CHILD SAFETY REAR DOOR LOCK

SPA2037

The child safety rear door locks help prevent rear doors
from being opened accidentally, especially when small
children are in the vehicle.

When the levers are in the lock position

, the child

safety rear door locks engage and the rear doors can
only be opened by the outside door handles.

To disengage, move the levers to the unlock position

The remote keyless entry system can operate all door
locks (including the back door) using the remote
controller. The remote controller can operate at a
distance of approximately 1 m (3.3 ft) away from the
vehicle. The operating distance depends upon the
conditions around the vehicle.

As many as 5 remote controllers can be used with one
vehicle. For information about the purchase and use of
additional remote controllers, contact a RENAULT
dealer.

The remote controller will not function under the
following conditions:
.

When the distance between the remote controller
and vehicle is more than approximately 1 m (3.3
ft).

When the remote controller battery is discharged.

When the key is in the ignition switch.

CAUTION:

When locking the doors using the remote
controller, be sure not to leave the key in the
vehicle.

Do not allow the remote controller, which
contains electrical components, to come
into contact with water or salt water. This
could affect the system function.

Do not drop the remote controller.

Do not strike the remote controller sharply
against another object.

Do not place the remote controller for an
extended period in an area where tempera-
tures exceed 60

8C (1408F).

When the outside temperature is extremely
low, the remote keyless entry system may

not function properly.

If a remote controller is lost or stolen, RENAULT
recommends erasing the ID code of that remote
controller from the vehicle. This may prevent the
unauthorized use of the remote controller to unlock
the vehicle. For information regarding the erasing
procedure, contact a RENAULT dealer.

For information regarding the replacement of a battery,
see “Remote controller battery” (P.8-24).

USING REMOTE KEYLESS ENTRY SYSTEM
(if equipped)

JVP0213X

Type A (with panic alarm)

LOCK button

UNLOCK button

PANIC button

Battery indicator light

Pre-driving checks and adjustments

3-7

REMOTE KEYLESS ENTRY SYSTEM

(if equipped)

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-8

Pre-driving checks and adjustments

JVP0222X

Type B (without panic alarm)

LOCK button

UNLOCK button

Battery indicator light

Locking doors

Remove the key from the ignition switch.

Close all doors including the back door.

Push the “LOCK”

button

on the remote

controller.

All doors will be locked.

Operate door handles to confirm that the doors
have been securely locked.

CAUTION:

After locking the doors using the remote con-
troller, be sure that the doors have been securely
locked by operating the door handles.

Unlocking doors

Push the “UNLOCK”

button

on the

remote controller.

All doors including the back door will be unlocked.

All doors will be locked automatically unless one of the
following operations is performed within 30 seconds
after pushing the “UNLOCK”

button

on the

remote controller while the doors are locked.

If during this 30-second time period, the “UNLOCK”
button on the remote controller is pushed, all doors will
be locked automatically after another 30 seconds.
.

Opening any doors.

Inserting the key into the ignition switch.

Selecting door unlock mode (if equipped):
When you first receive the vehicle, the door unlock
mode is set to unlock all the doors with one push of the
“UNLOCK”

button

. The door unlock mode

can be switched to the selective door unlock mode,
which unlocks the passenger’s doors at the second
push of the “UNLOCK”

button

Selective door unlock mode:

Push the “UNLOCK”

button

on the

remote controller.

The driver’s door unlocks.

Push the “UNLOCK”

button

on the

remote controller again.

All doors will be unlocked.

To switch to the selective door unlock mode, perform
the following procedure.

Push the “LOCK”

and “UNLOCK”

buttons

simultaneously for more than 5 seconds.

Perform the same procedure to deactivate the
selective door unlock mode.

When the selective door unlock mode is set, the
hazard indicator flashes 3 times.

When the all door unlock mode is set, the hazard
indicator flashes once.

Using panic alarm (if equipped)

If you are near your vehicle and feel threatened, you
may activate the alarm to call attention as follows:

Push the “PANIC”

button

on the

Intelligent Key for more than 0.5 second.

The theft warning alarm will stay on for 25
seconds.

The panic alarm stops when:

It has run for 25 seconds, or

Any of the buttons on the Intelligent Key are
pushed. (Note: Panic button should be pushed for
more than 0.5 second.)

