turn signal lights has not

burned out.

■

If the turn signals stop flashing

before a lane change has been

performed

Operate the lever again.

■

Customization

Some functions can be customized.

(



P.512)

Turn signal lever

Operating instructions

191

5-2. Driving procedures

ing

■

Using the manual mode

The parking brake can be set
and released manually.

U.S.A.

Canada

Pull the switch to set the
parking brake

The parking brake indicator light
will turn on.

Pull and hold the parking brake
switch if an emergency occurs and
it is necessary to operate the park-
ing brake while driving.

Push the switch to release
the parking brake

• Operate the parking brake switch

while depressing the brake pedal.

• Using the parking brake auto-

matic release function, the park-
ing brake can be released by
depressing the accelerator pedal.
When using this function, slowly
depress the accelerator pedal.

Make sure that the parking brake
indicator light turn off.

■

Turns automatic mode on

While the vehicle is stopped,
pull and hold the parking brake
switch until a message is shown
on the multi-information display.

“EPB Shift Interlock Function
Activated”

When the automatic mode is
turned on, the parking brake
operates as follows.



When the shift position is
shifted from P, the parking
brake will be released, and
the parking brake indicator
light will turn off.

Parking brake

The parking brake can be
set or released automati-
cally or manually.

In automatic mode, the
parking brake can be set or
released automatically
according to the shift lever
operation. Also, even in
automatic mode, the park-
ing brake can be set or
released manually.

Operating instructions

192

5-2. Driving procedures



When the shift position is
shifted to P, the parking brake
will be set, and the parking
brake indicator light will turn
on.

Operate the shift lever and P
position switch with the vehicle
stopped and the brake pedal
depressed.

■

Turns automatic mode off

While the vehicle is stopped,
press and hold the parking
brake switch until a message is
shown on the multi-information
display.

“EPB Shift Interlock Function
Deactivated”

Operate the shift lever and P
position switch with the vehicle
stopped and the brake pedal
depressed.

■

Parking brake operation

●

When the power switch is not in

ON, the parking brake cannot be

released using the parking brake

switch.

●

When the power switch is not in

ON, automatic mode (automatic

brake setting and releasing) is not

available.

■

Parking brake automatic

release function

●

When the shift position is shifted

from P, the parking brake will be

released in automatic mode.

●

When all of the following condi-

tions are met in manual mode, the

parking brake can be released by

depressing the accelerator pedal.

• The driver’s door is closed

• The driver is wearing the seat belt

• The shift position is in D or R

■

If “Parking Brake Temporarily

Unavailable” is displayed on

the multi-information display

If the parking brake is operated

repeatedly over a short period of

time, the system may restrict opera-

tion to prevent overheating. If this

happens, refrain from operating the

parking brake. Normal operation will

return after about 1 minute.

■

If “Parking Brake Unavailable”

is displayed on the multi-infor-

mation display

Operate the parking brake switch. If

the message does not disappear

after operating the switch several

times, the system may be malfunc-

tioning. Have the vehicle inspected

by your Toyota dealer.

■

Parking brake operation sound

When the parking brake operates, a

motor sound (whirring sound) may

be heard. This does not indicate a

malfunction.

■

Parking brake operation

●

Depending on the power switch

mode, the parking brake indicator

light will turn on and stay on as

described below:

ON: Comes on until the parking

brake is released.

Not in ON: Stays on for approxi-

mately 15 seconds.

●

When the power switch is turned

off with the parking brake set, the

parking brake indicator light will

stay on for about 15 seconds. This

193

5-2. Driving procedures

ing

does not indicate a malfunction.

■

When the parking brake switch

malfunctions

Automatic mode (automatic brake

setting and releasing) will be turned

on automatically.

■

Parking the vehicle



P.169

■

Parking brake engaged warning

buzzer

A buzzer will sound if the vehicle is

driven with the parking brake

engaged. “Parking Brake ON” is dis-

played on the multi-information dis-

play. (with the vehicle reached a

speed of 3 mph [5 km/h])

■

If the parking brake indicator

flashes



P.459

■

Usage in winter time



P.327

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle

alone. The parking brake may be

released unintentionally and there

is the danger of the vehicle mov-

ing that may lead to an accident

resulting in death or serious injury.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, set

the parking brake, shift the shift

position to P and make sure that

the vehicle does not move.

■

When the system malfunc-

tions

Stop the vehicle in a safe place

and check the warning messages.

■

When the parking brake can-

not be released due to a mal-

function

Driving the vehicle with the park-

ing brake set will lead to brake

components overheating, which

may affect braking performance

and increase brake wear.
Have the vehicle inspected by

your Toyota dealer immediately if

this occurs.

194

5-2. Driving procedures

Turns the brake hold system on

The brake hold standby indicator
(green)

comes on. While the

system is holding the brake, the
brake hold operated indicator (yel-
low)

comes on.

■

Brake hold system operating

conditions

The brake hold system cannot be

turned on in the following condi-

tions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat

belt.

●

The parking brake is engaged.

If any of the conditions above are

detected when the brake hold sys-

tem is enabled, the system will turn

off and the brake hold standby indi-

cator light will go off. In addition, if

any of the conditions are detected

while the system is holding the

brake, a warning buzzer will sound

and a message will be shown on the

multi-information display. The park-

ing brake will then be set automati-

cally.

■

Brake hold function

●

If the brake pedal is left released

for a period of about 3 minutes

after the system has started hold-

ing the brake, the parking brake

will be set automatically. In this

case, a warning buzzer sounds

and a message is shown on the

multi-information display.

●

To turn the system off while the

system is holding the brake, firmly

depress the brake pedal and

press the button again.

●

The brake hold function may not

hold the vehicle when the vehicle

is on a steep incline. In this situa-

tion, it may be necessary for the

driver to apply the brakes. A warn-

ing buzzer will sound and the

multi-information display will

inform the driver of this situation. If

a warning message is shown on

the multi-information display, read

the message and follow the

instructions.

■

When the parking brake is set

automatically while the system

is holding the brakes

Perform any of the following opera-

tions to release the parking brake.

●

Depress the accelerator pedal.

(The parking brake will not be

released automatically if the seat

belt is not fastened.)

●

Operate the parking brake switch

with the brake pedal depressed.

Brake Hold

The brake hold system
keeps the brake applied
when the shift position is in
D or N with the system on
and the brake pedal has
been depressed to stop the
vehicle. The system
releases the brake when the
accelerator pedal is
depressed with the shift
position in D to allow
smooth start off.

Enabling the system

Toyota Mirai (2023 year). Manual in english - page 11
