Peugeot 3008 Dag (2010.5). Instruction

125

Height adjustment

Front seat belt not fastened/
unfastened warning lamp

Fastening

 Pull the strap, then insert the tongue

in the buckle.

 Check that the seat belt is fastened

correctly by pulling the strap.

 To adjust the anchorage point,

squeeze the control A and slide it

until you ﬁ nd a notch.

When  the  ignition  is  switched
on,  this  warning  lamp  comes
on  on  the  seat  belt  and  pas-
senger's  front  airbag  warning

lamps  display,  if  the  driver  and/or  the
front  passenger  has  not  fastened  their
seat belt.
From  approximately  12  mph  (20  km/h)

this warning lamp ﬂ ashes for two minutes

accompanied by an audible signal. Once
these  two  minutes  have  elapsed,  this
warning lamp remains on until the driver
and/or  the  front  passenger  fastens  their
seat belt.

  Unfastening
      Press the red button on the buckle.
     Guide the seat belt as it reels in.

SEAT BELTS

Front seat belts

The front seat belts are ﬁ tted with a pre-

tensioning and force limiting system.
This system improves safety in the front
seats in the event of a front or side im-
pact.  Depending  on  the  severity  of  the
impact,  the  pretensioning  system  in-
stantly  tightens  the  seat  belts  against
the body of the occupants.
The pretensioning seat belts are active
when the ignition is on.
The  force  limiter  reduces  the  pressure
of the seat belt on the chest of the occu-
pant, so improving their protection.

126

1. Front and/or rear seat belts not fas-

tened/unfastened warning lamp.

  2.   Front left seat belt warning lamp.
  3.   Front right seat belt warning lamp.
  4.   Rear right seat belt warning lamp.
  5.   Rear centre seat belt warning lamp.
  6.   Rear left seat belt warning lamp.

Seat belt not fastened/unfastened
warning lamps display

Rear seat belts

The rear seats are each ﬁ tted with a

three-point inertia reel seat belt with
force limiter (with the exception of the
centre rear seat).

Seat belt unfastened warning lamp

  This warning lamp comes on on
the  seat  belt  and  passenger's
front  airbag  warning  lamps  dis-
play, when one or more rear pas-
sengers unfasten their seat belt.

From approximately 12 mph (20 km/h),

this warning lamp ﬂ ashes for two minutes

accompanied by an audible signal. Once
these  two  minutes  have  elapsed,  this
warning lamp remains on until the one or
more  rear  passengers  fasten  their  seat
belt.

Fastening
 Pull the strap, then insert the tongue

in the buckle.

 Check that the seat belt is fastened

correctly by pulling the strap.

  Unfastening
      Press the red button on the buckle.
     Guide the seat belt as it reels in.

The corresponding warning lamp  2  or  3
comes  on  in  red  on  the  seat  belt  and
passenger's front airbag warning lamps
display if the seat belt is not fastened or
is unfastened.

When  the  ignition  is  switched  on,  with
the  engine  running  or  when  the  vehicle
is moving at less than 12 mph (20 km/h),
the  corresponding  warning  lamps   4 ,   5
and  6  come on in red for approximately

30 seconds, if the seat belt is not fas-

tened.
When the vehicle is moving at more than
12 mph  (20 km/h),  the  corresponding
warning lamp  4 ,  5  or  6  comes on in red,
accompanied  by  an  audible  signal  and
a message on the multifunction screen,
if a rear passenger has unfastened their
seat belt.

Seat belt unfastened warning lamps
display

127

The driver must ensure that
passengers use the seat belts
correctly and that they are all

restrained securely before setting off.
Wherever you are seated in the ve-
hicle, always fasten your seat belt,
even for short journeys.
Do not invert the seat belt buckles as

they will not fulﬁ l their role fully.

The seat belts are ﬁ tted with an in-

ertia reel permitting automatic adjust-
ment of the length of the strap to your
size. The seat belt is stored automat-
ically when not in use.
Before and after use, ensure that the
seat belt is reeled in correctly.
The lower part of the strap must be
positioned as low as possible on the
pelvis.
The upper part must be positioned in
the hollow of the shoulder.
The inertia reels are ﬁ tted with an

automatic

locking

device

which

comes into operation in the event of a
collision, emergency braking or if the
vehicle rolls over. You can release

the device by pulling ﬁ rmly on the

strap and releasing it so that it re-
winds slightly.