Battery indicator light

The battery indicator light

(Type A) or

(Type B)

illuminates when you push any button. If the light does
not illuminate, the battery is weak or needs replace-
ment. For information regarding replacement of a
battery, see “Remote controller battery” (P.8-24).

Hazard indicator operation

When you lock or unlock the doors, the hazard
indicator will flash as a confirmation.
.

“LOCK”: The hazard indicator flashes once.

“UNLOCK”: The hazard indicator flashes twice.

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

SPA2406

Type A (with panic alarm)

SPA2502

Type B (without panic alarm)

Intelligent Key (2)

Mechanical key (inside the Intelligent Key) (2)

Key number plate

WARNING:

Radio waves could adversely affect electric
medical equipment. Those who use a pace-
maker should contact the electric medical
equipment manufacturer for the possible
influences before use.

The Intelligent Key transmits radio waves
when the buttons are pushed. The radio

waves may affect aircraft navigation and
communication systems. Do not operate the
Intelligent Key while on an airplane. Make
sure the buttons are not operated uninten-
tionally when the unit is stored during a
flight.

The Intelligent Key system can operate all the door
(including the back door) locks using the remote
controller function or pushing the request switch on
the vehicle without taking the key out from a pocket or
purse. The operating environment and/or conditions
may affect the Intelligent Key system operation.

Be sure to read the following before using the
Intelligent Key system.

CAUTION:

Be sure to carry the Intelligent Key with you
when operating the vehicle.

Never leave the Intelligent Key in the vehicle
when you leave the vehicle.

When the outside temperature is extremely
low, the Intelligent Key system may not
function properly.

The Intelligent Key is always communicating with the
vehicle as it receives radio waves. The Intelligent Key
system transmits weak radio waves. Environmental
conditions may interfere with the operation of the
Intelligent Key system under the following operating
conditions.
.

When operating near a location where strong
radio waves are transmitted, such as a TV tower,
power station and broadcasting station.

When in possession of wireless equipment, such
as a cellular telephone, transceiver, and CB radio.

When the Intelligent Key is in contact with or
covered by metallic materials.

When any type of radio wave remote control is
used nearby.

When the Intelligent Key is placed near an electric
appliance such as a personal computer.

When the vehicle is parked near a parking meter.

In such cases, correct the operating conditions before
using the Intelligent Key function or use the mechanical
key.

Although the life of the battery varies depending on the
operating conditions, the battery’s life is approximately
2 years. If the battery is discharged, replace it with a
new one.

For information regarding replacement of a battery, see
“Intelligent key battery” (P.8-25).

Since the Intelligent Key is continuously receiving radio
waves, if the key is left near equipment which transmits
strong radio waves, such as signals from a TV and
personal computer, the battery life may become
shorter.

To start the engine when the Intelligent Key battery is
discharged, see “Push-button ignition switch (model
with Intelligent Key system)” (P.5-6). Replace the
discharged battery with a new one as soon as
possible.

Because the steering wheel is locked electrically,
unlocking the steering wheel with the ignition switch in
the “LOCK” position is impossible when the vehicle
battery is completely discharged. In this case, unlock-
ing the steering wheel would be also impossible. Pay
special attention that the vehicle battery is not
completely discharged.

As many as 4 Intelligent Keys can be used with one
vehicle. For information about the purchase and use of
additional Intelligent Keys, contact a RENAULT dealer.

Pre-driving checks and adjustments

3-9

INTELLIGENT KEY SYSTEM (if

equipped)

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-10

Pre-driving checks and adjustments

CAUTION:

Do not allow the Intelligent Key, which
contains electrical components, to come
into contact with water or salt water. This
could affect the system function.

Do not drop the Intelligent Key.

Do not strike the Intelligent Key sharply
against another object.

Do not change or modify the Intelligent Key.

Wetting may damage the Intelligent Key. If
the Intelligent Key gets wet, immediately
wipe until it is completely dry.

If the outside temperature is below

í108C

(14

8F), the battery of the Intelligent Key may

not function properly.

Do not place the Intelligent Key for an
extended period in an area where tempera-
tures exceed 60

8C (1408F).

Do not attach the Intelligent Key with a key
holder that contains a magnet.

