387

7-2. Maintenance

7

Maintena

nce
 a

nd ca

re

7-2.Maintenance

■

Repair and replacement

It is recommended that genuine

Toyota parts be used for repairs to

ensure performance of each sys-

tem. If non-Toyota parts are used in

replacement or if a repair shop other

than a Toyota dealer performs

repairs, confirm the warranty cover-

age.

■

Allow inspection and repairs to

be performed by a Toyota

dealer

●

Toyota technicians are well-

trained specialists and are kept up

to date with the latest service

information. They are well

informed about the operation of all

systems on your vehicle.

●

Keep a copy of the repair order. It

proves that the maintenance that

has been performed is under war-

ranty coverage. If any problem

should arise while your vehicle is

under warranty, your Toyota

dealer will promptly take care of it.

General maintenance should be
performed on a daily basis. This
can be done by yourself or by a
Toyota dealer.

Scheduled maintenance should
be performed at specified inter-
vals according to the mainte-
nance schedule.

For details about maintenance
items and schedules, refer to the
“Scheduled Maintenance Guide” or
“Owner’s Manual Supplement”.

You can perform some mainte-
nance procedures by yourself.
Please be aware that do-it-your-
self maintenance may affect

Maintenance require-

ments

To ensure safe and econom-
ical driving, day-to-day care
and regular maintenance
are essential. It is the
owner’s responsibility to
perform regular checks.
Toyota recommends the
maintenance below.

WARNING

■

If your vehicle is not properly

maintained

Improper maintenance could

result in serious damage to the

vehicle and possible death or seri-

ous injury.

■

Handling of the 12-volt bat-

tery

●

Oils, fuels and fluids contained

in vehicles as well as waste pro-

duced by component wear con-

tain or emit chemicals known to

the State of California to cause

cancer and birth defects or

other reproductive harm. Avoid

exposure and wash any

affected area immediately.

●

12-volt battery posts, terminals

and related accessories con-

tain lead and lead compounds

which are known to cause brain

damage. Wash your hands after

handling. (



P.400)

General maintenance

Scheduled maintenance

Do-it-yourself mainte-
nance

388

7-2. Maintenance

warranty coverage.

The use of Toyota repair manuals is
recommended.
For details about warranty cover-
age, refer to the separate “Owner’s
Warranty Information Booklet” or
“Owner’s Manual Supplement”.

General maintenance

Listed below are the general
maintenance items that
should be performed at the
intervals specified in the
“Owner’s Warranty Informa-
tion Booklet” or “Owner’s
Manual Supplement/Sched-
uled Maintenance Guide”. It
is recommended that any
problem you notice should
be brought to the attention
of your Toyota dealer or
qualified service shop for
advice.

WARNING

■

If the fuel cell system is oper-

ating

Turn the fuel cell system off and

ensure that there is adequate

ventilation before performing

maintenance checks.

Fuel cell unit compart-
ment

Items

Check points

Brake fluid

Is the brake fluid at
the correct level?
(



P.399)

Coolant

Is the coolant at
the correct level?
(



P.397)

389

7-2. Maintenance

7

Maintena

nce
 a

nd ca

re

Radiator/con-
denser

The radiator and
condenser should
be free from for-
eign objects.
(



P.398)

Washer fluid

Is there sufficient
washer fluid?
(



P.399)

Trunk

Items

Check points

12-volt battery

Check the connec-
tions. (



P.400)

Vehicle interior

Items

Check points

Accelerator
pedal

• The accelerator

pedal should
move smoothly
(without uneven
pedal effort or
catching).

Transmission
“Park” mecha-
nism

• When parked on

a slope and the
shift position is in
P, is the vehicle
securely
stopped?

Items

Check points

Brake pedal

• Does the brake

pedal move
smoothly?

• Does the brake

pedal have
appropriate
clearance from
the floor?

• Does the brake

pedal have the
correct amount
of free play?

Brakes

• The vehicle

should not pull to
one side when
the brakes are
applied.

