Peugeot 308 (2024 year). Manual in english

Ease of use and comfort

Stowing rings

Rigid boot floor, 2-position boot floor or

hinged boot carpet (Rechargeable hybrid or

Electric)

Storage well under the carpet

The stowing rings are designed to secure

luggage using different types of retaining

nets or suitable straps.

For more information, contact a PEUGEOT

dealer or a qualified workshop.

Load space cover (SW)

In the event of sudden deceleration,

objects placed on the load space cover

can turn into projectiles.

Reeling in

► Pull the handle towards you and downwards;

the load space cover will automatically roll up.

The moving part

can be folded against the

backrests of the rear seats.

Removal

► Compress the control

and lift the load

space cover on the right then on the left to

remove it.

Storage

A recess located underneath the boot floor can

be used to store the load space cover:

– diagonally with the rigid boot floor.

– crosswise with the 2-position boot floor.

► With the 2-position boot floor, first remove the

2 covers on each side of the housing.

Installation

► Position the left-hand end of the load space

cover roller in its location

behind the rear left

seat.

► Compress the roller control

and put the

roller in place in its location

on the right.

► Release the control to secure the load space

cover.

► Unroll it until it clips on the boot pillars.

Ease of use and comfort

High load retaining net (SW)

Hooked onto the special upper and lower fixings,

this removable net allows the use of the entire

loading volume up to the roof:

– behind the front seats (row 1) when the rear

seats are folded,

– behind the rear seats (row 2) when the load

space cover is removed.

It protects the occupants in case of

sudden braking.

Behind the front seats

► Fold down the rear bench seat

► Insert the ends of the bar, one after the other,

into the fixing points in the roof.

► Attach the net’s straps to the lower anchoring

points, located on the fixings of the rear bench

seat backrest.

► Pull on the straps to stretch the net.

Behind the rear bench seat

► Remove the load space cover roller.

► Insert the ends of the bar, one after the other,

into the fixing points in the roof.

► Attach the straps of the net to the lower rings,

located on each side trim of the boot.

► Pull on the straps to stretch the net.

2-position boot floor (SW)

(Depending on version)

This 2-

position floor allows the boot volume to

be optimised using the lateral stops located on

the sides:

– High position (

100 kg max

.): to obtain a flat

floor up to the front seats, when the rear seats

are folded down.

– Low position (

150 kg max

.): maximum boot

volume.

On certain versions, the adjustable boot

floor cannot be fitted in the low position.

Ease of use and comfort

To change the height:

► Lift and pull the floor towards you using its

central handle, then use the lateral stops to

move it.

► Push the floor all the way forwards to place it

in the desired position.

To keep it in the inclined position:

► From the high position, lift the floor towards

the load space cover.

► Engage it in the inclined position in the lateral

stops to secure it in this position.

12 V accessory socket

► To connect

a 12 V accessory (maximum

power: 120 W), lift the cover and plug in a

suitable adaptor.

► Switch on the ignition.

The connection of an electrical device

not approved by PEUGEOT, such as a

USB charger, may adversely affect the

operation of vehicle electrical systems,

causing faults such as poor radio reception or

interference with displays in the screens.

Boot lamp

It comes on automatically when the boot is

opened and goes off automatically when the

boot is closed.

The lighting time varies according to the

circumstances:

– When the ignition is off, approximately 10

minutes.

– In energy saving mode, approximately 30

seconds.

– With the engine running, unlimited.

Storage well

► Lift the rigid boot floor as far as possible or lift

the hinged boot carpet (depending on version) to

access the storage well.

► With the 2-position boot floor (SW), lift the

boot floor as far as possible or lift the cover at

the back of the boot to access one or other of the

storage wells.

The cover at the back of the boot is also

accessible from the second row seats if the

backrests of the rear bench seat are folded

down.

Depending on version, it includes:

– A hazard warning triangle.

– A temporary puncture repair kit with the tool

kit.

– A spare wheel with the tool kit.

– The traction battery charging cables

(Rechargeable hybrid or Electric).

The load space cover can also be stored here

(SW).

Lighting and visibility

Exterior lighting control

stalk

Main lighting

Automatic illumination of lamps/daytime

running lamps

Sidelamps only

Dipped or main beam headlamps

Headlamp dipping

► Pull the lighting control stalk to switch

between dipped and main beam headlamps.

In "

AUTO

" and sidelamps mode, pull the lighting

control stalk to switch the main beam headlamps

on directly ("headlamp flash").

Display

Illumination of the corresponding indicator

lamp on the instrument panel confirms that the

selected lighting is on.

A fault with a lamp is signalled by the

permanent illumination of this warning

lamp, accompanied by the display of a message

and an audible signal.

Rear foglamps

They only work if the dipped or main

beam headlamps are on.

► Rotate the ring forwards/backwards to turn

them on/off.

When the lighting is switched off automatically

AUTO

" position) the foglamps and the dipped

beam headlamps remain on.

Switching on the foglamps is prohibited

in clear weather or in rain, both day and

night. In these situations, the power of their

beams may dazzle other drivers. They must

only be used in fog or falling snow (rules may

vary depending on country).

Do not forget to switch off the foglamps when

they are no longer necessary.

Switching off of the lighting when the

ignition is switched off

When the ignition is switched off, all of the

lamps turn off immediately, except for the

dipped beam headlamps if automatic guide-

me-home lighting is activated.

Switching on the lamps after

switching off the ignition

To reactivate the lighting control, rotate the

ring to the "

AUTO

" position, then to the

desired position.

If the driver's door is opened, a temporary

audible signal warns the driver that the lamps

are on.

They will go off automatically after a period

of time that depends on the level of charge in

the battery (entering energy economy mode).

In some weather conditions (e.g. low

temperature or humidity), misting on the

internal surface of the glass of the headlamps

and rear lamps is normal, and will disappear

after the lamps have been on for a few

minutes.

Lighting and visibility

Never look too closely at the light beam

of LED technology lamps - risk of serious

eye injury!

Travelling abroad

Vehicles equipped with manual

headlamp beam height adjustment:

If planning to use your vehicle in a country

that drives on the other side of the road, the

dipped beam headlamps must be adjusted to

avoid dazzling oncoming drivers. Consult a

PEUGEOT dealer or a qualified workshop.

Daytime running lamps/

Sidelamps

These LED lamps at the front of the vehicle light

up automatically when the engine starts.

They perform the following functions:

– Daytime running lamps (lighting control stalk

at position

"AUTO

" with adequate ambient light).

– Sidelamps (lighting control stalk at position

AUTO

" with low ambient light or "Sidelamps

only" or "Dipped/main beam headlamps").

In daytime running lamps mode, the

light-emitting diodes are brighter.

Direction indicators

► Left or right: lower or raise the lighting control

stalk, beyond the point of resistance.

If you keep the direction indicators on for

more than 20 seconds, the volume of the

audible signal will increase if the speed is

above 50 mph (80 km/h).

Three flashes

► Press briefly upwards or downwards, without

going beyond the point of resistance; the

direction indicators will flash 3 times.

The brightness of the daytime running lamps is

reduced when the direction indicators are on.

Parking lamps

(Depending on version)

Vehicle side marking by lighting the sidelamps

on the traffic side only.

