Scania Truck (2017 year). Spare parts and accessories - 7

98 |

2

 4 ser

ies

 Oil fi lter

Suitable for

Order no

Comparative no

164

9750 103 311

Hengst E21H D74

 Coolant expansion tank

Length 444 mm

Width

233 mm

Depth

279 mm

Suitable for

Order no

Comparative no

114

1100 129 455

HELLA 8MA 376 705-461

 Engine attachment

 Water fi lter

Outer ∅ 94 mm

Thread

1 1/16-16

Height

102,5 mm

Suitable for

Order no

Comparative no

144

9750 104 467

Hengst H34WF

| 99

2

 4 ser

ies

 Fuel fi lter

Suitable for

Filter type

Outer ∅

Height

Order no

Comparative no

144, 124, 114, 94

Screw-on fi lter

93 mm

141 mm

9750 104 272

Hengst H17WK04

124, 114, 94

Screw-on fi lter

93,5 mm

142 mm

9750 104 280

Hengst H17WK11

164, 144, 124, 114, 94

Screw-on fi lter

108 mm

157 mm

9750 104 485

Hengst H7090WK30

124

Filter insert

83 mm

185 mm

9750 103 818

Hengst E68KP01D73

164

Filter insert

85 mm

180,5 mm

9750 103 707

Hengst E57KP D73

  This fi gure corresponds to   9750 104 280

 Air fi lter

Filter type Filter insert

Suitable for

Outer ∅

Height

Order no

Comparative no

124, 114, 94

303 mm

446 mm

3565 420 121

Hengst E1013L

164, 144, 124

303 mm

526 mm

1392 001 033

Hengst E1033L

164, 144

304 mm

543 mm

9750 103 663

Hengst E540L

124, 114, 94

309,5 mm

464 mm

3359 004 240

Hengst E424L

  This fi gure corresponds to   1392 001 033

 Secondary air fi lter

Suitable for

Order no

Comparative no

144, 124, 114, 94

9740 001 720

Scania 1335680

 Engine attachment

100 |

2

 4 ser

ies

 Cabin fi lter

Filter type Pollen fi lter

Length

223 mm

Width

165 mm

Height

69 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9750 104 067

Hengst E956LI01

 Hydraulic fi lter

Filter type Filter insert

Outer ∅

58 mm

Height

100 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9750 103 076

Hengst E10H02

 Attachment screw

 for fl ywheel

Thread

M14

Length

35 mm

Property class 10.9

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3032 012 631

Scania 394591

 Engine attachment

| 101

2

 4 ser

ies

 Silencer

Standard Euro 2/3

Suitable for

Order no

Comparative no

164

8000 012 765

Dinex 68336

 Accessories

Description

Order no

Comparative no

Flexible pipe, length 220 mm

8000 012 763

Dinex 68270

Front pipe, length 360 mm

8700 682 720

Dinex 68272

Rear silencer, ∅ 114,3 mm

8700 687 170

Dinex 68717

Clamping piece, ∅ 146 mm

8790 068 858

Dinex 68858

Exhaust pipe clamp, ∅ 114,3 mm

8790 000 208

Dinex 68835

 to fi t Scania 164 C/G/L, Euro 2/3

Description

Order no

Comparative no

Flexible pipe, length 220 mm

8000 012 763

Dinex 68270

Front pipe, length 360 mm

8700 682 720

Dinex 68272

Intermediate pipe, length 385 mm

8700 687 080

Dinex 68708

Tailpipe, length 210 mm

4260 068 508

Dinex 68508

Tailpipe, length 900 mm

4260 068 767

Dinex 68767

Tailpipe, length 1025 mm

4260 068 768

Dinex 68768

Tailpipe, length 1275 mm

4260 068 701

Dinex 68701

Tailpipe, length 521 mm

4260 068 506

Dinex 68506

Clamping piece, ∅ 146 mm

8790 068 858

Dinex 68858

Exhaust pipe clamp, ∅ 114,3 mm

8790 000 208

Dinex 68835

Clamping piece

8700 688 500

Dinex 68850

Exhaust pipe clamp, ∅ 122-127 mm

8709 992 100

Dinex 99921

Flexible pipe, length 187 mm

