173

4-5. EyeSight

4

Dr

iv

ing

NOTICE

●

Under the conditions listed

below, it will become more diffi-

cult for the system to detect the

vehicle in front, motorcycles,

bicycles, pedestrians and obsta-

cles on the road, and lane mark-

ers. Also, EyeSight may

temporarily stop operating.

However, the temporary stop

will be canceled once these

conditions have improved and

the vehicle is driven for a short

period of time.

• Bad weather (for example

heavy rain, a blizzard or thick

fog). In particular, the system is

more likely to temporarily stop

operating when there is an oil

film adhering to the windshield,

a glass coating has been

applied, or poorly performing

wipers are used.

• Strong light is coming from the

front (sunlight or headlight

beams of oncoming traffic, etc.).

• The windshield washer is in

use.

• Raindrops, water drops, or dirt

on the windshield are not wiped

off sufficiently.

• The windshield has become

fogged, scratched or smeared,

or snow, dirt ,dust or frost has

adhered to it, or it is otherwise

affected. These will reduce the

stereo camera’s field of view.

Also, light is reflecting off the

dirt, etc.

• The vehicle is tilted at an

extreme angle due to loaded

cargo or other factors.

• Visibility is poor due to sand,

smoke or water vapor blowing in

the wind, or the front vision is

obscured due to water

splashes, snow, dirt or dust stir

up generated by the vehicle in

front or oncoming traffic.

• The stereo camera’s field of

view is obstructed.

• Through the entrance or exit of

a tunnel

• The rear aspect of the vehicle in

front is low, small or irregular

(for example a low bed trailer,

etc.).

• The obstacle is a fence, a wall

or a shutter, etc. with a uniform

pattern (a striped pattern, brick,

etc.) or with no pattern in front.

• The obstacle is a wall or door

made of glass or a mirror in

front.

• Driving at night or in a tunnel

when there is a vehicle in front

that does not have its taillights

on

• Driving through a banner or flag,

low branches on a tree or

thick/tall vegetation

• On steep uphill or downhill

grades

• The stereo camera is

obstructed by a hand, etc. (If

even one of the lenses is

obstructed, the system does not

operate properly.)

• It is completely dark and no

objects are detected.

• The area around the vehicle has

a uniform color (such as when

completely covered in snow,

etc.).

174

4-5. EyeSight

The stereo camera is located on
the interior lights unit.

1

Stereo camera

NOTICE

• Accurate detection is not possi-

ble due to reflections in the

windshield.

●

Under the conditions listed

below, EyeSight may temporar-

ily stop operating. If this occurs,

EyeSight will resume operating

when the conditions improve.

• The temperature inside the

vehicle is high, such as after the

vehicle was left in bright sun-

shine, or the temperature inside

the vehicle is low, such as after

the vehicle was left in an

extremely cold environment.

• Immediately after the engine

starts

●

Under the conditions listed

below, it is difficult to recognize

vehicles in front, motorcycles,

pedestrians, obstacles on the

road, traffic lanes, etc. Also, the

EyeSight system may temporar-

ily stop operating. If the Eye-

Sight system repeatedly stops

operating several times, con-

tact a Toyota dealer and have

the system inspected.

• The stereo camera lenses are

smeared such as from finger-

prints.

• The stereo camera has become

misaligned due to a strong

impact.

●

When there is a malfunction in

the EyeSight system, turn off

Pre-Collision Braking System

(



P.189) and Lane Departure

Warning (



P.221), and stop

using Adaptive Cruise Control

and Conventional Cruise Con-

trol. Contact a Toyota dealer

and have the system inspected.

●

When the slip indicator is illumi-

nated, Pre-Collision Braking

System may not operate prop-

erly. If the slip indicator is illumi-

nated, turn off Pre-Collision

Braking System. Also, do not

use Adaptive Cruise Control or

Conventional Cruise Control.

Handling of the stereo
camera

175

4-5. EyeSight

4

Dr

iv

ing

NOTICE

●

The stereo camera monitors

and detects smears or blurs on

the front of the camera. How-

ever, detection is not 100%

accurate.

