If a warning message is displayed

Master warning light

The  master  warning  light  also
comes  on  or  flashes  in  order  to
indicate  that  a  message  is  cur-
rently being displayed on the multi-
information display.

Multi-information display
Handling method

Follow the instructions of the mes-
sage on the multi-information dis-
play.

If any of the warning messages are shown again after the following
actions have been performed, contact your Toyota dealer.

: The master warning light may not come on or flash when a warning mes-

sage is displayed.

The multi-information display shows warnings of system mal-
functions, incorrectly performed operations, and messages that
indicate a need for maintenance. When a message is shown,
perform the correction procedure appropriate to the message.

2
3

600

The warning lights and warning buzzers operate as follows depending
on the content of the message. If a message indicates the need for
inspection by a dealer, have the vehicle inspected by your Toyota
dealer immediately.

The operation of the warning lights and warning buzzers may differ
from those stated. In this case, perform the correction procedure
according to the displayed message.

: A buzzer sounds the first time a message is shown on the multi-informa-

tion display.

Messages and warnings

System

warning

light

Warning

buzzer

Warning

Comes on



Sounds

Indicates an important situation, such
as when a system related to driving is
malfunctioning or that danger may
result if the correction procedure is not
performed



Comes on

or flashes

Sounds

Indicates  an  important  situation,  such
as  when  the  systems  shown  on  the
multi-information  display  may  be  mal-
functioning

Flashes



Sounds

Indicates a situation, such as when
damage to the vehicle or danger may
result

Comes on



Does not

sound

Indicates a condition, such as mal-
function of electrical components, their
condition, or indicates the need for
maintenance

Flashes



Does not

sound

Indicates a situation, such as when an
operation has been performed incor-
rectly, or indicates how to perform an
operation correctly

601

Wh
en tro

■

Warning messages

The warning messages explained below may differ from the actual messages
according to operation conditions and vehicle specifications.

■

System warning lights

The master warning light does not come on or flash in the following cases.
Instead, a separate system warning light will come on along with a message
or image shown on the multi-information display.

●

“Antilock Brake System Malfunction Visit Your Dealer”:
The ABS warning light comes on. (



P. 589)

●

“Braking Power Low Visit Your Dealer”:
The brake system warning light (yellow) will come on. (

P. 588)

●

Indicates that a door is not fully closed while the vehicle is stopped.:
The Open door warning light comes on. (

P. 590)

■

If “Visit Your Dealer” is shown

The system or part shown on the multi-information display is malfunctioning.
Have the vehicle inspected by your Toyota dealer.

■

If a message about an operation is shown

●

If a message about an operation of the accelerator pedal or brake pedal is
shown
• A warning message about an operation of the brake pedal may be shown

while the driving assist systems such as PCS (Pre-Collision System) (if
equipped) or the dynamic radar cruise control with full-speed range (if
equipped) is operating. If a warning message is shown, be sure to decel-
erate the vehicle or follow an instruction shown on the multi-information
display.

• A warning message is shown when Brake Override System operates.

(



P. 223, 604)

• A warning message is shown when Drive-Start Control or Parking Sup-

port Brake function (if equipped) operates (

P. 224, 376). Follow the

instructions on the multi-information display.

●

If a message about an operation of the power switch is shown
An instruction for operation of the power switch is shown when the incorrect
procedure for starting the hybrid system is performed or the power switch is
operated incorrectly. Follow the instructions shown on the multi-information
display to operate the power switch again.

●

If a message about a shift operation is shown
To prevent the shift position from being selected incorrectly or the vehicle
from moving unexpectedly, the shift position may be changed automatically
(



P. 251) or shift operation may be required. In this case, change the shift

position following the instructions on the multi-information display.

●

If a message or image about an open/close state of a part or replenishment
of a consumable is shown
Confirm the part indicated by the multi-information display or a warning light,
and then perform the coping method such as closing the open door or
replenishing a consumable.

