Toyota Mirai (2023 year). Manual in english

161

4-4. Adjusting the steering wheel and mirrors

Before

driving

view mirror defoggers. (



P.335,

342)

■

Automatic adjustment of the

mirror angle (if equipped)

A desired mirror face angle can be

entered to memory and recalled

automatically by the driving position

memory. (



P.142)

Folds the mirrors

Extends the mirrors

Putting the switch in the neutral
position sets the mirrors to auto-
matic mode. Automatic mode
allows the folding or extending of
the mirrors to be linked to lock-
ing/unlocking of the doors.

■

Customization

Some functions can be customized.

(



P.512)

When either “L” or “R” of the mir-
ror select switch is selected, the
outside rear view mirrors will
automatically angle downwards
when the vehicle is reversing in
order to give a better view of the
ground.
To disable this function, select
neither “L” nor “R”.

■

Adjusting the mirror angle
when the vehicle is revers-
ing

With the shift position in R,
adjust the mirror angle at a
desired position.
The adjusted angle will be mem-
orized and the mirror will auto-
matically tilt to the memorized
angle whenever the shift posi-
tion is shifted to R from next
time.

The memorized downward tilt posi-
tion of the mirror is linked to the
normal position (angle adjusted
with the shift position in other than
R). Therefore, if the normal position
is changed after adjustment, the tilt
position will also change.
When the normal position is
changed, readjust the angle in
reversing.

WARNING

■

When the mirror defoggers

are operating

Do not touch the rear view mirror

surfaces, as they can become

very hot and burn you.

Folding and extending the
mirrors

WARNING

■

When a mirror is moving

To avoid personal injury and mir-

ror malfunction, be careful not to

get your hand caught by the mov-

ing mirror.

Linked mirror function
when reversing

162

4-5. Opening, closing the windows

4-5.Opening, closing the windows

The power windows can be
opened and closed using the
switches.
Operating the switch moves the
windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway,

operate the switch in the opposite
direction.

■

The power windows can be

operated when

The power switch is in ON

■

Operating the power windows

after turning the fuel cell sys-

tem off

The power windows can be oper-

ated for approximately 45 seconds

even after the power switch is

turned to ACC or turned off. They

cannot, however, be operated once

either front door is opened.

■

Jam protection function

If an object becomes jammed

between the window and the win-

dow frame while the window is clos-

ing, window movement is stopped

and the window is opened slightly.

■

Catch protection function

If an object becomes caught

between the door and window while

the window is opening, window

movement is stopped.

■

When the side window cannot

be opened or closed

When the jam protection function or

catch protection function operates

unusually and the side window can-

not be opened or closed, perform

the following operations with the

power window switch of that door.

●

Stop the vehicle. With the power

switch in ON, within 4 seconds of

the jam protection function or

catch protection function activat-

ing, continuously operate the

power window switch in the one-

touch closing direction or one-

touch opening direction so that the

side window can be opened and

closed.

●

If the side window cannot be

opened and closed even when

performing the above operations,

perform the following procedure

for function initialization.

Turn the power switch to ON.

Pull and hold the power window

switch in the one-touch closing

direction and completely close

the side window.

Release the power window

switch for a moment, resume

pulling the switch in the one-

touch closing direction, and hold

it there for approximately 6 sec-

onds or more.

Press and hold the power win-

dow switch in the one-touch

opening direction. After the side

window is completely opened,

continue holding the switch for

an additional 1 second or more.

Power windows

Opening and closing the
power windows

163

4-5. Opening, closing the windows

Before

driving

Release the power window

switch for a moment, resume

pushing the switch in the one-

touch opening direction, and

hold it there for approximately 4

seconds or more.

Pull and hold the power window

switch in the one-touch closing

direction again. After the side

window is completely closed,

continue holding the switch for a

further 1 second or more.

If you release the switch while the

window is moving, start again from

the beginning.

If the window reverses and cannot

be fully closed or opened, have the

vehicle inspected by your Toyota

dealer.

■

Door lock linked window opera-

tion

●

The power windows can be

opened and closed using the
mechanical key.

(



P.483)

●

The power windows can be

opened using the wireless remote
control.

(



P.127)

: These settings must be custom-

ized at your Toyota dealer.

■

Power windows open warning

buzzer

A buzzer sounds and a message is

shown on the multi-information dis-

play in the instrument cluster when

the power switch is turned off and

the driver’s door is opened with the

power windows open.

■

Customization

Some functions can be customized.

