Select to set the fader/bal-
ance. (



P.419)

Select to set the automatic
sound leveliser. (

P.419)

■

Treble/Mid/Bass

How good an audio program
sounds is largely determined by
the mix of the treble, mid and
bass levels. In fact, different
kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid
and bass.

Select “Treble/Mid/Bass”.

Reordering the audio
source

USB port

Sound settings

419

5-6. Using the audio/visual system

Audio

Select the desired screen
button.

Select “+” or “-” to adjust
high-pitched tones.

Select “+” or “-” to adjust mid-
pitched tones.

Select “+” or “-” to adjust low-
pitched tones.

■

Fader/Balance

A good balance of the left and
right stereo channels and of the
front and rear sound levels is
also important.
Keep in mind that when listening
to a stereo recording or broad-
cast, changing the right/left bal-
ance will increase the volume of
1 group of sounds while
decreasing the volume of
another.

Select “Fader/Balance”.

Select the desired screen
button.

Select to adjust the sound
balance between the front
and rear speakers.

Select to adjust the sound
balance between the left and
right speakers.

■

Automatic sound levelizer
(ASL)

The system adjusts to the opti-
mum volume and tone quality
according to vehicle speed to
compensate for increased road
noise, wind noise, or other
noises while driving.

Select “Automatic Sound
Levelizer”.

Select “High”, “Mid”, “Low” or
“Off”.

■

Screen format settings

The screen format can be
selected for USB video.

Press the “MENU” button.

Select “Setup”.

Select “Audio”.

Audio screen adjustment

420

5-6. Using the audio/visual system

Select “Common”.

Select “Screen Format”.

Select the desired item to be
adjusted.

Select to display a 4 : 3
screen, with either side in
black.

Select to enlarge the image
horizontally and vertically to
full screen.

Select to enlarge the image
by the same ratio horizontally
and vertically.

■

Contrast and brightness
adjustment

The contrast and brightness of
the screen can be adjusted.

Press the “MENU” button.

Select “Setup”.

Select “Audio”.

Select “Common”.

Select “Display”.

Select the desired item to be
adjusted.



“Contrast”

“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of

the screen.



“Brightness”

“+”: Select to brighten the screen.
“-”: Select to darken the screen.

●

Depending on the audio source,

some functions may not be avail-

able.

Press this switch to operate
the voice command system.



The voice command system
and its list of commands can
be operated. (



P.454)

Voice command system

421

5-7. Radio operation

Audio

5-7.Radio operation

: This function is not made avail-

able in some countries or areas.

The radio operation screen can
be reached by the following
methods:



P.417

Select to display the audio
source selection screen.

Select to display the preset
stations screen. (



P.422)

Select to display the cache
radio operation screen.
(



P.422)

Select to display a list of
receivable stations.
(



Select to display the radio
options screen. (



Select to display the sound
setting screen. (

Select to tune to preset sta-

tions/channels. (



P.422)

Displays items on the chan-
nels registered to smart
favorites

(

P.426, 441)

Displays the artist info and
song title or album
Select to change the dis-
played information.
Displays messages when
available

Displays cover art, station
logo, etc.

Displays information about
the song/track currently
being played

: This function is not made avail-

able in some countries or areas.

Press to seek for stations in
the relevant program
type/channel category.
Press and hold for continu-
ous seek.

Turn to step up/down fre-
quencies/channels.
Turn to move up/down the
station list. Also, the knob

AM/FM/SiriusXM (SXM)

radio

Overview

Control screen

Control panel

422

5-7. Radio operation

can be used to enter selec-
tions on the list screens by
pressing it.

●

The radio automatically changes

to stereo reception when a stereo

broadcast is received.

Radio mode has a mix preset
function, which can store up to
36 stations (6 stations per page
x 6 pages) from any of the AM,
FM or SXM

bands.

Tune in the desired station.

Select and hold “(Hold Edit)”.



When “(Hold Edit)” is
selected, a confirmation mes-
sage appears. Select “Yes”
and select “OK”.



To change the preset station
to a different one, select and
hold the preset station.

: This function is not made avail-

able in some countries or areas.