• The brakes

should work
effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get
too close to the
floor when the
brakes are
applied.

Head
restraints

• Do the head

restraints move
smoothly and
lock securely?

Indica-
tors/buzzers

• Do the indica-

tors and buzzers
function prop-
erly?

Lights

• Do all the lights

come on?

Items

Check points

390

7-2. Maintenance

Parking brake

• Does the park-

ing brake oper-
ate normally?

• When parked on

a slope and the
parking brake is
on, is the vehicle
securely
stopped?

Seat belts

• Do the seat belts

operate
smoothly?

• The seat belts

should not be
damaged.

Seats

• Do the seat con-

trols operate
properly?

Steering wheel

• Does the steer-

ing wheel rotate
smoothly?

• Does the steer-

ing wheel have
the correct
amount of free
play?

• There should not

be any strange
sounds coming
from the steer-
ing wheel.

Items

Check points

Vehicle exterior

Items

Check points

Doors/trunk

• Do the

doors/trunk oper-
ate smoothly?

Hood

• Does the hood

lock system work
properly?

Fluid leaks

• There should not

be any signs of
fluid leakage
after the vehicle
has been parked.

Tires

• Is the tire infla-

tion pressure
correct?

• The tires should

not be damaged
or excessively
worn.

• Have the tires

been rotated
according to the
maintenance
schedule?

• The wheel nuts

should not be
loose.

Windshield
wipers

• The wiper blades

should not show
any signs of
cracking, split-
ting, wear, con-
tamination or
deformation.

• The wiper blades

should clear the
windshield with-
out streaking or
skipping.

391

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

7-3.Do-it-yourself maintenance

Do-it-yourself service

precautions

If you perform maintenance
by yourself, be sure to fol-
low the correct procedure
as given in these sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(



P.400)

• Grease
• Conventional

wrench (for ter-
minal clamp
bolts)

Brake fluid
level (



P.399)

• FMVSS No.116

DOT 3 or SAE
J1703 brake fluid
FMVSS No.116
DOT 4 or SAE
J1704 brake fluid

• Rag or paper

towel

• Funnel (used

only for adding
brake fluid)

Inverter cool-
ant level
(



P.397)

• “Toyota Super

Long Life Cool-
ant” or a similar
high quality eth-
ylene glycol-
based non-sili-
cate, non-amine,
non-nitrite and
non-borate cool-
ant with long-life
hybrid organic
acid technology
For the U.S.A.:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 50% cool-
ant and 50%
deionized water.
For Canada:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 55% cool-
ant and 45%
deionized water.

• Funnel (used

only for adding
coolant)

Fuses
(



P.425)

• Fuse with same

amperage rating
as original

• Flathead screw-

driver

Headlight aim
(



P.428)

• Phillips-head

screwdriver

Radiator and
condenser
(



P.398)



Items

Parts and tools

392

7-3. Do-it-yourself maintenance

Tire inflation
pressure
(



P.415)

• Tire pressure

gauge

• Compressed air

source

Washer fluid
(



P.399)

• Water or washer

fluid containing
antifreeze (for
winter use)

• Funnel (used

only for adding
water or washer
fluid)

WARNING

The fuel cell unit compartment

contains many mechanisms and

fluids that may move suddenly,

become hot, or become electri-

cally energized. To avoid death or

serious injury, observe the follow-

ing precautions.

■

When working on the fuel cell

unit compartment

●

Be careful not to touch the high-

voltage parts or hydrogen-

related parts.

●

Make sure that the “READY”

indicator is off.

●

Keep hands, clothing and tools

away from the moving fan.

●

Be careful not to touch the

motor, inverter, radiator, etc.

right after driving as they may

be hot. Coolant and other fluids

may also be hot.

●

Do not leave anything that may

burn easily, such as paper and

rags, in the fuel cell unit com-

partment.

Items

Parts and tools

●

Do not smoke, cause sparks or

expose an open flame to the 12-

volt battery. 12-volt battery

fumes are flammable.

