Access

In the first case, change the remote control

battery.

In the second case, reinitialise the remote

control.

Refer to the corresponding sections.

► Insert the key in the door lock.

► Turn the key towards the front/rear to unlock/

lock the vehicle.

► Turn the key towards the rear again within

5 seconds to deadlock the vehicle.

If the vehicle is fitted with an alarm, it will

not be activated when locking with the

key.

If the alarm is activated, the siren sounds

when the door is opened; switch on the

ignition to stop it.

Central locking not

functioning

Use these procedures in the following cases:

– Central locking malfunction.

– Battery disconnected or discharged.

In the event of a malfunction of the

central locking system, the battery must

be disconnected to ensure that the vehicle is

locked fully.

Front left-hand door

► Insert the key into the lock and turn it towards

the rear of the vehicle to lock the door, or

towards the front to unlock it.

Other doors

Unlocking

► Pull the interior door opening control.

Locking

► Open the doors.

► For the rear doors, check that the child lock

is not on.

Refer to the corresponding section.

►

Remove the black cap

, located on the edge

of the door, using the key.

► Insert the key into the socket without forcing

it, then turn the latch towards the inside of the

door.

► Remove the key and refit the black cap.

► Close the doors and check from the outside

that the vehicle is locked.

Changing the battery

A message is displayed on the instrument panel

when the battery needs changing.

Battery type: CR2032/3 volts.

► Unclip the cover by inserting a small

screwdriver in the slot and lift the cover.

► Remove the flat battery from its housing.

► Put the new battery in place, respecting the

polarity. Start by inserting it into the contacts

located in the corner, then clip the cover onto

the unit.

► Reinitialise the remote control.

For more information on

Reinitialising the

remote control

, refer to the corresponding

section.

Do not throw remote control batteries

away, as they contain metals that are

Access

harmful to the environment. Take them to an

approved disposal point.

This equipment contains a button type

battery.

Do not swallow the battery. Risk of chemical

burns!

Swallowing the battery can cause serious

internal burning in only 2 hours and can be

fatal.

If batteries have been swallowed or inserted

into a part of the body, seek immediate

medical advice.

Keep new and used batteries out of the reach

of children.

If the battery compartment does not close

properly, stop using the product and keep it

out of the reach of children.

Risk of explosion if the battery is

replaced with an incorrect type!

Replace the battery with the same type.

Risk of explosion or leaking of

inflammable liquid or gas!

Do not use in/store in/place in an environment

where the temperature is extremely high or

where the pressure is extremely low due to

very high altitude.

Do not try to burn, crush or cut a used battery.

Reinitialising the remote

control

Following replacement of the battery or in

the event of a fault, it may be necessary to

reinitialise the remote control.

► Insert the mechanical key (incorporated into

the remote control) into the lock to open the

vehicle.

► Place the electronic key against the back-up

reader on the steering column and hold it there

until the ignition is switched on.

►

With a manual gearbox,

place the gear lever

in neutral then fully depress the clutch pedal.

►

With an automatic gearbox,

while in mode

, depress the brake pedal.

► Switch on the ignition by pressing the

START/STOP

" button.

If the fault persists after reinitialisation, contact

a PEUGEOT dealer or a qualified workshop

without delay.

Doors

Opening

From outside

► After unlocking the vehicle or with the

"Keyless Entry and Start" system electronic key

in the recognition zone, pull the door handle.

From inside

► Pull the interior opening control of a door; this

unlocks the vehicle completely.

With selective unlocking activated:

– Opening the driver's door unlocks

the driver's door only (if the vehicle has not

already been completely unlocked).

– Opening one of the passenger doors

unlocks the rest of the vehicle.

Boot

Opening the tailgate

Access

► With the vehicle unlocked or with the

electronic key in the recognition zone, press the

central tailgate control.

► Raise the tailgate.

When selective unlocking is activated,

the electronic key must be close to the

rear of the vehicle.

The tailgate is not designed to hold a

bicycle carrier.

Closing the tailgate

► Lower the tailgate using the interior grips.

► Release the grips and press down on the

outside of the tailgate to close it.

In the event of a malfunction or if you

experience difficulty opening or closing

the tailgate, have it checked by a PEUGEOT

dealer or a qualified workshop without delay,

to avoid the issue deteriorating and prevent

any risk of the tailgate dropping, potentially

causing serious injury.

Back-up release

To manually unlock the boot in the event of a

battery or central locking failure.

Unlocking

► Fold the rear seats to gain access to the lock

from inside the boot.

► Insert a small screwdriver into hole

of the

lock to unlock the boot.

► Move the latch to the left.

Locking after closing

If the fault persists after closing again, the boot

will remain locked.

In the event of a fault with the central

locking system, it is essential to

disconnect the battery to lock the boot and so

ensure complete locking of the vehicle.

Hands-free tailgate

(Depending on version)

The motorised tailgate must only be operated

with the vehicle stationary.

Check that there is enough space to

allow for the movement of the motorised

tailgate.

Never insert a finger in the locking

system of the motorised tailgate - risk of

serious injury!

Anti-pinch

The motorised tailgate has an obstacle detection

system that automatically interrupts and reverses

its movement by a few degrees, to allow the

obstacle to be cleared.

Access

Please note that this anti-pinch system is not

active at the end of the closing travel (around

1 cm from completely closed).

To avoid the risk of injury through

pinching or trapping, before and during

operation of the motorised tailgate:

– ensure that there is no-one close to the

rear of the vehicle.

– monitor the activity of the rear passengers,

particularly any children.

Bicycle carrier/Towing device

The motorised tailgate is not designed to support

a bicycle carrier.

When installing a bicycle carrier on the towing

device with connection of the cable to the trailer

socket, the motorised operation of the tailgate

will be automatically deactivated.

If using a towing device or bicycle carrier

not recommended by PEUGEOT, it is

essential to deactivate the motorised

operation of the tailgate.

Motorised operation

Motorised operation of the tailgate is set

via the

Driving/Vehicle

touch screen

menu.

* Depending on version.

There are several ways of operating the tailgate:

Using the Keyless Entry and Start system’s

electronic key

Using the exterior tailgate control

Using the interior tailgate control

Using the control on the dashboard*

Opening

► A long press on the central button

of the

electronic key.

► A short press on the exterior tailgate control

, with the electronic key on your person.

► Two consecutive presses on the control

the dashboard.

The tailgate opens, either completely by

default, or to the position memorised

beforehand.

If motorised operation is not activated, these

actions release the tailgate (partially-open

position).

When the vehicle is locked, the request to

open the boot with one of the controls

unlocks the vehicle, or only the boot if

selective unlocking is activated, prior to the

opening of the boot.

Closing

► A short press on the interior tailgate control

It is possible to interrupt the operation of

the tailgate at any point.

Pressing one of these controls again

interrupts the movement that is underway.

Hands-free function (Hands-Free

Tailgate Access)

(Depending on version)

With the electronic key on your person, this

function allows the motorised tailgate to be

opened, closed or stopped via a "kicking"

movement under the rear bumper.

