LAN(diag)-19

LAN SYSTEM (DIAGNOSTICS)

Subaru Select Monitor

6) Change the setting with UP/DOWN key and press the [YES] key.
• List of body integrated module registration item

NOTE:
Setting is different depending on grade of vehicle.

CAUTION:
• It is possible to control the original functions of vehicle when registrations of body integrated mod-
ule and function setting are corresponded to vehicle equipment.
• When body integrated module is new one or “Factory” mode, key illumination blinks to show
equipment settings does not completed.
• Be sure not to change Factory initial setting except installation of new body integrated module.

NOTE:
“Factory” mode:
• Body integrated module has not been set yet. It can be recognized by key illumination blinking with ignition
switch turned to ON.
• All body integrated modules as part for repair are set to “Factory” mode. When replacing a body integrated
module, be sure to perform the registration operation.
“Market” mode:
• Each settings of body integrated module have been set. It can be recognized by key ring illumination op-
erating simultaneously with room light and turning off with ignition switch turned to ON.

Data

Initial set-

ting

Registration

Remarks

A/C ECM setting

OFF

ON

Illumination control does not operate if A/C ECM setting
is set to “OFF” in case of model with auto A/C.

OFF

If A/C ECM setting is set to “ON” in case of model with-
out auto A/C, illumination change to night illumination
and it is difficult to be recognized.

P/W ECM setting

OFF

ON

Be sure to set P/W ECM setting to “OFF”.

OFF

Center display failure (OP)

OFF

ON

Information may not be displayed on center display if
Center display failure is set to “OFF” in case of model
with center display.

OFF

Wiperdeicer (OP)

OFF

ON

ON signal does not output with operation of wiper
deicer switch if Wiperdeicer is set to “OFF” in model
with wiper deicer.

OFF

Rear fog light setting (OP)

OFF

ON

Vehicle is controlled in rear fog light equipped mode.

OFF

Vehicle is controlled in rear fog light no-equipped mode.
(Be sure to set to “OFF” in model without rear fog light.)

Factory initial setting (Reset of body
integrated module)

Factory

Factory (Reset)

If Factory initial setting is set to “Factory”, registrations
of items above is changed to “OFF”. Be sure to set to
“Market”.

Market (Settle-

ment)

LAN(diag)-20

LAN SYSTEM (DIAGNOSTICS)

Subaru Select Monitor

7) Perform the Factory setting. On the “ECM cus-
tomizing” display screen of Subaru Select Monitor,
select the {Factory initial setting} and press the
[YES] key.
8) Change the mode from Factory into Market.
9) Replace the immobilizer cartridge, and register
the immobilizer key. (Model with immobilizer)
10) Perform the registration according to the proce-
dures of “IMMOBILIZER TEACHING OPERATION
MANUAL”.
11) When key registration is completed, “Do you
want to register remote engine start?” is displayed.
Press the [NO] key to finish the registration.
12) Perform the function setting (ECM customiz-
ing).
<Ref. to LAN(diag)-21, FUNCTION SETTING
(ECM CUSTOMIZING), OPERATION, Subaru Se-
lect Monitor.>

NOTE:
For details concerning operation procedure, refer
to the SUBARU SELECT MONITOR OPERATION
MANUAL.

7. CLEAR MEMORY MODE

1) On the “Main Menu” display screen, select the
{2. Each System Check} and press the [YES] key.
2) On the “System Selection Menu” display screen,
select the {Integ. unit mode} and press the [YES]
key.
3) Press the [YES] key after the information of body
integrated module type is displayed.
4) On the “Integ. unit mode failure diag” display
screen, select the {Clear Memory} and press the
[YES] key.

5) When the “Done” are shown on the display
screen, turn the ignition switch to OFF.

NOTE:
For details concerning operation procedure, refer
to the SUBARU SELECT MONITOR OPERATION
MANUAL.

8. FREEZE FRAME DATA

NOTE:
• Data stored at the time of trouble occurrence is
shown on display.
• Freeze frame data will be memorized maximum
to 20.
• If freeze frame data is not stored in memory cor-
rectly (caused by low power supply of body inte-
grated module), DTC will be displayed with “?” on
the head of it in the Subaru Select Monitor display.
This shows it may be an unreliable reading.

Display

Contents to be monitored

Clear memory?

Clear function of DTC and
freeze frame data

LAN(diag)-21

LAN SYSTEM (DIAGNOSTICS)

Subaru Select Monitor

9. FUNCTION SETTING (ECM CUSTOMIZING)

1) On the “Main Menu” display screen, select the {Each System Check} and press the [YES] key.
2) On the “System Selection Menu” display screen, select the {Integ. unit mode} and press the [YES] key.
3) On the “Integ. unit mode failure diag” display screen, select the {ECM customizing} and press the [YES]
key.
4) Change the setting with UP/DOWN key and press the [YES] key.
• List of function setting item (ECM customizing)

No.

Data

Initial

setting

value

Customize setting

Remarks

1

Off delay time

Normal

Delay time below can be selected by setting.

After door closed

After key unlock

OFF

0 sec.

0 sec.

Short

3 sec.

10 sec.

