Peugeot 5008 (2024 year). Manual in english

Ease of use and comfort

Storage compartment below the steering

wheel

Illuminated glove box

Door pockets

USB socket / Front 12 V accessory socket

(120 W)

Storage compartment or Wireless

smartphone charger

Storage compartment

10.

Cup holder

11.

Front armrest with storage

12.

USB sockets or Rear 12 V socket (120 W)

13.

Storage compartment or Rear blower

Make sure you do not leave any item in

the passenger compartment which could

act like a magnifying glass under the effect of

the sun's rays and cause a fire - risk of fire or

damage to interior surfaces!

Sun visor

► With the ignition on, raise

the concealing

flap; depending on the version, the mirror is

illuminated automatically.

This sun visor is also equipped with a ticket

holder.

Glove box

► To open the glove box, lift

the handle.

With the ignition on, the glove box is lit when

open.

It houses the front passenger airbag deactivation

switch.

Never drive with the glove box open

when a passenger is at the front. It may

cause injury during sharp deceleration!

12 V accessory socket

► Plug

in a 12 V accessory (with a maximum

rated power of 120 W) using a suitable adapter.

Observe the maximum power rating to

avoid damaging the accessory.

The connection of an electrical device

not approved by PEUGEOT, such as a

USB charger, may adversely affect the

operation of vehicle electrical systems,

causing faults such as poor radio reception or

interference with displays in the screens.

USB socket

These symbols determine the type of use of a

USB socket:

Power supply and recharging.

Likewise, plus exchange of multimedia

data with the audio system.

Likewise, plus use of smartphone

applications with the touch screen.

The USB socket allows the connection of a

portable device or a USB memory stick.

It reads the audio files that are sent to your audio

system and played via the vehicle's speakers.

Ease of use and comfort

These files can be managed using the steering-

mounted controls or those on the touch screen.

Depending on version, the USB

socket located on the centre

console also allows a smartphone to be

connected by Android Auto

or CarPlay

enabling certain smartphone applications to be

used on the touch screen.

For best results, use a cable made or approved

by the device manufacturer.

These applications can be managed using the

steering-mounted controls or the audio system

controls.

When the USB socket is used, the

portable device charges automatically.

While charging, a message is displayed if the

power drawn by the portable device exceeds

the current supplied by the vehicle.

For more information about how to use this

equipment, refer to the sections describing

the audio and telematics systems.

FOCAL

Hi-Fi system

The vehicle is equipped with a high-

fidelity

acoustic system from the French brand FOCAL

10 speakers incorporating exclusive FOCAL

technologies offer the pleasure of pure and

detailed sound inside the vehicle:

– Polyglass technology central speaker/mid-

range satellite speakers: sound immersion and

spatialisation.

– Polyglass technology woofers/mid-ranges with

high excursion: balance, dynamics and precision

of sound.

– Aluminium TNF inverted dome tweeter:

optimal sound dispersion, detailed treble.

– 12 channel active amplification - 515 Watts

Hybrid Class AB/Class D technology: breadth

and finesse in the high frequency signals, as well

as real power in the bass.

– Subwoofer with high excursion Power

Flower

triple coil technology: deep and

controlled reproduction of low frequencies.

Wireless smartphone

charger

This system allows wireless charging of a

portable device such as a smartphone, using the

magnetic induction principle, in accordance with

the Qi 1.1 standard.

The portable device to be charged must be

compatible with the Qi standard, either by design

or by using a compatible holder or shell.

A mat can also be used provided that it is

approved by the Manufacturer.

The charging area is identified by the Qi symbol.

The charger works with the engine running and

with the Stop & Start system in STOP mode.

Charging is managed by the smartphone.

With the Keyless Entry and Start system, the

charger’s operation may be briefly disrupted

when a door is opened or the ignition is switched

off.

Charging

► With the charging area clear, place a device

in its centre.

Ease of use and comfort

When the portable device is detected, the

charger’s indicator lamp lights up green. It

remains lit for the whole time that the battery is

being charged.

The system is not designed to charge

multiple devices simultaneously.

Do not leave metal objects (e.g. coins,

keys, vehicle remote control) in the

charging area while a device is being charged

- Risk of overheating or interrupting the

charging!

When using applications for a long time

in combination with wireless charging,

some smartphones may switch to thermal

safety and cause some functions to stop.

Checking operation

The state of the indicator lamp allows the

operation of the charger to be monitored.

State of the

indicator lamp

Meaning

Off

Engine switched off.

No compatible devices

detected.

Charging complete.

Fixed green

Compatible portable

device detected.

Charging.

Flashing orange

Foreign object detected in

the charging zone.

Portable device not well

centred in the charging

zone.

Fixed orange

Malfunction of the

portable device's battery

meter.

Device battery

temperature too high.

Charger malfunction.

If the indicator lamp is fixed orange:

– remove the device, then place it back in the

centre of the charging zone.

– remove the device and try again in a quarter

of an hour.

If the problem persists, have the system checked

by a PEUGEOT dealer or a qualified workshop.

Front armrest

It includes a refrigerated storage space.

Opening

► Press the lever beneath

the cover.

The cover opens in two parts.

Storage

The small removable tray can be installed in

front of or behind the storage space.

A ventilation nozzle circulates fresh air.

Ease of use and comfort

Closing

► Fold back the two parts of the cover.

Mats

Fitting

When fitting it on the driver's

side, only use

the mountings present on the carpet (a "click"

indicates proper locking).

The other mats are simply laid over the carpet.

Removing/refitting

► To remove it on the

driver's side, move the

seat backwards and unclip the fasteners.

► To refit it, position the mat and secure it by

pressing down.

► Check that the mat is secured correctly.

To avoid any risk of jamming the pedals:

– Only use mats which are suited to the

fixings already present in the vehicle; these

fixings must be used.

– Never fit one mat on top of another.

The use of mats not approved by PEUGEOT

may interfere with access to the pedals and

hinder the operation of the cruise control/

speed limiter.

The approved mats have two fasteners

located underneath the seat.

Courtesy lamps

Front courtesy lamp

Front reading lamps

Rear courtesy lamp

Rear reading lamps

Front and rear courtesy

lamps

In this position, the courtesy lamp comes

on gradually:

– when the vehicle is unlocked.

– when the key is removed from the ignition

switch.

– when a door is opened.

– when the remote control locking button is

activated, in order to locate the vehicle.

It switches off gradually:

– when the vehicle is locked.

– when the ignition is switched on.

– 30 seconds after the last door is closed.

Permanently off.

Permanent lighting.

Ease of use and comfort

In "Permanent lighting" mode, the lighting time

varies according to the circumstances:

– With the ignition off, approximately 10 minutes.

