Peugeot 5008 (2024 year). Manual in english

Contents

■

Overview

■

Eco-driving

Dashboard instruments

Driver information

Digital instrument panels

Warning and indicator lamps

Remotely operable additional functions

(Rechargeable hybrid)

Access

Electronic key with remote control function

and built-in key

Keyless Entry and Start

Ease of use and comfort

Driving position

Front seats

Steering wheel adjustment

Heating and Ventilation

Dual-zone automatic air conditioning

Front demisting/defrosting

Heated windscreen

Rear screen demisting/defrosting

Temperature pre-conditioning

(Rechargeable hybrid)

Front fittings

Courtesy lamps

Interior ambient lighting

Rear fittings

Boot fittings

Lighting and visibility

Lighting control stalk

Direction indicators

Headlamp beam height adjustment

Automatic illumination of headlamps

Guide-me-home and welcome lighting

Automatic lighting systems - General

recommendations

Automatic headlamp dipping

Static cornering lighting

Night Vision

Wiper control stalk

Automatic wipers

Changing a wiper blade

Safety

General safety recommendations

Hazard warning lamps

Horn

Pedestrian horn (Hybrid or Rechargeable

hybrid)

Emergency or assistance

Event Data Recording system

Electronic stability control (ESC)

Advanced Grip Control

Hill Assist Descent Control

Deactivating the front passenger airbag

Driving recommendations

115

Starting/switching off the engine

116

Starting rechargeable hybrid vehicles

117

Electric parking brake

119

6-speed manual gearbox

121

Automatic gearbox (type 1)

121

Automatic gearbox (type 2)

124

Automatic gearbox (type 3)

Stop & Start (Petrol or Diesel)

134

e-Auto mode (Hybrid)

136

Tyre under-inflation detection

136

Overview

Presentation

These illustrations and descriptions are intended

as a guide. The presence and location of some

elements vary depending on the version or trim

level.

Instruments and controls

Sunroof and blind controls

Front courtesy/map reading lamps

Warning lamp display for seat belts and front

passenger airbag

Emergency call/Assistance call

Interior rear view mirror

Head-up digital display

Fusebox

Bonnet release

Door mirror and electric window control panel

Front passenger airbag

Glove box

Deactivation of the front passenger airbag

Centre console

8" or 10" HD touch screen

12 V socket/USB socket

Wireless smartphone charger

"START/STOP" button

Drive mode selector

Gearbox

Hill Assist Descent Control

Electric parking brake

Steering-mounted controls

External lighting controls/Direction indicators

Wiper controls/Screenwash/Trip computer

Automatic gearbox control paddles

Horn/Driver front airbag

Controls for Cruise control/Speed limiter/

Adaptive cruise control

Instrument panel and audio system

adjustment controls

Select the instrument panel display mode

Voice commands

Decrease/Increase volume

Select previous/next media

Confirm a selection

Overview

Access the

Telephone

Manage calls

Select an audio source

Display the list of radio stations/audio tracks

Side switch panel

Headlamp beam height adjustment

Temperature pre-conditioning operation

indicator lamp

Opening/Closing the hands-free tailgate

Alarm

Heated windscreen

Electric child lock

Lane keeping assist

Lane positioning assist

Opening the fuel filler flap

Central switch panel

Hazard warning lamps

Touch screen controls

Access to the

Energy

Front demisting/defrosting

Recirculation of interior air

Rear screen defrosting

Central locking

Heated seats

Hybrid system

Petrol engine

Electric motor

6-speed electric dual-clutch automatic

gearbox (e-DCS6)

48 V traction battery

12 V accessory battery

DC/DC converter

Belt starter

The 48 V hybrid technology requires no

connection to charge the traction battery.

The

Hybrid system

does not operate

continuously, but is activated according to

the state of the vehicle, the state of charge

of the traction battery, the thermal comfort of

the passenger compartment (switching on

the heating or air conditioning), the driving

conditions (acceleration, deceleration, braking,

engine start-up) and the road conditions (uphill,

downhill):

Overview

– The vehicle always starts with the petrol

engine to ensure the efficiency of the catalytic

converter and the availability of the brake assist.

– In normal driving, the petrol engine and

electric motor work together or separately to

optimise fuel consumption and electrical energy

or to charge the traction battery.

– During the acceleration phases, the electric

motor provides an additional boost to reach

the torque needed as fast as possible and to

improve the acceleration at low speed.

– During the deceleration phases, the electric

motor charges the traction battery, using the

inertia of the vehicle.

– The driving in all-electric is possible for parking

manoeuvring, for 20 mph (30 km/h) speed zones

in city, on urban and country roads with smooth

driving and on motorways in slight deceleration

or downhill.

The electric motor is integrated into the

automatic gearbox.

The DC/DC converter provides the link between

the 12 V accessory power supply and the 48 V

traction power supply.

The belt starter restarts the petrol engine after

driving in all-electric.

Rechargeable hybrid

system

Petrol engine

Front and rear electric motors (depending on

version)

Traction battery

12 V accessories batteries

8-speed electric automatic gearbox (e-EAT8)

Charging flap

Fuel filler flap

Driving mode selector

Domestic charging cable

The

rechargeable hybrid

technology combines

two sources of energy: that of the petrol engine

and that of one or two electric motors (depending

on version).

The engine and the motor can operate

alternately or simultaneously, according to the

driving mode selected and the driving conditions.

The electric power alone provides the mobility

of the vehicle in

Electric

mode, and in

Hybrid

mode in case of moderate demand. It assists the

petrol engine during starting and acceleration

phases.

The electric power is supplied by a rechargeable

traction battery.

Labels

“Ease of use and comfort - Rear bench seat -

Rear head restraints” section:

“Ease of use and comfort - Third row seats”

section:

"Ease of use and comfort - Front fittings -

Wireless smartphone charger" section:

"Lighting and visibility - Exterior lighting

control stalk" and "In the event of a

breakdown - Changing a bulb" sections:

Overview

"Safety - General safety recommendations -

Installing electrical accessories" section

"Safety - Child seats - Deactivating the front

passenger airbag" section

"Safety - ISOFIX mountings" section:

i-Size

TOP TETHER

"Driving - Electric parking brake" section

"Driving - Stop & Start" section:

"Practical information - Compatibility of

fuels" section:

"Practical information - Rechargeable hybrid

system" section:

"Practical information - Charging the traction

battery (Rechargeable hybrid)" section:

"Practical information - Bonnet" section:

"In the event of a breakdown - Temporary

puncture repair kit" section:

"In the event of a breakdown - Spare wheel"

section:

"In the event of a breakdown - 12 V battery/

Accessory batteries" section:

24V

12V

Eco-driving

Eco-driving refers to a range of everyday

practices that allow the motorist to optimise

the vehicle's energy consumption (fuel and/or

electricity) and CO

emissions.

Optimise your use of the gearbox

With a manual gearbox, move off gently and

change up promptly. While accelerating, change

up early.

With an automatic gearbox, favour automatic

mode. Do not depress the accelerator pedal

heavily or suddenly.

The gear shift indicator prompts you to engage

the most suitable gear. Whenever this indication

is displayed on the instrument panel, follow it

straight away.

With an automatic gearbox, this indicator

appears only in manual mode.

Drive smoothly

Maintain a safe distance between vehicles, use

engine braking rather than the brake pedal and

press the accelerator gradually. These practices

help to save on energy consumption, reduce

emissions and decrease general traffic

noise.

With a hybrid engine, engine braking is more

efficient. Anticipate slowing down as much as

you can and, if possible, favour deceleration with

engine braking in order to charge the traction

battery, to increase all-electric driving and to

reduce fuel consumption.