► Within one minute after switching off the

ignition, operate the lighting control stalk

upwards or downwards, depending on the side

of the traffic (e.g. when parking on the right, push

the lighting control stalk down to light up on the

left).

This is confirmed by an audible signal and the

lighting of the corresponding direction indicator

lamp on the instrument panel.

► To switch off the parking lamps, return the

lighting control stalk to the central position.

Headlamp beam height

adjustment

Manual headlamp

adjustment

To avoid dazzling other road users, the height

of the headlamp beams must be adjusted

according to the load in the vehicle.

Lighting and visibility

(Initial setting)

Driver only or driver + front passenger

5 people

5 people + load in the boot

Driver only + load in the boot

4 5 6

Not used

Automatic Peugeot Matrix

LED Technology 2.0

headlamp adjustment

This system automatically adjusts the height

of the headlamp beams according to different

parameters (e.g. vehicle load).

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

The system places the headlamp beams in the

lowest position.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Do not touch the Peugeot Matrix LED

Technology 2.0 headlamps - risk of

electrocution!

Automatic illumination of

lamps

With the lighting control stalk in the “

AUTO

”

position and if a low level of exterior brightness

is detected by the rain/sunshine sensor, the

sidelamps and dipped beam headlamps are

switched on automatically, without any action on

the part of the driver. They may also come on if

rain is detected, at the same time as automatic

operation of the windscreen wipers.

As soon as the brightness returns to a sufficient

level or after the windscreen wipers are switched

off, the lamps are switched off automatically.

Malfunction

In the event of a malfunction of the rain/

sunshine sensor, the vehicle’s lamps

come on and this warning lamp is displayed on

the instrument panel, accompanied by an

audible signal and/or the display of a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Do not cover the rain/sunshine sensor

located at the top centre of the

windscreen behind the interior rear view

mirror; the associated functions would no

longer be controlled.

In fog or snow, the rain/sunshine sensor

may detect sufficient light. For this

reason, the lighting will not come on

automatically.

The inner surface of the windscreen may

become misted up and affect the proper

operation of the rain/sunshine sensor.

In humid and cold weather, demist the

windscreen regularly.

Guide-me-home and

welcome lighting

Guide-me-home lighting

Automatic

With the ring of the lighting control stalk in the

AUTO

” position and when the light is poor, the

dipped beam headlamps come on automatically

when the ignition is switched off.

You can activate/deactivate and adjust

the duration of the guide-me-home

lighting in the

Settings > Vehicle

touch screen

application.

Manual

Lighting and visibility

► With the ignition off, pull the lighting control

stalk toward you ("headlamp flash") to activate/

deactivate the function.

Manual guide-me-home lighting goes off

automatically after a period of time.

Welcome lighting

When the vehicle is unlocked in low light

conditions and the "Automatic illumination of

headlamps" function is activated, this system

automatically switches on:

– On the outside, sidelamps, dipped beam

headlamps and door mirror spotlamps.

– Inside, courtesy lamps and footwell lighting.

Door mirror spotlamps

These spotlamps facilitate access to the vehicle

by lighting the ground near the front doors.

The spotlamps come on automatically:

– when the vehicle is unlocked.

– when a door is opened.

– when a request to locate the vehicle is

received from the remote control.

They also come on with the welcome lighting

and guide-me-home lighting functions.

They go off automatically after 30 seconds.

Automatic lighting

systems - General

recommendations

The automatic lighting systems use a detection

camera, located at the top of the windscreen.

Operating limits

The system may be disrupted or not work

correctly:

– When visibility conditions are poor

(e.g. snowfall, heavy rain).

– If the windscreen is dirty, misted-up or

masked (e.g. sticker) in front of the camera.

– If the vehicle is facing highly reflective signs

or safety barrier reflectors.

The system is not able to detect:

– Road users that do not have their own

lighting, such as pedestrians.

– Vehicles with hidden lighting (e.g. travelling

behind a safety barrier on the motorway).

– Vehicles at the top or bottom of a steep

slope, on winding roads, on crossroads.

Maintenance

Clean the windscreen regularly,

particularly the area in front of the camera.

The internal surface of the windscreen can

also become misted around the camera.

In humid and cold weather, demist the

windscreen regularly.

Do not allow snow to accumulate on the

bonnet or roof of the vehicle as this could

obstruct the camera.

Automatic headlamp

dipping

For more information, refer to the

General recommendations for

automatic lighting systems

With the ring of the lighting control stalk in the

AUTO

" position and the function activated on

the touch screen, this system automatically

switches between dipped and main beam

headlamps, according to lighting and traffic

conditions, using a camera located at the top of

the windscreen.

Lighting and visibility

This system is a driving aid.

The driver remains responsible for

the vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

and for compliance with driving and vehicle

regulations.

The system becomes operational when

the vehicle exceeds 16 mph (25 km/h).

When the speed falls below 9 mph (15 km/h),

the function is no longer operational.

Activation/Deactivation

It is configured in the

Settings > Vehicle

touch screen application.

The state of the system is stored when the

ignition is switched off.

When the system detects thick fog, it

temporarily deactivates the function.

Operation

If the ambient light level is very low and traffic

conditions permit:

– The main beam headlamps

come on automatically. These

indicator lamps light up on the instrument panel.

If the ambient light level is sufficient and/or the

traffic conditions do not allow the main beam

headlamps to be lit:

– The dipped beam headlamps

remain lit. These indicator lamps

light up on the instrument panel.

The function is deactivated if the foglamps

are switched on or if the system detects poor

visibility conditions (e.g. fog, heavy rain,

snowfall).

When the foglamps are switched off or when the

visibility conditions become favourable again, the

function is automatically reactivated.

This indicator lamp goes out when the

function is deactivated.

Pause

If the situation requires a change of headlamp

beam, the driver can take over at any time.

► Switch the headlamps manually between

dipped and main beam to pause the function.

If the "AUTO" and "Dipped beam" indicator

lamps were on, the system changes to main

beam.

If the "AUTO" and "Main beam" indicator lamps

were on, the system changes to dipped beam.

► To reactivate the function, once again switch

the headlamps manually between dipped and

main beam.

Malfunction

If a malfunction occurs with the system or

the camera, this warning lamp lights up

on the instrument panel, accompanied by an

audible signal and a message.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Peugeot Matrix LED

Technology 2.0

For more information, refer to the

General recommendations for

automatic lighting systems

Available only on versions equipped with Full

LED headlamps with Matrix Beam function.

This system automatically adapts the main

beam according to the driving conditions, so that

optimum illumination is maintained for the driver,

without causing a nuisance to other road users.

Lighting and visibility

The driver remains responsible for the

vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

and for compliance with driving and vehicle

regulations.

The system is active from 25 mph

(40 km/h) and deactivates below 12 mph

(20 km/h).

Activation/Deactivation

► Place the ring of the lighting control stalk in

the “

AUTO

” position.

This indicator lamp comes on in the

instrument panel.

It is configured in the

Settings > Vehicle

touch screen application.

The state of the system is stored when the

ignition is switched off.

When deactivated, the lighting system changes

to "Automatic illumination of lamps" mode.

It is recommended that you deactivate

the function in foggy or snowy conditions

or in case of heavy mist.