8703 068 507

Dinex 68507

 to fi t Scania 164 C/G/L, Euro 3, 05/2000-2004

 Engine attachment

 Central silencer

Standard Euro 2/3

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8790 000 095

Dinex 68327

Description

Order no

Comparative no

Front pipe, inner ∅ 114,3 mm, length 190 mm

8790 000 212

Dinex 68239

Front pipe, length 680 mm

8790 000 202

Dinex 68238

Front pipe, length 650 mm

8790 682 560

Dinex 68256

Front pipe, ∅ 114,3 mm

8790 000 204

Dinex 68241

Intermediate pipe, length 385 mm

8700 687 080

Dinex 68708

Flexible pipe, length 187 mm

8703 068 507

Dinex 68507

Tailpipe, length 675 mm

4260 686 080

Dinex 68608

Tailpipe, length 1025 mm

4260 068 608

Dinex 68607

Tailpipe, length 900 mm

4260 068 767

Dinex 68767

Tailpipe, length 1025 mm

4260 068 768

Dinex 68768

Tailpipe, length 425 mm

4260 068 773

Dinex 68773

Tailpipe, length 1275 mm

4260 068 701

Dinex 68701

Exhaust pipe clamp, ∅ 114,3 mm

8790 000 208

Dinex 68835

Clamping piece

8700 688 500

Dinex 68850

 Accessories
 to fi t Scania 144 C/G/L, 124 C/G/L, 114 C/G/L, 94 C/D/G/L, Euro 2/3, 1996-2004

102 |

2

 4 ser

ies

 Pipe clip

∅ 120 mm

Suitable for

Order no

Comparative no

164, 124, 114, 94

4260 068 898

Dinex 68898

 Flexible pipe

Length 945 mm

Suitable for

Order no

Comparative no

124, 114

4260 068 082

Dinex 68082

 Pipe clip

∅ 102 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

4260 068 899

Dinex 68899

 Engine attachment

 Fuel tank

Volume

Length x width x height

Order no

Comparative no

200 l

505 x 700 x 670 mm

1325 112 561

Scania 1871187

300 l

735 x 700 x 670 mm

8000 871 188

Scania 1871188

350 l

865 x 700 x 670 mm

1325 112 563

Scania 1871189

400 l

1014 x 700 x 670 mm

1325 112 775

Scania 1878319

500 l

1265 x 700 x 670 mm

1325 112 564

Scania 1871190

600 l

1515 x 700 x 670 mm

1325 112 565

Scania 1871191

700 l

1655 x 700 x 670 mm

1325 112 567

Scania 1871192

 (Illustration  similar)

| 103

2

 4 ser

ies

 Tensioning strap base

 for fuel tanks

Description

Suitable for

Length

Order no

Comparative no

Tensioning strap base

164, 144, 124, 114, 94

660 mm

6170 127 076

Scania 1747507

Tensioning strap base

164, 144, 124, 114, 94

500 mm

6170 127 078

Scania 1747506

Tightening strap

164, 144, 124, 114, 94

554 mm

8001 745 881

Scania 1745881

Tightening strap

164, 144, 124, 114, 94

685 mm

8000 012 299

Scania 1401839

Tightening strap

164, 144, 124, 114, 94

695 mm

6170 127 075

Scania 1745886

Tightening strap

164, 144, 124, 114, 94

710 mm

8000 012 300

Scania 1401840

  This fi gure corresponds to   6170 127 076

 Engine attachment

Scania P G R series EURO IV / V

Silencers & Exchangable filter units

DOC

Dinex no. 68000
OE no. 1881662

SCR

Dinex no. 68040
OE no. 1928891
1548342

SCR

Dinex no. 68020
OE no.  1928893
1541622

EURO IV / V REPLACEMENT SILENCERS

•  Direct replacements of original Euro IV / V
silencers.
•  Stainless steel material.
•  Replacement silencers are tested in Dinex
Technology Center, to ensure product functionality
with respect to emission reduction, back pressure
performance as well as noise reduction compliance.
•  Dinex is a full system manufacturer - from turbo
to tailpipe, including all emission components and
mixers.

