Scania Truck (2017 year). Spare parts and accessories

82 |

R, G

, P

, T

Cabin fi lter

Filter type Pollen fi lter

Suitable for

Length

Width

Height

Order no

Comparative no

R, G, P, T

223 mm

165 mm

69 mm

9750 104 067

Hengst E956LI01

R, G, P, T

366,5 mm

128 mm

20 mm

9750 103 424

Hengst E2960LI

This fi gure corresponds to 9750 103 424

Condenser

for air-conditioning

Version without dryer

Length

842 mm

Width

271 mm

Depth

16 mm

Suitable for

Order no

Comparative no

R, G, P

0351 344 301

HELLA 8FC 351 344-301

Condenser

for air-conditioning

Version with dryer

Length

775 mm

Width

332 mm

Depth

17 mm

Suitable for

Order no

Comparative no

2860 940 486

Scania 2014389

Cab

Rotating joint

Installation side Left/right

Inner ∅

23,5 mm

Length

61,5/80 mm

Application range

2-point cab suspension

Suitable for

Order no

Comparative no

P, T

2127 008 581

Scania 1372432

| 83

R, G

, P

, T

Cab

Bearing bush

for stabiliser

Outer ∅ 60 mm

Inner ∅

16,5 mm

Length

63,5/80 mm

Application range

Cab

Suitable for

Order no

Comparative no

R, G, P

9990 007 562

Scania 1377562

Bushing

for cab suspension

Suitable for

Outer ∅

Inner ∅

Order no

Comparative no

R, G, P

42,5 mm

14 mm

5831 870 611

Scania 1870611

R, G

60 mm

16,6 mm

8001 788 239

Scania 1788239

R, G

59 mm

16,5 mm

8001 892 896

Scania 1892896

Air spring bellows

for cab suspension

Suitable for

Order no

Comparative no

R, G, P

1903 005 015

TRW JHP5015AB

Air spring bellows

for cab suspension

Version without fastening element

Suitable for

Order no

Comparative no

R, G, P

6170 122 722

Scania 1444016

84 |

R, G

, P

, T

Cab damper

Suitable for

Installation location

Fastening

Order no

Comparative no

R, P, T

Cab front

Pin/pin

9800 125 698

Scania 1476415

R, G, P

Cab front

Pin/eye

3510 043 113

Scania 1870615

R, G, P

Cab, rear

Pin/eye

3510 043 110

Scania 1873668

This fi gure corresponds to 9800 125 698

Cab damper

Suitable for

Installation location

Fastening

Order no

Comparative no

R, G, P

Cab front

Pin/pin

6170 125 691

Scania 1466185

R, G, P

Cab, rear

Pin/eye

9200 043 112

Scania 1910106

R, G, P

Cab, rear

Pin/eye

1325 125 953

Scania 1761376

R, G, P

Cab, rear

Pin/eye

9200 035 033

Scania 1502473

This fi gure corresponds to 6170 125 691

Cab

Cab damper

Suitable for

Fastening

Version

Order no

Comparative no

R, G, P

Pin/pin

gas pressure, twin-tube system

8000 012 243

Scania 1424229

R, G, P

Pin/eye

gas pressure, twin-tube system

9200 315 349

Scania 1761373

R, G, P

Pin/pin

oil pressure, twin-tube system

9203 138 040

Scania 1943267

Plate/pin

gas pressure, twin-tube system

9270 314 348

Scania 2023667

This fi gure corresponds to 8000 012 243

| 85

R, G

, P

, T

Cab

Driver cab tilting pump

Version hydraulic

Suitable for

Order no

Comparative no

R, G, P

8001 549 740

Scania 1549740

R, G, P

1325 123 017

Scania 1794907

R, P

6170 123 011

Scania 1549741

1325 094 906

Scania 1794906

This fi gure corresponds to 8001 549 740

Cab damper

Version

gas pressure, twin-tube system

Fastening pin/pin

Length

208-300 mm

Suitable for

Order no

Comparative no

R, G, P

9200 290 203

Sachs 290 203

R, G, P

9200 290 988

Sachs 290 988

R, G, P, T

9200 290 987

Sachs 290 987

This fi gure corresponds to 9200 290 203

Driver cab tilting pump

Suitable for

Order no

Comparative no

R, G, P

9200 100 424

Scania 2204436

1325 123 013

Scania 1534977

86 |

R, G

, P

, T

Driver cab tilt cylinder

Suitable for

Stroke

Length

Order no

Comparative no

318 mm

502/820 mm

8001 549 739

Scania 1549739

R, P

330 mm

701 mm

6170 123 001

Scania 1720925

330 mm

648-960 mm

8000 012 046

Scania 1549738

R, P

332 mm

496 mm

6170 123 003

Scania 1720927

R, P

345 mm

696/1041 mm

6031 720 924

Scania 1720924

404 mm

582 mm

1325 048 921

Scania 1848921

This fi gure corresponds to 8000 012 046

Driver cab tilt cylinder

Suitable for

Order no

Comparative no

8000 938 630

Scania 1938630

Driver cab tilt cylinder

Suitable for

Order no

Comparative no

3510 041 064

Scania 1790112

Cab

