Renault Pulse (2012 year). Instruction

> (GLW 0RGHO .$2(0B5HQDXOW @

WARNING:

In freezing temperatures, the washer fluid may
freeze on the windshield and obscure your
vision. Warm the windshield with the defogger
before you wash the windshield.

CAUTION:

Do not operate the washer continuously for
longer than 30 seconds.

Do not operate the washer if the window
washer fluid reservoir is empty.

WINDSHIELD WIPER AND WASHER
SWITCH

JVI0271X

Type A (example)

JVI0034X

Type B (example)

The windshield wiper and washer operate when the
ignition switch is in the “ON” position.

Wiper operation

The lever position “INT” or “

”

operates the

wiper intermittently.
.

If equipped, the intermittent operation can be
adjusted by turning the adjustment control knob,
(longer)

or (shorter)

If equipped, the speed of the intermittent opera-
tion varies depending on the vehicle speed.

The lever position “AUTO”

operates the rain

sensing auto wiper system (if equipped). (See “Rain-
sensing auto wiper system” (P.2-33).)

The lever position “LO” or “

”

operates the

wiper at low speed.

The lever position “HI” or “

”

operates the

wiper at high speed.

To stop the wiper operation, move the lever up to the
“OFF” position.

The lever position “MIST” or “

”

operates the

wiper one sweep. The lever automatically returns to its
original position.

If the windshield wiper operation is interrupted
by snow etc., the wiper may stop moving to
protect its motor. If this occurs, turn the wiper
switch to OFF and remove the snow etc. on and
around the wiper arms. In approximately 20
seconds, turn the switch ON again to operate
the wiper.

Washer operation

To operate the washer, pull the lever toward the back
of the vehicle

until the desired amount of washer

fluid is spread on the windshield. The wiper will
automatically operate several times.

RAIN-SENSING AUTO WIPER SYSTEM (if
equipped)

SIC4018

Type A

Instruments and controls

2-33

WIPER AND WASHER SWITCH

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

2-34

Instruments and controls

SIC3909

Type B

The rain-sensing auto wiper system can automatically
turn on the wipers and adjust the wiper speed
depending on the rainfall and the vehicle speed by
using the rain sensor located on the upper part of the
windshield.

To set the rain-sensing auto wiper system, push the
lever down to the “AUTO” position

. The wiper will

sweep once while the ignition switch is in the “ON”
position.

The rain sensor sensitivity level can be adjusted by
turning the knob toward the front

(High) or toward

the rear

(Low).

High — High sensitive operation

Low — Low sensitive operation

To turn the rain-sensing auto wiper system off, push up
the lever to the “OFF” position, or pull down the lever
to the “

” (LO) or “

” (HI) position.

CAUTION:

Do not touch the rain sensor and around it when
the wiper switch is in the “AUTO” position and
the ignition switch is in the “ON” position. The
wipers may operate unexpectedly and cause to
an injury or a wiper damage.

The rain-sensing auto wipers are intended
for use during rain. If the switch is left in the
“AUTO” position, the wipers may operate
unexpectedly when dirt, fingerprints, oil film
or insects are stuck on or around the sensor.
The wipers may also operate when exhaust
gas or moisture affect the rain sensor.

When the windshield glass is coated with
water repellent, the speed of the rain-sen-
sing auto wipers may be higher even though
the amount of the rainfall is small.

Be sure to turn off the rain-sensing auto
wiper system when you use a car wash.

The rain-sensing auto wipers may not oper-
ate if rain does not hit the rain sensor even if
it is raining.

REAR WINDOW WIPER AND WASHER
SWITCH (if equipped)

JVI0273X

Type A

JVI0274X

Type B

If the rear window wiper operation is interrupted
by snow etc., the wiper may stop moving to
protect its motor. If this occurs, turn the wiper
switch to OFF and remove the snow etc. on and
around the wiper arms. In approximately 1
minute, turn the switch ON again to operate
the wiper.

The rear window wiper and washer operates when the
ignition switch is in the “ON” position.

Wiper operation

The switch position “INT”

operates the wiper

intermittently.

The switch position “ON”

operates the wiper

continuously.

To stop the wiper operation, turn the switch to the
“OFF” position.

Reverse synchronization function (if equipped):
When the windshield wiper switch is on, moving the
selector lever to the “R” (Reverse) position will operate
the rear window wiper.

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

Washer operation

To operate the washer, push the lever toward the front
of the vehicle

until the desired amount of washer

fluid is spread on the rear window. The wiper will
automatically operate several times.

