LAN(diag)-23

LAN SYSTEM (DIAGNOSTICS)

Subaru Select Monitor

10.FUNCTION CHECK

In order to check the body integrated module func-
tion, inspect the body integrated module and actu-
ator using Subaru Select Monitor without operating
switches.
1) On the “Main Menu” display screen, select the
{Each System Check} and press the [YES] key.
2) On the “System Selection Menu” display screen,
select the {Integ. unit mode} and press the [YES]
key.
3) On the “Integ. unit mode failure diag” display
screen, select the {System Operation Check Mode}
and press the [YES] key.
4) Select the item to be operated on the “System
Operation Check Mode” display screen with “UP/
Down key”, and press the [YES] key.

5) Pressing [YES] starts, [NO] cancels the opera-
tion and [YES] returns to the System Operation
Check Mode display screen.

NOTE:
If not equipped (based on area or condition), pro-
cess will not go on.

LAN00018

Function check

Heater cock valve output
lock actuat, LOCK output
All seat UNLOCK, output
Double lock Solenoid
Shift Lock Solenoid
key locking output
Horn output

LAN(diag)-24

LAN SYSTEM (DIAGNOSTICS)

Read Diagnostic Trouble Code (DTC)

7. Read Diagnostic Trouble

Code (DTC)

A: OPERATION

1. WITHOUT SUBARU SELECT MONITOR

NOTE:
Use the Subaru Select Monitor, because DTCs can
not be read out.

2. WITH SUBARU SELECT MONITOR

For details concerning DTC reading procedure, re-
fer to “Subaru Select Monitor”. <Ref. to LAN(diag)-
14, READ DIAGNOSTIC TROUBLE CODE (DTC),
OPERATION, Subaru Select Monitor.>

LAN(diag)-25

LAN SYSTEM (DIAGNOSTICS)

Clear Memory Mode

8. Clear Memory Mode

A: OPERATION

1. WITHOUT SUBARU SELECT MONITOR

NOTE:
Use the Subaru Select Monitor for Clear Memory
Mode.

2. WITH SUBARU SELECT MONITOR

For details concerning DTC clear operation, refer to
the “Subaru Select Monitor”. <Ref. to LAN(diag)-
20, CLEAR MEMORY MODE, OPERATION, Sub-
aru Select Monitor.>

LAN(diag)-26

LAN SYSTEM (DIAGNOSTICS)

Read Current Data

9. Read Current Data

A: OPERATION

1) On the “Main Menu” display screen, select the
{Each System Check} and press the [YES] key.
2) On the “System Selection Menu” display screen,
select the {Integ. unit mode} and press the [YES]
key.
3) On the “Integ. unit mode failure diag” display
screen, select the {Current Data Display & Save}
and press the [YES] key.
4) On the “Data Display Menu” screen, select the
{12 Data Display} and press the [YES] key.
5) Using the scroll key, scroll the display screen up
or down until the desired data is shown.
<Ref. to LAN(diag)-15, DISPLAY OF ANALOG DA-
TA, OPERATION, Subaru Select Monitor.> <Ref.
to LAN(diag)-16, DISPLAY OF ON/OFF DATA,
OPERATION, Subaru Select Monitor.> <Ref. to
LAN(diag)-17, CONFIRMATION OF CURRENT
SETTING, OPERATION, Subaru Select Monitor.>
