Front side marker lights

For the right side only:
Remove the clip and slide
the washer tank inlet pipe to
the right.

To prevent damage to the cover,
protect the tip of the screwdriver
with a rag.

Turn the bulb base counter-
clockwise.

Remove the light bulb.

When installing the bulb, reverse the steps

and

in reverse.

For the right side only: Install
the washer tank inlet pipe
and the clip by conducting
step

in reverse.

567

Mainten

■

Rear turn signal lights, back-up lights and rear side maker
lights

Open the back door. Insert a
screwdriver into the cover on
the  side  of  the  light  and
detach the claws indicated by
the  dotted  lines  near  the
exterior of the vehicle. Then,
pry the cover and pull it diag-
onally  backward  to  the  lug-
gage compartment to detach
the  claws  indicated  by  the
dotted  lines  near  the  vehicle
interior.

To prevent damage to the cover, protect the tip of the screwdriver with a
rag.

Remove the 2 screws.

Pull the light unit toward the
rear of the vehicle to remove
it.

568

Turn the bulb base counterclockwise.



Back-up light



Rear turn signal light



Rear side maker light

569

Mainten

Remove the light bulb.



Back-up light



Rear turn signal light



Rear side maker light

570

Install a new light bulb then install the bulb base to the light unit
by inserting it and turning the bulb base clockwise.



Back-up light



Rear turn signal light



Rear side maker light

571

Mainten

Align the grooves on the light
unit with the claws, and insert
the  light  unit  straight  so  that
the 2 pins on the light unit fit
into  the  holes.  Confirm  that
the  light  unit  is  completely
secured.

Install the 2 screws.

Install the cover.

572

■

Replacing the following bulbs

If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.

●

Headlights and daytime running lights

●

Parking lights (LED type: if equipped)

●

Fog lights

●

Front turn signal lights

●

Tail lights

●

Stop lights

●

High mounted stoplight

●

License plate lights

■

LED lights

The lights other than the parking lights (bulb type: if equipped), front side
marker lights, rear turn signal lights, rear side maker lights and back-up lights
each consist of a number of LEDs. If any of the LEDs burn out, take your
vehicle to your Toyota dealer to have the light replaced.

■

Condensation build-up on the inside of the lens

Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction. Contact your Toyota dealer for more information in the
following situations:

●

Large drops of water have built up on the inside of the lens.

●

Water has built up inside the light.

■

When replacing light bulbs



P. 560

573

Mainten

WARNING

■

Replacing light bulbs

●

Be sure to stop the hybrid system and turn off the lights. Do not attempt to
replace the bulb immediately after turning off the lights.
The bulbs become very hot and may cause burns.

●

Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.

●

Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.

●

Do not attempt to repair or disassemble light bulbs, connectors, electric
circuits or component parts.
Doing so may result in death or serious injury due to electric shock.

■

To prevent damage or fire

●

Make sure bulbs are fully seated and locked.

●

Check the wattage of the bulb before installing to prevent heat damage.

575

When trouble arises

7-1. Essential information

Emergency flashers .......... 576
If your vehicle has to

be stopped in an
emergency ...................... 577

If the vehicle is submerged

or water on the road is
rising ............................... 578

7-2. Steps to take in an

emergency

If your vehicle needs to

be towed ......................... 580

If you think something is

wrong .............................. 587

If a warning light turns on

or a warning buzzer
sounds ............................ 588

If a warning message is

displayed......................... 599

If you have a flat tire

(vehicles without
spare tire)........................ 607

If you have a flat tire

(vehicles with
spare tire)........................ 627

If the hybrid system will

not start........................... 641

If the electronic key does

not operate properly........ 643

If the 12-volt battery is

discharged ...................... 646

If your vehicle overheats ... 652
If the vehicle becomes

stuck ............................... 657

576

Emergency flashers

Press the switch.

All the turn signal lights will flash. To turn them off, press the switch once
again.

■

Emergency flashers

●

If the emergency flashers are used for a long time while the hybrid system is
not operating (while the “READY” indicator is not illuminated), the 12-volt
battery may discharge.

●

If any of the SRS airbags deploy (inflate) or in the event of a strong rear
impact, the emergency flashers will turn on automatically.
The emergency flashers will turn off automatically after operating for approx-
imately 20 minutes. To manually turn the emergency flashers off, press the
switch twice.
(The emergency flashers may not turn on automatically depending on the
force of the impact and conditions of the collision.)

The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in the road due to a breakdown, etc.



Vehicles with 7-inch display



Vehicles with 11.6-inch display

577

Wh
en tro

uble

ris

If your vehicle has to be stopped in an

emergency

Steadily step on the brake pedal with both feet and firmly depress it.

Do not pump the brake pedal repeatedly as this will increase the effort
required to slow the vehicle.

Shift the shift position to N.



If the shift position is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the hybrid system.



If the shift position cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle
speed as much as possible.
To  stop  the  hybrid  system,
press  and  hold  the  power
switch  for  2  consecutive  sec-
onds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by the road.

Only in an emergency, such as if it becomes impossible to stop
the vehicle in the normal way, stop the vehicle using the follow-
ing procedure:

Press and hold for 2 seconds or
more, or press briefly 3 times or
more

WARNING

■

If the hybrid system has to be turned off while driving

Power assist for the steering wheel will be lost, making the steering wheel
heavier to turn. Decelerate as much as possible before turning off the hybrid
system.

578

If the vehicle is submerged or water on the

road is rising

●

If the door can be opened, open the door and exit the vehicle.

●

If the door can not be opened, open the window using the power
window switch and ensure an escape route.

●

If the window can be opened, exit the vehicle through the window.

●

If the door and window cannot be opened due to the rising water,
remain calm, wait until the water level inside the vehicle rises to the
point that the water pressure inside of the vehicle equals the water
pressure outside of the vehicle and then open the door after waiting
for the rising water to enter the vehicle, and exit the vehicle. When
the outside water level exceeds half the height of the door, the door
cannot be opened from the inside due to water pressure.

This vehicle is not designed to be able to drive on roads that are
deeply flooded with water. Do not drive on roads where the
roads may be submerged or the water may be rising. It is dan-
gerous to remain in the vehicle, if it anticipated that the vehicle
will be flooded or set a drift. Remain calm and follow the follow-
ing.