Under certain conditions, the

function may fail to detect

smears or blurs on the front of

the stereo camera accurately. In

addition, this function may not

detect that there is snow or ice

on the windshield close to the

stereo camera. In such condi-

tions, be sure to keep the wind-

shield clean at all times
(indicated by

 ). Otherwise

the system may not operate cor-

rectly. When this function

detects that the front of the ste-

reo camera is smeared or

blurred, no EyeSight functions

can be activated except for

Conventional Cruise Control.

●

The stereo camera lenses are

precision components. Always

observe the following precau-

tions especially when handling

them.

• Never touch the stereo camera

lenses, and do not attempt to

wipe or clean the lenses. Doing

so could damage or soil the

lens, and lead to improper sys-

tem performance. If you ever

touch a lens for any reason, be

sure to contact your Toyota

dealer.

• When cleaning the windshield,

cover the front of the camera

casing with paper that does not

collect dust, such as copy

paper. Affix the paper to prevent

glass cleaner from getting on

the camera lenses. At this point,

make sure that the tape’s adhe-

sive surface does not come in

contact with the windshield or

the lens. Be sure to remove the

paper after cleaning.

• When having the inside of wind-

shield cleaned at a service sta-

tion, etc., be sure to request that

the attendant covers the cam-

era covers before washing the

vehicle.

• Do not subject the stereo cam-

era to a strong impact.

• Do not remove or disassemble

the stereo camera.

• Do not change the positions

where the stereo camera is

installed or modify any of the

surrounding structures.

●

Do not install an interior rear-

view mirror other than a genuine

Toyota rearview mirror (such as

a wide-type mirror) and the sun

visor. Also, use the rearview

mirror so that it does not

obstruct the stereo camera.

Failure to do so may affect the

stereo camera’s field of view

and could prevent the EyeSight

system from functioning prop-

erly.

Stereo camera

A

176

4-5. EyeSight

NOTICE

●

Do not install any accessories

other than the ones designated

by Toyota on the prohibited

areas shown in the illustrations

(grey zones).

Even if some accessories are

installed on the outside of the

prohibited areas, abnormal

operation of EyeSight may

occur due to the reflection of the

light or any objects. In this situa-

tion, move the accessories. For

details, contact your Toyota

dealer.

• Side view

Monitors or other accessories

• Front view

●

Do not place any objects on top

of the instrument panel. The

stereo camera may not be able

to detect objects accurately and

the EyeSight system may not

function properly due to reflec-

tions in the windshield. For

details, contact your Toyota

dealer.

A

●

If the top of the instrument panel

is polished with chemicals or

other substances, the stereo

camera may not be able to

detect objects accurately and

the EyeSight system may not

operate properly due to reflec-

tions in the windshield.

●

Do not install any wiper blades

other than genuine Toyota wiper

blades. Doing so may affect the

stereo camera’s field of view

and could prevent the EyeSight

system from functioning prop-

erly.

●

Replace damaged wiper blades

or worn wiper blade rubbers as

soon as possible. Using dam-

aged wiper blades or worn

wiper blade rubbers may cause

streaking on the windshield.

The stereo camera may not be

able to detect objects accurately

and the EyeSight system may

not function properly due to

streaks or droplets remaining on

the windshield.

●

Do not install any accessories

on the front side such as on the

hood or the grille. It may affect

the camera view and the system

may not operate correctly.

●

Make sure that the stereo cam-

era's field of view is not inter-

fered. Obstructing the stereo

camera’s view may impair the

system operation. For details,

contact your Toyota dealer.

177

4-5. EyeSight

4

Dr

iv

ing

EyeSight includes the following
functions.