●

The number of preset radio sta-

tions displayed on the screen can

be changed. (



P.440)

: This function is not made avail-

able in some countries or areas.

AM/FM and SXM radio program
can be cached and played back
in a time-shifted manner.

■

Automatic playback of the
cache

If the radio broadcast is inter-
rupted by another audio output,
such as an incoming phone call,
the system will automatically
cache the interrupted portion
and perform time-shift playback
when the interruption ends. This
function is available when “Auto
Pause” is set to on. (

■

Playing back the cache
manually

The broadcast cached in the
program cache can be played
back manually.

Select “SXM Replay”.

Select the desired cache
radio operation button.

Returns to the live radio
broadcast

Displays the replay offset

Presetting a station

Caching a radio program

423

5-7. Radio operation

Audio

from the current time

Skips backward 2 minutes
(AM/FM)
Select to select current/previ-
ous track (SXM)

Fast rewinds continuously

Pauses the playback (To
restart, select

)

Fast forwards continuously

Skips forward 2 minutes
(AM/FM)
Select to change the track
(SXM)

●

The system can store up to 20

minutes of AM/FM and less than

60 minutes of SXM. Cached data

will be erased when the radio

mode or station is changed or

when the audio system is turned

off.

●

AM/FM: If noise or silence occurs

during the caching process, cache

writing will continue, with the noise

or silence recorded as is. In this

case, the cached broadcast will

contain the noise or silence when

played back.

Select “Station List”.

Select “AM”, “FM” or “SXM

”.



Select the desired program
genre when the genre selec-
tion screen is displayed.

Select the desired station.

: This function is not made avail-

able in some countries or areas.

■

Refreshing the station list
(AM/FM)

Select “Station List”.

“Cancel Refresh”: Select to can-
cel the refresh.
“Source”: Select to change to
another audio source while
refreshing.

●

The audio/visual system sound is

muted during refresh operation.

●

In some situations, it may take

some time to update the station

list.

Select “Options”.

Select the desired item to be
set.

Select to turn automatic play-
back of the cache on/off.

When “SXM Tune Start” is
turned on, the current song is
played from the beginning
when you select the chan-
nel.

Analog FM only: Select to
display RBDS text mes-
sages.

Selecting a station from
the list

Radio options

424

5-7. Radio operation

Select to scan for receivable
stations. (Type scan in case
SXM

is current program

type/channel category.)

: This function is not made avail-

able in some countries or areas.

This audio/visual system is
equipped with Radio Broadcast
Data Systems (RBDS). RBDS
mode allows text messages to
be received from radio stations
that utilize RBDS transmitters.
When RBDS is on, the radio can
do the following functions.
• Only selecting stations of a

particular program type

• Displaying messages from

radio stations

• Searching for a stronger sig-

nal station

RBDS features are available
only when listening to an FM
station that broadcasts RBDS
information and the “FM Info”
function is on. (



: This function is not made avail-

able in some countries or areas.

All SiriusXM services, including
satellite radio and data services,
plus streaming services, require
a subscription, sold separately

or as a package by Sirius XM
Radio Inc. (or, in Canada, Sirius
XM Canada Inc.), after any trial
subscription which may be
included with your vehicle pur-
chase or lease. To subscribe
after your trial subscription, call
1-877-447-0011 (U.S.A.) or 1-
877-438-9677 (Canada).

■

Important information
about your subscription

Your SiriusXM services will
automatically stop at the end of
your trial unless you decide to
subscribe. If you decide to con-
tinue service, the paid subscrip-
tion plan you choose will
automatically renew and you will
be charged the rate in effect at
that time and according to your
chosen payment method. Fees
and taxes apply. You may can-
cel at any time by calling 1-866-
635-2349. See SiriusXM Cus-
tomer Agreement for complete
terms at www.siriusxm.com
(U.S.A.) or www.siriusxm.ca
(Canada). All fees and program-
ming subject to change. Traffic
information not available in all
markets.

Radio broadcast data sys-
tem

How to subscribe to Siri-
usXM Radio Services

425

5-7. Radio operation

●

ABOUT SiriusXM Services

• Most in-car trials today include

SiriusXM’s best package



All

Access. It includes every channel

available on your radio, plus

streaming.