Do not place the Intelligent Key near equip-
ment that produces a magnetic field, such as
a TV, audio equipment and personal compu-
ters or cellular phones.

If an Intelligent Key is lost or stolen, RENAULT
recommends erasing the ID code of that Intelligent
Key from the vehicle. This may prevent the unauthor-
ized use of the Intelligent Key to operate the vehicle.
For information regarding the erasing procedure,
contact a RENAULT dealer.

The Intelligent Key function can be disabled. For
information about disabling the Intelligent Key function,
contact a RENAULT dealer.

OPERATING RANGE

SPA2038

The Intelligent Key functions can only be used when
the Intelligent Key is within the specified operating
range from the request switch

When the Intelligent Key battery is discharged or
strong radio waves are present near the operating
location, the Intelligent Key system’s operating range
becomes narrower, and the Intelligent Key may not
function properly.

The operating range is within 80 cm (31.50 in) from
each request switch

If the Intelligent Key is too close to the door glass,
handle or rear bumper the request switches may not
function.

When the Intelligent Key is within the operating range,
it is possible for anyone, even someone who does not
carry the Intelligent Key, to push the request switch
and lock/unlock the doors.

USING INTELLIGENT KEY SYSTEM

JVP0088X

The request switch will not function under the following
conditions:
.

When the Intelligent Key is left inside the vehicle

When the Intelligent Key is not within the
operational range

When any door is open or not closed securely

When the Intelligent Key battery is discharged

When the ignition switch is in the “ACC” or “ON”
position

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

SPA2407

Do not push the door handle request switch with
the Intelligent Key held in your hand as illustrated.
The close distance to the door handle will cause
the Intelligent Key system to have difficulty
recognizing that the Intelligent Key is outside the
vehicle.

After locking the doors using the door handle
request switch, make sure that the doors have
been securely locked by operating the door
handles.

When locking the doors using the door handle
request switch, make sure to have the Intelligent
Key in your possession before operating the door
handle request switch to prevent the Intelligent
Key from being left in the vehicle.

The door handle request switch is operational only
when the Intelligent Key has been detected by the
Intelligent Key system.

Do not pull the door handle before pushing the
door handle request switch. The door will be
unlocked but will not open. Release the door
handle once and pull it again to open the door.

Request switch locations

JVP0095X

JVP0089X

When you carry the Intelligent Key with you, you can
lock or unlock all doors by pushing the door handle
request switch (driver’s or front passenger’s)

back door request switch

within the range of

operation.

When you lock or unlock the doors, the hazard
indicator will flash as a confirmation.

Locking doors

Push the ignition switch to the “OFF” position.

Carry the Intelligent Key with you.

Close all doors.

Push the door handle request switch

(driver’s

or front passenger’s) or the back door request
switch

All doors and the back door will be locked.

The hazard indicator flashes once.

Operate door handles to confirm that the doors
have been securely locked.

Lockout protection:
To prevent the Intelligent Key from being accidentally
locked in the vehicle, lockout protection is equipped
with the Intelligent Key system.
.

When the Intelligent Key is left in the vehicle and
you try to lock the door using the driver’s inside
lock knob after getting out of the vehicle, all the
doors will unlock automatically and a chime will
sound after the door is closed.

When the Intelligent Key is left in the vehicle while
the driver’s door is opened and you try to lock the
door using the power door lock switch after
getting out of the vehicle, an inside warning chime
will sound after the power door lock switch or the
driver’s inside lock knob is operated.

CAUTION:

The lockout protection may not function under
the following conditions:

When the Intelligent Key is placed on top of
the instrument panel.

Pre-driving checks and adjustments

3-11

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-12

Pre-driving checks and adjustments

When the Intelligent Key is placed inside of
the glove box.

When the Intelligent Key is placed inside of
the door pockets.

When the Intelligent Key is placed on or
under the spare tire area.

When the Intelligent Key is placed inside or
near metallic materials.

The lockout protection may function when the
Intelligent Key is outside the vehicle but is too
close to the vehicle.

Unlocking doors

All door unlock:
1.

Carry the Intelligent Key with you.

Push the door handle request switch

or back

door request switch

All doors and the back door will be unlocked.

