SCANIA industrial engines
dC13 077a. 331 kW (450 hp)
eu stage iiiB
Standard equipment
• Scania Engine Management System, EMS
• Extra high pressure fuel injection system, XPI
• Turbocharger
• Fuel filter and extra pre-filter with water
separator
• Fuel heater
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in block
• Oil filler, in valve cover
• Deep front oil sump
• Oil dipstick, in block
• Magnetic drain plug for oil draining
• Starter, 1-pole 5.5 kW
• Alternator, 1-pole 100A
• Flywheel, for use with friction clutch
• Silumin flywheel housing, SAE 1 flange
• Front mounted engine brackets
• SCR system
• Open crankcase ventilation
• Operator’s manual
Optional equipment
• Cooling package
• Puller and pusher fans
• Fan ring with sealing
• Hydraulic pump
• Air compressor
• AC compressor
• Side-mounted PTO
• Front-mounted PTO
• Exhaust connections
• Electrical base system
• Control and instrument panels
• Accelerator position sensor
• Engine heater
• Flywheels: SAE11.5”, SAE14”, DANA15/16”,
ZF WG260
• Stiff rubber engine suspension
• Air cleaner
• Closed crankcase ventilation
• Studs in flywheel housing
• External thermostat for extra oil cooler
• Low coolant level reaction
• Variable idle speed setting
• Low oil sump
• Oil level sensor
The industrial engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easily be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes repairability and fuel
economy.
The engine is equipped with a Scania developed Engine Management System,
EMS, in order to ensure the control of all aspects related to engine performance.
The injection system is Scania’s XPI (Extra High Pressure Injection), a common rail
system that in combination with SCR (Selective Catalytic Reduction) gives low exhaust
emissions with good fuel economy and a high torque. The engine can be fitted with
many accessories such as air cleaners, silencers, PTOs and flywheels in order to suit
a variety of installations.
This specification may be revised without notice.
Engine speed (rpm)
Rating
1200
1500
1800
2100
Gross power (kW)
ICFN
283
331
331
331
Gross power (hp)
ICFN
385
450
450
450
Gross torque (Nm)
ICFN
2252
2107
1756
1505
Spec fuel consumption. Full load (g/kWh)
188
194
199
210
Spec fuel consumption. 3/4 load (g/kWh)
190
191
199
215
Spec fuel consumption. 1/2 load (g/kWh)
194
194
205
228
Reductant consumption. Full load (g/kWh)
18
15
15
14
Heat rejection to coolant (kW)
99
100
99
113
ICFN – Continuous service: Rated output available 1/1 h.
Unlimited h/year service time at a load factor of 100%