In order to be effective, a seat belt
must:
-

be tightened as close to the body
as possible,

be pulled in front of you with a
smooth movement, checking that
it does not twist,

be used to restrain only one person,

not bear any trace of cuts or fraying,

- not be converted or modiﬁ ed to

avoid affecting its performance.

In  accordance  with  current  safety
regulations,  all  repairs  and  checks
must be carried out by a PEUGEOT
dealer who guarantees that the work
is carried out correctly.
Have  your  seat  belts  checked  regu-
larly by a PEUGEOT dealer and par-
ticularly  if  the  straps  show  signs  of
damage.
Clean the seat belt straps with soapy
water  or  a  textile  cleaning  product,
sold by PEUGEOT dealers.
After folding or moving a seat or rear
bench seat, ensure that the seat belt
is positioned and reeled in correctly.

  Recommendations for children
Use  a  suitable  child  seat  if  the  pas-
senger  is  less  than  12  years  old  or
shorter than one and a half metres.
Never  use  the  same  seat  belt  to
secure more than one person.
Never allow a child to travel on your lap.

In the event of an impact

  Depending  on  the  nature  and
seriousness  of  the  impacts ,  the
pre-tensioning  device  may  be  trig-
gered  before  and  independently  of
the  airbags.  Triggering  of  the  pre-
tensioners is accompanied by a slight
discharge  of  harmless  smoke  and  a
noise, due to the activation of the py-
rotechnic  cartridge  incorporated  in
the system.
In all cases, the airbag warning lamp
comes on.
Following  an  impact,  have  the  seat
belts  system  checked,  and  if  neces-
sary replaced, by a PEUGEOT dealer.

128

AIRBAGS

Deployment of the airbag(s) is
accompanied by a slight emis-
sion of harmless smoke and

a  noise,  due  to  the  activation  of  the
pyrotechnic cartridge incorporated in
the system.
This smoke is not harmful, but sensi-
tive individuals may experience slight
irritation.
The noise of the detonation may re-
sult  in  a  slight  loss  of  hearing  for  a
short time.

Front airbags

System which protects the driver and
front passenger in the event of a seri-
ous front impact in order to limit the risk
of injury to the head and chest.
The driver's airbag is ﬁ tted in the centre

of the steering wheel; the front passen-

ger's airbag is ﬁ tted in the dashboard

above the glove box.

  Deployment
The  airbags  are  deployed  simultane-
ously,  unless  the  passenger's  front
airbag  is  deactivated,  in  the  event  of  a
serious front impact to all or part of the
front impact zone  A , in the longitudinal
centreline of the vehicle on a horizontal
plane and directed from the front to the
rear of the vehicle.
The front airbag inﬂ ates between the front

occupant of the vehicle and the dash-
board to cushion his forward movement.

Impact detection zones

A. Front impact zone.
B. Side impact zone.

  The  airbags  do  not  oper-
ate  when  the  ignition  is
switched off.

This equipment will only deploy once.
If a second impact occurs (during the
same or a subsequent accident), the
airbag will not be deployed again.

  System designed to maximise the safety
of the occupants (with the exception of
the rear centre passenger) in the event
of violent collisions. It supplements the
action  of  the  force-limiting  seat  belts
(with  the  exception  of  the  rear  centre
passenger).
If  a  collision  occurs,  the  electronic  de-
tectors record and analyse the front and
side  impacts  sustained  in  the  impact
detection zones:
   -

in the case of a serious impact, the
airbags are deployed instantly and
protect the occupants of the vehicle
(with the exception of the rear centre
passenger); immediately after the

impact, the airbags deﬂ ate rapidly

so that they do not hinder visibility
or the exit of the occupants,

in the case of a minor or rear impact
or in certain roll-over conditions, the
airbags will not be deployed; the

seat belt alone is sufﬁ cient to pro-

vide optimum protection in these
situations.

129

If at least one of the two airbag
warning lamps come on contin-
uously, do not install a child seat
on the front passenger seat.

Have the system checked by a
PEUGEOT dealer.

Operating fault

If  this  warning  lamp  comes
on  in  the  instrument  panel,
accompanied  by  an  audible
warning and a message in the
multifunction  screen,  contact

a PEUGEOT dealer to have the system
checked. The airbags may no longer be
deployed in the event of a serious im-
pact.

  Reactivation
When  you  remove  the  child  seat,  turn
the switch  1  to the  "ON"  position to re-
activate  the  airbag  and  so  assure  the
safety  of  your  front  passenger  in  the
event of an impact.