SIC4127

Type A

SIC4145

Type B

The rear window defogger switch operates when the
ignition switch is in the “ON” position.

The defogger is used to reduce the moisture, fog or
frost on the rear window surface and outside door
mirror surface (if equipped) to improve the rear view.

When the defogger switch

is pushed, the indicator

light

illuminates and the defogger operates for

approximately 15 minutes. After the preset time has
passed, the defogger will turn off automatically.

To turn off the defogger manually, push the defogger
switch again.

CAUTION:

When operating the defogger continuously,
be sure to start the engine. Otherwise, it may
cause the battery to discharge.

When cleaning the inner side of the window,
be careful not to scratch or damage the
electrical conductors on the surface of the
window.

NOTE:

When the rear defogger is turned on, the Stop/
Start (Idling Stop) System (if equipped) will not
be activated.

Instruments and controls

2-35

DEFOGGER SWITCH (if equipped)

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

2-36

Instruments and controls

SIC2475

The hazard indicator flasher switch operates with the
ignition switch in any position except when the battery
is discharged.

The hazard indicator flasher is used to warn other
drivers when you have to stop or park under
emergency conditions.

When the hazard indicator flasher switch is pushed, all
turn signal lights will flash. To turn off the hazard
indicator flasher, push the hazard indicator flasher
switch again.

JVI0362X

The horn switch operates with the ignition switch in
any position except when the battery is discharged.

When the horn switch is pushed and held, the horn will
sound. Releasing the horn switch will cease the horn
sound.

MANUAL WINDOWS (if equipped)

SIC4435

The side windows can be opened

or closed

by turning the hand crank on each door.

POWER WINDOWS (if equipped)

WARNING:

Make sure that all passengers have their
hands, etc. inside the vehicle before operat-
ing the power windows.

Never leave children or adults who would
normally require the support of others alone
in the vehicle. They could unknowingly
activate switches or controls and inadver-
tently become involved in an accident.

The power windows operate when the ignition switch
is in the “ON” position.

To open a window, push down the power window
switch.

To close a window, pull up the power window switch.

HAZARD INDICATOR FLASHER

SWITCH

HORN

WINDOWS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

Driver’s window switch

The driver’s switch, which is the main switch, can
control all windows.

Locking passengers’ windows:

JVI0036X

Front and rear type

When the lock button

is pushed in, the passen-

gers’ windows cannot be operated.

To cancel the passengers’ windows lock, push the lock
button

again.

Passenger’s window switch

SIC2311

The passenger’s switch can control its corresponding
window.

When the passengers’ windows lock button on the
driver’s switch is pushed in, the passenger’s switch
cannot be operated.

Automatic function

JVI0037X

Front and rear type

Automatic function is available for the switch that has
an

mark on its surface.

The automatic function enables a window to fully open
or close (if equipped) without holding the switch down
or up.

To fully open the window, push the power window
switch down to the second detent and release the
switch. To fully close the window (if equipped), pull the
power window switch up to the second detent and
release the switch. The switch does not have to be
held during window operation.

To stop the window open/close operation during the
automatic function, push down or pull up the switch in
opposite directions.

Window timer (if equipped):
The window timer allows the window switch to be
operated for 15 minutes even if the ignition switch is
turned off and the key is removed. The window timer
will be cancelled when the corresponding door is
opened or the preset time has expired.

Auto-reverse function (if equipped):

WARNING:

There is a small distance just before the closed
position which cannot be detected. Make sure
that all passengers have their hands, etc. inside
the vehicle before closing the windows.

The auto-reverse function enables a window to
automatically reverse when something is caught in
the window as it is closing by the automatic function.
When the control unit detects an obstacle, the window
will be lowered immediately.

Depending on the environment or driving conditions,
the auto-reverse function may activate if an impact or
load similar to something being caught in the window
occurs.

When power window switch does not oper-
ate

Some power window functions (automatic close
function, auto-reverse function) will not operate as
described after the battery cable is disconnected and
the electrical supply is interrupted. Perform the
following procedure to initialize the power window
functions.

Turn the ignition switch to the "ON" position.

If the driver’s window is closed, open it completely
by operating the driver’s window switch.

Instruments and controls

2-37

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

2-38

Instruments and controls

Pull up and hold the driver’s window switch to
close the driver’s window. Hold the switch for
approximately 3 seconds after the window has
been fully closed, and then release it.

Check if the power window functions operate
properly.

If you open or close the power window continuously, it
may cause the power window not to operate properly.
Perform the above procedure.

