SCANIA INDUSTRIAL ENGINES (specification) - part 3
SCANIA INDUSTRIAL ENGINES
DC13 076A. 294 kW (400 hp)
EU Stage IIIA, China Phase III, India Bharat Stage III and Brazil MAR-I
Standard equipment
• Scania Engine Management System, EMS
• Unit injectors, PDE
• Turbocharger
• Saver ring in cylinder liner
• Fuel filter and extra pre-filter
with water separator
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in cylinder block
• Oil filler, in valve cover
• Deep front oil sump
• Oil dipstick, in cylinder block
• Magnetic drain plug for oil draining
• Starter motor, 1-pole 6.0 kW
• Alternator, 1-pole 100 A
• Flywheel, for use with friction clutch
• Silumin flywheel housing, SAE 1 flange
• Front mounted engine suspension
• Open crankcase ventilation
Optional equipment
• Cooling package
• Puller and pusher fans
• Fan ring with sealing
• Hydraulic pump
• Air compressor
• AC compressor
• Side-mounted PTO
• Front-mounted PTO
• Exhaust connections
• Engine heater
• Flywheels SAE11.5”, SAE14”, DANA15/16”,
DANA17” flexplate, ZF WG260
• Stiff rubber engine suspension
• Air cleaner
• Closed crankcase ventilation
• Studs in flywheel housing
• External thermostat for extra oil cooler
• Coolant level sensor
• Oil level sensor
• Low oil sump
The industrial engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easily be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes reparability and fuel
economy.
The engine is equipped with a Scania developed Engine Management System, EMS,
in order to ensure the control of all aspects related to engine performance.
The injection system is based on electronically controlled unit injectors that give low
exhaust emissions with good fuel economy and a high torque. The engine can be fit-
ted with many accessories such as air cleaners, PTOs and flywheels in order to suit a
variety of installations.
This specification may be revised without notice.
Engine speed (rpm)
1200
1500
1800
2100
Gross power (kW)
229
291
294
294
Gross power (hp, metric)
311
396
400
400
Gross torque (Nm)
1822
1853
1560
1337
Spec fuel consumption. Full load (g/kWh)
183
204
215
232
Spec fuel consumption. 3/4 load (g/kWh)
193
212
227
248
Spec fuel consumption. 1/2 load (g/kWh)
199
218
240
270
Heat rejection to coolant (kW)
68
88
91
105
Rating: ICFN – Continuous service: Rated output available 1/1 h.
Unlimited h/year service time at a load factor of 100%
