Peugeot 308 (2024 year). Manual in english

Driving

Driving recommendations

► Observe the driving regulations and remain

vigilant whatever the traffic conditions.

► Monitor your environment and keep your

hands on the wheel to be able to react to

anything that may happen any time.

► Drive smoothly, anticipate the need for

braking and maintain a longer safety distance,

especially in bad weather.

► Stop the vehicle before performing operations

that require sustained attention (e.g. settings).

► During long trips, take a break every 2 hours.

Important!

Never leave the engine running in a

closed space without sufficient

ventilation.

Internal combustion engines emit

toxic exhaust gases such as carbon

monoxide. Danger of poisoning and death!

In very severe wintry conditions

(temperature below -23°C), let the engine

run for 4 minutes before moving off, to ensure

the correct operation and durability of the

mechanical components of your vehicle

(engine and gearbox).

Never drive with the parking brake

applied.

Risk of overheating and

damaging the braking system!

Never park the vehicle and never

leave the engine running on a

flammable surface (e.g. dry grass, dead

leaves).

The vehicle exhaust system is very

hot, even several minutes after the engine

stops. Risk of fire!

Never drive on surfaces covered with

vegetation (e.g. tall grass,

accumulated dead leaves, crops, debris)

such as a field, a country lane overgrown

with bushes or a grassy verge.

This vegetation could come into contact with

the vehicle's exhaust system or other systems

which are very hot. Risk of fire!

Make sure you do not leave any item in

the passenger compartment which could

act like a magnifying glass under the effect of

the sun's rays and cause a fire. Risk of fire or

damage to interior surfaces!

Never leave the vehicle unattended,

with the engine running.

If you have to

leave your vehicle with the engine running,

apply the parking brake and put the gearbox

into neutral or position

(depending on

the type of gearbox).

Never leave children inside the vehicle

unsupervised.

On flooded roads

We strongly advise against driving on flooded

roads, as this could cause serious damage to

the internal combustion engine or electric motor,

the gearbox and the electrical systems of the

vehicle.

If the vehicle absolutely must drive through a

flooded section of road:

► Check that the depth of the water does not

exceed 15 cm, taking account of waves that

might be generated by other users.

► Deactivate the Stop & Start function.

► Drive as slowly as possible without stalling. In

all cases, do not exceed 6 mph (10 km/h).

► Do not stop and do not switch off the engine.

On leaving the flooded road, as soon as safety

conditions allow, make several light brake

applications to dry the brake discs and pads.

If in doubt about the state of your vehicle,

contact a PEUGEOT dealer or a qualified

workshop.

Driving

Noise (Electric)

On the outside

Due to the vehicle’s quiet operation when

driving, the driver must pay particular attention.

When manoeuvring, the driver must always

check the vehicle's immediate surroundings.

At speeds of up to 19 mph (30 km/h), the

pedestrian horn warns other road users of the

vehicle’s presence.

Cooling the traction battery

The cooling fan comes on during

charging to cool the on-board charger and the

traction battery.

On the inside

During use, you may hear certain perfectly

normal noises specific to electric vehicles, such

as:

– Traction battery relay when starting.

– Vacuum pump when braking.

– Vehicle tyres or aerodynamics when driving.

– Jolting and knocking noise during hill starts.

Towing

Driving with a trailer places greater

demands on the towing vehicle and

particular care must be taken.

Do not exceed the maximum towable

weights.

At altitude:

reduce the maximum load by

10% per 1,000 metres of altitude; the lower

air density at high altitudes decreases engine

performance.

New vehicle:

do not tow a trailer until the

vehicle has driven at least 620 miles

(1,000 kilometres).

If the outside temperature is high, let the

engine idle for 1 to 2 minutes after the

vehicle comes to a stop, to help it to cool.

Before setting off

Nose weight

► Distribute the load in the trailer so that the

heaviest items are located as close as possible

to the axle, and the nose weight (at the point

where it joins your vehicle) approaches the

maximum permitted, without exceeding it.

Tyres

► Check the tyre pressures of the towing

vehicle and of the trailer, observing the

recommended pressures.

Lighting

► Check the electrical signalling on the trailer

and the headlamp beam height of your vehicle.

If a genuine PEUGEOT towing device is

used, the rear parking sensors will be

deactivated automatically to avoid activating

the audible signal.

When driving

Cooling

Towing a trailer uphill causes the coolant

temperature to increase. The maximum towable

load depends on the gradient and the exterior

temperature. The fan’s cooling capacity does not

increase with engine speed.

► Reduce speed and lower the engine speed to

limit the amount of heating produced.

► Pay constant attention to the coolant

temperature.

If this warning lamp and the

STOP

warning lamp come on, stop the

vehicle and switch off the engine as soon as

possible.

Brakes

Using the engine brake is recommended to limit

the overheating of the brakes. Braking distances

are increased when towing a trailer.

Side wind

Bear in mind that the vehicle will be more

susceptible to wind when towing.

100

Driving

Anti-theft protection

Electronic immobiliser

The keys contain a code, which must be

recognised by the vehicle before starting is

possible.

If the system malfunctions, indicated by the

display of a message, the engine will not start.

Contact a PEUGEOT dealer.

Starting/switching off the

engine

The electronic key must be present in the

passenger compartment.

The electronic key is also detected in the

boot.

If the electronic key is not detected, a

message is displayed.

Move the electronic key so that the engine

can be started or switched off.

If there is still a problem, refer to the "

Key

not detected - Back-up starting or Back-up

switch-off

" section.

Starting

► With a

manual gearbox

, place the gear lever

in neutral and fully depress the clutch pedal.

► With an

automatic gearbox

, select mode

and depress the brake pedal.

► Press the "

START/STOP

" button while

maintaining pressure on the pedal until the

engine starts.

Diesel engines

With low temperatures and/or when the engine

is cold, starting takes place only after the

preheating warning lamp goes out.

If this warning lamp comes on after

pressing the "

START/STOP

" button:

► Keep the pedal fully depressed and do not

press the "

START/STOP

" button again until the

engine is running at a stabilised engine speed.

In all circumstances, if one of the starting

conditions is not met, a message is displayed.

In some circumstances, a message indicates

that it is necessary to turn the steering wheel

while pressing the "

START/STOP

" button to

assist unlocking of the steering column.

Petrol engines

After a cold start, pre-heating the

catalytic converter can cause noticeable

engine vibrations, for anything up to

2 minutes (accelerated idle speed).

Hybrid engines

The vehicle always starts with the petrol

engine to ensure the efficiency of the catalytic

converter and the availability of the brake

assist.

After a few moments, the petrol engine may

stop if the operating conditions allow (state

of charge of the traction battery, external

temperature, torque demand, selected driving

mode).

If the engine stalls, release the clutch

pedal and fully depress it again, the

engine will restart automatically.

Starting rechargeable hybrid

vehicles

► Fully depress the brake pedal and press

the

START/STOP

button for approximately

2 seconds.

► Keep the foot on the pedal until the

READY

indicator lamp comes on, indicating the

101

Driving

activation of the rechargeable hybrid system

(confirmed by an audible signal).

To exit

Park

mode, wait for the

READY

indicator lamp to come on.

By default, the system starts in

Electric

mode.

Depending on certain parameters (battery

charge level or outside temperature), the system

determines whether it is necessary to start the

petrol engine.

It is possible to change the driving mode at any

time using the mode selector.

When the vehicle starts in electric mode,

it makes no noise.

Pay particular attention to pedestrians and

cyclists who may not hear the vehicle coming

despite the pedestrian horn.

Switching off

► Deactivate cruise control alone or Drive

Assist Plus (depending on version).

► Immobilise the vehicle using the parking

brake.

► With a

manual gearbox

, ideally put the gear

lever into neutral.

► With an

automatic gearbox

, ideally select

mode

► Press the

START/STOP

button.

► For rechargeable hybrid vehicles, before

leaving the vehicle, check that the

READY

indicator lamp is switched off.

The automatic gearbox locks in mode

In some circumstances, it is necessary to turn

the steering wheel to lock the steering column.

If the vehicle is not immobilised, the

engine will not stop.

With the engine off, the braking and

steering assistance systems are also cut

off - risk of loss of control of the vehicle!

Never leave your vehicle with the

electronic key still inside.

Starting/Switching off

electric vehicles

Starting

The drive selector must be in mode

► Fully depress the brake pedal and briefly

press the

START/STOP

button.