If the power window functions do not operate properly
after performing the above procedure, repeat the
steps. See a RENAULT dealer, if necessary, for
checking the power window system.

WARNING:

Never allow hands, fingers, or any part of your
body within operating range of the sunshade.
You could be injured.

CAUTION:

Do not place any heavy objects on the roof
glass or surrounding area.

Do not hang from the sunshade and/or the
sunshade opening or hang any objects from
it. It may cause damage or deformation to
the sunshade.

Close the sunshade when you leave the
vehicle for extended periods of time to
prevent the inside of the vehicle from reach-
ing high temperatures.

JVI0020X

To open or close the sunshade, operate the knob

To open the sunshade, slide it toward the rear of the
vehicle

. To close, slide the sunshade toward the

front of the vehicle

If the battery cable is disconnected, the clock will reset
its time and the correct time will not be indicated.
Readjust the time.

For model with the vehicle information display, see
“Vehicle information display” (P.2-20)

For the clock adjustment in the audio unit (if equipped).
See “Audio system” (P.4-8).

ADJUSTING TIME

Meter display model (if equipped)

SIC4406

The digital clock

in the meter displays the time

when the ignition switch is in the “ON” position.

To display the clock, push the adjusting knob

. To

adjust the time, perform the following procedure.

Push the clock adjusting knob

for 3 seconds

or more to enter time adjust mode.

The hours display will start to flash.

Push the clock adjusting knob

to adjust the

hour.

To advance the time, hold down the knob

Wait at least 5 seconds for the minute display to
flash.

SUNSHADE (if equipped)

CLOCK

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

Push the clock adjusting knob

to adjust the

minutes.

To advance the time, hold down the knob

Wait at least 5 seconds for the second display “:”
to flash.

Push the clock adjusting knob

to reset the

second counter.

The selected values will be stored if no user input is
detected for 60 seconds, or can be reset by using the
adjusting knob.

SIC4436

The power outlet is for powering electrical accessories
such as cellular telephone.

CAUTION:

The outlet and plug may be hot during or
immediately after use.

This power outlet is not designed for use
with a cigarette lighter unit.

Do not use with accessories that exceed a 12
volt, 120W (10A) power draw. Do not use
double adapters or more than one electrical
accessory.

Use power outlets with the engine running
to avoid discharging the vehicle battery.

Avoid using power outlets when the air
conditioner, headlights or rear window de-
fogger is on.

Before inserting or disconnecting a plug, be
sure to turn off the power switch of electrical
accessory being used and the ignition
switch.

Push the plug in as far as it will go. If good
contact is not made, the plug may overheat
or the internal temperature fuse may open.

Do not allow water to contact the outlet.

When not in use, be sure to close the cap.

Instruments and controls

2-39

POWER OUTLETS (if equipped)

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

2-40

Instruments and controls

WARNING:

The storages should not be used while
driving so full attention may be given to
vehicle operation.

Keep the storage lids closed while driving to
help prevent injury in an accident or a
sudden stop.

GLOVE BOX

SIC4407

Type A

To open the glove box, pull the handle.

To close, push the lid in until the lock latches.

JVI0692X

Type B

To open the glove box, turn the knob counterclockwise.

To close, push the lid in and turn the knob clockwise.

UPPER INSTRUMENT BOX (if equipped)

JVC0034X

To open the upper instrument box, push the button.

To close, push the lid down.

CARD HOLDER (if equipped)

JVI0018X

Pull the sun visor down and slide a card in the card
holder

CUP HOLDERS

CAUTION:

Avoid abrupt starting and braking especially
when the cup holder is being used to prevent
spilling the contents. If the contents are hot, they
could scald you or your passengers.

SIC4408

Front

STORAGES

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

SIC4409

Rear

TONNEAU BOARD (if equipped)

WARNING:

Never put anything on the tonneau board, no
matter how small. Any object on it could
cause an injury in an accident or sudden
stop.

Do not leave the tonneau board in the
vehicle with it disengaged from the holder.

The tonneau board keeps the luggage compartment
contents hidden from the outside.

SIC4410

To remove the tonneau board:

Remove the straps

from the back door.

Remove the tonneau board from the tonneau
board holders

SPA1909

To block out glare from the front, swing down the
sun visor

To block glare from the side, remove the sun visor
from the center mount and swing it to the side

Instruments and controls

2-41

SUN VISORS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

2-42

Instruments and controls

CAUTION:

Do not leave the light switch on when the
engine is not running for extended periods
of time to prevent the battery from being
discharged.

