EB-9

EXTERIOR BODY PANELS

General Description

4. REAR DOOR PANEL

(1)

Rear door panel

(6)

Lower hinge

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Sealing cover

(7)

Door trim bracket upper

T1: 7.4 (0.75, 5.5)

(3)

Rear door weather strip

(8)

Door trim bracket lower

T2: 24.5 (2.5, 18.1)

(4)

Checker

T3: 29.4 (3.0, 21.7)

(5)

Upper hinge

T4: 32.3 (3.3, 23.8)

EB-00150

T1

T3

T2

(5)

(1)

T3

T2

(6)

T4

(4)

(7)

(8)

(2)

(3)

EB-10

EXTERIOR BODY PANELS

General Description

5. TRUNK LID PANEL

(1)

Trunk lid panel

(5)

Trunk lid trim

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

License plate light cover

(6)

Trunk lid arm cover

T1: 17.6 (1.8, 12.9)

(3)

Trunk lid garnish

(7)

Trunk lid arm ASSY

T2: 14 (1.43, 10.3)

(4)

Trunk lid lock ASSY

(8)

Torsion bar

EB-00161

(8)

(7)

(1)

(2)

(6)

(4)

(5)

T1

T2

(3)

EB-11

EXTERIOR BODY PANELS

General Description

6. REAR GATE PANEL

C: CAUTION

• Exterior body panels are heavy. Do not drop and
damage the panels. During removal and installa-
tion, do not damage the panel painting surface.
• While removing mounting bolts, using assistance
devices such as a support jack will help to support
the panel.
• Be careful not to lose small parts.

(1)

Rear gate damper stay

(3)

Rear gate panel

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Hinge

(4)

Rear gate side panel cover

T1: 7.5 (0.77, 5.53)

T2: 14.0 (1.43, 10.3)

T3: 25.0 (2.6, 18.4)

EB-00182

(3)

T3

T3

T1

T2

(2)

(1)

(4)

EB-12

EXTERIOR BODY PANELS

General Description

D: PREPARATION TOOL

1. SPECIAL TOOL

2. GENERAL TOOL

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

925610000

WRENCH

Used for removing and installing door hinge.

927780000

REMOVER

Used for removing and installing trunk torsion
bar.

TOOL NAME

REMARKS

Support jack

Used for supporting door panel.

Clip remover

Used for removing various types of clips.

ST-925610000

ST-927780000
