LI-34

LIGHTING SYSTEM

TRUNK ROOM LIGHT

30.Trunk Room Light

A: REMOVAL

1) Disconnect ground cable from battery.
2) Disconnect harness connectors and remove
trunk room light.

B: INSTALLATION

Install in the reverse order of removal.

C: INSPECTION

1) Visually check the bulb for blow out.
2) Check the bulb specification. <Ref. to LI-2,
SPECIFICATIONS, General Description.>
3) If NG, replace the bulb with a new one.

LI-00110

LI-35

LIGHTING SYSTEM

GLOVE BOX LIGHT

31.Glove Box Light

A: REMOVAL

1) Disconnect ground cable from battery.
2) Remove glove box. <Ref. to EI-32, REMOVAL,
Glove Box.>
3) Disconnect harness connector.
4) Remove glove box light.

B: INSTALLATION

Install in the reverse order of removal.

C: INSPECTION

1) Visually check the bulb for blow out.
2) Check the bulb specification. <Ref. to LI-2,
SPECIFICATIONS, General Description.>
3) If NG, replace the bulb with a new one.

LI-00111

LI-36

LIGHTING SYSTEM

DOOR STEP LIGHT

32.Door Step Light

A: REMOVAL

Remove the lens then detach the bulb.

B: INSTALLATION

Install in the reverse order of removal.

C: INSPECTION

1) Visually check the bulb for blow out.
2) Check the bulb specification. <Ref. to LI-2,
SPECIFICATIONS, General Description.>
3) If NG, replace the bulb with a new one.

LI-00012
