Renault Koleos (2018 year). Instruction - part 14

3.20

One-touch mode

Depending on the vehicle, this mode

works in addition to the operation of the

electric windows described previously.

It is only fitted to the driver’s window.

Briefly press or pull switch 1 fully: the

window is fully lowered or raised.

Pressing the switch again stops the

window moving.
Note: if the window detects resistance

when closing (e.g.: branch of a tree,

etc.) it stops and then lowers again by a

few centimetres.

ELECTRIC WINDOWS

(2/2)

Operating faults

In case of a fault when closing a window,

the system reverts to normal mode:

pull the switch concerned up as often

as necessary to fully close the window

(the window will close gradually), hold

the switch (still on the closure side) for

one second then lower and raise the

window fully to reinitialise the system.
If necessary, contact your authorised

dealer.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

3.21

ELECTRIC SUNROOF

(1/2)

To slide the curtain 1

With the ignition on:
– Full opening: push switch 2 to the

middle of position A;

– Full closing: push switch 2 to the

end of position B.

It doesn’t need to be held. The curtain

will automatically open or close all the

way.

To tilt the sunroof

When the sunroof is closed, press

switch 2 to tilt up the sunroof. It doesn’t

need to be held.
When the sunroof is tilt, press switch 2

to close the sunroof. It doesn’t need to

be held.

Special features

If the window detects resistance when

closing or tilting down (e.g.: arms,

branch of a tree, etc.) it moves to the

front or tilts up.
If this function malfunctions and re-

peats opening or tilting up the sunroof,

keep pushing the tilt down switch within

5 seconds after it happens; the sun-

roof will fully close gradually. Make sure

nothing is caught in the sunroof.

1

2

A

B

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
If something gets trapped, reverse

the direction of travel as soon as

possible by pushing switch 2 to the

position A.
RISK OF DEATH OR SERIOUS

INJURY.

3.22

ELECTRIC SUNROOF

(2/2)

It doesn’t need to be held. The sun-

roof will automatically open or close all

the way. To stop the window, push the

switch once more while it is opening or

closing.
Note: If you wish to open the sunroof

while driving, comfort opening is rec-

ommended to prohibit wind buffeting.

Precautions during use

–  Vehicle with loaded roof bars.

As a general rule, if there is a load

on the roof, use of the sunroof is not

recommended.
Before using the sunroof, check the

objects and/or accessories (bike

racks, roof boxes, etc.) attached to

the roof bars: they should be prop-

erly arranged and secured and

should not interfere with the opera-

tion of the sunroof.
Contact an approved dealer for de-

tails of possible conversions;

To slide the sunroof

With the ignition on:
– Comfort opening: push switch 2 to

the middle of position A;

– Full opening: push switch 2 to the

end of position A;

– Comfort closing: push switch 2 to

the middle of position B;

– Full closing: push switch 2 to the

end of position B.

2

–  check  that the sunroof is properly

closed before leaving your vehicle;

– clean the seal every three months

using products recommended by our

Technical Department;

–  do not open the sunroof immedi-

ately after it has rained or immedi-

ately after washing the vehicle.

Operating fault

If the sunroof does not close, please

consult an authorised dealer.

Closing the sunroof can

cause severe injuries.

A

B

3.23

Note: For vehicles fitted with a naviga-

tion system, you can use the multifunc-

tion screen to deactivate/activate the

courtesy lights which come on when

the doors or boot are opened. To do

this, please refer to “Vehicle settings

customisation menu” in Section 1.

Interior lights switch 1

Press switch 1 to turn on/off map read-

ing light 3 and 4. When a door is open,

door light 5 and foot light 6 are ON.

Interior lights switch 2

Press switch 1 to turn on/off door light 5

and foot light 6. When a door is open,

map reading light 3 and 4 are ON. You

can turn on/off the front door and foot

lights with the switch 2 control although

the doors are closed.

When the doors or boot are un-

locked and opened, the reading and

footwell lights come on temporarily.

INTERIOR LIGHTING (1/3)

With the doors properly shut, lock-

ing or starting the engine makes the

interior lights and the courtesy lights

go out.

4

3

5

1

2

Front door lights 5

Front footwell lights 6

6

3.24

INTERIOR LIGHTING (2/3)

Front and rear door ambient

light

Front and rear door ambient light 10

comes on when the door is opened.

Front door storage light

Front door storage light 11 comes on

when the door is opened.

10

11

Center console ambient light

Center console ambient light 9 comes

on when the door is opened.
Note: interior ambient lights can be

controlled by multifunction screen de-

pending on the vehicle. For more infor-

mation, please see to the multimedia

system instructions.

9

Map reading lights switch 7, 8

Press switch 7, 8 to turn on/off left or-

right map reading light independently.

Front mood light 9

Front mood light 9 comes on when the

illumination is turned on.

9

7

8

3.25

INTERIOR LIGHTING (3/3)

Glove box light

Glove box light 11 comes on when the

illumination is turned on.

12

Boot lights

Light  12 comes on when the boot is

opened.

11

3.26

Centre console storage

compartment 4

Front sun visor

Lower sun visor 2.

Courtesy mirrors

Lift the cover 3.