■

Pre-Collision Braking Sys-
tem

This function uses a following
distance warning feature to
warn the driver to take evasive
action when there is the possi-
bility of a collision with a vehicle,
pedestrian or obstacle in front of
you. If the driver does not take
evasive action, the brakes are
applied automatically to help
reduce vehicle collision dam-
age or, if possible, help prevent
a collision. (



P.179)

■

Adaptive Cruise Control

This function maintains the set
vehicle speed and when there is
a vehicle in front in the same
traffic lane, it follows the speed
of the vehicle in front up to the
maximum of the set vehicle
speed. (



P.190)

■

Conventional Cruise Con-
trol

In this mode, the system main-
tains a constant vehicle speed.
It does not follow the vehicle in
front. This function can be used
even when the stereo camera
has temporarily stopped operat-
ing (



P.229). This function is

used by switching from Adaptive
Cruise Control to Conventional
Cruise Control. (



P.207)

NOTICE

●

Keep the windshield (outside

and inside) clean at all times.

When the windshield has

become fogged, or it has a dirt

or an oil film on it, the stereo

camera may not detect objects

accurately and the EyeSight

system may not operate cor-

rectly. Never mount any device

to the center air vent, as any air-

flow change may impact Eye-

Sight performance.

●

Do not place any stickers or

accessories on the windshield

(outside or inside). If you have

to do so (for example, legally

required or electronic toll tag),

avoid the area directly in front of

the camera. Otherwise, it may

adversely affect the field of view

of the stereo camera and can

cause improper operation of the

system. For details, contact a

Toyota dealer.

●

Do not use any glass coating

agents or similar substances on

the windshield. Doing so may

interfere with the proper opera-

tion of the system.

●

Do not install any film or an

additional layer of glass on the

windshield. The system may not

operate correctly.

●

If there are scratches or cracks

on the windshield, contact a

Toyota dealer.

●

To have the windshield replaced

or repaired, contact a Toyota

dealer. Do not install a wind-

shield other than a genuine Toy-

ota windshield. The stereo

camera may not be able to

detect objects accurately and

the EyeSight system may not

operate properly.

EyeSight functions

178

4-5. EyeSight

■

Pre-Collision Throttle Man-
agement

This function reduces accidental
forward movement caused by
the shift lever being placed in
the wrong position or the accel-
erator pedal being accidentally
depressed, or depressed too
strongly. (



P.215)

■

Lane Departure Warning

This function warns the driver
when the vehicle is about to drift
off the road. (



P.220)

■

Lane Sway Warning

This function warns the driver
when it detects vehicle drifting
caused by driver fatigue, failure
to concentrate on the road, inat-
tention, strong crosswinds or
other factors. (



P.222)

■

Lead Vehicle Start Alert

This function notifies the driver
when the vehicle stopped in
front starts moving but the
driver’s vehicle remains station-
ary. (



P.224)

EyeSight does not operate when the

engine is not running.

 (Following distance set-

ting) switch
Cruise control switch
“ON-OFF” switch

■

Cruise control switch



“ON-OFF” switch

• Press this switch to turn cruise

control

*

 on/off.

• When the “ON-OFF” switch is

pressed,

 appears on the

meter display, and then



appears by pressing and holding
the

 (Following distance set-

ting) switch for approximately 2
seconds. When

 or

 is

shown on the meter display, this
indicates that the main cruise
control is on. (



P.196, 208)



“- SET” (push the cruise con-
trol switch down)

• Push this switch down to set

cruise control

*

. (



P.196, 208)

• Push this switch down to reduce

the set vehicle speed (when
cruise control

*

 is currently set).

(



P.201, 211)

Switch layout

A

C

179

4-5. EyeSight

4

Dr

iv

ing



“+ RES” (push the cruise con-
trol switch up)

• Push this switch up to set cruise

control

*

. (



P.196, 208)

• After cruise control* is canceled,

push this switch up to resume the
cruise control function at the vehi-
cle speed that was previously set.
(



P.205, 214)

• Push this switch up to increase

the set vehicle speed (when
cruise control

*

 is currently set).

(



P.200, 211)



“CANCEL” (pull the cruise
control switch toward you)

Pull this switch to cancel cruise
control

*

. (



P.203, 212)

*

: Adaptive Cruise Control and Con-

ventional Cruise Control

■

 (Following distance set-

ting) switch

• Press this switch to select the

set following distance in 4
stages (only when Adaptive
Cruise Control is on).
(



P.202)

• When the main cruise control

is on, switching between
Adaptive Cruise Control and
Conventional Cruise Control
is possible by pressing the



(Following distance set-
ting)switch

*

.