(



P.512)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Closing the windows

●

The driver is responsible for all

the power window operations,

including the operation for the

passengers. In order to prevent

accidental operation, especially

by a child, do not let a child

operate the power windows. It is

possible for children and other

passengers to have body parts

caught in the power window.

Also, when riding with a child, it

is recommended to use the win-

dow lock switch. (



P.164)

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When using the wireless remote

control or mechanical key and

operating the power windows,

operate the power window after

checking to make sure that

there is no possibility of any

passenger having any of their

body parts caught in the win-

dow. Also do not let a child

operate window by the wireless

remote control or mechanical

key. It is possible for children

and other passengers to get

caught in the power window.

●

When exiting the vehicle, turn

the power switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

164

4-5. Opening, closing the windows

This function can be used to
prevent children from acciden-
tally opening or closing a pas-
senger window.
Press the switch.

The indicator

will come on and

the passenger windows will be
locked.
The passenger windows can still be
opened and closed using the
driver’s switch even if the lock
switch is on.

■

The power windows can be

operated when

The power switch is in ON.

■

When the 12-volt battery is dis-

connected

The window lock switch is disabled.

If necessary, press the window lock

switch after reconnecting the 12-volt

battery.

WARNING

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

jammed just before the window

is fully closed. Be careful not to

get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body

or clothing to intentionally acti-

vate the catch protection func-

tion.

●

The catch protection function

may not work if something gets

caught just before the window is

fully opened. Be careful not to

get any part of your body or

clothing caught in the window.

Preventing accidental
operation (window lock
switch)

165

4-6. Favorite settings

Before

driving

4-6.Favorite settings

An individual can be identified
using the following authentica-
tion devices.



Bluetooth devices

An individual can be detected if the
same Bluetooth device that was
used as a handsfree phone the last
time the vehicle was entered is con-
nected to the audio system.

When an individual is identified
from an authentication device,
settings for the following func-
tions are recalled.



Vehicle settings that can be
set using the multimedia dis-
play

When an individual is identified, the
vehicle settings used when the
power switch was last turned off are
recalled.

My Settings

By recognizing an individ-
ual through Bluetooth
devices, the vehicle settings
recorded for that driver can
be recalled when that indi-
vidual enters the vehicle. By
assigning an authentication
device to a driver in
advance, the vehicle can be
entered with the preferred
settings of the driver. Set-
tings for up to 3 drivers can
be recorded with My Set-
tings. For details on how to
assign/delete Bluetooth
devices, set driver names,
perform initialization,
change drivers manually, or
delete a driver, refer to the
“MULTIMEDIA OWNER’S
MANUAL”.

Types of assigned
authentication devices

Recalled functions

167

ing

Driving

5-1. Before driving

Driving the vehicle.......

169

Cargo and luggage .....

175

Vehicle load limits .......

178

Trailer towing...............

179

Dinghy towing .............

179

5-2. Driving procedures

Power switch...............

180

Shift position ...............

185

Turn signal lever..........

190

Parking brake..............

191

Brake Hold ..................

194

ASC (Active Sound Control)

..................................

196

Water release (H

O switch)

..................................

196

5-3. Operating the lights and

wipers

Headlight switch..........

198

AHB (Automatic High

Beam)........................

200

Windshield wipers and

washer.......................

204

5-4. Refueling

Opening the fuel door .

210

5-5. Using the driving support

systems

Toyota Safety Sense 2.5 +

..................................

214

PCS (Pre-Collision System)

..................................

219

LTA (Lane Tracing Assist)

..................................

230

RSA (Road Sign Assist)

..................................

241

Dynamic radar cruise con-

trol with full-speed range

..................................

244

BSM (Blind Spot Monitor)

..................................

256

Intuitive parking assist.

261

RCTA (Rear Cross Traffic

Alert)..........................

272

RCD (Rear Camera Detec-

tion) ...........................

277

PKSB (Parking Support

Brake)........................

281

Parking Support Brake func-

tion (static objects front
and rear of the vehi-
cle/static objects around
the vehicle) ................

286

Parking Support Brake func-

tion (moving vehicle rear of
the vehicle) ................

290

Parking Support Brake func-

tion (pedestrians rear of
the vehicle) ................

291

169

5-1. Before driving

ing

5-1.Before driving

■

Starting the fuel cell system



P.180

■

Driving

With the brake pedal
depressed, shift the shift
position to D.

Check that the shift position indica-

tor shows D.

