CL-7

CLUTCH SYSTEM

General Description

2. CLUTCH PIPE AND HOSE

• 5MT LHD model

(1)

Master cylinder ASSY

(7)

Operating cylinder

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Clutch pipe

(8)

Clip

T1: 8 (0.8, 5.8)

(3)

Clamp

T2: 15 (1.5, 10.8)

(4)

Bracket

T3: 18 (1.8, 13.0)

(5)

Clutch hose

T4: 37 (3.8, 27.5)

(6)

Washer

T5: 25 (2.5, 18.4)

CL-00288

(1)

(2)

(3)

(8)

(4)

(5)

(6)

(7)

T1

T4

T5

T2

T3

T3

CL-8

CLUTCH SYSTEM

General Description

• 5MT RHD model

(1)

Operating cylinder

(7)

Clevis pin

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Washer

(8)

Snap pin

T1: 8 (0.8, 5.8)

(3)

Clutch hose

(9)

Pedal

T2: 15 (1.5, 10.8)

(4)

Clamp

(10)

Clip

T3: 18 (1.8, 13.0)

(5)

Clutch pipe

(11)

Bracket

T4: 25 (2.5, 18.4)

(6)

Master cylinder ASSY

T5: 37 (3.8, 27.5)

CL-00289

(8)

(6)

(5)

(10)

(11)

(4)

(9)

(1)

(2)

(3)

(7)

T3

T3

T2

T2

T1

T5

T4

CL-9

CLUTCH SYSTEM

General Description

• 6MT LHD model

(1)

Master cylinder ASSY

(6)

Washer

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Clutch pipe

(7)

Operating cylinder

T1: 15 (1.5, 10.8)

(3)

Clamp

(8)

Clevis pin

T2: 18 (1.8, 13.0)

(4)

Bracket

(9)

Snap pin

T3: 25 (2.5, 18.4)

(5)

Clutch hose

(10)

Pedal

T4: 41 (4.2, 30.2)

T1

CL-00397

(1)

(2)

(3)

(4)

(5)

(6)

(7)

T3

T2

T2

T4

(9)

(10)

(8)

S504.fm  9 ページ  ２００７年１２月３日　月曜日　午後１時４３分

CL-10

CLUTCH SYSTEM

General Description

• 6MT RHD model

(1)

Operating cylinder

(7)

Clevis pin

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Washer

(8)

Snap pin

T1: 15 (1.5, 10.8)

(3)

Clutch hose

(9)

Pedal

T2: 18 (1.8, 13.0)

(4)

Clamp

(10)

Clip

T3: 25 (2.5, 18.4)

(5)

Clutch pipe

(11)

Bracket

T4: 41 (4.2, 30.2)

(6)

Master cylinder ASSY

CL-00398

(8)

(6)

(5)

(10)

(11)

(4)

(9)

(7)

T2

T1

T1

T3

(3)

(2)

(1)

T2

T4
