Peugeot 3008 Dag (2010.5). Instruction - part 8

12 V ACCESSORY SOCKETS

 To connect a 12 V accessory (max

power: 120 Watts), remove the cover
and connect a suitable adaptor.

Exceeding the maximum power could
result in damage to your accessory.

FRONT ARMREST

Comfort and storage device for the driver
and front passenger.
 Raise the cover on the left.

Storage

A ventilation outlet distributes cooled air.

PEUGEOT CONNECT USB

  This  connection  box,  consisting  of  an
auxiliary  socket  and/or  USB  port,  is
located  in  the  front  armrest  (under  the
cover).
It  permits  the  connection  of  portable
equipment, such as a digital audio player
of the iPod

type or a USB memory stick.

It reads the audio ﬁ le formats (MP3,

OGG, WMA, WAV, ...) which are trans-
mitted to your audio equipment and
played via the vehicle's speakers.
You can manage these ﬁ les using the

steering mounted controls or the audio
equipment control panel and display
them on the multifunction screen.

When the USB port is used, the portable
equipment charges automatically.

  For  more  information  on  the
use  of  this  equipment,  refer
to the  "Audio and Telematics"
section.

100

To avoid any risk of jamming
of the pedals:

MATS

Removable carpet protection.

Refitting

To reﬁ t the mat on the driver's side:
 position the mat correctly,


reﬁ t the ﬁ xings by pressing,

 check that the mat is secured

correctly.

Fitting

When ﬁ tting the mat for the ﬁ rst time,

on the driver's side use only the ﬁ xings

provided in the wallet attached.
The other mats are simply placed on
the carpet.

Removal

To remove the mat on the driver's side:
 move the seat as far back as pos-

sible,



unclip the ﬁ xings,

 remove the mat.

only use mats which are suited

to the ﬁ xings already present in

the vehicle; these ﬁ xings must be

used,

  -   never ﬁ t one mat on top of another.
The  use  of  mats  not  approved  by
PEUGEOT may interfere with access
to the pedals and hinder the operation
of the cruise control/speed limiter.

101

REAR MULTIMEDIA

Multimedia system permitting the con-
nection of any external portable sys-
tem: Ipod Video, games consoles, DVD
player, …

Two separate video sources
can be connected via the RCA
connectors (yellow).

The video is displayed on two
7’’ screens, integrated in the
head restraints.

Two separate audio sources
can be connected via the RCA
connectors (red and white).

The audio is heard through
two wireless headphones with
Bluetooth technology which
operate with rechargeable bat-
teries.

The   A/B   button  allows  you  to  pair
the  headphones  with  the  screen:
A  left-hand side,  B  right-hand side.

You have a 12 V charger with two out-
puts permitting simultaneous charging
of both headphones.
It is also possible to connect a 3

set of

Bluetooth headphones.

Set-up
 With the engine running, connect

your portable system to the RCA con-
nectors (e.g. with AV1 on the left).

 Press the system's ON/OFF button,

the indicator lamp comes on and the
AV1 indicator lamps come on.

 Press and hold the ON/OFF button on

the headphones, the indicator lamp

on the headphones ﬂ ashes in blue.

 Press and hold the system's ON/OFF

button,  the  pairing  with  the  head-
phones  is  complete  when  the  blue
indicator  lamps  on  the  headphones
and  on  the  system  (in  the  shape  of
headphones) are lit continuously.

 Press the ON/OFF buttons on the

screens if you have a video source.

 Start playing your portable system.

If your seat is in the table posi-
tion, position a cover to avoid
damaging the screen.

These covers also conceal each
screen.

102

REAR ARMREST

SKI FLAP

Opening

 Lower the rear armrest.


Pull the ﬂ ap handle downwards.



Lower the ﬂ ap.

 Load the objects from inside the

boot.

 Lower the rear armrest for a more

comfortable position.

The armrest incorporates two cup holders.

Comfort and storage device for the rear
passengers.

Arrangement for storing and transporting
long objects.