– In energy saving mode, approximately 30

seconds.

– With the engine running, unlimited.

When the front courtesy lamp is in the

"Permanent lighting" position, the rear

courtesy lamp also comes on, unless it is in

the "Permanently off" position.

To switch off the rear courtesy lamp, put it in

the "Permanently off" position.

Reading lamps

► With the ignition on, operate the

corresponding switch.

Do not place anything against the

courtesy lamps.

Interior ambient lighting

The dimmed passenger compartment lighting

improves visibility inside the vehicle when the

light is poor.

Activation/deactivation and adjustment of

the light intensity are set via the

Driving/

Vehicle

touch screen menu.

Rear fittings

12 V accessory socket

► To connect a

12 V accessory (maximum

power: 120 W), lift the cover and plug in a

suitable adaptor.

The connection of an electrical device

not approved by PEUGEOT, such as a

USB charger, may adversely affect the

operation of vehicle electrical systems,

causing faults such as poor radio reception or

interference with displays in the screens.

USB sockets

Each USB socket is used only to power or

recharge a portable device.

Rear armrest

Ease of use and comfort

The armrest incorporates two cup holders.

Ski flap

Device for storing and transporting long objects.

Opening

► With the rear armrest lowered, open the flap

by pulling its handle downwards.

► Load the objects from inside the boot.

"Aircraft" type tables

► To use

the table, lower it fully until it locks in

the low position.

► To store it, raise the table to the high position,

passing the point of resistance.

On the passenger side, do not forget to

fold it before placing the backrest in the

"table" position.

For more information on the

Front seats

, and

in particular placing the backrest in the "table"

position, refer to the corresponding section.

Do not place hard or heavy objects on

the table.

They could become dangerous projectiles in

the event of emergency braking or impact.

Side blinds

Fitted to the second row windows, they protect

the passenger compartment from the sun's rays.

► Pull the central tab to unroll the blind.

► Position the blind's clip on the hook.

Always guide the blind slowly, using the

tab, while raising or lowering it.

Storage boxes

Depending on version, the storage boxes are

fitted in the floor, at the foot of the side seats on

the second row.

Ease of use and comfort

On the left-hand side, it may also contain the

temporary puncture repair kit.

► To open them, lift the cover by the notch.

Boot fittings

Load space cover shelf

12V accessory socket (max. 120W)

Boot lamp

Rear seat folding controls

Hooks

Stowing rings

Boot floor

Storage well/Tool box under the floor

Open storage compartments

Load space cover roller

12 V accessory socket (max. 120 W)

Boot lamp

Luggage retaining strap

Storage brackets of the load space cover

roller

Armrest with cup holder and storage

compartment

Open storage compartment

Concertina panels

Stowing rings

The stowing rings are designed to secure

luggage using different types of retaining

nets.

These retaining nets are available as an

option or as an accessory.

For more information, contact a PEUGEOT

dealer or a qualified workshop.

For information on installing the

High load

retaining net

, refer to the corresponding

section.

Load space cover shelf

It consists of two sections:

– a fixed section with an open storage space.

– a movable section which rises when the boot

is opened, with an open storage space.

Ease of use and comfort

To remove the load space cover shelf:

► Unhook the two cords.

► Raise the movable section slightly, then

unclip it on each side.

► Unclip the fixed section on each side, then

take out the load space cover shelf.

The load space cover shelf can be stowed under

the boot floor.

In the event of sudden deceleration,

objects placed on the load space cover

shelf can turn into projectiles.

Load space cover roller

In the 5-seat configuration, it is installed behind

the second row seats, with the third row seats

stored folded away.

In the 7-seat configuration, it is stored behind the

third row seats.

In the event of sudden deceleration,

objects placed on the load space cover

roller can turn into projectiles.

Installation

► Position the left-hand and right-hand ends of

the roller in cut-outs

, with the moving flap at

the front.

► Unwind the roller until it reaches the boot

pillars.

► Insert the roller guides into the rails in pillars

Removal

► Remove the roller guides from the rails in

pillars

► Guide the roller as it reels in.

► Unlock the roller by pressing one of the

handles located at the ends of the roller bracket.

Storage behind the 3

row seats

► Make sure that the 3

row seats are folded.

► Fold the first two concertina panels.

Ease of use and comfort

► Position the roller within the space located

above the armrest, one side after the other, tilting

it slightly.

► Slide the roller as far as possible, until it

reaches the notches at the back of the boot, with

the two hinges facing down.

► Unfold the 3

row seats.

The folded concertina panels can be placed in

the horizontal or upright position.

To fold the 3

row seats with the roller stored at

the back, it is necessary to raise the concertina

panels in order to give access to the seat

unlocking controls (red straps).

High load retaining net

This removable net allows the entire loading

volume up to the roof to be used:

– behind the front seats (1

row) when the rear

seats are folded down.

– behind the rear seats (2

row) when the load

space cover is removed.

It protects the occupants in case of

sudden braking.

Behind the front seats

(Depending on version)

► Fold

down the rear seats.

► Remove the trim covers on each side,

located in the upper section in the roof.

► Position the net's upper hooks in the roof.

► Attach the net’s straps to the lower anchorage

points, located directly below the fixings of the

rear bench seat cushion.

► Pull on the straps to stretch the net.

Once fitted, the net does not prevent

tipping of the rear backrests.

Ease of use and comfort

Behind the rear seats

► Remove the load space cover.

► Remove the trim covers on each side,

located in the upper section in the roof.

► Position the net's upper hooks in the roof.

► Attach the straps of the net to the lower rings,

located on each side trim of the boot.

► Pull on the straps to stretch the net.

Behind the front seats

► Fold down the rear seats.

► Insert the ends of the bar, one after the other,

into the fixing points in the roof.

► Remove the caps from the Top Tether fixings.

► Attach the net’s straps to the lower anchorage

points, located in the housing of the Top Tether

fixings.

► Pull on the straps to stretch the net.

Behind the rear seats

► Remove the load space cover roller.

► Insert the ends of the bar, one after the other,

into the fixing points in the roof.

► Attach the straps of the net to the lower rings,

located on each side trim of the boot.

► Pull on the straps to stretch the net.

2-position boot floor

This two-position floor allows the

boot volume to

be optimised using the lateral stops located on

the sides:

– High position (

100 kg max

.): to obtain a flat

floor up to the front seats, when the rear seats

are folded down.

– Low position (

150 kg max

.): maximum boot

volume.

Ease of use and comfort

On certain versions, the adjustable boot

floor cannot be fitted in the low position.

To change the height:

► Lift and pull the floor towards you using its

central handle, then use the lateral stops to

move it.