Normal

5 sec.

20 sec.

Long

8 sec.

30 sec.

2

Auto lock time

30 sec.

0 — 60 seconds

Workable when Auto locking is set to “ON” and Automatic
locking setup is “ON”. Time can be changed by 10 seconds:
0 (OFF) — 60 (maximum).

3

Rr defogger op. mode

15 min.

15 min.

Rear defogger stops in 15 minutes automatically after
switch is turned to ON.

Continuous

Rear defogger repeats active condition for 15 minutes and
inactive condition for 2 minutes until switch is turned to OFF.

4

Wiper deicer op. mode

15 min.

15 min.

Rear defogger stops in 15 minutes automatically after
switch is turned to ON.

Continuous

Rear defogger repeats active condition for 15 minutes and
inactive condition for 2 minutes until switch is turned to OFF.

5

Security Alarm Setup

OFF

ON

Security alarm (hazard, horn or siren) in active condition

OFF

Security alarm in inactive condition

6

Impact Sensor Setup

OFF

ON

Workable when Impact Sensor Setup is set to “ON” Impact
sensor in active condition

OFF

Impact sensor in inactive condition (Set Impact Sensor
Setup of model without impact sensor to “OFF”.)

7

Alarm monitor delay setting

ON

After doors are locked by keyless entry system operated,
Alarm monitor starts in following time.

ON

Delay time is 30 seconds.

OFF

Delay time is 0 seconds.

8

Lockout prevention

ON

ON

Lockout prevention in inactive condition (Lockout prevention
does not operate if safety knob is locked by hand.)

OFF

Lockout prevention in inactive condition

9

Impact sensor (OP)

OFF

ON

Vehicle is controlled in impact sensor equipped mode. (Set
impact sensor to “OFF” in model without impact sensor. If
impact sensor is set to “ON”, hazard, horn or siren operate
after doors are locked by keyless entry system operated
(Alarm monitor starting).)

OFF

Vehicle is controlled in impact sensor no-equipped mode.

10

Siren setting (OP)

OFF

ON

Siren sounds when alarm operates. (Set siren setting to
“OFF” in model without siren. Horn does not sound if siren
setting is set to “ON”.)

OFF

Horn sounds when alarm operates.

11

Answer-back buzzer setup

ON

ON

Workable when answer-back buzzer setup is set to “ON”.
When lock/unlock is selected by keyless entry system oper-
ated, answer-back buzzer sounds.

OFF

When lock/unlock is selected by keyless entry system oper-
ated, answer-back buzzer does not sound.

LAN(diag)-22

LAN SYSTEM (DIAGNOSTICS)

Subaru Select Monitor

5) After setting, make sure that vehicle equipment is same as the setting changed in the {Current Data Dis-
play & Save}.

CAUTION:
• It is possible to control the original functions of vehicle when settings above are corresponded to
vehicle equipment.
• Do not change the settings except for setting above during operation of equipment setting.
• Be sure not to change Factory initial setting except installation of new body integrated module.

NOTE:
For details concerning operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MAN-
UAL.

12

Hazard answer-back setup

ON

ON

Workable when hazard answer-back setup is set to “ON”.
When lock/unlock is selected by keyless entry system oper-
ated, hazard answer-back buzzer operates.

OFF

When lock/unlock is selected by keyless entry system oper-
ated, hazard answer-back does not operate.

13

Automatic locking setup

ON

ON

Workable when Automatic locking setup is set to “ON”.
Automatic locking operates.

OFF

Automatic locking does not operate.

14

Ans.-back Buzzer

ON

ON

Vehicle is controlled in answer-back buzzer equipped
mode.

OFF

Vehicle is controlled in answer-back buzzer non-equipped
mode. (Set Ans.-back Buzzer to “OFF” in model without
answer back buzzer.)

15

Auto locking

ON

ON

Vehicle is controlled in auto locking equipped mode.

OFF

Vehicle is controlled in auto locking non-equipped mode.
(Set Auto locking to “OFF” in model without auto locking.)

16

Initial Keyless Setting

—

—

—

Execution

Settings of keyless entry system are initialized. (No. 2: 30
sec., No. 11: ON, No. 12: ON, No. 13: ON, No. 14: ON)

17

Initial button setting

—

—

—

Execution

Settings of each function are initialized. (No. 1: Normal, No.
3: 15 min., No. 4: 15 min., No. 8: ON)

18

Initial Security setting

—

—

—

Execution

Settings of security system are initialized. (No. 5: OFF, No.
6: OFF, No. 7: ON, No. 10: OFF)

19

Passive Alarm (Not used)

OFF

ON

Applicable to North America model (If Passive Alarm is set
to “ON”, nothing operates and there is no negative effect.)

OFF

20

Door open warning (preven-
tion of battery run-out)

OFF

ON

If detecting door open for 30 minutes, room light, key illumi-
nation and door warning light are turned off to prevent bat-
tery run-out.

OFF

Room light, key illumination and door warning light is not
turned off.

21

(Specification) Security
setup

ON

Operate the selected security set. (EK model)

OFF

Normally in active condition

No.

Data

Initial

setting

value

Customize setting

Remarks
