1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM–127

EM

CAMSHAFT TIMING
GEAR ASSEMBLY

CAMSHAFT TIMING GEAR
OR SPROCKET

NO. 3 CHAIN TENSIONER
ASSEMBLY

9.0 (92, 80 in.*lbf)

24 (245, 18)

N*m (kgf*cm, ft*lbf)  : Specified torque

100 (1,020, 74)

x3

24 (245, 18)

9.0 (92, 80 in.*lbf)

x3

NO. 3 CAMSHAFT

NO. 4 CAMSHAFT

NO. 2 CHAIN

100 (1,020, 74)

19 (194, 14)

A126345E01

EM–128

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM

CAMSHAFT TIMING GEAR ASSEMBLY

CAMSHAFT TIMING GEAR OR SPROCKET

NO. 1 CAMSHAFT BEARING

NO. 2 CAMSHAFT BEARING

NO. 2 CHAIN TENSIONER
ASSEMBLY

9.0 (92, 80 in.*lbf)

NO. 2 CAMSHAFT

24 (245, 18)

N*m (kgf*cm, ft*lbf)  : Specified torque

x3

24 (245, 18)

9.0 (92, 80 in.*lbf)

NO. 2 CHAIN

NO. 1 CAMSHAFT

x3

100 (1,020, 74)

100 (1,020, 74)

19 (194, 14)

A126344E01

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM–129

EM

CYLINDER HEAD LH

CYLINDER HEAD
SET BOLT

NO. 1 WATER OUTLET PIPE

NO. 2 CYLINDER
HEAD GASKET

KNOCK SENSOR WIRE

30 (306, 22)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

1st: 36 (367, 27)

2nd: Turn 180°

x8

4.0 (41, 35 in.*lbf)

x2

4.0 (41, 35 in.*lbf)

x2

9.0 (92, 80 in.*lbf)

x6

x2

x2

10 (102, 7.4)

10 (102, 7.4)

A126346E01

EM–130

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM

CYLINDER HEAD GASKET

CYLINDER HEAD SET BOLT

CYLINDER HEAD SUB-ASSEMBLY

KNOCK SENSOR

KNOCK SENSOR

4.0 (41, 35 in.*lbf)

20 (204, 15)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

1st: 36 (367, 27)
2nd: Turn 180°

x2

x6

x2

4.0 (41, 35 in.*lbf)

20 (204, 15)

x2

9.0 (92, 80 in.*lbf)

x6

A126347E01