► Push the floor all the way forwards to place it

in the desired position.

To keep it in the inclined position:

► From the high position, lift the floor towards

the load space cover.

► Take it past the retractable stops, then rest

the floor on these stops.

Storage well

► Lift the boot floor as far as

possible or lift the

articulated boot mat (depending on version) to

access the storage well.

Depending on version, it includes:

– A temporary puncture repair kit with the tool

kit.

– A spare wheel with the tool kit.

– The traction battery charging cable

(Rechargeable hybrid).

The load space cover can also be stored here

(depending on version).

12 V accessory socket

► To connect a 12 V accessory (maximum

power: 120 W), lift the cover and plug in a

suitable adaptor.

► Switch on the ignition.

The connection of an electrical device

not approved by PEUGEOT, such as a

USB charger, may adversely affect the

operation of vehicle electrical systems,

causing faults such as poor radio reception or

interference with displays in the screens.

Boot lamp

It comes on automatically when the boot is

opened and

goes off automatically when the

boot is closed.

The lighting time varies according to the

circumstances:

– When the ignition is off, approximately 10

minutes.

– In energy saving mode, approximately 30

seconds.

– With the engine running, unlimited.

Lighting and visibility

Lighting control stalk

Main lighting

Automatic illumination of lamps/daytime

running lamps

Sidelamps only

Dipped or main beam headlamps

Highway function

With "Full LED" technology headlamps,

the range of the dipped beam headlamps is

automatically increased once the speed of the

vehicle is above 68 mph (110 km/h).

Foggy function

With "Full LED" technology headlamps,

in order to limit the “whiteout” effect when

driving in fog, the brightness of the dipped

beam headlamps is decreased automatically

when the rear foglamps are switched on.

These two functions are activated/

deactivated via the

Adaptive lighting

menu of the touch screen.

Headlamp dipping

► Pull the lighting control stalk to switch

between dipped and main beam headlamps.

In "

AUTO

" and sidelamps mode, pull the lighting

control stalk to switch the main beam headlamps

on directly ("headlamp flash").

Display

Illumination of the corresponding indicator

lamp on the instrument panel confirms that the

selected lighting is on.

A fault with a lamp is signalled by the

permanent illumination of this warning

lamp, accompanied by the display of a message

and an audible signal.

Rear foglamps

They only work if the dipped or main

beam headlamps are on.

► Rotate the ring forwards/backwards to turn

them on/off.

When the lighting is switched off automatically

AUTO

" position) the foglamps and the dipped

beam headlamps remain on.

Switching on the foglamps is prohibited

in clear weather or in rain, both day and

night. In these situations, the power of their

beams may dazzle other drivers. They must

only be used in fog or falling snow (rules may

vary depending on country).

Do not forget to switch off the foglamps when

they are no longer necessary.

Switching off of the lamps when the

ignition is switched off

When the ignition is switched off, all of the

lamps turn off immediately, except for dipped

beam headlamps if automatic guide-me-home

lighting is activated.

Switching on the lamps after

switching off the ignition

To reactivate the lighting control, rotate the

ring to the "

AUTO

" position, then to the

desired position.

Lighting and visibility

If the driver's door is opened, a temporary

audible signal warns the driver that the lamps

are on.

They will go off automatically after a period

of time that depends on the level of charge in

the battery (entering energy economy mode).

In some weather conditions (e.g. low

temperature or humidity), misting on the

internal surface of the glass of the headlamps

and rear lamps is normal, and will disappear

after the lamps have been on for a few

minutes.

Never look too closely at the light beam

of LED technology lamps - risk of serious

eye injury!

Travelling abroad

Vehicles equipped with manual

headlamp beam height adjustment:

If planning to use your vehicle in a country

that drives on the other side of the road, the

dipped beam headlamps must be adjusted to

avoid dazzling oncoming drivers. Contact a

PEUGEOT dealer or a qualified workshop.

Daytime running lamps/

Sidelamps

These LED lamps at the front and rear of the

vehicle light up automatically when the engine

starts.

They perform the following functions:

– Daytime running lamps (lighting control stalk

at position

"AUTO

" with adequate ambient light).

– Sidelamps (lighting control stalk at position

AUTO

" with low ambient light or "Sidelamps

only" or "Dipped/main beam headlamps").

Direction indicators

► Left or right: lower or raise the lighting control

stalk, beyond the point of resistance.

If you keep the direction indicators on for

more than 20 seconds, the volume of the

audible signal will increase if the speed is

above 50 mph (80 km/h).

Three flashes

► Press briefly upwards or downwards, without

going beyond the point of resistance; the

direction indicators will flash 3 times.

The lighting of the rear LED direction indicators

is scrolling.

Parking lamps

(Depending on version)

Vehicle side marking by lighting the sidelamps

on the traffic side only.

► Within one minute after switching off the

ignition, operate the lighting control stalk

upwards or downwards, depending on the side

of the traffic (e.g. when parking on the right, push

the lighting control stalk down to light up on the

left).

This is confirmed by an audible signal and the

lighting of the corresponding direction indicator

lamp on the instrument panel.

► To switch off the parking lamps, return the

lighting control stalk to the central position.

Lighting and visibility

Headlamp beam height

adjustment

Manual adjustment of LED

technology headlamps

To avoid dazzling other road users, the height

of these headlamp beams must be adjusted

according to the load in the vehicle.

0 (Initial setting)

Driver only or driver + front passenger

5 people

Not used

5 people + load in the boot

Not used

Driver only + load in the boot

Not used

0 (Initial setting)

Driver only or driver + front passenger

Driver only or driver + front passenger + row 3

7 people

7 people + load in the boot

Not used

Driver only + load in the boot

Not used

Automatic adjustment of

the Full LED technology

headlamps

This system automatically adjusts the height

of the headlamp beams according to different

parameters (e.g. vehicle load).

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

The system places the headlamp beams in the

lowest position.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Do not touch the Full LED technology

headlamps - risk of electrocution!

Automatic illumination of

lamps

With the lighting control stalk in the “

AUTO

”

position and if a low level of exterior brightness

is detected by the rain/sunshine sensor, the

sidelamps and dipped beam headlamps are

switched on automatically, without any action on

the part of the driver. They may also come on if

rain is detected, at the same time as automatic

operation of the windscreen wipers.

As soon as the brightness returns to a sufficient

level or after the windscreen wipers are switched

off, the lamps are switched off automatically.

Malfunction

In the event of a malfunction of the rain/

sunshine sensor, the vehicle’s lamps

come on and this warning lamp is displayed on

the instrument panel, accompanied by an

audible signal and/or the display of a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Do not cover the rain/sunshine sensor

located at the top centre of the

windscreen behind the interior rear view

mirror; the associated functions would no

longer be controlled.