●

SiriusXM All Access Subscription

• Listen everywhere with All

Access. You get every channel

available in your ride, plus you can

listen on the app and online



you can enjoy the best SiriusXM

has to offer, anywhere life takes

you. It’s the only package that

gives you all of our premium pro-

gramming, including Howard
Stern, every NFL, MLB

and NBA

game, every NASCAR

race,

NHL

games, 24/7 talk channels

dedicated to the biggest leagues,

and more. You get all kinds of

commercial-free music, including

artist-dedicated channels and

more, plus sports, news, talk and

entertainment.

Did you know? SiriusXM also

delivers a wide variety of services

to certain vehicles’ entertainment

and navigation systems such as

Traffic, Weather, Sports Scores,

Movie Listings, Fuel Prices, Stock

Prices and more. For a list of

available features in your vehicle,

visit siriusxm.com/infotainment

and get the most out of your driv-

ing experience.

●

RADIO OPERATION

• Look for the Sirius, XM, SiriusXM,

Band, SAT, AUX, Radio or Source

button and you’re in. If you can’t

hear us, it’s easy to get started:

Locate your Radio ID by turning to

Channel 0. If you don’t see your

number there, go to siri-

usxm.com/activationhelp to find it.

Visit siriusxm.com/refresh or call

1-855-MYREFRESH (697-3373)

to send a refresh signal to your

radio.

Canadian Customers:

Locate your Radio ID by turning to

Channel 0.

Visit siriusxm.ca/refresh to send a

refresh signal to your radio or call

1-888-539-7474 for service.

: This function is not made avail-

able in some countries or areas.

Each SiriusXM tuner is identified
with a unique radio ID. The radio
ID is required when activating
an SiriusXM Satellite service or
when reporting a problem.



If “Ch 000” is selected using
the “TUNE SCROLL” knob,
the ID code, which is 8 alpha-
numeric characters, will be
displayed. If another channel
is selected, the ID code will no
longer be displayed.

NOTICE

●

It is prohibited to copy, decom-

pile, disassemble, reverse engi-

neer, hack, manipulate, or

otherwise make available any

technology or software incorpo-

rated in receivers compatible

with the SiriusXM Satellite

Radio System or that support

the SiriusXM website, the

streaming service or any of its

content. Furthermore, the
AMBE

voice compression soft-

ware included in this product is

protected by intellectual prop-

erty rights including patent

rights, copyrights, and trade

secrets of Digital Voice Sys-

tems, Inc.

●

Note: this applies to SiriusXM

Satellite Radio receivers only

and not SiriusXM Ready

devices.

Displaying the radio ID

426

5-7. Radio operation

: This function is not made avail-

able in some countries or areas.

Up to 20 channels can be regis-
tered as presets in the cache.
For channel registration, refer to
(

P.440).

Select channels registered to
smart favorites.

Select “SXM Replay”.

●

Caches up to 30 minutes for each

Smart Favorite preset.

●

The radio plays the track from

start when that track has not previ-

ously been heard by the user and

the station is registered as a smart

favorite.

●

When “SXM Tune Start” is turned

on (

P.423), the current song is

played from the beginning when

you select the channel.

●

Displays icons on the channels

registered to smart favorites.

(



P.421)

When problems occur with the SiriusXM tuner, a message will
appear on the screen. Referring to the table below to identify the
problem, take the suggested corrective action

: This function is not made available in some countries or areas.

●

Contact the SiriusXM Listener Care Center at 1-877-447-0011 (U.S.A.) or

Smart favorites

Refer to the table below to identify the problem and take
the suggested corrective action

Message

Explanation

“Check

Antenna”

The SiriusXM antenna is not connected. Check whether the
SiriusXM antenna cable is attached securely. Contact your
Toyota dealer for assistance.

A short circuit occurs in the antenna or the surrounding
antenna cable. Contact your Toyota dealer for assistance.

“No Signal”

The SiriusXM signal is too weak at the current location. Wait
until your vehicle reaches a location with a stronger signal.

“Chan

Unavailable”

The channel you selected is not broadcasting any program-
ming. Select another channel.