► Keep the foot on the brake pedal until the

READY

indicator lamp comes on and an audible

signal is emitted, indicating that the vehicle is

ready to drive.

► With the foot on the brake, select the

mode

D/B

► Release the brake pedal, then accelerate.

On starting, the instrument panel lights up and

the power indicator cursor moves to the "neutral"

position. The steering column automatically

unlocks (you may hear a sound and feel the

steering wheel move).

Switching off

► Press the

START/STOP

button.

Before exiting the vehicle, check that:

– The drive selector is in mode

– The

READY

indicator lamp is off.

If the driver's door is opened while the

required conditions for stopping are not

satisfied, an audible signal is emitted,

accompanied by the display of a warning

message.

Switching on the ignition

without starting the engine

With the electronic key in the passenger

compartment, pressing the "

START/STOP

button,

without depressing any of the pedals

allows the ignition to be switched on without

starting the engine.

102

Driving

► Press this button again to switch off the

ignition and allow the vehicle to be locked.

Key not detected

Back-up starting

A back-up reader is fitted to the steering column,

to enable the engine to be started if the system

fails to detect the key in the recognition zone, or

if the battery in the electronic key is flat.

► Place and hold the remote control against the

back-up reader.

►

With a manual gearbox

, place the gear lever

in neutral, then fully depress the clutch pedal.

►

With an automatic gearbox or a drive

selector

, select mode

, then depress the brake

pedal.

► Press the "

START/STOP

" button.

The engine starts.

Back-up switch-off

If the electronic key is not detected or is no

longer in the recognition zone, a message

appears in the instrument panel when closing a

door or trying to switch off the engine.

► To confirm the instruction to switch off the

engine, press the "

START/STOP

" button for

approximately 5 seconds.

In the event of a fault with the electronic key,

contact a PEUGEOT dealer or a qualified

workshop.

Emergency switch-off

In case of emergency only, the engine can be

switched off without conditions (even when

driving).

► Press the

START/STOP

button for about

5 seconds.

Electric parking brake

In automatic mode, this system applies the

parking brake when the engine is switched off

and releases it when the vehicle moves off.

At any time, with the engine running:

► To apply the parking brake, briefly pull the

control.

► To release it, briefly push the control while

pressing the brake pedal.

Automatic mode is activated by default.

This automatic operation can be deactivated in

certain situations.

Indicator lamp

This indicator lamp comes on both on the

instrument panel and on the control to

confirm that the parking brake has been applied,

accompanied by display of the message

Parking brake applied

The indicator lamp goes out to confirm the

release of the parking brake, accompanied by

the display of the message "

Parking brake

released

103

Driving

The indicator lamp flashes in response to a

manual request to apply or release the brake.

In the event of a battery failure, the

electric parking brake will not operate.

As a safety measure, with a manual gearbox,

if the parking brake is not applied, immobilise

the vehicle by engaging a gear.

As a safety measure, with an automatic

gearbox or drive selector, if the parking brake

is not applied, immobilise the vehicle by

placing the supplied chock against one of the

wheels.

Contact a PEUGEOT dealer or a qualified

workshop.

Before leaving the vehicle, check that the

parking brake is applied: the parking

brake indicator lamps on the instrument panel

and the control must be on fixed.

If the parking brake is not applied, there is an

audible signal and a message is displayed on

opening the driver's door.

Never leave a child alone inside the

vehicle, as they could release the parking

brake.

When the vehicle is parked: on a

steep slope, heavily loaded or during

towing

With a manual gearbox, turn the wheels

toward the pavement and engage a gear.

With an automatic gearbox or a drive selector,

turn the wheels toward the pavement and

select mode

When towing, the vehicle is approved for

parking on slopes of up to 12%.

Manual operation

Manual release

With the ignition on or engine running:

► Press the brake pedal.

► While maintaining pressure on the brake

pedal, briefly push the control.

If the brake pedal is not depressed, the

parking brake is not released and a

message is displayed.

Manual application

With the vehicle stationary:

► Briefly pull the control.

The control indicator lamp flashes to confirm the

application request.

Automatic operation

Automatic release

First ensure that the engine is running and that

the driver's door is closed.

The electric parking brake gradually releases

automatically as the vehicle moves off.

With a manual gearbox

► Fully depress the clutch pedal and engage

first gear or reverse.

► Depress the accelerator pedal and release

the clutch pedal.

With an automatic gearbox

► Depress the brake pedal.

► Select mode

► Release the brake pedal and depress the

accelerator pedal.

With a drive selector

► Depress the brake pedal.

► Select mode

► Release the brake pedal and depress the

accelerator pedal.

With an automatic gearbox or drive

selector, if the brake does not release

automatically, check that the front doors are

properly closed.

When stationary with the engine running,

do not depress the accelerator pedal

unnecessarily. Risk of parking brake release.

104

Driving

Automatic application

With the vehicle stationary, the parking brake

is applied automatically when the engine is

switched off.

It is not applied automatically if the

engine stalls or enters STOP mode with

Stop & Start.

In automatic mode, the parking brake

can be manually applied or released at

any time using the control.

Special cases

Immobilising the vehicle with the

engine running

To immobilise the vehicle with the engine

running, briefly pull the control.

Parking the vehicle with the brake

released

In very cold conditions (ice), applying the

parking brake is not recommended.

To immobilise the vehicle, engage a gear or

place the chocks against one of the wheels.

With an automatic gearbox or drive

selector, mode

is automatically

selected when the ignition is switched off. The

wheels are blocked.

For more information on

Free-wheeling

, refer

to the corresponding section.

With an automatic gearbox or a drive

selector, if you open the driver's door

while mode

is engaged, an audible signal

will sound and mode

will be engaged. The

audible signal stops when the driver's door is

closed.

Deactivating automatic

operation

In some situations, for example when it is

extremely cold or when towing (e.g. caravan,

breakdown), it may be necessary to deactivate

automatic operation of the system.

► Start the engine.

► Use the control to apply the parking brake, if

it is released.

► Take your foot fully off the brake pedal.

► Push the control for 10 to a maximum of

15 seconds.

► Release the control.

► Depress and hold the brake pedal.

► Pull the control for 2 seconds.

This indicator lamp on the instrument

panel comes on to confirm deactivation of

the automatic functions.

► Release the control and the brake pedal.

From this point onwards, only the manual

functions, using the control, allow the parking

brake to be applied and released.

► Follow this procedure again to reactivate

automatic operation (confirmed by the indicator

lamp on the instrument panel going out).

Emergency braking

If depressing the brake pedal fails to provide

effective braking or in exceptional circumstances

(e.g. driver unwell, assisted driving), the vehicle

can be braked by sustained pulling on the

electric parking brake control. Braking continues

for as long as the control is kept pulled, and

ceases when the control is released.

The ABS and DSC systems stabilise the vehicle

during emergency braking.

If emergency braking malfunctions, the message

Parking brake fault

" will be displayed on the

instrument panel.

If the ABS and DSC systems

malfunction, indicated by lighting

one or both warning lamps on the instrument

panel, the vehicle’s stability is no longer ensured.

► In this case, ensure the vehicle's stability by

successive and repeated "pull-release" actions

on the electric parking brake control until the

vehicle comes to a complete stop.

105

Driving

Manual gearbox

Engaging 5

or 6

gear

► Move the gear selector fully to the right to

engage 5

or 6

gear.

Failure to follow this instruction could

cause permanent damage to the gearbox

(inadvertent engagement of 3

or 4

gear).

Engaging reverse gear

► Raise the ring under the knob and move the

gear selector to the left, then forwards.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

engine starting:

► Always select neutral.

► Press the clutch pedal.

Automatic gearbox

(EAT8/e-EAT8)

For petrol/Diesel versions

Automatic 8-speed gearbox with push selector.

It also offers a manual mode with gear changes

via control paddles located behind the steering

wheel.

For rechargeable hybrid

versions

Automatic 8-speed gearbox with push selector

and regenerative braking function.

With the exception of the manual mode and

regenerative braking function, its operation is

identical to that of other EAT8 gearboxes.

Push selector

Auto Park

Press this button to switch to Parking mode.

For parking the vehicle: the front wheels are

blocked.

Reverse

Neutral

To free-wheel and move the vehicle, with the

ignition off.

For more information on

Free-wheeling

, refer

to the corresponding section.

Driving in automatic mode

The gearbox manages gear changes

according to the style of driving, the road

profile and the vehicle load.

Driving in manual mode (Petrol / Diesel)

Press this button to switch to manual mode.