In fog or snow, the rain/sunshine sensor

may detect sufficient light. For this

Lighting and visibility

reason, the lighting will not come on

automatically.

The inner surface of the windscreen may

become misted up and affect the proper

operation of the rain/sunshine sensor.

In humid and cold weather, demist the

windscreen regularly.

Guide-me-home and

welcome lighting

Guide-me-home lighting

With the ring of the lighting control stalk in the

AUTO

" position and when the light is poor, the

dipped beam headlamps come on automatically

when the ignition is switched off.

You can activate/deactivate this function

and adjust the guide-me-home lighting

duration in the

Driving

Vehicle

touch screen

menu.

Welcome lighting

When the vehicle is unlocked, if the ambient

light is low and the "Automatic illumination of

headlamps" function is activated, this system

automatically turns on certain exterior lamps

as well as certain lamps in the passenger

compartment.

You can activate/deactivate this function

and adjust the welcome lighting duration

in the

Driving

Vehicle

touch screen menu.

Door mirror spotlamps

These spotlamps facilitate access to the vehicle

by lighting the ground near the front doors.

When the front courtesy lamp switch is in

this position, the spotlamps come on

automatically:

– when the vehicle is unlocked.

– when a door is opened.

– when a request to locate the vehicle is

received from the remote control.

Whatever the position of the front courtesy lamp

switch, they also come on with the welcome

lighting and guide-me-home lighting functions.

They go off automatically after 30 seconds.

Automatic lighting

systems - General

recommendations

The automatic lighting systems use a detection

camera, located at the top of the windscreen.

Operating limits

The system may be disrupted or not work

correctly:

– When visibility conditions are poor

(e.g. snowfall, heavy rain).

– If the windscreen is dirty, misted-up or

masked (e.g. sticker) in front of the camera.

– If the vehicle is facing highly reflective signs

or safety barrier reflectors.

The system is not able to detect:

– Road users that do not have their own

lighting, such as pedestrians.

– Vehicles with hidden lighting (e.g. travelling

behind a safety barrier on the motorway).

– Vehicles at the top or bottom of a steep

slope, on winding roads, on crossroads.

Maintenance

Clean the windscreen regularly,

particularly the area in front of the camera.

The internal surface of the windscreen can

also become misted around the camera.

In humid and cold weather, demist the

windscreen regularly.

Do not allow snow to accumulate on the

bonnet or roof of the vehicle as this could

obstruct the camera.

Automatic headlamp

dipping

For more information, refer to the

General recommendations for

automatic lighting systems

Lighting and visibility

With the ring of the lighting control stalk in the

AUTO

" position and the function activated on

the touch screen, this system automatically

switches between dipped and main beam

headlamps, according to lighting and traffic

conditions, using a camera located at the top of

the windscreen.

This system is a driving aid.

The driver remains responsible for

the vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

and for compliance with driving and vehicle

regulations.

The system becomes operational when

the vehicle exceeds 16 mph (25 km/h).

When the speed falls below 9 mph (15 km/h),

the function is no longer operational.

Activation/Deactivation

The settings are changed via the

Driving/

Vehicle

touch screen menu.

The state of the system is stored when the

ignition is switched off.

Operation

If the ambient light level is very low and traffic

conditions permit:

– The main beam headlamps

come on automatically. These

indicator lamps light up on the instrument panel.

If the ambient light level is sufficient and/or the

traffic conditions do not allow the main beam

headlamps to be lit:

– The dipped beam headlamps

remain lit. These indicator lamps

light up on the instrument panel.

The function is deactivated if the foglamps

are switched on or if the system detects poor

visibility conditions (e.g. fog, heavy rain,

snowfall).

When the foglamps are switched off or when the

visibility conditions become favourable again, the

function is automatically reactivated.

This indicator lamp goes out when the

function is deactivated.

Pause

If the situation requires a change of headlamp

beam, the driver can take over at any time.

► Switch the headlamps manually between

dipped and main beam to pause the function.

If the "AUTO" and "Dipped beam" indicator

lamps were on, the system changes to main

beam.

If the "AUTO" and "Main beam" indicator lamps

were on, the system changes to dipped beam.

► To reactivate the function, once again switch

the headlamps manually between dipped and

main beam.

Static cornering lighting

With the dipped or main beam headlamps on,

this function allows headlamps to illuminate

the inside of a bend using light-emitting diodes

(LEDs).

The speed of the vehicle must be less than 56

mph (90 km/h).

This function is only available with the "Full LED"

technology headlamps.

Lighting and visibility

Activation / Deactivation

It is set via the

Driving / Vehicle

touch

screen menu.

Switching on / off

This system operates from a certain angle of

rotation of the steering wheel.

The system does not operate:

– below a certain angle of rotation of the

steering wheel.

– above 56 mph (90 km/h),

– when reverse gear is engaged.

Night Vision

This system identifies and signals the presence

of pedestrians and animals in the driver's field

of vision, in low exterior light conditions, using

an infrared camera located at the front of the

vehicle.

Select the "

Night vision

" display mode if you

want the infrared camera image to be displayed

constantly on the instrument panel. When the

conditions are met, an alert is triggered if there is

a risk of collision.

The permanent display disappears upon

switching off the ignition or if the conditions are

not met.

This system is a driving aid system that

cannot, under any circumstances,

replace the driver's assessment of night-time

visibility and traffic conditions.

In some cases, the differences in temperature

are insufficient and the system may not detect

all dangers or, conversely, it may give false

warnings (e.g. engines of lorries parked by

the side of the road).

Activation/Deactivation

This function is set via the

Driving/

Vehicle

touch screen menu.

Conditions for operation

– With the engine running and in Stop mode

of Stop & Start.

– Very low light conditions with dipped beam

headlamps on and in good working order.

– Temperature between -30°C and +28°C.

– Speed below 99 mph (160 km/h).

– Detection of animals taller than 0.50 m.

Operation

If the function is selected but the display

on the instrument panel and the alerts are

not available (in "

Night Vision

"mode), the

indicator lamp comes on in grey.

If all operating conditions are met, the

indicator lamp comes on in green: the

display on the instrument panel (with "

Night

Vision

" mode selected) and the triggering of

alerts are available.

If certain operating conditions (speed or

temperature) are not met, the indicator

lamp comes on in orange: only the display on the

instrument panel is available (in "

Night Vision

mode).

Whilst the exterior light is too bright or the dipped

beam headlamps have not been switched on,

the alerts are not available.

Lighting and visibility

The camera detection range is between 15 m

(for pedestrians) and 200 m, depending on

visibility conditions.

