ET-8

ENTERTAINMENT

REAR SPEAKER

7. Rear Speaker

A: REMOVAL

1) Disconnect ground cable from battery.
2) Remove rear door trim. <Ref. to EI-31, REMOV-
AL, Rear Door Trim.>
3) Remove rear speaker mounting screws.

4) Disconnect harness connector and remove rear
speaker.

B: INSTALLATION

Install in the reverse order of removal.

ET-00024

ET-9

ENTERTAINMENT

WOOFER

8. Woofer

A: REMOVAL

1) Disconnect ground cable from battery.
2) Remove rear shelf trim. <Ref. to EI-45, Remov-
al, Rear Shelf Trim.>
3) Remove woofer mounting screws.
4) Disconnect harness connector, and then re-
move woofer.

B: INSTALLATION

Install in the reverse order of removal.

ET-10

ENTERTAINMENT

SPEAKER AMPLIFIER

9. Speaker Amplifier

A: REMOVAL

1) Disconnect ground cable from battery.
2) Remove passenger's seat. <Ref. to SE-7, RE-
MOVAL, Front Seat.>
3) Disconnect harness connector.
4) Remove mounting nuts, and then detach speak-
er amplifier.

B: INSTALLATION

Install in the reverse order of removal.

ET-00029

ET-11

ENTERTAINMENT

ANTENNA

10.Antenna

A: INSPECTION

Measure resistance between antenna terminal and
each antenna wire.
If an antenna wire is OK, resistance will be less
than 1

Ω

. If an antenna wire is broken, resistance

will be more than 1 M

Ω

.

NOTE:
When checking continuity, wind a piece of tin foil
around the tip of the tester probe (A) and press the
foil (B) against the wire (C) with your finger.

To locate the broken point, move the probe along
the antenna wire.

B: REPAIR

1) Clean antenna wire and the surrounding area
with a cloth dampened by alcohol.
2) Paste a thin masking film (B) on glass along the
broken wire.
3) Deposit conductive silver composition (C) (DU-
PONT NO. 4817) on the broken portion (A) with a
drawing pen.

4) Dry out the deposited portion.
5) After repair has been completed, measure resis-
tance in the repaired wire.

ET-00007

(B)

(C)

(A)

ET-00008

(B)

(C)

ET-00009

(A)
