5-15. Phone settings

Audio

To add another number to
this contact, select “Yes”.

■

Registering a new contact
in a different way (from the
call history screen)

Display the phone top
screen. (



P.463)

Select “History” and select a
contact not yet registered in
the contact list.

Select “Add to Contacts”.

Follow the steps in “Register-
ing a new contact to the con-
tacts list” from step

(



P.484)

For PBAP compatible
Bluetooth

phones, this function

is available when “Automatic
Transfer” is set to off. (



P.481)

Select “Edit Contact”.

Select the desired contact.

Select

next to the name

or desired number.

Enter the name or the phone
number and select “OK”.

For PBAP compatible
Bluetooth

phones, this function

is available when “Automatic
Transfer” is set to off. (



P.481)

Select “Delete Contacts”.

Select the desired contact
and select “Delete”.

Select “Yes” when the confir-
mation screen appears.

●

Multiple data can be selected and

deleted at the same time.

●

When a Bluetooth

phone is

deleted, the contact data will be

deleted at the same time.

Up to 15 contacts (maximum of
4 numbers per contact) can be
registered in the favorites list.

■

Registering the contacts in
the favorites list

Select “Add Favorite”.

Select the desired contact to
add to the favorites list.



Dimmed contacts are already
stored as a favorite.

Check that a confirmation
screen is displayed when the
operation is complete.



When 15 contacts have
already been registered to the
favorites list

When 15 contacts have
already been registered to
the favorites list, a registered
contact needs to be replaced.
Select “Yes” when the confir-
mation screen appears to
replace a contact.

Select the contact to be
replaced.

Editing the contact data

Deleting the contact data

Favorites list setting

486

5-15. Phone settings

Check that a confirmation
screen is displayed when the
operation is complete.

■

Registering contacts in the
favorites list in a different
way (from the contact
details screen)

Display the phone top
screen. (



P.463)

Select “Contacts” and select
the desired contact.

Select “Add Favorite”.

Check that a confirmation
screen is displayed when the
operation is complete.

■

Deleting favorites from the
favorites list

Select “Remove Favorite”.

Select the desired contacts
and select “Remove”.

Select “Yes” when the confir-
mation screen appears.

Check that a confirmation
screen is displayed when the
operation is complete.

■

Deleting favorites from the
favorites list in a different
way (from the contact
details screen)

Display the phone top
screen. (



P.463)

Select “Favorites” or “Con-
tacts” and then select the
favorite you wish to delete.

Select “Remove Favorite”.

Select “Yes” when the confir-
mation screen appears.

Check that a confirmation
screen is displayed when the
operation is complete.

Calls can be made by saying the
voice tag of a registered contact
in the contact list. (



P.454)

Select “Manage Voice Tags”.

Select the desired item to be
set.

Select to register a new voice
tag. (



P.486)

Select to edit a voice tag.
(



P.487)

Select to delete a voice tag.
(



P.487)

■

Registering a voice tag

Up to 50 voice tags can be reg-
istered.

Select “New”.

Select the desired contact to
register a voice tag for.

Select “REC” and record a
voice tag.



When recording a voice tag,

Setting voice tags

487

5-15. Phone settings

Audio

do so in a quiet area.

“Play”: Select to play the voice tag.

Select “OK” when voice tag
registration is complete.

■

Editing a voice tag

Select “Edit”.

Select the desired contact to
edit.

Follow the steps in “Register-
ing a voice tag” from step

(



P.486)

■

Deleting the voice tag

Select “Delete”.

Select the desired contact
and select “Delete”.

Select “Yes” when the confir-
mation screen appears.

●

Multiple data can be selected and

deleted at the same time.

●

Voice tags are deleted when the

set language of the system is

changed. (



P.410)

Display the phone settings
screen. (



P.479)

Select “Messaging”.

Select the desired item to be
set.

Select to set automatic mes-
sage transfer on/off.

Select to set automatic mes-
sage readout on/off.

Select to set updating mes-
sage read status on phone
on/off.

Select to set display of mes-
saging account names on the
message screen on/off.
When set to on, messaging
account names used on the
cellular phone will be dis-
played.