When the traffic is flowing smoothly, select the

cruise control.

Control the use of electrical equipment

Before moving off, if the passenger compartment

is too warm, ventilate it by opening the windows

and air vents before using the air conditioning.

At speeds above 31 mph (50 km/h), close the

windows and leave the air vents open.

Consider using equipment that can help keep

the temperature in the passenger compartment

down (e.g. sunroof blind, window blinds).

Unless automatically regulated, switch off the air

conditioning as soon as the desired temperature

has been reached.

Switch off the demisting and defrosting functions,

if they are not managed automatically.

Switch off the heated seat as soon as possible.

Adapt your use of the headlamps and/or

foglamps to the level of visibility, in accordance

with current legislation in the country in which

you are driving.

Avoid running the engine before moving off,

particularly in winter (other than in severe wintry

conditions: temperature below -23°C). The

vehicle will warm up much faster while driving.

As a passenger, avoid connecting your

multimedia devices (e.g. film, music, video

game) to help reduce the consumption of energy.

Disconnect all portable devices before leaving

the vehicle.

Limit the causes of excess consumption

Spread loads throughout the vehicle. Place the

heaviest items in the boot as close as possible to

the rear seats.

Limit the loads carried in the vehicle and

minimise wind resistance (e.g. roof bars, roof

rack, bicycle carrier, trailer). Preferably, use a

roof box.

Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and refit

summer tyres.

Avoid using the Dynamic Pack for too long, in

order to limit your energy consumption.

Comply with the servicing instructions

Check tyre pressures regularly, with the tyres

cold, referring to the label in the door aperture on

the driver's side.

Carry out this check in particular:

– before a long journey.

– at each change of season.

– after a long period out of use.

Do not forget the spare wheel and, where

applicable, the tyres on your trailer or caravan.

Have your vehicle serviced regularly (e.g. engine

oil, oil filter, air filter, passenger compartment

filter, etc.). Observe the schedule of operations in

the manufacturer's service schedule.

With a BlueHDi Diesel engine, if the SCR system

has a fault, your vehicle will emit pollution. Visit

a PEUGEOT dealer or a qualified workshop

as soon as possible to restore your vehicle's

nitrogen oxide emissions to legal levels.

Eco-driving

When filling the fuel tank, do not continue after

the third cut-out of the nozzle, to avoid overflow.

You will only see the fuel consumption of your

new vehicle settle down to a consistent average

after the first 1,900 miles (3,000 kilometres).

Optimising the driving range of electrified

vehicles

The vehicle's consumption of electrical energy

greatly depends on the route profile, speed and

driving style, as well as the use of the heating/air

conditioning.

Favour the

ECO

and

CHARGE

zones of the

power indicator by driving smoothly and at a

steady speed.

Hybrid vehicles

Maximise the vehicle's inertia by releasing the

accelerator pedal so that the vehicle slows

down by itself (e.g. when driving downhill or

approaching a traffic light).

When the accelerator pedal is released, provided

that the slider on the power indicator in the

instrument panel is still moving in the

CHARGE

zone, energy recovery is optimal.

Energy recovery makes it possible to make

efficient use of the "passive" phases of driving

(deceleration).

The recovered energy is used to recharge the

traction battery and is then used for all-electric

driving or further acceleration.

When the traction battery is almost full, the

energy recovery is gradually reduced.

Rechargeable hybrid vehicles

Connect the vehicle as soon as possible.

Anticipate slowing down as much as possible

and, if possible, favour decelerations with the

regenerative braking function activated (power

indicator in the

CHARGE

zone).

With the vehicle connected, carry out

temperature pre-conditioning before setting off.

To optimise consumption during a journey:

► Program a destination into the vehicle’s GPS

navigation system.

► Select the

Hybrid

driving mode.

► Make sure that the battery charge level is

close to maximum.

► Avoid using the e-Save function.

► Use the heating/air conditioning system

wisely.

Dashboard instruments

Driver information

Instrument panel

The instrument panel displays all the information

the driver needs about the status of the vehicle's

various systems.

This information appears in the form of warning

and indicator lamps and messages.

The instrument panel is in the form of a fully

digital screen.

Head-up digital display

These digital instrument panels can be

customised.

Depending on the display mode selected, certain

information is not displayed or is presented

differently.

Dials and gauges

With the "Dials" display mode (Petrol or

Diesel)

With the "Energy" display mode (Hybrid)

With the "Energy" display mode

(Rechargeable hybrid)

Fuel gauge (Petrol or Diesel)

Fuel gauge and remaining range (miles or

km) (Hybrid or Rechargeable hybrid)

Speedometer (mph or km/h)

READY

indicator lamp (Rechargeable hybrid)

Gear shift indicator (arrow and recommended

gear)

Selector position on automatic gearbox

Rev counter (x 1,000 rpm) (Petrol or Diesel)

Power indicator (Hybrid or Rechargeable

hybrid)

Engine coolant temperature indicator (°C)

(Petrol, Diesel or Hybrid)

Battery charge level and remaining range

(miles or km) indicator (Rechargeable hybrid)

Trip distance recorder (miles or km)

Total distance recorder (miles or km)

Cruise control or speed limiter settings

Display of speed limit signs

Driving mode selected (other than

Normal

mode)

Energy flows (Hybrid or Rechargeable hybrid)

Hybrid or Rechargeable hybrid

In all-electric driving mode, the speed is

displayed in blue instead of white when the

petrol engine is running.

Buttons

Instrument panel ambient lighting on/off

Short press: start a manual test

Long press: reset the service indicator or trip

distance recorder (depending on the context)

Displays

Most warning and indicator lamps do not have a

fixed position.

The warning and indicator lamps in the second

line are displayed from right to left in order of

priority.

For certain functions that have indicator lamps

for both operation and deactivation, there is only

one dedicated location.

Permanent information

In the standard display, the instrument panel

shows:

– in fixed locations:

• Information related to the gearbox and gear

shift indicator.

• Fuel gauge.

• Coolant temperature indicator (Petrol, Diesel

or Hybrid).

• Battery charge level and range indicator

(Rechargeable hybrid).

Dashboard instruments

• Power indicator (Hybrid or Rechargeable

hybrid).

• Distance recorders.

– in variable locations:

• Digital speedometer.

• Status or alert messages displayed

temporarily.

Optional information

Depending on the selected display mode and

active features, additional information may be

displayed:

– Rev counter (Petrol or Diesel).

– Trip computer.

– Driving aid functions.

– Speed limiter or cruise control.

– Media currently playing.

– Navigation instructions.

– Engine information from the Dynamic Pack.

– Night Vision function.

– Energy flows (Hybrid or Rechargeable hybrid).

Personalising the

instrument panel

Depending on version, the appearance of the

instrument panel can be modified (colour and/or

display mode).

Display language and units

These depend on the touch screen

settings.

When travelling abroad, the speed must be

shown in the official units of the country you

are driving in (mph, miles or km/h, km).

As a safety measure, these adjustments

must be carried out with the vehicle

stationary.

Choosing the display colour

Depending on version, the instrument panel

display colour depends on the colour scheme

chosen in this system.

This function is set via the

Settings

touch

screen menu.

Choosing the display mode

In each mode, specific types of information are

displayed on the instrument panel.

► Turn the thumbwheel on the left of the

steering wheel to display and scroll through the

various modes on the right-hand side of the

instrument panel.

► Press the thumbwheel to confirm the mode.

The new display mode is applied immediately.

Display modes

– "

Dials

": standard display of analogue and

digital speedometers, distance recorders and:

• fuel gauge, coolant temperature indicator

and rev counter (Petrol or Diesel).

• fuel gauge, coolant temperature indicator

and power indicator (Hybrid).