*

: To switch to Conventional Cruise

Control, press and hold the
switch for approximately 2 sec-
onds or longer.

*

: If equipped

Some unusual noises may be audi-

ble during automatic braking. This is

caused by the braking control and is

normal.

Pre-Collision Braking

System

*

When there is the risk of a
rear-end collision with an
obstacle or pedestrian in
front, the EyeSight system
helps to prevent or minimize
a collision by warning the
driver. If the driver still does
not take evasive action to
avoid a collision, the brakes
can be automatically
applied just before the colli-
sion in order to reduce
impact damage, or if possi-
ble, prevent the collision. If
the driver takes evasive
action to avoid a collision,
Pre-Collision Braking Assist
will operate in order to help
the driver to prevent or min-
imize the collision.

This function can be acti-
vated when the shift lever is
in the D, M or N position.

180

4-5. EyeSight

WARNING

●

Never use Pre-Collision Braking

System and Pre-Collision Brak-

ing Assist to stop your car or

avoid a collision under ordinary

conditions. These functions

cannot prevent collisions under

all conditions. If the driver relies

only on Pre-Collision Braking

System for Brake operation, col-

lisions may occur.

●

When a warning is activated,

pay attention to the front of the

vehicle and its surroundings,

and operate the brake pedal

and/or take other actions if nec-

essary.

●

The EyeSight Pre-Collision

Braking System is primarily

designed to prevent rear-end

collisions with other vehicles

when possible or to minimize

damage and injuries in the

event of a collision. In addition

to other vehicles, things such as

motorbikes, bicycles and pedes-

trians can also be treated as

obstacles. However, there may

be cases when detection is not

possible depending on a variety
of conditions

*2

. For example,

when a vehicle is viewed from

the side, oncoming vehicle,

vehicles approaching in

reverse, small animals or chil-

dren, or walls or doors are not

likely to be detected.

●

Pre-Collision Braking System

will operate at the point when it

determines that a collision can-

not be avoided and is designed

to apply strong braking force

just before a collision. The result

of this varies depending on a
variety of conditions

*2

. Because

of this, performance of this func-

tion will not always be the same.

●

When Pre-Collision Braking

System is activated, it will con-

tinue to operate even if the

accelerator pedal is partially

depressed. However, it will be

canceled  if the accelerator

pedal is suddenly or fully

depressed.

●

If the driver depresses the brake

pedal or turns the steering

wheel, the system may deter-

mine that this constitutes eva-

sive action by the driver, and the

automatic braking control may

not activate in order to allow the

driver full control.

●

When the difference in speed

with the obstacle in front is the
following figure

*1

or more, it may

not be possible to avoid a colli-

sion. Even if the speed differ-
ence is the following figure

*1

 or

less, in cases such as when

another vehicle cuts in front of

you, or in other cases depend-

ing on visibility, the condition of

road surface and other fac-
tors

*2

, the function may be

unable to stop the vehicle or

may not activate. Pre-Collision

Braking Assist also may not

activate depending on the con-
ditions

*2

 listed below.

*1

:For vehicles: approximately 30

mph (50 km/h),
For pedestrians: approxi-
mately 20 mph (35 km/h)

*2

:Conditions in which Pre-Colli-

sion Braking System cannot
detect obstacles:

• Distance to obstacle in front of

you, speed difference, proxim-

ity conditions, lateral displace-

ment (the amount of offset)

• Vehicle conditions (amount of

load, number of occupants, etc.)

181

4-5. EyeSight

4

Dr

iv

ing

WARNING

• Road conditions (grade, slip-

periness, shape, bumps, etc.)

• Visibility ahead is poor (rain,

snow, fog or smoke, etc.)

• The detected object is some-

thing other than a vehicle,

motorcycle, bicycle or pedes-

trian.



 A domestic animal or other ani-

mal (a dog or deer, etc.)