The hazard indicator flashes twice.

If a door handle is pulled while unlocking the doors,
that door may not be unlocked. Returning the door
handle to its original position will unlock the door. If the
door does not unlock, after returning the door handle,
push the door handle request switch to unlock the
door.

Selective door unlock mode:
1.

Carry the Intelligent Key with you.

Push the door handle request switch (driver’s or
front passenger’s)

or back door request

switch

The corresponding door will be unlocked.

Push the door handle request switch (driver’s or
front passenger’s)

or back door request

switch

again within 5 seconds.

All doors will be unlocked.

Switching door unlock mode (if equipped):
To switch the door unlock mode from one to another,
see “Using remote keyless entry system” (P.3-7).

Automatic relock:
All doors will be locked automatically unless one of the
following operations is performed within 30 seconds
after pushing the request switch while the doors are
locked.
.

Opening any doors.

Pushing the ignition switch.

If during the preset time period the “UNLOCK”
button on the Intelligent Key is pushed, all doors will be
locked automatically after the next preset time.

BATTERY SAVER SYSTEM

When all the following conditions are met for a period
of time, the battery saver system will cut off the power
supply to prevent battery discharge.
.

The ignition switch is in the “ACC” position, and

All doors are closed, and

The selector lever is in the “P” (Park) position
(Automatic transmission/Continuously Variable
Transmission model).

WARNING AND AUDIBLE REMINDERS

The Intelligent Key system is equipped with a function
that is designed to minimize improper operations of the
Intelligent Key and to help prevent the vehicle from
being stolen.

Type A (model with vehicle information dis-
play)

The warning buzzer sounds and the warning display
appears on the dot matrix display (in the vehicle
information display) when improper operations are
detected. See the troubleshooting guide on the next
page. For warning and indicators on the vehicle
information display, see “Vehicle information display”
(P.2-20).

CAUTION:

When the buzzer sounds and the warning
display appears, be sure to check both the
vehicle and the Intelligent Key.

Type B (model without dot matrix display)

A chime or beep sounds inside and outside the vehicle
and a warning light illuminates or blinks.

See the troubleshooting guide on the next page and
“Warning/indicator lights and audible reminders” (P.2-
12).

Intelligent Key system warning light:

P position selecting warning light:

CAUTION:

When the chime or beep sounds or the warning
light illuminates or blinks, be sure to check both
the vehicle and the Intelligent Key.

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

TROUBLE SHOOTING GUIDE

Symptom

Possible cause

Action to take

When pushing the ignition switch to stop
the engine

Type A: The SHIFT P warning appears on
the display and the inside warning chime
sounds continuously or for a few sec-
onds.
Type B: The P position selecting warning
light in the meter and the inside warning
chime sounds continuously (Automatic
Transmission and Continuously Variable
Transmission models).

The selector lever is not in the “P” (Park)
position.

Shift the selector lever to the “P” (Park)
position.

When shifting the selector lever to the P
(Park) position. (Automatic Transmission
and Continuously Variable Transmission
models)

The inside warning chime sounds con-
tinuously.

The ignition switch is in the “ACC” or
“ON” position.

Push the ignition switch to the “OFF”
position.

When opening the driver’s door to get
out of the vehicle

The inside warning chime sounds con-
tinuously.

The ignition switch is in the “ACC”
position.

Push the ignition switch to the “OFF”
position.

When closing the door after getting out
of the vehicle

Type A: The NO KEY warning appears on
the display, the outside chime sounds 3
times and the inside warning chime
sounds for a few seconds.
Type B: The Intelligent Key system
warning light in the meter blinks in yellow,
the outside chime sounds 3 times and
the inside warning chime sounds for a
few seconds.

The ignition switch is in the “ACC” or
“ON” position.

Push the ignition switch to the “OFF”
position.

Type A: The SHIFT P warning appears on
the display and the outside chime sounds
continuously.
Type B: The P position selecting warning
light in the meter illuminates and the
outside chime sounds continuously
(Automatic Transmission and Continu-
ously Variable Transmission models).

The ignition switch is in the “ACC” or
“OFF” position and the selector lever is
not in the “P” (Park) position.

Move the selector lever to the “P” (Park)
position and push the ignition switch to
the “OFF” position.