• fuel gauge, battery charge level indicator and

power indicator (Rechargeable hybrid).

– "

Navigation

": specific display, showing current

navigation information (map and instructions).

– "

Driving

": specific display, showing

information relating to active driving aid systems.

– "

Night vision

": minimal display with infrared

camera image (associated with the Night Vision

function).

– "

Minimum

": minimal display with digital

speedometer and distance recorders, and in the

event of a warning only, fuel gauge and coolant

temperature indicator (depending on version).

– "

Energy

": specific display, showing a visual

representation of the vehicle’s energy flows

(Hybrid or Rechargeable hybrid).

– "

Personal

": minimal display, with the ability

to select and display optional information in the

personalisable areas on the left and right.

Configuring a "Personal" display mode

With PEUGEOT Connect Radio

Dashboard instruments

► Press

Settings

in the banner of the

touch screen.

► Select "

Configuration

► Select "

Instrument panel

personalisation

With PEUGEOT Connect Nav

► Press

Settings

in the banner of the

touch screen.

► Select "

OPTIONS

► Select "

Instrument panel

personalisation

► For each personalised display area (left and

right), select a type of information using the

corresponding scroll arrows on the touch screen:

• "

Driving aids

• "

Engine info

" (depending on version).

• "

G-metres

" (depending on version).

• "

Temperatures

" (engine oil).

• "

Media

• "

Navigation

• "

Trip computer

• "

Rev counter

• "

Hybrid flows

" (depending on version).

• "

Power indicator

" (depending on version).

• "

Accessories consumption

" (depending on

version).

• "

Night vision

► Confirm to save and exit.

Personal" mode is displayed immediately.

Warning and indicator

lamps

Displayed as symbols, the warning and indicator

lamps inform the driver of the occurrence of a

malfunction (warning lamps) or of the operating

status of a system (operation or deactivation

indicator lamps). Certain lamps light up in two

ways (fixed or flashing) and/or in several colours.

Associated warnings

The illumination of a lamp may be accompanied

by an audible signal and/or a message displayed

in a screen.

Relating the type of alert to the operating status

of the vehicle allows you to determine whether

the situation is normal or whether a fault has

occurred: refer to the description of each lamp

for further information.

When the ignition is switched on

Certain red or orange warning lamps come on

for a few seconds when the ignition is switched

on. These warning lamps should go off as soon

as the engine is started.

For more information on a system or a function,

refer to the corresponding section.

Persistent warning lamp

If a red or orange warning lamp comes on, there

may be fault which needs further investigation.

If a lamp remains lit

The references

(1)

(2)

and

(3)

in the warning

and indicator lamp description indicate whether

you should contact a qualified professional in

addition to the immediate recommended actions.

(1)

You must stop the vehicle

Stop as soon as it is safe to do so and switch off

the ignition.

(2)

: Contact a PEUGEOT dealer or a qualified

workshop.

(3)

: Go to a PEUGEOT dealer or a qualified

workshop.

List of warning and

indicator lamps

Red warning/indicator lamps
STOP

Fixed, associated with another warning

lamp, accompanied by the display of a

message and an audible signal.

A serious fault with the engine, braking system,

power steering or automatic gearbox or a major

electrical fault has been detected.

Carry out (1) and then (2).

Maximum coolant temperature

Fixed.

The temperature of the cooling system is

too high.

Carry out (1), then wait until the engine has

cooled down before topping up the level, if

necessary. If the problem persists, carry out (2).

Dashboard instruments

Engine oil pressure

Fixed.

There is a fault with the engine lubrication

system.

Carry out (1) and then (2).

Traction battery overheating (Hybrid or

Rechargeable hybrid)

Fixed, combined with the STOP

warning lamp, accompanied by the

display of a message and an audible signal.

The traction battery's temperature is too high.

Carry out (1).

Evacuate the vehicle as quickly as possible

and move to a safe distance.

Carry out (2).

Traction battery malfunction (Hybrid or

Rechargeable hybrid)

Fixed, combined with the Service

warning lamp, accompanied by the

display of a message.

The traction battery has a fault.

Carry out (2).

System malfunction (Hybrid or

Rechargeable hybrid)

Fixed.

The hybrid system is faulty.

Carry out (1) and then (2).

Cable connected (Rechargeable hybrid)

Fixed when the ignition is switched on.

The charging cable is connected to the

vehicle's connector.

Fixed when the ignition is switched on,

accompanied by a message.

It is not possible to start the vehicle while the

charging cable is connected to the vehicle’s

connector.

Disconnect the charging cable and close the

flap.

12V battery charge

Fixed.

The battery charging circuit is faulty

(e.g. dirty terminals, loose or severed alternator

belt).

Carry out (1).

If the electric parking brake stops working,

immobilise the vehicle:

► With the manual gearbox, engage a gear.

► With the automatic gearbox, fit the chocks

against one of the wheels.

Clean and tighten the terminals. If the warning

lamp does not go off when the engine is started,

carry out (2).

Door(s) open

Fixed, associated with a message

identifying the access.

An audible signal supplements the alert if the

speed is higher than 6 mph (10 km/h).

A door or the boot is not properly closed.

Seat belts not fastened/unfastened

Fixed or flashing, accompanied by an

increasing audible signal.

A seat belt has not been fastened or has been

unfastened.

Electric parking brake

Fixed.

The electric parking brake is applied.

Flashing.

Application/release is faulty.

Carry out (1): park on flat ground (on a level

surface).

With a manual gearbox, engage a gear.

With an automatic gearbox, select mode

Switch off the ignition and carry out (2).

Braking

Fixed.

The brake fluid level in the braking circuit

has dropped significantly.

Carry out (1), then top up with fluid that complies

with the manufacturer's recommendations. If the

problem persists, carry out (2).

Fixed.

The electronic brake force

distribution (EBFD) system is faulty.

Carry out (1) and then (2).

Orange warning/indicator lamps
Service

Temporarily on, accompanied by the

display of a message.

One or more minor faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel.

You may be able to deal with some faults

yourself, such as changing the battery in the

remote control.

Dashboard instruments

For other faults, such as with the tyre under-

inflation detection system, carry out (3).

Fixed, accompanied by the display of a

message.

One or more major faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel, then carry

out (3).

Fixed, accompanied by the display of the

message "

Audible Warning System

fault: Repair needed

The audible warning system is in failure.

The following driving aids may be disturbed or

unavailable:

– Road signs recognition.

– Active Safety Brake/Collision Risk Alert.

– Lane keeping assist.

– Driver Attention Warning by Camera.

Carry out (3).

Fixed, accompanied by the message

Parking brake fault

Automatic release of the electric parking brake is

unavailable.

Carry out (2).

Service warning lamp fixed and

service spanner flashing then

fixed.

The servicing interval has been exceeded.

The vehicle must be serviced as soon as

possible.

Only with BlueHDi Diesel engines.

Engine pre-heating (Diesel)

Temporarily on

(up to approximately 30 seconds in

severe weather conditions).

When switching on the ignition, if the weather

conditions and the engine temperature make it

necessary.

Wait until the warning lamp goes off before

starting.

When the warning lamp goes off, starting will

occur immediately if you press and hold:

– the clutch pedal with a manual gearbox.

– the brake pedal with an automatic gearbox.

If the engine does not start, make the engine

starting request again, while keeping your foot

on the pedal.

Low fuel level

Fixed, with the reserve level shown in red,

accompanied by an audible signal and

the display of a message.

When it first comes on, you have

approximately

6 litres of fuel

remaining in the tank (reserve).

Until the fuel level is topped up, this alert will

be repeated every time the ignition is switched

on, with increasing frequency as the fuel level

decreases and approaches zero.