If the parking brake is set,
release the parking brake.
(



P.191)

Gradually release the brake
pedal and gently depress the
accelerator pedal to acceler-
ate the vehicle.

■

Stopping

Depress the brake pedal.

If necessary, set the parking
brake.

If the vehicle is to be stopped for an

extended period of time, shift the

shift position to P. (



P.185)

■

Parking the vehicle

Depress the brake pedal to
stop the vehicle completely.

If the parking brake is
released, set the parking
brake. (



P.191)

Shift the shift position to P.
(



P.185)

Check that the shift position indica-

tor shows P and the parking brake

indicator is illuminated.

Press the power switch to
stop the fuel cell system.

Slowly release the brake
pedal.

Lock the door, making sure
that you have the electronic
key on your person.

If parking on a hill, block the wheels

as needed.

■

Starting off on a steep
uphill

Firmly depress the brake
pedal and shift the shift posi-
tion to D.

The hill-start assist control will be

activated.

Set the parking brake.
(



P.191)

Release the brake pedal and
gently depress the accelera-
tor pedal to accelerate the
vehicle.

Release the parking brake.
(



P.191)

■

For fuel-efficient driving

Keep in mind that fuel cell electric

vehicles are similar to conventional

vehicles, and it is necessary to

refrain from activities such as sud-

den acceleration. (



P.91)

■

Driving in the rain

●

Drive carefully when it is raining,

because visibility will be reduced,

the windows may become fogged-

Driving the vehicle

The following procedures
should be observed to
ensure safe driving:

Driving procedure

170

5-1. Before driving

up, and the road will be slippery.

●

Drive carefully when it starts to

rain, because the road surface will

be especially slippery.

●

Refrain from high speeds when

driving on an expressway in the

rain, because there may be a

layer of water between the tires

and the road surface, preventing

the steering and brakes from

operating properly.

■

ECO Accelerator Guidance

(



P.108)

Eco-friendly driving may be

achieved more easily by staying

within the zone of Eco acceleration.

Also, by staying within the zone of

Eco acceleration, it will be easier to

obtain a good Eco score.

●

When starting off:

Gradually depress the accelerator
pedal to stay within the zone of Eco
acceleration and accelerate to the
desired speed. By refraining from
excessive acceleration, a good eco
start score will be obtained.

●

When driving:

After accelerating to the desired
speed, release the accelerator
pedal and drive at a stable speed
while staying within the zone of Eco
acceleration. By staying within the
zone of Eco acceleration, a good
eco cruise score will be obtained.

●

When stopping:

By starting to release the accelera-
tor pedal early before decelerating,
a good eco stop score will be
obtained.

■

Restraining the fuel cell system

output (Brake Override System)

●

When the accelerator and brake

pedals are depressed at the same

time, the fuel cell system output

may be restrained.

●

A warning message is displayed

on the multi-information display

while the system is operating.

■

Breaking in your new Toyota

To extend the life of the vehicle,

observing the following precautions

is recommended:

●

For the first 186 miles (300 km):

Avoid sudden stops.

●

For the first 621 miles (1000 km):

• Do not drive at extremely high

speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low

gears.

• Do not drive at a constant speed

for extended periods.

■

Drum-in-disc type parking

brake system

Your vehicle has a drum-in-disc type

parking brake system. This type of

brake system needs bedding-down

of the brake shoes periodically or

whenever the parking brake shoes

and/or drum are replaced. Have

your Toyota dealer perform the bed-

ding down operation.

■

Operating your vehicle in a for-

eign country

Comply with the relevant vehicle

registration laws and confirm the

availability of the correct fuel.

(



P.497)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

When starting the vehicle

Always keep your foot on the

brake pedal while stopped with

the “READY” indicator is illumi-

nated. This prevents the vehicle

from creeping.

171

5-1. Before driving

ing

WARNING

■

When driving the vehicle

●

Do not drive if you are unfamil-

iar with the location of the brake

and accelerator pedals to avoid

depressing the wrong pedal.

• Accidentally depressing the

accelerator pedal instead of the

brake pedal will result in sudden

acceleration that may lead to an

accident.

• When backing up, you may twist

your body around, leading to dif-

ficulty in operating the pedals.

Make sure to operate the pedals

properly.

• Make sure to keep a correct

driving posture even when mov-

ing the vehicle only slightly. This

allows you to depress the brake

and accelerator pedals properly.

• Depress the brake pedal using

your right foot. Depressing the

brake pedal using your left foot

may delay response in an emer-

gency, resulting in an accident.

