1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM–123

EM

NO.2 OIL PAN SUB-ASSEMBLY

OIL PAN DRAIN PLUG

OIL PAN SUB-ASSEMBLY

OIL STRAINER SUB-ASSEMBLY

9.0 (92, 80 in.*lbf)

21 (214, 16)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

O-RING

GASKET

21 (214, 16)

21 (214, 16)

x9

x2

x6

x2

x2

x2

x2

10 (102, 7.0)

GASKET

40 (408, 30)

9.0 (92, 80 in.*lbf)

x10

x2

10 (102, 7.4)

A126340E01

EM–124

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM

CRANKSHAFT
POSITION SENSOR

OIL CONTROL VALVE FILTER

REAR ENGINE OIL SEAL

REAR ENGINE OIL SEAL RETAINER

OIL CONTROL VALVE FILTER

9.0 (92, 80 in.*lbf)

62 (632, 46)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

O-RING

GASKET

PLUG

10 (102, 7.4)

PLUG

62 (632, 46)

GASKET

9.0 (92, 80 in.*lbf)

x2

x5

10 (102, 7.4)

Apply MP grease

OIL LEVEL GAUGE
GUIDE

A126341E01

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM–125

EM

CRANKSHAFT
PULLEY

TIMING CHAIN OR
BELT COVER
SUB-ASSEMBLY

WATER PUMP
ASSEMBLY

9.0 (92, 80 in.*lbf)

23 (235, 17)

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

GASKET

x9

TIMING CHAIN
COVER PLATE

GASKET

x4

x8

9.0 (92, 80 in.*lbf)

x9

23 (235, 17)

250 (2,549, 184)

TIMING GEAR CASE
OR TIMING CHAIN
CASE OIL SEAL

x6

x2

23 (235, 17)

23 (235, 17)

Apply MP grease

A126342E01

EM–126

1GR-FE ENGINE MECHANICAL  –  ENGINE UNIT

EM

CAMSHAFT TIMING
GEAR OR SPROCKET

CHAIN SUB-ASSEMBLY

CHAIN TENSIONER
SLIPPER

NO. 1 IDLE GEAR

NO. 1 CHAIN TENSIONER
ASSEMBLY

NO. 1 CHAIN VIBRATION
DAMPER

NO. 2 CHAIN VIBRATION
DAMPER

N*m (kgf*cm, ft*lbf)  : Specified torque

Non-reusable part

O-RING

KEY

10 (102, 7.4)

NO. 1 IDLE GEAR SHAFT

NO. 2 IDLE GEAR SHAFT

60 (612, 44)

19 (194, 14)

A126343E01