Refuel without delay to avoid running out of fuel.

Never drive until completely empty

, as

this could damage the emissions control and

injection systems.

Engine self-diagnostic system

Flashing.

The engine management system has a

fault.

There is a risk that the catalytic converter will be

destroyed.

You

must

carry out (2).

Fixed.

The emissions control system has a fault.

The warning lamp should go off when the engine

is started.

Carry out (3) without delay.

AdBlue

(BlueHDi)

On for around 30 seconds when starting

the vehicle, accompanied by a message

indicating the driving range.

The driving range is between 1,500 and 500

miles (2,400 and 800 km).

Top up the AdBlue

Fixed, on switching on the ignition,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is between 500 and 62 miles

(800 and 100 km).

Promptly

top up the AdBlue

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating the

driving range.

The driving range is less than 62 miles (100 km).

You

must

top up the AdBlue

avoid engine

starting being prevented

, or carry out (3).

Dashboard instruments

Flashing, accompanied by an audible

signal and a message indicating that

starting is prevented.

The AdBlue

tank is empty: the legally required

engine immobiliser system prevents the engine

from starting.

To restart the engine, top up the AdBlue

or carry

out (2).

It is

essential

to add at least 10 litres of AdBlue

to the tank.

SCR emissions control system (BlueHDi)

Fixed when the ignition is

switched on, accompanied

by an audible signal and a message.

A malfunction of the SCR emissions control

system has been detected.

This alert disappears once the exhaust

emissions return to normal levels.

Flashing AdBlue

warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating the driving range.

Depending on the message displayed, it is

possible to drive for up to 685 miles (1,100 km)

before the engine immobiliser is triggered.

Carry out (3) without delay, to

avoid starting

being prevented

Flashing AdBlue

warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating that starting is prevented.

The engine immobiliser prevents the engine from

restarting (the permitted driving limit has been

exceeded after confirmation of a malfunction of

the emissions control system).

To start the engine, carry out (2).

Automatic functions deactivated (electric

parking brake)

Fixed.

The "automatic application" (on switching

off the engine) and "automatic release" (on

acceleration) functions are deactivated.

If automatic application/release is no longer

possible:

► Start the engine.

► Use the control to apply the electric parking

brake.

► Take your foot fully off the brake pedal.

► Hold the control pressed in the release

direction for between 10 and 15 seconds.

► Release the control.

► Depress and hold the brake pedal.

► Pull the control in the application direction for

2 seconds.

► Release the control and the brake pedal.

Malfunction (with electric parking brake)

Fixed, accompanied by the

message "

Parking brake fault

The vehicle cannot be immobilised with the

engine running.

If manual application and release commands are

not working, the electric parking brake control is

faulty.

The automatic functions must be used at all

times and are automatically reactivated in the

event of a fault with the control.

Carry out (2).

Fixed, accompanied by the

message "

Parking brake

fault

The electric parking brake is faulty: manual and

automatic functions may not be working.

When stationary, to immobilise the vehicle:

► Pull the electric parking brake control and

hold it for approximately 7 to 15 seconds, until

the indicator lamp lights up on the instrument

panel.

If this procedure does not work, secure the

vehicle:

► Park on a level surface.

► With a manual gearbox, engage a gear.

► With an automatic gearbox, select

, then

place the supplied chocks against one of the

wheels.

Then carry out (2).

Braking

Fixed.

A minor fault with the braking system has

been detected.

Drive carefully.

Carry out (3).

Dashboard instruments

Pedestrian horn (Hybrid or Rechargeable

hybrid)

Fixed.

Horn fault detected.

Carry out (3).

Collision Risk Alert/Active Safety Brake

Flashing.

The system activates and brakes the

vehicle momentarily to reduce the speed of

collision with the vehicle in front.

For more information, refer to the

Driving

section.

Fixed, accompanied by the display of a

message.

The system has been deactivated via the touch

screen.

Fixed, accompanied by a message and

an audible signal.

The system has a fault.

Carry out (3).

Fixed, accompanied by the display of the

message "

Driving Assistance Sensor

blind: Clean sensor, see User Manual

The sensor is masked.

Stop as soon as it is safe to do so and switch off

the ignition.

Clean the front camera.

Fixed.

The system has a fault.

If these warning lamps come on after the engine

is switched off and then restarted, carry out (3).

Fixed.

The system is deactivated

temporarily because the driver and/or front

passenger (depending on version) has been

detected as present but the corresponding seat

belt has not been fastened.

Anti-lock braking system (ABS)

Fixed.

The anti-lock braking system has a fault.

The vehicle retains conventional braking.

Drive carefully at moderate speed, then carry

out (3).

Dynamic stability control (DSC)/Anti-slip

regulation (ASR)

Fixed.

The system is deactivated.

The DSC/ASR system is reactivated

automatically when the vehicle is restarted,

and at speeds above approximately 31 mph

(50 km/h).

At speeds below 31 mph (50 km/h), it can be

reactivated manually.

Flashing.

DSC/ASR regulation is activated in the

event of a loss of grip or trajectory.

Fixed.

The DSC/ASR system has a fault.

Carry out (3).

Emergency brake malfunction (with

electric parking brake)

Fixed, accompanied by the

message "

Parking brake fault

Emergency braking does not deliver optimal

performance.

If automatic release is not available, use manual

release or carry out (3).

Hill start assist

Fixed, accompanied by the

message "

Anti roll-back system

fault

The system has a fault.

Carry out (3).

Road signs recognition

Fixed, accompanied by the display of a

message and an audible signal.

The system has a fault.

Carry out (3).

Fixed, accompanied by the display of the

message "

Driving Assistance Sensor

blind: Clean sensor, see User Manual

The sensor is masked.

Stop as soon as it is safe to do so and switch off

the ignition.

Clean the front camera.

Lane keeping assist

Flashing.

You are about to cross a broken

lane marking without operating the direction

indicators.

Dashboard instruments

The system is activated, then corrects the

trajectory if it detects a risk of unintentionally

crossing a line or hard shoulder (depending on

version).

For more information, refer to the

Driving

section.

Fixed.

The system has been automatically

deactivated or placed on standby.

Fixed, accompanied by the display of the

message "

Driving Assistance Sensor

blind: Clean sensor, see User Manual

The sensor is masked.

Stop as soon as it is safe to do so and switch off

the ignition.

Clean the front camera.

Fixed, accompanied by the display

of a message and an audible

signal.

The system has a fault.

Carry out (3).

Lane positioning assist

Fixed, accompanied by the

Service warning lamp.

The system has a fault.

Carry out (3).

Driver Attention Warning by Camera

(Distraction detection)

Fixed.

The system is deactivated.

Fixed, accompanied by the display of a

message and an audible signal.

The system has a fault.

Carry out (3).

Fixed, accompanied by the display of the

message "

Driving Assistance Sensor

blind: Clean sensor, see User Manual

The sensor is masked.

Stop as soon as it is safe to do so and switch off

the ignition.

Clean the front camera.

Airbags

Fixed.

One of the airbags or seat belt

pyrotechnic pretensioners is faulty.

Carry out (3).

Front passenger airbag (ON)

Fixed.

The front passenger airbag is activated.

The control is set to the "

" position.

In this case, do not install a "rearward facing"

child seat on the front passenger seat - risk

of serious injury!

Front passenger airbag (OFF)

Fixed.

The front passenger airbag is deactivated.

The control is set to the “

OFF

” position.

A "rearward facing" child seat can be installed,

unless there is a fault with the airbags (Airbags

warning lamp on).

Under-inflation

Fixed.

The pressure in one or more tyres is too

low.

Check the pressure of the tyres as soon as

possible.

