Scania Truck (2017 year). Spare parts and accessories - 8

114 |

2

4 ser

ies

Leaf spring

Installation location Rear axle

Form

8

Number of leaves

10

Axle load

26,3 t

Width

90 mm

Length at front/rear 795 mm

Length at rear

795 mm

Thickness

250 mm

Camber

70 mm

Suitable for

Order no

Comparative no

144

8000 005 549

Scania 1398987

Spring bushing

Suitable for

Length

Outer ∅

Inner thread

Order no

Comparative no

164, 144, 124, 114, 94

89 mm

36 mm

M28 x 4

1539 000 500

Scania 0128680

164, 144, 124, 114, 94

89 mm

46 mm

M36 x 4

1599 000 400

Scania 0135036

164, 144, 124, 114, 94

103 mm

46 mm

M36 x 4

1539 000 400

Scania 0135698

164, 144, 124, 114, 94

121,5 mm

65 mm

1246 845 010

Scania 255669

This figure corresponds to 1539 000 500

Suspension and damping

Spring hoop

Suitable for

Length

Thread

Thread length

Clearance

Order no

164, 144, 124, 114, 94

173 mm

M22 x 2,5

60 mm

93 mm

5831 859 926

164, 144, 124, 114, 94

256 mm

M22 x 2,5

70 mm

93 mm

6170 125 419

164, 144, 124, 114, 94

308 mm

M24

70 mm

105 mm

8000 112 730

| 115

2

 4 ser

ies

 Axles and steering

 Drag-link

Length

1921 mm

Cone-∅ 30 mm

Pipe ∅

60 mm

Suitable for

Order no

Comparative no

124, 114, 94

9072 007 278

TRW JTR4321

 Drag-link

Cone-∅ 30 mm

Suitable for

Length

Pipe ∅

Order no

Comparative no

144, 124, 114

495 mm

40 mm

9070 321 456

Lemförder 21456 01

164, 144, 124, 114, 94

1053 mm

50 mm

9070 900 016

Lemförder 14824 02

  This fi gure corresponds to   9070 900 016

 Drag-link

Cone-∅ 30 mm

Suitable for

Length

Pipe ∅

Order no

Comparative no

144, 124, 114

495 mm

40 mm

9050 001 235

Lemförder 21456 01

164, 144, 124, 114, 94

1059 mm

52 mm

9052 100 902

Lemförder 21009 02

124, 114

1920 mm

60 mm

9050 001 146

Lemförder 23493 01

124, 114

1921 mm

60 mm

9053 665 501

Lemförder 36655 01

  This fi gure corresponds to   9050 001 146

116 |

2

 4 ser

ies

 Ball joint

Installation location Front axle

Installation side

Left/right

Cone-∅

30 mm

Suitable for

Thread type

Order no

Comparative no

164, 144, 124, 114, 94

Left-hand thread

9070 900 123

Lemförder 11492 03

164, 144, 124, 114, 94

Right-hand thread

9070 900 117

Lemförder 11505 03

 Ball joint

Cone-∅

30 mm

Thread type Right-hand thread

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9079 991 567

Lemförder 25353 01

 Ball joint

Cone-∅ 30 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

5233 016 271

Lemförder 27853 01

 Axles and steering

 Ball joint

Cone-∅

30 mm

Thread type Right-hand thread

Suitable for

Thread

Length

Order no

Comparative no

164, 144, 124, 114, 94

M26 x 1,5

95 mm

9070 900 061

Lemförder 19537 01

164, 144, 124, 114, 94

M26 x 1,5

75 mm

9073 377 202

Lemförder 38273 01

164, 144, 124, 114, 94

M30 x 1,5

141 mm

9072 535 301

Lemförder 25353 01

| 117

2

 4 ser

ies

 Ball joint

Cone-∅

26 mm

Thread type Right-hand thread
  Scope  of  supply

 With  accessories

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

1903 003 532

TRW JTE3532

 Ball joint

Cone-∅

30 mm

Inner thread M26 x 1,5
  Scope  of  supply

 With  accessories

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

1903 000 127

TRW JTE0127

 Ball joint

Installation location At steering cylinder

Cone-∅

30 mm

Inner thread

M26 x 1,5

Thread type

Right-hand thread

  Scope  of  supply

 With  accessories

Suitable for

Length

Order no

Comparative no

164, 144, 124, 114, 94

75 mm

9073 377 201

Lemförder 38273 01

164, 144, 124, 114, 94

90 mm

9073 377 101

Lemförder 38272 01

  This fi gure corresponds to   9073 377 201

 Axles and steering

 Ball joint

Length

120 mm

Cone-∅

30 mm

Outer thread M30 x 1,5

Suitable for

Thread type

Order no

Comparative no

164, 144, 124, 114, 94

Left-hand thread

9073 305 101

Lemförder 11492 03

164, 144, 124, 114, 94

Rght-hand thread

9073 305 201

Lemförder 11505 03

118 |

2

 4 ser

ies

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9070 900 010

Lemförder 37247 01

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9073 603 065

TRW JTR4144

 (Illustration  similar)

