Scania Truck (2017 year). Spare parts and accessories - 3

34 |

1

 R, G

, P

, T

 Fastening set

Suitable for

Version

Order no

R, G, P, T

Phoenix K004

1722 052 729

 Fastening set

Suitable for

Version

Order no

R, G, P, T

Phoenix K031

1722 053 106

 Suspension and damping

 Shock absorber

Suitable for

Installation location

Fastening

Order no

Comparative no

R, G, P, T

Front axle

Pin/eye

9750 001 431

Sachs 125 998

R, G, P

Eye/eye

9200 316 291

Sachs 316 291

Suitable for

Number of leaves

Axle load

Position strength

Camber

Thickness

Order no

Comparative no

R, G, P, T

2

7,5 t

2 x 32  mm

125 mm

70 mm

1090 128 000

Scania 1377668

R, G, P, T

2

2 x 30 mm

133 mm

66 mm

1090 126 000

Scania 1377666

R, G, P, T

3

8,5 t

3 x 29 mm

137 mm

96 mm

1090 116 000

Scania 1377670

R, G, P, T

4

4 x 28 mm

116 mm

122 mm

1090 138 000

Scania 1479518

 Parabolic spring

Installation location Front axle

Form

1K

Width

90 mm

Bushing front

36 mm

Bushing rear

36 mm

Length at front/rear 910 mm

Length at rear

910 mm

  This fi gure corresponds to   1090 128 000

Suspension and damping

36 |

1

 R, G

, P

, T

 Parabolic leaf spring

Number of leaves

2

Width

100 mm

Bushing front

30/65 mm

Length at front/rear 707 mm

Length at rear

410 mm

Thickness

97 mm

Suitable for

Form

Version

Order no

Comparative no

R, G, P, T

50A

left

1090 189 000

Scania 1421060

R, G, P, T

50B

right

1090 187 000

Scania 1421061

  This fi gure corresponds to   1090 189 000

 Leaf spring

Number of leaves

2

Width

90 mm

Form

1L

Length at front/rear 910 mm

Length at rear

910 mm

Thickness

70 mm

Camber

126 mm

Bushing front

36 mm

Bushing rear

36 mm

Suitable for

Order no

Comparative no

R, G, P, T

1090 140 000

Scania 1528206

 Suspension and damping

 Leaf spring

Installation location Rear axle

Form

8

Number of leaves

10

Axle load

26,3 t

Width

90 mm

Length at front/rear 795 mm

Length at rear

795 mm

Thickness

250 mm

Camber

70 mm

Suitable for

Order no

Comparative no

R, G, P, T

8000 005 549

Scania 1398987

 Pitman spring

Number of leaves

2

Width

100 mm

Bushing front

30/65 mm

Length at front/rear 714 mm

Length at rear

419 mm

Thickness

97 mm

Description

Installation side

Order no

Comparative no

R, G, P, T

left

1080 205 000

Scania 1769877

R, G, P, T

right

1080 207 000

Scania 1769878

| 37

1

 R, G

, P

, T

 Spring bushing

Suitable for

Length

Outer ∅

Inner thread

Order no

Comparative no

R, G, P, T

89 mm

36 mm

M28 x 4

1539 000 500

Scania 0128680

R, G, P, T

89 mm

46 mm

M36 x 4

1599 000 400

Scania 0135036

R, G, P, T

103 mm

46 mm

M36 x 4

1539 000 400

Scania 0135698

R, G, P, T

121,5 mm

65 mm

1246 845 010

Scania 255669

  This fi gure corresponds to   1539 000 500

 Suspension and damping

 Spring hoop

Suitable for

Length

Thread

Clearance

Order no

Comparative no

R, G, P, T

309 mm

M24

105 mm

8001 397 705

Scania 1397705

R, G, P, T

227 mm

M22

92 mm

9990 000 630

Scania 2064011

R, G, P, T

203 mm

M22

92 mm

9990 000 622

Scania 2096131

R, G, P

213 mm

M22

92 mm

9990 000 624

Scania 2096132

  This fi gure corresponds to   8001 397 705

 Spring hoop

Suitable for

Length

Thread

Thread length

Clearance

Order no

Comparative no

R, G, P, T

173 mm

M22 x 2,5

60 mm

93 mm

5831 859 926

Scania 1859926

R, G, P, T

256 mm

M22 x 2,5

70 mm

93 mm

6170 125 419

Scania 2096135

R, G, P, T

308 mm

M24

70 mm

105 mm

8000 112 730

Scania 2154121

