Scania Truck (2017 year). Spare parts and accessories - 5

66 |

1

 R, G

, P

, T

 Compressed air

 Alternating check valve

Connection 1 M16 x 1.5 reserve

Connection 2 M16 x 1,5 outlet

Suitable for

Order no

Comparative no

R, G, P

3990 001 030

Knorr 295358

 Working cylinder

Connection thread

M12 x 1

Operating pressure max. 12 bar

Stroke

53 mm

Length

180,5 mm

Cylinder length

155 mm

∅

50 mm

Temperature range

-25 to +120 °C

Suitable for

Order no

Comparative no

R, P, T

0114 115 000

WABCO 421 411 500 0

 Working cylinder

Connection thread

M12 x 1,5

Operating pressure 10 bar

Stroke

60 mm

Suitable for

Order no

Comparative no

R, G, P, T

6170 118 675

Scania 1821737

 Brake hose

∅ 12 mm

Suitable for

Length

Order no

Comparative no

R, G, P

600 mm

1325 018 680

Scania 1123476

R, G, P

630 mm

1325 018 682

Scania 1123477

R, G, P

720 mm

1325 018 681

Scania 1123479

R, G, P

500 mm

6170 128 111

Scania 1356151

  This fi gure corresponds to   1325 018 682

| 67

1

R, G

, P

, T

Compressed air

Speed sensor

for ABS/EBS

Scope of supply

With bush

Suitable for

Order no

Comparative no

R, G, P, T

1325 092 051

Scania 1892051

Speed sensor

for ABS/EBS

Version

with cable

Installation side

Left

Cable length

2740 mm

Temperature range -40 to +150 °C

Standard

ISO 20653

Protection class

IP68

Suitable for

Order no

Comparative no

R, G, P, T

1325 189 552

Scania 1892048

Speed sensor

for EBS

Suitable for

Version

Length

Order no

Comparative no

R, G, P, T

straight

1745 mm

1325 092 057

Scania 1892057

R, G, P, T

straight

2675 mm

1325 021 634

Scania 1428452

Scania 1438785

Scania 1428486

Scania 1530705

Scania 1534522

R, G, P

angled

2060 mm

1325 021 628

Scania 1892056

R, G, P, T

angled

2650 mm

1325 021 626

Scania 1892070

This figure corresponds to 1325 092 057

Suitable for

Order no

Comparative no

R, G, P, T

3510 096 330

Scania 1892059

Speed sensor

for ABS/EBS

Length 3400 mm

Speed sensor

for ABS

Suitable for

Version

Length

Order no

Comparative no

R, G, P, T

straight

2780 mm

1325 189 553

Scania 1892050

R, G, P, T

angled

1050 mm

1325 092 062

Scania 1892062

R, G, P, T

angled

1055 mm

1263 001 624

Scania 1892047

R, G, P, T

angled

2740 mm

1325 189 550

Scania 1892053

This figure corresponds to 1325 189 553

68 |

1

 R, G

, P

, T

 Relay

 change-over

 Plastic housing
Voltage

24 V

Number of poles

5

Electric current

20 A

Temperature range -40 to 85 °C

Colour

black

Suitable for

Order no

Comparative no

R, G, P, T

3633 220 420

Bosch 0 986 AH0 615

 Switch

 for split transmission

Thread M18 x 1,5

Suitable for

Order no

Comparative no

R, G, P, T

6000 160 174

Scania 1420005

Scania 1423971

Scania 1472739

 Indicator switch

Switch function

Wipe, wash, fl ash, switch lights

Number of connections 8

Suitable for

Order no

Comparative no

R, G, P, T

5841 542 529

Scania 1542529

Scania 1422111

 Pressure switch

Outer thread

M18 x 1,5/M27 x 1

Spanner size 27 mm

Length

35/44 mm

Material

brass

Suitable for

Order no

Comparative no

R, G, P, T

9460 159 431

Scania 370710

  Application range

 Differential  lock  actuation

 Electrics

 EUROPART – Europe's No. 1 for truck, trailer, van and bus spare parts.