Reinitialise the detection system after adjusting

the pressure.

Under-inflation warning lamp

flashing then fixed and Service

warning lamp fixed.

The tyre pressure monitoring system is faulty.

Under-inflation detection is no longer monitored.

Check the tyre pressures as soon as possible

and carry out (3).

Parking sensors

Flashing.

The system detects an obstacle.

Fixed, accompanied by the display of a

message and an audible signal.

The system has a fault.

Carry out (3).

Fixed, accompanied by the display of the

message "

Parking Assistance Sensor

blind: Clean sensor, see User Manual

The sensor is masked.

Stop as soon as it is safe to do so and switch off

the ignition.

Clean the front and/or rear sensors.

Dashboard instruments

Stop & Start (Petrol or Diesel)

Fixed, accompanied by the display of a

message.

The Stop & Start system has been deactivated

manually.

The engine will not switch off at the next traffic

stop.

Reactivate the system via the touch screen.

Fixed.

The Stop & Start system has been

deactivated automatically.

The engine will not switch off at the next traffic

stop, if the exterior temperature is:

– below 0°C.

– above +35°C.

For more information, refer to the

Driving

section.

Flashing then fixed, accompanied by a

message.

The system has a fault.

Carry out (3).

e-Auto mode (Hybrid)

Fixed, accompanied by the display of a

message.

The e-Auto mode has been deactivated

manually.

The petrol engine will not switch off at the next

release of the accelerator pedal or at the next

traffic stop.

Reactivate the mode via the touch screen.

Rear foglamps

Fixed.

The lamps are on.

Green warning/indicator lamps
Blind spot monitoring

Fixed.

The function has been activated.

Hill Assist Descent Control

Fixed.

The function has been activated, but the

conditions for regulation are not met (gradient,

gear engaged).

Flashing.

The function is regulating the speed of

the vehicle.

The vehicle is being braked; the brake lamps

come on during the descent.

Stop & Start

Fixed.

When the vehicle stops, the Stop & Start

puts the engine into STOP mode.

Flashing temporarily.

STOP mode is momentarily unavailable

or START mode is automatically triggered.

For more information, refer to the

Driving

section.

Vehicle ready to drive (Rechargeable

hybrid)

Fixed, accompanied by an audible signal

when it comes on.

The vehicle is ready to drive.

The indicator lamp goes out upon reaching a

speed of approximately 3 mph (5 km/h) and

lights up again when the vehicle stops moving.

The lamp will go out when you turn off the

engine and exit the vehicle.

Lane positioning assist

Fixed.

The function has been activated.

All conditions have been met: the system is

operating.

For more information, refer to the

Driving

section.

Automatic wiping

Fixed.

Automatic windscreen wiping is activated.

Direction indicators

Flashing with audible signal.

The direction indicators are on.

Sidelamps

Fixed.

The lamps are on.

Dipped beam headlamps

Fixed.

The lamps are on.

Automatic headlamp dipping

Fixed.

The function has been activated

via the touch screen (

Driving

Vehicle

menu).

The lighting control stalk is in the "AUTO"

position.

Dashboard instruments

For more information, refer to the

Lighting and

visibility

section.

Blue warning/indicator lamps
Main beam headlamps

Fixed.

The lamps are on.

Black/white warning lamps
Foot on the brake

Fixed.

Insufficient or no pressure on the brake

pedal.

With an automatic gearbox, with the engine

running, before releasing the parking brake, to

move out of position

eSave function (Rechargeable hybrid)

Fixed, accompanied by the reserved

electric range.

The eSave function is activated.

Indicators

Service indicator

The servicing information is expressed in terms

of distance (miles or kilometres) and time

(months or days).

The alert is given at whichever of these two

terms is reached first.

The servicing information is displayed in the

instrument panel. Depending on the version of

the vehicle:

– The distance recorder display line indicates

the distance remaining before the next service

is due, or the distance travelled since it was due

preceded by the "-" sign.

– An alert message indicates the distance

remaining, as well as the period before the next

service is due or how long it is overdue.

The value indicated is calculated

according to the distance covered and

the time elapsed since the last service.

The alert may also be triggered close to a

due date.

Service spanner

On temporarily when the ignition is

switched on.

Between 620 and 1,860 miles (1,000 and 3,000

km) remain before the next service is due.

Fixed, when the ignition is switched on.

The next service is due in less than 620

miles (1,000 km).

Have your vehicle serviced very soon.

Service spanner flashing

Flashing then fixed, when the

ignition is switched on.

(With BlueHDi Diesel engines, associated with

the Service warning lamp.)

The servicing interval has been exceeded.

Have your vehicle serviced as soon as possible.

Resetting the service indicator

The service indicator must be reset after each

service.

If you have serviced your vehicle yourself:

► Switch off the ignition.

► Press and hold the button located on the end

of the wiper control stalk.

► Switch on the ignition; a temporary display

window appears and a countdown begins.

► When the display indicates =0, release the

button; the spanner disappears.

If you have to disconnect the battery

following this operation, lock the vehicle

and wait at least 5 minutes for the reset to be

registered.

Reminder of the servicing information

You can access the servicing information at any

time.

► Press the trip distance recorder reset button.

Dashboard instruments

The servicing information is displayed for a few

seconds, then disappears.

Engine oil level indicator

(Depending on version)

On versions fitted with an electric gauge, the

engine oil level status is displayed on the

instrument panel for a few seconds when

the ignition is switched on, after the servicing

information, in the form of messages.

The level read will only be correct if the

vehicle is on level ground and the engine

has been off for more than 30 minutes.

Low oil level

This is indicated by the message "

Oil

level incorrect

" on the instrument panel,

accompanied by the lighting of the Service

warning lamp and an audible signal.

If a low oil level is confirmed by a check using

the dipstick, the level must be topped up to avoid

damage to the engine.

For more information on

Checking levels

, refer

to the corresponding section.

Oil gauge malfunction

This is indicated by the message "

Oil level

measurement invalid

" on the instrument panel.

Consult a PEUGEOT dealer or a qualified

workshop.

In the event of a malfunction of the

electric gauge, the oil level is no longer

monitored.

If the system is faulty, you must check the

engine oil level using the manual dipstick

located in the engine compartment.

For more information on

Checking levels

refer to the corresponding section.

Coolant temperature

indicator

With the engine running:

– In zone

, the temperature is correct.

– In zone

, the temperature is too high.

The associated warning lamp and the

STOP

warning lamp light up in red on the

instrument panel, accompanied by the display of

a message and an audible signal.

You must stop the vehicle as soon as it is

safe to do so.

Wait a few minutes before switching off the

engine.

After switching off the ignition, carefully

open the bonnet and check the coolant

level.

For more information on

Checking

levels

, refer to the corresponding

section.

AdBlue

range indicators

(BlueHDi)

The Diesel BlueHDi engines are equipped with

a system that associates the SCR (Selective

Catalytic Reduction) emissions control system

and the Diesel particle filter (DPF) for the

treatment of exhaust gases. They cannot

function without AdBlue

fluid.

When the level of AdBlue

falls below the

reserve level (between 1,500 and 0 miles (2,400

and 0 km)), a warning lamp lights up when

the ignition is switched on and an estimate

of the distance that can be travelled before

engine starting is prevented is displayed in the

instrument panel.

The engine starting prevention system

required by regulations is activated

automatically once the AdBlue

tank is empty.

It is then no longer possible to start the

Dashboard instruments

engine until the minimum level of AdBlue

has

been topped up.

Manual display of driving range

While the driving range is greater than

1,500 miles (2,400 km), it is not displayed

automatically.

► Press this button to temporarily display the

driving range.