The driver changes gear using the steering-

mounted controls.

Driving in automatic mode with regenerative

braking function (Rechargeable hybrid)

Press this button to activate the regenerative

braking function.

The gearbox also manages braking when the

accelerator pedal is released.

► In mode

, with your foot on the brake pedal,

push without passing the point of resistance:

• Forwards, mode

is selected.

• Backwards, mode

is selected.

Release the selector fully after each push; it

will then return to its initial position.

106

Driving

Special cases

To avoid mode

(quick change from

and

back again):

► In mode

, push backwards past the point of

resistance, mode

is selected.

► In mode

, push forwards past the point of

resistance, mode

is selected.

► To return to mode

, push without passing

the point of resistance.

Steering-mounted controls

(Depending on equipment)

In mode

, the steering-mounted control

paddles can be used to change gear manually.

They cannot be used to select neutral or to

engage or disengage reverse gear.

► Pull the "

" or "

" paddle towards you and

release to shift up or down a gear, respectively.

Information displayed on

the instrument panel

When the ignition is switched on, the gearbox

status is displayed on the instrument panel:

Parking

Reverse

Neutral

D1...8

Automatic forward gear

B1...8

Automatic forward gear with

regenerative braking function activated

M1...8

Manual forward gear

In all-electric driving, the gear engaged is not

indicated.

The state of the gearbox remains displayed on

the instrument panel for a few seconds after

switching off the ignition.

Operation

Only appropriate mode change instructions are

validated.

With the engine running, if it is necessary to

depress the brake pedal to change modes,

an alert message will be displayed on the

instrument panel.

With the engine running and the brakes

released, if

is selected, the

vehicle moves off, even without pressing the

accelerator pedal.

Never depress the accelerator and brake

pedals at the same time - risk of damage to

the gearbox!

If you open the driver's door while mode

is engaged, an audible signal will

sound and mode

will be engaged. The

audible signal stops when the driver's door is

closed.

At speeds below 3 mph (5 km/h),

opening the driver’s door will engage

mode

- risk of sudden braking!

In the event of battery failure, it is

essential to place the chock(s) supplied

with the tool kit against one of the wheels to

immobilise the vehicle.

Special aspects of automatic mode

The gearbox selects the gear that provides

optimal performance based on ambient

temperature, road profile, vehicle loading and

driving style.

For maximum acceleration, press the accelerator

fully down (kick-down). The gearbox changes

down automatically or holds the selected gear

until the maximum engine speed is reached.

Steering mounted controls allow the driver to

temporarily select a gear, if the vehicle speed

and engine speed conditions permit.

Special aspects of manual mode

The gearbox only changes from one gear to

another if the vehicle speed and engine speed

conditions permit.

107

Driving

Regenerative braking (Brake function)

The regenerative braking function emulates

engine braking, slowing the vehicle with no need

to depress the brake pedal. When the driver

releases the accelerator pedal, the vehicle slows

down more quickly.

The energy recovered when the accelerator

pedal is released is used to partially recharge the

traction battery.

This partial recharging has no effect on

the charge level indicator.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

► From mode

, press button

to activate/

deactivate the function.

on the instrument panel is replaced with

The state of the function is not saved when the

ignition is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

Regenerative braking using the brake

pedal

Energy recovery can also be produced

by depressing the brake pedal in order to

partially recharge the traction battery, without

affecting the charge level indicator.

Starting the vehicle

► Fully depress the brake pedal.

► Start the engine.

► With your foot on the brake pedal, push once

or twice backwards to select automatic mode

or forwards to shift into reverse gear

► Release the brake pedal.

► Accelerate gradually to automatically release

the electric parking brake.

The vehicle moves off immediately.

Automatic gearbox

Never try to start the engine by pushing

the vehicle.

Switching the vehicle off

Regardless of the current gearbox mode,

mode

is immediately engaged automatically

when the ignition is switched off.

However, in mode

, mode

will be engaged

after a delay of 5 seconds (time to enable free-

wheeling mode).

Check that mode

has been engaged and

that the electric parking brake was applied

automatically; if not, apply it manually.

The corresponding indicator lamps on the

gear selector and the electric parking

brake control must be on, as well as the indicator

lamps on the instrument panel.

Gearbox malfunction

This warning lamp comes on,

accompanied by an audible signal and

the display of a message.

Go to a PEUGEOT dealer or a qualified

workshop.

Do not drive faster than 62 mph (100 km/h),

keeping to the speed limit.

Switching of the gearbox to back-up mode

Mode

locks in third gear.

The paddles on the steering wheel do not work

and mode

is no longer accessible.

You may feel a significant jolt on engaging

reverse gear. This will not damage the gearbox.

Selector malfunction

Minor malfunction

This warning lamp comes on,

accompanied by the display of a message

and an audible signal.

Drive carefully.

Go to a PEUGEOT dealer or a qualified

workshop.

In some cases, the selector indicator lamps may

no longer come on, but the gearbox state is still

displayed on the instrument panel.

108

Driving

Major malfunction

This warning lamp comes on,

accompanied by the display of a

message.

You must stop the vehicle.

Stop as soon as it is safe to do so and

switch off the ignition.

Contact a PEUGEOT dealer or a qualified

workshop.

Electric dual-clutch

automatic gearbox

(e-DCS6/7)

6-speed

or 7-speed electrified dual-clutch

automatic gearbox with push selector for

respectively hybrid vehicles or rechargeable

hybrid vehicles.

It also offers a manual mode with gear changes

via control paddles located behind the steering

wheel.

It includes the 48 V electric motor, which

improves the performance of the petrol engine,

reduces fuel consumption and drives in

all-electric.

Push selector

For hybrid vehicles

For rechargeable hybrid vehicles

Auto Park

Press this button to switch to Parking mode.

For parking the vehicle: the front wheels are

blocked.

Reverse

Neutral

To free-wheel and move the vehicle, with the

ignition off.

For more information on

Free-wheeling

, refer

to the corresponding section.

Driving in automatic mode

The gearbox manages gear changes

according to the style of driving, the road

profile and the vehicle load.

Driving in manual mode (Hybrid)

Press this button to switch to manual mode.

The driver changes gear using the steering-

mounted controls.

Driving in automatic mode with regenerative

braking function (Rechargeable hybrid)

Press this button to activate the regenerative

braking function.

The gearbox also manages braking when the

accelerator pedal is released.

► In mode

, with your foot on the brake pedal,

push without passing the point of resistance:

• Forwards, mode

is selected.

• Backwards, mode

is selected.

Release the selector fully after each push; it

will then return to its initial position.

Special cases

To avoid mode

(quick change from

and

back again):

► In mode

, push backwards past the point of

resistance, mode

is selected.

► In mode

, push forwards past the point of

resistance, mode

is selected.

109

Driving

► To return to mode

, push without passing

the point of resistance.

Steering-mounted controls

(Depending on equipment)

In mode

, the steering-mounted control

paddles can be used to change gear manually.

They cannot be used to select neutral or to

engage or disengage reverse gear.

► Pull the "

" or "

" paddle towards you and

release to shift up or down a gear, respectively.

Electric motor

The electric motor included in the automatic

gearbox, which is used for the first start, provides

12 V power supply via the DC/DC converter and

provides electric assistance to the petrol engine.

The electric motor has the following features:

– Provide an additional torque to the gearbox,

optimising the performance of the petrol engine.

– Recover the kinetic energy of the deceleration

phases, converting it into electrical energy, which

can be used for traction or for the power supply

of electrical accessories installed on the vehicle.

– Recharge the 48 V traction battery when the

state of charge is too low.

– Provide all-electric driving only.

These features are achieved through the

following functions set of automatic operating

mode:

– e-Boost.

– e-Creeping.

– e-Launch.

– e-Queueing.

– e-Parking.

A manual operating mode is also available

to activate/deactivate the restart of the petrol

engine while driving: the e-Auto mode.

When mode

is selected on the

automatic gearbox, the noise level in the

engine compartment may increase due to the

start of the charging phase of the traction

battery: this is normal and does not represent

a malfunction.

Information displayed on

the instrument panel

When the ignition is switched on, the gearbox

status is displayed on the instrument panel:

Parking

Reverse

Neutral

Automatic forward gear (Hybrid)

M1...6

Manual forward gear (Hybrid)

D1...7

Automatic forward gear (Rechargeable

hybrid)

B1...7

Automatic forward gear with

regenerative braking function

(Rechargeable hybrid)

The gear engaged is also displayed in Sport

mode.