With the ignition on, this warn-
ing lamp comes on in the seat
belt and passenger's front air-
bag warning lamps display for
approximately one minute, if
the passenger's front airbag is
activated.

To  assure  the  safety  of  your
child,  it  is  imperative  that  the
passenger's  front  airbag  is

deactivated  when  you  install  a  "rear
facing"  child  seat  on  the  front  pas-
senger seat.
Otherwise, the child would risk being
seriously injured or killed if the airbag
were deployed.

According  to  version,  this
warning lamp comes on either
in  the  instrument  panel  or  in
the seat belt and passenger's
front  airbag  warning  lamps

display when the ignition is on and until
the airbag is reactivated.

If this warning lamp ﬂ ashes,

contact a PEUGEOT dealer.
The passenger's front airbag
may no longer be deployed in
the event of a serious impact.

  Deactivation
Only  the  passenger's  front  airbag  can
be deactivated:
       with the ignition off , insert the key

in the passenger airbag deactivation
switch 1 ,

 turn it to the "OFF" position,
 then, remove the key keeping the

switch in the new position.

131

For the airbags to be fully
effective, observe the
following safety rules:

Sit in a normal upright position.
Wear a correctly adjusted seat belt.
Do not leave anything between the
occupants and the airbags (a child,
pet, object...). This could hamper the
operation of the airbags or injure the
occupants.
After an accident or if the vehicle has
been stolen or broken into, have the
airbag systems checked.
All work on the airbag system is strict-
ly forbidden unless it is carried out by

qualiﬁ ed personnel of the PEUGEOT

dealer network.
Even  if  all  of  the  precautions  men-
tioned  are  observed,  a  risk  of  injury
or of minor burns to the head, chest
or arms when an airbag is deployed
cannot  be  ruled  out.  The  bag  in-

ﬂ ates almost instantly (within a few

milli seconds) then deﬂ ates within the

same time discharging the hot gas via
openings provided for this purpose.

  Front airbags
Do  not  drive  holding  the  steering
wheel  by  its  spokes  or  resting  your
hands  on  the  centre  part  of  the
wheel.
Passengers must not place their feet
on the dashboard.
If possible, do not smoke as deploy-
ment of the airbags can cause burns
or  the  risk  of  injury  from  a  cigarette
or pipe.
Never remove or pierce the steering
wheel or hit it violently.

Lateral airbags
Use only approved covers on the seats.

These will not hinder inﬂ ation of the

lateral airbags. Consult a PEUGEOT
dealer.
Do not ﬁ x or attach anything to the

seat  backs  (clothing...).  This  could
cause  injury  to  the  chest  or  arms  if
the lateral airbag is deployed.
Do  not  sit  with  the  upper  part  of  the
body  any  nearer  to  the  door  than
necessary.

Curtain airbags
Do not ﬁ x or attach anything to the

roof.  This  could  cause  injury  to  the
head  if  the  curtain  airbag  is  de-
ployed.
Do  not  remove  the  grab  handles  in-
stalled on the roof, they play a part in
securing the curtain airbags.

130

Lateral airbags

System which protects the driver and
front passenger in the event of a seri-
ous side impact in order to limit the risk
of injury to the chest.
Each lateral airbag is ﬁ tted in the front, in

the outer side of the seat back frame.

  Deployment
The  lateral  airbags  are  deployed  uni-
laterally  in  the  event  of  a  serious  side
impact applied to all or part of the side
impact zone  B , perpendicular to the lon-
gitudinal  centreline  of  the  vehicle  on  a
horizontal  plane  and  directed  from  the
outside  towards  the  inside  of  the  ve-
hicle.

Curtain airbags

System which protects the driver and
passengers (with the exception of the
rear centre passenger) in the event of a
serious side impact in order to limit the
risk of injury to the side of the head.
Each curtain airbag is built into the pil-
lars and the upper passenger compart-
ment area.

Operating fault

  Deployment
The curtain airbag is deployed at the same
time as the corresponding lateral airbag in
the event of a serious side impact applied
to all or part of the side impact zone  B , per-
pendicular to the longitudinal centreline of
the  vehicle  on  a  horizontal  plane  and  di-
rected from the outside towards the inside
of the vehicle.
The curtain airbag inﬂ ates between the

front or rear occupant of the vehicle and
the windows.

