Subaru Legacy (2005 year). Manual - part 1034
LAN(diag)-15
LAN SYSTEM (DIAGNOSTICS)
Subaru Select Monitor
2. READ CURRENT DATA
1) On the “Main Menu” display screen, select the {Each System Check} and press the [YES] key.
2) On the “System Selection Menu” display screen, select the {Integ. unit mode} and press the [YES] key.
3) On the “Integ. unit mode failure diag” display screen, select the {Current Data Display & Save} and press
the [YES] key.
4) On the “Current Data Display & Save” display screen, select the {12 Data Display} and press the [YES]
key.
5) Using the scroll key, scroll the display screen up or down until the desired data is shown.
• A support list contains both of analog and digital data, and they are shown in the following table.
3. DISPLAY OF ANALOG DATA
Items to be displayed
Unit of measure
NOTE
BATT Voltage (Control)
10 — 15 V
—
BATT Voltage (BACK UP)
10 — 15 V
—
IG power supply voltage
10 — 15 V
—
ACC voltage
10 — 15 V
—
Illumination VR voltage
0 — 5 V
—
Illumi. output d-ratio
0 — 100%
—
ambient temp sensor V
0 — 5 V
—
Ambient temperature
−40 — 87.5°C
—
Fuel level voltage
0 — 8 V
—
Fuel level resistance
0 — 102.3
Ω
CAN communication input value
key-lock solenoid V
6 — 12 V
—
number of regist.
0 — 4
—
Front Wheel Speed
km/h
—
VDC/ABS latest f-code
DTC display
It is normal when DTC is not been input
even if this code is displayed.
Blower fan levels
0 — 2 levels
0: OFF, 1: Low, 2: 2 levels or more
Fuel level resistance2
0 — 102.3
Ω
Output value for OBD diagnosis
Fuel consumption
cc/s
—
Coolant Temp.
−40 — 130°C
—
Vehicle lateral G
m/s
2
—
SPORT Shift Stages
0 — 7 levels
(0: light OFF, 6: fail, 7: ATF temperature
High/Low)
Shift Position
0 — 7 levels
(8 is no input)
Off delay time
OFF, Short, Normal, Long
—
Auto lock time
20, 30, 40, 50, 60 seconds
—
