or  bar),  then  gradually
decrease.
The  air  pressure  gauge  will
display  the  actual  tire  infla-
tion  pressure  about  1  to  5
minutes  after  the  switch  is
turned on.

• Turn the compressor switch

off and then check the tire
inflation

pressure.

Being

careful  not  to  over  inflate,
check and repeat the inflation
procedure  until  the  specified
tire  inflation  pressure  is
reached.

• The tire can be inflated for about 5 to 20 minutes (depending on

the outside temperature). If the tire inflation pressure is still lower
than the specified point after inflation for 25 minutes, the tire is
too damaged to be repaired. Turn the compressor switch off and
contact your Toyota dealer.

• If the tire inflation pressure exceeds the specified air pressure, let

out some air to adjust the tire inflation pressure. (



P. 621, 668)

With the compressor switch off, disconnect the hose from the valve
on the tire and then pull out the power plug from the power outlet
socket.

Some sealant may leak when the hose is removed.

Install the valve cap onto the valve of the emergency repaired tire.

619

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

Attach the air release cap to the
end of the hose.

If the air release cap is not

attached, the sealant may leak

and the vehicle may get dirty.

Temporarily store the bottle in the luggage compartment while it is
connected to the compressor.
To spread the liquid sealant evenly within the tire, immediately drive
safely for about 3 miles (5 km) below 50 mph (80 km/h).
After  driving,  stop  your  vehicle
in  a  safe  place  on  a  hard,  flat
surface  and  reconnect  the
repair kit.

Remove the air release cap from

the hose before reconnecting the

hose.

Turn the compressor switch on and wait for several seconds, then
turn it off. Check the tire inflation pressure.

If the tire inflation pressure is
under

19 psi

(130 kPa,

1.3 kgf/cm

or bar): The

puncture cannot be repaired.
Contact your Toyota dealer.
If the tire inflation pressure is
19 psi (130 kPa, 1.3 kgf/cm

or bar) or higher, but less
than the specified air pres-
sure: Proceed to step

If the tire inflation pressure is the specified air pressure (



P. 668):

Proceed to step

620

7-2. Steps to take in an emergency

Turn the compressor switch on to inflate the tire until the specified
air pressure is reached. Drive for about 3 miles (5 km) and then
perform step

Attach the air release cap to the
end of the hose.

If the air release cap is not

attached, the sealant may leak

and the vehicle may get dirty.

Store the bottle in the luggage compartment while it is connected to
the compressor.
Taking precautions to avoid sudden braking, sudden acceleration
and sharp turns, drive carefully at under 50 mph (80 km/h) to the
nearest Toyota dealer that is less than 62 miles (100 km) away for
tire repair or replacement.

When having the tire repaired or replaced, make sure to tell the Toyota

dealer that the sealant is injected.

621

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

■

If the tire is inflated to more than the specified air pressure

Disconnect the hose from the valve.

Disconnect the hose from the valve, remove the air release cap from

the hose and then reconnect the hose.
Turn the compressor switch on and wait for several seconds, and then

turn it off. Check that the air pressure indicator shows the specified air

pressure. (



P. 668)

If the air pressure is under the designated pressure, turn the compres-

sor switch on again and repeat the inflation procedure until the speci-

fied air pressure is reached.

■

The valve of a tire that has been repaired

After a tire is repaired with the emergency tire puncture repair kit, the

valve should be replaced.

■

After a tire is repaired with the emergency tire puncture repair kit

●

The tire pressure warning valve and transmitter should be replaced.

●

Even if the tire inflation pressure is at the recommended level, the tire

pressure warning light may come on/flash.

■

Note for checking the emergency tire puncture repair kit

Check the sealant expiry date occasionally.

The expiry date is shown on the bottle. Do not use sealant whose expiry

date has already passed. Otherwise, repairs conducted using the emer-

gency tire puncture repair kit may not be performed properly.

Install the air release cap to the end of

the hose and push the protrusion on

the air release cap into the tire valve

to let some air out.

622

7-2. Steps to take in an emergency

■

Emergency tire puncture repair kit

●

The emergency tire puncture repair kit is for filling the car tire with air.

●

The sealant has a limited life span. The expiry date is marked on the

bottle. The sealant should be replaced before the expiry date. Contact

your Toyota dealer for replacement.

●

The sealant stored in the emergency tire puncture repair kit can be used

only once to temporarily repair a single tire. If the sealant in the bottle

and other parts of the kit have been used and need to be replaced, con-

tact your Toyota dealer.

●

The compressor can be used repeatedly.

●

The sealant can be used when the outside temperature is from -40°F

(-40°C) to 140°F (60°C).

●

The kit is exclusively designed for size and type of tires originally

installed on your vehicle. Do not use it for tires that a different size than

the original ones, or for any other purposes.

●

If the sealant gets on your clothes, it may stain.

●

If the sealant adheres to a wheel or the surface of the vehicle body, the

stain may not be removable if it is not cleaned at once. Immediately wipe

away the sealant with a wet cloth.

●

During operation of the repair kit, a loud operation noise is produced.

This does not indicate a malfunction.

●

Do not use to check or to adjust the tire pressure.

623

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

WARNING

■

Do not drive the vehicle with a flat tire

Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the

wheel beyond repair.
Driving with a flat tire may cause a circumferential groove on the side

wall. In such a case, the tire may explode when using a repair kit.

■

Caution while driving

●

Store the repair kit in the luggage compartment.

Injuries may result in the event of an accident or sudden braking.

●

The repair kit is exclusively only for your vehicle.

Do not use repair kit on other vehicles, which could lead to an accident

causing death or serious injury.

●

Do not use repair kit for tires that are different size than the original

ones, or for any other purpose. If the tires have not been completely

repaired, it could lead to an accident causing death or serious injury.