In the event of a minor impact
or  bump  on  the  side  of  the
vehicle  or  if  the  vehicle  rolls
over,  the  airbag  may  not  be
deployed.

In the event of a rear or front colli-
sion, the airbag is not deployed.

Impact detection zones

A. Front impact zone.
B. Side impact zone.

If  this  warning  lamp  comes  on
in the instrument panel, accom-
panied by an audible signal and
a  message  in  the  multifunction
screen,  contact  a  PEUGEOT

dealer to have the system checked. The
airbags may no longer be deployed in the
event of a serious impact.

The lateral airbag inﬂ ates between the

front occupant of the vehicle and the
corresponding door panel.

131

For the airbags to be fully
effective, observe the
following safety rules:

qualiﬁ ed personnel of the PEUGEOT

ﬂ ates almost instantly (within a few

milli seconds) then deﬂ ates within the

same time discharging the hot gas via
openings provided for this purpose.

Lateral airbags
Use only approved covers on the seats.

These will not hinder inﬂ ation of the

lateral airbags. Consult a PEUGEOT
dealer.
Do not ﬁ x or attach anything to the

Curtain airbags
Do not ﬁ x or attach anything to the

132

The electric parking brake combines
2 operational modes:
-

Automatic application/release

Application is automatic when the
engine stops, release is automatic
on use of the accelerator (activated
by default),

Manual application/release

The parking brake can be applied/
released manually by pulling control
lever A .

   Deactivation is recommended
in  particularly  cold  conditions
(ice) and during towing (break-
down, caravan...). Refer to the
"Manual release" paragraph.

Programming the mode
Depending on the country of registration
of the vehicle, the automatic application
when the engine is switched off and the
automatic release when you press the
accelerator can be deactivated.

If  this  warning  lamp  comes
on  in  the  instrument  panel,
the  automatic  mode  is  deac-
tivated.

Activation/deactivation of
this function is possible by
a PEUGEOT dealer.

The  parking  brake  is  then  applied  and
released  manually.  When  the  driver's
door is opened, there is an audible sig-
nal  and  a  message  is  displayed  if  the
brake is not applied.

Do not place any object (packet
of cigarettes, telephone, ...) be-
hind the electric brake control.

133

With the vehicle stationary, to apply the
parking brake whether the engine is run-
ning or off, pull on the control lever A .
Application of the parking brake is con-

ﬁ rmed by:

illumination of the braking warn-
ing lamp and of the warning
lamp P in the control lever A ,

When  the  driver’s  door  is  opened  with
the engine running, a beep is heard and
a  message  is  displayed  if  the  parking
brake has not been applied, unless the
selector  lever  is  in  position   P   (Park)  in
the case of an automatic gearbox.

Manual release

With  the  ignition  on  or  the  engine  run-
ning,  to  release  the  parking  brake,
press   on  the   brake    pedal   or  the  ac-
celerator,  pull then release  the control
lever  A .
Full  application  of  the  parking  brake  is

conﬁ rmed by:

the braking warning lamp and
of the warning lamp P in the
the control lever A going off,

If  you  pull  the  control  lever   A
without pressing the brake ped-
al, the parking brake will not be
released  and  a  warning  lamp
will  come  on  in  the  instrument
panel.

Manual application

Maximum application

If  necessary,  you  can  make  a   maxi-
mum application  of the parking brake.
It  is  obtained  by  means  of  a   long  pull
on the control lever  A , until you see the
message  "Handbrake  on"  and  a  beep
is heard.

In the case of towing, a loaded
vehicle or parking on a gradi-
ent, make a maximum applica-

tion of the parking brake then turn the
front wheels towards the pavement
and engage a gear when you park.
After a maximum application, the re-
lease time will be longer.

Before leaving the vehicle,
check

that

parking

brake

warning lamp in the instru-

ment panel is on, not ﬂ ashing.

Maximum application is essential:
-

in  the  case  of  a  vehicle  towing  a
caravan  or  a  trailer,  if  the  automatic
functions  are  activated  but  you  are
applying the parking brake manually,

when the gradient you are parked
on is variable in its effect (e.g. on a
ferry, in a lorry, during towing).

display of the message
"Handbrake on".

display of the message
"Handbrake off".

134

Automatic application,
engine off

With the vehicle stationary, the parking
brake is automatically applied when
the engine is switched off .

illumination of the braking warn-
ing lamp and of the warning
lamp P in the control lever A ,

Automatic release

The electric parking brake  releases au-
tomatically  and  progressively   when
you press the accelerator:
       Manual  gearbox:   press  down  fully

on the clutch pedal, engage ﬁ rst

gear or reverse, press on the accel-
erator pedal and move off.