Turn off the lights when you leave the
vehicle.

JVI0022X

ROOM LIGHT

The room light

has a three-position switch.

When the switch is in the on position

, the light

illuminates.

When the switch is in the center position

, the room

light illuminates when a door is opened.

The interior light timer will keep the room light on for
approximately 15 seconds or 30 seconds when:
.

The key is removed from the ignition switch with all
doors closed (model without Intelligent Key
system).

The ignition switch is placed in the "OFF" or
LOCK" position (model with Intelligent Key sys-
tem).

The driver’s door is unlocked without the key in the
ignition switch (model without Intelligent Key
system).

The doors are unlocked with the UNLOCK button
(on the keyfob or Intelligent Key) or the request
switch (model with Intelligent Key system) with the
ignition switch in the "LOCK" position.

The driver’s door is opened and then closed with
the ignition switch in the "LOCK" position and
without the key in the ignition switch.

The interior light timer will be cancelled when:
.

The driver’s door is locked.

The ignition switch is turned to the “ON” position.

When the switch is in the off position

, the room

light does not illuminate, regardless of any condition.

FRONT MAP LIGHTS (if equipped)

To turn on the front map light

(if equipped), push

the on switch

, and the light illuminates. To turn off,

push the off switch

Battery saver system

If any door is left open for a period of time with the
room light switch placed horizontally or the room
control switch in the center position

, the room light

will automatically turn off.

INTERIOR LIGHTS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3 Pre-driving checks and adjustments

Keys ............................................................................................................. 3-2

Key ........................................................................................................ 3-2
Anti-Theft System key (if equipped) ............................................ 3-2
Intelligent Key (if equipped) ........................................................... 3-3

Door locks ................................................................................................. 3-4

Super lock system (if equipped) ................................................... 3-4
Locking with key ................................................................................ 3-5
Locking with inside lock knob ....................................................... 3-5
Locking with power door lock switch (if equipped) ................ 3-6
Vehicle speed sensing door lock mechanism (if equipped) .... 3-6
Auto door lock releasing mechanism (if equipped) ................. 3-6
Child safety rear door lock ............................................................. 3-7

Remote keyless entry system (if equipped) ..................................... 3-7

Using remote keyless entry system (if equipped) .................... 3-7

Intelligent Key system (if equipped) ................................................... 3-9

Operating range ............................................................................. 3-10
Using intelligent Key system ....................................................... 3-10
Battery saver system ..................................................................... 3-12
Warning and audible reminders ................................................. 3-12
Trouble shooting guide ................................................................. 3-13
Using remote keyless entry function ......................................... 3-15

Security system (if equipped) .......................................................... 3-16

Theft warning system ................................................................. 3-16
Anti-Theft System ........................................................................ 3-17

Hood ....................................................................................................... 3-18

Opening hood .............................................................................. 3-18
Closing hood ................................................................................ 3-18

Back door .............................................................................................. 3-19

Opening back door ..................................................................... 3-19

Fuel filler lid ........................................................................................... 3-19

Opening fuel filler lid .................................................................. 3-19
Fuel filler cap ................................................................................ 3-20

Steering wheel ...................................................................................... 3-20
Mirrors ..................................................................................................... 3-20

Inside rearview mirror ................................................................. 3-20
Outside rearview mirrors ........................................................... 3-21
Vanity mirrors (if equipped) ....................................................... 3-23

Parking brake ........................................................................................ 3-23

Lever type ...................................................................................... 3-23

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-2

Pre-driving checks and adjustments

Your vehicle can only be driven with the keys specific
to your vehicle. A key number plate is supplied with
your key. Record the key number and keep the key
number plate in a safe place, except in the vehicle, in
case of the need to duplicate the keys.

The key can only be duplicated using an original key or
the original key number. The key number is required
when you have lost all of the keys and do not have the
original key to duplicate from. If the key is lost, or you
need extra keys, provide an original key or the key
number to a RENAULT dealer.

CAUTION:

Do not leave the keys inside the vehicle when
leaving the vehicle.

KEY

JVP0083X

Type A

Your vehicle is equipped with the following set of keys:

Master key (Molded)

Master key (Plate)

Key number plate

JVP0084X

Type B

Master key

Master key (Plate)

Key number plate

As many as 5 master keys with remote controller can
be registered and used with one vehicle.

