Toyota Mirai (2023 year). Manual in english - page 12

195

5-2. Driving procedures

ing

Make sure that the parking brake

indicator light goes off. (



P.191)

■

When an inspection at your

Toyota dealer is necessary

When the brake hold standby indi-

cator (green) does not illuminate

even when the brake hold switch is

pressed with the brake hold system

operating conditions met, the sys-

tem may be malfunctioning. Have

the vehicle inspected at your Toyota

dealer.

■

If “Brake Hold Malfunction

Press Brake to Deactivate Visit

Your Dealer” or “Brake Hold

Malfunction Visit Your Dealer”

is displayed on the multi-infor-

mation display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer.

■

Warning messages and buzzers

Warning messages and buzzers are

used to indicate a system malfunc-

tion or to inform the driver of the

need for caution. If a warning mes-

sage is shown on the multi-informa-

tion display, read the message and

follow the instructions.

■

If the brake hold operated indi-

cator flashes



P.459

WARNING

■

When the vehicle is on a

steep incline

When using the brake hold sys-

tem on a steep incline exercise

caution. The brake hold function

may not hold the vehicle in such a

situation.

■

When stopped on a slippery

road

The system cannot stop the vehi-

cle when the gripping ability of the

tires has been exceeded. Do not

use the system when stopped on

a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not

designed for use when parking

the vehicle for a long period of

time. Turning the power switch off

while the system is holding the

brake may release the brake,

which would cause the vehicle to

move. When operating the power

switch, depress the brake pedal,

shift the shift position to P and set

the parking brake.

196

5-2. Driving procedures

: If equipped

■

Customization

Some functions can be customized.

(



P.519)

■

Operating conditions

When the driving mode select

switch is not in Eco drive mode.

■

Temporary cancelation of the

ASC system functions

The ASC system may be temporar-

ily canceled depending on the driv-

ing conditions, such as when the

tires slip due to sudden accelera-

tion.
The tones may not sound if the driv-

ing mode is switched continuously

in short time periods.

When the H

O switch pressed

while the “READY” indicator is
on, the vehicle purges water.
When the switch is pressed
again, purging stops.

System purging and purging com-
plete messages are displayed in
the multi-information display.

■

Water release function during

cold weather

In the following cases, the fuel cell

system automatic drainage may not

operate. It may not be possible to

start the fuel cell system due to the

fuel cell stack, hydrogen pipes, etc.,

being frozen.

●

When transporting or towing the

ASC (Active Sound

Control)

The ASC is a system that
conveys the operating con-
ditions, such as accelera-
tion and deceleration of the
vehicle, with sounds to the
driver. The vehicle’s reac-
tion with regards to the
driver’s acceleration and
brake operations are con-
veyed with sound. The
respective tone changes for
normal mode and sport
mode. (



P.320)

Water release (H

switch)

When the fuel cell system is
stopped, water is automati-
cally purged from the tail-
pipe.

To minimize water accumu-
lation at parking garages,
etc., purge can be done
manually before parking.

O switch

197

5-2. Driving procedures

ing

vehicle in frozen areas

●

When the 12-volt battery terminals

are disconnected and remain as

such in frozen areas

Operate the water release function
with the following procedure before-
hand to prevent water from freezing
in the system.

Turn the power switch to ON and

press the H

O switch.

Check that the “Active Purge Mode

ON” message is displayed in the

multi-information display.

While depressing the brake,

press the power switch to start

the fuel cell system.

Check that the “READY” indicator

turns on.

Press the power switch to stop

the fuel cell system.

The water release is automatically

performed. (Longer than normal

water purge)

■

Purging while parked

The water release function does not

completely prevent purging while

parked. The purge capacity while

parked changes depending on out-

side temperature and operating con-

ditions.
If the “READY” indicator continues

to remain on after water release has

been performed, water may be gen-

erated and purged when parked.

198

5-3. Operating the lights and wipers

5-3.Operating the lights and wipers

Operating the

switch

turns on the lights as follows:

U.S.A.

Canada

The side marker, parking,

tail, license plate, instrument
panel lights, and daytime run-
ning lights (



P.198) turn on.

The headlights and all

lights listed above (except
daytime running lights) turn
on.

The headlights, daytime

running lights (



P.198) and

all the lights listed above turn
on and off automatically.

(if equipped) Off

■

AUTO mode can be used when

The power switch is in ON.

■

Daytime running light system

●

The daytime running lights illumi-

nate using the same lights as the

parking lights and illuminate

brighter than the parking lights.

