Scania Truck (2017 year). Spare parts and accessories

50 |

R, G

, P

, T

Braking system

Brake lining set

Brake drum ∅ 413 mm

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

R, P

19931

19,00 mm

178 mm

2119 931 051

Textar 1993104

R, G, P, T

19932

19,00 mm

203 mm

2119 932 051

Textar 1993204

R, G, P, T

19932

20,00 mm

203 mm

2119 932 151

Textar 1993206

R, G, P, T

19932

21,00 mm

203 mm

2119 932 251

Textar 1993208

This figure corresponds to 2119 931 051

Brake drum

Inner ∅

413 mm

Height

253 mm

Hole pattern 10 x 23,5/3 x M12 mm

Brake path

149 mm

Suitable for

Order no

Comparative no

R, G, P, T

2090 413 011

Scania 360567

Brake lining set

Brake drum ∅ 413 mm

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

R, P

19931

19,00 mm

178 mm

2119 931 008

Scania 385948

Scania 551123

R, G, P, T

19932

19,00 mm

203 mm

2119 932 008

Scania 1109003

Scania 551124

R, G, P, T

19933

19,10 mm

254 mm

2119 933 008

Scania 1535250

This figure corresponds to 2119 932 008

| 51

R, G

, P

, T

Brake lining set

Suitable for

WVA no.

Lining thickness

Lining width

Order no

Comparative no

R, G, P, T

17991

19 mm

127 mm

2117 991 503

Beral 17991 190000 16374

R, G, P, T

19932

19 mm

203 mm

2119 932 503

Beral 19932 190000 15504

R, G, P, T

19932

20 mm

203 mm

2119 932 603

Beral 19932 200000 16374

Braking system

Suitable for

Form

Installation location

Installation side

Order no

Comparative no

R, G, P, T

left offset, 0 mm

rear axle

left/right

1205 842 250

Scania 1112831

R, G, P, T

left cropped, +25 mm

rear axle

left

1205 842 220

Scania 1112833

R, G, P, T

right offset, -25 mm

rear axle

right

1205 842 260

Scania 1112834

R, G, P, T

left offset, +65 mm

front axle

left

1205 842 740

Scania 1789568

R, G, P, T

right offset, -65 mm

front axle

right

1205 842 735

Scania 1789567

Slack adjuster

Version automatic

This fi gure corresponds to 1205 842 250

Suitable for

Form

Distance between holes

Order no

Comparative no

R, G, P, T

left offset +25 mm

3400 726 600

Haldex 72660C

R, G, P, T

right offset, +25 mm

3400 726 610

Haldex 72661C

R, G, P, T

left offset, +65 mm

9990 001 002

Haldex 79443C

R, G, P, T

right offset, -65 mm

9990 001 004

Haldex 79442C

R, G, P, T

left offset -75 mm

165 mm

3400 728 070

Haldex 79105C

R, G, P, T

left offset, +75 mm

165 mm

3400 728 080

Haldex 79106C

Slack adjuster

Version automatic

This fi gure corresponds to 9990 001 004

52 |

R, G

, P

, T

Compressed air

Compressor

Version

water cooled

Number of cylinders 2

Capacity

720 cm³

Fastening

Flange

Suitable for

Order no

Comparative no

3403 865 300

Knorr K038653N00

Compressor

Version

water cooled

Number of cylinders 2

Capacity

720 cm³

Fastening

Flange

Type

Suitable for

Order no

Comparative no

R, G, P

3404 949 000

Knorr K053603N00

Reman

R, G, P

3405 360 300

Knorr K053603X00

Compressor

Version

water cooled

Number of cylinders 2

Capacity

720 cm³

Fastening

Flange

Shaft dia.

28 mm

Type

Suitable for

Order no

Comparative no

R, G, P

3400 244 100

Knorr K024410N00

Reman

R, G, P

3405 374 000

Knorr K053740X00

Compressor

Type

Suitable for

Order no

Comparative no

3405 364 300

Knorr K053643N00

Reman

3400 364 300

Knorr K053643X00

Version

water cooled

Number of cylinders 2

Fastening

Flange

Shaft dia.