The function temporarily is deactivated when

the system detects thick fog or when the

foglamps are switched on manually. This is

signalled by the indicator lamp going off on

the instrument panel.

Operation

Using a camera, the system detects the driving

conditions (brightness, lights from oncoming or

followed vehicles, road turns) and adapts the

beams of the main headlamps accordingly.

The modules that make up the main beams

switch on and off gradually, segment by

segment, depending on the driving conditions

detected.

Nominal main beam lighting is restored as soon

as the vehicle is no longer detected by the

system.

If the system is selected but the display

on the instrument panel and the alerts are

not available, the indicator lamp comes on in

grey.

Followed vehicle

When approaching a vehicle from behind, only

those lamp segments directed at the followed

vehicle go off, thereby creating a "tunnel" so as

not to dazzle its driver.

Oncoming vehicle

When an oncoming vehicle approaches, only

those lamp segments directed at this vehicle

go off, thereby creating a "tunnel" during the

duration of the approach.

Entering an illuminated area

At the entrance to an illuminated area (e.g. a

town), the lamp segments are gradually switched

off from the outside to the inside of the vehicle to

switch to the dipped beams.

Exiting an illuminated area

The lamp segments gradually light up from the

inside to the outside of the vehicle to restore the

main beams.

Pause

If the situation requires a change of headlamp

beam, the driver can take over at any time.

► Switch the dipped/main beam headlamps

manually to pause the function.

The lighting system changes to "Automatic

illumination of lamps" mode.

Lighting and visibility

► To reactivate the function, manually switch

the dipped/main beam headlamps again.

Malfunction

In the first case, this warning lamp is

displayed on the instrument panel,

accompanied by a message if the sensor is

masked.

This is a normal behavior, which does not

request the support of a qualified workshop.

Stop the vehicle and verify if the front camera is

covered by dirt, mud, sand, snow, ice or anything

preventing the sensing.

The system is operational again after the

detection field has been cleaned.

In the second case, this warning lamp is

displayed on the instrument panel,

accompanied by an audible signal and a

message if a malfunction occurs with the

adaptive headlamp lighting or the camera.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Do not cover the rain/sunshine sensor

located at the top centre of the

windscreen behind the interior rear view

mirror; the associated functions would no

longer be controlled.

Wiper control stalk

Before operating the wipers in wintry

conditions, clear any snow, ice or frost

from the windscreen and around the wiper

arms and blades.

Do not operate the wipers on a dry

windscreen. In extremely hot or cold

weather, check that the wiper blades are not

stuck to the windscreen before operating the

wipers.

After using an automatic car wash, you

may temporarily notice abnormal noises

and poorer wiping performance. You do not

need to replace the wiper blades.

With intermittent wipers

With AUTO wiping

Windscreen wipers

► To select the wiping speed: raise or lower the

stalk to the desired position.

Fast wiping (heavy rain)

Normal wiping (moderate rain)

Intermittent wipers

Automatic wipers

Switching off

Manual

After the ignition has been switched off,

the wipers may move slightly at the foot

of the windscreen.

Lighting and visibility

In position

, the wiping frequency is

automatically reduced when the speed of

the vehicle drops below 3 mph (5 km/h).

When the speed is above 6 mph (10 km/h)

again, the wiping frequency returns to the

original frequency (fast or normal).

Single wipe

If the wiper control stalk is:

► In the

INT

AUTO

position, pull the stalk

briefly towards you then release it.

► In the

position, press briefly on the stalk

then release it.

Pressing and holding triggers continuous wiping

at the normal wiping speed.

Windscreen wash

► Pull the wiper control stalk towards you and

hold.

A final wiping cycle is performed when

screenwashing ends.

The windscreen wash jets are

incorporated into the tip of each wiper

arm.

An additional jet is installed below the

midpoint of the arm on the driver's side.

Screenwash fluid is sprayed along the length

of the wiper blade. This improves visibility and

reduces screenwash fluid consumption.

With automatic air conditioning, any

action on the screenwash control results

in temporary closure of the air intake to

protect the passenger compartment from any

odour.

To avoid damaging the wiper blades, do

not operate the screenwash if the

screenwash reservoir is empty.

Only operate the screenwash if there is no

risk of the fluid freezing on the windscreen

and hindering visibility. During the winter

period, use "very cold climate" rated products.

Never top up with water.

Rear wiper

► Turn the ring to align the desired symbol with

the marking.

Off

Intermittent wiping

Screenwash-wipe

If the ignition has been switched off with

the rear wiper active, operate the ring to

reactivate wiping when the ignition is switched

on again (unless the ignition was off for less

than 1 minute).

The first rotation of the ring to the screenwash

position triggers a single wipe. If the ring is

then left in the intermittent wiping position, the

rear wiper adopts a wiping speed dependent

on that of the windscreen wipers and the

speed of the vehicle.

Reverse

When reverse gear is engaged, the rear wiper

will come into operation automatically if the front

windscreen wipers are operating.

It is configured in the

Settings > Vehicle

touch screen application.

In the event of accumulation of snow or

hard frost or if a bicycle carrier is fitted to

a towing system, deactivate the automatic

rear wiper via the

Settings > Vehicle

touch

screen application.

Rear screenwash

► Turn the ring as far as it will go and hold it in

position.

The screenwash and the wiper operate for as

long as the ring remains turned.

A final wiping cycle is performed when screen

washing ends.

Lighting and visibility

An additional jet is fitted above the number plate

to clean the reversing camera (depending on

version).

With reverse gear engaged, the washing

of the reversing camera is triggered by

clicking on this button in the right side menu of

the touch screen.

Front intermittent wiping

In Intermittent mode, the driver can adjust the

wiping frequency by turning the ring to one of the

5 available positions.

The first (upper) position corresponds to the

longest time interval between 2 wipes for light

rain.

The last (lower) position corresponds to the

shortest time interval between 2 wipes for heavy

rain.

A rotation of the ring from a higher position to a

lower position triggers a confirmation wiping.

After the ignition has been switched off

for more than 1 minute with the wiper

control stalk in the

INT

position, when

the ignition is switched on again:

– the system works as soon as the vehicle

exceeds 6 mph (10 km/h), if the outside

temperature is below +3°C.

– the system works immediately, if the

outside temperature is above +3°C.

Automatic windscreen

wipers

AUTO

mode, the front wipers work

automatically and adapt to the intensity of

precipitation depending on the sensitivity of the

sensor selected.

The rainfall detection function uses a rain/

sunshine sensor located at the top centre of the

windscreen, behind the rear view mirror.

In certain weather conditions (e.g. fog,

frost, snow, projections on salty roads),

the driver may have to return to manual

wiping.

Switching on/off

To switch on:

► Put the wiper control stalk in the

AUTO

position.

► Turn the ring to adjust the sensitivity of the

sensor.

A wiping cycle, accompanied by the display of

a message, confirms that the request has been

taken into account.

► To switch off, put the wiper control stalk in

another position or in the

position.

Adjusting the sensitivity

The first position (upper) corresponds to the

lowest sensitivity of the sensor.

The last position (lower) corresponds to the

highest sensitivity of the sensor.

The higher the sensitivity, the faster the system

reacts and increases the wiping frequency.