(On some models: Using the

same lights as the headlights but

at a lower intensity.)

●

To make your vehicle more visible

to other drivers during daytime

driving, the daytime running lights

turn on automatically when all of

the following conditions are met.

(The daytime running lights are

not designed for use at night.)

• The fuel cell system is operating

• The parking brake is released

• The headlight switch is in the

position

: When the surroundings are bright

●

The daytime running lights remain

on after they illuminate, even if the

parking brake is set again.

●

For the U.S.A.: Daytime running

lights can be turned off by operat-

ing the switch.

●

Compared to turning on the head-

lights, the daytime running light

system offers greater durability

and consumes less electricity, so

it can help improve fuel economy.

Headlight switch

The headlights can be oper-
ated manually or automati-
cally.

Operating instructions

199

5-3. Operating the lights and wipers

ing

■

Headlight control sensor

The sensor may not function prop-

erly if an object is placed on the sen-

sor, or anything that blocks the

sensor is affixed to the windshield.

Doing so interferes with the sensor

detecting the level of ambient light

and may cause the automatic head-

light system to malfunction.

■

Automatic light off system

●

When the headlights are on: The
headlights and tail lights turn off
30 seconds after the driver’s door
is opened and closed if the power
switch is turned to ACC or off.
(The lights turn off immediately if

on the key is pressed after all

the doors are closed.)

●

When only the tail lights are on:

The tail lights turn off automati-

cally if the power switch is turned

to ACC or off and the driver’s door

is opened.

To turn the lights on again, turn the
power switch to ON, or turn the light
switch off once and then back to

■

Light reminder buzzer

A buzzer sounds when the power

switch is turned off or turned to ACC

and the driver’s door is opened

while the lights are turned on.

■

Automatic headlight leveling

system (if equipped)

The level of the headlights is auto-

matically adjusted according to the

number of passengers and the load-

ing condition of the vehicle to

ensure that the headlights do not

interfere with other road users.

■

Windshield wiper linked head-

light illumination

When driving during daytime with
the headlight switch turned to

, if

the windshield wipers are used, the
headlights will turn on automatically
after several seconds to help
enhance the visibility of your vehi-
cle.

■

12-volt battery-saving function

In order to prevent the 12-volt bat-

tery of the vehicle from discharging,

if the headlights and/or tail lights are

on when the power switch is turned

off the 12-volt battery saving func-

tion will operate and automatically

turn off all the lights after approxi-

mately 20 minutes. When the power

switch is turned to ON, the 12-volt

battery-saving function will be dis-

abled.

When any of the following are per-

formed, the 12-volt battery-saving

function is canceled once and then

reactivated. All the lights will turn off

automatically 20 minutes after the

12-volt battery-saving function has

been reactivated:

●

When the headlight switch is oper-

ated

●

When a door or the trunk is

opened or closed

■

Customization

Some functions can be customized.

(



P.512)

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the lights on longer

than necessary when the fuel cell

system is off.

200

5-3. Operating the lights and wipers

With the headlights on, push
the lever away from you to
turn on the high beams.

Pull the lever toward you to the
center position to turn the high
beams off.

Pull the lever toward you and
release it to flash the high
beams once.

You can flash the high beams with
the headlights on or off.

Press the Automatic High
Beam switch.

Turning on the high beam
headlights

AHB (Automatic High

Beam)

The Automatic High Beam
uses a front camera located
behind the upper portion of
the windshield to assess the
brightness of the lights of
vehicles ahead, street-
lights, etc., and automati-
cally turns the high beams
on or off as necessary.

WARNING

■

Limitations of the Automatic

High Beam

Do not overly rely on the Auto-

matic High Beam. Always drive

safely, taking care to observe your

surroundings and turning the high

beams on or off manually if nec-

essary.

■

To prevent incorrect opera-

tion of the Automatic High

Beam system

Do not overload the vehicle.

Activating the Automatic
High Beam

201

5-3. Operating the lights and wipers

ing

Turn the headlight switch to

the

position.

When the headlight switch lever is

in the low beam position, the AHB

system will be enabled and the

AHB indicator will illuminate.

■

Conditions to turn the high

beams on/off automatically

●

When all of the following condi-

tions are met, the high beams will

be turned on automatically (after

approximately 1 second):

• The vehicle speed is approxi-

mately 21 mph (34 km/h) or more.

• The area ahead of the vehicle is

dark.

• There are no vehicles ahead with

headlights or tail lights turned on.

• There are few streetlights on the

road ahead.

