Peugeot 3008 Dag (2010.5). Instruction

Heated seats control
With the engine running, the front seats
can be heated separately.

 Use the adjustment dial, placed on

the side of each front seat, to switch
on and select the level of heating re-
quired:

  0  :    Off.
  1  :  Low.
  2  :  Medium.
  3  :  High.

Head restraint height and angle

adjustment

 To raise the head restraint, pull it for-

wards and upwards at the same time.

 To remove the head restraint, press

the lug A and pull the head restraint
upwards.

 To put the head restraint back in

place, engage the head restraint
stems in the openings keeping them
in line with the seat back.

 To lower the head restraint, press

the lug A and the head restraint at
the same time.

 To adjust the angle of the head re-

straint, tilt its lower part forwards or
rearwards.

The head restraint is ﬁ tted with

a frame with notches which
prevents it from lowering; this
is a safety device in case of
impact.

The adjustment is correct when the

upper edge of the head restraint is

level with the top of the head.
Never  drive  with  the  head  restraints
removed; they must be in place and
adjusted correctly.

Manual lumbar adjustment
 Turn the knob to obtain the desired

level of lumbar support.

Folding the seat backrest
 Check that no object, either on or

underneath the seat, could hinder
its movement.

 To make the operation easier, place

the head restraint in the low position

(if the seat is in the fully forward po-

sition).



If your vehicle is ﬁ tted with the video

pack, place the protective cover on
the head restraint.

 Lift the control, located behind the

seat, then guide the seat backrest
forwards.

When  the  seat  backrest  is  in  this  posi-
tion,  the  seat  behind  it  and  the  centre
rear seat must not be occupied.
This position, associated with that of the
rear seats, allows you to transport long
objects inside the vehicle.
The maximum weight on the seat is 30 kg.

Table position, front passenger
seat

Returning the seat to the normal

position
 Guide the seat backrest rearwards

until it locks in place.

Folding the seat from the boot

Each section of the bench seat (1/3 or

2/3) has its own control to release the

seat back and its seat cushion from the
boot.
 Check that nothing is preventing

the seat back from folding (head re-

straint, seat belts, ...),

 check also that no object on or un-

der the seat could hinder its move-
ment,

 pull the control from the boot.

REAR SEATS

Never drive with rear passen-
gers when the head restraints
are removed; the head re-

straints must be in place and in the
high position.

Rear head restraints

These have a high position (comfort and

safety) and a low position (rear visibility).

They can also be removed.
To remove a head restraint:
 pull the head restraint fully upwards,
 then, press the lug A .

Bench seat the left-hand (2/3) or right-

hand (1/3) section of which can be fold-

ed to adapt the boot load space.

The seat cushion lowers to be
covered by the seat back; this

leaves a ﬂ at boot ﬂ oor, if the

adjustable ﬂ oor is in the intermediate

position.

Folding the seat from the rear

Check  that  no  object,  either  on  or  un-
derneath  the  seat,  could  hinder  its
movement.
      Move  the  corresponding  front  seat

forwards if necessary,

 check that the seat belt is positioned

correctly on the side of the seat
back,

 place the head restraints in the low

position or remove them if necessary,

 pull the control 1 forwards to release

the seat back 2 which tilts easily
onto the seat cushion 3 .

Returning the seat back to its

original position

 Put the seat back in the upright posi-

tion and secure it, the seat cushion
also returns to its original position,

 check that the red indicator, located

at the control 1 , is no longer visible,



reﬁ t the head restraints or put them

back in place.

When  returning  the  rear  seat  back  to
its  original  position,  take  care  not  to
trap the seat belts and ensure that their
buckles are positioned correctly.

The objects observed are, in
reality, closer than they ap-
pear.

Take this into account in order to cor-
rectly judge the distance of vehicles
approaching from behind.