The image provided by the camera is displayed

in shades of grey in the instrument panel; warm

objects appear brighter than cold objects.

If pedestrians or animals are detected, they

appear in yellow frames.

If the system detects a risk of

collision with pedestrians or

animals, it triggers an alert: one of these symbols

appears on the instrument panel. The

corresponding silhouette is framed in red.

If the "

Night Vision

" display mode has not been

selected, the alert is triggered in the form of a

temporary window.

In the event of an alert, the driver may act by

making an avoiding manoeuvre or by braking.

Operating limits

The following situations may interfere with

the operation of the system or prevent it from

working:

– Poor visibility conditions (falling snow, heavy

rain, thick fog).

– Camera masked by snow, mud or dust.

– Camera scratched after going through roller

car washes repeatedly.

– Very high outside temperature.

– At the top or bottom of a steep slope.

– On a very winding road.

– In a bend.

– After an impact which may have impaired the

camera settings or damaged it.

– After repainting of the grille outside of the

PEUGEOT dealer network or a qualified

workshop.

Maintenance

recommendations

The infrared camera has a wash nozzle

connected to the vehicle’s front screenwash

system.

This wash nozzle does not operate every time

the front screenwash system is used. Its wash

frequency is preset in the system.

Regularly check that the infrared camera is

clean.

In bad weather, or in wintry conditions, ensure

that the infrared camera is not covered with mud,

ice or snow.

Malfunction

If the event of a malfunction, this warning

lamp comes on in orange on the

instrument panel, accompanied by the display of

a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Wiper control stalk

Before operating the wipers in wintry

conditions, clear any snow, ice or frost

from the windscreen and around the wiper

arms and blades.

Do not operate the wipers on a dry

windscreen. In extremely hot or cold

weather, check that the wiper blades are not

stuck to the windscreen before operating the

wipers.

After using an automatic car wash, you

may temporarily notice abnormal noises

and poorer wiping performance. You do not

need to replace the wiper blades.

Windscreen wipers

Lighting and visibility

► To select the wiping speed: raise or lower the

stalk to the desired position.

Fast wiping (heavy rain)

Normal wiping (moderate rain)

Intermittent wiping (proportional to the

vehicle’s speed)

Switching off

Automatic wiping

Refer to the corresponding section.

Single wipe

► Pull the stalk briefly towards you.

In position

, the wiping frequency is

automatically reduced when the speed of

the vehicle drops below 3 mph (5 km/h).

When the speed is above 6 mph (10 km/h)

again, the wiping frequency returns to the

original frequency (fast or normal).

If the ignition has been switched off with

the windscreen wipers active, you must

operate the control stalk again to reactivate

wiping when the ignition is switched on again

(unless the ignition was off for less than

a minute).

After the ignition has been switched off,

the wipers may move slightly at the foot

of the windscreen.

Windscreen wash

► Pull the wiper control stalk towards you and

hold.

A final wiping cycle is performed when

screenwashing ends.

The windscreen wash jets are

incorporated into the tip of each wiper

arm.

Screenwash fluid is sprayed along the length

of the wiper blade. This improves visibility and

reduces screenwash fluid consumption.

To avoid damaging the wiper blades, do

not operate the screenwash if the

screenwash reservoir is empty.

Only operate the screenwash if there is no

risk of the fluid freezing on the windscreen

and hindering visibility. During the winter

period, use "very cold climate" rated products.

Never top up with water.

Rear wiper

►

Turn the ring to align the desired symbol with

the marking.

Off

Intermittent wiping

Screenwash-wipe

Reverse gear

When reverse gear is engaged, the rear wiper

will come into operation automatically if the front

windscreen wipers are operating.

The settings are changed via the

Driving/

Vehicle

touch screen menu.

In the event of accumulation of snow or

hard frost or if a bicycle carrier is fitted to

a towing device, deactivate the automatic rear

wiper via the vehicle configuration menu.

Rear screenwash

► Turn the ring as far as it will go and hold it in

position.

The screenwash and the wiper operate for as

long as the ring remains turned.

Lighting and visibility

A final wiping cycle is performed when screen

washing ends.

Automatic windscreen

wipers

AUTO

mode, the windscreen wipers operate

automatically and adapt to the intensity of the

rainfall.

Detection is via a rain/brightness sensor, located

at the top centre of the windscreen behind the

rear view mirror.

Do not cover the rain/sunshine sensor.

When using an automatic car wash,

switch off the automatic wipers and the

ignition.

In winter, wait until the windscreen is

completely clear of ice before activating the

automatic wipers.

Switching on

► Give a short downwards push to the control

stalk.

A wiping cycle confirms that the instruction has

been accepted.

This indicator lamp lights up on the

instrument panel, accompanied by a

message.

Switching

off

► Give the control stalk another brief push

downwards or place the control stalk in another

position (

Int

This indicator lamp goes off in the

instrument panel, accompanied by a

message.

If the ignition has been off for more than

one minute, the automatic wipers must

be reactivated by pushing the control stalk

downwards.

Malfunction

If a fault occurs with the automatic wipers, the

wipers operate in intermittent mode.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Changing a wiper blade

Special position of the

windscreen wipers

This maintenance position is used while cleaning

or replacing the wiper blades. It can also be

useful, in wintry weather (ice, snow), to release

the wiper blades from the windscreen.

To maintain the effectiveness of the flat

wiper blades, it is advisable to:

– handle them with care.

– clean them regularly using soapy water.

– avoid using them to hold cardboard on the

windscreen.

– replace them at the first signs of wear.

Before removing a windscreen wiper blade

Operating the wiper control stalk within one

minute after switching off the ignition will place

the wiper blades in a vertical position.

► Proceed with the desired operation or the

replacement of the wiper blades.

After refitting a windscreen wiper blade

► To return the wiper blades to their initial

position after the operation, switch on the ignition

and operate the wiper control stalk.

Lighting and visibility

Removing/Refitting at the

front

► Carry out these wiper blade replacement

operations from the driver's side.

► Starting with the wiper blade farthest from

you, hold each arm by the rigid section and raise

it as far as possible.

Take care not to hold the arms at the jet

locations.

Do not touch the wiper blades - risk of

irreparable deformation.

Do not release them while moving them. Risk

of damaging the windscreen!

► Clean the windscreen using screenwash

fluid.

Do not apply "Rain X" type water-

repellent products.

► Unclip the worn wiper blade closest to you

and remove it.

► Install the new wiper blade and clip it to the

arm.

► Repeat the procedure for the other wiper

blade.

► Starting with the wiper blade closest to you,

once again hold each arm by the rigid section,

then guide it carefully onto the windscreen.

Removing/refitting at the

rear

► Hold the arm by the rigid section and raise it

as far as possible.