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to your health. If you ingest sealant,

consume as much water as possible, and then immediately consult a

doctor.

●

If sealant gets in eyes or adheres to skin, immediately wash it off with

water. If discomfort persists, consult a doctor.

624

7-2. Steps to take in an emergency

WARNING

■

When fixing the flat tire

●

Stop your vehicle in a safe and flat area.

●

Do not touch the wheels or the area around the brakes immediately

after the vehicle has been driven.

After the vehicle has been driven, the wheels and the area around the

brakes may be extremely hot. Touching these areas with hands, feet or

other body parts may result in burns.

●

Connect the valve and hose securely with the tire installed on the vehi-

cle. If the hose is not properly connected to the valve, air leakage may

occur as sealant may be sprayed out.

●

If the hose comes off the valve while inflating the tire, there is a risk

that the hose will move abruptly due to air pressure.

●

After inflation of the tire has completed, the sealant may splatter when

the hose is disconnected or some air is let out of the tire.

●

Follow the operation procedure to repair the tire. If the procedures not

followed, the sealant may spray out.

●

Keep back from the tire while it is being repaired, as there is a chance

of it bursting while the repair operation is being performed. If you

notice any cracks or deformation of the tire, turn off the compressor

switch and stop the repair operation immediately.

●

The repair kit may overheat if operated for a long period of time. Do not

operate the repair kit continuously for more than 40 minutes.

●

Parts of the repair kit become hot during operation. Be careful handling

the repair kit during and after operation. Do not touch the metal part

connecting the bottle and the compressor. It will be extremely hot.

●

Do not attach the vehicle speed warning sticker to an area other than

the one indicated. If the sticker is attached to an area where an SRS

airbag is located, such as the pad of the steering wheel, it may prevent

the SRS airbag from operating properly.

625

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

WARNING

■

Driving to spread the liquid sealant evenly

Observe the following precautions to reduce the risk of accidents.

Failing to do so may result in a loss of vehicle control and cause death

or serious injury.

●

Drive the vehicle carefully at a low speed. Be especially careful when

turning and cornering.

●

If the vehicle does not drive straight or you feel a pull through the

steering wheel, stop the vehicle and check the following.
• Tire condition. The tire may have separated from the wheel.

• Tire inflation pressure. If the tire inflation pressure is 19 psi

(130 kPa, 1.3 kgf/cm

or bar) or less, the tire may be severely dam-

aged.

NOTICE

■

When performing an emergency repair

●

A tire should only be repaired with the emergency tire puncture repair

kit if the damage is caused by a sharp object such as nail or screw

passing through the tire tread.

Do not remove the sharp object from the tire. Removing the object may

widen the opening and disenable emergency repair with the repair kit.

●

The repair kit is not waterproof. Make sure that the repair kit is not

exposed to water, such as when it is being used in the rain.

●

Do not put the repair kit directly onto dusty ground such as sand at the

side of the road. If the repair kit vacuums up dust etc., a malfunction

may occur.

■

Precautions for the emergency tire puncture repair kit

●

The repair kit power source should be 12 V DC suitable for vehicle

use. Do not connect the repair kit to any other source.

●

If fuel splatters on the repair kit, the repair kit may deteriorate. Take

care not to allow fuel to contact it.

●

Place the repair kit in a storage to prevent it from being exposed to dirt

or water.

●

Store the repair kit in the luggage compartment out of reach of chil-

dren.

●

Do not disassemble or modify the repair kit. Do not subject parts such

as the air pressure indicator to impacts. This may cause a malfunction.

626

7-2. Steps to take in an emergency

NOTICE

■

To avoid damage to the tire pressure warning valves and transmit-

ters

When a tire is repaired with liquid sealants, the tire pressure warning

valve and transmitter may not operate properly. If a liquid sealant is

used, contact your Toyota dealer or other qualified service shop as soon

as possible. After use of liquid sealant, make sure to replace the tire

pressure warning valve and transmitter when repairing or replacing the

tire. (



P. 530)

627

Wh
en tro

uble

ris

7-2. Steps to take in an emergency

If you have a flat tire (vehicles with spare

tire)

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift position to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers. (



P. 576)

Your vehicle is equipped with a spare tire. The flat tire can be
replaced with the spare tire.
For details about tires:



P. 528

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the

wheel beyond repair, which could result in an accident.

Before jacking up the vehicle

628

7-2. Steps to take in an emergency



Vehicles with compact spare tire

Location of the spare tire, jack and tools

Wheel nut wrench
Jack handle
Towing eyelet

Jack
Spare tire

1
2
3

4
5

629

7-2. Steps to take in an emergency

Wh
en tro

uble

ris



Vehicles with full-size spare tire

Jack handle
Wheel nut wrench
Spare tire

Towing eyelet
Jack

1
2
3

4
5

630

7-2. Steps to take in an emergency

WARNING

■

Using the tire jack

Observe the following precautions.

Improper use of the tire jack may cause the vehicle to suddenly fall off

the jack, leading to death or serious injury.

●

Only use the tire jack that comes with this vehicle for replacing a flat

tire.

Do not use it on other vehicles, and do not use other tire jacks for

replacing tires on this vehicle.

●

Do not raise the vehicle while someone is inside.

●

Do not use the tire jack for any purpose other than replacing tires or

installing and removing tire chains.

●

Do not put any part of your body under the vehicle while it is supported

by the jack.

●

Do not start the hybrid system or drive the vehicle while the vehicle is

supported by the jack.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to

replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

●

When lowering the vehicle, make sure that there is no-one near the

vehicle. If there are people nearby, warn them vocally before lowering.

●

Put the jack properly in its jack point.

(



P. 634)

Content .. 36 37 38 39 ..