STORAGE COMPARTMENTS
UNDER THE REAR FOOTWELLS

Depending on the conﬁ guration, the

vehicle has storage compartments un-
der the footwells, located forward of the
outer rear seats. Access is via clipped

ﬂ aps with a handle A .

103

PANORAMIC SUNROOF

Component  which  has  a  tinted  glass
panoramic surface to increase the light
and visibility in the passenger compart-
ment.
Fitted  with  an  electric  blind  in  several
sections  to  improve  temperature  and
noise related comfort.

If the blind meets an obstacle
during operation, you must
reverse the movement of the

blind.  To  do  this,  press  the  control
concerned.
When  the  driver  operates  the  blind
control,  he  must  ensure  that  no  one
is  preventing  correct  closing  of  the
blind.
The driver must ensure that passen-
gers use the blind correctly.
Be aware of children when operating
the blind.

manual mode

 Pull or press control A gently.

The blind stops when you release
the control.

automatic mode

 Pull or press control A

ﬁ rmly.

One press opens or closes the

blind completely.

Pressing the control again stops

the blind.

  Safety anti-pinch
In  automatic  mode  and  at  the  end  of
its travel, if the blind meets an obstacle
while  closing  it  stops  and  moves  back
slightly.

One-touch electric blind

There are two options for opening and
closing:

If the blind re-opens during a
closing manoeuvre, and im-
mediately after it stops:

 pull the control until the blind is

fully open,

 press the control until the blind is

fully closed.

The safety anti-pinch function is
not operational during these opera-
tions.

Reinitialisation: if the blind's supply is
cut off while it is moving, the safety anti-
pinch must be reinitialised:
 press the control until the blind is

fully closed,



continue to press for at least 3 seconds.

A slight movement of the blind will then

be noticeable, conﬁ rming the reinitiali-

sation.

104

BOOT FITTINGS

1. Load space cover

2. Hooks

3. 12 V accessory socket (120 W)

4. Torch

5. Rear seats folding controls

6. Adjustable boot

(3 position ﬂ oor )

Stowing rings on the ﬂ oor

8. Luggage retaining net

9. Storage trays

105

Rear parcel shelf

  To fold it:
      unhook the two cords,
     fold  it  concertina-style  to  the  rear

seats.

To remove it:
 fold the rear parcel shelf as de-

scribed above,



unclip the ﬁ xings on the left and on

the right by pushing gently,

 place your hands as shown on the

illustration then pull the assembly
towards you,

To store it at the bottom of the boot:
 remove the rear parcel shelf as de-

scribed above,



place the ﬂ oor at an angle,

 place the rear parcel shelf in its lo-

cation (recess marked A ), at bottom
of the boot,

 the rear parcel shelf will be protected if

you place the ﬂ oor in the intermediate

position.

This consists of three sections which
can be folded back on each other.

To put it back in place:
 take hold of the rear parcel shelf

with both hands then place it on its
support,

     unfold it to the boot pillars,
     hook the two cords,
     if necessary, press on the top of the

rear parcel shelf, on the left and on

the right, to engage the ﬁ xings.

  When changing a wheel
The  hooks  facilitate  access
to  the  spare  wheel,  retain-

ing the boot carpet by means of the
two cords.

The hooks can be used to secure shop-
ping bags.

Hooks

 To connect a 12 V accessory (max

power: 120 W), remove the cap and
connect an appropriate adaptor.

 Turn the key to the ignition position.

12 V accessory socket

Luggage retaining net

Hooked onto the stowing rings on the

movable boot ﬂ oor, this enables you to

secure your luggage.
Observe the loads indicated on the side
of the boot, in accordance with the posi-

tion of the movable ﬂ oor.
For safety reasons in case of sharp
braking, we recommend that heavy ob-

jects are placed on the ﬂ oor as close as

possible to the back of the rear seats.

107

 Raise the boot carpet, hooking the

two cords on the hooks, then gain
access to the storage box.

