SCANIA INDUSTRIAL ENGINES
DC13 091A. 257 kW (350 hp)
Fuel optimized
Standard equipment
• Scania Engine Management System, EMS
• Unit injectors, PDE
• Turbocharger
• Saver ring in cylinder liner
• Fuel filter and extra pre-filter
with water separator
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in cylinder block
• Oil filler, in valve cover
• Deep front oil sump
• Oil dipstick, in cylinder block
• Magnetic drain plug for oil draining
• Starter motor, 1-pole 6.0 kW
• Alternator, 1-pole 100 A
• Flywheel, for use with friction clutch
• Silumin flywheel housing, SAE 1 flange
• Front mounted engine suspension
• Open crankcase ventilation
Optional equipment
• Cooling package
• Puller and pusher fans
• Fan ring with sealing
• Hydraulic pump
• Air compressor
• AC compressor
• Side-mounted PTO
• Front-mounted PTO
• Exhaust connections
• Engine heater
• Flywheels SAE11.5”, SAE14”, DANA15/16”,
DANA17” flexplate, ZF WG260
• Stiff rubber engine suspension
• Air cleaner
• Closed crankcase ventilation
• Studs in flywheel housing
• External thermostat for extra oil cooler
• Coolant level sensor
• Oil level sensor
• Low oil sump
The industrial engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easily be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes reparability and fuel
economy.
The engine is equipped with a Scania developed Engine Management System, EMS,
in order to ensure the control of all aspects related to engine performance.
The injection system is based on electronically controlled unit injectors, which
provide good fuel economy and a high torque. The engine can be fitted with many ac-
cessories such as air cleaners, PTOs and flywheels in order to suit a variety
of installations.
This specification may be revised without notice.
Engine speed (rpm)
1200
1500
1800
2100
Gross power (kW)
245
257
257
257
Gross power (hp)
333
350
350
350
Gross torque (Nm)
1950
1636
1363
1169
Spec fuel consumption. Full load (g/kWh)
183
183
192
206
Spec fuel consumption. 3/4 load (g/kWh)
184
187
197
216
Spec fuel consumption. 1/2 load (g/kWh)
190
195
212
237
Heat rejection to coolant (kW)
85
86
93
101
Rating: ICFN – Continuous service: Rated output available 1/1 h.
Unlimited h/year service time at a load factor of 100%
Note: Only available in the SLA market
