Peugeot 807 (2013 year). Instruction

9.5

A press on the dial gives access to

short-cut menus according to the

display in the screen.

GENERAL OPERATION

DISPLAY ACCORDING TO CONTEXT

RADIO:

Activate / Deactivate TA

Activate / Deactivate RDS

MUSIC MEDIA PLAYERS,

CD or USB (according to

media):

Play modes:

Normal

Random

Random on all media

Repetition

TELEPHONE

(call in progress):

Private mode

FULL SCREEN MAP OR IN A

NEW WINDOW:

Stop / Restore guidance

Select destination

Enter an address

Directory

GPS coordinates

Divert route

Move the map

Info. on location

Select as destination

Select as stage

Save this place (contacts)

Quit map mode

Guidance criteria

Put call on hold

DTMF ring tones

Hang up

Change waveband

9.6

03 STEERING MOUNTED CONTROLS

RADIO: select the previous/next preset

station.
Select the next entry in the address book.

Change the audio source.
Start a call from the address book.
Call/End call on the telephone.
Press for more than 2 seconds:

access to the address book.

RADIO: change to the previous radio

station in the list.
Long press: automatic search for a

lower frequency.
CD: select the previous track.
CD: continuous press: fast reverse.

RADIO: change to the next radio station

in the list.
Long press: automatic search for a

higher frequency.
CD: select the next track.
CD: continuous press: fast forward play.

Volume increase.

Volume decrease.

Mute: press the volume

increase and decrease

buttons simultaneously.
Restore the sound by

pressing one of the two

volume buttons.

9.7

04 AUDIO SETTINGS

They are accessible by the MUSIC

button in the control panel or by a long

press on RADIO according to the source

in use.

- "

Equalizer" (choice of 6 musical ambiences)

- "

Bass"

"Treble"

"Loudness" (Activate/Deactivate)

"Distribution" (" Driver ", "

All passengers ")

"Le-Ri balance " (Left/Right)

- "

Fr-Re balance " (Front/Rear)

- "

Auto. Volume " depending on road speed (Activate/Deactivate)

The audio settings (Equalizer,

r Bass , Treble and Loudness ) are

different and independent for each sound source.
The settings for distribution and balance are common to all sources.

The distribution (or spatialisation using the Arkamys

system) of sound

is an audio process that allows the audio quality to be adapted to the

number of listeners in the vehicle.

9.8

""""""""""""

Navigation guidance

Navigation - guidance

Navigation guidance

N i

""""""""""""

To delete the list of recent destinations, select "Guidance

options" in the navigation menu then select "Delete last

destinations" and confi rm. Select "Yes" then confi rm.
Deleting just one destination is not possible.

Go from the list to the menu (left/right).

NAVIGATION - GUIDANCE

Access to the "NAVIGATION" menu

Press NAV.

Contact a PEUGEOT

dealer for mapping

updates.

A short press on the end of the

lighting control stalk repeats

the last navigation message.

9.9

NAV to display the

"Navigation - guidance " menu.

TOWARDS A NEW DESTINATION

NAVIGATION - GUIDANCE

SELECTING A DESTINATION

Select "Select destination " and

confi rm, then select " Enter an address"

and confi rm.

Select the " Country " function then

confi rm.

Select "Town" function then confi rm to

enter the destination town.

Select the letters in the name of the

town one at a time, confi rming each one

with the dial.

Selection the town from the list offered, then confi rm
A pre-set list (by entering the fi rst few letters) of the towns in the country selected

can be accessed directly by selecting and confi rming " List" on the screen.

Turn the dial and select "OK" then

confi rm.

If possible, enter the " Road " and "N°/X"

information in the same way.

Select "Archive " to save the address entered in a contact fi le.
The system allows up to 400 contact fi les to be recorded.

Confi rm " OK " to start guidance.

Select the guidance criteria: "Fastest

route", " Shortest route" or optimised

"Distance/Time ", then select the

desired restriction criteria: "With tolls",

"With Ferry", or "Traffi c info" then

confi rm "OK".

9.10

SELECTING A DESTINATION

NAVIGATION - GUIDANCE

TO ONE OF THE RECENT DESTINATIONS

Press NAV to display the

"Navigation - guidance" menu.

Select the desired destination and

confi rm to start guidance.

TOWARDS A CONTACT IN THE CONTACTS DIRECTORY

Select " Select destination" and

confi rm, then select " Directory " and

confi rm.

Selection the desired destination from

your contacts and confi rm " OK " to start

the guidance.

Press NAV to display the

"Navigation - guidance " menu.

Navigation towards a contact imported from your telephone is only

possible if the address is compatible with the system.

9.11

Select "Select destination" and

confi rm, then select " GPS coordinates "

and confi rm.

Enter the GPS coordinates and confi rm

"OK " to start the guidance.

Press NAV to display the

"Navigation - guidance" menu.

NAVIGATION - GUIDANCE

TOWARDS GPS COORDINATES

TOWARDS A POINT ON THE MAP

With the map displayed, press OK to

display the contextual menu. Select

"Move the map " and confi rm.