Pre-driving checks and adjustments

3-13

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-14

Pre-driving checks and adjustments

Symptom

Possible cause

Action to take

When pushing the request switch or the
“LOCK”

button on the Intelligent

Key to lock the door

The outside chime sounds for a few
seconds and all the doors unlock.

The Intelligent Key is inside the vehicle.

Carry the Intelligent Key with you.

The ignition switch is in the “ACC” or
“ON” position.

Push the ignition switch to the “OFF”
position.

A door is not closed securely.

Close the door securely.

When pushing the door handle request
switch to lock the door

The outside chime sounds for a few
seconds.

The Intelligent Key is inside the vehicle.

Carry the Intelligent Key with you.

A door is not closed securely.

Close the door securely.

When pushing the ignition switch to start
the engine

Type A: The Intelligent Key battery
indicator appears on the display.
Type B: The Intelligent Key system
warning light in the meter blinks in green.

The battery charge is low.

Replace the battery with a new one. (See
“Battery” (P.8-23).)

Type A: The NO KEY warning appears on
the display and the inside warning chime
sounds for a few seconds.
Type B: The Intelligent Key system
warning light in the meter blinks in yellow
and the inside warning chime sounds for
a few seconds.

The Intelligent Key is not in the vehicle.

Carry the Intelligent Key with you.

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

USING REMOTE KEYLESS ENTRY FUNC-
TION

Operating range

SPA2252

Type A (with panic alarm)

SPA2045

Type B (without panic alarm)

It is possible to lock/unlock all doors including the back
door using the remote keyless entry system. The
operating distance depends upon the conditions
around the vehicle. To securely operate the lock and
unlock buttons, approach the vehicle to about 1 m (3.3
ft) from the door.

The remote keyless entry system will not function under
the following conditions:

When the Intelligent Key is not within the
operational range.

When the Intelligent Key battery is discharged.

For information regarding the replacement of a battery,
see “Battery” (P.8-23).

Locking doors

When you lock or unlock the doors including the back
door, the hazard indicator will flash as a confirmation.

Place the ignition switch in the “OFF” position and
carry the Intelligent Key.

Close all doors (including the back door).

Push the “LOCK”

button

on the

Intelligent Key.

All doors will be locked.

Operate the door handles to confirm that the
doors have been securely locked.

CAUTION:

After locking the doors using the Intelligent Key,
be sure that the doors have been securely
locked by operating the door handles.

Unlocking doors

Push the “UNLOCK”

button

on the

Intelligent Key.

All doors (including the back door) will be
unlocked.

All doors will be locked automatically unless one of the
following operations is performed within 30 seconds
after pushing the “UNLOCK”

button on the

Intelligent Key while the doors are locked. If during this
30-second time period, the “UNLOCK”

button on

the Intelligent Key is pushed, all doors will be locked
automatically after another 30 seconds.

Opening any door or back door.

Pushing the ignition switch.

Selecting door unlock mode (if equipped):
When you first receive the vehicle, the door unlock
mode is set to unlock all the doors with one push of the
“UNLOCK”

button

. The door unlock mode

can be switched to the selective door unlock mode,
which unlocks the passenger’s doors at the second
push of the “UNLOCK”

button

Selective door unlock mode:

Push the “UNLOCK”

button

on the

Intelligent Key.

The driver’s door unlocks.

Push the “UNLOCK”

button

on the

Intelligent Key again.

All doors will be unlocked.

To switch to the selective door unlock mode, perform
the following procedure.

Push the “LOCK”

and “UNLOCK”

buttons

simultaneously for more than 5 seconds. Perform the
same procedure to deactivate the selective door
unlock mode.
.

When the selective door unlock mode is set, the
hazard indicator flashes 3 times.

When the all door unlock mode is set, the hazard
indicator flashes once.

Pre-driving checks and adjustments

3-15

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-16

Pre-driving checks and adjustments

Using panic alarm (if equipped)

If you are near your vehicle and feel threatened, you
may activate the alarm to call attention as follows:

Push the “PANIC”

button

on the

Intelligent Key for more than 0.5 second.

The theft warning alarm will stay on for 25
seconds.