Actions required related to a lack of

AdBlue

The following warning lamps light up when the

quantity of AdBlue

is below the reserve level:

driving range of 1,500 miles (2,400 km).

Together with the warning lamps, messages

regularly remind you of the need to top up to

avoid engine starting being prevented. Refer to

the

Warning and indicator lamps

section for

details of the messages displayed.

For more information on

AdBlue

(BlueHDi)

and in particular on topping

up, refer to the corresponding section.

Warning/

indicator

lamps on

Action

Remaining

range

Top up.

Between

1,500 miles

and 500

miles (2,400

km and 800

km)

Top up as

soon as

possible.

Between

500 miles

and 62

miles (800

km and

100 km)

A top-up is

vital

, there is

a risk that the

engine will

be prevented

from starting.

Between 62

miles and 0

miles (100

km and 0

km)

To be able

to restart the

engine, add at

least 10 litres

of AdBlue

the tank.

0 miles (km)

Taking into account of top-up

Top-up detection may not be

instantaneous after addition. It may take a few

minutes of driving before the top-up detection

is effective.

Malfunction of the SCR emissions

control system

Malfunction detection

If a malfunction is detected,

these warning lamps come

on, accompanied by an

audible signal and the

display of an "

Emissions

control fault

" message.

The alert is triggered while driving when the

fault is detected for the first time, and thereafter

when switching on the ignition for subsequent

journeys, for as long as the cause of the fault

persists.

If the fault is temporary, the alert

disappears during the next journey, after

self-diagnostic checks of the SCR emissions

control system.

Malfunction confirmed during the

permitted driving phase (between 685

miles and 0 miles (1,100 km and 0 km))

If the fault indication is still displayed

permanently after 31 miles (50 km) of driving, the

fault in the SCR system is confirmed.

Dashboard instruments

The AdBlue warning lamp flashes and

a message is displayed ("

Emissions

control fault: starting prevented in X miles

(kms)

"), indicating the driving range in miles or

kilometres.

While driving, the message is displayed every 30

seconds. The alert is repeated when switching

on the ignition.

You can continue driving for up to 685 miles

(1,100 km) before the

engine starting

prevention

system is triggered.

Have it checked by a PEUGEOT dealer

or a qualified workshop.

Starting prevented

Every time the ignition is switched on, the

message "

Emissions control fault: Starting

prevented

" is displayed.

To restart the engine

Contact a PEUGEOT dealer or a

qualified workshop.

Power indicator (Hybrid or

Rechargeable hybrid)

The power indicator shows in real time the power

demanded from the vehicle.

There are 3 zones:

With hybrid engine

POWER High power demand, using the

combined capabilities of the petrol

engine and the electric motor.

The slider is located in this zone

during more dynamic driving phases

when high levels of performance are

being demanded.

ECO

Optimal use of energy (internal

combustion or electric).

The slider is located in this zone

when driving under electric power and

when optimal use is being made of

the petrol engine, both accessible by

adopting a suitable driving style.

CHARGE Energy recovery for recharging the

traction battery.

The slider is located in this zone

during deceleration: taking your foot

off the accelerator pedal or braking.

When the ignition is switched on and

before the engine is started, the power

indicator only displays "

OFF

With rechargeable hybrid engine

POWER High power demand, using the

combined capabilities of the petrol

engine and the electric motor(s)

(depending on version).

The slider is located in this zone

during more dynamic driving phases

when high levels of performance are

being demanded.

ECO

Optimal use of energy (internal

combustion or electric).

The slider is located in this zone

when driving under electric power and

when optimal use is being made of

the petrol engine, both accessible by

adopting a suitable driving style.

A symbol indicates the threshold at

which the petrol engine will restart.

The driver can therefore moderate

their acceleration to remain in electric

driving mode.

CHARGE Energy recovery for partly

recharging the traction battery.

The slider is located in this zone

during deceleration: taking your foot

off the accelerator pedal or braking.

Dashboard instruments

Charge level indicator

(Rechargeable hybrid)

The charge level of the traction battery and

the remaining range in electric driving mode

are permanently displayed when the vehicle is

switched on.

The range displayed depends on the use

of the vehicle (type of driving and speed),

the outside temperature and the activated

comfort equipment.

Manual test on the

instrument panel

This function allows you, at any time, to check

certain indicators and to display the alerts log.

► With the engine running, briefly press this

button.

The following information is displayed on the

instrument panel:

– Engine oil level.

– Next service due.

– Driving range associated with the AdBlue

and

the SCR system (BlueHDi Diesel).

– Current alerts.

This information is also displayed

automatically every time the ignition is

switched on.

Distance recorders

With the ignition on, the distances are

permanently indicated. They are deactivated

about 30 seconds after switching the ignition

off. They are displayed when the driver's door

is opened, and when the vehicle is locked or

unlocked.

When travelling abroad, you may have to

change the distance units (km or miles):

the road speed must be displayed in the local

country’s official unit (km/h or mph).

The unit is changed via the screen

configuration menu, with the vehicle

stationary.

Total distance recorder

This recorder measures the total distance

travelled by the vehicle since its initial

registration.

Trip distance recorder

This measures the distance travelled since it was

last reset by the driver.

Resetting the trip recorder

► With the ignition on, press the button until

zeros appear.

Instrument panel lighting

dimmer

Allows the instrument panel lighting to be

switched on or off.

► Press this button.

The brightness of the instrument panel lighting is

adjusted using the touch screen.

Dashboard instruments

With PEUGEOT Connect Radio

► Press this button to select the

Settings

menu.

► Select "

Brightness

► Adjust the brightness by pressing the

arrows or moving the slider.

The settings are applied immediately.

► Press outside the settings window to exit.

You can also switch off the screen:

► Press this button to select the

Settings

menu.

► Select "

Dark

The screen goes off completely.

► Press the screen again (anywhere on its

surface) to turn it on.

With PEUGEOT Connect Nav

With the lamps switched on:

► Press this button to select the

Settings

menu.

► Select "

OPTIONS

► Select "

Screen configuration

► Select the "

Brightness

” tab.

► Adjust the instrument panel and

screen brightness by using the arrows or

moving the slider.

► Press this button to save and exit.

You can also switch off the screen:

► Press this button to select the

Settings

menu.

► Select "

Turn off screen

The screen goes off completely.

► Press the screen again (anywhere on its

surface) to turn it on.

Trip computer

Displays information related to the current trip

(range, fuel consumption, average speed, etc.).

Data displayed on the

instrument panel

Trip computer data is permanently displayed

when the "

Computer

" or "

Personal

" display

mode is selected (depending on version).

In all other display modes, pressing the end of

the wiper control stalk will cause this data to

appear temporarily in a specific window.

Displaying the different tabs

► Pressing the button located on the end of the

wiper control stalk displays the following tabs in

turn:

– Current information:

• Total driving range (Petrol or Diesel).

• Current consumption (Petrol, Diesel or

Hybrid).

• Time counter for Stop & Start (Petrol or

Diesel).

• Percentage of the current journey travelled

in all-electric driving mode (Hybrid or

Rechargeable hybrid).

– Trips "

" then "

• Average speed.

• Average consumption.

• Distance travelled.

End of trip page

(Depending on version)

When the ignition is switched off, the instrument

panel automatically displays an additional page

of the trip computer that recapitulates information

about the last trip.

The end of trip page contains the following

information:

– Range.

– Trip time.

– Distance travelled.

– Percentage of the current journey travelled in

all-electric driving mode (Hybrid or Rechargeable

hybrid).

– Average consumption.

Dashboard instruments

Trip reset

► When the desired trip is displayed,

press the button on the end of the wiper

control stalk for more than 2 seconds.

Trips "

" and "

" are independent and are used

in the same way.