36 mm

| 53

R, G

, P

, T

Compressed air

Compressor

With drive shaft, pressurised lubrication, water-cooled valve plate, with energy saving mechanism
Version

water cooled

Number of cylinders 2

Capacity

608 cm³

Fastening

Flange

Coolant connection M18 x 1.5

Oil pressure connection M12 x 1.5

Suitable for

Order no

Comparative no

R, G, P, T

3400 016 615

Knorr-Bremse K016615ES

Suitable for

Order no

Comparative no

R, G, P, T

3400 043 840

Knorr II159920051

Cylinder head gasket set

for compressor

Repair kit

for compressor

Suitable for

Order no

Comparative no

R, G, P

3400 348 744

Knorr K034874K50

Cylinder head kit

for compressor

Suitable for

Order no

Comparative no

R, G, P, T

3450 414 465

Knorr SEB01444004

R, G, P, T

3400 044 230

Knorr SEB011380061

(Illustration similar)

54 |

R, G

, P

, T

Compressed air

Blowoff valve

Version

without safety valve

Connection 1

M16 x 1.5

Connection 2

M16 x 1.5

Outlet pressure 10,3 bar

Suitable for

Order no

Comparative no

R, G, P, T

3404 810 091

Knorr 0481009102

Gasket set

for compressor

Suitable for

Order no

Comparative no

R, G, P, T

3420 680 570

Knorr II326840061

Repair kit

for 2-cylinder compressors

Suitable for

Order no

Comparative no

R, G, P, T

3400 035 470

Knorr II159920063

Repair kit

for compressor

Suitable for

Order no

Comparative no

R, G, P

3400 188 090

Knorr K018809

Pressure limiter

Version

without safety valve

Connection

M16 x 1.5

Outlet pressure max. 16 bar

Inlet pressure

3 bar

Suitable for

Order no

Comparative no

3401 551 557

Knorr AC155F

Pressure limiter

Version

without safety valve

Connection

M16 x 1.5

Outlet pressure 7,3 bar

Suitable for

Order no

Comparative no

R, G, P, T

3630 090 180

Knorr 0481009018000

| 55

R, G

, P

, T

Compressed air

ABS solenoid control valve

Connection

electric, bayonet (DIN) 72585

Voltage

24 V

Connection thread

M22 x 1,5

Operating pressure max. 13 bar

Temperature range

-40 to +80 °C

Protection class

IP69K

Suitable for

Order no

Comparative no

R, G, P, T

0371 950 970

WABCO 472 195 097 0

Brake power controller

Version

manual, without relay function, lever on right

Connection

M22 x 1.5/M22 x 1.5

Number of connections 4

Application pressure

0,5 bar

68° working range of the lever
Scope of supply

With lever, without trailer control valve

Suitable for

Order no

Comparative no

R, G, P, T

3990 001 070

Knorr 1186938

EBS foot brake module

Type

Suitable for

Order no

Comparative no

R, G, P, T

3400 044 696

Knorr K044696N50

Reman

R, G, P, T

3404 469 650

Knorr K044696X50

56 |

R, G

, P

, T

EBS single channel module

Operating pressure max. 12.5 bar

Protection class

IP6K6K

Connection

M22 x 1.5/M16 x 1.5

Temperature range

-40 to +85 °C

Type

Suitable for

Order no

Comparative no

R, G, P, T

3400 085 000

Knorr K021202N50

Reman

R, G, P, T

3400 212 025

Knorr K021202X50

EBS trailer modulator

Operating pressure max. 12.5 bar

Protection class

IP6K6K

Connection

M22 x 1.5/M16 x 1.5

Temperature range

-40 to +80 °C

Type

Suitable for

Order no

Comparative no

R, G, P, T

5233 016 212

Knorr K020623N50

Reman

R, G, P, T

3402 062 350

Knorr K020623X50

EBS two channel module

Operating pressure max. 12.5 bar

Protection class

IP6K6K

Connection

M22 x 1.5/M16 x 1.5

Temperature range

-40 to +85 °C

Type

Suitable for

Order no

Comparative no

R, G, P, T

3400 032 014

Knorr K032014N50

Reman

R, G, P, T

3403 201 450

Knorr K032014X50

Compressed air

Solenoid valve

3/2-direction control

Connection thread

M22 x 1.5/M16 x 1.5 VOSS

Operating pressure max. 13 bar

Suitable for

Order no

Comparative no

R, G, P, T

0640 060 050

WABCO 973 011 300 0

| 57

R, G

, P

, T

Compressed air

ALB controller

Connection

M16 x 1.5/M22 x 1.5

Operating pressure max. 10 bar

Temperature range

-40 to +80 °C

Suitable for

Order no

Comparative no

R, G, P

0397 220 000

WABCO 475 722 000 0

Relay valve

Connection

M22 x 1.5/M16 x 1.5

Operating pressure max. 10 bar

Suitable for

Order no

Comparative no

R, G, P, T

0640 110 020

WABCO 973 011 002 0

Relay valve

Version

with integrated check valve

Connection

M22 x 1.5/M16 x 1.5

Operating pressure max. 13 bar

Suitable for

Order no

Comparative no

R, G, P

0640 110 500

WABCO 973 011 050 0

ALB controller

Version

pneumatic

Connection

M16 x 1.5/M12 x 1.5

Operating pressure max. 10 bar

Temperature range

-40 to +80 °C

Suitable for

Order no

Comparative no

R, G, P

3807 230 010

WABCO 475 723 001 0

(Illustration similar)