Select to set adding the vehi-
cle signature to outgoing
messages on/off.
The vehicle signature can be
edited. (



P.487)

Select to reset all setup
items.

●

Depending on the phone, these

functions may not be available.

Select “Vehicle Signature”.

Message settings screen

Vehicle signature settings

488

5-15. Phone settings

Select the desired item to be
set.

Select to set adding the vehi-
cle signature to outgoing
messages on/off.

Select to edit the vehicle sig-
nature. (



P.488)

Select to reset all setup
items.

■

Editing vehicle signature

Select “Edit Vehicle Signa-
ture”.

Enter desired signature with
using keyboard.

Select “OK”.

Select “OK” on the confirma-
tion screen, or select “Edit
Again” when it needs to
amend.

489

5-16. What to do if... (Bluetooth

)

Audio

5-16.What to do if... (Bluetooth

)

■

When using the hands-free
system with a Bluetooth

device

The hands-free system or
Bluetooth

device does not

work.

■

When registering/connect-
ing a cellular phone

A cellular phone cannot be reg-
istered.

Troubleshooting

If there is a problem with the
hands-free system or a
Bluetooth

device, first

check the table below.

Troubleshooting

Likely cause

Solution

The connected
device may not
be a compatible
Bluetooth

cellu-

lar phone.

For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
http://www.
toyota.com/
audio-
multimedia in the
United States,
http://www.
toyota.ca/
connected
in Canada, and
https://www.
toyotapr.com/
serviciosconecta
dos in Puerto
Rico

The Bluetooth

version of the
connected cellu-
lar phone may
be older than the
specified ver-
sion.

Use a cellular
phone with
Bluetooth

ver-

sion 2.0 or
higher (recom-
mended: Ver.
4.2 or higher).
(



P.389)

490

5-16. What to do if... (Bluetooth

)

A Bluetooth

connection can-

not be made.

■

When making/receiving a
call

A call cannot be made/received.

■

When using the phonebook

Phonebook data cannot be
transferred manually/automati-
cally.

Likely cause

Solution

An incorrect
passcode was
entered on the
cellular phone.

Enter the correct
passcode on the
cellular phone.

The registration
operation has
not been com-
pleted on the cel-
lular phone side.

Complete the
registration oper-
ation on the cel-
lular phone
(approve regis-
tration on the
phone).

Old registration
information
remains on
either this sys-
tem or the cellu-
lar phone.

Delete the exist-
ing registration
information from
both this system
and the cellular
phone, then reg-
ister the cellular
phone you wish
to connect to this
system.
(



P.393)

Likely cause

Solution

Another
Bluetooth

device is already
connected.

Manually con-
nect the cellular
phone you wish
to use to this
system.
(



P.391)

Bluetooth

func-

tion is not
enabled on the
cellular phone.

Enable the
Bluetooth

func-

tion on the cellu-
lar phone.

Automatic
Bluetooth

con-

nection on this
system is set to
off.

Set automatic
Bluetooth

con-

nection on this
system to on
when the engine
switch is in ACC
or ON. (



P.396)

Preferred device
settings function
on this system is
set to on.

Set preferred
device settings
function on this
system to off.
(



P.396)

Set the desired
cellular phone to
the highest auto-
matic connec-
tion priority.
(



P.396)

Likely cause

Solution

Your vehicle is in
a

area.

Move to where

no longer

appears on the
display.

Likely cause

Solution

491

5-16. What to do if... (Bluetooth

)

Audio

Phonebook data cannot be

edited.

■

When using the Bluetooth

message function

Messages cannot be viewed.

New message notifications are
not displayed.

Likely cause

Solution

The profile ver-
sion of the con-
nected cellular
phone may not
be compatible
with transferring
phonebook data.

For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
http://www.
toyota.com/
audio-
multimedia in the
United States,
http://www.
toyota.ca/connec
ted in Canada,
and https://www.
toyotapr.com/
serviciosconecta
dos in Puerto
Rico

Automatic con-
tact transfer
function on this
system is set to
off.