► Clean the rear screen using screenwash

fluid.

► Unclip the worn wiper blade and remove it.

► Install the new wiper blade and clip it to the

arm.

► Once again hold the arm by the rigid section,

then guide it carefully onto the rear screen.

Safety

General safety

recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

For all work on your vehicle, use a

qualified workshop that has the technical

information, skills and equipment required, all

of which a PEUGEOT dealer is able to

provide.

Depending on country regulations,

certain safety equipment may be

mandatory: high visibility safety vests,

warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories

The fitting of electrical equipment or

accessories not approved by PEUGEOT may

cause excessive current consumption and

faults and failures with the electrical system

of your vehicle. Contact a PEUGEOT dealer

for information on the range of approved

accessories.

As a safety measure, access to the

diagnostic socket

, used for the vehicle's

electronic systems, is reserved strictly for

PEUGEOT dealers or qualified workshops,

equipped with the special tools required (risk

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

serious accidents). The Manufacturer cannot

be held responsible if this advice is not

followed.

Any modification or adaptation not intended

or authorised by PEUGEOT or carried out

without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication

transmitter with an external aerial, you must

without fail contact a PEUGEOT dealer for

the specification of transmitters which can

be fitted (frequency, maximum power, aerial

position, specific installation requirements), in

line with the UN ECE Regulation 10.

Declarations of conformity for radio

equipment

The relevant certificates are available on the

brand website:

http://public.servicebox.peugeot.com/APddb/

Hazard warning lamps

► Pressing this red button causes all the

direction indicators to flash.

They can work with the ignition switched off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on

the rate of deceleration, the hazard warning

Safety

lamps come on automatically. They switch off

automatically when you next accelerate.

They can be turned off by pressing the button

again.

Horn

► Press the central part of the steering wheel.

Pedestrian horn (Hybrid

or Rechargeable hybrid)

This system alerts pedestrians that the vehicle is

approaching, when driving in all-electric.

The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** Depending on the geographic coverage provided by the "eCall (SOS)" and "ASSISTANCE" systems.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

This function cannot be deactivated.

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Emergency or assistance

call

eCall (SOS)

ASSISTANCE

eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.

The eCall (SOS) system provides direct contact

to the emergency services and is fully built

into the vehicle. This contact is made either

automatically via the sensors built into the

vehicle, or by pressing button

According to the country of sale, the eCall (SOS)

system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

► To make an emergency call manually, press

button

for more than 2 seconds.

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.

The eCall (SOS) system immediately locates

your vehicle and puts you in contact with the

appropriate emergency services**.

► Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when

communication is established.

In the event that a serious accident is

detected by the sensors built into the

vehicle, such as the airbag control unit, an

emergency call is made automatically.

The eCall (SOS) system is a public

service of general interest and is

free-of-charge.

Safety

System operation

– Upon switching on the ignition, if the indicator

lamp lights up red, then green, and then goes

out: the system is operating correctly.

– If the indicator lamp is fixed red: system

malfunction

– If the indicator lamp flashes red: replace the

emergency battery.

In the latter two cases, emergency and

assistance call services may not work.

Contact a dealer or a qualified repairer as soon

as possible.

The system fault does not prevent the

vehicle from being driven.

Data processing

All processing of personal data by

the eCall (SOS) function complies with

the framework for protection of personal

information established by Regulation

2016/679 (General Data Protection

Regulation - GDPR) or by UK GDPR

(Data Protection, Privacy and Electronic

Communications) Regulations 2019 and

Directive 2002/58/EC of the European

Parliament and the Council, and in particular,

seeks to protect the vital interests of the data

subject, in accordance with Article 6 (1) d)

GDPR.

The processing of personal data is strictly

limited to the purpose of handling the eCall

(SOS) function used with the "112" single

European emergency call number.

The eCall (SOS) function is only able to

collect and process the following data

relating to the vehicle: vehicle identification

number, vehicle type (passenger vehicle or

light commercial vehicle), fuel type or power

source, three most recent locations and

direction of travel, number of passengers

and a timestamped log file of the automatic

activation of the system and its timestamp.

The recipients of the processed data are the

emergency call handling centres designated

by the relevant national authorities in the

territory in which they are located, enabling

priority routing and handling of calls to the

"112" emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until

a call is made. The system is not traceable

and is not continuously monitored in its

normal operating mode.

The data in the system's internal memory is

automatically and continuously erased. Only

the vehicle’s three most recent locations,

necessary for the normal functioning of the

system, are stored.

When an emergency call is triggered, the data

log is stored for no more than 13 hours.

Access to data

You have the right of access to data and

as appropriate to request the rectification,

erasure or restriction of processing of any

personal data not processed in accordance

with the provisions of GDPR. Third parties

to which data has been disclosed shall

be notified of any rectification, erasure or

restriction carried out in compliance with

the corresponding GDPR, unless it proves

impossible or involves a disproportionate

effort.

You also have the right to lodge a complaint

with the respective data protection

supervisory authority.

If you want to claim your above-mentioned

rights please contact us per email at:

privacyrights@stellantis.com.

For more information regarding our contact

details please take a look at our Privacy &

Cookies Policy on the brand's website.

Safety

ASSISTANCE

► If the vehicle breaks down, press button

for more than 2 seconds to request assistance

(confirmed by a voice message*).

► Pressing again immediately cancels the

request.

Privacy mode allows you to manage the

level of sharing (data and/or location)

between your vehicle and PEUGEOT.

It can be configured in the

Settings

touch

screen menu.

By default, depending on equipment,

deactivate/reactivate geolocation by

simultaneously pressing the 2 buttons, then

press the "ASSISTANCE" button to confirm.

If you purchased your vehicle outside the

PEUGEOT dealer network, we invite you

to have a dealer check the configuration of

these services and, if desired, modify them to

suit your wishes. In a multilingual country,

configuration is possible in the official national

language of your choice.

For technical reasons, in particular to

improve the quality of telematic services

for customers, the Manufacturer reserves the

* Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems and the official national language chosen by the owner of the

vehicle.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

right to carry out updates to the vehicle's

on-board telematic system at any time.

If you benefit from the Peugeot Connect

Packs offer with the SOS and Assistance

Pack included, there are additional services

available to you in your personal space, via

the website for your country.

For information about the SOS and

Assistance Pack, please refer to the general

conditions for these services.

Event Data Recording

system

(Depending on country of sale)

This vehicle is fitted with an accident data

recording system, also called Event Data

Recorder (EDR).

This system gathers and records certain vehicle

data over a short period (a few seconds) before,

during and after an event such as an accident or

collision.