The "Hands-Free Tailgate/Access"

function is set via the

Driving/Vehicle

touch screen menu.

Access

Ensure that you are steady on your feet

before performing the "kicking"

movement.

Take care not to touch the exhaust system

which may be hot - risk of burns!

Rechargeable hybrid vehicles

The function is not available when the

vehicle is connected.

► Position yourself behind the vehicle by the

number plate and perform a "kicking" movement

in the "

" detection zone.

The "kicking" movement must be given forwards,

smoothly, not too fast and with a vertical

movement from low to high. Raise the foot

sufficiently and remove it immediately.

Recognition of the "kicking" movement is

confirmed by the lighting of the direction

indicators followed by an audible signal.

"Sideward kicking" movements do not

work. If the "kicking" movement has not

been detected, wait at least 2 seconds before

repeating the movement.

Do not perform repetitive "kicking"

movements.

If the motorised tailgate has not started to open,

check that:

– the function is activated.

– the electronic key is on your person, outside

the vehicle in the rear recognition area.

– the "kicking" movement was performed in the

detection zone, close enough to the bumper.

– the foot was removed from the bumper quickly

enough.

Automatic locking with the hands-free

function

► To activate/deactivate the automatic locking

of the vehicle when closing the tailgate with the

hands-free function, press this button.

The green indicator lamp comes on to indicate

that the function is activated.

When the vehicle is locked, the request

to open the tailgate with this function

unlocks the vehicle, or only the tailgate if

selective unlocking is activated, prior to the

opening of the tailgate.

Closing the tailgate with the "Hands-Free

Tailgate Access" function enables you to lock

the vehicle.

Recommendations on the hands-free

function (Hands-Free Tailgate Access)

If it does not work, check that the electronic key

is not exposed to a source of electromagnetic

interference (e.g. smartphone).

The function may be deactivated or affected if

there is rain or snow.

Access

The function may not work correctly with a

prosthetic leg.

In some circumstances, the tailgate may open or

close by itself, particularly when:

– hitching up or removing a trailer;

– operating a towing device;

– fitting or removing a bicycle carrier;

– loading or unloading bicycles on/from a bicycle

carrier;

– depositing or lifting something behind the

vehicle;

– an animal approaches the rear bumper;

– washing the vehicle;

– maintenance is performed on the vehicle;

– accessing the spare wheel.

To avoid such operating problems, keep the

electronic key away from the recognition zone or

deactivate the hands-free function.

Towing device

The installation of a towing device may

disturb the detection system.

► Perform the "kicking" movement on the

right side of the towing device.

Memorising an opening

position

memorise

a position, in order to limit the

motorised tailgate opening angle:

► move the tailgate to the desired position

manually or by pressing the button.

► press button

or the exterior control

for

more than 3 seconds (memorisation is confirmed

by a brief audible signal).

Memorising is not available until the

height of opening is more than or equal

to 1 metre between the low position and the

high position of the tailgate.

delete

the memorised position:

► open the tailgate to any position.

► press button

or the exterior control

for

more than 3 seconds (deletion is confirmed by a

long audible signal).

Manual operation

The tailgate can be manoeuvred by hand, even

with motorised operation activated.

The tailgate must be stationary.

► Move the tailgate as slowly and smoothly as

possible.

When opening and closing the motorised tailgate

manually, there is no assistance from gas struts.

Resistance to opening and closing is therefore

entirely normal.

In case of the motor overheating

Repeatedly opening and closing the

motorised tailgate can cause overheating of

its electric motor, after which opening and

closing will not be possible.

Allow at least 10 minutes for the electric

motor to cool down before operating the

tailgate again.

If you are unable to wait, operate it manually.

Manual closing of the

motorised tailgate in case of

failure

This operation is

only necessary in the case of

failure or deinitialisation/loss of the tailgate

motor

If the failure originates from the battery, it is

recommended to recharge it or change it with the

tailgate

closed

In this situation, a significant force may be

needed to close the tailgate.

► Close it gently without slamming, as slowly as

possible, by pushing at the centre of the tailgate.

Do not lower the tailgate by pushing at

one of its sides - risk of damage!

Precautions in use

In wintry conditions

To avoid any operating problems, remove

the snow or wait until the ice melts before

requesting motorised opening of the tailgate.

When washing

When washing the vehicle in an

automatic car wash, do not forget to lock and

move away from the vehicle to prevent any

risk of unwanted opening.

Access

Alarm

(Depending on version)

System which protects and provides a deterrent

against theft and break-ins.

Exterior perimeter monitoring

The system checks for opening of the vehicle.

The alarm is triggered if anyone tries to open a

door, the boot or the bonnet, for example.

Interior volumetric monitoring

The system checks for any variation in volume in

the passenger compartment.

The alarm is triggered if anyone breaks a

window, enters the passenger compartment or

moves inside the vehicle.

Anti-tilt monitoring

The system checks for any change in the attitude

of the vehicle.

The alarm goes off if the vehicle is lifted or

moved.

When the vehicle is parked, the alarm

will not be triggered if the vehicle is

knocked.

Self-protection function

The system checks whether any of its

components are out of service.

The alarm is triggered if the battery, the central

control or the siren wiring is put out of service or

damaged.

Work on the alarm system

Consult a PEUGEOT dealer or a

qualified workshop.

Locking the vehicle with full

alarm system

Activation

► Switch off the ignition and exit the vehicle.

► Lock or deadlock the vehicle using the

remote control or with the Keyless Entry and

Start system.

When the monitoring system is active, the red

indicator lamp in the button flashes once per

second and the direction indicators come on for

about 2 seconds.

The exterior perimeter monitoring is activated

after 5 seconds and the interior volumetric and

anti-tilt monitoring after 45 seconds.

Door, boot or bonnet

If an opening is not properly closed,

the vehicle is not locked, but the exterior

perimeter monitoring will be activated after

45 seconds, at the same time as the interior

volumetric and anti-tilt monitoring.

Deactivation

► Press one of the remote control unlocking

buttons:

short press

long press

► Unlock the vehicle with the Keyless Entry and

Start system.

The monitoring system is deactivated: the

indicator lamp in the button goes off and the

direction indicators flash for about 2 seconds.

If the vehicle automatically locks itself

again (as happens if a door or the boot is

not opened within 30 seconds of unlocking),

the monitoring system is automatically

reactivated.

Access

Locking the vehicle

with exterior perimeter

monitoring only

Deactivate the interior volumetric and anti-tilt

monitoring to avoid the unwanted triggering of

the alarm, in certain cases such as:

– Slightly open window.

– Washing the vehicle.

– Changing a wheel.

– Towing the vehicle.

– Transport on a ship or ferry.

Deactivating the interior volumetric

and anti-tilt monitoring

► Switch off the ignition and within 10 seconds

press the alarm button until its red indicator lamp

is on fixed.

► Get out of the vehicle.

► Immediately lock the vehicle using the remote

control or the Keyless Entry and Start system.