Definitions

Range

(miles or km)

Distance that can still be travelled with the

fuel remaining in the tank (based on the

average fuel consumption over the last few miles

(kilometres) travelled).

This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62

miles (100 km).

Dashes appearing permanently in place of

numbers while driving indicates a malfunction.

Consult a PEUGEOT dealer or a qualified

workshop.

Current consumption

(mpg or l/100 km or km/l)

Calculated during the last few seconds.

This function is only displayed at speeds above

19 mph (30 km/h).

Average consumption

(mpg or l/100 km or km/l)

Calculated since the last trip computer

reset.

Average speed

(mph or km/h)

Calculated since the last trip computer

reset.

Distance travelled

(miles or km)

Calculated since the last trip computer

reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with the Stop & Start

function, a time counter calculates the time spent

in STOP mode during a journey.

The time counter is reset each time the ignition is

switched on.

Touch screen

This system gives access to the following

elements:

– Permanent display of the time and outside

temperature (a blue warning lamp appears if

there is a risk of ice).

– Heating/air conditioning system controls.

– Vehicle functions and equipment setting

menus.

– Audio system and telephone controls and

display of related information.

– Display of visual manoeuvring aid functions

(visual parking sensor information, Park Assist,

etc.).

– Internet services and display of related

information.

– Navigation system controls and

display of related information (depending on

version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Recommendations

This screen is of the capacitive type.

– Do not use pointed objects on the touch

screen.

– Do not touch the touch screen with wet hands.

– Use a soft, clean cloth to clean the touch

screen.

Dashboard instruments

Principles

► Use the buttons arranged below the touch

screen to access the menus, then press the

buttons that appear on the touch screen.

Some menus may display across two pages:

press the "

OPTIONS

" button to access the

second page.

After a few moments with no action on

the second page, the first page is

displayed automatically.

To deactivate/activate a function, select "

OFF

or "

Configuring a function

Access to additional information on the

function

Confirm

Return to the previous page or confirm

Volume adjustment/mute.

Upper bar

Certain information is displayed permanently in

the upper bar of the touch screen:

– Time and outside temperature (a blue warning

lamp appears if there is a risk of ice).

– Reminder of the air conditioning information,

and direct access to the corresponding menu.

– Reminder of information from the

RadioMedia

and

Telephone

menus and

navigation instructions (depending on

equipment).

– Notifications.

– Access to the

Settings

for the touch screen

and the digital instrument panel (date/time,

languages, units, etc.).

Menus

Press the touch screen with three fingers

to show all of the menu buttons.

For more information about the menus,

refer to the sections describing the audio

and telematics systems.

Radio/Media

Climate

Settings for temperature, air flow, etc.

For more information on

Dual-zone automatic

air conditioning

, refer to the corresponding

section.

Navigation

(Depending on equipment)

Driving or Vehicle

(Depending on

equipment)

Activation, deactivation and settings for certain

functions.

The functions are organised in 2 tabs: "

Driving

functions

" and "

Vehicle settings

Telephone

Applications

Access to certain configurable equipment.

Energy

Access to the rechargeable hybrid system

features (energy flow, consumption statistics,

deferred charging, eSave function).

Energy menu

Flow

The page shows the operation of the

rechargeable hybrid system in real time.

Dashboard instruments

Active driving mode

Petrol engine

Electric motor(s)

Traction battery charge level

The energy flows have a colour for each type of

driving:

– Blue: 100% electrical energy.

– Orange: energy from the petrol engine.

– Green: energy recovery.

Statistics

This page shows electrical energy and fuel

consumption statistics.

Average electrical consumption for the current

trip (kWh/100 km) and historical values:

– Blue bar chart: directly consumed energy

supplied by the traction battery.

– Green bar chart: energy recovered during

deceleration and braking, used to recharge the

battery.

Average fuel consumption for the current trip

(kWh/100 km) and historical values (orange bar

chart).

► You can change the displayed time scale by

pressing the

buttons.

A current trip is any trip of more than 20

minutes without switching off the ignition.

Charging

This page allows you to programme deferred

charging.

For more information on

Charging the traction

battery (Rechargeable hybrid)

, refer to the

corresponding section.

eSave

The

eSave

function makes it possible to reserve

all or part of the electrical energy in the traction

battery for later use during a journey (e.g. driving

in an urban area or in an area reserved for

electric vehicles).

► Select the electric range to be reserved (

20 km

or the full range

MAX

) then activate

the function by pressing

Activation of the function is confirmed by

the lighting of this indicator lamp on the

instrument panel and the indication of the energy

reserve in miles or kms.

► To use the energy reserve, choose the

Electric

driving mode in the mode selector.

If the requested range exceeds the

available range (not recommended), the

internal combustion engine starts to recharge

the traction battery up to the requested

threshold. This leads to excessive fuel

consumption.

Remotely operable

additional functions

(Rechargeable hybrid)

(Depending on country of sale)

The following functions are

available from the

MYPEUGEOT

APP

application, which is

accessible from a smartphone:

– Managing the traction battery charging

(deferred charging).

– Managing the temperature pre-conditioning.

– Viewing the state of charge and range of the

vehicle.

Installation procedure

► Download the

MYPEUGEOT APP

application

from the appropriate online store for your

smartphone.

► Create an account.

► Enter the vehicle identification number

(available on the vehicle registration certificate).

For more information on

Identification

markings

, refer to the corresponding section.

Access

Electronic key with

remote control function

and built-in key

Remote control function

The remote control can be used to perform

the following remote functions (depending on

version):

– Unlocking/Locking/Deadlocking the vehicle.

– Unlocking - Opening the boot.

– Remote operation of lighting.

– Folding/Unfolding the door mirrors.

– Activating/Deactivating the alarm.

– Locating the vehicle.

– Closing the windows.

– Closing the sunroof.

– Activating the vehicle’s electronic immobiliser.

Back-up procedures allow the vehicle to be

locked/unlocked in the event of a failure of the

remote control, the central locking, the battery,

etc. For more information on the

Back-up

procedures

, refer to the corresponding section.

Built-in key

The key built into the remote control can be

used for the following operations, depending on

version:

– Unlocking/Locking/Deadlocking the vehicle.

– Activation/Deactivation of the manual child

lock.

– Activation/Deactivation of the front passenger

airbag.

– Back-up Unlocking/Locking of the doors.

► To eject the key or put it back in place, pull

and hold the button.

Once the built-in key is ejected, always

keep it with you to be able to carry out

the corresponding back-up procedures.

Unlocking the vehicle

Selective unlocking (driver’s door, boot) is

configured in the

Driving

Vehicle

touch

screen menu.

Complete unlocking

► Press the unlocking button.

Selective unlocking

Driver's door

► Press the unlocking button.

The driver's door and the fuel filler flap are

unlocked (Petrol, Diesel or Hybrid).

The driver's door is unlocked (Rechargeable

hybrid).

► Press it

again

to unlock the other doors and

the boot.

The charging nozzle can be unplugged on the

second press.

Complete or selective unlocking, and alarm

deactivation (depending on version), is confirmed

by the flashing of the direction indicators.

Depending on version, the door mirrors unfold.

Selective unlocking and opening of

the tailgate

By default, selective unlocking of the tailgate

is deactivated and its motorised operation is

activated.

Access

► With a motorised tailgate: press and

hold this button to unlock the boot and

trigger the motorised opening of the tailgate.

► With a non-motorised tailgate: press and hold

this button to unlock the boot and partially open

the tailgate.

When selective unlocking of the tailgate is

activated, the doors and the fuel filler flap remain

locked.

After a selective unlocking of the tailgate, if the

vehicle has not been fully unlocked, the tailgate

will automatically relock after closing.