602

■

If “See Owner’s Manual” is shown

●

If “Braking Power Low Stop in a Safe Place See Owner’s Manual” is shown,
this may be a malfunction. Immediately stop the vehicle in a safe place and
contact your Toyota dealer. Continuing to drive the vehicle may be danger-
ous.

●

If “Engine Oil Pressure Low” is shown, this may be a malfunction. Immedi-
ately stop the vehicle in a safe place and contact your Toyota dealer.

●

If the following messages are shown, there may be a malfunction. Immedi-
ately have the vehicle inspected by your Toyota dealer.
• “Hybrid System Malfunction”
• “Check Engine”
• “Hybrid Battery System Malfunction”
• “Accelerator System Malfunction”
• “Smart Key System Malfunction See Owner’s Manual”

■

If “Shift System Not Active Apply Parking Brake Securely While Parking
See Owner’s Manual” is shown

Indicates a temporary operation failure or malfunction in the shift control sys-
tem. Immediately have the vehicle inspected by your Toyota dealer.
When the message is shown, the hybrid system may not be started or the
shift position may not be changed normally. (Coping method:

P. 606)

■

If “Shift System Malfunction Apply Parking Brake Securely While Park-
ing See Owner’s Manual” is shown

Indicates a malfunction in the shift control system. Immediately have the vehi-
cle inspected by your Toyota dealer.
When the message is shown, the hybrid system may not be started or the
shift position may not be changed normally. (Coping method:

P. 606)

■

If “

Switch Malfunction Apply Parking Brake Securely While Parking

See Owner’s Manual” is shown

The P position switch may not operate. Immediately have the vehicle
inspected by your Toyota dealer.
When parking the vehicle, stop the vehicle on level ground and apply the
parking brake firmly.

■

If “Shift System Malfunction Shifting Unavailable See Owner’s Manual”
is shown

Indicates a malfunction in the shift control system. Immediately have the vehi-
cle inspected by your Toyota dealer.
The shift position may not be shifted from P to other than P.

■

If “Shift System Malfunction Stop in a Safe Place See Owner’s Manual”
is shown

Indicates a malfunction in the shift control system. Immediately have the vehi-
cle inspected by your Toyota dealer.
The shift position may not be changed. Stop the vehicle in a safe place.

603

Wh
en tro

■

If “Shift System Malfunction See Owner’s Manual” is shown

Indicates a malfunction in the shift control system. Immediately have the sys-
tem inspected by your Toyota dealer.
The system may not operate properly.

■

If “Low 12-Volt Battery Apply Parking Brake Securely While Parking See
Owner’s Manual” is shown

Indicates that the 12-volt battery charge is insufficient. Charge or replace the
12-volt battery.

●

When the message is shown, the hybrid system may not start or the shift
position may not be changed normally. (Coping method:



P. 606)

●

After charging the 12-volt battery, the message may not go off until the shift
position is changed from P.

■

If “Shifting Unavailable Low 12-Volt Battery See Owner’s Manual” is
shown

Indicates that the shift position cannot be changed because the voltage of the
12-volt battery drops. Charge or replace the 12-volt battery.
(Coping method in the case the 12-volt battery is discharged:

P. 646)

■

If “Hybrid System Overheated. Reduced Output Power.” is shown

The message may be shown when driving under severe operating conditions.
(For example, when driving up a long steep hill or driving up a steep hill in
reverse.)
Coping method:



P. 652

■

If “Maintenance Required for Traction Battery Cooling Parts See Owner’s
Manual” is shown

The filter may be clogged, the air intake vent may be blocked or there may be
a gap in the duct.

●

If the air intake vent is dirty, refer to P. 546 for information on how to clean
the air intake vent.

●

If the message is shown when the air intake vent is not dirty, have the vehi-
cle inspected by your Toyota dealer.

■

If “Traction Battery Needs to be Protected Refrain From the Use of
Position” is shown

This message may be displayed when the shift position is in N.
As the hybrid battery (traction battery) can not be charged when the shift
position is in N, shift the shift position to P when the vehicle is stopped.