MIRRORS

Door mirrors

Each ﬁ tted with an adjustable mirror

glass permitting the lateral rearward vi-
sion necessary for overtaking or park-
ing. They can also be folded for parking

in conﬁ ned spaces.

Folding
-

Automatic: lock the vehicle using
the remote control or the key.

Manual: with the ignition on, pull
control A rearwards.

The folding and unfolding of
the door mirrors using the re-
mote control can be deactivat-
ed by a PEUGEOT dealer.

Fold  the  mirrors  when  putting  your
vehicle  through  an  automatic  car
wash.

Adjustment

Unfolding
-

Automatic: unlock the vehicle using
the remote control or the key.

Manual: with the ignition on, pull
control A rearwards.

  If the mirrors are folded using
control   A ,  they  will  not  unfold
when the vehicle is unlocked.
Pull again on control  A .

 Move control A to the right or to

the left to select the corresponding
mirror.

 Move control B in all four directions

to adjust.

 Return control A to the central

position.

Demisting - Defrosting
If your vehicle is ﬁ tted with heated mir-

rors, the demisting-defrosting operates
with the engine running, by switching

on the heated rear screen (refer to the

"Rear screen demist-defrost" page).

Adjustment
 Adjust the mirror so that the glass

is directed correctly in the "day"

position.

As a safety precaution, the
mirrors must be adjusted to

reduce the "blind spot".

Manual day/night model

Day/night position


Pull the lever to change to the "night"

anti-dazzle position.

 Push the lever to change to the nor-

mal "day" position.

Rear view mirror

Adjustable  mirror  providing  a  central
rearward view.
Equipped  with  an  anti-dazzle  system,
useful in poor light.

  In  order  to  ensure  optimum
visibility  during  your  manoeu-
vres,  the  mirror  lightens  au-

tomatically when reverse gear is
engaged.

Automatic day/night model

By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes  between  the  day  and  night
uses.
It has an anti-dazzle system which dark-
ens  the  mirror  glass:  this  reduces  any
driver  discomfort  caused  by  the  light
beams of following vehicles, the sun...

Unfolding the key

Unlocking the vehicle

 Press the open padlock to

unlock the vehicle.

Complete unlocking using the
remote control

REMOTE CONTROL KEY

System  which  permits  central  unlock-
ing  or  locking  of  the  vehicle  using  the
lock or from a distance. It is also used to
locate  and  start  the  vehicle,  as  well  as
providing protection against theft.

Complete unlocking using the key
 Turn the key to the left in the driver's

door lock to unlock the vehicle.

Unlocking is conﬁ rmed by rapid ﬂ ashing

of  the  direction  indicators  for  approxi-
mately two seconds.
According  to  version,  the  door  mirrors
unfold at the same time.

Selective unlocking using the
remote control

Selective unlocking using the key
 Turn the key to the left in the driver's

door lock once to unlock the driver's
door only.

 Turn the key to the left in the driver's

door lock again to unlock the other

doors and the boot.

 Press the open padlock

once to unlock the driver's
door only.

 Press the open padlock again to un-

lock the other doors and the boot.

Each unlocking is conﬁ rmed by rapid

ﬂ ashing of the direction indicators for

approximately two seconds.
According to version, the door mirrors

unfold at the same time as the ﬁ rst

unlocking action.
The selective unlocking is only available

on versions ﬁ tted with deadlocking.

The complete or selective
unlocking parameter is set
via the multifunction screen

conﬁ guration menu.

Complete unlocking is activated by de-

fault.



First press this button to

unfold the key.

Locating your vehicle

 Press the closed padlock to locate

your locked vehicle in a car park.

This is indicated by lighting of the direc-

tion indicators for a few seconds.

Deadlocking renders the exte-
rior and interior door controls
inoperative.

It also deactivates the manual central

control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

Deadlocking using the remote
control

Deadlocking using the key

Folding the key

 Press the closed padlock

to  lock  the  vehicle  com-
pletely or press the closed
padlock for more than two
seconds  to  close  the  win-
dows  automatically  in  ad-
dition to locking (according
to version).