“Ch Unsub-

scribed”

The channel you selected is no longer available. Wait for
about 2 seconds until the radio returns to the previous chan-
nel or “Ch 001”. If it does not change automatically, select
another channel.

“Subscription

Updated”

Subscription is updated. Select “OK” to clear this message.

427

5-7. Radio operation

Audio

1-877-438-9677 (Canada).

428

5-8. Media operation

5-8.Media operation

The USB memory operation
screen can be reached by the
following methods:



P.417



Connecting a USB memory
(



When an Apple Car-
Play/Android Auto connec-
tion is established, this
function will be unavailable.



USB audio

Select to display the audio
source selection screen.

Select to return to the top
screen.

Select to display a song list
screen.

Select to display the play
mode selection screen.

Select to display the sound
setting screen. (

Select to set repeat playback.
(



P.429)

Select to change the
file/track.
Select and hold to fast
rewind.

Select to play/pause.

Select to change the
file/track.
Select and hold to fast for-
ward.

Select to set random play-
back. (

P.429)

Select to change the
folder/album.

Displays cover art

Select to change the artist.



USB video

Select “Browse”.

Select “Videos”.

Select the desired folder and
file.

Select to display the audio
source selection screen.

Select to return to the top
screen.

Select to display a song list
screen.

Select to display the play

USB memory

Overview

Control screen

429

5-8. Media operation

mode selection screen.

Select to display the sound
setting screen. (

Select to change the file.
Select and hold to fast
rewind.

Select to play/pause.

Select to change the file.
Select and hold to fast for-
ward.

Select to display a full screen
image.

Select to change the folder.

Press to change the
file/track.
Press and hold to fast for-
ward/rewind.

Turn to change the file/track.
Turn to move up/down the
list. Also, the knob can be
used to enter selections on
the list screens by pressing it.

●

While the vehicle is being driven,

this function can only output

sound.

●

If tag information exists, the

file/folder names will be changed

to track/album names.

The file/track or folder/album
currently being listened to can
be repeated.

Select

●

Each time

is selected, the

mode changes as follows:



When random playback is off

• file/track repeat



folder/album

repeat



off



When random playback is on

• file/track repeat



off

Files/tracks or folders/albums
can be automatically and ran-
domly selected.

Select

●

Each time

is selected, the

mode changes as follows:

• random (1 folder/album random)



folder/album random (all

folder/album random)



off

Control panel

Repeating

Random order

WARNING

●

Do not operate the player’s con-

trols or connect the USB mem-

ory while driving.

NOTICE

●

Do not leave your portable

player in the car. In particular,

high temperatures inside the

vehicle may damage the porta-

ble player.

430

5-8. Media operation

: This function is not made avail-

able in some countries or areas.

The iPod/iPhone operation
screen can be reached by the
following methods:

P.417



Connecting an iPod/iPhone
(





When an Android Auto con-
nection is established, this
function will be unavailable.



An Apple CarPlay connection
is not established

Select to display the audio
source selection screen.

Select to return to the top
screen.

Select to display a song list
screen.

Select to display the play
mode selection screen.

Select to display the sound

NOTICE

●

Do not push down on or apply

unnecessary pressure to the

portable player while it is con-

nected as this may damage the

portable player or its terminal.

●

Do not insert foreign objects into

the port as this may damage the

portable player or its terminal.

iPod/iPhone (Apple

CarPlay

)

Overview

Control screen

431

5-8. Media operation

Audio

setting screen. (

Select to set repeat playback.
(



Select to change the track.
Select and hold to fast
rewind.

Select to play/pause.

Select to change the track.
Select and hold to fast for-
ward.

Select to set random play-
back. (



Displays cover art

Select to change the album.

Select to change the artist.

Select to change the playlist.



An Apple CarPlay connection
is established

Select to display the audio
source selection screen.

Select to return to the top
screen.

Select to display the sound
setting screen. (

Select to display the Apple
CarPlay screen.

Select to set repeat playback.
(



Select to change the track.
Select and hold to fast
rewind.

Select to play/pause.

Select to change the track.
Select and hold to fast for-
ward.

Select to set random play-
back. (