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9072 028 998

TRW JTR4402

 Trailing arm

Bore hole ∅

19/19 mm

Distance between holes 115/115 mm

Bearing version

Molecular bearing

Suitable for

Length

Order no

Comparative no

164, 144, 124, 114, 94

568 mm

9050 029 384

Lemförder 29384 01

164, 144, 124, 114, 94

568 mm

9052 758 102

Lemförder 27581 02

124, 114

606 mm

9053 074 701

Lemförder 30747 01

 Angle joint

Installation side At steering cylinder

Length

75 mm

Cone

26 mm

Thread type

Right-hand thread

Inner thread

M26 x 1,5

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9053 748 301

Lemförder 37483 01

 Axles and steering

www.trwaftermarket.com/en/hcv

As part of ZF Aftermarket, every TRW part is built to meet the challenge, just like the
dedicated people around the world who bring them to you. Backed by a global network
of aftermarket experts TRW products set the standards for safety and quality.

This is Erik Larsson.

He delivers supplies to towns in the
Arctic Circle. They rely on him and
he relies on TRW Proequip. That’s
because TRW make a full range of
parts for HCV that off er excellent
safety performance, from pads with
the perfect material mix for HCVs,
to discs that match OE standards, to
XCAP ball joints that beat six major
competitors in durability tests.

TRW Proequip Made by True
Originals. For True Originals.