INFORMATION HOTLINE: Tel 0 180 225 1125 / Dinex GmbH/ Gewerbestraße 3-5/ 36148 Kalbach
Fax 0 6655 918 601/ info@dinex.de/ www.dinex.de

EURO IV
Dinex no. 68339
OE no. 1538681
1865785

EURO IV / V
Dinex no. 68343
OE no. 1548344
1914724
1944683

EURO V
Dinex no. 68350
OE no. 1548340

104 |

2

4 ser

ies

Tank sensor

for fuel supply

Suitable for

Length

Order no

Comparative no

124

479 mm

6170 121 275

Scania 1846137

164, 144, 124, 114, 94

485 mm

8000 012 700

Scania 1541083

164, 144, 124, 114, 94

495 mm

1325 121 278

Scania 2304440

164, 144, 124, 114, 94

643 mm

8000 012 880

Scania 1541082

124

643 mm

6170 121 277

Scania 1846136

This figure corresponds to 8000 012 880

Fuel cap

∅

60 mm

Version lockable, with ventilation

Suitable for

Material

Fig.

Order no

164, 144, 124, 114, 94

plastic

1

1129 281 301

164, 144, 124, 114, 94

stainless steel

2

1129 208 710

1

2

Fuel cap

for AdBlue

®

Version

with lock

Material plastic

Suitable for

Order no

Comparative no

series 4

1129 235 593

Scania 1759435

Engine attachment

106 |

2

 4 ser

ies

 Drive

 Clutch kit

∅

430 mm

Number of teeth 24

Suitable for

Order no

Comparative no

124, 114, 94

9750 000 356

Sachs 3400 700 356

Scania 574984

 Clutch kit

 in exchange

∅ 430 mm
  Scope  of  supply

 With  release  bearing

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

6953 328 800

LuK 643 3288 00

Scania 572953

 Clutch kit

 in exchange

∅ 430 mm
  Scope  of  supply

 Central  release  mechanism

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9735 003 084

LuK 643 3087 33

Scania 572955

 Clutch kit

 in exchange

∅ 430 mm

Suitable for

Order no

Comparative no

164

9735 003 294

LuK 643 3294 00

Scania 572943

  Scope of supply

 With  release  bearing

| 107

2

 4 ser

ies

 Drive

 Clutch plate

Parameter

430TZFV

Number of teeth

24

Toothed hub profi le 46x50-24N

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9736 006 893

LuK 343 0203 10

Scania 1111148

 Coupling pressure plate

Parameter ZBFO430

∅

430 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8000 025 320

LuK 143 0253 20

Scania 571289

 Clutch plate

Parameter

430WGTZ

∅

430 mm

Number of teeth 24

Suitable for

Order no

Comparative no

164

9270 056 732

Sachs 1878 003 065

Scania 574908

 Clutch plate

Parameter

430WGTZ

∅

430 mm

Number of teeth

24

Toothed hub profi le 46 x 50-24N

Suitable for

Order no

Comparative no

144, 124, 114, 94

9270 003 839

Sachs 1878 003 839

Scania 1479575

108 |

2

 4 ser

ies

 Coupling pressure plate

 in exchange

Parameter MFZ430

∅

430 mm

Suitable for

Order no

Comparative no

124, 114, 94

9750 002 364

Sachs 3482 000 999

Scania 1479574

 Coupling pressure plate

 in exchange

Parameter MFZ430

∅

430 mm

Suitable for

Order no

Comparative no

164

9270 000 257

Sachs 3482 000 257

Scania 571324

 Coupling pressure plate

 in exchange

Parameter MFZ430

∅

430 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9270 083 039

Sachs 3482 083 039

Scania 1321259

 Drive

 Flywheel

  Scope of supply

 With external ring gear, without thrust ring

Suitable for

Order no

Comparative no

164, 124, 114, 94

9750 001 018

Sachs 3421 601 042

| 109

2

 4 ser

ies

 Clutch release bearing

Parameter KZISZ-5

Suitable for

Order no

Comparative no

164, 124, 114, 94

9305 171 255

LuK 500 1158 10

Scania 1851631

 Clutch servo

Operating pressure max. 10 bar

Stroke

30 mm

∅

117 mm

Suitable for

Order no

Comparative no

124, 114, 94

0640 100 010

WABCO 974 010 001 0

Scania 1469161

 Clutch master cylinder

Version servo

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3400 629 683

Knorr 629683AM

Scania 1513717

 Release fork

Suitable for

Order no

Comparative no