 A guardrail, telephone pole,

tree, fence or wall, etc.

• Even if the obstacle is a motor-

cycle, bicycle or pedestrian,

depending on the brightness of

the surroundings as well as the

relative movement, and aspect

or angle of the object, there may

be cases when the system can-

not detect it.

• The system determines that

operation by the driver (based

on accelerator pedal operation,

braking, steering wheel angle,

etc.) is intended as evasive

action.

• Vehicle maintenance status

(brake systems, tire wear, tire

pressure, whether a temporary

spare tire is being used, etc.)

• A trailer or another vehicle, etc.

is being towed.

• The brakes are cold due to the

outside temperature being low

or just after starting the engine.

• The brakes are overheated on

downhill grades (braking perfor-

mance is reduced).

• In rain or after washing the vehi-

cle (the brakes are wet and

braking performance is

reduced.)

• Recognition conditions of the

stereo camera

In particular, the function may be
unable to stop the vehicle or may
not activate in the following cases.



 Bad weather (for example

heavy rain, a blizzard or thick fog)



 Visibility is poor due to sand,

smoke or water vapor blowing in
the wind, or the front vision is
obscured due to water splashes,
snow, dirt or dust stir up gener-
ated by the vehicle in front or
oncoming traffic.



 At night or in a tunnel without

the headlights on



 At night or in a tunnel when

there is a vehicle in front that does
not have its taillights on



 Approaching a motorcycle,

bicycle or pedestrian at night



 Ambient light is poor in the

evening or early morning.



 A vehicle, motorcycle, bicycle

or pedestrian is outside the area
illuminated by the headlights.



 Strong light is coming from the

front (for example, sunlight at
dawn, sunset or headlight beams,
etc.).



 The windshield has become

fogged, scratched or smeared, or
snow, dirt, dust or frost has
adhered to it, or it is otherwise
affected. These will reduce the
stereo camera’s field of view.
Also, light is reflecting off the dirt,
etc.

182

4-5. EyeSight

WARNING



 Fluid has not been fully wiped

off the windshield during or after
washer use.



 The target cannot be correctly

recognized because the stereo
camera’s view is obstructed by
water droplets from rain or the
window washer, or by the wiper
blades.



 The stereo camera’s field of

view is obstructed.



 The rear aspect of the vehicle

in front is low, small or irregular
(the system may recognize
another part of the vehicle as its
rear and will determine operation
from that).

• There is an empty truck or

trailer with no rear and/or side

panels on the cargo bed.

• Vehicles that have cargo pro-

truding from their back ends

• Non-standard shaped vehicles

(vehicle transporters or vehi-

cles with a sidecar fitted, etc.)

• The height of the vehicle is low,

etc.



 There is a wall, etc. in front of a

stopped vehicle.



 There is another object near

the vehicle.



 A vehicle, etc. has its side fac-

ing you.



 With vehicles that are backing

up or with oncoming vehicles, etc.



 The size and height of an

obstacle is smaller than the limita-
tions of the stereo camera’s rec-
ognition capability.
• With small animals or children,

etc.

• With pedestrians who are sitting

or lying down



 The detected object is a fence

or wall, etc. with a uniform pattern
(a striped pattern or brick pattern,
etc.).



 There is a wall or door made of

glass or a mirror in front.



 The vehicle in front suddenly

swerves, accelerates, or deceler-
ates.



 A vehicle, motorcycle, bicycle

or pedestrian suddenly cuts in
from the side or suddenly runs in
front of you.



 Your vehicle is immediately

behind an obstacle after changing
lanes.



 There is a vehicle, motorcycle,

bicycle or pedestrian in a location
close to your vehicle’s bumper.

183

4-5. EyeSight

4

Dr

iv

ing

WARNING



 The speed difference between

your vehicle and an obstacle is 4
mph (5 km/h) or less (As braking
is performed once the obstacle is
in close proximity to your vehicle,
depending on the shape and size
of the obstacle, there may be
some cases when the obstacle is
outside the range of the camera’s
field of view.).