Watch Erik’s story at
www.trwaftermarket.com/en/hcv

120 |

2

4 ser

ies

Stabilizer mounting

Suitable for

Installation location

Length

Outer ∅

Inner ∅

Order no

Comparative no

164, 144, 124, 114, 94

Front axle/rear axle

50 mm

46,5 mm

16 mm

6171 516 496

Scania 1516496

164, 144, 124, 114, 94

Front axle/rear axle

100 mm

71 mm

50 mm

9290 002 220

Scania 228483

164, 144, 124, 114, 94

Front axle/rear axle

104 mm

95 mm

65 mm

9800 127 054

Scania 1344190

164, 144, 124, 114, 94

Front axle

119 mm

56 mm

40 mm

9290 002 240

Scania 213604

This figure corresponds to 9290 002 240

Bearing bush

Installation location Rear axle

Installation side

Left/right

Length

96,5 mm

Outer ∅

105 mm

Inner ∅

50 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9290 002 145

Scania 295751

Shaft sealing ring

Installation location Rear axle

Installation side

Left/right

Suitable for

Outer ∅

Inner ∅

Thickness

Order no

Comparative no

164, 144, 124, 114, 94

100 mm

75 mm

14 mm

8000 117 203

Scania 2057586

164, 144, 124, 114, 94

170 mm

142 mm

16 mm

8000 012 634

Scania 1740992

164, 144, 124, 114, 94

188 mm

158 mm

16 mm

8022 502 436

Scania 1907845

This figure corresponds to 8022 502 436

Wheel hub sealing ring

Suitable for

Inner ∅

Thickness

Order no

164, 144, 124, 114, 94

129,5 mm

3 mm

1325 117 074

164, 144, 124, 114, 94

162 mm

6 mm

1325 017 093

This figure corresponds to 1325 117 074

Axles and steering

| 121

2

 4 ser

ies

 Wheel bolt

Suitable for

Thread

Length

Order no

Comparative no

124, 114, 94

7/8" 11BSF

80,5 mm

2219 001 430

Scania 1368690

164, 144, 124, 114, 94

7/8" 11BSF

81/92 mm

8000 011 455

Scania 1368692

164, 144, 124, 114, 94

7/8" 11BSF

85/96 mm

2219 001 410

Scania 1368693

164, 144, 124, 114, 94

7/8" 11BSF

111 mm

2219 001 420

Scania 1368694

  This fi gure corresponds to   2219 001 430

 Wheel bolt

Length

82 mm

Bolt length

72 mm

Thread length 47 mm

Head ∅

37 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

5832 285 275

Scania 2285275

 ABS ring

Suitable for

Outer ∅

Inner ∅

Thickness

Order no

Comparative no

124, 114, 94

164 mm

126 mm

8,5 mm

5830 041 012

Scania 1375382

164, 144, 124, 114, 94

170 mm

126 mm

9 mm

8000 117 165

Scania 1442300

164, 144, 124, 114, 94

188,5 mm

172,5 mm

20 mm

6030 442 296

Scania 1442296

  This fi gure corresponds to   5830 041 012

 Axles and steering

 Wheel nut

Thread

7/8" 11BSF

Spanner size 33 mm

Height

26 mm

Surface

phosphated

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

2219 001 100

Scania 2285273

 Wheel hub

 without bearing

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

5832 290 532

Scania 2290532

122 |

2

 4 ser

ies

 Wheel bearing set

Outer ∅ 127 mm

Inner ∅

68 mm

Width

115 mm

  Scope  of  supply

 Compact bearing and sealing ring

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8001 531 400

SKF VKBA 5314

 Axles and steering

 O-ring

Thickness 3 mm

Suitable for

Inner ∅

Order no

Comparative no

164, 124, 114, 94

84 mm

5831 503 399

Scania 1503399

164, 124, 114, 94

225 mm

0132 511 208

Scania 1120873

  This fi gure corresponds to   5831 503 399

 Wheel bearing set

 SmartSET

Version pre-assembled, with permanent lubrication
  Scope  of  supply

 With  mounting  tool

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

6957 237 009

FAG 723 7009 10

164, 144, 124, 114, 94

6957 237 014

FAG 723 7014 10

Axles and steering

Quality comes first.

Always.

This is why leading truck manufacturers like Iveco,

MAN, Mercedes-Benz, Renault, Scania and Volvo

put their trust in us. And that’s also why many fleet

managers, mechanics and drivers worldwide think

of us first for aftermarket products. Thank you for

over 100 years of trust.

For trouble-free years on the road.

124 |

2

 4 ser

ies

 Stabilizer mounting

Outer ∅ 57 mm

Inner ∅

20 mm

Length

30 mm

Suitable for

Order no

Comparative no

144, 124, 114, 94

9290 002 230

Scania 310808

 Repair kit

 for stabiliser

Outer ∅ 57 mm

Inner ∅

20 mm

Length

30 mm

Suitable for

Order no

Comparative no

144, 124, 114, 94

5832 156 626

Scania 2156626

 Axles and steering

 Tapered roller bearing

Height

40 mm

Outer ∅ 147 mm

Inner ∅

90 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8012 102 482

Scania 1524625

 (Illustration  similar)

 Tapered roller bearing

Height

40 mm

Outer ∅ 147 mm

Inner ∅

90 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8022 102 482

SKF VKHB 2029

Axles and steering

Customer satisfaction is our top priority. That's why
you can expect not only high-quality products
from EUROPART, but also a friendly and expert
service team who are ready to help you by phone.
Contact our qualified EUROPART technicians
who will not only give you expert advice but will
also assist you with your questions and problems,
providing technical support as well as a reliable
fault diagnosis service.

We will also be happy to provide you with free
remote  maintenance using a secure remote
connection. Whether your components are made
by Haldex, Knorr or WABCO – contact us directly
to make use of our expertise.

Urgent questions?

Direct assistance.

Telephone support: EUROPART technicians are ready to help you

EUROPART – Europe's No. 1 for truck, trailer, van and bus spare parts.

126 |

2

 4 ser

ies

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 37 mm

Outer ∅

430 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

2090 430 001

Scania 1852817

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 37 mm

Outer ∅

430 mm

 Width of cooling channel 12 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3400 810 000

Knorr K000810

 Braking system

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 37 mm

Outer ∅

430 mm

Suitable for

Order no

164, 144, 124, 114, 94

1068 017 000

 Brake caliper

Suitable for

Type

Order no

Comparative no

164, 144, 124, 114, 94

SB7202RC

3400 047 081

Knorr K040946K50

164, 144, 124, 114, 94

SB7212RC

3400 047 080

Knorr K040945K50

164, 124, 114, 94

SN7203RC

3450 414 766

Knorr K003803

164, 124, 114, 94

SN7213RC

3450 414 767

Knorr K003804

164, 144, 124, 114, 94

SN7264RC

3450 414 776

Knorr K040953K50

164, 144, 124, 114, 94

SN7274RC

3450 414 777

Knorr K040954K50

  This fi gure corresponds to   3450 414 776

| 127

2

 4 ser

ies

 Brake pad set

Installation location Front axle/rear axle

Brake system

SB/SN 7

WVA no.