Only the exterior perimeter monitoring is

activated; the button's red indicator lamp flashes

once every second.

To take effect, this deactivation must be

carried out after each time the ignition is

switched off.

Reactivating the interior volumetric

and anti-tilt monitoring

► Deactivate the exterior perimeter monitoring

by unlocking the vehicle using the remote control

or the Keyless Entry and Start system.

The indicator lamp in the button goes off.

► Reactivate all monitoring by locking the

vehicle using the remote control or the Keyless

Entry and Start system.

The red indicator lamp in the button once again

flashes every second.

Triggering of the alarm

This is indicated by sounding of the siren

and flashing of the direction indicators for 30

seconds.

Depending on the country of sale, certain

monitoring functions remain active until the alarm

has been triggered eleven times consecutively.

When the vehicle is unlocked using the remote

control or the Keyless Entry and Start system,

rapid flashing of the red indicator lamp in the

button informs you that the alarm was triggered

during your absence. When the ignition is

switched on, this flashing stops.

Failure of the remote control

To deactivate the monitoring functions:

► Unlock the vehicle using the key in the

driver's door lock.

► Open the door; the alarm is triggered.

► Switch on the ignition; this stops the alarm.

The indicator lamp in the button goes off.

Locking the vehicle without

activating the alarm

► Lock or deadlock the vehicle using the key

(built-in the remote control) in the driver's door

lock.

Malfunction

When the ignition is switched on, the fixed

lighting of the red indicator lamp in the button

indicates a system malfunction.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Electric windows

Left-hand front

Right-hand front

Right-hand rear

Left-hand rear

Deactivation of electric window controls

located by rear seats

Access

Manual operation

► To open/close the window, press/pull the

switch without passing the point of resistance;

the window stops as soon as the switch is

released.

Automatic operation

► To open/close the window, press/pull the

switch past its resistance point: the window

opens/closes completely when the switch is

released.

Operating the switch again stops the movement

of the window.

Window controls remain operational for

approximately 45 seconds after switching

off the ignition or after locking the vehicle.

After that time, the controls are disabled.

To reactivate them, switch on the ignition or

unlock the vehicle.

Anti-pinch

If the window meets an obstacle while rising, it

stops and immediately partially lowers again.

Overtaking of the anti-pinch

After triggering the anti-pinch, check

that there are no obstacles blocking the

movement of the window.

Try to close the window again.

If the window closing is interrupted by the

anti-pinch 3 times in a row (max. 10 seconds

between each action), the anti-pinch function

becomes inoperable.

Without this protection, the window can only

be closed manually - risk of injury!

Deactivating the rear

controls for the rear electric

windows

For your children's safety, press control

deactivate the controls for the rear electric

windows, irrespective of their positions.

The red indicator lamp in the button comes

on and a confirmation message is displayed.

The lamp will remain lit until the controls are

reactivated.

The rear electric windows can still be controlled

using the driver's controls.

Reinitialising the electric

windows

After reconnecting the battery, or in the event

of abnormal window movement, the anti-pinch

function must be reinitialised.

Automatic window closing is no longer

available, only manual closing is

possible.

Remote window closing with the electronic

key is also no longer available in this case.

The anti-pinch function is inoperable during

the following sequence of operations.

For each window:

► Lower the window fully, then raise it; it will

rise in steps of a few centimetres each time the

control is pressed. Repeat the operation until the

window is fully closed.

► Continue to pull the control for at least one

second after the window reaches the closed

position.

If an electric window meets an obstacle

during operation, the movement of the

window must be reversed. To do this, press

the relevant control.

When the driver operates the passengers’

electric window controls, it is important to

ensure that nothing can prevent the window

from closing properly.

It is important to ensure that passengers use

the electric windows correctly.

Pay particular attention to children when

operating the windows.

Be aware of passengers and/or other persons

present when closing windows remotely using

the electronic key.

Access

Do not put your head or arms through the

open windows when the vehicle is moving -

risk of serious injury!

Panoramic sunroof

The panoramic sunroof consists of a movable

glass panel that slides over the roof and a blind

that can be opened independently. Opening the

sunroof automatically opens the blind.

► To operate the panoramic sunroof or the

blind, use the buttons in the roof console.

Sunroof blind control

Sunroof control

The sunroof or blind can be operated when the

ignition is turned on (if the battery is charged

enough), with the engine running, in STOP mode

of Stop & Start, and up to 45 seconds after

turning off the ignition or after locking the vehicle.

Precautions

Do not put your head or arms through the

sunroof while the vehicle is moving - risk

of serious injury!

Ensure that any luggage or accessories

carried on the roof bars do not interfere

with the movement of the sunroof.

Do not place heavy loads on the movable

glass panel of the sunroof.

If the sunroof is wet, following a rain

shower or washing the vehicle, wait until

it is completely dry before operating it.

Do not operate the sunroof if it is covered by

snow or ice - risk of damage!

Use only plastic scrapers to remove snow or

ice from the sunroof.

Regularly check the condition of the

sunroof seals (e.g. presence of dust,

dead leaves).

If using a car wash, check first that the roof is

correctly closed and keep the high-pressure

jet at least 30 centimetres from the seals.

Never leave the vehicle with the sunroof

open.

Operation

When opening the sunroof fully, the movable

glass moves to a partially open position, then

slides over the roof. Any intermediate position is

possible.

Depending on the speed of the vehicle,

the partially open position may vary to

improve the acoustics.

Before operating the sunroof or blind

control buttons, ensure that no object or

person might prevent the movement.

Be particularly aware of children when

operating the sunroof or blind.

If something is trapped when operating the

sunroof or blind, you should reverse the

movement of the sunroof or blind by pressing

the control in question.

The driver must ensure that passengers use

the sunroof and blind correctly.

Anti-pinch system

If the sunroof or blind encounters an obstacle

when closing, the movement is automatically

reversed.

The roof anti-pinch system is designed to be

effective at speeds of up to 75 mph (120 km/h).

Opening/Closing

► To open the sunroof or the blind, use the

part of the button located towards the rear of the

vehicle.

Access

► To close the sunroof or the blind, use the part

of the button located towards the front of the

vehicle.

Operation of buttons

► Pressing a button beyond its point of

resistance directly opens or closes the sunroof

or blind fully.

► Pressing the button again stops the current

movement.

► When holding a button (without going

beyond the point of resistance), the movement

of the sunroof or blind stops when this button is

released.

► When the sunroof is closed: pressing once

without passing the point of resistance moves it

to a partially open position.

► When the sunroof is partially open: pressing

once without passing the point of resistance

opens or closes it fully.

The sunroof and windows, then the blind,

can be closed by holding down the door

locking control. The manoeuvre stops as soon

as the locking control is released.

Closing of the blind is limited by the

position of the sunroof: the blind cannot

go further than the front of the movable glass.

During simultaneous movements of the

sunroof and blind, the blind automatically

stops or resumes movement depending on

the position of the sunroof.

Reinitialisation

Following reconnection of the battery or in the

event of a fault or jerky movement of the sunroof

or blind, reinitialisation is required.