 Fast, easy to use, comprehensive – many
registered customers are benefiting from the
EUROPART Workshop Online System (EWOS).
You can be confi dent of fi nding the products you
need on our online system, and you can order at
anytime, 24 hours a day.
EWOS does so much more: Display your individual
terms and the availability of parts directly and
manage your own fl eet of vehicles based on
part ordering records using EWOS. The EWOS

system also provides access to technical data
and manuals.
The system is accompanied by catalogues with
a  smart search function, linked directly to the
online system, so that you can place your order
quickly and directly.

 Identify the product you need.

Order at anytime.

 The EUROPART Workshop Online System: Browse, fi nd and order the products you need
24 hours a day

70 |

1

 R, G

, P

, T

 Starter Motor

 in exchange

Voltage

24 V

Power

4 kW

Pinion teeth 9

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P

3698 601 128

Bosch 0 986 011 280

 Starter Motor

 in exchange

Voltage

24 V

Power

5,5 kW

Pinion teeth 12

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P, T

3561 381 480

Bosch 0 986 021 480

 Starter Motor

 in exchange

Voltage

24 V

Power

4 kW

Pinion teeth 9

Version

clockwise direction of rotation

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P

0726 253 001

HELLA 8EA 726 253-001

 Starter Motor

 in exchange

Voltage

24 V

Power

6 kW

Version

clockwise direction of rotation

Pinion teeth 12

Flange

3-hole

Suitable for

Order no

Comparative no

R, P, T

3850 022 225

Bosch 0 986 022 250

 Electrics

www.prestolite.co.uk

Original Equipment Quality Starter Motors and Alternators

from an OE Supplier to the

European Truck and Bus & Coach Industries

| 71

1

 R, G

, P

, T

 Starter Motor

Voltage

24 V

Power

6 kW

Version

clockwise direction of rotation

Pinion teeth 11

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P, T

5240 903 545

Prestolite M90R3545SE

 Starter Motor

Voltage

24 V

Power

5,5 kW

Pinion teeth 12

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P, T

7063 002 461

Bosch 0 986 021 480

 Electrics

www.prestolite.co.uk

Original Equipment Quality Starter Motors and Alternators

from an OE Supplier to the

European Truck and Bus & Coach Industries

72 |

1

 R, G

, P

, T

 Alternator

Voltage

24 V

Charging current 100 A

Version

clockwise rotation, with belt pulley

Flange

4-hole

Housing-∅

142 mm

Number of ribs

8

Suitable for

Order no

Comparative no

R, G, P, T

5240 861 079

Prestolite 861079

 Alternator

Voltage

24 V

Charging current 110 A

Version

clockwise rotation, with belt pulley

Housing-∅

154 mm

Number of ribs

8

Suitable for

Order no

Comparative no

R, P, T

5240 860 805

Prestolite 860805GB

 Alternator

Voltage

24 V

Charging current 100 A

Version

with belt pulley

Number of ribs

8

Suitable for

Order no

Comparative no

R, G, P, T

7063 002 117

Bosch 0 986 047 820

 Electrics

| 73

1

 R, G

, P

, T

 Alternator

 as replacement

Voltage

24 V

Charging current 65 A

Version

without belt pulley

Flange

3-hole

Suitable for

Order no

Comparative no

R, G, P

8000 000 677

Bosch 0 986 039 490

 Alternator

 in exchange

Voltage

24 V

Charging current 100 A

Version

with connection for tachometer

Number of ribs

8

Suitable for

Order no

Comparative no

R, G, P, T

0738 211 571

HELLA 8EL 738 211-571

 Electrics

74 |

1

 R, G

, P

, T

 Truck driver's seat

 Kingman Comfort

 Length adjustment 150 mm
  Application  range

 Vehicles with already integrated 3-point belt, without belt pretensioner or vehicles specialised for this