■

If “Traction Battery Needs to be Protected Shift into

to Restart” is

shown

This message is displayed when the hybrid battery (traction battery) charge
has become extremely low because the vehicle has been left with the N shift
position selected for a certain amount of time.
When operating the vehicle, shift to P and restart the hybrid system.

604

■

If “Shifted into

Shift Again to Start Vehicle” is shown

Message is displayed when the automatic P position selection function oper-
ates. (



P. 252)

To start off the vehicle after the shift position is changed to P, operate the shift
lever again.

■

If “Shift to

Before Exiting Vehicle” is shown

Message is displayed when the driver’s door is opened without turning the
power switch to off with the shift position in any position other than P.
Shift the shift position to P.

■

If “Shift is in

Release Accelerator Before Shifting” is shown

Message is displayed when the accelerator pedal has been depressed and
the shift position is in N.
Release the accelerator pedal and shift the shift position to D or R.

■

If “Depress Brake When Vehicle is Stopped. Hybrid System may Over-
heat.” is shown

The message may be shown when the accelerator pedal is depressed to hold
the vehicle while the vehicle is stopped on an uphill, etc.
The hybrid system may overheat. Release the accelerator pedal and depress
the brake pedal.

■

If “Shifted to

Stop Vehicle to Shift to

” is shown

If the P position switch is pressed while driving, the shift position is changed
to N and the message is shown. (



P. 251)

■

If “Auto Power OFF to Conserve Battery” is shown

The power switch has been turned off by the automatic power off function.
When starting the hybrid system next time, operate the hybrid system for
approximately 5 minutes to recharge the 12-volt battery.

■

If “Engine Oil Level Low Add or Replace” is displayed

The engine oil level may be low. Check the level of the engine oil, and add
engine oil if necessary. This message may be displayed if the vehicle is
stopped on a slope. Move the vehicle to a level surface and check if the mes-
sage disappears.

■

If “Accelerator and Brake Pedals Pressed Simultaneously” is shown

The accelerator and brake pedals are being depressed simultaneously.
(

P. 223)

Release the accelerator pedal and depress the brake pedal.

605

Wh
en tro

■

If a message that indicates the malfunction of front camera is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 289, 588)

●

PCS (Pre-Collision System) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

AHB (Automatic High Beam) (if equipped)

●

RSA (Road Sign Assist) (if equipped)

●

Dynamic radar cruise control with full-speed range (if equipped)

■

If a message that indicates the malfunction of radar sensor is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 289, 588)

●

PCS (Pre-Collision System) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

Dynamic radar cruise control with full-speed range (if equipped)

■

If “Radar Cruise Control Unavailable See Owner’s Manual” is shown

The dynamic radar cruise control with full-speed range system is suspended
temporarily or until the problem shown in the message is resolved. (causes
and coping methods:

P. 289)

■

If “Radar Cruise Control Unavailable” is shown

The dynamic radar cruise control with full-speed range system cannot be
used temporarily. Use the system when it becomes available again.

■

If “Maintenance Required Soon” is displayed (U.S.A. only)

Indicates that all maintenance according to the driven distance on the mainte-
nance schedule

should be performed soon.

Comes on approximately 4500 miles (7200 km) after the message has been
reset.
If necessary, perform maintenance. Please reset the message after the main-
tenance is performed. (



P. 502)

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual

Supplement” for the maintenance interval applicable to your vehicle.

■

If “Maintenance Required Visit Your Dealer” is displayed (U.S.A. only)

Indicates that all maintenance is required to correspond to the driven distance
on the maintenance schedule

Comes on approximately 5000 miles (8000 km) after the message has been
reset. (The indicator will not work properly unless the message has been
reset.)
Perform the necessary maintenance. Please reset the message after the
maintenance is performed. (



P. 502)

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual

Supplement” for the maintenance interval applicable to your vehicle.

606

■

If the shift position cannot be changed or the power switch is turned to
ACCESSORY mode even if trying to turn the power switch off when a
warning message is shown

If the 12-volt battery is discharged or the shift control system is malfunction-
ing, the followings may occur.

●

The shift position may not be changed to P.
When parking, stop the vehicle on level ground and apply the parking brake
firmly.