► Check that nothing is interfering with the

sunroof or blind and that the seals are clean.

► With the ignition on, fully close the sunroof

and blind.

► Press and hold the front part of button

, until

the sunroof and blind move slightly, then hold for

a further 1 second before releasing.

► Wait 2 seconds and then press and hold the

front part of button

. The blind and the sunroof

will open and close, one after the other. When

both are completely closed again, hold for a

further 2 seconds and release.

If there is an operating fault, restart the

whole procedure.

Ease of use and comfort

Driving position

Correct seating position

Adopting a good driving position contributes to

improving driver comfort and protection.

It also optimises interior and exterior visibility as

well as access to controls.

Certain seat adjustments described in this

section depend on the trim level and the country

in which the vehicle is sold.

Driver’s side

Sit fully back in the seat with your pelvis, back

and shoulders in contact with the seat backrest.

Adjust the seat cushion height so that your eyes

are level with the centre of the windscreen.

The head should be at a minimum distance of

10 cm from the roof.

Adjust the longitudinal position of the seat so

that you can fully depress the pedals with legs

slightly flexed.

The distance between the knees and the

dashboard should be at least 10 cm, for easy

access to the dashboard controls.

Adjust the backrest angle to as vertical a position

as possible; never tilt it more than 25°.

Adjust the head restraint so that its upper edge is

level with the top of the head.

Adjust the length of the seat cushion to support

your thighs.

Adjust the lumbar support so that it conforms to

the shape of the spine.

Adjust the steering wheel reach so that it is at

least 25 cm from the sternum and you can hold it

with your arms slightly bent.

Adjust the steering wheel height so that it does

not obstruct the information displayed on the

instrument panel.

As a safety precaution, adjust the seats

only when the vehicle is stationary.

Electrically-adjustable seats

Switch the ignition on to enable the

adjustments to be made.

Passenger’s side

Sit fully back in the seat with the pelvis, back and

shoulders in contact with the seat backrest.

Adjust the longitudinal position of the seat so that

you are at a distance of at least 25 cm from the

dashboard.

Adjust the head restraint so that its upper edge is

level with the top of the head.

Before moving off

Adjust the interior and exterior door mirrors to

reduce blind spots.

Fasten the seat belt: place the diagonal belt in

the middle of the shoulder and adjust the lap belt

so that it is tightened across the pelvis.

Ensure that all passengers have fastened their

seat belts correctly.

Electric door mirrors

Switch the ignition on to enable the

adjustments to be made.

Ease of use and comfort

When driving

Maintain a good driving position and hold the

steering wheel with both hands at the 'quarter to

three' position, so that you can easily and quickly

reach the controls behind and near the steering

wheel.

Never adjust the seats or steering wheel

when driving.

Always keep your feet on the floor.

Front seats

Before moving the seat backwards,

ensure that there is no person or object

that might prevent the full travel of the seat.

There is a risk of trapping or pinching

passengers if present in the rear seats or of

jamming the seat if large objects are placed

on the floor behind the seat.

Manually-adjusted seats

Longitudinal adjustment of the seat position

► Raise the control bar and slide the seat

forwards or backwards.

► Release the bar to lock the seat in

position in one of the notches.

Seat cushion height adjustment

► Raise or lower the control as many times

as needed to obtain the desired height.

Seat backrest angle adjustment

► Turn the knob forwards or backwards to

recline the backrest to the desired angle.

► For a passenger seat that can be placed

in the table position, pull the handle and

guide the backrest forwards or backwards.

Head restraint height adjustment

Refer to the corresponding section.

Lumbar support adjustment

(only on the driver's seat)

► Turn the knob forwards or backwards

to increase or decrease the level of lumbar

support.

‘AGR’ certified seats

Additional adjustments

Seat cushion length adjustment

► Pull the handle forwards to release the

cushion, then move the front part of the seat

cushion forwards or backwards.

Seat cushion angle electric adjustment

► Press and hold the front or rear of the

button to raise or lower the front part of the

seat cushion.

Ease of use and comfort

Lumbar support electric adjustment

The control allows independent adjustment of

the depth and vertical position of the lumbar

support.

► Press and hold the front or rear of the

control to increase or reduce the lumbar

support.

► Press and hold the top or bottom of the

control to raise or lower the lumbar support

area.

Placing the passenger seat

in the table position

The backrest of the passenger seat can be fully

folded forwards and secured in this position.

This function, when associated with folding

of the backrest of the rear seats, helps with

transporting long and bulky objects.

First steps:

► Lower the head restraint.

► Fold up the “aircraft” type table (depending

on version).

► Move the seat backwards to allow space for

the head restraint.

► Adjust the seat to the lowest position.

► Check that there is nothing that might

interfere with folding of the backrest (seat belt,

child seat, items of clothing, bags, etc.).

Deactivation of the front passenger

airbag is recommended.

Folding the backrest

► Pull the control fully upwards to release the

backrest.

► Tip the backrest fully forwards.

In this position, the backrest can support

a maximum load of

30 kg

When sharp deceleration occurs, objects

placed on the folded backrest can turn into

projectiles.

Returning the backrest into position

► Pull the control fully upwards to release the

backrest.

► Raise the backrest and guide it backwards

until it latches into place.

► Check that the backrest is correctly latched

into place.

Front head restraints

Adjusting the height

Upwards:

► Pull the head restraint up to the desired

position; you can feel the head restraint clicking

into position.

Downwards:

► Press lug

to lower the head restraint.

The head restraint is correctly adjusted

when its upper edge is level with the top

of the head.

Removing a head restraint

► Pull the head restraint fully up.

► Press lug

to release the head restraint and

raise it fully.

► Stow the head restraint securely.

Ease of use and comfort

Refitting a head restraint

► Insert the head restraint rods into the guides

in the corresponding seat backrest.

► Push the head restraint fully down.

► Press the lug

to release the head restraint

and push it down.

► Adjust the height of the head restraint.

Never drive with the head restraints

removed; they should be in place and

adjusted for the occupant of the seat.

Electrically-adjusted driver's

seat

To carry out these electric adjustments,

switch on the ignition or start the engine

if the vehicle has gone into energy economy

mode.

These electric adjustments are accessible

about 1 minute after opening the driver's door.

They are deactivated about 1 minute after

switching the ignition off.

Seat cushion height and angle adjustment/

Longitudinal adjustment of the seat position

► Raise or lower the front of the control to

obtain the desired seat cushion angle.

► Raise or lower the rear of the control to

raise or lower the seat cushion.

► Slide the control forwards or backwards to

move the seat forwards or backwards.

Seat backrest angle adjustment

► Turn the control forwards or backwards to

recline the backrest to the desired angle.

Head restraint height adjustment

Refer to the corresponding section.

Seat cushion length adjustment

► Pull the handle forwards to release the

cushion, then move the front part of the seat

cushion forwards or backwards.

Lumbar support adjustment

The control allows independent adjustment of

the depth and vertical position of the lumbar

support.