58 |

R, G

, P

, T

Compressed air

Relay valve

Version

dual circuit for addition prevention

Connection 1-2 M22 x 1,5/3 x M16 x 1,5/M22 x 1,5

Connection 4

M16 x 1.5

Suitable for

Order no

Comparative no

R, G, P, T

3630 260 270

Knorr 0481026027000

Relay valve

Version

single circuit, with integrated silencer

Connection

M22 x 1.5/M22 x 1.5/M16 x 1.5

Operating pressure max. 10.2 bar

Temperature range

-40 to +80 °C

Suitable for

Order no

Comparative no

R, G, P, T

3450 404 805

Knorr AC574CXY

Relay valve

Version

single circuit

Connection 1-2

M22 x 1,5

Connection 4

M16 x 1.5

Operating pressure max. 13 bar

Suitable for

Order no

Comparative no

R, G, P, T

3400 045 956

Knorr 0481026021000

Trailer control valve

Operating pressure max. 10 bar

Thread

M16 x 1,5

Type

Suitable for

Order no

Comparative no

R, G, P, T

0640 090 100

WABCO 973 009 010 0

Reman

R, G, P, T

0640 090 107

WABCO 973 009 010 7

Trailer control valve

Operating pressure max. 10 bar

Thread

M16 x 1,5

Suitable for

Order no

Comparative no

R, G, P

3800 090 220

WABCO 973 009 022 0

| 59

R, G

, P

, T

Compressed air

Motor coach brake valve

Operating pressure max. 9 bar

Nominal width

10 mm

venting: silencer

Type

Suitable for

Order no

Comparative no

R, G, P, T

0283 151 800

WABCO 461 315 180 0

Reman

R, G, P, T

0283 151 807

WABCO 461 315 180 7

Quick-release valve

Version

without silencer, with bypass

Connection thread

M22 x 1.5/M16 x 1.5

Operating pressure max. 10 bar

Suitable for

Order no

Comparative no

R, G, P, T

3400 008 920

Knorr KX2552/3

Overfl ow valve

Version

without return fl ow

Operating pressure max. 13 bar

Setting range

5,3-7,0 bar

Nominal width

8 mm

Ovefl ow pressure

10 bar

Connection thread

M22 x 1.5

Suitable for

Order no

Comparative no

R, G, P, T

3804 341 001

WABCO 434 100 136 0

Motor coach brake valve

Version

without microswitch, without kick plate

Connection 1 2 x diameter 12 mm

Connection 2 3 x diameter 12 mm
2 output circuits diameter 12 mm

Suitable for

Order no

Comparative no

R, G, P, T

3400 046 064

Knorr 0481064603000

60 |

R, G

, P

, T

Compressed air

Air treatment unit

Version

Electronic

Type

E-APU

Connection M12 x 1.5

Suitable for

Order no

Comparative no

R, G, P, T

8000 100 090

WABCO 932 510 009 0

Repair kit

four-circuit protection valve

Suitable for

Order no

Comparative no

R, G, P, T

3805 109 582

WABCO 932 510 958 2

Repair kit

for air dryer

Suitable for

Order no

Comparative no

R, G, P

0565 109 522

WABCO 932 510 952 2

R, G, P, T

0565 109 562

WABCO 932 510 956 2

(Illustration similar)