A rotation of the ring from a higher position to a

lower position triggers a confirmation wiping.

After the ignition has been switched off

for more than 1 minute with the wiper

control stalk in the

AUTO

position, when the

ignition is switched on again:

– the system works, depending on the

volume of rain detected, as soon as the

vehicle exceeds 6 mph (10 km/h), if the

outside temperature is below +3°C.

– the system works immediately, depending

on the volume of rain detected, if the outside

temperature is above +3°C.

Do not cover the rain/sunshine sensor.

When using an automatic car wash,

switch off the automatic wipers and the

ignition.

Lighting and visibility

In winter, wait until the windscreen is

completely clear of ice before activating the

automatic wipers.

Malfunction

If a fault occurs with the automatic wipers, the

wipers operate in intermittent mode.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Special position of the

windscreen wipers

This maintenance position is used while cleaning

or replacing the wiper blades. It can also be

useful, in wintry weather (ice, snow), to release

the wiper blades from the windscreen.

To maintain the effectiveness of the flat

wiper blades, it is advisable to:

– handle them with care.

– clean them regularly using soapy water.

– avoid using them to hold cardboard on the

windscreen.

– replace them at the first signs of wear.

Before removing a windscreen wiper blade

Operating the wiper control stalk immediately

after switching off the ignition will place the wiper

blades in a vertical position.

► Proceed with the desired operation or the

replacement of the wiper blades.

After refitting a windscreen wiper blade

► To return the wiper blades to their initial

position after the operation, switch on the ignition

and operate the wiper control stalk.

Changing a wiper blade

Removing/Refitting at the front

► Carry out these wiper blade replacement

operations from the driver's side.

► Starting with the wiper blade farthest from

you, hold each arm by the rigid section and raise

it as far as possible.

Take care not to hold the arms at the jet

locations.

Do not touch the wiper blades - risk of

irreparable deformation.

Do not release them while moving them. Risk

of damaging the windscreen!

► Clean the windscreen using screenwash

fluid.

Do not apply "Rain X" type water-

repellent products.

Lighting and visibility

► Unclip the worn wiper blade closest to you

and remove it.

► Install the new wiper blade and clip it to the

arm.

► Repeat the procedure for the other wiper

blade.

► Starting with the wiper blade closest to you,

once again hold each arm by the rigid section,

then guide it carefully onto the windscreen.

Removing/refitting at the rear

► Hold the arm by the rigid section and raise it

as far as possible.

► Clean the rear screen using screenwash

fluid.

► Identify the position of the arm on which the

wiper blade is attached.

► Unclip the worn wiper blade by pulling it

towards the rear screen and remove it.

► Install the new wiper blade in the same

position of the arm and clip it into position.

► Once again hold the arm by the rigid section,

then guide it carefully onto the rear screen.

Take care not to use an incorrect position

during fitting - risk of damage!

Safety

General safety

recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

Depending on country regulations,

certain safety equipment may be

mandatory: high visibility safety vests,

warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories

The fitting of electrical equipment or

accessories not approved by PEUGEOT may

cause excessive current consumption and

faults and failures with the electrical system

of your vehicle. Contact a PEUGEOT dealer

for information on the range of approved

accessories.

As a safety measure, access to the

diagnostic socket

, used for the vehicle's

electronic systems, is reserved strictly for

PEUGEOT dealers or qualified workshops,

equipped with the special tools required (risk

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

serious accidents). The Manufacturer cannot

be held responsible if this advice is not

followed.

Any modification or adaptation not intended

or authorised by PEUGEOT or carried out

without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication

transmitter with an external aerial, you must

without fail contact a PEUGEOT dealer for

the specification of transmitters which can

be fitted (frequency, maximum power, aerial

position, specific installation requirements), in

line with the UN ECE Regulation 10.

Declarations of conformity for radio

equipment

The relevant certificates are available on the

brand website:

http://public.servicebox.peugeot.com/APddb/

Hazard warning lamps

► Pressing this button causes all the direction

indicators to flash.

They can work with the ignition switched off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on

the rate of deceleration, the hazard warning

lamps come on automatically. They switch off

automatically when you next accelerate.

Safety

They can be switched off by pressing the button.

Horn

► Press the central part of the steering wheel.

Pedestrian horn (Hybrid,

Rechargeable hybrid or

Electric)

This system alerts pedestrians that the vehicle

is approaching (Electric), when driving in all-

electric (Hybrid) or in

Electric

driving mode

(Rechargeable hybrid).

The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** Depending on the geographic coverage provided by the "eCall (SOS)" and "ASSISTANCE" systems.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

This function cannot be deactivated.

Emergency or assistance

call

eCall (SOS)

ASSISTANCE

eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.

The eCall (SOS) system provides direct contact

to the emergency services and is fully built

into the vehicle. This contact is made either

automatically via the sensors built into the

vehicle, or by pressing button

According to the country of sale, the eCall (SOS)

system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

► To make an emergency call manually, press

button

for more than 2 seconds.

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.

The eCall (SOS) system immediately locates

your vehicle and puts you in contact with the

appropriate emergency services**.

► Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when

communication is established.

In the event that a serious accident is

detected by the sensors built into the

vehicle, such as the airbag control unit, an

emergency call is made automatically.

The eCall (SOS) system is a public

service of general interest and is

free-of-charge.

Operation of the system

– Upon switching on the ignition, the indicator

lamp lights up for a few seconds and then goes

out: the system is operating correctly.

Safety

– The indicator lamp flashes red: emergency

battery is flat. This will be recharged after a few

minutes' driving.

– The indicator lamp is fixed red: system

malfunction. The emergency and assistance call

services may not work.

– If the indicator lamp does not light up when

the ignition is turned on, this is also a system

malfunction.

If the problem persists, contact a qualified

workshop as soon as possible.

The malfunction of the system does not

prevent the vehicle from driving.

When an onboard system update is

being performed, the eCall (SOS)

function is not available.

Data processing

All processing of personal data by

the eCall (SOS) function complies with

the framework for protection of personal

information established by Regulation

2016/679 (General Data Protection

Regulation - GDPR) or by UK GDPR

(Data Protection, Privacy and Electronic

Communications) Regulations 2019 and

Directive 2002/58/EC of the European

Parliament and the Council, and in particular,

seeks to protect the vital interests of the data

subject, in accordance with Article 6 (1) d)

GDPR.

The processing of personal data is strictly

limited to the purpose of handling the eCall

(SOS) function used with the "112" single

European emergency call number.

The eCall (SOS) function is only able to

collect and process the following data

relating to the vehicle: vehicle identification

number, vehicle type (passenger vehicle or

light commercial vehicle), fuel type or power

source, three most recent locations and

direction of travel, number of passengers

and a timestamped log file of the automatic

activation of the system and its timestamp.

The recipients of the processed data are the

emergency call handling centres designated

by the relevant national authorities in the

territory in which they are located, enabling

priority routing and handling of calls to the

"112" emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until

a call is made. The system is not traceable

and is not continuously monitored in its

normal operating mode.

The data in the system's internal memory is

automatically and continuously erased. Only

the vehicle’s three most recent locations,

necessary for the normal functioning of the

system, are stored.