●

If any of the following conditions

are met, the high beams will turn

off automatically:

• The vehicle speed is below

approximately 17 mph (27 km/h).

• The area ahead of the vehicle is

not dark.

• Vehicles ahead have their head-

lights or tail lights turned on.

• There are many streetlights on the

road ahead.

■

Front camera detection infor-

mation

●

The high beams may not be auto-

matically turned off in the following

situations:

• When a vehicle suddenly appears

from around a curve

• When the vehicle is cut in front of

by another vehicle

• When vehicles ahead cannot be

detected due to repeated curves,

road dividers or roadside trees

• When vehicles ahead appear in a

faraway lane on a wide road

• When the lights of vehicles ahead

are not on

●

The high beams may be turned off

if a vehicle ahead that is using fog

lights without its headlights turned

on is detected.

●

House lights, street lights, traffic

signals, and illuminated billboards

or signs and other reflective

objects may cause the high

beams to change to the low

beams, or the low beams to

remain on.

●

The following factors may affect

the amount of time taken for the

high beams to turn on or off:

• The brightness of the headlights,

fog lights, and tail lights of vehi-

cles ahead

• The movement and direction of

vehicles ahead

• When a vehicle ahead only has

operational lights on one side

• When a vehicle ahead is a two-

wheeled vehicle

• The condition of the road (gradi-

ent, curve, condition of the road

surface, etc.)

• The number of passengers and

amount of luggage in the vehicle

●

The high beams may turn on or off

unexpectedly.

●

Bicycles or similar vehicles may

not be detected.

●

In the following situations the sys-

tem may not be able to correctly

detect the surrounding brightness

level. This may cause the low

beams to remain on or the high

beams to flash or dazzle pedestri-

ans or vehicles ahead. In such a

case, it is necessary to manually

switch between the high and low

beams.

202

5-3. Operating the lights and wipers

• When driving in inclement weather

(heavy rain, snow, fog, sand-

storms, etc.)

• When the windshield is obscured

by fog, mist, ice, dirt, etc.

• When the windshield is cracked or

damaged

• When the front camera is

deformed or dirty

• When the temperature of the front

camera is extremely high

• When the surrounding brightness

level is equal to that of headlights,

tail lights or fog lights

• When headlights or tail lights of

vehicles ahead are turned off,

dirty, changing color, or not aimed

properly

• When the vehicle is hit by water,

snow, dust, etc., from a preceding

vehicle

• When driving through an area of

intermittently changing brightness

and darkness

• When frequently and repeatedly

driving ascending/descending

roads, or roads with rough, bumpy

or uneven surfaces (such as

stone-paved roads, gravel roads,

etc.)

• When frequently and repeatedly

taking curves or driving on a wind-

ing road

• When there is a highly reflective

object ahead of the vehicle, such

as a sign or mirror

• When the back of a preceding

vehicle is highly reflective, such as

a container on a truck

• When the vehicle’s headlights are

damaged or dirty, or are not aimed

properly

• When the vehicle is listing or titling

due to a flat tire, a trailer being

towed, etc.

• When the headlights are changed

between the high beams and low

beams repeatedly in an abnormal

manner

• When the driver believes that the

high beams may be flashing or

dazzling pedestrians or other driv-

ers

■

Temporarily lowering sensor

sensitivity

The sensitivity of the sensor can be

temporarily lowered.

Turn the power switch off while

the following conditions are met.

●

The headlight switch is in

●

The headlight switch lever is in

low beam position.

●

Automatic High Beam switch is

on.

Turn the power switch to ON.

Within 60 seconds after step

repeat pushing the headlight

switch lever to the high beam

position then pulling it to the orig-

inal position quickly 10 times,

then leave the lever in the origi-

nal position.

If the sensitivity is changed, the

AHB indicator is turn on and off 3

times.

■

Switching to the high
beams

Push the lever away from you.

The AHB indicator will turn off and
the high beam indicator will turn on.
Pull the lever to its original position
to activate the Automatic High
Beam system.

Turning the high beams
on/off manually

203

5-3. Operating the lights and wipers

ing

■

Switching to the low beams

Press the Automatic High Beam
switch.

The AHB indicator will turn off.
Press the switch to activate the
Automatic High Beam system
again.

■

Temporarily switching to
the low beams

Pull the lever toward you and
then return it to its original posi-
tion.

The high beams are on while the
lever is pulled toward you. How-
ever, after the lever is returned to its
original position, the low beams
remain on for a certain period of
time. Afterwards, the Automatic
High Beam system will be activated
again.