●

The driver should pay extra

attention to pedestrians as this

vehicle is powered only by an

electric motor (traction motor).

As there is no engine noise, the

pedestrians may misjudge the

vehicle’s movement. Even with

the acoustic vehicle alerting

system activate, drive with care

as pedestrians in the vicinity

may still not notice the vehicle if

the surrounding area is noisy.

●

During normal driving, do not

turn off the fuel cell system.

Turning the fuel cell system off

while driving will not cause loss

of steering or braking control,

however, power assist to the

steering will be lost. This will

make it more difficult to steer

smoothly, so you should pull

over and stop the vehicle as

soon as it is safe to do so.

In the event of an emergency,

such as if it becomes impossible

to stop the vehicle in the normal

way:



P.446

●

Using the brakes continuously

may cause the brakes to over-

heat and lose effectiveness

when driving down a steep hill.

●

Do not adjust the positions of

the steering wheel, the seat, or

the inside or outside rear view

mirrors while driving.

Doing so may result in a loss of

vehicle control.

●

Always check that all passen-

gers’ arms, heads or other parts

of their body are not outside the

vehicle.

●

Do not drive in excess of the

speed limit. Even if the legal

speed limit permits it, do not

drive over 85 mph (140 km/h)

unless your vehicle has high-

speed capability tires. Driving

over 85 mph (140 km/h) may

result in tire failure, loss of con-

trol and possible injury. Be sure

to consult a tire dealer to deter-

mine whether the tires on your

vehicle are high-speed capabil-

ity tires or not before driving at

such speeds.

■

When driving on slippery

road surfaces

●

Sudden braking, acceleration

and steering may cause tire

slippage and reduce your ability

to control the vehicle.

172

5-1. Before driving

WARNING

●

Sudden acceleration or regen-

erative braking due to shifting

could cause the vehicle to skid.

●

After driving through a puddle,

lightly depress the brake pedal

to make sure that the brakes

are functioning properly. Wet

brake pads may prevent the

brakes from functioning prop-

erly. If the brakes on only one

side are wet and not functioning

properly, steering control may

be affected.

■

When shifting the shift posi-

tion

●

Do not let the vehicle roll back-

ward while a forward driving

position is selected, or roll for-

ward while the shift position is in

Doing so may result in an acci-

dent or damage to the vehicle.

●

Do not shift the shift position to

P while the vehicle is moving.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

R while the vehicle is moving

forward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift position to

a driving position while the vehi-

cle is moving backward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Changing the shift position to N

while the vehicle is moving will

disengage the fuel cell system.

Regenerative braking is not

available with the fuel cell sys-

tem disengaged.

●

Be careful not to change the

shift position with the accelera-

tor pedal depressed. Changing

the shift position to any posi-

tions other than P or N may lead

to unexpected rapid accelera-

tion of the vehicle that may

cause an accident and result in

death or serious injury.

After changing the shift position,

make sure to confirm the cur-

rent shift position displayed on

the shift position indicator inside

the meter.

■

If you hear a squealing or

scraping noise (brake pad

wear limit indicators)

Have the brake pads checked and

replaced by your Toyota dealer as

soon as possible.

Rotor damage may result if the

pads are not replaced when

needed.

It is dangerous to drive the vehicle

when the wear limits of the brake

pads and/or those of the brake

discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator

pedal unnecessarily.

If the shift position is in any

position other than P or N, the

vehicle may accelerate sud-

denly and unexpectedly, caus-

ing an accident.

●

In order to prevent accidents

due to the vehicle rolling away,

always keep depressing the

brake pedal while stopped with

the “READY” indicator is illumi-

nated, and apply the parking

brake as necessary.

173

5-1. Before driving

ing

WARNING

●

If the vehicle is stopped on an

incline, in order to prevent acci-

dents caused by the vehicle roll-

ing forward or backward, always

depress the brake pedal and

securely apply the parking

brake as needed.

■

When the vehicle is parked

●

Do not leave glasses, cigarette

lighters, spray cans, or soft

drink cans in the vehicle when it

is in the sun.

Doing so may result in the fol-

lowing:

• Gas may leak from a cigarette

lighter or spray can, and may

lead to a fire.

• The temperature inside the

vehicle may cause the plastic

lenses and plastic material of

glasses to deform or crack.

• Soft drink cans may fracture,

causing the contents to spray

over the interior of the vehicle,

and may also cause a short cir-

cuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in

the vehicle. If a cigarette lighter

is in a place such as the glove

box or on the floor, it may be lit

accidentally when luggage is

loaded or the seat is adjusted,

causing a fire.