► Press and hold the front or rear of the

control to increase or reduce the lumbar

support.

► Press and hold the top or bottom of the

control to raise or lower the lumbar support

area.

Memorising driving

positions

Associated with the electrically-adjusted driver’s

seat, this function allows two driving positions

to be memorised, to make these adjustments

easier if there are frequent driver changes.

It records the electric adjustments made to the

seat and door mirrors.

Using buttons M/1/2

Ease of use and comfort

► Enter the vehicle and switch the ignition on.

► Adjust your seat and the door mirrors.

► Press button

, then press button

within 4 seconds.

An audible signal confirms the memorisation.

Memorising a new position cancels the previous

position.

Recalling a stored position

While the seat is moving, take care that

no person or object hinders the

automatic movement of the seat.

With the ignition on or engine running

► Press button

to recall the

corresponding position.

An audible signal sounds when adjustment is

complete.

You can interrupt the current movement by

pressing button

or by using one of the

seat adjustment controls.

A stored position cannot be recalled while

driving.

The recalling of stored positions is deactivated

45 seconds after switching off the ignition.

Heated seats

The function is active only with the engine

running and when the outside temperature is

below 20°C.

►

Press the button corresponding to the seat.

► Each press changes the heating level; the

corresponding number of indicator lamps come

on.

► To switch off the heating, press the button

until all of the indicator lamps are off.

The system status is memorised when the

ignition is switched off.

Do not use the function when the seat

is not occupied.

Reduce the heating intensity as soon as

possible.

When the seat and passenger compartment

have reached a satisfactory temperature,

switch the function off; reducing electrical

consumption in turn decreases energy

consumption.

Prolonged use of heated seats is not

recommended for people with sensitive

skin.

There is a risk of burns for people whose

perception of heat is impaired (e.g. illness,

taking medication).

To keep the heated pad intact and to prevent

a short circuit:

– Do not place heavy or sharp objects on the

seat.

– Do not kneel or stand on the seat.

– Do not spill liquids onto the seat.

– Never use the heating function if the seat

is damp.

Multipoint massage

System with a choice of type of massage and

adjustment of its intensity.

This system operates with the engine running, as

well as in STOP mode of the Stop & Start.

The massage settings are adjusted via the touch

screen.

From the front seat:

► Press this button; its green indicator

lamp comes on.

The settings page is displayed on the touch

screen with the last memorised settings.

If the settings suit you and you make no

changes, the display returns to its previous state,

and the function activates immediately.

Seats must be adjusted one after another,

starting with the driver's seat.

Ease of use and comfort

To modify the settings:

► Begin with the driver’s seat.

► Select a massage intensity from the three

levels offered: "

" (Low), "

" (Normal) or "

(High).

► Select another type of massage from those

offered.

► Wait for the driver's seat settings page to

disappear.

► Next, proceed with the passenger's seat in

the same way.

The changes are applied immediately.

Once activated, the system starts a one hour

massage cycle, made up of sequences of 6

minutes of massage followed by 3 minutes at

rest.

The system automatically stops at the end of the

cycle; the indicator lamp for the button goes off.

Steering wheel

adjustment

► When stationary, pull the control to release

the steering wheel.

► Adjust the height and reach to suit your

driving position.

► Push the control to lock the steering wheel.

For safety reasons, these adjustments

must only be carried out with the vehicle

stationary.

Mirrors

Door mirrors

Adjustment

► Move control

to the right or to the left to

select the corresponding mirror.

► Move control

in any of the four directions

to adjust.

► Return control

to its central position.

As a safety measure, the mirrors should

be adjusted to reduce the "blind spots".

The objects that you see in the mirrors are

in fact closer than they appear. Take this

into account in order to correctly judge the

distance of vehicles approaching from behind.

Manual folding

The mirrors can be folded manually (parking

obstruction, narrow garage, etc.).

► Turn the mirror towards the vehicle.

Electric folding

Depending on equipment, the door mirrors can

be folded electrically.

► From the inside, with the

ignition on, place control

in the

central position.

► Pull control

backwards.

► Lock the vehicle from the outside.

If the mirrors are folded using control

they will not unfold when the vehicle is

unlocked.

Electric unfolding

► From outside: unlock the vehicle.

► From inside: with the ignition on, place

control

in the central position and then pull it

rearwards.

Ease of use and comfort

Depending on version, the automatic

door mirror folding/unfolding function is

configured via the

Driving

Vehicle

touch

screen menu.

Otherwise, this setting can be carried out at a

PEUGEOT dealer or a qualified workshop.

Automatic tilting in reverse gear

Depending on version, this function allows to

automatically tilt the mirrors downwards to assist

with parking manoeuvres in reverse gear.

With the engine running, on engaging reverse

gear, the mirror glasses tilt downwards.

They return to their initial position:

– A few seconds after coming out of reverse

gear.

– Once the vehicle speed exceeds 6 mph

(10 km/h).

– When the engine is switched off.

This function is set via the

Driving/

Vehicle

touch screen menu.

Demisting/Defrosting

The demisting/defrosting of the door

mirrors works with the demisting/

defrosting of the rear screen.

For more information on

Rear screen

demisting/defrosting

, refer to the

corresponding section.

Interior rear view mirror

The electrochrome system uses a sensor that

detects the level of exterior brightness and that

coming from the rear of the vehicle, in order to

automatically and gradually switch between day

and night usage.

To ensure optimum visibility while

manoeuvring, the mirror automatically

brightens when reverse gear is engaged.

The system is deactivated if the load in the

boot exceeds the height of the load space

cover or if the load space cover has items

placed on it.

Rear head restraints

High position

(use):

► Pull the head restraint fully up.

Low position

(stowing; when the seats are not

in use):

► Press the lugs

to release the head restraint

and push it down.

Ease of use and comfort

The rear head restraints can be removed.

Removing a head restraint

► Pull the head restraint fully up.

► Press the lugs

to release the head restraint

and remove it completely.

► Store the head restraint.

Refitting a head restraint

► Insert the head restraint rods into the guides

in the corresponding seat backrest.

► Push the head restraint down as far as it will

go.

► Press the lugs

to release the head restraint

and push it down.

Never drive with passengers seated at

the rear when the head restraints are

removed; the head restraints should be in

place and in the high position.

The head restraint for the central

seat and those for the side seats

are not interchangeable.

Rear bench seat

Bench seat with fixed cushions and split folding

backrests (2/3-1/3) to adapt the boot load space.

Folding the backrests

Each section of the backrest has two release

controls:

– A grip

on the outer edge of the backrest.

– A lever

on the boot side trim (depending on

version).

The backrests should only be

manoeuvred when the vehicle is

stationary.

First steps:

► Lower the head restraints.

► Lift up the rear armrest.

► If necessary, move the front seats forward.

► Check that no person or object might interfere

with the folding of the backrests (e.g. clothing,

luggage).

► Check that the outer seat belts are lying flat

on the backrests.

► Check that the centre seat belt buckle is

stored in its housing.