 Press the closed padlock again

within ﬁ ve seconds to deadlock the

vehicle.

If one of the doors or the boot

is still open, the central locking
does not take place.

When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds un-
less a door is opened.

Normal locking using the key
 Turn the key to the right in the driver's

door lock to lock the vehicle com-
pletely.

Locking is conﬁ rmed by ﬁ xed lighting of

the direction indicators for approximately
two seconds.
According to version, the door mirrors
fold at the same time.

The folding and unfolding of the
door mirrors using the remote

control can be deactivated by a

PEUGEOT dealer.

Locking the vehicle

 Press the closed padlock

to lock the vehicle com-
pletely.

 Press the closed padlock for more

than  two  seconds  to  close  the  win-
dows  automatically  in  addition  to
locking (according to version).

Normal locking using the remote
control

 Turn the key to the right in the

driver's door lock to lock the vehicle
completely  and  hold  it  in  this  posi-
tion  for  more  than  two  seconds  to
close  the  windows  automatically
in  addition  to  locking  (according  to
version).

 Turn the key to the right again within

ﬁ ve seconds to deadlock the vehicle.

Deadlocking is conﬁ rmed by ﬁ xed light-

ing of the direction indicators for ap-
proximately two seconds.
According to version, the door mirrors
fold at the same time.



First press this button to

fold the key.

  Electronic engine immobiliser
The  key  contains  an  electronic  chip
which  has  a  special  code.  When  the
ignition  is  switched  on,  this  code  must

be recognised in order for starting to be

possible.

This electronic engine immobiliser locks

the engine management system a few
minutes after the ignition is switched off

and prevents starting of the engine by

anyone who does not have the key.

Anti-theft protection

In the event of a malfunction,

you are informed by lighting of

this warning lamp, an audible

signal and a message on the
multifunction screen.

In this case, your vehicle does not start;
contact a PEUGEOT dealer as soon as

possible.

For  more  information,  refer
to  the  "Practical  information  -
Energy  economy  mode"  sec-
tion.

Starting the vehicle

 Insert the key in the ignition switch.

The system recognises the starting
code.

 Turn the key fully towards the dash-

board to position 3 (Starting) .

 When the engine starts, release the

key.

Switching the vehicle off



Immobilise the vehicle.

 Turn the key fully towards you to po-

sition 1 (Stop) .

 Remove the key from the ignition

switch.

  Energy economy mode
After  switching  off  the  engine  (posi-
tion  1-Stop ), you can still use functions
such  as  the  audio  and  telematics  sys-
tem, the wipers, the dipped headlamps,
the courtesy lamps, etc. for a maximum

combined period of thirty minutes.

A heavy object (key fob...), at-

tached  to  the  key  and  weigh-
ing  down  on  its  shaft  in  the
ignition  switch,  could  cause  a
malfunction.

Remote control problem

Following disconnection of the vehicle

battery, replacement of the remote con-

trol battery or in the event of a remote

control malfunction, you can no longer
unlock, lock or locate your vehicle.
 First of all, use the key in the lock to

unlock or lock your vehicle.

 Then, reinitialise the remote control.
If the problem persists, contact a

PEUGEOT dealer as soon as possible.

Changing the battery

Battery ref.: CR1620/3 volts.

  Reinitialisation
      Switch off the ignition.
     Turn the key to position  2 (Ignition

on ) .

 Press the closed padlock immedi-

ately for a few seconds.

 Switch off the ignition and remove

the key from the ignition switch.

The remote control is fully operational
again.

If the battery is ﬂ at, you are in-

formed by illumination of this

warning lamp, an audible signal

and a message in the multifunc-
tion screen.

 Unclip the casing using a coin at the

notch.



Slide the ﬂ at battery out of its loca-

tion.



Slide the new battery into its loca-

tion observing the original direction.

 Clip the casing.
 Reinitialise the remote control.