  This fi gure corresponds to   8000 112 730

38 |

1

 R, G

, P

, T

 Drag-link

Cone-∅ 30 mm

Suitable for

Length

Pipe ∅

Order no

Comparative no

R, G, P

495 mm

40 mm

9070 321 456

Lemförder 21456 01

R, G, P, T

1053 mm

50 mm

9070 900 016

Lemförder 14824 02

  This fi gure corresponds to   9070 900 016

 Axles and steering

 Drag-link

Length

1921 mm

Cone-∅ 30 mm

Pipe ∅

60 mm

Suitable for

Order no

Comparative no

R, G, P

9072 007 278

TRW JTR4321

 Ball joint

Length

120 mm

Cone-∅ 30 mm

Suitable for

Thread type

Order no

Comparative no

R, G, P, T

Left-hand thread

9070 900 123

Lemförder 11492 03

R, G, P, T

Right-hand thread

9070 900 117

Lemförder 11505 03

 Drag-link

Cone-∅ 30 mm
  Scope  of  supply

 With  accessories

Suitable for

Length

Pipe ∅

Order no

Comparative no

R, G, P

495 mm

40 mm

9050 001 235

Lemförder 21456 01

R, G, P, T

1059 mm

52 mm

9052 100 902

Lemförder 21009 02

R, G, P

1920 mm

60 mm

9050 001 146

Lemförder 23493 01

R, G, P

1921 mm

60 mm

9053 665 501

Lemförder 36655 01

  This fi gure corresponds to   9050 001 146

| 39

1

 R, G

, P

, T

 Ball joint

Length

145 mm

Cone-∅ 30 mm

Suitable for

Order no

Comparative no

R, G, P, T

5233 016 271

Lemförder 27853 01

 Axles and steering

 Ball joint

Length

141 mm

Cone-∅

30 mm

Thread type Right-hand thread

Suitable for

Order no

Comparative no

R, G, P, T

9072 535 301

Lemförder 25353 01

 Ball joint

Cone-∅

30 mm

Inner thread M26 x 1,5

Thread type

Right-hand thread

Suitable for

Length

Order no

Comparative no

R, G, P

75 mm

9073 377 202

Lemförder 38273 01

R, G, P

95 mm

9070 900 061

Lemförder 19537 01

 Ball joint

Length

120 mm

Cone-∅

30 mm

Outer thread M30 x 1,5

Suitable for

Thread type

Order no

Comparative no

R, G, P, T

Left-hand thread

9073 305 101

Lemförder 11492 03

R, G, P, T

Rght-hand thread

9073 305 201

Lemförder 11505 03

40 |

1

 R, G

, P

, T

 Ball joint

Cone-∅

30 mm

Thread

M24 x 1,5

Thread type Right-hand thread

Suitable for

Length

Order no

Comparative no

R, G, P, T

140 mm

9070 004 083

TRW JTE4083

R, G, P, T

142 mm

9070 004 082

TRW JTE4082

 Ball joint

Length

141 mm

Cone-∅

30 mm

Thread type Right-hand thread

Suitable for

Order no

Comparative no

R, G, P, T

9079 991 567

Lemförder 25353 01

 Angle joint

Length

75 mm

Installation side At steering cylinder

Thread type

Right-hand thread

Inner thread

M26 x 1,5

Cone

26 mm

Suitable for

Order no

Comparative no

R, G, P

9053 748 301

Lemförder 37483 01

 Ball joint

Cone-∅

30 mm

Inner thread M26 x 1,5

Thread type

Right-hand thread

  Scope  of  supply

 With  accessories

Suitable for

Length

Order no

Comparative no

R, G, P

75 mm

9073 377 201

Lemförder 38273 01

R, G, P

90 mm

9073 377 101

Lemförder 38272 01

  This fi gure corresponds to   9073 377 201

 Axles and steering

| 41

1

 R, G

, P

, T

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

R, G, P, T

9070 900 010

Lemförder 37247 01

 Ball joint

Length

90 mm

Cone-∅

30 mm

Inner thread M26 x 1,5

Thread

M24 x 1,5

  Scope  of  supply

 With  accessories

Suitable for

Order no

Comparative no

R, G, P

1903 000 127

TRW JTE0127

 Ball joint

Length

135 mm

Cone-∅

26 mm

Thread type Right-hand thread
  Scope  of  supply

 With  accessories

Suitable for

Order no

Comparative no

R, G, P, T

1903 003 532

TRW JTE3532

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

R, G, P, T

9073 603 065

TRW JTR4144

 (Illustration  similar)