Suitable for

Order no

R

9361 503 150

Description

Order no

Arm rest, left

9361 029 136

Arm rest, right

9361 029 137

Retrofi t set XXL cushion reinforcement up to 160 kg

9360 072 266

 Accessories

  This fi gure corresponds to   9361 029 136

 Cab

 Truck driver's seat

 Automatic weight adjustment with connection to the vehicle compressed air system with permanent

min. 7.5 bar, built-in 3-point safety belt system, adjustable upper belt diverter, height adjustment with memory

function, seat back adjustment, shoulder adjustment, lean and horizontal settings, adjustable vertical movement

damper, on/off horizontal springing, adjustable seat cushion depth, integrated pneumatic system (IPS) for

adjustment of backrest to individual body contour (lumbar support and adjustable side support), rapid lowering,

grey/anthracite seat covering with fi ne silver coloured stripes
Version

comfort, operable on the left, with seat air-conditioning

Suspension pneumatic

Track width

216 mm

Suitable for

Order no

R, P (08/2003-)

9368 972 401

 (Illustration  similar)

Description

Version

Order no

Arm rest, left

luxury with textile cover

9360 707 413

Arm rest, right

luxury with textile cover

9360 707 313

Arm rest, left

standard

9369 296 511

Arm rest, right

standard

9369 296 521

 Accessories

 It is not permitted to use this item in vehicles with air bag systems, seat belt pretensioners and belt lock

sensors!

Armrests must be ordered separately.

Not suitable for drivers < 175 cm!

 6860/875 NTS

| 75

1

R, G

, P

, T

Storage table

Installation side right

Colour

black

Suitable for

Order no

R

1002 010 726

Storage table

with non-slip mat

Installation side right

Colour

walnut effect wood finish

Suitable for

Order no

R

1002 010 728

Storage table

Installation side centre

Colour

walnut effect wood finish

Suitable for

Order no

R

1002 010 727

Cab

Shock absorber

for seat adjustment

Version

oil pressure, twin-tube system

Fastening eye/eye

Suitable for

Order no

Comparative no

R, G, P, T

6421 034 108

Scania 1498862

Storage table

Installation location passenger side

Installation side

right

Colour

walnut effect wood finish

Material

poplar laminated wood

Suitable for

Order no

R

1002 010 210

76 |

1

 R, G

, P

, T

 Cab

 Wiper rods

Suitable for

Installation side

Order no

Comparative no

R, G, P, T (-2007)

left

8000 002 019

Scania 1525888

R, G, P, T (-2007)

right

8000 002 017

Scania 1525890

 Storage table

 with non-slip mat

Installation location bottom

Installation side

right

Colour

black

Material

poplar laminated wood

Suitable for

Order no

R

1002 010 723

 Storage table

 with non-slip mat

Installation location bottom

Installation side

right

Colour

walnut effect wood fi nish

Material

poplar laminated wood

Suitable for

Order no

R

1002 010 724

 Wiper rods

Length 766 mm
  Application  range

 for  RHD

Suitable for

Order no

Comparative no

R, P, T (-2007)

3600 134 500

Scania 1525889

| 77

1

 R, G

, P

, T

 Wiper motor

Voltage 24 V

Suitable for

Order no

Comparative no

R, G, P, T (-2007)

8000 012 017

Scania 1392755

 Wiper blade

Length 700 mm
  Scope  of  supply

 With  4  adapters

 (Illustration  similar)

Suitable for

Order no

Comparative no

R, P, T (2004-)

7257 002 110

SWF 132.704

 Cab

 Wiper arm

Suitable for

Order no

Comparative no

R, G, P, T

8000 011 950

Scania 1864620

 Wiper bearing

Installation location front

Thread

M10

Suitable for

Installation side

Order no

Comparative no

R, G, P, T (-2007)

left

8000 002 016

Scania 1525891

R, G, P, T (-2007)

right

8000 002 015

Scania 1525892

78 |

1

 R, G

, P

, T

 Wiper blade

 with plug-in and threaded connection

Length 700 mm

Suitable for

Order no

Comparative no

R, P, T (2004-)