This replacement battery is available

from PEUGEOT dealers.

Lost keys

Visit a PEUGEOT dealer with the vehicle's V5 registration document and

your personal identiﬁ cation documents.

The PEUGEOT dealer will be able to retrieve the key code and the transponder

code required to order a replacement key.

Do not throw the remote con-

trol batteries away, they contain

metals which are harmful to the
environment.

Take them to an approved collection
point.

Remote control

The high frequency remote control is a sensitive system; do not operate it while

it is in your pocket as there is a possibility that it may unlock the vehicle, without

you being aware of it.

Do not repeatedly press the buttons of your remote control out of range and

out of sight of your vehicle. You run the risk of stopping it from working and the

remote control would have to be reinitialised.
The remote control does not operate when the key is in the ignition, even when
the ignition is switched off, except for reinitialisation.

Locking the vehicle

Driving with the doors locked may make access to the passenger compartment

by the emergency services more difﬁ cult in an emergency.

As a safety precaution (with children on board), remove the key from the ignition

when you leave the vehicle, even for a short time.

Anti-theft protection

Do not make any modiﬁ cations to the electronic engine immobiliser system; this

could cause malfunctions.

When purchasing a second-hand vehicle

Have the key codes memorised by a PEUGEOT dealer, to ensure that the keys

in your possession are the only ones which can start the vehicle.

  Electronic engine immobiliser
The  key  contains  an  electronic  chip
which  has  a  special  code.  When  the
ignition  is  switched  on,  this  code  must

be recognised in order for starting to be

possible.

This electronic engine immobiliser locks

the engine management system a few
minutes after the ignition is switched off

and prevents starting of the engine by

anyone who does not have the key.

Anti-theft protection

In the event of a malfunction,

you are informed by lighting of

this warning lamp, an audible

signal and a message on the
multifunction screen.

In this case, your vehicle does not start;
contact a PEUGEOT dealer as soon as

possible.

For  more  information,  refer
to  the  "Practical  information  -
Energy  economy  mode"  sec-
tion.

Starting the vehicle

 Insert the key in the ignition switch.

The system recognises the starting
code.

 Turn the key fully towards the dash-

board to position 3 (Starting) .

 When the engine starts, release the

key.

Switching the vehicle off



Immobilise the vehicle.

 Turn the key fully towards you to po-

sition 1 (Stop) .

 Remove the key from the ignition

switch.

combined period of thirty minutes.

A heavy object (key fob...), at-

tached  to  the  key  and  weigh-
ing  down  on  its  shaft  in  the
ignition  switch,  could  cause  a
malfunction.

ALARM

System which protects and provides a
deterrent against the theft of your vehi-
cle. It provides two types of protection,
exterior and interior, as well as an anti-
tamper function.

Locking the vehicle with full
alarm

Do not make any modiﬁ ca-

tions to the alarm system, this
could cause malfunctions.

To be effective, this deactivation

must be carried out each time

the ignition is switched off.

Reactivation of the interior
volumetric protection
 Unlock the vehicle using the unlock-

ing button on the remote control.

 Relock the vehicle using the remote

control.

The alarm is activated again with both

types of protection; the indicator lamp

on button A switches off.

Locking the vehicle with
exterior protection alarm only

Activation
 Switch off the ignition and get out of

the vehicle.

 Lock or deadlock the vehicle using

the locking button on the remote

control.

The alarm is activated; the indicator lamp

on button A ﬂ ashes once per second.

Exterior perimiter protection

The system detects opening of the
vehicle.
The alarm is triggered if anyone tries to

enter the vehicle by forcing a door, the

boot or the bonnet.

Interior volumetric protection

The system detects any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks

a window or moves inside the vehicle.
If you wish to leave a pet in the vehicle
or a window partially open, deactivate
the interior volumetric protection.

Anti-tamper function

The system detects the putting out of
service of its components.
The alarm is triggered if anyone tries
to put the wires of the siren, the central

control or the battery out of service.