Set automatic
contact transfer
function on this
system to on.
(



P.482)

Passcode has
not been entered
on the cellular
phone.

Enter the pass-
code on the cel-
lular phone if
requested
(default pass-
code: 1234).

Transfer opera-
tion on the cellu-
lar phone has
not completed.

Complete trans-
fer operation on
the cellular
phone (approve
transfer opera-
tion on the
phone).

Likely cause

Solution

Automatic con-
tact transfer
function on this
system is set to
on.

Set automatic
contact transfer
function on this
system to off.
(



P.482)

Likely cause

Solution

Message trans-
fer is not enabled
on the cellular
phone.

Enable mes-
sage transfer on
the cellular
phone (approve
message trans-
fer on the
phone).

Automatic trans-
fer function on
this system is set
to off.

Set automatic
transfer function
on this system to
on. (



P.482)

Likely cause

Solution

Notification of
SMS/MMS/E-
mail reception on
this system is set
to off.

Set notification
of SMS/MMS/E-
mail reception on
this system to
on. (



P.480)

Automatic mes-
sage transfer
function is not
enabled on the
cellular phone.

Enable auto-
matic transfer
function on the
cellular phone.

492

5-16. What to do if... (Bluetooth

)

■

In other situations

The Bluetooth

connection sta-

tus is displayed at the top of the
screen each time the engine
switch is in ACC or ON.

Even though all conceivable
measures have been taken, the
symptom status does not
change.

●

For details, refer to the owner’s

manual that came with the cellular

phone.

Likely cause

Solution

Connection con-
firmation display
on this system is
set to on.

To turn off the
display, set con-
nection confir-
mation display
on this system to
off. (



P.396)

Likely cause

Solution

The cellular
phone is not
close enough to
this system.

Bring the cellu-
lar phone closer
to this system.

Radio interfer-
ence has
occurred.

Turn off Wi-Fi

devices or other
devices that may
emit radio
waves.

The cellular
phone is the
most likely cause
of the symptom.

Turn the cellular
phone off,
remove and rein-
stall the battery
pack, and then
restart the cellu-
lar phone.

Enable the cellu-
lar phone’s
Bluetooth

con-

nection.

Disable the
Wi-Fi

connec-

tion of the cellu-
lar phone.

Stop the cellular
phone’s security
software and
close all applica-
tions.

Before using an
application
installed on the
cellular phone,
carefully check
its source and
how its operation
might affect this
system.

Likely cause

Solution

493

5-17. Connected Services overview

Audio

5-17.Connected Services overview

: This function is not made avail-

able in some countries or areas.



The functions included are
classified into the following
four types.

• Type A: Function achieved by

using a smartphone or an embed-
ded cellular device in the vehicle
(DCM: Data Communication
Module) and the system

• Type B: Function achieved by

using DCM and the system

• Type C: Function achieved by

using DCM

• Type D: Function achieved by

using DCM and a smartphone

●

Connected Services functionality

is dependent upon network recep-

tion level and signal strength.

●

Each function is available in the

following areas:

• Toyota Apps is available in the

contiguous United States, Wash-

ington D.C. and Alaska.

• Wi-Fi

Hotspot is available in the

contiguous United States, Wash-

ington D.C. and Alaska.

• Safety Connect is available in the

contiguous United States, Wash-

ington D.C. and Alaska.

• Remote Connect is available in

the contiguous United States,

Washington D.C. and Alaska.

• Service Connect is available in the

contiguous United States, Wash-

ington D.C. and Alaska.

Connected Services

Connected Services
includes Toyota Apps, Ser-
vice Connect, Wi-Fi

Hotspot, Safety Connect
and Remote Connect.

Functional overview

Function

Type

Toyota Apps

Type A

Wi-Fi

Hotspot

Type B

Safety Connect

Type C

Remote Connect, Ser-
vice Connect

Type D

494

5-17. Connected Services overview

Content provider
Provides contents to the application server.

Application server

Type A: Function achieved by using a smart-

phone or DCM

Of the functions included with Connected Services, the
Toyota Apps rely on the use of a smartphone or DCM.