When an emergency call is triggered, the data

log is stored for no more than 13 hours.

Access to data

You have the right of access to data and

as appropriate to request the rectification,

erasure or restriction of processing of any

personal data not processed in accordance

with the provisions of GDPR. Third parties

to which data has been disclosed shall

be notified of any rectification, erasure or

restriction carried out in compliance with

the corresponding GDPR, unless it proves

impossible or involves a disproportionate

effort.

You also have the right to lodge a complaint

with the respective data protection

supervisory authority.

If you want to claim your above-mentioned

rights please contact us per email at:

privacyrights@stellantis.com.

For more information regarding our contact

details please take a look at our Privacy &

Cookies Policy on the brand's website.

Safety

ASSISTANCE

► If the vehicle breaks down, press button

for more than 2 seconds to request assistance

(confirmed by a voice message*).

► Pressing again immediately cancels the

request.

Privacy mode allows you to manage the

level of sharing (data and/or location)

between your vehicle and PEUGEOT.

It can be configured in the

Settings

touch

screen application.

If you purchased your vehicle outside the

PEUGEOT dealer network, you are

invited to have a dealer check the

configuration of these services and, if desired,

modify it as required. In a multilingual country,

services can be configured to use the official

national language of your choice.

For technical reasons and in particular to

improve the quality of telematics services

provided to customers, the Manufacturer

reserves the right to carry out updates to the

vehicle's on-board telematics system at any

time.

* Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems and the official national language chosen by the owner of the

vehicle.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

During an update to the vehicle's

on-board telematics system, the

ASSISTANCE system will be unavailable.

If you benefit from the Peugeot Connect

Packs offer with the SOS and Assistance

Pack included, there are additional services

available to you in your personal space, via

the website for your country.

For information about the SOS and

Assistance Pack, please refer to the general

conditions for these services.

Event Data Recording

system

(Depending on country of sale)

This vehicle is fitted with an accident data

recording system, also called Event Data

Recorder (EDR).

This system gathers and records certain vehicle

data over a short period (a few seconds) before,

during and after an event such as an accident or

collision.

In order to gain a better understanding of the

circumstances surrounding the event, this

system records how the vehicle’s various

systems are operating at the time of the event,

including:

– Any deployment of a restraint system

(e.g. airbag, seat belt).

– The status of the seat belts of all the

occupants (fastened/unfastened).

– The contact or intensity of pressure exerted on

the pedal(s) engaged by the driver.

– The speed of the vehicle.

– The status of some driving and manoeuvring

aids systems.

The following are not recorded by the system:

– Data on normal driving conditions, in other

words data not directly related to the event.

– Personal data on the driver and any other

occupants.

– The geographical location of the vehicle at the

time of the event.

The reading of data recorded by the system

requires the following:

– Access to the interior of the vehicle or to the

system.

And

– Special equipment that can be purchased from

the manufacturer BOSCH (www.BoschCDRTool.

com).

Aside from the vehicle Manufacturer, other

parties such as law enforcement agencies may

access this data in order to analyse the event.

Safety

Electronic stability control

(ESC)

The electronic stability control programme

includes the following systems:

– Anti-lock braking system (ABS) and Electronic

brake force distribution (EBFD).

– Emergency braking assistance (EBA).

– Post Collision Safety Brake (PCSB).

– Anti-slip regulation (ASR).

– Dynamic stability control (DSC).

– Trailer stability assist (TSA).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

ABS prevents wheel locking in the event of

emergency braking.

Electronic brake force distribution (EBFD)

manages overall braking pressure on each

individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

Normal operation of the ABS may make

itself felt by slight vibrations of the brake

pedal.

The fixed illumination of this warning lamp

signals that there is a fault with the ABS.

The vehicle retains conventional braking. Drive

carefully at a moderate speed.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

This warning lamp, when lit together with

the

STOP

and ABS warning lamps,

accompanied by a message and an audible

signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a PEUGEOT dealer or a qualified

workshop.

When changing wheels (tyres and rims),

ensure that these are approved for your

vehicle.

After an impact

Have it checked by a PEUGEOT dealer

or a qualified workshop.

Emergency braking

assistance (EBA)

This system reduces the emergency stopping

distance, by optimising the braking pressure.

It is triggered in relation to the speed at which

the brake pedal is depressed. The effect of this

is a reduction in the resistance of the pedal and

an increase in braking efficiency.

Post Collision Safety Brake

(PCSB)

If an accident is detected, the vehicle initiates

automatic post collision braking. The goal of this

system is to reduce the risk of further collisions if

the driver does not react.

The system is not operational if the capability of

the vehicle to trigger and execute the automatic

post collision braking is not available, as it can

occur in destructive accidents or in other specific

accident scenarios.

It is possible to override the automatic braking by

pressing the brake pedal or accelerator pedal.

Operating conditions

The system operates, if the following conditions

are met:

– Airbags or pyrotechnic seat belt pretensioners

have been deployed by the collision.

– Braking systems and electric functions remain

continuously operational during and after

collision.

– Driver has not depressed the brake or

accelerator pedal.

Malfunction

In the event of a

malfunction, one of these

warning lamps will come on fixed on the

instrument panel, accompanied by the Service

warning lamp, the display of a message and an

audible signal.

Safety

Have it checked by a PEUGEOT dealer or a

qualified workshop.

Anti-slip regulation (ASR)/

Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying

the brakes on the driving wheels to avoid one

or more wheels spinning. It also enhances the

vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the

dynamic stability control system automatically

uses engine braking and the brakes on one or

more wheels to return the vehicle to the desired

path, within the limits of the laws of physics.

These systems are activated automatically every

time the vehicle is started.

These systems are activated in the event

of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (e.g. moving a vehicle

that is bogged down in mud, stuck in snow, on

loose soil), it may prove useful to deactivate the

DSC/ASR systems, so that the wheels can move

freely and regain grip.

Reactivate the system as soon as the level of

grip permits.

The ASR system is deactivated/

reactivated in the

ADAS

touch screen

application.

Deactivation/reactivation of the ASR

system is indicated by this indicator lamp

on the instrument panel coming on/going out and

the display of a message.

The ASR system is automatically reactivated

every time the ignition is switched off or at

speeds over 31 mph (50 km/h)

Reactivation is manual below 31 mph (50 km/h).

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a PEUGEOT dealer or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage

the driver to take extra risks or drive at high

speed.

It is in conditions of reduced grip (rain, snow,

ice) that the risk of loss of grip increases. It

is therefore important for your safety to keep

these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends

on compliance with the manufacturer's

recommendations relating to the wheels

(tyres and rims), braking and electronic

components, as well as the assembly and

repair procedures provided by PEUGEOT

dealers.

In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information

Identification markings

, refer to the

corresponding section.

Trailer stability assist (TSA)

When towing, this system reduces the risk of the

vehicle or trailer snaking.

Operation

The system is activated automatically when the

ignition is switched on.

The electronic stability control system (ESC)

must not have any faults.

The vehicle speed must be between 37 and 99

mph (60 and 160 km/h).

If the system detects that the trailer is

snaking, it applies the brakes to stabilise

the trailer and reduces engine power, if

necessary, to slow the vehicle (indicated by the

flashing of this warning lamp on the instrument

panel and the brake lamps coming on).