The panic alarm stops when:

It has run for 25 seconds, or

Any of the buttons on the Intelligent Key are
pushed. (Note: Panic button should be pushed for
more than 0.5 second.)

Hazard indicator operation

When you lock or unlock the doors, the hazard
indicator will flash as a confirmation.
.

“LOCK”: The hazard indicator flashes once.

“UNLOCK”: The hazard indicator flashes twice.

Your vehicle is equipped with either or both of the
following security systems:
.

Theft warning system

Anti-Theft System*

(* immobilizer)

The security condition will be shown by the security
indicator light.

THEFT WARNING SYSTEM

The theft warning system provides visual and audio
alarm signals if parts of the vehicle are disturbed.

Security indicator light

SIC2045

The security indicator light is located in the meter
panel.

This light operates whenever the ignition switch is in
the “ACC”, “OFF” or “LOCK” position. This is normal.

How to activate the system:
1.

Close all windows and push the ignition switch to
the “OFF” position.

The system can be activated even if the
windows are open.

Carry the Intelligent Key with you and get out of
the vehicle.

Make sure the hood is closed. Close and lock all
doors with the door handle request switch, LOCK

button

on the Intelligent Key (If the door

is locked using the inside lock knob, the system
will not be activated) or power door lock switch (If
the door is locked using the power door lock
switch with all the doors closed, the system will
not be activated. To activate the system, lock the
door using the power door lock switch with any of
the doors open, then close all the doors).

Confirm that the security indicator light comes on.
The security indicator light stays on for approxi-
mately 30 seconds. The vehicle security system is
now pre-armed. After approximately 30 seconds
the vehicle security system automatically shifts
into the armed phase. The security light begins to
flash once every approximately 3 seconds.

If, during this 30-second pre-arm time period, the
door is unlocked with the door handle request
switch, the “UNLOCK”

button

on the

Intelligent Key, the power door lock switch, or the
ignition switch is pushed to the “ACC” or “ON”
position, the system will not arm.

Even when the driver and/or passengers are in
the vehicle, the system will activate with all
doors locked and ignition switch in the

“LOCK”

position. Push the ignition switch to the

“ACC” or

“ON” position to turn the system off.

Theft warning system operation:
The warning system will give the following alarm:
.

The hazard indicator blinks and the horn sounds
intermittently for approximately 30 seconds.

SECURITY SYSTEM (if equipped)

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

The alarm automatically turns off after approxi-
mately 30 seconds. However, the alarm reacti-
vates if the vehicle is tampered with again.

The alarm is activated by:
.

Operating the door without using the Intelligent
Key system.

Opening the hood.

How to stop alarm:
.

The alarm will stop by unlocking a door with the
door handle request switch or “UNLOCK”
button

on the Intelligent Key.

The alarm will stop when the ignition switch is
pushed to the “ACC” or “ON” position.

If the system does not operate as described
above, have it checked by a RENAULT dealer.

ANTI-THEFT SYSTEM

The Anti-Theft System will not allow the engine to start
without the use of the registered Anti-Theft System
key.

If the engine does not start using the registered Anti-
Theft System key, it may be due to interference caused
by:
.

Another Anti-Theft System key.

Automated toll road device.

Automated payment device.

Other devices that transmit similar signals.

Start the engine using the following procedure:

Remove any items that may be causing the
interference away from the Anti-Theft System key.

Leave the ignition switch in the “ON” position for
approximately 5 seconds.

Turn the ignition switch to the “OFF” or “LOCK”
position, and wait approximately 10 seconds.

Repeat steps 2 and 3 again.

Start the engine.

Repeat the steps above until all possible inter-
ferences are eliminated.

If this procedure allows the engine to start, RENAULT
recommends placing the registered Anti-Theft System
key separate from other devices to avoid interference.

FCC WARNING:

Changes or modifications not expressly ap-
proved by the party responsible for compliance
could void the user

’s authority to operate the

equipment.

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions; (1) This device may not cause harm-
ful interference, and (2) this device must accept
any interference received, including interference
that may cause undesired operation of the
device.

Security indicator light

SIC2045

The security indicator light is located on the meter
panel. It indicates the status of Anti-Theft System.

The light operates whenever the ignition switch is in

the “LOCK”, “OFF” or “ACC” position. The security
indicator light indicates that the security systems on
the vehicle are operational.