ANTI-THEFT SYSTEM* KEY (if equipped)

JVP0085X

Type A

Your vehicle is equipped with the following set of keys:

Anti-Theft System key (Molded)

Key number plate

KEYS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

JVP0086X

Type B

Anti-Theft System key

Anti-Theft System key (Molded)

Key number plate

JVP0087X

Type C

Anti-Theft System key

Anti-Theft System key (Molded)

Key number plate

JVC0063X

Type D

Anti-Theft System key

Key number plate

Your vehicle can only be driven with the Anti-Theft
System keys, which are registered to your vehicle’s
Anti-Theft System components. As many as 5 Anti-
Theft System keys can be registered and used with
one vehicle. The new keys must be registered by a
RENAULT dealer prior to use with the Anti-Theft
System of your vehicle. Since the registration process
requires erasing all memory in the Anti-Theft System
components when registering new keys, be sure to
take all Anti-Theft System keys that you have to the
RENAULT dealer.

CAUTION:

Do not allow the Anti-Theft System key, which
contains an electrical transponder, to come into
contact with water or salt water. This could
affect the system function.

*: Immobilizer

INTELLIGENT KEY (if equipped)

SPA2406

Type A (with panic alarm)

SPA2502

Type B (without panic alarm)

Intelligent Key (2)

Mechanical key (inside the Intelligent Key) (2)

Key number plate

Your vehicle can only be driven with the Intelligent
Keys, which are registered to your vehicle’s Intelligent
Key system components and Anti-Theft System*
components. As many as 4 Intelligent Keys can be
registered and used with one vehicle. The new keys
must be registered by a RENAULT dealer prior to use
with the Intelligent Key system and Anti-Theft System
of your vehicle. Since the registration process requires

Pre-driving checks and adjustments

3-3

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-4

Pre-driving checks and adjustments

erasing all memory in the Intelligent Key components
when registering new keys, be sure to take all
Intelligent Keys that you have to the RENAULT dealer.

*: Immobilizer

CAUTION:

Be sure to carry the Intelligent Key with you.
Do not leave the vehicle with the Intelligent
Key inside.

Be sure to carry the Intelligent Key with you
when driving. The Intelligent Key is a preci-
sion device with a built-in transmitter. To
avoid damaging it, please note the follow-
ing.

— The Intelligent Key is water resistant;

however, wetting may damage the In-
telligent Key. If the Intelligent Key gets
wet, immediately wipe until it is com-
pletely dry.

— Do not bend, drop or strike it against

another object.

— Do not place the Intelligent Key for an

extended period in a place where tem-
peratures exceed 60

8C (1408F).

— Do not change or modify the Intelligent

Key.

— Do not use a magnet key holder.

— Do not place the Intelligent Key near

equipment that produces a magnetic
field such as a TV, audio equipment
and personal computers or cellular
phones.

— Do not allow the Intelligent Key to come

into contact with water or salt water,
and do not wash it in a washing
machine. This could affect the system
function.

If an Intelligent Key is lost or stolen,
RENAULT recommends erasing the ID code
of that Intelligent Key. This will prevent the
Intelligent Key from unauthorized use to
unlock the vehicle. For information regard-
ing the erasing procedure, please contact a
RENAULT dealer.

Mechanical key

SPA2033

To remove the mechanical key, release the lock knob at
the back of the Intelligent Key.

To install the mechanical key, firmly insert it into the
Intelligent Key until the lock knob returns to the lock
position.

Use the mechanical key to lock or unlock the doors.
(See “Door locks” (P.3-4).)

WARNING:

Always look before opening any doors, to
avoid an accident with oncoming traffic.

SUPER LOCK SYSTEM (if equipped)

WARNING:

For Super Lock System equipped models, failure
to follow the precautions below may lead to
hazardous situations. Make sure the Super Lock
System activation is always safely conducted.

When the vehicle is occupied, never lock the
doors with the remote keyless entry system
or the Intelligent Key system. Doing so will
trap the occupants, since the Super Lock
System prevents the doors from being
opened from the inside of the vehicle.

Only operate the remote controller or the
Intelligent Key lock button when there is a
clear view of the vehicle. This is to prevent
anybody from being trapped inside the
vehicle through the Supper Lock System
activation.

Locking the doors with the remote controller or the
Intelligent Key “LOCK” button

or the request

switch will lock all doors and activate the Super Lock
System.

This means that none of the doors can be opened from
the inside in order to prevent theft.

DOOR LOCKS

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

The system will be released when the door is unlocked
with the remote controller or the Intelligent Key
“UNLOCK” button

or the request switch.

The Super Lock System will not activate when the
doors are locked with the power door lock switch or
mechanical key.