●

Do not attach adhesive discs to

the windshield or windows. Do

not place containers such as air

fresheners on the instrument

panel or dashboard. Adhesive

discs or containers may act as

lenses, causing a fire in the

vehicle.

●

Do not leave a door or window

open if the curved glass is

coated with a metallized film

such as a silver-colored one.

Reflected sunlight may cause

the glass to act as a lens, caus-

ing a fire.

●

Always apply the parking brake,

shift the shift position to P, stop

the fuel cell system and lock the

vehicle.

Do not leave the vehicle unat-

tended while the “READY” indi-

cator is illuminated.

If the vehicle is parked with the

shift position in P but the park-

ing brake is not set, the vehicle

may start to move, possibly

leading to an accident.

■

When taking a nap in the vehi-

cle

Always turn the fuel cell system

off. Otherwise, if you accidentally

move the shift lever or depress

the accelerator pedal, causing the

vehicle to unintentionally move,

which can lead to an accident,

resulting in death or serious injury.

■

When braking

●

When the brakes are wet, drive

more cautiously.

Braking distance increases

when the brakes are wet, and

this may cause one side of the

vehicle to brake differently than

the other side. Also, the parking

brake may not securely hold the

vehicle.

●

If the electronically controlled

brake system does not operate,

do not follow other vehicles

closely and avoid hills or sharp

turns that require braking.

In this case, braking is still pos-

sible, but the brake pedal

should be depressed more

firmly than usual. Also, the brak-

ing distance will increase. Have

your brakes fixed immediately.

174

5-1. Before driving

WARNING

●

The brake system consists of 2

or more individual hydraulic sys-

tems; if one of the systems fails,

the other(s) will still operate. In

this case, the brake pedal

should be depressed more

firmly than usual and the brak-

ing distance will increase. Have

your brakes fixed immediately.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator

and brake pedals at the same

time during driving, as this may

restrain the fuel cell system out-

put.

●

Do not use the accelerator

pedal or depress the accelera-

tor and brake pedals at the

same time to hold the vehicle on

a hill.

■

When parking the vehicle

Always set the parking brake, and

shift the shift position to P. Failure

to do so may cause the vehicle to

move or the vehicle may acceler-

ate suddenly if the accelerator

pedal is accidentally depressed.

■

Avoiding damage to vehicle

parts

●

Do not turn the steering wheel

fully in either direction and hold

it there for an extended period

of time.

Doing so may damage the

power steering motor.

●

When driving over bumps in the

road, drive as slowly as possible

to avoid damaging the wheels,

underside of the vehicle, etc.

■

If you get a flat tire while driv-

ing

A flat or damaged tire may cause

the following situations. Hold the

steering wheel firmly and gradu-

ally depress the brake pedal to

slow down the vehicle.

●

It may be difficult to control your

vehicle.

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnor-

mally.

Information on what to do in case

of a flat tire (



P.467)

■

When encountering flooded

roads

Do not drive on a road that has

flooded after heavy rain, etc.

Doing so may cause the following

serious damage to the vehicle:

●

Fuel cell system stalling

●

Short in electrical components

●

Fuel cell system damage

caused by water immersion

In the event that you drive on a

flooded road and the vehicle is

flooded, be sure to have your Toy-

ota dealer check the following:

●

Fuel cell system

●

Brake function

●

Changes in quantity and quality

of transmission fluid, etc.

●

Lubricant condition for the bear-

ings and suspension joints

(where possible), and the func-

tion of all joints, bearings, etc.

175

5-1. Before driving

ing

When the following unusual
operation is performed with the
accelerator pedal depressed,
the fuel cell system output may
be restrained.
• When the shift position is

shifted to R

• When the shift position is

shifted from P or R to forward
drive shift position such as D

When the system operates, a mes-
sage appears on the multi-informa-
tion display. Read the message and
follow the instruction.

: Depending on the situation, the

shift position may not be
changed.

■

Drive-Start Control (DSC)

●

When the TRAC is turned off

(



P.323), sudden start restraint

control also does not operate. If

your vehicle have trouble escap-

ing from the mud or fresh snow

due to sudden start restraint con-

trol operation, deactivate TRAC

(



P.323) so that the vehicle may

become able to escape from the

mud or fresh snow.