The folding of the backrest is

accompanied by a slight lowering of the

corresponding cushion.

To obtain a flat surface, it is necessary to

place the adjustable boot floor in the high

position.

When the backrest is released, the red

indicator in the release grip is visible.

Folding from the passenger

compartment

► Press the backrest release grip

Ease of use and comfort

► Guide the backrest

down to the horizontal

position.

Folding from the boot

► Pull the backrest release lever

towards you.

The backrest

folds fully onto the cushion.

Repositioning the backrests

First check that the outer seat belts are

lying vertically flat alongside the backrest

latching rings.

► Put the backrest

in the upright position and

push it firmly to latch it home.

► Check that the red indicator is no longer

visible in the release grip

► Ensure that the outer seat belts were not

trapped during the operation.

Please note: an incorrectly latched

backrest compromises the safety of

passengers in the event of sudden braking or

an accident.

The contents of the boot may be thrown

forward - risk of serious injury!

Second row seats

Seat adjustment

The three second row seats are independent

and of the same width. Their backrests can be

folded to adapt the boot load space.

Longitudinal adjustment

Seat backrest angle adjustment and folding

Folding the backrest from behind and

emergency exit for third row passengers

Access to third row seats

Ease of use and comfort

Longitudinal adjustment

► Raise control bar

and slide the seat

forwards or backwards.

► Release the bar to lock the seat in position in

one of the notches.

Seat backrest angle adjustment

Side seats

► Lift control handle

and guide the backrest

backwards or forwards, raising yourself slightly

if needed.

► Release the handle and ensure the backrest

is properly locked on one of the positions offered.

Central seat

► Lift control strap

and guide the backrest

backwards or forwards, raising yourself slightly

if needed.

► Release the strap and ensure the backrest is

properly locked on one of the positions offered.

Flat floor

Folding the backrests

► Check that the "aircraft" type tables of the

front seats are properly folded.

► Place the second row seats in the maximum

rear position.

Before and while performing the

operation on the seats, check that the

passengers, children in particular, keep their

hands and their feet far from the moving parts

of the seats (hinges, slides, etc.) - risk of

serious injury!

Folding from the outside

► Pull handle

or strap

until the backrest

is fully folded.

► Release the control.

► Gently push the backrest forwards so that

the backrest tilts until it is folded onto the seat

cushion.

Ease of use and comfort

Folding from the boot

When loading, for example, or from the third row

seats:

► Pull strap

to unlock the desired seat and

give the backrest a slight push forwards.

Repositioning the seat

► Place the continuity panels of the 2

row

seats back up against the backrests.

► Straighten the backrest until it locks.

Before performing any operations on the

rear seats, to avoid damage to the seat

belts, check that the outer seat belts are

properly tensioned. The central seat belt must

be stored in the headlining.

Continuity panels

Each seat has a continuity panel at the bottom of

the backrest, which, once unfolded:

– allows for a continuous loading surface in the

boot, whatever the position of the seats,

– prevents objects from sliding beneath the 2

row seats.

The continuity panels are held against the

backrests with a magnetic fixing element.

These continuity panels are not designed

to support a weight greater than

30 kg

Before unfolding the continuity panels,

check that the 2

row seats are pulled as

far back as possible.

Accessing third row seats

The third row seats are accessed via the second

row side seats.

From the outside or from the third row seats:

► Check that the "aircraft" type tables of the

front seats are properly folded up.

► Pull paddle

and guide the backrest

forwards to tilt it and move the seat forwards.

To put the seat back in place:

► Straighten the backrest until the seat locks.

Whatever the initial position of the seat, it is

placed automatically a third of the way along

the longitudinal adjustment range in order to

preserve enough space for passengers in the

third row seats.

Ease of use and comfort

If this system fails (paddle

), the third

row passengers can also get out after

having folded the backrest of the second row

seats using strap

Do not let children operate the seats

unsupervised.

Third row seats

The two third row seats are stored in a retracted

position in the bottom of the boot. Each one is

covered with rigid concertina panels, secured to

the vehicle.

Do not let children operate the seats

unsupervised.

Each concertina panel can support a

maximum load of

100 kg

with the third

row seats folded away.

With the third row seats removed and the

removable concertina panels supports

installed, the maximum load is limited to

50 kg

When there is a seat at the back of the boot, the

removable support is fixed against the front wall

of its housing.

If the seat is removed from the back of the boot

for extra storage space, the removable support

must be installed on the two lugs on the central

wall.

Folding the concertina

panels

► Pull one of the straps; the 3 sections of the

corresponding panel fold into concertina form.

When the 3

row seats are straightened, these

folded concertina panels can be left upright or

flat behind the seats (freeing up the seat well as

a storage space).

Positioning the seats

These operations are carried out from the boot

sill, according to the upper label on the back of

the 3

row seats.

Ease of use and comfort

► Remove the load space cover roller.

► Before doing anything to the 3

row seats,

straighten imperatively the continuity panels of

the 2

row seats (step

► Fold back the concertina panel and straighten

it vertically.

► Pull the black strap

, located behind the

backrest (step

The backrest tilts backwards bringing the seat

cushion with it; the seat locks in the open

position.

The load space cover roller can be stored behind

the backrests of the 3

row seats.

For more information on the

Boot fittings

, and

in particular the load space cover roller, refer to

the corresponding section.

Storing the seats

► Before doing anything to the 3

row seats,

straighten imperatively the continuity panels of

the 2

row seats.

► Place the head restraints in the low position.

► Check that the seat belts in the 3

row are

properly stored along the side trims without

being folded or twisted.

► Pull red strap

, located at the bottom of the

backrest.

The seat is unlocked.

► Push the backrest slightly forwards.

The backrest tilts and folds onto the cushion; the

folded seat is stored at the back of its storage

area.

► Reposition the concertina panels above the

retracted seats.

Before doing anything to the 3

row

seats, straighten imperatively the

continuity panels of the 2

row seats - Risk of

irreversible damage or breakage!

Do not try to fold back a seat in the 3

row

without having opened it until the backrest is

fully locked.

Do not leave anything on or underneath the

cushions of the 3

row seats when they are

being folded.

Do not guide strap

when storing the seat -

your fingers may get trapped!

Removing the seats

Removing the right-hand seat first is

recommended in order to facilitate access to the

left-hand seat unlocking control.

The seat must be in the folded-away position.

These operations must be performed from the

boot sill, according to the lower label on the back

of the 3

row seats.

Ease of use and comfort

► Fold back the concertina panel.

► Lift the yellow lever

, located on the right-

hand side, as far upwards as possible to unlock

the seat (step

► While keeping the yellow lever held up as far

as possible, raise the rear part of the seat using

the red strap

(step

► Once the rear part of the seat has been

raised, take hold of each side of the seat

cushion, at the plastic covers, then bring the

seat towards you, keeping it at the same angle

(step

Repositioning the seats

These operations must be performed from the

boot sill.

As long as the seat is not in the correct

position, it must be held with both hands

by the sides, keeping it folded.