■

Temporarily switching to the

low beams

It is recommended to switch to the

low beams when the high beam

may cause problems or distress to

other drivers or pedestrians nearby.

204

5-3. Operating the lights and wipers

Operate the

lever oper-

ates the wipers or washer as fol-
lows:



Intermittent windshield wip-
ers with interval adjuster

When intermittent windshield
wiper operation is selected, the
wiper interval can be also
adjusted.

(U.S.A.) or

(Canada)
Off

(U.S.A.) or

(Can-

ada)
Intermittent operation

(U.S.A.) or

(Can-

ada)
Low speed wiper operation

(U.S.A.) or

(Can-

ada)
High speed wiper operation

(U.S.A.) or

(Can-

ada)
Temporary operation

Wiper intervals can be adjusted
when intermittent operation is
selected.

Increases the intermittent
windshield wiper frequency

Decreases the intermittent
windshield wiper frequency

Windshield wipers and

washer

Operating the lever can
switch between automatic
operation and manual oper-
ation, or can use the
washer.

NOTICE

■

When the windshield is dry

Do not use the wipers, as they

may damage the windshield.

Operating the wiper lever

205

5-3. Operating the lights and wipers

ing

Washer/wiper dual

operation

Pulling the lever operates the wip-
ers and washer.
(After operating several times, the
wipers operate once more time
after a short delay to prevent drip-
ping. However, the dripping preven-
tion does not operate while the
vehicle is moving.)



Rain-sensing windshield wip-
ers

When

is selected, the wip-

ers will operate automatically
when the sensor detects falling
rain. The system automatically
adjusts wiper timing in accor-
dance with rain volume and
vehicle speed.

(U.S.A.) or

(Canada)

Off

Rain-sensing wiper oper-

ation

The wipers will operate automati-
cally when the sensor detects fall-
ing rain. The system automatically
adjusts wiper timing in accordance
with rain volume and vehicle speed.

(U.S.A.) or

(Canada)

Low speed wiper operation

(U.S.A.) or

(Canada)

High speed wiper operation

(U.S.A.) or

(Canada)

Temporary operation

When

is selected, the sen-

sor sensitivity can be adjusted
by turning the switch ring.

206

5-3. Operating the lights and wipers

Increases the sensitivity

Decreases the sensitivity

Washer/wiper dual

operation

Rear camera washer

operation

Pushing the lever operates the rear
camera washer and cleans the rear
camera and the camera for the Dig-
ital Rear-view Mirror.

: Vehicles with Digital Rear-view

Mirror

■

The windshield wiper and

washer can be operated when

The power switch is in ON.

■

Effects of vehicle speed on

wiper operation (vehicles with

rain-sensing windshield wipers)

Even when the wipers are not in

AUTO mode, vehicle speed affects

the time until the drip prevention

wiper sweep occurs.
With low speed windshield wiper

operation selected, wiper operation

will be switched from low speed to

intermittent wiper operation only

when the vehicle is stationary.

(However, when the sensor sensitiv-

ity is adjusted to the highest level,

the mode cannot be switched.)

■

Raindrop sensor (vehicles with

rain-sensing windshield wipers)

●

The raindrop sensor judges the

amount of raindrops.

An optical sensor is adopted. It

may not operate properly when

sunlight from the rising or setting

of the sun intermittently strikes the

windshield, or if bugs, etc., are

present on the windshield.

●

If the wiper is turned to AUTO

mode while the power switch is in

ON, the wipers will operate once

to show that AUTO mode is acti-

vated.

●

If the temperature of the raindrop

sensor is 185°F (85°C) or higher,

or 5°F (-15°C) or lower, automatic

operation may not occur. In this

case, operate the wipers in any

mode other than AUTO mode.

207

5-3. Operating the lights and wipers

ing

■

If no windshield washer fluid

sprays

Check that the washer nozzles are

not blocked if there is washer fluid in

the windshield washer fluid reser-

voir.

■

Front door opening linked wind-

shield wiper stop function

(vehicles with rain-sensing

windshield wipers)

When

is selected and the wind-

shield wipers are operating, if a front
door is opened while the vehicle is
stopped and the P shift position is
selected, operation of the wind-
shield wipers will be stopped to pre-
vent anyone near the vehicle from
being sprayed by water from the
wipers. When the front door is
closed, wiper operation will resume.

■

When stopping fuel cell system

in an emergency while driving

If the windshield wipers are operat-

ing when fuel cell system is

stopped, the windshield wipers will

operate in high speed operation.

After the vehicle is stopped, opera-

tion will return to normal when the

power switch is turned to ON, or

operation will stop when the driver’s

door is opened.