However, in all-electric driving, the gear engaged

is not indicated.

The state of the gearbox remains displayed on

the instrument panel for a few seconds after

switching off the ignition.

Operation

Only appropriate mode change instructions are

validated.

With the engine running, if it is necessary to

depress the brake pedal to change modes,

an alert message will be displayed on the

instrument panel.

With the engine running and the brakes

released, if

is selected, the

vehicle moves off, even without pressing the

accelerator pedal.

Never depress the accelerator and brake

pedals at the same time - risk of damage to

the gearbox!

If you open the driver's door while mode

is engaged, an audible signal will

sound and mode

will be engaged. The

110

Driving

audible signal stops when the driver's door is

closed.

At speeds below 3 mph (5 km/h),

opening the driver’s door will engage

mode

- risk of sudden braking!

In the event of battery failure, it is

essential to place the chock(s) supplied

with the tool kit against one of the wheels to

immobilise the vehicle.

Special aspects of automatic mode

These functions respond to common driving

situations where the electric motor is available

to provide additional power or zero-emission

driving.

These functions are only available if the

traction battery is sufficiently charged.

These five functions cannot be deactivated.

e-Launch

With the petrol engine off, this function allows the

vehicle to run in electric mode without affecting

performance.

By depressing the accelerator pedal, the vehicle

starts to drive as soon as the mode

of the

automatic gearbox is selected.

e-Creeping

With the petrol engine off, by releasing the

brake pedal, this function allows the vehicle to

be moved forward or backward in electric mode

without having to depress the accelerator pedal,

as soon as the mode

of the automatic

gearbox is selected.

e-Queueing

This function makes it possible to follow a

queue of vehicles with several stops followed

by restarts of the vehicle, using the e-Creeping,

e-Launch and electric driving modes.

e-Parking

This function allows parking manoeuvres to be

carried out at reduced speed with the help of

the electric motor when the mode

of the

automatic gearbox is selected.

e-Boost

This function allows simultaneous operation

of the petrol engine and the electric motor,

combined with the automatic gearbox.

By fully depressing the accelerator pedal ("kick-

down" function), when the traction battery is fully

charged, it is possible to exceed the torque of

the petrol engine alone, thanks to the additional

torque provided by the electric motor.

Repeated use of the brake pedal causes

the restart of petrol engine to provide

braking assistance.

Special aspects of manual mode

The gearbox only changes from one gear to

another if the vehicle speed and engine speed

conditions permit.

The petrol engine can also be switched off in

manual mode when stopped in traffic or when

the accelerator pedal is released.

For hybrid vehicles, the all-electric potential of

the driving mode used (

Normal

Eco

) is also

retained.

For rechargeable hybrid vehicles, the all-electric

potential of the driving mode used (

Hybrid

Electric

) is also retained.

Using the steering wheel paddles also

causes the restarting of petrol engine.

If high traction is required, the driver can

deactivate the e-Auto mode using the touch

screen application.

Regenerative braking (Brake

function)

The regenerative braking function emulates

engine braking, slowing the vehicle with no need

to depress the brake pedal. When the driver

releases the accelerator pedal, the vehicle slows

down more quickly.

The energy recovered when the accelerator

pedal is released is used to partially recharge the

traction battery.

111

Driving

This partial recharging has no effect on

the charge level indicator.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

► From mode

, press button

to activate/

deactivate the function.

on the instrument panel is replaced with

The state of the function is not saved when the

ignition is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

Regenerative braking using the brake

pedal

Energy recovery can also be produced

by depressing the brake pedal in order to

partially recharge the traction battery, without

affecting the charge level indicator.

Starting the vehicle

► Fully depress the brake pedal.

► Start the petrol engine by depressing the

brake pedal until the engine is running at a

stabilised engine speed.

► With your foot on the brake pedal, push once

or twice backwards to select automatic mode

or forwards to shift into reverse gear

► Release the brake pedal.

► Accelerate gradually to automatically release

the electric parking brake.

The petrol engine may stop after the first start if

operating conditions allow (e.g. state of charge

of the traction battery, external temperature,

efficiency of the catalytic converter, torque

demand, selected driving mode, thermal comfort

of the passenger compartment).

Then, the vehicle moves off immediately in all-

electric (e-Launch function).

Switching the

vehicle off

Regardless of the current gearbox mode,

mode

is immediately engaged automatically

when the ignition is switched off.

However, in mode

, mode

will be engaged

after a delay of 5 seconds (time to enable free-

wheeling mode).

Check that mode

has been engaged and

that the electric parking brake was applied

automatically; if not, apply it manually.

The corresponding indicator lamps on the

gear selector and the electric parking

brake control must be on, as well as the indicator

lamps on the instrument panel.

Gearbox malfunction

This warning lamp comes on,

accompanied by an audible signal and

the display of a message.

Go to a PEUGEOT dealer or a qualified

workshop.

Do not drive faster than 62 mph (100 km/h),

keeping to the speed limit.

Switching of the gearbox to back-up mode

Depending on the malfunction, the gearbox only

shifts in odd or even gears, locks in one gear or

loses some gears.

For hybrid vehicles, the paddles on the steering

wheel do not work and mode

is no longer

accessible.

You may feel a significant jolt on engaging

reverse gear. This will not damage the gearbox.

Selector malfunction

Minor malfunction

This warning lamp comes on,

accompanied by the display of a message

and an audible signal.

Drive carefully.

Go to a PEUGEOT dealer or a qualified

workshop.

In some cases, the selector indicator lamps may

no longer come on, but the gearbox state is still

displayed on the instrument panel.

112

Driving

Major malfunction

This warning lamp comes on,

accompanied by the display of a

message.

You must stop the vehicle.

Stop as soon as it is safe to do so and

switch off the ignition.

Contact a PEUGEOT dealer or a qualified

workshop.

Drive selector (Electric)

The drive selector is a pulse selector with a

regenerative braking function.

The drive selector provides traction control

based on the driving style, the road profile and

the vehicle load.

With regenerative braking activated, it also

manages engine braking when the accelerator

pedal is released.

Park

Button for parking the vehicle: the front

wheels are locked (the button lights up to

indicate that it is activated).

Reverse

To engage reverse gear, with your foot on the

brake pedal.

Neutral

To move the vehicle with the ignition off and

so allow it to free-wheel.

For more information on

Free-wheeling

, refer

to the corresponding section.

Drive (automatic forward gear)

Brake (regenerative braking)

Regenerative braking (the button lights up to

indicate its activation).

Information displayed on

the instrument panel

When the ignition is switched on, the drive

selector status is displayed on the instrument

panel:

: Park.

: Reverse.

: Neutral.

: Drive (automatic forward gear).

: Brake (regenerative braking activated).

Operation

► In mode

, with your foot on the brake pedal,

push without passing the point of resistance:

• Forwards, mode

is selected.

• Backwards, mode

is selected.

Release the selector fully after each push; it

will then return to its initial position.

Special cases

To avoid mode

(quick change from

and

back again):

► In mode

, push backwards past the point of

resistance, mode

is selected.

► In mode

, push forwards past the point of

resistance, mode

is selected.

► To return to mode

, push without passing

the point of resistance.

Regenerative braking

With the Brake function and when

decelerating

The Brake function emulates engine braking,

slowing the vehicle with no need to depress the

brake pedal. The vehicle slows more quickly

when the driver releases the accelerator pedal.

The energy recovered when the accelerator

pedal is released is then used to partially

recharge the traction battery, thereby increasing

the vehicle's driving range.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

113

Driving

► From mode

, press button

to activate/

deactivate the function (the button lights up when

the function is activated).

on the instrument panel is replaced with

The system status is not saved when the ignition

is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

With the brake pedal

When the brake pedal is depressed, the

intelligent braking system automatically recovers

some of the energy and uses it to recharge the

traction battery.

This energy recovery also reduces use of the

brake pads, thereby limiting their wear.

The driver may experience a different

sensation when depressing the brake

pedal compared to a vehicle without

regenerative braking.

Driving modes

The driving modes available depend on the

engine and equipment of the vehicle.

Driving modes are selected using the following

control:

► Press the control to display the modes on the

instrument panel.

► Press the control again to change mode.

With an electric vehicle, when starting the

vehicle, no mode can be selected until the

READY

indicator lamp is displayed.

When the message disappears, the selected

mode is activated and remains indicated on the

instrument panel (except

Normal

mode).

The selected mode is activated immediately.