 Electronic gear control gearbox :

select position A , M or R then press
on the accelerator pedal.

 Automatic gearbox: select posi-

tion D , M or R then press on the ac-
celerator pedal.

Before leaving the vehicle,
check

that

parking

brake

warning lamp in the instrument

panel is on (not ﬂ ashing).

Never leave a child alone inside the
vehicle with the ignition on, as they
could release the parking brake.

the  braking  warning  lamp
and of the warning lamp  P  in
the control lever  A  going off,

An audible signal will conﬁ rm to you

the application/release of your electric
parking brake.

Full release of the parking brake is con-

ﬁ rmed by:

To immobilise the vehicle,
engine running

With the engine running and the vehicle
stationary, in order to immobilise the ve-
hicle  it  is  essential  to   manually   apply
the parking brake by  pulling  on control
lever  A .
The  application  of  the  parking  brake  is

conﬁ rmed by:

illumination of the braking
warning lamp and the warning
lamp P in the control lever A ,

When  the  driver’s  door  is  opened,  an
audible signal heard and a message is
displayed  if  the  parking  brake  has  not
been applied, unless the selector lever
is in position  P  (Park) in the case of an
automatic gearbox.

Before leaving the vehicle,
check

that

parking

brake

warning lamp in the instru-

ment panel is on, not ﬂ ashing.

   When  stationary,  with  the  en-
gine running, do not press the
accelerator  pedal  unneces-
sarily, as you may release the
parking brake.

The application of the parking brake is

conﬁ rmed by:

display of the message
"Handbrake on".

  In the case of towing, a loaded vehi-
cle or parking on a gradient, turn the
front  wheels  towards  the  pavement
and engage a gear when you park.

display of the message
"Handbrake off".

display of the message
"Handbrake on".

135

Particular situations

In certain situations (e.g. start-

ing  the  engine),  the  parking  brake
can automatically alter its force. This
is normal operation.
To  advance  your  vehicle  a  few  cen-
timetres  without  starting  the  engine,
but with the ignition on, press on the
brake  pedal  and  release  the  park-
ing brake  by pulling  then  releasing
control  lever   A .  The  full  release  of

the parking brake is conﬁ rmed by the

warning  lamp  in  the  control  lever   A
and  the  warning  lamp  in  the  instru-
ment panel going off and the display
of the message "Handbrake off".
If a parking brake fault occurs  while
applied

or if the battery runs ﬂ at, an

emergency release is always pos-
sible.

EMERGENCY BRAKING

  In the event of a failure of the main ser-
vice brake or in an exceptional situation
(e.g.  driver  taken  ill,  under  instruction,
etc)  a continuous pull on the control
lever   A   will stop the vehicle .
The  electronic  stability  programme
(ESP)  provides  stability  during  emer-
gency braking.
If  there  is  a  fault  with  the  emergency
braking, one of the following messages
will be displayed:
   -

"Parking brake faulty".

"Parking brake control faulty".

If a failure of the ESP system is
signalled by the illumination of
this warning lamp, then brak-
ing stability is not guaranteed.
In this event, stability must be

assured by the driver by repeating al-
ternate "pull release" actions on control
lever A .

  The  emergency  braking  must
only  be  used  in  exceptional
circumstances.

136

Front left seat moved back fully.

In the event of the electric parking brake
malfunctioning or the battery running

ﬂ at, an emergency manual device can

release the parking brake.

Emergency release

 Immobilise the vehicle (or keep

it stationary, if the brake pedal is
pressed), with the engine running,

by engaging ﬁ rst gear (manual gear-

box), position P (automatic gearbox)
or M or R (6-speed electronic gear
control gearbox).

 Switch off the engine but leave the

ignition on. If it is impossible to im-
mobilise the vehicle, do not operate
the control and contact a PEUGEOT
dealer urgently.

 Fetch the two vehicle blocks and

the release device, located under
the boot carpet (see "Changing a
wheel" in the "Practical information"
section).

 Immobilise the vehicle by placing

blocks in front and behind one of the
front wheels.

 Slide the front left-hand seat back

as far as possible.



Lift up the ﬂ oor plug B in the carpet

under the seat.

 Pierce the protective cover C on the

tube D with the release device.

 Place the release device in the tube D .
 Turn the release device clockwise.