Repair kit

for air dryer

Suitable for

Order no

Comparative no

R, G, P

3800 251 095

WABCO 932 510 954 2

| 61

R, G

, P

, T

Compressed air

Muffl er

Connection

Snap contour

Operating pressure 11 bar

Height

53 mm

∅

69 mm

Suitable for

Order no

Comparative no

R, G, P, T

0174 070 700

WABCO 432 407 070 0

Muffl er

Connection Snap contour

Suitable for

Order no

Comparative no

R, G, P, T

3400 410 630

Knorr II41063F

Membrane brake cylinder

Type

Connection

M16 x 1.5

Operating pressure

10.7 bar

Stroke

64 mm

Thread

M16 x 1,5

Bolt length

38 mm

Length of piston rod 15 mm

Temperature range

-40 to +80 °C

Standard

DIN/ISO 1219

Application range

Vehicles with disc brakes

Suitable for

Order no

Comparative no

R, G, P, T

3450 409 380

Knorr K002556

Membrane brake cylinder

Type

Installation location

front axle

Installation side

left/right

Connection

M16 x 1,5

Operating pressure

max. 10 bar

Stroke

65 mm

Piston rod thread

M16 x 1,5

Length of piston rod 15 mm
Force output 8500 N at 6 bar
Application range

Vehicles with disc brake

Suitable for

Order no

Comparative no

R, G, P, T

0135 061 430

WABCO 423 506 143 0

62 |

R, G

, P

, T

Compressed air

Combination brake cylinder

Suitable for

Length of piston rod

Type

Order no

Comparative no

R, G, P

15 mm

24/16

3809 254 610

WABCO 925 461 351 0

R, G, P, T

15 mm

24/16

3809 254 613

WABCO 925 461 350 0

R, G, P, T

15 mm

24/30 IBV

3804 813 120

WABCO 925 481 312 0

R, G, P, T

15 mm

24/30 IBV

3804 813 110

WABCO 925 481 311 0

R, G, P, T

15 mm

24/30 IBV

3804 813 100

WABCO 925 481 310 0

R, G, P

15 mm

24/30 IBV

3804 813 140

WABCO 925 481 314 0

R, G, P, T

15 mm

24/30 IBV

0554 813 130

WABCO 925 481 313 0

R, G, P, T

70 mm

20/24

3804 300 660

WABCO 925 430 066 0

R, G, P, T

70 mm

20/24

3804 300 360

WABCO 925 430 036 0

R, G, P

70 mm

20/24

3804 300 350

WABCO 925 430 035 0

R, G, P, T

215 mm

24/24

0554 310 387

WABCO 925 431 038 7

R, G, P, T

215 mm

24/24

0554 310 370

WABCO 925 431 037 0

R, G, P

247 mm

24/30

0554 315 147

WABCO 925 431 514 7

This fi gure corresponds to 0554 813 130

Membrane brake cylinder

Connection

M16 x 1.5

Operating pressure max. 8.5 bar

Temperature range

-40 to 80 °C

Application range

Vehicles with S-cam brake

Suitable for

Order no

Comparative no

R, G, P, T

3450 408 165

Knorr II33481A

Membrane brake cylinder

Connection

M16 x 1.5

Operating pressure

max. 8.5 bar

Stroke

75 mm

Thread

M16 x 1,5

Bolt length

42 mm

Length of piston rod 180 mm
Application range