For petrol, Diesel or hybrid

versions

Whenever the ignition is switched on,

Normal

driving mode is selected by default.

Normal

To restore the default settings.

Eco

To reduce energy consumption by reducing the

performance of the heating and air conditioning,

without deactivating them.

Sport

With a manual gearbox: to obtain more dynamic

driving with action on the power steering,

accelerator and the possibility of displaying the

vehicle’s dynamic settings on the instrument

panel.

With an automatic gearbox: to obtain more

dynamic driving with action on the power

steering, accelerator, gear changes, displaying

the vehicle’s dynamic settings on the instrument

panel (depending on version) and activation/

deactivation of the display colour (depending on

version).

The selection of the

Sport

mode deactivates the

Stop & Start function / e-Auto mode.

Coasting mode (Petrol or Diesel)

Depending on version and engine, with

the gear selector in mode

, in

Eco

and

Normal

modes, gradually and fully releasing

the accelerator pedal allows free-wheeling

which can save fuel.

A drop in engine speed is normal (rev counter

at idle, drop in engine noise).

114

Driving

For rechargeable hybrid

versions

Whenever the ignition is switched on,

Electric

driving mode is selected by default.

Electric

Allows driving using 100% electrical energy.

The maximum speed is approximately 84 mph

(135 km/h).

When starting the vehicle, if the conditions do

not allow the activation or retention of

Electric

mode, the message "

Electric mode currently

unavailable

" is displayed on the instrument

panel. The vehicle automatically changes to

Hybrid

mode.

Conditions of activation

– Adequate battery charge level. Charging

the vehicle after each drive is therefore

recommended.

Electric

mode is available as

long as there is power left in the battery.

– Outside temperature between approximately

-5°C and 45°C.

Manually exiting the mode

► Fully depress the accelerator pedal, or

► Select another mode.

In case of non-use of the vehicle for a

long period (several months), a restart of

the petrol engine may occur even if the

battery is charged.

In the event of multiple starts of the

internal combustion engine without a

sufficient rise in temperature,

Electric

mode

may be temporarily unavailable (natural

phenomenon of dilution of fuel in oil). The

message "

Electric mode unavailable:

automatic operation in progress

" then

appears on the instrument panel.

To regain normal electrical operation, drive

approximately 50 miles (80 km) in "motorway"

conditions or approximately 125 miles

(200 km) in urban conditions.

This phenomenon does not cause any

mechanical or electrical damage. It can occur

several times in the life of the vehicle.

Hybrid

To optimise the vehicle's fuel consumption by

managing the

alternating or simultaneous

operation of the two types of engine

depending on driving conditions and driving

style.

Hybrid

mode, it is possible to drive in 100%

electric mode if the battery charge level is

sufficient and acceleration requirements are

moderate.

Sport

To obtain more dynamic driving in order to

benefit from the maximum performance of the

vehicle.

Electric power is used to supplement the petrol

engine as long as there is energy left in the

battery.

For electric versions

Each time the ignition is switched on,

Normal

mode is selected by default.

Normal

This optimises the driving range and dynamic

performance.

To obtain maximum torque and power, depress

the accelerator pedal fully.

Eco

Optimises energy consumption, by reducing

the output of the heating and air conditioning

(without actually deactivating them) and limiting

both motor torque and power.

Sport

Enables more dynamic driving, acting on the

power steering, accelerator and gear changes

with a drive selector and the possibility of

displaying the vehicle’s dynamic settings on the

instrument panel.

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

– The vehicle is completely stationary, with your

foot on the brake pedal.

– Certain slope conditions are met.

– The driver’s door is closed.

115

Driving

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

Operation

Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

– If first gear or neutral is engaged on a manual

gearbox.

– If mode

is selected on an automatic

gearbox.

– If mode

is selected on the drive

selector.

Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Gear shift indicator

(Depending on engine)

This system is designed to reduce fuel

consumption by recommending the most suitable

gear.

Operation

Depending on the driving situation and

the vehicle's equipment, the system may

recommend skipping one or more gears.

Gear engagement recommendations are

not to be considered mandatory. Indeed, the

configuration of the road, the traffic density and

safety remain determining factors when choosing

the best gear. Therefore, the driver remains

responsible for deciding whether or not to follow

the system’s advice.

The system cannot be deactivated.

With an automatic gearbox, the system is

only active in manual operation.

The information appears on the

instrument panel, in the form of an arrow

and the recommended gear.

The system adapts the gear change

instructions according to the driving

conditions (e.g. slope, load) and driving style

(e.g. power demand, acceleration, braking).

The system never suggests:

– engaging first gear.

– engaging reverse gear.

Stop & Start (Petrol or

Diesel)

The Stop & Start function puts the engine

temporarily into standby - STOP mode - during

phases when the vehicle is stationary (e.g. red

lights, traffic jams). The engine automatically

restarts - START mode - as soon as the driver

indicates the intention of moving off again.

Primarily designed for urban use, the function

is intended to reduce fuel consumption and

116

Driving

exhaust emissions as well as the noise level

when stationary.

The function does not affect the functionalities of

the vehicle, in particular the braking.

Deactivation/Reactivation

By default, the function is activated when the

ignition is switched on.

It is configured in the

ADAS

touch screen

application.

Direct access to the

Shortcuts for driving aids

The display of a message on the instrument

panel confirms the change of state.

If the function is deactivated while the engine is

in STOP mode, it will restart immediately.

Associated indicator lamps

Function activated: engine on standby

(STOP mode)

Function deactivated or malfunction

Opening the bonnet

Before doing anything under the bonnet,

deactivate the Stop & Start system to avoid

any risk of injury caused by the engine

restarting automatically.

Driving on flooded roads

Before entering into a flooded area, it is

strongly recommended that you deactivate

the Stop & Start system.

For more information on

Driving

recommendations

, particularly on flooded

roads, refer to the corresponding section.

Operation

Main conditions for operation

– The driver’s door must be closed.

– The driver's seat belt must be fastened.

– The level of charge in the battery must be

sufficient.

– The temperature of the engine must be within

its nominal operating range.

– The outside temperature must be between

0°C and 35°C.

Putting the engine into standby

(STOP mode)

The engine automatically enters standby mode

as soon as the driver indicates their intention to

stop:

–

With a manual gearbox:

when you place

the gear lever in neutral and release the clutch

pedal.

–

With an automatic gearbox:

with the gear

selector in mode

, when the brake pedal

is depressed until the vehicle stops or when the

mode

is selected, with the vehicle stationary.

Time counter

A time counter adds up the time spent in standby

during the journey. It is reset to zero every time

the ignition is switched on.

Special cases

The engine will not go into standby if the

conditions for operation are not met and in the

following cases:

– Steep slope (ascending or descending).

– Sport mode selected (depending on

equipment).

– Needed to maintain a comfortable temperature

in the passenger compartment.

– Demisting active.

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

117

Driving

After the engine has restarted, STOP

mode is not available until the vehicle

has reached a speed of 5 mph (8 km/h).

During parking manoeuvres, STOP mode

is not available for a few seconds after

coming out of reverse gear or turning the

steering wheel.

Restarting the engine (START mode)

The engine automatically restarts as soon as the

driver indicates the intention of moving off again:

With a manual gearbox:

when the clutch pedal

is fully depressed.

With an automatic gearbox:

– With the selector in mode

: when the

brake pedal is released.

– With the selector in mode

and the brake

pedal released: when the mode

selected.

– With the selector in mode

and the brake

pedal depressed: when the mode

is selected.

– When the reverse gear is engaged.

Special cases

The engine will restart automatically if the

conditions for operation are met again and in the

following cases:

– Deselecting the Sport mode (depending on

equipment).

– With a manual gearbox: vehicle speed

exceeds 2.5 mph (4 km/h).

– With an automatic gearbox, in mode

, vehicle

speed exceeds 0.6 mph (1 km/h).

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

Malfunctions

In the event of a fault with the system, this

warning lamp flashes for a few moments

on the instrument panel, then remains on,

accompanied by the display of a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

The vehicle stalls in STOP mode

All of the instrument panel warning lamps come

on if there is a fault.

► Switch off the ignition then start the engine

again with the key or the

START/STOP

button.

12 V battery

The Stop & Start system requires a

12 V battery of specific technology and

specification.

All work must be carried out only by a

PEUGEOT dealer or a qualified workshop

e-Auto mode (Hybrid)

The petrol engine stops when low power or

torque is required and in stabilised conditions.

The petrol engine is restarted by the belt starter.