In order to gain a better understanding of the

circumstances surrounding the event, this

system records how the vehicle’s various

systems are operating at the time of the event,

including:

– Any deployment of a restraint system

(e.g. airbag, seat belt).

– The status of the seat belts of all the

occupants (fastened/unfastened).

– The contact or intensity of pressure exerted on

the pedal(s) engaged by the driver.

– The speed of the vehicle.

– The status of some driving and manoeuvring

aids systems.

The following are not recorded by the system:

– Data on normal driving conditions, in other

words data not directly related to the event.

– Personal data on the driver and any other

occupants.

– The geographical location of the vehicle at the

time of the event.

The reading of data recorded by the system

requires the following:

– Access to the interior of the vehicle or to the

system.

And

– Special equipment that can be purchased from

the manufacturer BOSCH (www.BoschCDRTool.

com).

Aside from the vehicle Manufacturer, other

parties such as law enforcement agencies may

access this data in order to analyse the event.

Safety

Electronic stability control

(ESC)

The electronic stability control programme

includes the following systems:

– Anti-lock braking system (ABS) and Electronic

brake force distribution (EBFD).

– Emergency braking assistance (EBA).

– Anti-slip regulation (ASR).

– Dynamic stability control (DSC).

– Trailer stability assist (TSA).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

ABS prevents wheel locking in the event of

emergency braking.

Electronic brake force distribution (EBFD)

manages overall braking pressure on each

individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

Normal operation of the ABS may make

itself felt by slight vibrations of the brake

pedal.

The fixed illumination of this warning lamp

signals that there is a fault with the ABS.

The vehicle retains conventional braking. Drive

carefully at a moderate speed.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

This warning lamp, when lit together with

the

STOP

and ABS warning lamps,

accompanied by a message and an audible

signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a PEUGEOT dealer or a qualified

workshop.

When changing wheels (tyres and rims),

ensure that these are approved for your

vehicle.

After an impact

Have it checked by a PEUGEOT dealer

or a qualified workshop.

Emergency braking

assistance (EBA)

This system reduces the emergency stopping

distance, by optimising the braking pressure.

It is triggered in relation to the speed at which

the brake pedal is depressed. The effect of this

is a reduction in the resistance of the pedal and

an increase in braking efficiency.

Intelligent traction control

(Depending on version)

The intelligent traction control system helps

improve grip when driving on snow.

This system detects situations of poor surface

grip that could make it difficult to move off

or make progress on deep fresh snow or

compacted snow.

In these situations, the system limits the amount

of wheel spin to provide the best traction and

trajectory control for the vehicle.

The use of winter tyres is strongly

recommended on slippery surfaces.

Anti-slip regulation (ASR)

/ Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying

the brakes on the driving wheels to avoid one

or more wheels spinning. It also enhances the

vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the

dynamic stability control system automatically

uses engine braking and the brakes on one or

more wheels to return the vehicle to the desired

path, within the limits of the laws of physics.

These systems are activated automatically every

time the vehicle is started.

Safety

These systems are activated in the event

of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (starting a vehicle

which is bogged down, stuck in snow, on soft

ground, etc.), it may be advisable to deactivate

the ASR system, so that the wheels can turn

freely and regain grip.

Reactivate the system as soon as the level of

grip permits.

This function is set via the

Driving/

Vehicle

touch screen menu.

Deactivation is confirmed by the lighting

of this indicator lamp on the instrument

panel and the display of a message.

The ASR system is reactivated automatically

every time the ignition is switched off, or at

speeds over 31 mph (50 km/h).

Reactivation is manual below 31 mph (50 km/h).

Malfunction

In the event of a malfunction, this warning

lamp comes on on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage

the driver to take extra risks or drive at high

speed.

It is in conditions of reduced grip (rain, snow,

ice) that the risk of loss of grip increases. It

is therefore important for your safety to keep

these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends

on compliance with the manufacturer's

recommendations relating to the wheels

(tyres and rims), braking and electronic

components, as well as the assembly and

repair procedures provided by PEUGEOT

dealers.

In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information

Identification markings

, refer to the

corresponding section.

Trailer stability assist (TSA)

When towing, this system reduces the risk of the

vehicle or trailer snaking.

Operation

The system is activated automatically when the

ignition is switched on.

The electronic stability control system (ESC)

must not have any faults.

The vehicle speed must be between 37 and 99

mph (60 and 160 km/h).

If the system detects that the trailer is

snaking, it applies the brakes to stabilise

the trailer and reduces engine power, if

necessary, to slow the vehicle (indicated by the

flashing of this warning lamp on the instrument

panel and the brake lamps coming on).

For information on weights and towed loads,

refer to the

Engine technical data and towed

loads

section or your vehicle’s registration

certificate.

To ensure safe driving with a

Towing device

refer to the corresponding section.

Malfunction

If a fault occurs, this warning lamp lights

up on the instrument panel, accompanied

by a message and an audible signal.

To continue towing a trailer, reduce speed and

drive carefully!

Have it checked by a PEUGEOT dealer or a

qualified workshop.

The trailer stability control system

provides an extra safety feature under

normal driving conditions, when following the

recommendations for use of trailers and

Safety

current legislation in force in your country. It

must not encourage the driver to take extra

risks, such as using a trailer in unsuitable

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

tyres, faulty braking system) or driving at

excessive speed.

In certain cases, the system may not detect

trailer snaking, particularly with a light trailer.

When driving on slippery or poor surfaces, the

system may not be able to prevent sudden

trailer snaking.

Advanced Grip Control

This special patented traction control system

improves grip on snow, mud and sand.

For optimum grip on snow, it is

recommended that you fit the vehicle

with winter tyres.

For optimum system performance, contact a

PEUGEOT dealer to choose the most suitable

tyres.

Recommendations

The vehicle is designed principally

to drive on tarmac roads, but it may

occassionally drive on other less passable

terrain.

However, it does not permit off-road driving:

– Driving on terrain that can damage the

underbody or tear off elements (e.g. fuel

pipe, fuel cooler) by obstacles or stones in

particular.

– Driving on terrain with steep gradients and

poor grip.

– Crossing a waterway.

Operating modes

Snow

This mode constantly adapts the level of wheel

spin to offer maximum traction according to the

snow conditions (a lot of wheel spin in thick

snow; very little on ice). The wheel spin is also

adapted to the conditions encountered when

driving uphill by optimising the acceleration of

the vehicle.

(mode active up to 50 mph (80 km/h))

Mud

This mode, when moving off, allows considerable

spin on the wheel with the least grip to optimise

clearing of the mud and to regain grip. At the

same time, the wheel with the most grip is

controlled in such a way as to transmit as much

traction torque as possible.

When moving, the system optimises wheel spin

to respond to the driver's requirements as fully

as possible.