If selective unlocking of the tailgate is

deactivated, pressing the button unlocks the

whole vehicle.

If motorised operation of the tailgate is

deactivated, pressing the button partially

opens the tailgate.

To lock the vehicle, it is necessary to close

the tailgate again.

Locking the vehicle

Normal locking

► Press the locking button.

The locking, and the activation of the alarm

depending on version, is confirmed by the

lighting of the direction indicators.

Depending on version, the door mirrors fold.

An access (door or boot) that is not

properly closed prevents locking of the

vehicle. However, if the vehicle is fitted with

an alarm, it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or boot

are not subsequently opened, the vehicle

will automatically lock itself again after about

30 seconds. If the vehicle is fitted with an

alarm, it will be reactivated automatically.

Deadlocking

Deadlocking renders the interior door

controls inoperative. It also disables the

central locking button.

The horn remains operational.

Never leave anyone inside the vehicle

when it is deadlocked.

► Press the locking button.

► Press the locking button again within 5

seconds to deadlock the vehicle (confirmed by

the temporary lighting of the direction indicators).

Closing the windows

Holding the locking button pressed for

more than 3 seconds closes the windows.

When closing windows, ensure that no

person or object could prevent their

correct closure.

To leave the windows partly open on versions

with alarm, you must first deactivate the

interior volumetric alarm.

For more information on the

Alarm

, refer to

the corresponding section.

Locating the vehicle

This function helps you to spot your vehicle from

a distance, with the vehicle locked:

– The direction indicators flash for approximately

10 seconds.

– The door mirror spotlamps come on.

– The courtesy lamps come on.

► Make a long press on this button.

Remote lighting of the

lamps

Availability of this function depends on version.

► Press this button. The sidelamps,

dipped beam headlamps, number plate

lamps and door mirror spotlamps come on for 30

seconds.

Pressing again before the end of the timed

period switches off the lamps immediately.

Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your

pocket, due to the risk of unintentionally

unlocking the vehicle.

Avoid pressing the remote control buttons

while out of range of the vehicle, due to

Access

the risk of rendering the remote control

inoperative. It would then be necessary to

reset it.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in

malfunctions.

Remember to turn the steering wheel to

engage the steering lock.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an

emergency.

As a safety precaution, take the electronic key

with you when leaving the vehicle, even for a

short time.

Purchasing a second-hand vehicle

Have the key codes memorised by a

PEUGEOT dealer, to ensure that the keys

in your possession are the only ones able to

start the vehicle.

Keyless Entry and Start

This system allows the unlocking, locking

and starting of the vehicle, while carrying the

electronic key on your person in the recognition

zone

Unlocking the vehicle

Selective unlocking (driver’s door, boot) is

configured in the

Driving

Vehicle

touch

screen menu.

Selective unlocking is deactivated by default.

Complete unlocking

► Pass your hand behind the handle of one

of the front doors or press the tailgate opening

control.

If the motorised tailgate opening control is

activated, this action triggers its automatic

opening.

Opening the windows

Depending on version, keeping your hand

behind the door handle or maintaining the

press on the tailgate opening control allows the

windows to be opened to the desired position.

Selective unlocking

Driver's door

► Pass your hand behind the driver’s door

handle.

The driver's door and the fuel filler flap are

unlocked (Petrol, Diesel or Hybrid).

The driver's door is unlocked (Rechargeable

hybrid).

► To unlock the vehicle completely, pass your

hand behind the front passenger door handle

with the electronic key close to the passenger

door.

Complete or selective unlocking, and

deactivation of the alarm depending on version,

is confirmed by the flashing of the direction

indicators.

Depending on version, the door mirrors unfold.

Access

Selective unlocking of the tailgate

► Press the tailgate opening control to unlock

just the boot.

The doors remain locked.

If selective unlocking of the tailgate is

deactivated, pressing this control also

unlocks the doors.

Locking the vehicle

Normal locking

► Press the handle on one of the front doors

(at the markings) or the locking control on the

tailgate.

It is not possible to lock the vehicle if one of the

electronic keys is left inside the vehicle.

Closing the windows and sunroof

Maintaining pressure on the door handle or

the tailgate control allows the windows and,

depending on version, the sunroof to be closed

to the desired position.

This operation also closes the sunroof blind.

Make sure that no item or person could

prevent the correct closing of the

windows and sunroof.

Pay particular attention to children when

operating windows.

The locking, and the activation of the alarm

depending on version, is confirmed by the

temporary lighting of the direction indicators.

Depending on version, the door mirrors fold.

Deadlocking

Deadlocking renders the interior door

controls inoperative. It also disables the

central locking button.

The horn remains operational.

Never leave anyone inside the vehicle when it

is deadlocked.

► Press the handle on one of the front doors

(at the markings) or the locking control on the

tailgate to lock the vehicle.

► Press it again within 5 seconds to deadlock

the vehicle (confirmed by the temporary lighting

of the direction indicators).

Advice

If one of the doors or the boot is still open

or if the electronic key for the Keyless

Entry and Start system has been left inside

the vehicle, central locking will not take place.

However, if the vehicle is fitted with an alarm,

it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or

boot are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is fitted with

an alarm, it will be reactivated automatically.

Depending on version, the automatic

door mirror folding/unfolding function is

configured via the touch screen's

Driving

Vehicle

menu.

Otherwise, this setting can be carried out at a

PEUGEOT dealer or a qualified workshop.

As a safety measure, never leave the

vehicle, even for a short time, without

taking the Keyless Entry and Start system’s

electronic key with you.

Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

Access

To preserve the battery charge in the

electronic key and the vehicle's battery,

the "hands-free" functions are set to

hibernation mode after 21 days without use.

To restore these functions, press one of the

remote control buttons or start the engine with

the electronic key against the back-up reader.

For more information on starting with the

Keyless Entry and Start system, refer to the

corresponding section.

Electrical interference

The electronic key may not work if it is

close to an electronic device (e.g. mobile

telephone (switched on or on standby), laptop

computer, strong magnetic fields). If this

occurs, move the electronic key away from

the electronic device.

Central locking

Manual

► Press this button to lock/unlock the vehicle

(doors and boot) from inside the vehicle.

The indicator lamp comes on to confirm the

central locking of the vehicle.

Central locking does not take place if any

of the doors are open.

When locking/deadlocking from the

outside

When the vehicle is locked or deadlocked

from the outside, the indicator lamp flashes

and the button is deactivated.

► After normal locking, pull one of the

interior door controls to unlock the vehicle.

► After deadlocking, you must use the

remote control, the "Keyless Entry and

Start" system or the built-in key to unlock the

vehicle.

Automatic (anti-intrusion

security)

The doors and boot lock automatically while

driving (speed above 6 mph (10 km/h)).

To deactivate/reactivate this function (activated

by default):

► Press the button until an audible signal is

triggered and a confirmation message appears.

Transporting long or voluminous

objects

Press the central locking control to drive

with the boot open and the doors locked.

Otherwise, every time the speed of the

vehicle exceeds 6 mph (10 km/h), the sound

of the locks rebounding will be heard and an

alert will be displayed.

Back-up procedures

Lost keys, remote control,

electronic key

Go to a PEUGEOT dealer with the vehicle's

registration certificate, your personal

identification documents and if possible, the label

bearing the key code.

The PEUGEOT dealer will be able to retrieve the

key code and the transponder code, enabling a

new key to be ordered.

Complete unlocking/locking

of the vehicle with the key

Use this procedure in the following situations:

– Remote control battery discharged.

– Remote control malfunction.

– Vehicle battery discharged.

– Vehicle in an area subject to strong

electromagnetic interference.

Peugeot 5008 (2024 year). Manual in english - page 1