●

Be extremely cautious when

working on the 12-volt battery. It

contains poisonous and corro-

sive sulfuric acid.

●

Take care because brake fluid

can harm your hands or eyes

and damage painted surfaces. If

fluid gets on your hands or in

your eyes, flush the affected

area with clean water immedi-

ately.

If you still experience discom-

fort, consult a doctor.

●

Never touch, disassemble,

remove or replace the high-volt-

age parts, cables and their con-

nectors. It can cause severe

burns or electric shock that may

result in death or serious injury.

■

When working near the elec-

tric cooling fan or radiator

grille

Be sure the power switch is off.

With the power switch in ON, the

electric cooling fan may automati-

cally start to run if the air condi-

tioning is on and/or the coolant

temperature is high. (



P.398)

■

Safety glasses

Wear safety glasses to prevent

flying or falling material, fluid

spray, etc. from getting in your

eyes.

NOTICE

■

If you remove the air cleaner

filter

Driving with the air cleaner filter

removed may cause excessive

motor wear due to dirt in the air.

393

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

1

Pull the hood lock release
lever.

The hood will pop up slightly.

2

Pull up the auxiliary catch
lever and lift the hood.

■

Front

Hood

Opening the hood

WARNING

■

Pre-driving check

Check that the hood is fully closed

and locked.

If the hood is not locked properly,

it may open while the vehicle is in

motion and cause an accident,

which may result in death or seri-

ous injury.

Positioning a floor

jack

When using a floor jack, fol-
low the instructions in the
manual provided with the
jack and perform the opera-
tion safely.
When raising your vehicle
with a floor jack, position
the jack correctly. Improper
placement may damage
your vehicle or cause injury.

Location of the jack point

394

7-3. Do-it-yourself maintenance

■

Rear

WARNING

■

When raising your vehicle

Make sure to observe the follow-

ing precautions to reduce the pos-

sibility of death or serious injury:

●

Make sure to set the floor jack

properly at the jack point.

Raising the vehicle with an
improperly positioned floor jack
will damage the vehicle and may
cause the vehicle to fall off the
floor jack.

●

Do not jack up on the hydrogen

tanks nor the rear suspension.



Type A



Type B

Front

Suspension

Hydrogen tanks

395

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

Inverter coolant reservoir (



P.398)

Fuel cell stack coolant reservoir (



P.398)

Fuse boxes (



P.425)

Brake fluid reservoir (



P.399)

Washer fluid tank (



P.399)

Inverter coolant radiator (



P.398)

Electric cooling fan

Condenser (



P.398)

Fuel cell stack coolant radiator (



P.398)

■

12-volt battery



P.400

Fuel cell unit compartment

Components

396

7-3. Do-it-yourself maintenance

■

Removing the fuel cell unit compartment cover



Outside



Front

■

Installing the clips

1

Push up center portion

2

Insert

3

Press

■

Removing the fuel cell
stack cover

Remove the fuel cell stack
cover.

Fuel cell unit compartment cover

NOTICE

■

Checking the fuel cell unit

compartment cover after

installation

Make sure that the cover is

securely installed in its original

position.

Fuel cell stack cover

397

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

■

Installing the fuel cell stack
cover

Install the fuel cell stack cover.

1

Attach the hooks on the rear
side of the fuel cell stack
cover.

2

Insert the front side of the
fuel cell stack cover on the
pins.

The coolant level is satisfactory
if it is between the “MAX” and
“MIN” lines on the reservoir

when the fuel cell system is
cold.

Fuel cell stack reservoir cap

“MAX” line

“MIN” line

If the level is on or below the “MIN”
line, add coolant up to the “MAX”
line. (



P.476)

The coolant level is satisfactory
if it is between the “MAX” and
“MIN” lines on the reservoir
when the fuel cell system is
cold.

NOTICE

■

Checking the fuel cell stack

cover after installation

Make sure that the cover is

securely installed in its original

position.