Safety

For more information on weights and towed

loads, refer to the

Engine technical data

and towed loads

section or your vehicle’s

registration certificate.

To ensure safe driving with a

Towing device

refer to the corresponding section.

Malfunction

If a fault occurs, this warning lamp lights

up on the instrument panel, accompanied

by a message and an audible signal.

To continue towing a trailer, reduce speed and

drive carefully!

Have it checked by a PEUGEOT dealer or a

qualified workshop.

The trailer stability control system

provides an extra safety feature under

normal driving conditions, when following the

recommendations for use of trailers and

current legislation in force in your country. It

must not encourage the driver to take extra

risks, such as using a trailer in unsuitable

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

tyres, faulty braking system) or driving at

excessive speed.

In certain cases, the system may not detect

trailer snaking, particularly with a light trailer.

When driving on slippery or poor surfaces, the

system may not be able to prevent sudden

trailer snaking.

Seat belts

Inertia reel

The seat belts are equipped with an inertia

reel which allows the strap length to adjust

automatically to the shape of the user. The seat

belt returns to its storage automatically when it

is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a

collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a

frontal or side impact.

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Progressive force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, taking their

stature into account, thus improving their

protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic

device may trigger before and independently

of airbag deployment. Deployment of the

pretensioners is accompanied by a slight

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

cartridge incorporated in the system.

In all cases, the airbag warning lamp comes

on.

Following an impact, have the seat belt

system checked, and if necessary replaced,

by a PEUGEOT dealer or a qualified

workshop.

Front seat belts

The front seat belts are fitted with a pyrotechnic

pretensioning system and a progressive force

limiting system.

Rear seat belts

Each of the rear seats has a three-point seat belt

with inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

Safety

Fastening

► Pull the strap, then insert the tongue into the

buckle.

► Check that the seat belt is fastened correctly

by pulling on the strap.

Unfastening

► Press the red button on the buckle.

► Guide the seat belt as it is reeled in.

Seat belt not fastened/

unfastened alerts

Front left seat belt warning lamp

Front right seat belt warning lamp

Rear left seat belt warning lamp

Rear centre seat belt warning lamp

Rear right seat belt warning lamp

Not fastened/unfastened warning lamp

It comes on in red on both the instrument panel

and on the seat belts warning lamps display as

soon as the system detects that a seat belt is not

fastened or has been unfastened.

Front seat belt not fastened alert

When the ignition is switched on, if the

driver or front passenger has not fastened their

seat belt, the corresponding warning lamp (

) comes on in red. At a speed greater than 12

mph (20 km/h), the warning lamp flashes red,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on fixed in red until the seat belt is

fastened.

Rear seat belt not fastened alert

When the ignition is switched on, if one of

the rear passengers has not fastened their seat

belt, the corresponding warning lamp (

)

comes on in red for 1 minute.

Seat belt unfastened alert

After the ignition is switched on, if the

driver or a passenger unfastens their seat belt,

the corresponding warning lamp (

) comes on in red. At a speed greater than

12 mph (20 km/h), the warning lamp flashes,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on until the seat belt has been

fastened again.

With the ignition on, if the driver or a

passenger fastens their seat belt, the

corresponding warning lamp (

)

comes on in green on the display.

With the ignition on, if one of the front or

rear passenger seats is detected as being

unoccupied, the corresponding warning lamp (

) comes on in grey on the display.

When there are no longer any not fastened/

unfastened alerts, the green or grey warning

lamps remain on for around 30 seconds, then

go off.

Advice

The driver must ensure that passengers

use the seat belts correctly and that they

are all fastened before setting off.

Wherever seated in the vehicle, you must

always fasten the seat belt, even for short

journeys.

Do not invert the seat belt buckles, as they

will not fulfil their role properly.

To ensure the proper functioning of the belt

buckles, make sure that there are no foreign

bodies present (e.g. a coin) before fastening.

Before and after use, ensure that the seat belt

is reeled in correctly.

After folding or moving a seat or rear bench

seat, ensure that the seat belt is positioned

and reeled in correctly.

Installation

The lower part of the strap must be

positioned as low as possible over the pelvis.

The upper part must be positioned in the

hollow of the shoulder.

At the front, adjusting the position of the

seat belt may require the seat height to be

adjusted.

In order to be effective, a seat belt must:

Safety

– be tightened as close to the body as

possible.

– be pulled in front of you with a smooth

movement, checking that it is not twisted.

– only be used to secure one person.

– not show signs of tearing or fraying.

– not be changed or modified, in order to

avoid affecting its performance.

Recommendations for children

Use a suitable child seat if the passenger

is less than 12 years old or shorter than 1.5

metres.

Never use the same seat belt to secure more

than one child.

Never carry a child on your lap.

For more information on

Child seats

, refer to

the corresponding section.

Maintenance

In accordance with current safety

regulations, for all work on your vehicle's

seat belts, contact a qualified workshop with

the skills and equipment needed, which a

PEUGEOT dealer is able to provide.

Have the seat belts checked regularly by a

PEUGEOT dealer or a qualified workshop,

particularly if the straps show signs of

damage.

Clean the seat belt straps with soapy water or

a textile cleaning product, sold by PEUGEOT

dealers.

Airbags

General information

This system is designed to improve the safety

of the occupants of the front seats and the rear

outer seats in the event of a violent collision. The

airbags supplement the action of the seat belts

equipped with a force limiting system.

Electronic detectors record and analyse the

front and side impacts sustained in the impact

detection zones:

– In the event of violent impact, the airbags

deploy instantly and help better protect the

occupants of the vehicle; immediately after the

impact, the airbags deflate rapidly in order not

to hinder the visibility or the possible exit of the

occupants.

– In the event of a slight impact, a rear impact

and under certain rollover conditions, the airbags

may not deploy; only the seat belt helps to

protect you in these situations.

The seriousness of the impact depends on the

nature of the obstacle and the speed of the

vehicle at the moment of collision.

The airbags do not operate when the

ignition is switched off.

This equipment will only deploy once. If a

second impact occurs (during the same or a

subsequent accident), the airbag will not be

deployed again.

Impact detection zones

Front impact zone

Side impact zone

When one or more airbags are deployed,

the detonation of the pyrotechnic charge

incorporated in the system makes a noise and

releases a small quantity of smoke.

This smoke is not harmful, but sensitive

individuals may experience irritation.

The detonation noise associated with the

deployment of one or more airbags may result

in a slight loss of hearing for a short time.

Safety

Front airbags

This system protects the driver and front

passenger in the event of a serious front impact,

limiting the risk of head and chest injury.

The driver's airbag is fitted in the centre of the

steering wheel; the front passenger airbag is

fitted in the dashboard above the glove box.

Deployment

They are deployed, except for the front

passenger airbag if it is deactivated*, in the

event of a violent front impact applied to all or

part of front impact zone

The front airbag inflates between the chest and

head of the front occupant of the vehicle and

the steering wheel, on the driver's side, and the

dashboard, on the passenger's side, to cushion

their forward movement.

* For more information on Deactivating the front passenger airbag, refer to the corresponding section.