Gas spring

Spring force 400 N

Stroke

40 mm

Length

145,5 mm

Suitable for

Order no

Comparative no

R, G, P, T

4440 512 020

Stabilus 094307

| 87

R, G

, P

, T

Cab

Gas spring

LIFT-O-MAT

Suitable for

Spring force

Stroke

Order no

Comparative no

R, G, P, T

250 N

40 mm

2881 002 611

Stabilus 2611NO

R, G, P

400 N

120 mm

9270 008 674

Stabilus 8674DJ

Gas spring

Suitable for

Description

Spring force

Length

Order no

Comparative no

for front flap

250 N

785 mm

2880 031 866

Scania 2031866

R, G, P, T

for radiator grille

250 N

155 mm

1325 002 325

Scania 1727269

for radiator grille

250 N

685 mm

1325 123 256

Scania 2031868

R, G

for radiator grille

400 N

700 mm

1325 123 259

Scania 2031872

R, G, P

for side flap

85 N

235,5 mm

9200 049 807

Scania 1866714

R, G, P, T

for storage box

65 N

445/240 mm

1325 023 270

Scania 1761668

This figure corresponds to 2880 031 866

88 |

R, G

, P

, T

Cab

Headlight bracket

With 4 lugs for bolting on 4 rectangular headlamps, lamp bracket for front mounting, front bracket with

TÜV certificate, polished to high-gloss by hand
∅

60 mm

Material V2A stainless steel
Scope of supply

Without headlamps

Suitable for

Order no

R 2009-/2014-

1002 004 023

Headlight bracket

With 4 clamps for bolting on 4 headlamps, roof bracket to be secured at original points with clamps, polished to

high-gloss by hand
∅

60 mm

Material V2A stainless steel
Application range

For vehicles with flat roof
Scope of supply

Without headlamps

Suitable for

Order no

R Highline 2009-/2014-

1002 003 043

Headlight bracket

With 6 loose brackets for bolting on headlamps, pre-wired for assembly at original points, polished to high-gloss

by hand
∅

60 mm

Material V2A stainless steel

Suitable for

Order no

R Topline 2009-

8520 864 168

Headlight bracket

Hydra

With 6 bolt-on lugs for bolting on 6 headlamps, lamp bracket incl. 15 LED lights for mounting at original points,

roof bracket mounted without removing the roof liner, polished to high-gloss by hand
∅

60 mm

Material V2A stainless steel
Application range

For vehicles with side tube along the entire length of the roof
Scope of supply

Without headlamps

Suitable for

Order no

R Topline 2009-/2014-

1002 013 013

| 89

R, G

, P

, T

Cab

Headlight bracket

for clamping

With 4 welded brackets for bolting on headlamps, pre-wired for assembly at original points, polished to high-

gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Suitable for

Order no

R Topline 2009-

9150 503 013

Headlight bracket

for clamping

With 4 loose brackets for bolting on headlamps, up to 6 headlamps can be connected, pre-wired for assembly at

original points, polished to high-gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Suitable for

Order no

R Topline 2009-

9190 503 022

Headlight bracket

for clamping

With 4 welded brackets for bolting on headlamps, pre-wired for assembly at original points, polished to high-

gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Suitable for

Order no

R Topline 2009-

1002 064 161

Headlight bracket

With 6 loose brackets for bolting on headlamps, pre-wired for assembly at original points, polished to high-gloss

by hand
Installation location Front

∅

60 mm

Material

V2A stainless steel

Suitable for

Order no

R Highline 2009-

8520 864 158

90 |

R, G

, P

, T

Cab

Headlight bracket

for clamping

With 4 welded brackets for bolting on headlamps, pre-wired for assembly at original points,

polished to high-gloss by hand
Installation location Top

Material

V2A stainless steel

Suitable for

Order no

R Highline 2009-

9156 503 038

Headlight bracket

for clamping

With 4 loose brackets for bolting on headlamps, up to 6 headlamps can be connected,

pre-wired for assembly at original points, polished to high-gloss by hand
∅

60 mm

Material V2A stainless steel

Suitable for

Order no

R Highline 2009-

9080 008 668

Headlight bracket

for clamping

With 4 welded brackets for bolting on headlamps, pre-wired for assembly at original points,

polished to high-gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Suitable for