For safety reasons , it is essential
to continue turning the device as far
as it will go. The parking brake is re-
leased.

 Remove the release device and

store it with the blocks in the tool-
box.

The

operation

the

parking

brake  reinitialises  when  the  igni-
tion  is  switched  off  then  on  again.
If  the  reinitialisation  of  the  parking
brake  proves  impossible,  contact  a
PEUGEOT dealer.

The subsequent time required for
application may be longer than dur-
ing normal operation.

For safety reasons, you must
contact a PEUGEOT dealer
as soon as possible to replace
the protective cover.

Following  an  emergency  unlocking,
immobilisation  of  the  vehicle  is  no
longer  guaranteed  once  the  manual
emergency  release  has  been  de-
ployed  and  the  manual  control  does
not  allow  the  re-application  of  your
parking brake.
Take no action, either on the control
lever   A ,  or  stopping  or  starting  the
engine  while  the  release  device  is
engaged.
Take  care  not  to  allow  moisture  or
dust in the proximity of the protective
cover.

137

HILL START ASSIST

System  which  keeps  your  vehicle  im-
mobilised  temporarily  (approximately
2  seconds)  when  starting  on  a  gradi-
ent, the time it takes to move your foot
from the brake pedal to the accelerator
pedal.
This function is only active when:
   -

the vehicle is completely stationary,
with your foot on the brake pedal,

in particular conditions on a slope,

with the driver’s door closed.

The hill start assist function cannot be
deactivated.

Operation

  On an ascending slope, with the ve-
hicle  stationary,  the  vehicle  is  held
for  a  momentarily  when  you  release
the brake pedal:
   -   provided you are in ﬁ rst gear or neu-

tral on a manual gearbox,

provided you are in A or M on an
electronic gear control gearbox,

provided you are in D or M on an
automatic gearbox.

  On a descending slope, with the ve-
hicle  stationary  and  reverse  gear
engaged, the vehicle is held momen-
tarily  when  you  release  the  brake
pedal.

Do not exit the vehicle while
it is being held in the hill start
assist phase.

If  you  need  to  exit  the  vehicle  with
the  engine  running,  apply  the  park-
ing brake manually then ensure that
the parking brake warning lamp (and
the warning lamp  P  in the lever of the

electric parking brake) are on ﬁ xed

(not ﬂ ashing).

If a fault occurs, these warning lamps
come on. Contact a PEUGEOT dealer
to have the system checked.

138

Operating faults

If the electric parking brake fault warning lamp comes on together with one or more of the warning lamps presented in these
tables, place the vehicle in a safe condition (on level ground, gear engaged) and contact a PEUGEOT dealer without delay.

Situations

Consequences

Display of the message " Parking brake
fault " and of the following warning
lamps:

The automatic functions are deactivated.

Hill start assist is not available.

The electric parking brake can only be used manually.

Display of the message " Parking brake
fault " and of the following warning
lamps:

Manual release of the electric parking brake is only available by pressing the
accelerator pedal and releasing the control.

Hill start assist is not available.

The automatic functions and the manual application are still available.

Display of the message " Parking brake
fault " and of the following warning
lamps:

The automatic functions are deactivated.

Hill start assist is not available.

To apply the electric parking brake:

 Immobilise the vehicle and sw itch off the ignition.

 Pull the control for at least 5 seconds or until application is complete.

 Switch on the ignition and check the switching on of the electric parking brake

warning lamps.

The application is slower than during normal operation.
To release the electric parking brake:
 Switch on the ignition.
 Pull the control and hold it for approximately 3 seconds then release it.

If the braking warning lamp is ﬂ ashing or if the warning lamps do not come on with

the ignition on, these procedures will not work. Place the vehicle on level ground
and have it checked by a PEUGEOT dealer.

and possibly

ﬂ ashing

139

Situations

Consequences

Display of the message " Parking
brake control fault - auto parking
brake activated " and of the following
warning lamps:

Only the automatic application on switching off the engine and automatic
release on acceleration functions are available.

The manual application/release of the electric parking brake and the emergency
braking are not available.

and possibly

ﬂ ashing

Battery fault

If the battery warning lamp comes on you must stop immediately as soon as

the trafﬁ c allows. Stop and immobilise your vehicle (if necessary, place the

two chocks under the wheels).

Apply the electric parking brake before switching off the engine.

Peugeot 3008 Dag (2010.5). Instruction - part 10