(mode active up to 31 mph (50 km/h))

Sand

This mode allows little spin on the two driving

wheels at the same time to allow the vehicle to

move forward and limit the risks of getting stuck

in the sand.

(mode active up to 75 mph (120 km/h))

Do not use the other modes on sand as

the vehicle may become stuck.

With manual gearbox

► Turn the selector to choose the mode

corresponding to the driving conditions

encountered.

An indicator lamp associated with each mode

comes on, accompanied by the display of a

message to confirm your choice.

Standard (ESC)

Whenever the ignition is switched off, the

system automatically resets to this mode.

Safety

Snow

Mud

Sand

ESC OFF

Deactivation of the ASR and DSC

systems.

The ASR and DSC systems will no

longer act on the operation of the engine

or of the brakes in the event of a change of

trajectory.

These systems are reactivated automatically

from 31 mph (50 km/h) or whenever the

ignition is switched back on.

With automatic gearbox

► Press the

DRIVE MODE

button; the various

modes are displayed on the instrument panel.

► Select “

Snow

”, “

Mud

” or “

Sand

” depending

on the context.

The chosen mode continues to be displayed in

the instrument panel.

► To deactivate, select “

Normal

” mode or any

other driving mode.

The system is automatically deactivated when

the ignition is switched off.

Hill Assist Descent

Control

Hill Assist Descent Control system for medium to

steep slopes, on tarmac or other road surfaces

(e.g. gravel, mud).

This system reduces the risk of slip or loss of

control of the vehicle when descending, whether

going forward or in reverse.

During a descent, the system assists the driver

in maintaining a constant speed, depending on

the gear engaged, while progressively releasing

the brakes.

For the system to activate, the gradient

must be greater than 5%.

The system can be used with the gearbox in

neutral.

Otherwise, engage a gear corresponding to

the speed to prevent the engine stalling.

With an automatic gearbox, the system can

be used with the selector at

The system is no longer available if the

speed of the vehicle is:

– above 43 mph (70 km/h).

– managed by the Adaptive cruise control

function, depending on the type of gearbox.

Switching on

By default, the system is not selected.

The state of the function is not saved when the

ignition is switched off.

► To select the system, at speeds below

31 mph (50 km/h), press this button until

its green indicator lamp lights up; this lamp

appears in grey on the instrument panel.

► The system becomes active at speeds

below 19 mph (30 km/h); this lamp lights

up in green on the instrument panel.

► When the vehicle begins its descent, the

driver can release the accelerator and brake

pedals; the system regulates the speed:

– If the gearbox is in first or second gear,

the speed decreases and the

indicator lamp flashes rapidly.

Safety

– If the gearbox is in neutral or if the clutch

pedal is depressed, the speed decreases and

the indicator lamp flashes slowly; in this case,

the maintained descent speed is lower.

On a descent, with the vehicle stationary, if the

driver releases the accelerator and brake pedals,

the system will release the brakes to set the

vehicle gradually in motion.

The brake lamps light up automatically when the

system is regulating.

If the speed exceeds 19 mph (30 km/h),

regulation is paused automatically, the

indicator lamp goes back to grey in the

instrument panel, but the green indicator lamp in

the button remains on.

Regulation resumes automatically when the

speed falls below 19 mph (30 km/h) again, if the

slope and pedal release conditions are met.

You can depress the accelerator or brake pedal

again at any time.

Switching off

► Press the button until its indicator lamp goes

off; the indicator lamp on the instrument panel

goes off.

At speeds above 43 mph (70 km/h), the system

is automatically deactivated; the indicator lamp in

the button goes off.

Malfunction

In the event of a malfunction, this warning

lamp comes on in green on the

instrument panel, accompanied by the display of

a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Seat belts

Inertia reel

The seat belts are equipped with an inertia

reel which allows the strap length to adjust

automatically to the shape of the user. The seat

belt returns to its storage automatically when it

is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a

collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a

frontal or side impact.

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, thus improving

their protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic

device may trigger before and independently

of airbag deployment. Deployment of the

pretensioners is accompanied by a slight

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

cartridge incorporated in the system.

In all cases, the airbag warning lamp comes

on.

Following an impact, have the seat belt

system checked, and if necessary replaced,

by a PEUGEOT dealer or a qualified

workshop.

Front seat belts

The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting

system.

Fastening

► Pull the strap, then insert the tongue into the

buckle.

► Check that the seat belt is fastened correctly

by pulling on the strap.

Unfastening

► Press the red button on the buckle.

► Guide the seat belt as it is reeled in.

Safety

Height adjustment

► To adjust the height of the anchorage point,

squeeze control

and slide it to the notch

desired.

Rear seat belts

Each of the rear seats has a three-point seat belt

with inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

For the centre seat, the buckle is held

horizontally by an elastic strap if the centre seat

belt is not being used.

Rear second row seat belts

Each of the rear second row seats is fitted with a

three-point selt belt with an inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

Before performing any operations on the

rear seats, to avoid damage to the seat

belts, check that:

– the outer seat belts are properly tensioned.

– the central seat belt is completely reeled in.

Rear second row central

seat belt

The seat belt for the rear central seat is built into

the roof.

Safety

Installation

► Pull the strap and insert the tongue

into the

left buckle (located on the passenger’s right side

when seated in the vehicle).

► Insert the tongue

into the right buckle

(located on the passenger’s left side when

seated in the vehicle).

► Check that each buckle is fastened correctly

by pulling the strap.

Removal and storage

► Press the red button on buckle

, then the

black button on buckle

► Guide the strap as it reels in and offer up

tongue

, then

to the magnet at the anchoring

point on the roof.

Rear third row seat belts

Installation

► Pull the strap, then insert the tongue into the

buckle.

► Check that the seat belt is fastened correctly

by pulling on the strap.

Removal and storage

► Press the red button on the buckle.

► Guide the seat belt as it is reeled in.

► Flatten the seat belt strap against the boot

side trim using the magnetic retaining system.

Ensure that seat belts are always fixed

when not in use.

Seat belt not fastened/

unfastened alerts

Not fastened/unfastened warning lamp

It comes on in red on both the instrument panel

and the front passenger airbag and seat belts

warning lamps display, once the system detects

that a seat belt is not fastened or has been

unfastened.

Seat belts not fastened/unfastened

identification indicator lamp

The red indicator lamps on the display indicate

the location of the seat belts which are not

fastened or have been unfastened.

Not fastened at the front

When the ignition is switched on, the warning

lamp and the corresponding indicator lamps light

up if the driver and/or the front passenger have

not fastened their seat belts.

Peugeot 5008 (2024 year). Manual in english - page 3