Vehicles with S-cam brake

Suitable for

Order no

Comparative no

R, G, P, T

3403 378 333

Knorr II33783A

64 |

R, G

, P

, T

Compressed air

Combination brake cylinder

Connection

M16 x 1.5

Operating pressure max. 10.5/8.5 bar

Stroke

65/65 mm

Release pressure

4.9 bar

Type

24/24

Power output F: 8800 N/20 mm

Suitable for

Order no

Comparative no

R, G, P, T

0554 310 637

Wabco 925 431 063 7

ECAS solenoid valve

Connection

M22 x 1.5

Operating pressure max. 13 bar

Average voltage

24 V

Temperature range

-40 °C to 80 °C

Protection class

IP6K9K

Suitable for

Order no

Comparative no

R, G, P, T

3808 800 320

WABCO 472 880 032 0

Suitable for

Application range

Length of piston rod

Stroke

Type

Order no

Comparative no

R, G, P

Vehicles with disc brake

15 mm

64/57 mm

24/30

3450 409 110

Knorr K017119N00

R, G, P

Vehicles with S-cam brake

250 mm

64/64 mm

24/105

3990 000 070

Knorr K2B0514X50

R, G, P, T

Vehicles with S-cam brake

250 mm

64/64 mm

24/80

3990 000 040

Knorr K2B0506X50

R, G, P, T

Vehicles with S-cam brake

251 mm

64/64 mm

30/80

3400 008 440

Knorr K2B0520XU

R, G, P, T

Vehicles with S-cam brake

251 mm

64/64 mm

20/80

3990 003 780

Knorr K2B0504X50

Combination brake cylinder

Connection M16 x 1.5/M16 x 1.5

This fi gure corresponds to 3450 409 110

| 65

R, G

, P

, T

Compressed air

ECAS solenoid valve

Version

with noise reducer, solenoid connection at top

Installation location

Rear axle, tag axle

Connection

Electric, 2 x bayonet DIN

Voltage

24 V

Connection thread

M22 x 1.5, VOSS 230

Operating pressure max. 5-13 bar

Protection class

IP6K6K

Suitable for

Order no

Comparative no

R, G, P

0379 051 110

WABCO 472 905 111 0

ECAS solenoid valve

Connection

M22 x 1.5

Operating pressure max. 5-13 bar

Voltage

24 V

Protection class

IP6K9K

Suitable for

Order no

Comparative no

R, G, P, T

6001 343 254

WABCO 472 880 001 0

ECAS path sensor

Connection

Bayonet DIN 72585-A1-2.1-Sn/K2

Version

with lever, without temperature compensation

Temperature range -40 °C to 80 °C

Setting

100°

Please note that the base section must be ordered separately.

441 050 711 2 = 209 mm

441 050 712 2 = 289 mm

441 050 713 2 = 299 mm

441 050 714 2 = 323 mm

Suitable for

Order no

Comparative no

R, G, P

0210 501 000

WABCO 441 050 100 0

Air spring valve

Version

with fl at lever, secondary bleeding

Setting

17,5°

Thread

M12 x 1,5/M16 x 1,5

Height limit 39,5°

Suitable for

Order no

Comparative no

3450 408 125

Knorr II32763

Scania Truck (2017 year). Spare parts and accessories - 4