Press OK to display the contextual

menu for " Move the map " mode.

Select " Select as destination " or

"Select as stage" and confi rm.

Move the cursor using the control to

identify the desired destination.

9.12

TOWARDS POINTS OF INTEREST (POI)

NAVIGATION - GUIDANCE

The points of interest (POI) indicate all of the service locations in the vicinity

(hotels, various businesses, airports...).

Select the " Enter an address " function

and confi rm, then select Select

destination and confi rm.

To select a POI close to your current

location, select "POI" and confi rm, then

select " Around the current place " and

confi rm.
To select a POI as a stage on the route,

select " POI" and confi rm, then select " On

the route" and confi rm.
To select a POI as a destination, fi rst

enter the country and town (see "Towards

a new destination"), select "POI" and

confi rm, fi nally select "Near" and confi rm.

Search for POIs in the categories

suggested in the following pages.

Select " Search by Name " to search for POIs by name and not by

proximity.

Select the POI and confi rm " OK" to start

the guidance.

Press NAV to display the

"Navigation - guidance" menu.

9.14

05 NAVIGATION - GUIDANCE

ALERT PARAMETERS
RISK AREAS

Select:
-  "Visual alert"
-  "Audible alert"
-

"Alert only in guidance"

"Overspeed alarm only".

The choice of time of notifi cation defi nes

how long in advance that Risk area

warnings are given.
Select " OK " to confi rm the screen.

Select " Guidance options " and confi rm,

then select "Set parameters for risk

areas " and confi rm.

These functions are only available if risk areas have been

downloaded and installed on the system.
The detailed procedure for updating risk area POIs can be found at

www.peugeot.com.

Press NAV to display the " Navigation -

guidance" menu.

9.15

05 NAVIGATION - GUIDANCE

ADDING A STAGE

Press NAV to display the

"Navigation - guidance " menu.

Select " Journey leg and route " then

confi rm.

Select " Close to " a route passing

close to the stage or " Strict " for a route

passing through the stage.
Confi rm " OK " to start the guidance, and

give a general indication of the guidance

route.

Select "Add a stage " then confi rm
The address of the stage is entered as

a destination, by "Enter an address",

a contact in " Directory ", or " Previous

destinations".

ORGANISING STAGES

To organise stages, carry out operations

1 to 2 again, then select " Order/delete

journey legs" and confi rm.

Select and confi rm to save the

modifi cations.

Select the stage that you want to move

in the order.

Select "Delete " to delete the stage.

9.16

05 NAVIGATION - GUIDANCE

ROUTE OPTIONS

CALCULATION CRITERIA

Select " Guidance options " and confi rm.

Select " OK " and confi rm to save the

modifi cations.

Select " Defi ne calculation criteria" and

confi rm.
This function allows modifi cation of:
- the

guidance criteria: (" Fastest

route", " Shortest route",

"Distance/Time "),

the exclusion criteria: (" With tolls"

or "With Ferry "),

- traffi c avoidance: (" Traffi c info ").

Press NAV to display the

"Navigation - guidance" menu.

If traffi c avoidance (Traffi c info) is selected, the system suggests

an alternative route if there is a delay on the guidance route.

9.17

05 NAVIGATION - GUIDANCE

Press NAV to display the

"Navigation - guidance" menu.

MAP MANAGEMENT

SELECTING THE POINTS OF INTEREST DISPLAYED ON

THE MAP

Select " Map management " and confi rm.

Select from the various categories the

ones that you want to display on the

screen.

Select "Map details" and confi rm.

Select " By default" to have only "Oil stations, garages" and

"Accident-prone area " appear on the map (if installed in the

system).

Select " OK " then confi rm and select

"OK" again then confi rm to save the

modifi cations.

9.18

05 NAVIGATION - GUIDANCE

Select " Map management " and confi rm.

Select:
-

"Vehicle direction" to have the map

follow the direction of travel,

"North direction" to keep the map

always North up,

"Perspective view " to display a

perspective view.

Select "Map orientation " and confi rm.

The colour of the map, different from the day and night mode, is

confi gured in the " SETUP" menu.

MAP ORIENTATION

Press NAV to display the

" Navigation - guidance" menu.

Street names are visible on the map from the 100 m scale.

9.19

05 NAVIGATION - GUIDANCE

Press NAV to display the

"Navigation - guidance" menu.

ADJUSTING THE GUIDANCE SPEECH SYNTHESIS

Select " Guidance options " and confi rm.

ADJUSTING THE VOLUME/DEACTIVATION

Select " Set speech synthesis" and

confi rm.

Select the volume graph and confi rm.

Select "Deactivate " to deactivate voice messages.

Select " OK " and press the dial to

confi rm.

Adjust the volume to the desired level

and confi rm.

The volume of messages can be adjusted during the transmission

of the message using the volume adjustment control.

The volume setting of guidance messages is also accessible via the

"SETUP" / " Voice synthesis " menu.