 On sharp curves, steep uphill

grades or steep downhill grades



 On a bumpy or unpaved road



 There are changes in bright-

ness, such as at a tunnel
entrance or exit.

●

Do not test Pre-Collision Brak-

ing System on its own. It may

operate improperly and cause

an accident.

●

The system may not operate

correctly under the conditions

listed below. When these condi-

tions occur, turn off Pre-Colli-

sion Braking System. (



P.189)

• The tire pressure is not cor-

rect.

*1

• The temporary spare tire is

installed.

*1

• Tires that are unevenly worn or

tires with uneven wear patterns
are installed.

*1

• Tires that are the wrong size are

installed.

*1

• A flat tire has been fixed tempo-

rarily with a tire repair kit.

• The suspension has been modi-

fied (including a genuine Toyota

suspension that has been modi-

fied).

• An object that obstructs the ste-

reo camera’s view is installed

on the vehicle.

• Tire chains are installed.

• The headlights are dirty or they

have snow and ice or dirt on

them. (Objects are not correctly

illuminated and are difficult to

detect.)

• The optical axes are not aligned

correctly. (Objects are not cor-

rectly illuminated and are diffi-

cult to detect.)

• The lights including headlights

and fog lights have been modi-

fied.

• Vehicle operation has become

unstable due to an accident or

malfunction.

• The brake system warning light

is illuminated in red.

*2

• A heavy cargo is inside the

vehicle.

• The maximum number of occu-

pants is exceeded.

• The meter is not operating prop-

erly; such as when the lights do

not illuminate, the beeps do not

sound, the display is different
from when it is normal, etc.

*3

*1

:The wheels and tires have

functions that are critically
important. Be sure to use the
correct ones. (



P.386)

184

4-5. EyeSight

WARNING

*2

:If the brake system warning

light (red) does not turn off,
immediately pull the vehicle
over in a safe place and con-
tact a Toyota dealer to have the
system inspected.

*3

:For details about the meter,

refer to P.88.

NOTICE

In the following situations, turn off

Pre-Collision Braking System.

Otherwise Pre-Collision Braking

System may activate unexpect-

edly.

●

The vehicle is being towed.

●

The vehicle is being loaded onto

a carrier.

●

A chassis dynamometer,

free-rollers or similar equip-

ment is being used.

●

A mechanic lifts up the vehicle,

starts the engine and spins the

wheels freely.

●

Passing hanging banners, flags

or branches

●

Thick/tall vegetation is touching

the vehicle.

●

Driving on a race track

●

In a drive-through car wash

Pre-Collision Braking System may

activate in the following situations.

Therefore concentrate on safe

driving.

●

Passing through an automatic

gate (opening and shutting)

●

Driving close to the vehicle in

front

●

Driving in a location where the

grade of the road changes rap-

idly

●

Visibility is poor due to sand,

smoke or water vapor blowing in

the wind, or the front vision is

obscured due to water

splashes, snow, dirt or dust stir

up generated by the vehicle in

front or oncoming traffic.

●

Passing through clouds of

steam or smoke, etc.

●

In adverse weather, such as

heavy snow or snowstorms

185

4-5. EyeSight

4

Dr

iv

ing

The EyeSight system can also
detect pedestrians. The Eye-
Sight system detects pedestri-
ans from their size, shape and
movement. The system detects
a pedestrian when the contour
of the head and shoulders are
clear.

Approx. 3 1/3 ft - 6 2/3 ft (1-2
m)

NOTICE

●

The exhaust gas emitted by the

vehicle in front is clearly visible

in cold weather, etc.

●

There is an obstacle on a curve

or intersection.

●

A vehicle or an object is being

narrowly passed.

●

Stopping very close to a wall or

a vehicle in front

●

Passing through water spray

from road sprinklers or snow

clearing sprinklers on the road

If there are installed accessories,

etc. that are protruding beyond

the edge of the front bumper, the

vehicle’s length will increase and

the system may not be able to

prevent a collision.

If the driver operates the brake

pedal during automatic braking,

the pedal may feel stiff; however,

this is normal. By depressing the

brake pedal further you can apply

more braking force.