► Check in advance that the seat storage well

is empty and that the removable support is

properly secured against the front wall.

► While holding it by the sides at the plastic

covers, tilt the seat forwards.

► Simultaneously place both hooks located at

the front of the seat onto the coloured securing

lugs on the right and left at the bottom of the seat

well.

Check that the front hooks of the seat are

positioned correctly on the two lugs.

If they are not, you must remove the seat and

start the procedure again.

Ease of use and comfort

► Release the rear part of the seat which will

lock in place under its own weight.

The yellow lever

folds back automatically.

If the seat is not perfectly horizontal, do

not press on the backrest and do not try

to unfold it - risk of damaging the mechanism!

Take out the seat and start the operation

again.

Seat modularity

Configuration examples

7 seats

5 seats

Transport of

objects

6 seats

4 seats

By folding the second row seats and

retracting the third row seats, you obtain

a continuous storage floor through to the back

of the front seats.

By placing the front passenger seat in the

table position, you obtain a continuous

storage floor through to the dashboard.

Operations on the seats must only be

done when the vehicle is stationary.

Heating and Ventilation

Air intake

The air circulating in the passenger compartment

is filtered and originates either from the

exterior, via the grille located at the base of the

windscreen, or from the inside in air recirculation

mode.

Controls

Depending on version, the controls are

accessible in the

Climate

touch screen menu

or are grouped together on the centre console

panel.

Air distribution

Windscreen demisting/de-icing vents

Front side window demisting/de-icing vents

Adjustable and closable side air vents

Ease of use and comfort

Adjustable and closable central air vents

Air outlets to the front footwells

Air outlets to the rear footwells

Adjustable and closable air vents, with blower

(depending on version)

Advice

Using the ventilation and air

conditioning system

► To ensure that air is distributed evenly,

keep the external air intake grilles at the base

of the windscreen, the nozzles, the vents, the

air outlets and the air extractor in the boot

free from obstructions.

► Do not cover the sunshine sensor located

on the dashboard; this sensor is used to

regulate the automatic air conditioning

system.

► Operate the air conditioning system for at

least 5 to 10 minutes once or twice a month to

keep it in good working order.

► If the system does not produce cold air,

switch it off and contact a PEUGEOT dealer

or a qualified workshop.

When towing a large load on a steep gradient

in high temperatures, switching off the air

conditioning increases the available engine

power, enhancing the towing capacity.

Avoid driving for too long with the

ventilation off or with prolonged operation

of interior air recirculation. Risk of misting and

deterioration of the air quality!

If the interior temperature is very high

after the vehicle has stood for a long

time in the sunshine, air the passenger

compartment for a few moments.

Put the air flow control at a setting high

enough to quickly change the air in the

passenger compartment.

Condensation created by the air

conditioning results in a discharge of

water underneath the vehicle. This is perfectly

normal.

Servicing the ventilation and air

conditioning system

► Ensure that the passenger compartment

filter is in good condition and have the filter

elements replaced regularly.

We recommend using a composite passenger

compartment filter. Its specific active additive

helps protect against polluting gases and bad

smells.

► To ensure correct operation of the

air conditioning system, have it checked

according to the recommendations in the

Manufacturer’s service schedule.

Stop & Start / e-Auto mode

The heating and air conditioning systems

only operate when the engine is running.

Temporarily deactivate the corresponding

system to maintain a comfortable temperature

in the passenger compartment.

For more information, refer to the

corresponding section.

Rechargeable hybrid vehicles

Intensive use of the air conditioning

reduces the vehicle range in

Electric

mode.

Dual-zone automatic air

conditioning

This system automatically controls the activation

of the air conditioning system, regulating the

temperature, air flow and air distribution inside

the passenger compartment.

This system works with the engine running, but

access to the ventilation and its controls remains

possible with the ignition on.

Press the

Climate

menu button to display

the system controls page.

Ease of use and comfort

Temperature adjustment

Air flow adjustment

Air distribution adjustment

Interior air recirculation

Air conditioning on/off

Maximum air conditioning

Switching the system off

Automatic visibility programme

Automatic comfort programme on/off

10.

Access to the secondary page

11.

Selection of settings for the Automatic

comfort programme (Soft/Normal/Fast)

12.

"AQS (Air Quality System)" function (with

pollution sensor) (depending on version)

13.

Mono-zone/Dual-zone

14.

Temperature conditioning (depending on

version)

"REAR" function (depending on version)

Adjusting the temperature

The driver and front passenger can each choose

their own temperature setting.

The value indicated corresponds to a level of

comfort and not to a precise temperature.

► Press one of the buttons

to increase (red)

or decrease (blue) the value.

It is recommended that you avoid a difference of

more than 3°C in the settings for left and right.

Automatic Comfort

programme

This automatic mode ensures optimum

management of the passenger compartment

temperature, air flow and air distribution, based

on the selected comfort level.

► Press button

to activate or deactivate the

air conditioning system’s automatic mode .

The indicator lamp in the button lights up

when the air conditioning system is operating

automatically.

You can adjust the intensity of the

automatic Comfort programme by using the

OPTIONS

" button to select one of the available

settings:

– "

Soft

": provides soft and quiet operation by

limiting air flow.

– "

Normal

": offers the best compromise

between a comfortable temperature and quiet

operation (default setting).

– "

Fast

": provides strong and effective air flow.

To change the current setting (shown by the

corresponding indicator lamp), press button

repeatedly until the desired setting is displayed.

To ensure passenger comfort in the rear seats,

favour "

Normal

" and "

Fast

" settings.

This setting is associated with automatic mode

only. However, on deactivation of

AUTO

mode,

the indicator lamp for the most recently selected

setting remains on.

Changing the setting does not reactivate

AUTO

mode if it was deactivated.

Ease of use and comfort

In cold weather with the engine cold, the

air flow is increased gradually until the

comfort setting has been reached, in order to

limit the delivery of cold air into the passenger

compartment.

On entering the vehicle, if the interior

temperature is much colder or warmer than

the comfort setting requested, there is no

need to alter the value displayed to more

quickly reach the required level of comfort.

The system automatically corrects the

temperature difference as quickly as possible.

Automatic Visibility

programme

For more information on button

, refer to the

“

Front Demisting/Defrosting

” section.

"Air Quality System" (AQS)

function

Using a pollution sensor, this function

automatically activates recirculation of the

interior air once a certain level of polluting

substances in the exterior air is detected.

When the air quality returns to a satisfactory

level, recirculation of interior air is automatically

deactivated.

This function is not designed to detect

unpleasant odours.

Recirculation is automatically activated when the

windscreen wash is used or when reverse gear

is engaged.

The function does not operate if the exterior

temperature is below 5 °C, to avoid the risk of

misting of the windscreen and side windows.

To activate or deactivate the function, go to the

secondary page by using the "

OPTIONS

" button,

then press button

Manual control

It is possible to manually adjust one or more

of these functions, while the system retains

automatic control of the other functions:

– air flow.

– air distribution.

The indicator lamp in the "

AUTO

” button goes

out if a setting is changed.