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Front door storage pockets 1

They can hold a 1.5-litre bottle.

PASSENGER COMPARTMENT STORAGE, FITTINGS

(1/5)

1

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

4

When driving, ensure the

courtesy mirror cover is

closed. Risk of injury.

3

2

3.27

Front centre armrest storage

compartment 10

With the sliding armrest 8 in its rear-

most position, lifting the control 9 and

raise the armrest.

Cup holders 5

This can be used for storing a mobile

ashtray, cup holder, etc.
Slide the curtain 6 to open the storage

compartment.

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of injury if hot liquid

escapes.

PASSENGER COMPARTMENT STORAGE, FITTINGS

(2/5)

5

Raise the button 7 to ventilate the stor-

age according to the temperature set

by the air conditioner. Lower the button

to stop the function.

8

9

10

7

6

Do not kneel down or foot

on the armrest. There is a

risk of injury.

Do not insert your finger

while sliding the armrest.

There is a risk of injury.

3.28

PASSENGER COMPARTMENT STORAGE, FITTINGS

(3/5)

Glove box

To open the glove box, lift the catch 11.

11

12

Grab handle 12

This offers support and can be held

when the vehicle is being driven.
Do not use it for getting into or out of

the vehicle.

13

12

Clothes hooks 13

12

3.29

PASSENGER COMPARTMENT STORAGE, FITTINGS

(4/5)

Sunglasses holder 15

(depending on the vehicle)
Push 15 to open the sunglasses holder.

16

Front seat storage pockets 16

15

Coin holder 14

(depending on the vehicle)

14

3.30

Rear door storage

compartment 18

PASSENGER COMPARTMENT STORAGE, FITTINGS

(5/5)

18

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

Rear armrest with cup holder

Pull down the armrest 17.

17

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of injury if hot liquid

escapes.

3.31

Ashtray location 1

Cigarette lighter or

accessories sockets 2

With the ignition on, push in the ciga-

rette lighter 2 - it will spring back with a

click when it is ready. Pull it out to use.
After use, replace it without pushing it

all the way in.

Accessories sockets 3

They are provided for connecting ac-

cessories approved by our Technical

Department.

ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET

If your vehicle is not fitted with a

cigar lighter and an ashtray, these

can be obtained from an approved

Dealer.

2

1

3

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

3

3.32

The headrest is a safety

component; check that it is

fitted and in the correct po-

sition. The top of the head-

rest should be as close as possible

to the top of the head.

Centre seat headrest  storage

position

Press the button A and lower the cen-

tral headrest 1 completely.
When the headrest is set at the

lowest position, this is for storage

only. It should not be in this position

when a seat is occupied.

Position for use

Lift the headrest to maximum height,

then lower it until it locks.

To remove a headrest

Raise the headrest as far as it will go,

then press button A and remove the

headrest.

To refit a headrest

Insert the rods in the holes, press the

button A and lower the headrest. Check

that it is correctly locked in place.

REAR HEADRESTS

A

Note: When the headrest need to be

reassembled, pay attention to its posi-

tion which is drawn in the label.

3.33

To replace the seatback, proceed in

the reverse order to removal.

Refit the seatback and click it back into

place.

REAR BENCH SEAT

(1/3)

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

When moving the rear

seats, ensure that nothing

obstructs the anchorage

points (passenger’s arm or

leg, a pet, gravel, cloth, toys, etc.).

A

1

The configuration of the

two-seat bench with the

small seatback B pulled

down, does not allow the

central seat to be used as it would

be impossible to buckle the seat belt

(belt buckles inaccessible).

When refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

To manually fold down the

seatbacks

Ensure that the front seats are far

enough forward.

Lower the headrests fully.

Pull the control 1 and lower the seat-

back A.

B

3.34

To automatically fold down

the seatbacks (flat position)

Place seat belt in hook 2 to avoid dam-

aging the belt. From the boot, pulling

the control 3 enables you to automati-

cally unlock the rear bench seatbacks

to get a flat floor.

Conditions of use
– Vehicle stationary;
– tailgate open;
–  rear seat belts unlocked.

Operating fault
If all user conditions have been ful-

filled and the folding action still fails to

operate, please contact an authorised

dealer.

REAR BENCH SEAT

(2/3)

When moving the rear

seats, ensure that nothing

obstructs the anchorage

points (passenger’s arm or

leg, a pet, gravel, cloth, toys, etc.).

Use restriction

It is forbidden to drive with a seatback

or a front seat folded down when there

is a passenger occupying a rear seat.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

2

3

3.35

Depending on the vehicle, if you lower

the rear seats armrest, there is a rear

seats heating controller on the rear

armrest.

Rear heated seats

(depending on the vehicle)
With the engine running, press switch 4

(for left side of the rear seat) or switch 5

(for right side of the rear seat). The in-

dicator light on the switch lights on to

confirm that the heating has been ac-

tivated.

Press the left side of the switch to select

the warmest setting or the right side of

the switch to select the average setting.
The middle position of the switch is off.

The indicator light in the switch lights

off.
The system, which has a thermostat,

decides whether heating is needed de-

pending on the position selected and

stops heating once a certain tempera-

ture has been reached.

REAR BENCH SEAT (3/3)

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

4

5