Detection of pedestrians

A

186

4-5. EyeSight

When there is an obstacle in front of you during driving, the system
activates in the following sequence in order to warn the driver and to
activate braking control and the stop lights.

Following distance warning:

When the system determines that there is a risk of collision, an alert sounds
repeated short beeps and the indicators on the meter display illuminate to
warn the driver.
The Following Distance Warning operates when Adaptive Cruise Control is
not activated.
When the driver depresses the brake pedal to decelerate and achieves a
suitable following distance, the warning is canceled.

First braking and warning:

When the system determines that there is a high risk of collision with an
obstacle in front, an alert sounds repeated short beeps and the indicators
on the meter display illuminate to warn the driver. Braking control may be
activated and in some situations, engine output may also be controlled. If
the system determines that the amount of evasive action (braking, steering,
etc.) taken by the driver has reduced the risk of collision, braking activation
is canceled.

Secondary braking and warning:

WARNING

The EyeSight system’s Pre-Colli-

sion Braking function also identi-

fies pedestrians as obstacles.

However, depending on the con-

ditions, there may be cases when

the system cannot detect a

pedestrian. In the following condi-

tions, the possibility that the sys-

tem may not be able to detect a

pedestrian as an object is particu-

larly high.

●

Pedestrians are walking in a

group.

●

A pedestrian is next to a wall or

other obstacle.

●

A pedestrian is using an

umbrella.

●

A pedestrian is wearing clothes

that are a similar color to the

surrounding environment.

●

A pedestrian is carrying bulky

luggage.

●

A pedestrian is bent over,

crouching down or lying down.

●

A pedestrian is in a dark loca-

tion.

●

A pedestrian suddenly crosses

in front of you from the side or

suddenly runs in front of you.

Pre-Collision Braking System operation

187

4-5. EyeSight

4

Dr

iv

ing

If the system then determines that the risk of collision is extremely high, the
alert changes to a continuous beeping sound and stronger braking control
is activated. Despite any evasive action taken by the driver, if the system
subsequently determines that a collision is unavoidable, braking and
engine output are controlled by the system.
When the vehicle is completely stopped by the automatic braking system, a
short tone “3 intermittent beeps, 1 short beep and 1 long beep” will sound
and braking will be gradually released and the vehicle will start creeping. To
stop the vehicle completely, depress the brake pedal after the vehicle has
stopped.

●

Neither first braking nor secondary braking will operate in the following

cases.

• The vehicle speed is approximately 1 mph (1 km/h) or less (When the shift

lever is in the N position and your vehicle speed is approximately 2 mph (4

km/h) or less) or 100 mph (160 km/h) or more.

• VSC is active.

●

If the system detects the stop lights of the vehicle in front, your vehicle will

start decelerating earlier than if it does not.

●

There are some cases where the first braking is applied for a longer period

of time. One of the reasons for this is due to a large speed difference with

an obstacle in front. In those cases, stronger or weaker braking control

may be activated.

After the Pre-Collision Braking System operation, a message
appears and stays on the meter display for a certain period of time.

“Pre-Collision Braking System Activated”

A

188

4-5. EyeSight

Following distance warning

Possible collision area

First braking and warning

Highly possible collision area

Secondary braking and warning

Extremely highly possible collision area

Obstacle

When Pre-Collision Braking
System is activated (when the
system determines that there is
a high risk of collision with an
obstacle in front), if the driver
depresses the brake pedal, the
system determines that this is
emergency braking and acti-
vates braking assist automati-

cally.

Pre-Collision Braking Assist function

does not operate when the vehicle

speed is approximately 7 mph (10

km/h) or less or 100 mph (160 km/h)

or more.

Operating system

Strength of Auto-

matic Braking

Indication on the
multi-information

display

Alert type

Following distance
warning

Weak

Repeated short
beeps

First braking

Moderate

Repeated short
beeps

Secondary brak-
ing

Strong

Continuous
beep

A

C

D

Pre-Collision Braking
Assist operation