Order no

R Highline 2009-

1002 064 151

Headlight bracket

With 4 lugs for bolting on 4 headlamps, roof bracket to be secured without removing the roof liner,

polished to high-gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Application range

For vehicles with flat roof

Suitable for

Order no

R 2009-/2014-

9156 503 039

| 91

R, G

, P

, T

Cab

Headlight bracket

With 4 lugs for bolting on 4 headlamps, roof bracket to be secured without removing the roof liner,

polished to high-gloss by hand
Installation location Top

∅

60 mm

Material

V2A stainless steel

Application range

For vehicles with flat roof

Suitable for

Order no

R 2009-/2014-

1002 064 141

Headlight bracket

With 4 welded brackets for bolting on headlamps, pre-wired for assembly at original points,

polished to high-gloss by hand
Installation location Bottom

∅

60 mm

Material

V2A stainless steel

Application range

For vehicles with flat roof

Suitable for

Order no

R, G, P 2009-

1002 004 020

Skirting protection bracket

Mega

Short assembly duration, assembly at original points, polished to high-gloss by hand
∅ 76 mm
with TÜV certificate

Suitable for

Order no

R 2009-/2014-

1002 023 238

92 |

R, G

, P

, T

Cab

Tread set

Version

3-piece

Material Stainless steel

Suitable for

Installation location

Order no

R 2009-

Left

1002 030 050

R 2009-

Right

1002 030 055

Suitable for

Order no

R 2009-/2014-

1002 023 239

Skirting protection bracket

Mini

Short assembly duration, assembly at original points, polished to high-gloss by hand
∅ 76 mm
with TÜV certificate

Frontal protection system

Protects the bumper in minor accidents, polished to high-gloss by hand
∅

60 mm

Material V2A stainless steel
Scope of supply

With fastening elements

Suitable for

Order no

R 2009-/2014-

1002 001 000

Frontal protection system

Version short

Suitable for

Order no

1002 001 005

| 95

Serie 4

Engine attachment........................................................................96–105

Drive ...........................................................................................106–111

Suspension and damping ...........................................................112–114

Axles and steering ......................................................................115–125

Braking system ...........................................................................126–129

Compressed air ..........................................................................130–149

Electrics ......................................................................................150–157

Cab .............................................................................................158–169

96 |

4 ser

ies

Engine radiator

Length 860 mm

Width

686 mm

Depth

42 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8000 010 751

HELLA 8MK 376 724-611

Engine attachment

Engine radiator

Length 938 mm

Width

860 mm

Depth

42 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9100 270 070

HELLA 8MK 376 721-621

Radiator fan

Number of blades 8

Outer ∅

750 mm

Scope of supply

With fan coupling

Suitable for

Order no

Comparative no

124

9100 278 090

HELLA 8MV 376 728-371

| 97

4 ser

ies

Water pump seal

Suitable for

Order no

Comparative no

9800 111 221

Scania 1384468

124, 114, 94

8000 002 013

Scania 1403883

124, 114, 94

8000 002 014

Scania 1541633

164, 144, 124, 114, 94

1325 024 157

Scania 1879484

164, 144, 124, 114, 94

8000 012 635

Scania 1357243

164

1325 024 220

Scania 1498657

This figure corresponds to 8000 002 013

Suitable for

Impeller-∅

Fig.

Order no

Comparative no

88 mm

9150 000 977

Scania 1510490

124, 114

105 mm

9150 000 927

Scania 1896752

144

105 mm

9150 000 946

Scania 1508532

164

112 mm

9150 000 928

Scania 1549482

164, 144, 124, 114, 94

112 mm

9150 000 929

Scania 1787120

Water pump

Version with pulley
Scope of supply

With seals

Engine attachment

Double thermostat

Scope of supply

With seal

Suitable for

Opening temperature

Height

Order no

164, 144, 124, 114, 94

80 °C

42,3 mm

1602 900 001

164, 144, 124, 114, 94

83 °C

25 mm

1602 900 007

This figure corresponds to 1602 900 001

Scania Truck (2017 year). Spare parts and accessories - 6