 Axles and steering

42 |

1

 R, G

, P

, T

 Steering Track Rod

Length

1743 mm

Cone-∅ 30 mm

Pipe ∅

50 mm

Suitable for

Order no

Comparative no

R, G, P, T

9072 028 998

TRW JTR4402

Bore hole ∅

19/19 mm

Distance between holes 115/115 mm

Bearing version

Molecular bearing

Suitable for

Length

Order no

Comparative no

R, G, P

568 mm

9050 029 384

Lemförder 29384 01

R, G, P

568 mm

9052 758 102

Lemförder 27581 02

R, G, P

606 mm

9053 074 701

Lemförder 30747 01

 Trailing arm

  This fi gure corresponds to   9050 029 384

 Steering gear

 PROEQUIP

Version ball circuit steering gear, hydraulic

Suitable for

Order no

Comparative no

R, G, P

1903 000 003

TRW JRB5003

R, G, P

1903 000 005

TRW JRB5007

 Steering gear

 PROEQUIP

Version ball circuit steering gear, hydraulic

Suitable for

Order no

Comparative no

R, G, P

1903 000 048

Scania 1930699

 Steering gear

Version hydraulic
  Application  range

 For vehicles with power steering

Suitable for

Order no

Comparative no

R, G, P

3851 001 212

Scania 1783436

 Axles and steering

| 43

1

R, G

, P

, T

Stabilizer mounting

Suitable for

Installation location

Length

Outer ∅

Inner ∅

Order no

Comparative no

R, G, P, T

Front axle/rear axle

50 mm

46,5 mm

16 mm

6171 516 496

Scania 1516496

R, G, P, T

Rear axle

96,5 mm

105 mm

50 mm

9290 002 145

Scania 295751

R, G, P, T

Front axle/rear axle

100 mm

71 mm

50 mm

9290 002 220

Scania 228483

R, G, P, T

Front axle/rear axle

104 mm

95 mm

65 mm

9800 127 054

Scania 1344190

R, G, P, T

Front axle

119 mm

56 mm

40 mm

9290 002 240

Scania 213604

This figure corresponds to 9800 127 054

Axles and steering

Stabilizer mounting

Outer ∅ 57 mm

Inner ∅

20 mm

Length

30 mm

Suitable for

Order no

Comparative no

R, G, P

9290 002 230

Scania 310808

Repair kit

for stabiliser

Outer ∅ 57 mm

Inner ∅

20 mm

Length

30 mm

Suitable for

Order no

Comparative no

R, G, P, T

5832 156 626

Scania 2156626

Bearing bush

Outer ∅ 120,5 mm

Inner ∅

84 mm

Width

91,5 mm

Suitable for

Order no

Comparative no

R, G, P

6007 726 930

Scania 1772693

44 |

1

R, G

, P

, T

Wheel hub sealing ring

Suitable for

Inner ∅

Thickness

Order no

Comparative no

R, G, P, T

129,5 mm

3 mm

1325 117 074

Scania 804725

R, G, P, T

162 mm

6 mm

1325 017 093

Scania 1765061

This figure corresponds to 1325 117 074

Shaft sealing ring

Installation side Left/right

This figure corresponds to 8022 502 436

Suitable for

Outer ∅

Inner ∅

Thickness

Order no

Comparative no

R, G, P, T

100 mm

75 mm

14 mm

8000 117 203

Scania 2057586

R, G, P, T

170 mm

142 mm

16 mm

8000 012 634

Scania 1740992

R, G, P, T

188 mm

158 mm

16 mm

8022 502 436

Scania 1907845

Wheel nut

Thread

7/8" 11BSF

Spanner size 33 mm

Height

26 mm

Surface

phosphated

Suitable for

Order no

Comparative no

R, G, P

2219 001 100

Scania 2285273

Wheel bolt

Suitable for

Thread

Length

Order no

Comparative no

R, G, P

7/8" 11BSF

80,5 mm

2219 001 430

Scania 1368690

R, G, P, T

7/8" 11BSF

81/92 mm

8000 011 455

Scania 1368692

R, G, P

7/8" 11BSF

85/96 mm

2219 001 410

Scania 1368693

R, G, P

7/8" 11BSF

111 mm

2219 001 420

Scania 1368694

R, G, P, T

7/8"-11BSF

82 mm

5832 285 275

Scania 2285275