Using a smartphone

• Toyota audio multimedia system enables applicable apps

installed on a smartphone to be displayed on and operated from
the screen via a Bluetooth



Via DCM

• Toyota audio multimedia system enables applicable apps

installed on the system to be displayed on and operated from the
screen.

A few settings must be performed before Toyota Apps can be
used. (



P.496)

By using a smartphone or DCM

495

5-17. Connected Services overview

Audio

Provides applications to the system or a smartphone.

Smartphone

Using the Toyota mobile application, communication is relayed
between the system, application server and content provider.

Applications
Display usable content from the content providers on the screen
using the data connection of the connected smartphone or DCM.

System
Content received, via a smartphone or DCM, from content pro-
vider servers is displayed on the screen. The system is equipped
with an application player to run applications.

Via DCM

: For known compatible phones, refer to http://www.toyota.com/

connected-services in the United States.

The required operations to acti-
vate applications and connect a
smartphone to the system, and
the registration steps for the
Connected Services are
explained in this section.

■

Subscription



Services requiring a separate
contract can also be used.

: For details, refer to

http://www.toyota.com/
connected-services
or call 1-800-331-4331 in the
United States.

■

Availability of function



Toyota Apps is available in
the contiguous United States,
Washington D.C. and Alaska.

●

Data usage fees may apply while

using Toyota Apps. Confirm data

usage fees before using this func-

tion.

●

For details regarding operation of

the Toyota Apps, refer to

http://www.toyota.com/

connected-services

in the United States.

●

These functions are not made

available in some countries or

areas. Availability of functions of

the Toyota Apps is dependent on

network reception level.

■

Initializing personal data

The personal data used in appli-
cations can be reset. (



P.413)



The following personal data
can be deleted and returned
to their default settings:

• Downloaded contents
• Radio stations that were listened

●

Once initialized, the data and set-

tings will be erased. Pay much

attention when initializing the

Before using the function

496

5-17. Connected Services overview

data.

■

Settings required to use
Toyota mobile application

Perform the settings in the fol-
lowing order.

Download the Toyota mobile
application to your smart-
phone.

Open the Toyota mobile
application on your smart
phone and follow instruc-
tions. Bluetooth

Pairing is

required.

In order to use Toyota mobile appli-

cation, the following must first be

performed:



phone

with the hands-free system.
(



P.386)

●

Applications can only be used

when the Toyota mobile applica-

tion has been downloaded to your

smartphone, and the application is

running.

●

Toyota mobile application opera-

tional procedures can also be con-

firmed by visiting

http://www.toyota.com/

connected-services

in the United States.

●

If a Toyota mobile application is

used while iPod audio/video is

being played back, system opera-

tion may become unstable.

: Vehicles equipped with DCM

■

Subscription



After you have signed the
Telematics Subscription Ser-
vice Agreement and are
enrolled, you can begin
receiving services. A variety
of subscription terms are
available. Contact your

Preparation before using
Toyota mobile application

Type B: Function

achieved by using

DCM and the system

The functionality of Wi-Fi

Hotspot is made possible
through the shared work of
the DCM and the system.
These are subscription-
based telematics services
that use Global Positioning
System (GPS) data and
embedded cellular technol-
ogy to provide safety and
security as well as conve-
nience features.
These services are available
by subscription on select,
telematics hardware-
equipped vehicles and sup-
ported by the Toyota
response center, which
operates 24 hours a day, 7
days a week.

For details about Wi-Fi

Hotspot:



P.398

Before using the function

497

5-17. Connected Services overview

Audio

Toyota dealer, or call 1-800-
331-4331 in the United
States, for further subscription
details. (



P.495)

■

Availability of functions



Wi-Fi

Hotspot is available in

the contiguous United States,
Washington D.C. and Alaska.

: Vehicles equipped with DCM

●

Free/Open Source Software Infor-

mation

This product contains Free/Open

Source Software (FOSS).