When the windshield wipers are
not being used, they retract to
below the hood. To enable the
windshield wipers to be lifted

WARNING

■

Caution regarding the use of

windshield wipers in AUTO

mode (vehicles with rain-

sensing windshield wipers)

The windshield wipers may oper-

ate unexpectedly if the sensor is

touched or the windshield is sub-

ject to vibration in AUTO mode.

Take care that your fingers or any-

thing else do not become caught

in the windshield wipers.

■

Caution regarding the use of

washer fluid

When it is cold, do not use the

washer fluid until the windshield

becomes warm. The fluid may

freeze on the windshield and

cause low visibility. This may lead

to an accident, resulting in death

or serious injury.

NOTICE

■

When there is no washer fluid

spray from the nozzle

Damage to the washer fluid pump

may be caused if the lever is

pulled toward you and held con-

tinually.

■

When a nozzle becomes

blocked

In this case, contact your Toyota

dealer.

Do not try to clear it with a pin or

other object. The nozzle will be

damaged.

Changing the windshield
wiper rest position/Lifting
the windshield wipers

208

5-3. Operating the lights and wipers

when parking in cold conditions
or when replacing a windshield
wiper insert, change the rest
position of the windshield wipers
to the service position using the
wiper lever.

■

Raising the wipers to the
service position

Within approximately 45 sec-
onds of turning the power switch
off, move the wiper lever to the

(U.S.A.) or

(Canada)

position and hold it for approxi-
mately 2 seconds or more.

The wipers will move to the service
position.

■

Lifting the windshield wip-
ers

While holding the hook portion

of the wiper arm, lift the wind-

shield wiper from the wind-

shield.

■

Lowering the windshield wipers

to the retracted position

With the windshield wipers placed

on the windshield, turn the power

switch to ON and then move the

wiper lever to an operating position.

When the wiper switch is turned off,

the windshield wipers will stop at the

retracted position. Even if the wipers

deviate while the power switch is off,

the wipers will return to the normal

position.

NOTICE

■

When lifting the windshield

wipers

●

Do not lift the windshield wipers

when they are in the retracted

position below the hood. Other-

wise, they may contact the

hood, possibly resulting in dam-

age to a windshield wiper and/or

the hood.

●

Do not lift a windshield wiper by

the wiper blade. Otherwise, the

wiper blade may be deformed.

209

5-3. Operating the lights and wipers

ing

NOTICE

●

Do not operate the wiper lever

when the windshield wipers are

lifted. Otherwise, the wind-

shield wipers may contact the

hood, possibly resulting in dam-

age to the windshield wipers

and/or hood.

210

5-4. Refueling

5-4.Refueling



Close the all the doors and
windows.



Set the parking brake.



Shift the shift position to P.



Turn the power switch off.



Turn off the headlights.

■

Fuel types



P.497

■

Notes on fueling

●

Fueling will not be possible if the

pressure inside the vehicle’s

hydrogen tanks is higher than the

supply pressure of the hydrogen

station. If the hydrogen tanks are

more than half full, the vehicle will

be unable to fuel at a H35 dis-

penser. A hydrogen station with a

H70 dispenser (supply pressure of
10150 psi) [70 MPa, 714 kgf/cm

700 bar] is necessary to com-

pletely fill hydrogen tanks.

●

If the fueling cannot be completed

due to trouble with the station

equipment, call the number indi-

cated on the equipment.

Opening the fuel door



Fuel with compressed
hydrogen gas only at hydro-
gen stations.



Fuel at hydrogen stations
conforming with the Society
of Automotive Engineers
(SAE) J2601 fueling proto-
col or laws that may super-
sede such SAE protocols.



Refer to the Mirai Station
Finder Application in Con-
nected services,
https://www.toyota.com/
connected-services/ (for
U.S. owners) or
https://www.toyota.ca/
toyota/en/about/
connected-services (for
Canadian owners), or call
1-800-331-4331 (for U.S.
owners) or 1-888-869-6828
(for Canadian owners).



Observe any notices or
instructions shown at hydro-
gen stations.



The filling time and amount
of fuel may depend on out-
side temperature and the
equipment at that hydrogen
station.



Vehicles with expired hydro-
gen tanks must not be used.
Check P.83 to learn how
and when to check the expi-
ration. Consult your Toyota
dealer.

Before filling

WARNING

■

When filling

Observe the following precautions

while fueling the vehicle. Failure

to do so may result in death or

serious injury.

Content .. 10 11 12 13 ..