The e-Auto mode can switch off the petrol

engine in the following cases:

– When the operating strategies permit.

– Vehicle speed up to 90 mph (145 km/h).

– When the driver releases the accelerator

pedal in stabilised conditions or in deceleration.

– During the stop phases.

Restarting is only achieved by the belt starter

until the torque demand is available, if the

traction battery is sufficiently charged. When the

torque demand is insufficient, the petrol engine

restarts.

Using the steering wheel paddles also

causes the restarting of petrol engine.

The e-Auto mode cannot switch off the petrol

engine in the following cases:

– The state of charge is less than 30% of the

traction battery energy.

– There is a need for vacuum brake assist

depending on the altitude.

– The Sport mode is selected.

– Maintaining thermal comfort in the passenger

compartment (heating, air conditioning,

demisting/defrosting).

Deactivation/Reactivation

By default, the function is activated when the

ignition is switched on.

It is configured in the

ADAS

touch screen

application.

Direct access to the

Shortcuts for driving aids

118

Driving

The display of a message on the instrument

panel confirms the change of state.

Function deactivated, this indicator lights

up in the instrument panel.

If high traction is required, the driver can

deactivate the e-Auto mode using the

touch screen application.

Tyre under-inflation

detection

This system alerts the driver if one or more tyres

suffer a drop in pressure.

The alert is raised when the vehicle is moving,

not when stationary.

It compares the information given by the wheel

speed sensors with

reference values, which

must be reinitialised every time the tyre

pressures are adjusted or a wheel changed

It takes into account the last values stored

during the reinitialisation request. It is therefore

essential that the tyre pressure is correct during

the operation. This operation is the driver’s

responsibility.

The tyre under-inflation detection cannot,

in any circumstances, replace the need

for vigilance on the part of the driver.

This system does not avoid the need to

regularly check the tyre pressures (including

the spare wheel), especially before a long

journey.

Driving with under-inflated tyres, particularly

in adverse conditions (heavy load, high

speed, long journey):

– worsens road-holding.

– lengthens braking distances.

– causes premature wear of the tyres.

– increases energy consumption.

The inflation pressures defined for the

vehicle can be found on the tyre pressure

label.

For more information on the

Identification

markings

, refer to the corresponding section.

Checking tyre pressures

This check should be done monthly

when the tyres are "cold" (vehicle stopped for

1 hour or after a journey of less than 6 miles

(10 km) at moderate speeds).

Otherwise, add 0.3 bar to the pressures

shown on the label.

Snow chains

The system does not have to be

reinitialised after fitting or removing snow

chains.

Under-inflation alert

This is signalled by the fixed illumination

of this warning lamp, accompanied by an

audible signal and, depending on equipment, the

display of a message.

► Reduce speed immediately, avoid excessive

steering movements and avoid sudden braking.

► Stop the vehicle as soon as it is safe to do

so.

The loss of pressure detected may not

always cause visible deformation of the

tyre.

Do not rely on just a visual check.

► Using a compressor, such as the one in

the temporary puncture repair kit, check the

pressures of all four tyres when cold.

► If it is not possible to carry out this check

immediately, drive carefully at reduced speed.

► In the event of a puncture, use the

temporary puncture repair kit or the spare wheel

(depending on equipment).

Driving too slowly may not ensure

optimum monitoring.

The alert is not immediately triggered in the

event of a sudden loss of pressure or tyre

blow-out. This is because analysis of the

values read by the wheel's speed sensors

can take several minutes.

The alert may be delayed at speeds below

25 mph (40 km/h), or when adopting a sporty

driving mode.

The alert is kept active until the system is

reinitialised.

119

Driving

Reinitialisation

The system must be reinitialised after any

adjustment to the pressure of one or more tyres,

and after changing one or more wheels.

Before reinitialising the system, make

sure that the pressures of the four tyres

are correct for the conditions of use of the

vehicle and conform to the values written on

the tyre pressure label.

Check the pressures of the four tyres before

performing the reinitialisation.

The system does not advise if a pressure is

incorrect at the time of reinitialisation.

With the vehicle stationary, the system

can be reinitialised in the

Settings>Vehicle

touch screen application.

► Then select

Safety > Tire Pressure Setup

► Press

YES

to confirm.

The reinitialisation is confirmed by the display of

a message and an audible signal.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel.

A message appears, accompanied by an audible

signal.

In this case, the tyre under-inflation monitoring

function is no longer performed.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Non-standard or 'space-saver' spare

wheel

The use of this type of spare wheel may

suspend tyre pressure monitoring.

In this case, the malfunction warning lamp

comes on and disappears once the wheel

has been replaced by one of uniform size (the

same as the others), the pressure readjusted

and the reinitialisation carried out.

Driving and manoeuvring

aids - General

recommendations

Driving and manoeuvring aids cannot, in

any circumstances, replace the need for

vigilance on the part of the driver.

The driver must comply with the Highway

Code, must remain in control of the vehicle in

all circumstances and must be able to retake

control of it at all times. The driver must adapt

the speed to climatic conditions, traffic and

the state of the road.

It is the driver's responsibility to constantly

monitor traffic conditions, assess the distance

and relative speed of other vehicles, and

anticipate their manoeuvres before using the

direction indicator and changing lanes.

These systems do not make it possible to

exceed the laws of physics.

Driving aids

You should hold the steering wheel with

both hands, always use the door and interior

mirrors, always leave your feet close to the

pedals and take a break every 2 hours.

Manoeuvring aids

The driver must always check the

surroundings of the vehicle before and during

the whole manoeuvre, in particular using the

mirrors.

Radar(s)

The operation of the radar(s), along with

any associated functions, may be affected

by the accumulation of dirt (e.g. mud, ice),

in poor weather conditions (e.g. heavy rain,

snow), by the masking of the detection zone

with adhesive labels or other objects, or if the

bumpers are damaged.

If the front or rear bumper is to be repainted,

contact a PEUGEOT dealer or a qualified

workshop; certain types of paint could

interfere with the operation of the radar(s).

Take care not to cover the detection zones

on the front and rear bumpers with adhesive

labels or other objects; they may hamper

correct operation of the associated system.

120

Driving

Driving aids camera

This camera and its associated functions

may be impaired or not work if the windscreen

area in front of the camera is dirty, misty,

frosty, covered with snow, damaged or

masked by a sticker.

In humid and cold weather, demist the

windscreen regularly.

Poor visibility (e.g. inadequate street lighting,

heavy rain, thick fog, snowfall), dazzle

(e.g. headlamps of an oncoming vehicle, low

sun, reflections on a damp road, leaving a

tunnel, alternating shade and light) can also

impair detection performance.

In the event of a windscreen replacement,

contact a PEUGEOT dealer or a qualified

workshop to recalibrate the camera;

otherwise, the operation of the associated

driving aids may be disrupted.

Other cameras

The images from the camera(s)

displayed on the touch screen or on the

instrument panel may be distorted by the

terrain.

In the presence of areas in shade, or in

conditions of bright sunlight or inadequate

lighting, the image may be darkened and with

lower contrast.

Obstacles may appear further away than they

actually are.

Sensors

The operation of the sensors, as well as

any associated functions, may be disrupted

by noise pollution such as that emitted by

noisy vehicles and machinery (e.g. lorries,

pneumatic drills), by the accumulation of

snow or dead leaves on the road or in the

event of damaged bumpers and mirrors.

When reverse gear is engaged, an audible

signal (long beep) indicates that the sensors

may be dirty.

A front or rear impact to the vehicle can

upset the sensors’ settings, which is not

always detected by the system: distance

measurements may be distorted.

The sensors do not systematically detect

obstacles that are too low (pavements, studs)

or too thin (trees, posts, wire fences).

Certain obstacles located in the sensors’ blind

spots may not be detected or may no longer

be detected during the manoeuvre.

Certain materials (fabrics) absorb sound

waves: pedestrians may not be detected.

Maintenance

Clean the bumpers and door mirrors and

the field of vision of the cameras regularly.

When washing your vehicle at high pressure,

direct the spray from at least 30 cm away

from the radar, sensors and cameras.

Mats/Pedal trims

The use of mats or pedal trims not

approved by PEUGEOT may interfere with

the operation of the speed limiter or cruise

control.

To avoid any risk of jamming the pedals:

– Ensure that the mat is secured correctly.

– Never fit one mat on top of another.

Units of speed

Ensure that the units of speed displayed

on the instrument panel (mph or km/h) are

those for the country you are driving in.