Emergency situations

If the Super Lock System is activated due to a traffic
accident or other unexpected circumstances while you
are in the vehicle:
.

Place the ignition switch to the “ON” position, the
Super Lock System will be released and all the
doors can be unlocked with the power door lock
switch. You can then open the doors.

Unlock the door using the remote controller or the
Intelligent Key. The Super Lock System will be
released and you can open the door.

LOCKING WITH KEY

JVP0093X

Type A

To lock the driver’s door or passenger’s door, insert the
key to the door cylinder located on the driver’s or
passenger’s side door and turn the key to the front of
the vehicle

For locking the back door, see “Opening back door”
(P.3-19).

To unlock the driver’s door or passenger’s door, turn
the key to the rear of the vehicle

For unlocking the back door, see “Opening back door”
(P.3-19).

Type B

To lock the door, insert the key to the door key cylinder
located on the driver’s side door, and turn the key to
the front of the vehicle

. All doors including the

back door will lock.

To unlock the door, turn the key to the rear of the
vehicle

. All doors including the back door will

unlock.

Type C

To lock the driver’s door, insert the key to the door
cylinder located on the driver’s side door and turn the
key to the front of the vehicle

For locking other doors, use the power door lock
switch. (See “Locking with power door lock switch”
(P.3-6).)

To unlock the driver’s door, turn the key to the rear of
the vehicle

For unlocking other doors, use the power door lock
switch. (See “Locking with power door lock switch”
(P.3-6).)

LOCKING WITH INSIDE LOCK KNOB

SPA2760

To lock the front doors, push the inside lock knob to
the lock position

, and then close the door while

pulling the door handle.

To lock the rear doors, push the inside lock knob to the
lock position

and then close the door.

CAUTION:

When locking the doors using the inside
lock knob, be sure not to leave the key in the
vehicle.

When the key is in the ignition switch and
the driver’s door is open, the inside lock
knob will not lock the door(s).

To unlock, pull the inside lock knob to the unlock
position

When the doors are locked, pulling the driver’s side
door handle will unlock the door (if equipped).

Pre-driving checks and adjustments

3-5

&RQGLWLRQ

> (GLW 0RGHO .$2(0B5HQDXOW @

3-6

Pre-driving checks and adjustments

Right-Hand Drive (RHD) model (if equipped)

SPA2709

To unlock and open the door, pull the inside door
handle as illustrated.

The doors cannot be opened by using the inside door
handle when the Super Lock System is activated.

LOCKING WITH POWER DOOR LOCK
SWITCH (if equipped)

JVP0004X

JVP0003X

Power door lock switch (located on the center console)

To lock the doors, push the power door lock switch to
the lock position

CAUTION:

When locking the doors using the power
door lock switch, be sure not to leave the
key in the vehicle.

When the key is in the ignition switch and
the driver’s door is open, the power door
lock switch will not lock the doors.

To unlock, push the power door lock switch to the
unlock position

VEHICLE SPEED SENSING DOOR LOCK
MECHANISM (if equipped)

All doors will be locked automatically when the vehicle
speed reaches 10 km/h (6 MPH). Once the lock has
been unlocked, while driving, the vehicle speed
sensing door lock mechanism will not lock the door
again unless one of the following is performed.
.

Opening any doors.

Placing the ignition switch in the “OFF” position.

To activate or deactivate vehicle speed
sensing door lock mechanism

To activate or deactivate the door lock mechanism,
perform the following procedures.

Place the ignition switch in the “ON” position.

Within 20 seconds, push and hold the power door
lock switch to the “LOCK” position for 5 seconds.

The hazard indicator light will flash as follows if the
switching operation is successful:

Twice — activated

Once — deactivated

AUTO DOOR LOCK RELEASING ME-
CHANISM (if equipped)

All doors will be unlocked automatically when the
ignition switch moved “ON” to “OFF” position (models
with Intelligent Key system).

All doors will be unlocked automatically when the key
is removed from the ignition switch (models without
Intelligent Key system).

To activate or deactivate auto door lock
releasing mechanism

To activate or deactivate the auto door lock releasing
mechanism, perform the following procedures.

Place the ignition switch in the “ON” position.

Within 20 seconds, push and hold the power door
lock switch to the “UNLOCK” position for 5
seconds.

The hazard indicator light will flash as follows if the
switching operation is successful:

Twice - activated

Once - deactivated

&RQGLWLRQ

Renault Pulse (2012 year). Instruction - part 6