Lateral airbags

This system protects the driver and front

passenger in the event of a serious side impact,

limiting the risk of injury to the chest, between

the hip and the shoulder.

Each lateral airbag is fitted in the seat backrest

frame, on the door side.

Deployment

The lateral airbags are deployed on one side in

the event of a serious side impact applied to all

or part of the side impact zone

The lateral airbag inflates between the chest of

the vehicle's occupant and the corresponding

door panel.

Curtain airbags

This system helps provide greater protection for

the driver and passengers (with the exception

of the rear centre passenger) in the event of a

serious side impact, in order to limit the risk of

injury to the side of the head.

Each curtain airbag is built into the pillars and

the upper passenger compartment area.

Deployment

It deploys simultaneously with the corresponding

lateral airbag in the event of a serious side

impact applied to all or part of the side impact

zone

The curtain airbag inflates between the front

and rear occupants of the vehicle and the

corresponding windows.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel. Contact a PEUGEOT

dealer or a qualified workshop to have the

system checked.

The airbags may not be deployed in the event of

a serious impact.

Safety

In the event of a minor impact or bump at

the side of the vehicle or if the vehicle

rolls over, the airbags may not be deployed.

In the event of a rear or front collision, none of

the lateral airbags are deployed.

Advice

For the airbags to be fully effective,

observe the safety recommendations

below.

Adopt a normal and upright sitting position.

Fasten your seat belt and position it correctly.

Do not place anything between the occupants

and the airbags (e.g. child, animal, object), do

not fix or attach anything near or in the path of

the airbags, as this could cause injuries when

they are deployed.

Never modify the original definition of the

vehicle, particularly in the area directly around

the airbags.

Even if all of the precautions mentioned are

observed, a risk of injury or of minor burns to

the head, chest or arms cannot be ruled out

when an airbag is deployed. The bag inflates

almost instantly (within a few milliseconds)

then deflates within the same time,

discharging the hot gas via openings provided

for this purpose.

After an accident or if the vehicle has been

stolen, have the airbag systems checked.

All work must be carried out only by a

PEUGEOT dealer or a qualified workshop

Front airbags

Do not drive holding the steering wheel

by its spokes or resting your hands on the

centre part of the wheel.

Passengers must not place their feet on the

dashboard.

Do not smoke as deployment of the airbags

can cause burns or the risk of injury from a

cigarette or pipe.

Never remove or pierce the steering wheel or

hit it violently.

Do not fix or attach anything to the steering

wheel or dashboard, as this could cause

injuries when the airbags are deployed.

Lateral airbags

Use only approved seat covers

compatible with the deployment of these

airbags. For information on the range of seat

covers suitable for your vehicle, contact a

PEUGEOT dealer.

Do not fix or attach anything to the seat

backrests (e.g. clothing) as this could cause

injuries to the chest or arm when the airbag is

deployed.

Do not sit with the upper part of the body any

nearer to the door than necessary.

The vehicle's front door panels include side

impact sensors.

A damaged door or any unauthorised or

incorrectly executed work (modification or

repair) on the front doors or their interior trim

could compromise the operation of these

sensors - risk of malfunction of the lateral

airbags!

All work must be carried out only by a

PEUGEOT dealer or a qualified workshop

Curtain airbags

Do not fix or attach anything to the roof,

as this could cause head injuries when the

curtain airbag is deployed.

Do not remove the grab handles installed on

the roof.

Child seats

The regulations on carrying children are

specific to each country. Refer to the

legislation in force in your country.

For maximum safety, please observe the

following recommendations:

– In accordance with European regulations,

all children under the age of 12 or less than

1.5 metres tall must travel in approved child

seats suited to their size or weight

, on seats

fitted with a seat belt or ISOFIX mountings.

–

Statistically, the safest seats in your

vehicle for carrying children are the rear

seats.

–

Children ageing less than 15 months must

travel in the "rearward facing" position,

whether in the front or rear of the vehicle.

Safety

It is recommended

that children travel

on the

rear seats

of the vehicle:

– "

rearward facing

" up to the age of 3.

– "

forward facing

" over the age of 3.

Make sure that the seat belt is correctly

positioned and tightened.

For child seats with a support leg, ensure that

the support leg is in firm and steady contact

with the floor.

An incorrectly installed child seat in a

vehicle compromises the child's safety in

the event of an accident.

Ensure that there is no seat belt or seat belt

buckle under the child seat, as this could

destabilise it.

Remember to fasten the seat belts or the

child seat harness keeping the slack relative

to the child's body to a minimum, even for

short journeys.

When installing a child seat using the seat

belt, ensure that the seat belt is tightened

correctly on the child seat and that it secures

the child seat firmly on the vehicle seat. If

the passenger seat is adjustable, move it

forwards if necessary.

Remove the head restraint before

installing a child seat with a backrest on a

passenger seat.

Ensure that the head restraint is stored or

attached securely to prevent it from being

thrown around the vehicle in the event of

sharp braking. Refit the head restraint once

the child seat has been removed.

Installing a booster seat

The chest part of the seat belt must be

positioned on the child's shoulder without

touching the neck.

Ensure that the lap part of the seat belt

passes correctly over the child's thighs.

Use a booster seat with a backrest, equipped

with a belt guide at shoulder level.

Additional protections

To prevent accidental opening of the

doors and rear windows, use the "Child lock".

Take care not to open the rear windows by

more than one third.

To protect young children from the sun's rays,

fit side blinds on the rear windows.

As a safety measure, do not leave:

– A child alone and unsupervised inside a

vehicle.

– A child or an animal in a vehicle which is

exposed to the sun, with the windows closed.

– The keys within reach of children inside the

vehicle.

Child seat at the rear

Forward-facing or rearward-facing

► Move the vehicle's front seat forward and

straighten the backrest so that the legs of the

child in the forward-facing or rearward-facing

child seat itself do not touch the vehicle's front

seat.

► Check that the backrest of the forward-facing

child seat is as close as possible to the backrest

of the vehicle's rear seat, and ideally in contact

with it.

Centre rear seat

A child seat with a support leg must never be

installed on the

centre rear passenger seat

Safety

Child seat at the front

► Adjust the front passenger seat to the

highest

and

fully back longitudinal position

with the backrest straightened

"Forward facing"

You must leave the front passenger

airbag active.

"Rearward facing"

The front passenger airbag must be

deactivated before installing a rearward

facing child seat. Otherwise,

the child risks

being seriously injured or killed if the

airbag is deployed

Warning label - Front passenger airbag

You must comply with the following instruction,

as reminded by the warning label on both sides

of the passenger sun visor:

NEVER use a rearward facing child restraint

on a seat protected by an ACTIVE AIRBAG in

front of it, DEATH or SERIOUS INJURY to the

CHILD can occur.

Deactivating the front

passenger airbag

Passenger airbag OFF

To ensure the safety of the child, the front

passenger airbag MUST be deactivated

when a "rearward facing" child seat is

installed on the front passenger seat.

Otherwise, the child risks being seriously

injured or killed in the event of deployment of

the airbag.

Vehicles not equipped with a

deactivation/reactivation control

Installing a "rearward facing" child seat on

the front passenger seat is strictly prohibited

- risk of death or serious injury in the event of

airbag deployment!