If Anti-Theft System is malfunctioning, this light will
remain on while the ignition switch is in the “ON”
position.

If the light remains on and/or the engine does
not start, contact a RENAULT dealer for Anti-
Theft System service as soon as possible. Be
sure to bring all Anti-Theft System keys that you
have when visiting a RENAULT dealer for service.

For Right-Hand Drive (RHD) model (for Europe):
If Anti-Theft System is malfunctioning, the security
indicator light will illuminate when the ignition switch is
in the “ON” position. However, if the security indicator
light turns off after 15 minutes, you can start the engine
once. See a RENAULT dealer for Anti-Theft System
service as soon as possible.

Pre-driving checks and adjustments

3-17

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-18

Pre-driving checks and adjustments

WARNING:

The hood must be closed and latched
securely before driving. Failure to do so
could cause the hood to fly open and result
in an accident.

Never open the hood if steam or smoke is
coming from the engine compartment to
avoid injury.

OPENING HOOD

JVP0090X

Pull the hood lock release handle

located

below the instrument panel until the hood springs
up.

Locate the lever

in between the hood and

grille and push the lever sideways with your
fingertips.

Raise the hood

Remove the support rod

and insert it into the

slot

Hold the coated parts

when removing or

resetting the support rod. Avoid direct contact
with the metal parts, as they may be hot
immediately after the engine has been stopped.

CLOSING HOOD

While supporting the hood, return the support rod
to its original position.

Slowly lower the hood to about 20 to 30 cm (8 to
12 in) above the hood lock, then let it drop.

Make sure it is securely latched.

CAUTION:

Before closing the hood, be sure to release the
support rod and store it in position. Otherwise,
the support rod will be damaged.

HOOD

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

WARNING:

Make sure the back door has been closed
securely to prevent it from opening while driving.
Do not drive with the back door open. This could
allow dangerous exhaust gases to be drawn into
the vehicle.

OPENING BACK DOOR

JVP0091X

For model with the door key cylinder

The back door can be opened by pulling the opener
handle and pulling up the back door.

To close the back door, pull down until it securely
locks.

For model without the door key cylinder

To open the back door, unlock it with one of the
following operations, then pull the handle.
.

Push the back door request switch (if equipped).
(See “Intelligent Key system” (P.3-9).)

Push the “UNLOCK” button on the Intelligent Key
(if equipped). (See “Intelligent Key system” (P.3-
9).)

Push the “UNLOCK” button on the remote
controller (if equipped). (See “Remote keyless
entry system” (P.3-7).)

Push the power door lock switch to the “UN-
LOCK” position.

Locking with key (for model with the door key
cylinder)

JVP0096X

To lock the back door, push it down firmly, insert the
key to the door key cylinder and turn the key clockwise

. To unlock the back door, turn the key counter-

clockwise

WARNING:

Fuel is extremely flammable and highly
explosive under certain conditions. You
could be burned or seriously injured if it is
misused or mishandled. Always stop the
engine and do not smoke or allow open
flames or sparks near the vehicle when
refueling.

Fuel may be under pressure. Turn the cap a
half of a turn, and wait for any

“hissing”

sound to stop to prevent fuel from spraying
out and possibly causing personal injury.
Then remove the cap.

Use only an original equipment type fuel
filler cap as a replacement. It has a built-in
safety valve needed for proper operation of
the fuel system and emission control sys-
tem. An incorrect cap can result in a serious
malfunction and possible injury.

OPENING FUEL FILLER LID

SPA2336

To open the fuel filler lid, pull the fuel filler lid release
handle.

Pre-driving checks and adjustments

3-19

BACK DOOR

FUEL FILLER LID

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-20

Pre-driving checks and adjustments

FUEL FILLER CAP

SPA1755

The fuel filler cap is a ratcheting type. Turn the cap
counterclockwise

to remove. Tighten the cap

clockwise

until ratchet clicks, more than twice,

after refueling.

CAUTION:

If fuel is spilled on the vehicle body, flush it away
with water to avoid paint damage.

WARNING:

Never adjust the steering wheel while driving so
that full attention may be given to vehicle
operation.

JVP0092X

While pushing the lock lever down

, adjust the

steering wheel up or down

until the desired

position is achieved.