29108

Coating length

247,5 mm

Lining width

109,5 mm

Lining thickness

30,00 mm

  Scope  of  supply

 With  accessories
 Splined socket for resetter is not included with pad set. If required, please order 3566180782.

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

2323 405 206

Scania 1390428

 Braking system

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 40 mm

Outer ∅

430 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

7980 005 025

Meritor MBR5025

 Brake drum

Inner ∅

413 mm

Hole circle ∅

335 mm

Hub ∅

295 mm

Number of holes 10

Suitable for

Installation location

Height

Order no

Comparative no

164, 144, 124, 114, 94

Front/rear axle

275,5 mm

2090 413 033

Scania 1414153

164, 144, 124, 114, 94

Rear axle

320 mm

2090 413 014

Scania 360573

  This fi gure corresponds to   2090 413 014

128 |

2

 4 ser

ies

 Braking system

Hole circle ∅

335 mm

Number of holes 10

Suitable for

Height

Order no

Comparative no

164, 144, 124, 114, 94

253 mm

2090 413 011

Scania 360567

124

263 mm

2090 413 012

Scania 285894

 Brake drum

  This fi gure corresponds to   2090 413 011

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

164, 144, 124, 114, 94

19931

19,00 mm

178 mm

2119 931 008

Scania 385948

Scania 551123

164, 144, 124, 114, 94

19932

19,00 mm

203 mm

2119 932 008

Scania 1109003

Scania 551124

164, 144, 124, 114, 94

19933

19,10 mm

254 mm

2119 933 008

Scania 1535250

 Brake lining set

Brake drum ∅ 413 mm

  This fi gure corresponds to   2119 932 008

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

164, 144, 124, 114, 94

19931

19,00 mm

178 mm

2119 931 051

Textar 1993104

164, 144, 124, 114, 94

19932

19,00 mm

203 mm

2119 932 051

Textar 1993204

164, 144, 124, 114, 94

19932

20,00 mm

203 mm

2119 932 151

Textar 1993206

164, 144, 124, 114, 94

19932

21,00 mm

203 mm

2119 932 251

Textar 1993208

 Brake lining set

Brake drum ∅ 413 mm

  This fi gure corresponds to   2119 931 051

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

164, 144, 124, 114, 94

19932

19 mm

203 mm

2119 932 503

Bera l 1 9932 190000 15504

164, 144, 124, 114

19932

20 mm

203 mm

2119 932 603

Bera l 1 9932 200000 16374

 Brake lining set

WVA no.

19932

Contents of set 4

 (Illustration  similar)

| 129

2

 4 ser

ies

 Braking system

Suitable for

Form

Installation location

Installation side

Order no

Comparative no

164, 144, 124, 114, 94

left offset, 0 mm

rear axle

left/right

1205 842 250

Scania 1112831

164, 144, 124, 114, 94

left cropped, +25 mm

rear axle

left

1205 842 220

Scania 1112833

164, 144, 124, 114, 94

right offset, -25 mm

rear axle

right

1205 842 260

Scania 1112834

164, 144, 124, 114, 94

left offset, +65 mm

front axle

left

1205 842 740

Scania 1789568

164, 144, 124, 114, 94

right offset, -65 mm

front axle

right

1205 842 735

Scania 1789567

 Slack adjuster

Version automatic

  This fi gure corresponds to   1205 842 250

 Slack adjuster

Version automatic

Suitable for

Form

Distance between holes

Order no

Comparative no

164, 144, 124, 114, 94

left offset +25 mm

3400 726 600

Haldex 72660C

164, 144, 124, 114, 94

right offset, +25 mm

3400 726 610

Haldex 72661C

164, 144, 124, 114, 94

left offset, +65 mm

9990 001 002

Haldex 79443C

164, 144, 124, 114, 94

right offset, -65 mm

9990 001 004

Haldex 79442C

164, 124, 114, 94

left offset, +75 mm

165 mm

3400 728 080

Haldex 79106C

164, 124, 114, 94

left offset -75 mm

165 mm

3400 728 070

Haldex 79105C

  This fi gure corresponds to   9990 001 004
