Subaru Legacy (2005 year). Manual - part 696

CL-3

CLUTCH SYSTEM

General Description

B: COMPONENT

1. CLUTCH ASSEMBLY

• 5MT EC, EK and KA model (Non-turbo model)

(1)

Dust cover

(6)

Release bearing

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Lever spring

(7)

Clutch cover

T1: 16 (1.6, 11.8)

(3)

Pivot

(8)

Clutch disc

T2: 72 (7.3, 52.8)

(4)

Release lever

(9)

Dual mass flywheel

(5)

Clip

CL-00286

(1)

(2)

(4)

(3)

(5)

(5)

(6)

(7)

(8)

(9)

T1

T1

T2

CL-4

CLUTCH SYSTEM

General Description

• 5MT KS and K4 model (Non-turbo model)

(1)

Dust cover

(6)

Release bearing

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Lever spring

(7)

Clutch cover

T1: 16 (1.6, 11.8)

(3)

Pivot

(8)

Clutch disc

T2: 72 (7.3, 52.8)

(4)

Release lever

(9)

Flexible flywheel

(5)

Clip

CL-00401

T2

(9)

(8)

(7)

T1

(5)

T1

(3)

(2)

(1)

(4)

(5)

(6)

CL-5

CLUTCH SYSTEM

General Description

• 5MT Turbo model

(1)

Dust cover

(5)

Release bearing

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Lever spring

(6)

Clutch cover

T1: 16 (1.6, 11.8)

(3)

Pivot

(7)

Clutch disc

T2: 72 (7.3, 52.8)

(4)

Release lever

(8)

Dual mass flywheel

CL-00293

(1)

(2)

(4)

(3)

(5)

T1

(6)

(7)

(8)

T1

T2

CL-6

CLUTCH SYSTEM

General Description

• 6MT model

(1)

Dust cover

(5)

Release bearing

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Release lever

(6)

Clutch cover

T1: 16 (1.6, 11.8)

(3)

Release shaft

(7)

Clutch disc

T2: 44 (4.5, 32.5)

(4)

Plug

(8)

Flywheel

T3: 81 (8.2, 59.4)

CL-00302

(1)

(2)

(5)

(3)

(4)

(6)

(7)

(8)

T1

T3

T2