If this is not the case, when the vehicle is

stationary, set the display to the required

units of speed so that it complies with what is

authorised locally.

In case of doubt, contact a PEUGEOT dealer

or a qualified workshop.

121

Driving

Steering wheel with

hands-on detection

(with Drive Assist 2.0)

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

The steering wheel is equipped with a hands-on

detection system to avoid distraction on the part

of the driver.

It is prohibited to cover or attach anything to the

steering wheel.

The driver must always check the

surroundings of the vehicle and

supervise the whole manoeuvre.

Any use of a system built into Drive Assist

2.0 must remain under the driver’s vigilance.

The system also detects the presence of

hands when using the Lane Positioning assist

system with Drive Assist Plus.

The system may suffer interference or

not work correctly if:

– the steering wheel is covered by some

protection.

– the driver wears thick gloves (e.g. ski

gloves).

In the event of improper detection of hands

on the steering wheel, Drive Assist 2.0 is

not activated or is deactivated after a few

seconds.

Installation of mechanical anti-theft

devices on the steering wheel is

prohibited - risk of damage!

Shortcuts for driving aids

The full list of available driving aids can be found

in the

Functions

tab.

Driving aids can be accessed directly to quickly

activate/deactivate them.

By default, driving aids are already stored in the

Shortcuts

tab (e.g. Stop & Start, Lane keeping

assist).

Other driving aids can be added or deleted from

this tab.

It is configured in the

ADAS>Functions

touch screen application.

► Press the button corresponding to the

driving assistance concerned:

• Full symbol: the function is added to the

Shortcuts

tab.

• Empty symbol: the function is deleted from

the

Shortcuts

tab.

► Check the modification in the

Shortcuts

tab.

► Press this button to access directly to the

Shortcuts

tab.

Multiple deactivation

It is possible to deactivate several driver

assistance functions simultaneously.

This is done in two steps:

– First of all, the selection of all the functions

that you want to deactivate.

– Secondly, the simultaneous deactivation of all

these functions.

Selection of functions

► Press this button on the dashboard to

display the

ADAS

tabs.

► Select the

Functions

tab.

► Press this button to display the list of

available functions.

► Select the functions that will be deactivated

by a long press on the

ADAS

button at each

start (e.g. Stop-Start, Lane Keeping Assist,

Automatic Braking System (Active Safety

Brake)).

122

Driving

► Press this button to return to the

previous page.

The functions to deactivate are saved in the

system.

Deactivation of these functions

► Press and hold this button on

the dashboard.

All previously selected functions are deactivated

until the vehicle is next restarted (confirmed by

an audible signal).

Road signs recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

This system displays the maximum speed

authorised locally on the instrument panel, using:

– Speed limit signs detected by the camera.

– Speed limit information from the on-board

navigation system’s mapping.

– Speed limit information from the connected

services.

– Signs indicating a shared traffic zone detected

by the camera.

Sign detected

Suggested speed

(calculated)

Entry into a shared

traffic zone

Example:

Without PEUGEOT

i-Connect

Advanced

10 mph or 20 km/h

(depending on

the units on the

instrument panel)

With PEUGEOT

i-Connect

Advanced

Display of the speed

in force in the country

you are driving in.

– Some supplementary traffic signs detected by

the camera.

Supplementary

traffic sign detected

Display of the

speed associated

with the

supplementary

traffic sign

Speed limit when

raining

Examples:

If the wiper control

stalk is in the

"intermittent wipe"

or "automatic wipe"

position (in order

to activate the rain

sensor):

68 mph (110 km/h)

(for example)

Speed limit when

towing

If an approved towing

device is fixed to the

vehicle:

56 mph (90 km/h)

(for example)

Speed limit

applicable over a

certain distance

Example:

43 mph (70 km/h)

(for example)

123

Driving

Supplementary

traffic sign detected

Display of the

speed associated

with the

supplementary

traffic sign

Speed limit for

vehicles with a

gross vehicle

weight or gross

train weight less

than 3.5 tonnes

56 mph (90 km/h)

(for example)

Speed limit in case

of snow

Example:

If the outside

temperature is below

3°C:

19 mph (30 km/h)

(for example)

with a "snowflake"

symbol

Speed limit at

certain times of the

day

Example:

19 mph (30 km/h)

(for example)

with a "clock" symbol

To get valid speed limit information, the

vehicle's current position is sent via the

telematics unit and is immediately deleted

after processing.

Tracking of the vehicle position is not possible

at any time.

This is not impacted by the privacy settings of

the connected services.

On-board navigation mapping should be

regularly updated in order to receive

accurate speed limit information from the

system.

The units for the speed limit (mph or

km/h) depend on the country you are

driving in.

This should be taken into account to ensure

you observe the speed limit.

For the system to work properly when

changing countries, the speed unit of the

instrument panel must match that of the

country you are driving in.

Country selection is only available for audio

systems without on-board navigation.

Automatic sign reading is a driving aid

system and does not always display the

correct speed limits.

The speed limit signs present on the road

always take priority over those displayed by

the system.

The system is designed to detect signs that

conform to the Vienna Convention on road

signs.

Specific speed limits, such as those for

heavy goods vehicles, are not displayed.

The display of the speed limit on the

instrument panel is updated when passing

a speed limit sign intended for cars (light

vehicles).

Information displayed on

the instrument panel

Detected speed limit indication

End of speed limit indication

The system is active but is not detecting speed

limit information.

124

Driving

On detecting speed limit information, the system

displays the value, accompanied by an audible

signal.

For a suggested maximum speed, when the

vehicle exceeds it, the speed is displayed and

flashes for 3 seconds.

If the vehicle continues to exceed it, the

speed is displayed and flashes for 8 seconds,

accompanied by an audible signal.

Operating limits

The system does not take account of reduced

speed limits, especially those imposed in the

following cases:

– Atmospheric pollution.

– Towing.

– Driving with a space-saver type spare wheel

or snow chains fitted.

– Tyre repaired using the temporary puncture

repair kit.

– Young drivers.

The system may not display the speed limit if it

does not detect a speed limit sign within a preset

period and in the following situations:

– Non-standard road signs.

– Road signs that are obstructed, damaged or

bent.

Settings

Deactivation/Activation

By default, the overspeed alert sound is

automatically activated at every engine start.

You can activate/deactivate the

overspeed alert and the speed limit

change sound.

Direct access to the

Shortcuts for driving aids

The system cannot be deactivated.

The speed limit change sound is saved

when the ignition is switched off.

In the event of the overspeed alert sound

deactivation, this warning lamp lights up a

few seconds on the instrument panel.

Country selection

The list of detected road signs can be updated

by selecting a specific country.

► In the

ADAS

touch screen application,

select

Functions

Road Signs

Country

setting

► In the

Select Country

list, select the desired

country.

The current country is displayed under

the function name in the settings screen.

The country selection is saved when the

ignition is switched off.

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

This warning lamp lights up on the

instrument panel with the message

Driving Assistance Sensor blind: Clean

sensor, see User Manual

" if the sensor is

masked.

This is a normal behavior, which does not

request the support of a qualified workshop.

In this case, stop the vehicle and verify if the

front camera is covered by dirt, mud, sand,

snow, ice or anything preventing the sensing.

The system is operational again after the

detection field has been cleaned.

Speed setting

recommendations

The driver can select the speed displayed by the

Road signs recognition

system as the speed

setting for the speed limiter, cruise control or

adaptive cruise control using the

button.

125

Driving

If rain is detected, the system proposes a speed

setting to the driver which is lower than the

speed read/sent from the mapping system in

order to adapt to the weather conditions (e.g. on

motorways, the proposed speed is 68 mph (110

km/h) instead of 81 mph (130 km/h).

For more information on the

Speed

limiter

Cruise control

Adaptive

cruise control

, refer to the corresponding

sections.

Speed setting advance recommendations

With Drive Assist 2.0 activated, the system

detects the next speed limit sign, displays it in

the background and proposes this new speed as

the speed setting.

Once memorised:

– If the speed setting is lower than the previous

one, the vehicle slows down to reach this new

speed when it gets to the sign.

– If the speed setting is higher than the previous

one, the vehicle speeds up to reach this new

speed when it passes the sign.

Steering-mounted controls

Select speed limiter mode

Select cruise control mode

Memorise the speed setting

Information displayed on the

instrument panel

Without speed setting advance

recommendation

With speed setting advance recommendation

Current speed setting

Speed memorisation prompt

Current speed limit indication

Next speed limit indication

Operating conditions

– Eligible roads: roads with separate

carriageways with prohibited access for

pedestrians and cyclists.