Depending on the conﬁ guration, this

has areas for storing:
-

a box of spare bulbs,

- a ﬁ rst aid kit,
-

a tyre repair kit,

two warning triangles,

...

Storage box

108

Adjustable boot floor

This three position ﬂ oor allows you to op-

timise the volume of the boot by means
of the guides placed on the sides:
- High position (50 kg max): the ﬂ oor

is level with the closed lower tail-
gate.

You can load objects while keeping
an area protected and isolated.

Intermediate position (100 kg max):

the ﬂ oor is level with the open lower

tailgate.

You obtain a ﬂ at ﬂ oor to the front

seats when the rear seats are in the
retracted position.

Low position (150 kg max): maxi-
mum boot volume.

To place and support the ﬂ oor at an angle:
 From the high position, raise the

ﬂ oor towards the load space cover.

 Do not hesitate to pass the two re-

tractable stops then place the ﬂ oor

back on these two stops.

To change the height of the ﬂ oor:


Push the ﬂ oor fully forwards then, with

the help of the support stops A , move

the ﬂ oor to the position required.

The ﬂ oor is equipped with four stowing

rings to secure your luggage, observing
the loads indicated (in the boot).

109

Torch

This is a removable lamp, ﬁ tted in the

boot wall, which can be used to illumi-
nate the boot or as a torch.

  Operation
This torch operates with NiMH type re-
chargeable batteries.
It  has  a  battery  life  of  approximately
45 minutes  and  charges  while  you  are
driving.

Use
 Extract the torch from its location

pulling the side of the torch A .

 Press the switch, located on the

back, to switch the torch on or off.

 Unfold the support, located on the

back, to set down and raise the

torch; for example, when changing

a wheel.

Storing
 Put the torch back in place in its loca-

tion starting with the narrow part B .

If  you  have  forgotten  to  switch  off
the  torch,  this  switches  it  off  auto-
matically.

Rear side blinds

Fitted on the rear windows, these protect
your young children from the sun.

 Pull the blind by the central tab.
 Position the blind attachment on the

hook.

Observe the polarities when

ﬁ tting the batteries.

Never replace the rechargeable batter-
ies with normal single-use batteries.

It the torch is not engaged cor-
rectly,  it  may  not  charge  and
may  not  come  on  when  the
boot is opened.

For the boot lighting function,
refer to the "Visibility - § Boot
lamp" section.

105

Rear parcel shelf

  To fold it:
      unhook the two cords,
     fold  it  concertina-style  to  the  rear

seats.

To remove it:
 fold the rear parcel shelf as de-

scribed above,



unclip the ﬁ xings on the left and on

the right by pushing gently,

 place your hands as shown on the

illustration then pull the assembly
towards you,

To store it at the bottom of the boot:
 remove the rear parcel shelf as de-

scribed above,



place the ﬂ oor at an angle,

 place the rear parcel shelf in its lo-

cation (recess marked A ), at bottom
of the boot,

 the rear parcel shelf will be protected if

you place the ﬂ oor in the intermediate

position.

This consists of three sections which
can be folded back on each other.

To put it back in place:
 take hold of the rear parcel shelf

with both hands then place it on its
support,

     unfold it to the boot pillars,
     hook the two cords,
     if necessary, press on the top of the

rear parcel shelf, on the left and on

the right, to engage the ﬁ xings.

108

Adjustable boot floor

This three position ﬂ oor allows you to op-

timise the volume of the boot by means
of the guides placed on the sides:
- High position (50 kg max): the ﬂ oor

is level with the closed lower tail-
gate.

You can load objects while keeping
an area protected and isolated.

Intermediate position (100 kg max):

the ﬂ oor is level with the open lower

tailgate.

You obtain a ﬂ at ﬂ oor to the front

seats when the rear seats are in the
retracted position.

Low position (150 kg max): maxi-
mum boot volume.

To place and support the ﬂ oor at an angle:
 From the high position, raise the

ﬂ oor towards the load space cover.