9790 000 017

SWF 132.704

 Washer fl uid pump

Version dual outlet pump, electric

Voltage 24 V

Suitable for

Order no

Comparative no

R, G, P, T (-2009)

5234 856 032

Scania 1722690

 Washer fl uid pump

Version electric

Voltage 24 V

Suitable for

Order no

Comparative no

R, G, P, T (-2009)

9800 122 086

Scania 1548504

 Cab

 Wiper blade

 with plug connection

Version with integrated washer nozzle

Length

700 mm

Suitable for

Order no

Comparative no

R, G, P, T

7920 132 705

SWF 132.705

| 79

1

 R, G

, P

, T

 Window winder

Suitable for

Version

Installation side

Order no

Comparative no

R, G, P, T

without motor

Left

3870 851 088

Valeo 851088

R, G, P, T

without motor

Right

3870 851 089

Valeo 851089

R, G, P, T

with motor

Left

3870 851 086

Valeo 851086

R, G, P, T

with motor

Right

3870 851 087

Valeo 851087

  This fi gure corresponds to   3870 851 086

 Electric motor

 for window winder

Installation side left

Suitable for

Order no

Comparative no

R, G, P, T

6170 003 499

Scania 2303350

 Cab

 Window winder

Version without motor

Width

52 cm

Height

26,5 cm

Depth

6 cm

Suitable for

Order no

Comparative no

R, G, P, T

8000 012 729

Scania 2303349

 Heater Motor

 for interior

Voltage 24 V

Suitable for

Order no

Comparative no

R, G, P, T (03/2008-)

8001 854 876

Scania 2195206

80 |

1

 R, G

, P

, T

 Evaporator

 for air-conditioning

 Refrigerant R 134a
Material Aluminium

Length

350 mm

Width

190 mm

Depth

48 mm

  Scope  of  supply

 Without  pipe  connector

Suitable for

Order no

Comparative no

R, G, P

9102 720 050

Dasis 272005N

Length 453 mm

Width

157 mm

Depth

32 mm

 Grid dimensions 453 x 157 x 32 mm
  Application  range

 Vehicles with/without air-conditioning system

Suitable for

Order no

Comparative no

R, G, P, T

8000 012 853

Dasis 279001N

 Heat exchanger

 for interior heating

 Cab

 Evaporator

 for air-conditioning

 Refrigerant R 134a
Length 510 mm

Width

228 mm

Depth

68 mm

Suitable for

Order no

Comparative no

R, G, P, T (-2008)

9108 202 670

Dasis 820267N

 Heat exchanger

 HVAC-edition2, for interior heating

Suitable for

Order no

Comparative no

R, G, P

5831 772 717

Scania 1772717

Length 426 mm

Width

182 mm

Depth

26 mm

| 81

1

 R, G

, P

, T

 Cab

 Air-conditioning compressor

Manufacturer's restriction Sanden

Voltage

24 V

Connection

Ear mounting

Pulley ∅

120 mm

Number of ribs

10

Suitable for

Order no

Comparative no

R, G, P

0351 119 381

Dasis 850626N

 Air-conditioning compressor

Manufacturer's restriction Sanden

Voltage

24 V

Pulley ∅

119 mm

Number of ribs

8

Suitable for

Order no

Comparative no

R, G, P, T

9100 850 749

HELLA 8FK 351 134-821

 Air-conditioning compressor

Manufacturer's restriction Sanden

Voltage

24 V

Connection

PAD

Pulley ∅

119 mm

Number of ribs

8

Suitable for

Order no

Comparative no

R, G, P

0351 135 481

HELLA 8FK 351 135-481

 Condenser

 for air-conditioning

Version without dryer

Length

706 mm

Width

373 mm

Depth

17 mm

Suitable for

Order no

Comparative no

R, G, P, T

0351 307 361

HELLA 8FC 351 307-361