Checking the fuel cell
stack coolant

NOTICE

■

Fuel cell stack coolant

An exclusive coolant for the fuel

cell system is filled in the fuel cell

stack coolant reservoir. Do not

use any substitute. It may dam-

age your vehicle.

Checking the inverter
coolant

398

7-3. Do-it-yourself maintenance

Inverter coolant reservoir cap

“MAX” line

“MIN” line

If the level is on or below the “MIN”
line, add coolant up to the “MAX”
line. (



P.476)

■

Inverter coolant selection

Only use “Toyota Super Long Life

Coolant” or a similar high quality

ethylene glycol based non-silicate,

non-amine, non-nitrite, and non-

borate coolant with long-life hybrid

organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is

a mixture of 50% coolant and 50%

deionized water. (Minimum tem-

perature: -31°F [-35°C])
Canada:
“Toyota Super Long Life Coolant” is

a mixture of 55% coolant and 45%

deionized water. (Minimum tem-

perature: -44°F [-42°C])
For more details about coolant, con-

tact your Toyota dealer.

■

If the inverter coolant level

drops within a short time of

replenishing

Visually check the radiators, hoses,

inverter coolant reservoir cap, drain

cock and water pump.

If you cannot find a leak, have your

Toyota dealer test the cap and

check for leaks in the cooling sys-

tem.

Check the radiator and con-
denser and clear away any for-
eign objects. If either of the
above parts is extremely dirty or
you are not sure of their condi-
tion, have your vehicle
inspected by your Toyota dealer.

WARNING

■

When the cell system is hot

Do not remove the coolant reser-

voir caps. (



P.479)

The cooling system may be under

pressure and may spray hot cool-

ant if the cap is removed, causing

serious injuries, such as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct

mixture of water and antifreeze

must be used to provide proper

lubrication, corrosion protection

and cooling. Be sure to read the

antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to

prevent it from damaging parts or

paint.

Checking the radiator and
condenser

WARNING

■

When the fuel cell system is

hot

Do not touch the radiator or con-

denser as they may be hot and

cause serious injuries, such as

burns.

399

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

■

Checking fluid level

The brake fluid level should be
between the “MAX” and “MIN”
lines on the tank.

Brake fluid reservoir cap

“MAX” line

“MIN” line

■

Adding fluid

Make sure to check the fluid
type and prepare the necessary
item.



Fluid type

FMVSS No.116 DOT 3 or SAE
J1703 brake fluid
FMVSS No.116 DOT 4 or SAE
J1704 brake fluid



Item

Clean funnel

■

Brake fluid can absorb moisture

from the air

Excess moisture in the brake fluid

can cause a dangerous loss of brak-

ing efficiency. Use only newly

opened brake fluid.

If any washer does not work or
the warning message appears
on the multi-information display,
the washer tank may be empty.
Add washer fluid.

Checking and adding the
brake fluid

WARNING

■

When filling the reservoir

Take care as brake fluid can harm

your hands and eyes and damage

painted surfaces.

If fluid gets on your hands or in

your eyes, flush the affected area

with clean water immediately.
If you still experience discomfort,

see a doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level

to go down slightly as the brake

pads wear out or when the fluid

level in the accumulator is high.

If the reservoir needs frequent

refilling, there may be a serious

problem.

Adding the washer fluid

400

7-3. Do-it-yourself maintenance

The 12-volt battery is located in
the right-hand side of the trunk.

Remove the luggage mat:



P.352

■

Before recharging

When recharging, the 12-volt bat-

tery produces hydrogen gas which

is flammable and explosive. There-

fore, observe the following precau-

tions before recharging:

●

If recharging with the 12-volt bat-

tery installed on the vehicle, be

sure to disconnect the ground

cable.

●

Make sure the charger is off when

connecting and disconnecting the

charger cables to the 12-volt bat-

tery.