Deactivation
 Unlock the vehicle using the unlock-

ing button on the remote control.

The alarm is deactivated; the indicator

lamp on button A switches off.

  Deactivation of the interior
volumetric protection
      Switch off the ignition.
  

Within ten seconds, press button A

until the indicator lamp is lit continu-
ously.

 Get out of the vehicle.
 Lock or deadlock the vehicle using

the locking button on the remote

control.

The exterior protection alarm alone re-
mains activated; the indicator lamp on

button A ﬂ ashes once per second.

Triggering
This is indicated by sounding of the siren

and ﬂ ashing of the direction indicators

for approximately thirty seconds.
After it has been triggered, the alarm is

again operational.

If the alarm is triggered ten
times in succession, the elev-

enth time will result in it be-

coming inactive.

If the indicator lamp on button A

ﬂ ashes rapidly, this indicates that the

alarm was triggered during your ab-

sence. When the ignition is switched

on, this ﬂ ashing stops immediately.
To avoid triggering the alarm when
washing your vehicle, lock it using
the key in the driver's door lock.
Do not activate the alarm before dis-

connecting the battery, otherwise the

siren will sound.

Failure of the remote control
 Unlock the vehicle using the key in

the driver's door lock.

 Open the door; the alarm is trig-

gered.

 Switch on the ignition; the alarm

stops.

Malfunction
When the ignition is switched on, light-

ing of the indicator lamp on button A for

ten seconds indicates a siren fault.
Have it checked by a PEUGEOT dealer.

Locking the vehicle without
activating the alarm
 Lock or deadlock the vehicle using

the key in the driver's door lock.

  Automatic operation *
Depending on the legislation in force in
your  country,  one  of  these  cases  may
occur:
   -

45 seconds after the vehicle is
locked using the remote control, the
alarm is activated, regardless of the

status of the doors and boot.

2 minutes after the last door or the

boot is closed, the alarm is activated.

 To avoid triggering the alarm on

entering the vehicle, ﬁ rst press the

unlocking button on the remote

control.

* According to country.

  The  electric  window  controls
remain  operational  for  ap-
proximately  45  seconds  after

the ignition is switched off or until the
vehicle is locked after a front door is
opened.
If one of the passenger windows can-

not be operated from the driver's door

control  pad,  carry  out  the  operation
from  the  control  pad  of  the  passen-
ger door concerned, and vice versa.

ELECTRIC WINDOWS

System  intended  to  open  or  close  a  win-
dow  manually  or  automatically.   Fitted
with  a  safety  anti-pinch  system  and  a
system  for  deactivation  in  the  event  of
misuse of the rear controls.

1. Driver's electric window control.
2. Passenger's electric window

control.

3. Rear right electric window

control.

4. Rear left electric window control.
5. Deactivation of the rear electric

window and door controls.

If the window cannot be closed

(for example, in the presence
of ice), immediately after the
movement is reversed:

 press and hold the control until

the window opens fully,

 then pull the control immediately

and hold it until the window closes,

 continue to hold the control for

approximately one second after
the window has closed.

The safety anti-pinch function is not
operational during these operations.

Safety anti-pinch
When the window rises and meets an

obstacle, it stops and partially lowers

again.

automatic mode



Press or pull the control ﬁ rmly.

The window opens or closes fully
when the control is released.

 Pressing the control again stops

the movement of the window.

One-touch electric windows

There are two options:
-

manual mode

 Press or pull the control gently.

The window stops when the con-
trol is released.

After approximately ten con-
secutive complete opening/
closing movements of the win-

dow, a protection function is activated
to prevent damage to the electric win-
dow motor.
After this, you have approximately
one minute within which to close the
window.
Once the window is closed, the con-

trols will become available again af-

ter approximately 40 minutes.

Peugeot 3008 Dag (2010.5). Instruction - part 5