Pull the lock lever up

firmly to lock the steering

wheel in place.

WARNING:

Adjust the position of all mirrors before driving.
Do not adjust the mirror positions while driving
so that full attention may be given to vehicle
operation.

INSIDE REARVIEW MIRROR

SPA2447

While holding the inside rearview mirror, adjust the
mirror angles until the desired position is achieved.

SPA2143

Pull the adjusting lever

(if equipped) when the

glare from the headlights of the vehicle behind you
obstructs your vision at night.

STEERING WHEEL

MIRRORS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

Push the adjusting lever

(if equipped) during the

day for the best rearward visibility.

OUTSIDE REARVIEW MIRRORS

WARNING:

Never touch the outside rearview mirrors
while they are in motion. Doing so may pinch
your fingers or damage the mirror.

Never drive the vehicle with the outside
rearview mirrors folded. This reduces rear
view visibility and may lead to an accident.

Objects viewed in the outside mirror are
closer than they appear. (if equipped)

The picture dimensions and distance in the
outside mirrors are not real.

Adjusting

Remote control type (if equipped):

SPA2214

The outside rearview mirror remote control operates
when the ignition switch is in the “ACC” or “ON”
position.

Move the switch to select the right

or left

mirror.

Adjust each mirror until the desired position is
achieved

Lever control type (if equipped):

SPA2772

Adjust the mirror angles with the inside lever until the
desired position is achieved.

Manual control type (if equipped):

SPA2140

Push on the mirror surface directly to adjust it to the
desired position.

Defogging (if equipped)

The outside rearview mirrors will be heated when the
rear window defogger switch is operated.

Folding

SPA1732A

Pre-driving checks and adjustments

3-21

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-22

Pre-driving checks and adjustments

Remote control type (if equipped):
The outside rearview mirror remote control operates
when the ignition switch is in the “ACC” or “ON”
position.

The outside rearview mirrors automatically fold when
the outside rearview mirror folding switch is pushed to
the “CLOSE” position

. To unfold, push to the

“OPEN” position

CAUTION:

Continuously performing the fold/unfold
operation of the outside rearview mirror
may cause the switch to stop the operation.

Do not touch the mirrors while they are
moving. Your hand may be pinched, and the
mirror may malfunction.

Do not drive with the mirrors stored. You will
be unable to see behind the vehicle.

If the mirrors were folded or unfolded by
hand, there is a chance that the mirror will
move forward or backward during driving. If
the mirrors were folded or unfolded by hand,
be sure to adjust them again electrically
before driving.

JVC0025X

Automatic folding function with interlocking
door lock (if equipped):
The outside rearview mirrors fold automatically by
interlocking door lock. The function can be used while
the switch is in the “AUTO” position

The outside rearview mirrors fold automatically
when the door is locked by the door handle
request switch or the remote keyless entry system.

The outside rearview mirrors unfold when the
ignition switch is placed in the “ACC” or “ON”
position.

CAUTION:

When the outside rearview mirror is folded/
unfolded manually, the mirror may fold/unfold
accidentally while driving. Be sure to fold/unfold
the outside rearview mirror by an electrical
operation after folding/unfolding manually.

WARNING:

When the outside rearview mirror is folded/
unfolded manually, depending on the switch
position, the outside rearview mirror may
start operation by turning the ignition switch
to the

“ACC” or “ON” position.

When unfolding the outside rearview mirror
with the switch being in the

“AUTO” position,

the mirror will be unfolded further by turning
the ignition switch to the

“ACC” or “ON”

position.

To return its original position, fold the out-
side rearview mirror once.

The outside rearview mirror remote control operates
when the ignition switch is in the "ACC" or "ON"

position.

The outside rearview mirrors automatically fold when
the outside rearview mirror folding switch is pushed to
the "CLOSE" position

. To unfold, push to the

"AUTO" position

CAUTION:

Continuously performing the fold/unfold opera-
tion of the outside rearview mirror may cause
the switch to stop the operation.

Manual control type (if equipped):

SPA1829

Fold the outside rearview mirror by pushing it toward
the rear of the vehicle.

&RQGLWLRQ

Renault Pulse (2012 year). Instruction - part 7