– Drive Assist 2.0 activated.

– Vehicle speed between 0 and 112 mph (0 and

180 km/h).

– Steering wheel properly held by the driver.

126

Driving

Memorising the speed setting

►

Switch on the speed limiter

1-LIMIT

or cruise

control

Information related to the speed limiter or cruise

control is displayed.

When a new speed setting is detected, the

system displays the value and “

OK?

" to suggest

saving it as a new speed setting.

If there is a difference of less than 3 mph

(5 km/h) between the speed setting and

the speed displayed by the Road signs

recognition, the "

OK?

“ symbol is not

displayed.

Depending on the road conditions, several

speeds may be displayed.

► Press

3-OK

to confirm the new speed setting.

The display then reverts to its previous state.

Extended Traffic Sign

Recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

This additional system recognises these road

signs and displays them on the instrument panel.

As you approach it, the symbol of the

corresponding sign is displayed on the

instrument panel.

The selected display mode must be "

Driving

The actual road signs always take priority

over those displayed by the system.

The signs must comply with the Vienna

Convention on road signs.

Activation/Deactivation

It is configured in the

ADAS

touch screen

application.

Speed limiter

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

This system prevents the vehicle from

exceeding the speed programmed by the

driver (speed setting).

The speed limiter is switched on manually.

The minimum speed setting is 19 mph (30 km/h).

The speed setting remains in the system

memory when the ignition is switched off.

Steering-mounted controls

Speed limiter selection

Switch on/pause the speed limiter at the

previously saved speed setting

Increase/Decrease the speed setting

Activate the speed limiter at the previously

saved speed setting

Use the speed suggested by the Road signs

recognition function

For more information on the

Road signs

recognition

function, refer to the corresponding

section.

127

Driving

Information displayed on

the instrument panel

Speed limiter mode selection indication

Speed limiter on (green)/pause (grey)

indication

Speed setting value

Speed suggested by the Road signs

recognition function (depending on version)

Switching on/Pausing

► Press

1-LIMIT

to select the speed limiter

mode; the function is paused (grey).

► If the limit speed setting is suitable (most

recent speed setting programmed in the system),

press

2-I I>

4-OK

to switch the speed limiter

on (green).

► Pressing

2-I I>

again temporarily pauses the

function.

When the speed setting remains below

the vehicle's speed for a prolonged

period of time, an audible warning is emitted.

Adjusting the speed setting

You do not have to switch the speed limiter on in

order to set the speed.

To change the speed setting using the vehicle’s

current speed:

► For steps of +/- 1 mph (1 km/h), make

successive short presses upwards/downwards

to increase/decrease.

► For steps of +/- 5 mph (5 km/h), press and

hold upwards/downwards on

to increase/

decrease.

When the function is activated, the limit

speed value can be changed using the speed

suggested by the Road signs recognition

function displayed on the instrument panel:

–

When passing the sign:

► Press

4-OK

to save the suggested speed.

This value is then immediately shown as the new

speed setting on the instrument panel.

–

After passing the sign:

► Press

4-OK

. The message "

OK?

" is

displayed to confirm the request to save.

► Press

4-OK

again to save the suggested

speed. The new speed setting value is displayed

on the instrument panel.

Temporarily exceeding the

speed setting

► Fully depress the accelerator pedal.

The speed limiter is temporarily deactivated and

the displayed speed setting flashes.

► Release the accelerator pedal to return to

below the speed setting.

When exceeding the speed is not due to the

driver's action (e.g. in case of a steep slope), an

audible signal is triggered immediately.

On a steep descent or in the event of

sharp acceleration, the speed limiter will

not be able to prevent the vehicle from

exceeding the speed setting.

If necessary, apply the brakes to control your

vehicle’s speed.

When the vehicle speed returns to the speed

setting level, the speed limiter operates again:

the speed setting display becomes fixed again.

Off

► Press

1-LIMIT

: the speed limiter information

display disappears.

Malfunction

In the event of a malfunction, dashes are

displayed flashing and then fixed instead of the

speed setting.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

128

Driving

Cruise control - Specific

recommendations

The cruise control function does not

guarantee compliance with the maximum

authorised speed and the safety distance

between vehicles, the driver remains

responsible for their driving.

In the interest of public safety, only use cruise

control if the traffic conditions enable vehicles

to drive at a steady speed and maintain an

adequate safety distance.

Remain vigilant while cruise control is

activated.

If you press and hold one of the

speed setting modification buttons, your

vehicle may change speed very abruptly.

When

descending a steep hill

, the cruise

control system cannot prevent the vehicle

from exceeding the set speed. Brake if

necessary to control the vehicle speed.

steep climbs

or when towing, the set

speed may not be reached or maintained.

Exceeding the programmed speed

setting

You can

temporarily

exceed the speed

setting by pressing the accelerator pedal (the

programmed speed flashes).

To return to the speed setting, release the

accelerator pedal (when the set speed is

reached again, the displayed speed stops

flashing).

Operating limits

Never use the system in the following

situations:

– In an urban area with the risk of

pedestrians crossing the road.

– In heavy traffic (except versions with the

Stop & Go function).

– On winding or steep roads.

– On slippery or flooded roads.

– In poor weather conditions.

– In the event of restricted visibility for the

driver.

– Driving on a speed circuit.

– Driving on a rolling road.

– When using a ‘space-saver’ type spare

wheel.

– When using snow chains or non-slip

covers.

Cruise control

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

and the

Specific recommendations on cruise

control

This system automatically maintains the

vehicle’s speed at the value programmed

by the driver (speed setting), without the use of

the accelerator pedal.

Cruise control is switched on manually.

It requires a minimum vehicle speed of 25 mph

(40 km/h).

With a manual gearbox, whichever gear is

engaged.

With an automatic gearbox, mode

or second

gear or higher in mode

must be engaged.

With a drive selector, mode

must be

engaged.

Cruise control remains active after

changing gear, regardless of the gearbox

type, on engines fitted with the Stop & Start

function.

Switching off the ignition cancels any

speed setting.

Steering-mounted controls

Cruise control selection

129

Driving

Switch on/pause cruise control at the

previously saved speed setting

Increase/Decrease the speed setting (if

cruise control activated)

Activation of cruise control in progress (if

cruise control deactivated)

Activation of cruise control in progress

Use the speed suggested by the Road signs

recognition

For more information on the

Road signs

recognition

function, refer to the corresponding

section.

Information displayed on

the instrument panel

Cruise control mode selection indication

Cruise control on (green)/pause (grey)

indication

Speed setting value

Speed suggested by the Road signs

recognition function (depending on version)

Switching on/pausing

► Press button

to select the cruise control

mode; the function is paused (grey).

► Press

upwards/downwards, or press

4-OK

to activate the cruise control and save a speed

setting as soon as the vehicle speed reaches the

desired level (green).

► Pressing button

2-I I>

temporarily pauses the

function.

► Pressing

2-I I>

4-OK

again will

reactivate cruise control (green).

Cruise control operation is also

temporarily interrupted (pause):

– by pressing the brake pedal.

– automatically, if the electronic stability

control (ESC) system is triggered.

– by shifting to neutral or engaging reverse

gear.

– by depressing the clutch pedal for more

than 5 seconds.

– by using the electric parking brake.

Modifying the speed setting

The cruise control must be active.

To change the speed setting using the vehicle’s

current speed:

► For steps of +/- 1 mph (1 km/h),

make successive short presses upwards/

downwards on

to increase/decrease.

► For steps of +/- 5 mph (5 km/h), press and

hold upwards/downwards on

to increase/

decrease.

Prolonged pressing and holding

upwards/downwards on

causes a very

rapid change in vehicle speed.

As a precaution, we recommend setting

a cruise speed fairly close to the current

speed of your vehicle, to avoid any sudden

acceleration or deceleration of the vehicle.

When the function is activated, the speed

setting value can be changed using the speed

suggested by the Road signs recognition

function displayed on the instrument panel:

–

When passing the sign:

► Press

4-OK

to save the suggested speed.

This value is then immediately shown as the new

speed setting on the instrument panel.

–

After passing the sign:

► Press

4-OK

. The message "

OK?

" is

displayed to confirm the request to save.

► Press

4-OK

again to save the suggested

speed. The new speed setting value is displayed

on the instrument panel.

Peugeot 308 (2024 year). Manual in english - page 4