■

After recharging/reconnecting

the 12-volt battery

●

Unlocking the doors using the

smart key system may not be pos-

sible immediately after reconnect-

ing the 12-volt battery. If this

happens, use the wireless remote

control or the mechanical key to

lock/unlock the doors.

●

Start the fuel cell system with the

power switch in ACC. The fuel cell

system may not start with the

power switch turned off. However,

the fuel cell system will operate

normally from the second attempt.

WARNING

■

When adding washer fluid

Do not add washer fluid when the

fuel cell system is hot or operating

as washer fluid contains alcohol

and may catch fire if spilled on the

fuel cell system, etc.

NOTICE

■

Do not use any fluid other

than washer fluid

Do not use soapy water or anti-

freeze instead of washer fluid.

Doing so may cause streaking on

the vehicle’s painted surfaces, as

well as damaging the pump lead-

ing to problems of the washer

fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as

necessary.

Refer to the freezing tempera-

tures listed on the label of the

washer fluid bottle.

12-volt battery

Location

401

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

●

The power switch mode is

recorded by the vehicle. If the 12-

volt battery is reconnected, the

vehicle will return the power

switch mode to the status it was in

before the 12-volt battery was dis-

connected. Make sure to turn off

the power switch before discon-

necting the 12-volt battery. Take

extra care when connecting the

12-volt battery if the power switch

mode prior to discharge is

unknown.

●

When the 12-volt battery is recon-

nected, start the fuel cell system,

depress the brake pedal, and con-

firm that it is possible to shift into

each shift position.

If the system will not start even after

multiple attempts, contact your Toy-

ota dealer.

WARNING

■

Chemicals in the 12-volt bat-

tery

The 12-volt battery contains poi-

sonous and corrosive sulfuric acid

and may produce hydrogen gas

which is flammable and explosive.

To reduce the risk of death or seri-

ous injury, take the following pre-

cautions while working on or near

the 12-volt battery:

●

Do not cause sparks by touch-

ing the 12-volt battery terminals

with tools.

●

Do not smoke or light a match

near the 12-volt battery.

●

Avoid contact with eyes, skin

and clothes.

●

Never inhale or swallow electro-

lyte.

●

Wear protective safety glasses

when working near the 12-volt

battery.

●

Keep children away from the

12-volt battery.

■

Where to safely charge the

12-volt battery

Always charge the 12-volt battery

in an open area. Do not charge

the 12-volt battery in a garage or

closed room where there is insuf-

ficient ventilation.

■

Emergency measures regard-

ing electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean

water for at least 15 minutes

and get immediate medical

attention. If possible, continue

to apply water with a sponge or

cloth while traveling to the near-

est medical facility.

●

If electrolyte gets on your skin

Wash the affected area thor-

oughly. If you feel pain or burn-

ing, get medical attention

immediately.

●

If electrolyte gets on your

clothes

It can soak through clothing on

to your skin. Immediately take

off the clothing and follow the

procedure above if necessary.

●

If you accidentally swallow elec-

trolyte

Drink a large quantity of water

or milk. Get emergency medical

attention immediately.

■

When replacing the 12-volt

battery

Use a 12-volt battery designed for

this vehicle. Failure to do so may

cause gas (hydrogen) to enter the

passenger compartment, causing

a fire or explosion.
For replacement of the 12-volt

battery, contact your Toyota

dealer.

402

7-3. Do-it-yourself maintenance

Make sure that the 12-volt bat-
tery terminals are not corroded
and that there are no loose con-
nections, cracks, or loose
clamps.

Terminals

Hold-down clamp

Check the 12-volt battery condi-
tion by indicator color.

Blue: Good condition

Red: Charging is necessary.
Have the vehicle inspected
by your Toyota dealer.

Clear: Replacement is nec-
essary.
Have the 12-volt battery
checked by your Toyota
dealer.

NOTICE

■

When recharging the 12-volt

battery

Never recharge the 12-volt bat-

tery while the fuel cell system is

operating. Also, be sure all acces-

sories are turned off.

Exterior

Checking the 12-volt bat-
tery condition