► Press button

again to reactivate the

automatic Comfort programme.

Adjusting the air flow

►

Press one of the buttons

(

) to increase

or decrease air flow.

The air flow symbol (a fan) is filled in according

to the request.

When the air flow is reduced to a minimum,

ventilation stops.

OFF

" is displayed alongside the fan.

Adjusting the air distribution

► Press the buttons

to adjust the air flow

distribution inside the passenger compartment.

Windscreen and side windows.

Central and side air vents.

Footwells.

The lighting of the button indicates that air is

being blown in the specified direction.

For a uniform distribution of air in the passenger

compartment, the three buttons can be activated

simultaneously.

AUTO

mode, the indicator lamps in all three

buttons

are off.

Air conditioning on/off

The air conditioning system is designed to

operate effectively in all seasons, with the

windows closed.

It is used to:

– lower the temperature in summer,

– increase the effectiveness of demisting in

winter, above 3°C.

► Press button

to activate/deactivate the air

conditioning system.

When the system is activated, the indicator lamp

in the button comes on.

Air conditioning does not operate when

the air flow is disabled.

To obtain cool air more quickly, enable interior

air recirculation for a brief period. Then return

to the intake of exterior air.

Ease of use and comfort

Switching off the air conditioning may result in

some discomfort (humidity or misting).

Maximum air conditioning

This function automatically adjusts the

temperature setting to the lowest possible, the

air distribution towards the central and side air

vents, the air flow to maximum and activates

interior air recirculation.

► Press button

to activate/deactivate the

function (the indicator lamp will come on/switch

off).

Once the function is deactivated, the system

returns to the previous settings.

Mono-zone/Dual-zone

The passenger temperature setting can be linked

to the driver's setting (mono-zone function).

It is available in the secondary page which can

be accessed via the "

OPTIONS

" button.

► Press button

to activate the "

MONO

function; its status is displayed as "

The function is automatically deactivated if the

passenger uses their temperature adjustment

buttons (dual-zone function).

“REAR” function

When this function is activated, the rear air

vents blower starts up. In this case, the rear

passengers can control the air flow from these

air vents independently of the air conditioning air

flow control for the front air vents.

When the function is deactivated, the maximum

air flow distributed by the rear air vents is limited

by the air conditioning air flow setting for the

front air vents.

The function is available on the secondary

page, which can be accessed by pressing the

“

OPTIONS

” button.

► Press button

to activate the "

REAR

function; its status is displayed as "

► Press the “

large fan

” or “

small fan

” button to

increase or decrease the air flow.

The corresponding indicator lamps come on.

If all of the indicator lamps are off, a slight air

flow can still be felt as a result of the vehicle's

movement.

Ventilation with the ignition

When the ignition is switched on, the ventilation

system and the air flow

and air distribution

settings in the passenger compartment are

activated, for a period which depends on the

battery charge.

This function does not include the air

conditioning system.

Switching the system off

► Press button

; all the indicator lamps of the

system go out.

This action deactivates all of the functions of the

air conditioning system.

The temperature is no longer regulated. A slight

flow of air can still be felt, due to the forward

movement of the vehicle.

Interior air recirculation

The intake of exterior air prevents the formation

of mist on the windscreen and side windows.

Recirculating the interior air isolates the

passenger compartment from outside odours

and fumes and allows the desired passenger

compartment temperature to be achieved more

rapidly.

► Press this button to activate/deactivate

the function (confirmed by the

illumination/extinction of the indicator lamp).

Ease of use and comfort

This function is activated automatically

when reverse gear is engaged.

Front demisting/defrosting

Automatic Visibility

programme

This mode allows the windscreen and side

windows to be demisted or defrosted as quickly

as possible.

► Press this button to activate/deactivate

the mode (confirmed by the illumination/

extinction of the indicator lamp).

The programme automatically manages the air

conditioning (depending on version), air flow

and air intake, and provides optimum distribution

towards the windscreen and side windows.

It is possible to manually change the air flow

without deactivating the automatic Visibility

programme.

With Stop & Start, when demisting has

been activated, STOP mode is not

available.

In wintry conditions, before moving off,

remove all snow or ice on the windscreen

near the camera.

Otherwise, the operation of the equipment

using the camera may be affected.

Heated windscreen

In cold weather, this system heats the bottom of

the windscreen, as well as the area alongside

the left-hand windscreen pillar.

Without changing the settings for the air

conditioning system, it allows faster release

of the windscreen wiper blades when they

are frozen to the windscreen and helps avoid

the accumulation of snow resulting from the

operation of the windscreen wipers.

Switching on/off

► With the engine running, press this button to

activate/deactivate the function (confirmed by an

indicator lamp).

The function is activated when the outside

temperature drops below 0°C. It is deactivated

automatically when the engine is switched off.

Rear screen

demisting/defrosting

This demisting/de-icing only works with the

engine running.

Depending on version, it also demists/de-ices

the door mirrors.

► Press this button to activate/deactivate

the function (confirmed by the indicator

lamp coming on/switching off).

Demisting/defrosting switches off automatically

to prevent an excessive consumption of

electrical current.

Switch off demisting/defrosting when

you no longer need it; reducing

electrical consumption in turn decreases

energy consumption.

Ease of use and comfort

Temperature

pre-conditioning

(Rechargeable hybrid)

This function allows you to programme the

temperature in the passenger compartment to

reach a pre-defined, non-modifiable temperature

(approx. 21°C) before you enter the vehicle, on

the days and at the times of your choice.

This function is available when the vehicle is

connected or not connected.

Programming

(With PEUGEOT Connect Nav)

In the

Climate

OPTIONS

menu:

Select

Temperature conditioning

► Press

to add a programme.

► Select the time of entry into the vehicle and

the desired days. Press

► Press

to activate this programming.

The pre-conditioning sequence begins

approximately 45 minutes before the

programmed time when the vehicle is connected

(20 minutes when it is not connected) and is

maintained for 10 minutes after.

This indicator lamp comes on fixed when

a temperature pre-conditioning cycle is

programmed. It flashes when temperature pre-

conditioning is in progress.

You can set multiple programmes.

Each one is saved in the system.

To optimise the driving range, we recommend

starting a programme while the vehicle is

connected.

Programming can also be carried out

from a smartphone using the

MYPEUGEOT APP

application.

With PEUGEOT Connect Radio, programming

can only be carried out from a smartphone using

the application.

For more information on

Remote functions

refer to the corresponding section.

The fan noise that occurs during

temperature pre-conditioning is perfectly

normal.

Operating conditions

– The function is only activated when the

ignition is switched off

and the

vehicle

locked

– When the vehicle is not connected, the

function is only activated if the battery charge

level is greater than 20%.

– When the vehicle is not connected and a

recurring programme is active (e.g. from Monday

to Friday), if two temperature pre-conditioning

sequences are run without the vehicle being

used, the programme will be deactivated.

Front fittings

Grab handle

Sun visor

Card holder

Peugeot 5008 (2024 year). Manual in english - page 2