This figure corresponds to 2219 001 430

ABS ring

Suitable for

Outer ∅

Inner ∅

Thickness

Order no

Comparative no

R, G, P, T

170 mm

126 mm

9 mm

8000 117 165

Scania 1442300

R, G, P, T

188,5 mm

172,5 mm

20 mm

6030 442 296

Scania 1442296

This figure corresponds to 8000 117 165

Installation side Left/right

Axles and steering

| 45

1

 R, G

, P

, T

 Wheel hub

 without bearing

Suitable for

Order no

Comparative no

R, G, P, T

5832 290 532

Scania 2290532

 Axles and steering

 O-ring

Thickness 3 mm

Suitable for

Inner ∅

Order no

Comparative no

R, G, P, T

84 mm

5831 503 399

Scania 1503399

R, G, P, T

225 mm

0132 511 208

Scania 1120873

  This fi gure corresponds to   5831 503 399

 Wheel bearing set

 SmartSET

Version pre-assembled, with permanent lubrication
  Scope  of  supply

 With  mounting  tool

Suitable for

Order no

Comparative no

R, G, P, T

6957 237 009

FAG 723 7009 10

R, G, P, T

6957 237 014

FAG 723 7014 10

46 |

1

 R, G

, P

, T

 Wheel bearing set

Outer ∅ 127 mm

Inner ∅

68 mm

Width

115 mm

  Scope  of  supply

 Compact bearing and sealing ring

Suitable for

Order no

Comparative no

R, G, P, T

8001 531 400

SKF VKBA 5314

 Tapered roller bearing

Height

40 mm

Outer ∅ 147 mm

Inner ∅

90 mm

Suitable for

Order no

Comparative no

R, G, P, T

8012 102 482

Scania 1524625

 (Illustration  similar)

 Tapered roller bearing

Height

40 mm

Outer ∅ 147 mm

Inner ∅

90 mm

Suitable for

Order no

Comparative no

R, G, P, T

8022 102 482

SKF VKHB 2029

 Axles and steering

48 |

1

 R, G

, P

, T

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 37 mm

Outer ∅

430 mm

Suitable for

Order no

Comparative no

R, G, P, T

2090 430 001

Scania 1852817

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 37 mm

Outer ∅

430 mm

 Width of cooling channel 12 mm

Suitable for

Order no

Comparative no

R, G, P, T

3400 810 000

Knorr K000810

 Braking system

 Brake disc

Version

internally ventilated

Thickness

45 mm

Minimum thickness 40 mm

Outer ∅

430 mm

Suitable for

Order no

Comparative no

R, G, P, T

7980 005 025

Meritor MBR5025

 Brake caliper

Suitable for

Type

Order no

Comparative no

R, G, P

SB7202RC

3400 047 081

Knorr K040946K50

R, G, P

SB7212RC

3400 047 080

Knorr K040945K50

R, G, P

SN7203RC

3450 414 766

Knorr K003803

R, G, P

SN7213RC

3450 414 767

Knorr K003804

R, G, P, T

SN7264RC

3450 414 776

Knorr K040953K50

R, G, P, T

SN7274RC

3450 414 777

Knorr K040954K50

  This fi gure corresponds to   3450 414 776

| 49

1

R, G

, P

, T

Brake pad set

Installation location Front axle/rear axle

Brake system

SB/SN 7

WVA no.

29108

Coating length

247,5 mm

Lining width

109,5 mm

Lining thickness

30,00 mm

Scope of supply

With accessories
Splined socket for resetter is not included with pad set. If required, please order 3566180782.

Suitable for

Order no

Comparative no

R, P, T

2323 405 206

Scania 1390428

Braking system

Brake drum

Inner ∅

413 mm

Hole circle ∅

335 mm

Hub ∅

295 mm

Number of holes 10

Installation location

Height

Order no

Comparative no

Front/rear axle

275,5 mm

2090 413 033

Scania 1414153

Rear axle

320 mm

2090 413 014

Scania 360573

This figure corresponds to 2090 413 014