Deactivating/Reactivating the front

passenger airbag

For vehicles on which it is fitted, the switch is

located on the side of the dashboard.

Safety

With the ignition off:

► To deactivate the airbag, turn the key in the

switch to the "

OFF

" position.

► To reactivate it, turn the key to the "

position.

When the ignition is switched on:

This warning lamp comes on and remains

lit to signal deactivation.

This warning lamp comes on for about

1 minute to signal activation.

"ISOFIX" mountings

The seats shown below are fitted with ISOFIX

compliant mountings:

The mountings comprise three rings for each

seat, indicated by a marking:

– Two rings

, located between the vehicle seat

backrest and cushion.

These rings are located behind zips.

The 2 latches on

ISOFIX child seats

are

secured to them.

– One ring

, located behind the seat, called the

TOP TETHER

, for attaching seats fitted with an

upper strap.

This system prevents the child seat from tipping

forwards in the event of a front impact.

This ISOFIX mounting system provides fast,

reliable and safe fitting of the child seat in the

vehicle.

To secure the child seat to the

TOP TETHER

► Remove and stow the head restraint before

installing the child seat on this seat (refit it once

the child seat has been removed).

► Pass the strap of the child seat behind the

seat backrest, centring it between the openings

for the head restraint rods.

► Secure the upper strap hook to ring

► Tighten the upper strap.

When fitting an ISOFIX child seat to the

left-hand rear seat of the bench seat,

before fitting the seat, first move the centre

rear seat belt towards the middle of the

vehicle, so as to avoid the seat interfering

with the operation of the seat belt.

Safety

An incorrectly installed child seat in a

vehicle compromises the child's safety in

the event of an accident.

Strictly observe the fitting instructions

provided in the user guide supplied with the

child seat.

For information about the options for

fitting ISOFIX child seats in your vehicle,

refer to the summary table.

i-Size child seats

i-Size child seats have two latches that are

anchored to the two rings

These i-Size child seats also have:

– either an upper strap that is attached to ring

– or a support leg that rests on the vehicle

floor, compatible with the approved i-Size seat

position.

Their role is to prevent the child seat from tipping

forward in the event of a collision.

For more information on the

ISOFIX mountings

refer to the corresponding section.

Recommended child seats

"RÖMER Baby-Safe 3 i-Size"

Size: 40 - 83 cm

From birth to 15 months

(up to 13 kg)

With or without its ISOFIX base.

Suitable for "rearward facing" installation only.

"RÖMER TriFix 2 i-Size"

Size: 76 - 105 cm

From 15 months to 4 years

(from 9 to 22 kg)

Installed with ISOFIX and Top Tether

mountings.

Suitable for "forward facing" installation only.

"RÖMER KidFix i-Size"

Size: 100 - 150 cm

From 3.5 to 12 years

(from 15 to 36 kg)

Can be installed with or without ISOFIX

mountings.

The child is restrained by the seat belt.

"GRACO Booster"

Size: over 135 cm

(from 22 to 36 kg)

The child is restrained by the seat belt.

Please follow the child restraint

manufacturers' instructions for installing

the appropriate child restraint in the vehicle.

For the semi-universal or vehicle-specific

child restraint (ISOFIX or belt-type child

Safety

restraint), refer to the list of vehicles provided

in the child restraint user manual.

Ensure that the installation location of the

child restraint system inside the vehicle is

correct.

Refer to the summary table for the installation

of child seats.

Installing universal, ISOFIX and i-Size child seats

In compliance with European regulations, this table indicates the options for installing child seats secured using the seat belt and universally approved

(a)

as well as the largest

ISOFIX

and

i-Size

child seats for the seat positions fitted with

ISOFIX

anchorage points in the vehicle.

Seat number

Front seats

(d)

Rear seats

(d)

Front passenger airbag

Deactivated "OFF"

(b)

Activated "ON"

(c)

Position compatible with a

universal (a)

child seat

yes

(f) (i)

yes

(f) (j)

yes

(e)

yes

Position compatible with an

i-Size

child

seat

yes

Position equipped with a

Top Tether

hook

yes

Carrycot

" type child seat

Safety

Seat number

Front seats

(d)

Rear seats

(d)

Front passenger airbag

Deactivated "OFF"

(b)

Activated "ON"

(c)

"Rearward facing"

ISOFIX

child seat

(g) (h)

"Forward facing"

ISOFIX

child seat

Child booster seat

Rules:

– A position that is

i-Size

compatible is also

compatible with

and

F2X

– A position that is

compatible is also

compatible with

and

– A position that is

compatible is also

compatible with

F2X

and

– A position that is

compatible is also

compatible with

(a)

Universal child seat: child seat that can be

installed in all vehicles using the seat belt.

(b)

To install a "

rearward facing

" child seat at

this seat position, the front passenger airbag

must be deactivated ("

OFF

").

(c)

Only a "

forward facing

" child seat is

authorised at this seat position with the front

passenger airbag activated ("

").

(d)

Depending on version, refer to the

legislation in force in your country before

installing a child in this seat position.

(e)

Never install a child seat with a support leg

on the centre rear seat.

(f)

For a seat with height adjustment, adjust

the seat to the highest position and move it

fully back.

(g)

Adjust the driver's seat to the highest

position.

(h)

Adjust the passenger seat to the

intermediate forward longitudinal position.

(i)

For a universal "

rearward facing

" and/or

forward facing

" (

) child seat in groups

(j)

For a universal "

forward facing

" (

) child

seat in groups

Safety

Key

Seat position where the installation of a

child seat is forbidden.

Front passenger airbag

deactivated

Front passenger airbag

activated

Seat position suitable for the installation

of a child seat secured using the seat belt

and

universally approved "rearward facing"

and/or "forward facing"

(

) for all sizes and

weight groups.

Seat position suitable for the installation

of a child seat secured using the seat belt

and

universally approved "forward facing"

(

) for groups

and

, or dedicated to

children between 76 and 150 cm in size only.

Seat position authorised for the

installation of an

i-Size

child seat.

Seat position not suitable for the

installation of a child seat with support

leg.

Presence of a

Top Tether

anchorage

point at the rear of the backrest,

authorising the installation of an

universal

ISOFIX child seat

"Rearward facing"

ISOFIX

child seat:

–

ISOFIX

child seat for a

baby

–

ISOFIX reduced size

child seat.

–

ISOFIX large size

child seat.

"Forward facing"

ISOFIX

child seat:

–

F2X

ISOFIX

child seat

for toddlers

–

ISOFIX reduced height

child seat.

–

ISOFIX full height

child seat.

Booster

child seat:

–

reduced width booster

seat.

–

full width booster

seat.

Seat position where the installation of an

ISOFIX

child seat is forbidden.

For seat adjustments, refer to the summary table

Installing universal, ISOFIX and i-Size child

seats

Manual child lock

The system prevents a rear door from being

opened using its interior handle.

The control is located on the edge of each rear

door (indicated by a marking on the bodywork).

Activation/Deactivation

► To activate, turn the built-in key fully:

• To the right on the left-hand rear door.

• To the left on the right-hand rear door.

► To deactivate, turn it in the opposite direction.

Peugeot 308 (2024 year). Manual in english - page 3