●

The hybrid system may not start.

●

The power switch may be turned to ACCESSORY mode even if trying to
turn the power switch off.
In this case, the power switch may be turned off after applying the parking
brake.

●

The automatic P position selection function (

P. 252) may not operate.

Before turning the power switch off, be sure to press the P position switch
and check that the shift position is in P by the shift position indicator or P
position switch indicator.

■

Warning buzzer

P. 595

NOTICE

■

If “Maintenance Required for Traction Battery at Your Dealer” is shown

The hybrid battery (traction battery) is scheduled to be inspected or
replaced. Have the vehicle inspected by your Toyota dealer immediately.

●

Continuing to drive the vehicle without having the hybrid battery (traction
battery) inspected will cause the hybrid system not to start.

●

If the hybrid system does not start, contact your Toyota dealer immedi-
ately.

607

Wh
en tro

If you have a flat tire (vehicles without

spare tire)

Your  vehicle  is  not  equipped  with  a  spare  tire,  but  instead  is
equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire
tread  can  be  repaired  temporarily  using  the  emergency  tire
puncture  repair  kit.  (The  kit  contains  a  bottle  of  sealant.  The
sealant  can  be  used  only  once  to  temporarily  repair  one  tire
without removing the nail or screw from the tire.) After temporar-
ily  repairing  the  tire  with  the  kit,  have  the  tire  repaired  or
replaced by your Toyota dealer.

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the

wheel beyond repair, which could result in an accident.

608

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift position to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers.

●

Check the degree of the tire damage.

A  tire  should  only  be  repaired
with  the  emergency  tire  punc-
ture  repair  kit  if  the  damage  is
caused by a nail or screw pass-
ing through the tire tread.

• Do not remove the nail or

screw  from  the  tire.  Remov-
ing the object may widen the
opening  and  make  emer-
gency  repair  with  the  repair
kit impossible.

• To avoid sealant leakage, move the vehicle until the area of the

puncture, if known, is positioned at the top of the tire.

■

A flat tire that cannot be repaired with the emergency tire puncture

repair kit

In the following cases, the tire cannot be repaired with the emergency tire

puncture repair kit. Contact your Toyota dealer.

●

When the tire is damaged due to driving without sufficient air pressure

●

When there are any cracks or damage at any location on the tire, such

as on the side wall, except the tread

●

When the tire is visibly separated from the wheel

●

When the cut or damage to the tread is 0.16 in. (4 mm) long or more

●

When the wheel is damaged

●

When two or more tires have been punctured

●

When more than one sharp objects such as nails or screws have passed

through the tread on a single tire

●

When the sealant has expired

Before repairing the tire

609

Wh
en tro



2WD models

Location of the emergency tire puncture repair kit and tools

Jack handle
Jack
(Use of the jack:



P. 613)

Wheel nut wrench

Emergency tire puncture
repair kit
Towing eyelet

1
2

610



AWD models

Towing eyelet
Jack handle
Wheel nut wrench

Emergency tire puncture
repair kit
Jack
(Use of the jack:

P. 613)

1
2
3

611

Wh
en tro

Emergency tire puncture repair kit components

Hose
Air release cap
Sticker

Power plug
Air pressure gauge
Compressor switch

1
2
3

4
5
6

612

Pull up the handle to open the
deck board.

Secure the deck board using
the grocery bag hooks.
(

P. 463)

Take out the emergency tire puncture repair kit.

2WD models: If the luggage cover (if equipped) is stowed, turn over the

tonneau cover to take out the emergency tire puncture repair kit.

Taking out the emergency tire puncture repair kit



2WD models



AWD models

613

Wh
en tro

■

Taking out the jack

Unhook the tightening strap and take out the jack.

■

Storing the jack

Place the jack in the same direction as the mark next to the storage

space.

2WD models

AWD models

2WD models

AWD models

WARNING

■

After using the tools and jack

Before driving, make sure all the tools and jack are securely in place in

their storage location to reduce the possibility of personal injury during a

collision or sudden braking.

614