 Do not hesitate to pass the two re-

tractable stops then place the ﬂ oor

back on these two stops.

To change the height of the ﬂ oor:


Push the ﬂ oor fully forwards then, with

the help of the support stops A , move

the ﬂ oor to the position required.

The ﬂ oor is equipped with four stowing

rings to secure your luggage, observing
the loads indicated (in the boot).

109

Torch

This is a removable lamp, ﬁ tted in the

boot wall, which can be used to illumi-
nate the boot or as a torch.

  Operation
This torch operates with NiMH type re-
chargeable batteries.
It  has  a  battery  life  of  approximately
45 minutes  and  charges  while  you  are
driving.

Use
 Extract the torch from its location

pulling the side of the torch A .

 Press the switch, located on the

back, to switch the torch on or off.

 Unfold the support, located on the

back, to set down and raise the

torch; for example, when changing

a wheel.

Storing
 Put the torch back in place in its loca-

tion starting with the narrow part B .

If  you  have  forgotten  to  switch  off
the  torch,  this  switches  it  off  auto-
matically.

Rear side blinds

Fitted on the rear windows, these protect
your young children from the sun.

 Pull the blind by the central tab.
 Position the blind attachment on the

hook.

Observe the polarities when

ﬁ tting the batteries.

Never replace the rechargeable batter-
ies with normal single-use batteries.

It the torch is not engaged cor-
rectly,  it  may  not  charge  and
may  not  come  on  when  the
boot is opened.

For the boot lighting function,
refer to the "Visibility - § Boot
lamp" section.

  PEUGEOT recommends  that
children  should  travel  in  the
rear seats  of your vehicle:

"rearwards-facing" up to the age of 2,

"forwards-facing" over the age of 2.

GENERAL POINTS RELATING
TO CHILD SEATS

  "Forwards-facing"
When  a  "forwards-facing"  child  seat  is
installed on the  front passenger seat ,
adjust the vehicle's seat to the interme-
diate longitudinal position with the seat
back  upright  and  leave  the  passenger
airbag activated.

Intermediate longitudinal position

* The rules for carrying children are

speciﬁ c to each country. Refer to the

current legislation in your country.

  "Rearwards-facing"
When a "rearwards-facing" child seat is
installed on the  front passenger seat ,
it is essential that the passenger airbag
is  deactivated.  Otherwise,   the  child
would risk being seriously injured or

killed if the airbag were to inﬂ ate .

Although  one  of  PEUGEOT's  main  cri-
teria  when  designing  your  vehicle,  the
safety of your children also depends on
you.
For  maximum  safety,  please  observe
the following recommendations:
   -

in  accordance  with  European  reg-
ulations,   all  children  under  the
age  of  12  or  less  than  one  and  a
half metres tall must travel in ap-
proved child seats suited to their
weight

, on seats ﬁ tted with a seat

belt or ISOFIX mountings * ,

statistically, the safest seats in
your vehicle for carrying children
are the rear seats,

a  child  weighing  less  than  9 kg
must  travel  in  the  "rearwards-
facing" position both in the front
and in the rear.

CHILD SEAT IN THE FRONT

111

Passenger airbag OFF

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are
secured using a three point seat belt :

Group 0+: from birth to 13 kg

Group 1: from 9 to 18 kg

"RÖMER/BRITAX

Baby-Safe Plus".

Installed in the

rearwards-facing

position.

"RÖMER Duo Plus

ISOFIX".

Groups 1, 2 and 3: from 9 to 36 kg

"KIDDY Life".

The use of the restraining cushion is

compulsory for the transportation of

young children (from 9 to 18 kg).

Groups 2 and 3: from 15 to 36 kg

"RECARO Start''.

"KLIPPAN Optima".

From the age

of 6 years

(approximately 22 kg),
the booster is used on

its own.

  For  more  information  on  de-
activating  the  airbag,  refer
to  the  "Safety"  section  then
"Airbags".

Content .. 6 7 8 9 ..