Cargo capacity depends on the
total weight of the occupants.
(Cargo capacity) = (Total load
capacity) — (Total weight of
occupants)
Steps for Determining Correct
Load Limit —
(1) Locate the statement “The
combined weight of occupants
and cargo should never exceed
XXX kg or XXX lbs.” on your
vehicle’s placard.
(2) Determine the combined
weight of the driver and passen-
gers that will be riding in your
vehicle.
(3) Subtract the combined
weight of the driver and passen-
gers from XXX kg or XXX lbs.
(4) The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1400 lbs. and
there will be five 150 lb passen-
gers in your vehicle, the amount
of available cargo and luggage
load capacity is 650 lbs. (1400 −
750 (5



150) = 650 lbs.)

NOTICE

If the shift control system is dam-

aged by flooding, it may not be

possible to shift the shift position

to P, or from P to other positions.

In this case, contact your Toyota

dealer.

Sudden start restraint
control (Drive-Start Con-
trol [DSC])

Cargo and luggage

Take notice of the following
information about storage
precautions, cargo capacity
and load:

Capacity and distribution

176

5-1. Before driving

(5) Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo and
luggage load capacity calcu-
lated in Step 4.
(6) If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your vehi-
cle. Consult this manual to
determine how this reduces the
available cargo and luggage
load capacity of your vehicle.
(



P.178)

Toyota does not recommend towing
a trailer with your vehicle. Your
vehicle is not designed for trailer
towing.

Cargo capacity

Total load capacity (vehicle
capacity weight) (



P.496)

When 2 people with the com-
bined weight of A lb. (kg) are rid-
ing in your vehicle, which has a
total load capacity (vehicle

capacity weight) of B lb. (kg),
the available amount of cargo
and luggage load capacity will
be C lb. (kg) as follows:

lb. (kg) - A

lb. (kg) = C

lb.

(kg)

:A =Weight of people

:B =Total load capacity

:C =Available cargo and luggage

load

In this condition, if 3 more passen-
gers with the combined weight of D
lb. (kg) get on, the available cargo
and luggage load will be reduced E
lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb.

(kg)

:D =Additional weight of people

:E =Available cargo and luggage

load

As shown in the example above,
if the number of occupants
increases, the cargo and lug-
gage load will be reduced by an
amount that equals the
increased weight due to the
additional occupants. In other
words, if an increase in the num-
ber of occupants causes an
excess of the total load capacity
(combined weight of occupants
plus cargo and luggage load),
you must reduce the cargo and
luggage on your vehicle.

Calculation formula for
your vehicle

177

5-1. Before driving

ing

WARNING

■

Things that must not be car-

ried in the trunk

The following things may cause a

fire if loaded in the trunk:

●

Receptacles containing gaso-

line

●

Aerosol cans

■

Storage precautions

Observe the following precau-

tions.

Failure to do so may prevent the

pedals from being depressed

properly, may block the driver’s

vision, or may result in items hit-

ting the driver or passengers, pos-

sibly causing an accident.

●

Stow cargo and luggage in the

trunk whenever possible.

●

Do not place cargo or luggage

in or on the following locations.

• At the feet of the driver

• On the front passenger or rear

seats (when stacking items)

• On the package tray

• On the instrument panel

• On the dashboard

●

Secure all items in the occupant

compartment.

■

Capacity and distribution

●

Do not exceed the maximum

axle weight rating or the total

vehicle weight rating.

●

Even if the total load of occu-

pant’s weight and the cargo

load is less than the total load

capacity, do not apply the load

unevenly. Improper loading may

cause deterioration of steering

or braking control which may

cause death or serious injury.

NOTICE

■

Roof film (vehicles with elec-

tronic sunshade)

Do not attach a roof carrier on the

roof film. It may damage the film

surface.

178

5-1. Before driving

■

Total load capacity and seating

capacity

These details are also described on

the tire and loading information

label. (



P.428)

Vehicle load limits

Vehicle load limits include
total load capacity, seating
capacity, towing capacity
and cargo capacity.



Total load capacity (vehicle
capacity weight):



P.496

Total load capacity means the
combined weight of occu-
pants, cargo and luggage.



Seating capacity:



P.496

Seating capacity means the
maximum number of occu-
pants whose estimated aver-
age weight is 150 lb. (68 kg)
per person.



TWR (Trailer Weight Rat-
ing)

Toyota does not recommend
towing a trailer with your vehi-
cle.



Cargo capacity

Cargo capacity may increase
or decrease depending on the
weight and the number of
occupants.

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to

the tires, but also degrade steer-

ing and braking ability, resulting in

an accident.

Toyota Mirai (2023 year). Manual in english - page 10