164, 124, 114, 94

6031 737 306

Scania 1737306

 for release bearing

 Drive

 Clutch release bearing

Parameter KZIZ-5

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9270 005 202

Sachs 3100 005 202

Scania 1393162

110 |

2

 4 ser

ies

 Clutch slave cylinder

Length of piston rod 129,5 mm

Bore hole ∅

38,1 mm

Material

Aluminium

Suitable for

Order no

Comparative no

164, 124, 114, 94

6031 754 943

FTE KN38017.3.5

Scania 1754943

 Ball head

 for gear shift linkage

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

6035 502 680

Scania 1384624

 Ball joint

Installation location Down shift linkage

Length

55 mm

Outer thread

M12 x 1

Thread type

Right-hand thread

Material

Cast steel

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9073 304 100

Scania 371452

 Drive

 Clutch slave cylinder

Length of piston rod 273,5 mm

Bore hole ∅

38,1 mm

Material

Aluminium

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3500 020 824

Scania 1756460

| 111

2

 4 ser

ies

 Propeller shaft

Connection 4.5°

Suitable for

Length

Order no

Comparative no

series 4

535 mm

9220 057 019

Wichmann 12-0057019

Scania 1796589

series 4

1783 mm

9220 005 966

Wichmann 12-0006258

Scania 1758434

 Propeller shaft

Suitable for

Order no

Comparative no

series 4

9220 006 243

Wichmann 12-0006243

Scania 1758601

series 4

9220 027 314

Wichmann 12-0027314

Scania 1796582

series 4

9220 058 128

Wichmann 12-0058128

Scania 1796591

 Ball joint

Installation location Upper shift linkage

Length

55 mm

Outer thread

M12 x 1

Thread type

Left-hand thread

Material

Cast steel

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9073 304 200

Scania 371451

 Drive

 Propeller shaft

Suitable for

Order no

Comparative no

series 4

9895 200 000

Wichmann 12-0030208

Scania 1759124

Connection 4,5°

112 |

2

 4 ser

ies

 Suspension and damping

 Fastening set

Suitable for

Version

Order no

series 4

Phoenix K004

1722 052 729

 Fastening set

Suitable for

Version

Order no

series 4

Phoenix K031

1722 053 106

 Shock absorber

Version

Oil pressure, twin-tube system

Fastening

Pin/eye

Installation location Front axle

Length

690 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9750 001 431

Sachs 125 998

 Air spring bellows

Version

double bellows

∅ of cover 160 mm
 Top mounting 2 x M10

Bottom mounting 2 x M10

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

1780 200 193

Conti FD 200-19 M14 M10

| 113

2

4 ser

ies

Suspension and damping

Parabolic spring

Installation location Front axle

Form

1K

Width

90 mm

Bushing front

36 mm

Bushing rear

36 mm

Length at front/rear 910 mm

Length at rear

910 mm

Suitable for

Number of leaves

Axle load

Position strength

Camber

Thickness

Order no

Comparative no

124, 114, 94

2

7,5 t

2 x 32  mm

125 mm

70 mm

1090 128 000

Scania 1377668

114, 94

2

2 x 30 mm

133 mm

66 mm

1090 126 000

Scania 1377666

124, 114, 94

3

8,5 t

3 x 29 mm

137 mm

96 mm

1090 116 000

Scania 1377670

124

4

4 x 28 mm

116 mm

122 mm

1090 138 000

Scania 1479518

This figure corresponds to 1090 128 000

Parabolic leaf spring

Number of leaves

2

Width

100 mm

Bushing front

30/65 mm

Length at front/rear 707 mm

Length at rear

410 mm

Thickness

97 mm

Suitable for

Form

Version

Order no

Comparative no

144, 114, 94

50A

left

1090 189 000

Scania 1421060

144, 114, 94

50B

right

1090 187 000

Scania 1421061

This figure corresponds to 1090 189 000

Schomäcker Federn

für alle Nutzfahrzeuge

Schomäcker Federnwerk GmbH ·  Borgholzhausener Straße 1 · 49324 Melle
Telefon +49 5422 108-0 · Telefax +49 5422 108-127
E-Mail  federnwerk@schomaecker.de · Internet  www.schomaecker.de

SCH_Anzg_Trost10_01.indd   1

29.07.10   14:03