The license information and/or the

source code of such FOSS can be

found at the following URL.

http://opensource.lge.com

●

Exposure to radio frequency sig-

nals:

The Toyota audio multimedia sys-

tem installed in your vehicle

includes a low power radio trans-

mitter and receiver. The system

receives and also sends out radio

frequency (RF) signals.

●

In August 1996, the Federal Com-

munications Commission (FCC)

adopted RF exposure guidelines

with safety levels for mobile wire-

less phones. Those guidelines are

consistent with the safety stan-

dards previously set by both U.S.

and international standards bod-

ies.

• ANSI (American National Stan-

dards Institute) C95.1 [1992]

• NCRP (National Council on Radi-

ation Protection and Measure-

ment) Report 86 [1986]

• ICNIRP (International Commis-

sion on Non-Ionizing Radiation

Protection) [1996]

●

These standards are based on

comprehensive and periodic eval-

uations of the relevant scientific lit-

erature. Over 120 scientists,

engineers, and physicians from

Type C: Function

achieved by using

DCM

The functionality of Safety
Connect is made possible
by the use of a DCM.
For details, (



P.66)

498

5-17. Connected Services overview

universities, government health

agencies, and industry reviewed

the available body of research to

develop the ANSI Standard

(C95.1).

●

The design of Toyota audio multi-

media system complies with the

FCC guidelines in addition to

those standards.

●

Contact with the Toyota response

center is dependent upon the

telematics device being in opera-

tive condition, cellular connection

availability and GPS satellite sig-

nal reception, which can limit the

ability to reach the Toyota

response center or receive sup-

port. Enrollment and Telematics

Subscription Service Agreement

required. A variety of subscription

terms are available; charges vary

by subscription term selected.

●

The Toyota response center

offers support in multiple lan-

guages.

●

Select Safety Connect-sub-

scribed vehicles are capable of

communicating vehicle informa-

tion. Please see the terms and

conditions for additional details.

Owners who do not wish to have

their vehicle transmit this informa-

tion can opt out at the time of

enrollment or by calling 1-800-

331-4331 in the United States,

and following the prompts for

Safety Connect.

●

For further details about the ser-

vice, contact your Toyota dealer.

●

Toyota audio multimedia are not

subject to section 255 of the Tele-

communications Act and the sys-

tem is not TTY compatible.

500

5-17. Connected Services overview

: Vehicles equipped with remote

connect only

Remote Connect is a service
that lets you view and remotely
control certain aspects of your
vehicle.

■

Subscription



After you sign the Telematics
Subscription Service Agree-
ment (see the Safety Connect
section



P.66), download the

Toyota App from your smart-
phone app store, and register
within the app (or enroll and
complete registration at the
dealer), you can begin using
these services.



A variety of subscription terms
are available. Contact your
Toyota dealer, or call 1-800-
331-4331 for further subscrip-

tion details.

■

Availability of function



Remote Connect is available
in the contiguous United
States, Washington D.C. and
Alaska.

●

Availability of functions of the

Remote Connect is dependent on

network reception level.

●

Remote Connect should only be

used by authorized users.

●

Laws in some communities may

require that the vehicle be within

view of the user when operating

Remote Connect.

In some states, use of Remote

Connect may violate state or local

laws. Before using Remote Con-

nect, check your state and local

laws.

●

Any malfunction of the vehicle

should be repaired by your Toyota

dealer.

●

Remote Connect is designed to

work at temperatures above

approximately -22 °F (-30 °C).

This specification is related to the

Remote Connect operation, but is

dependent on the vehicle’s oper-

ating temperature range which

may be different.

●

Content is subject to change with-

out notice.

●

Additional information can be

found at http://www.toyota.com/

connected-services in the United

States.

Type D: Function

achieved by using

DCM and a smart-

phone

The functionality of Remote
Connect and Service Con-
nect are made possible by
the use of a DCM and a
smartphone.
For details about these ser-
vices, refer to
http://www.toyota.com/conn
ected-services.

Remote Connect

WARNING

●

Operating Remote Connect

incorrectly may lead to unfore-

seen accidents or malfunctions.

Check the vehicle condition and

assume full responsibility before

using.

Toyota RAV4 (2022 year). Manual in english - page 30
