Peugeot 807 (2013 year). Instruction

9.21

06 TRAFFIC INFORMATION

Access to the "TRAFFIC INFORMATION" menu

Go from the list to the menu (left/right).

""""""" a c

at o

Traffi c information

Traffic information

T ffi i f

"""""""

Press "TRAFFIC".

9.22

06 TRAFFIC INFORMATION

CONFIGURE THE FILTERING AND DISPLAY OF TMC MESSAGES

TMC (Traffi c Message Channel) messages contain information on traffi c and weather conditions, received in real time and transmitted to the

driver in the form of audible announcements and symbols on the navigation map.
The navigation system can then suggest an alternative route to avoid a traffi c problem.

Press the TRAFFIC button to display the

Traffi c information menu.

Select the "Geographic fi lter" function

and confi rm.

The system offers a choice of:
- "

Retain all the messages",

or
-

"Retain the messages"

● "Around the vehicle ", (confi rm

the mileage to modify and select

the distance),

● "

On the route".

Confi rm " OK " to save the modifi cations.

We recommend:
-

a fi lter on the route and

a fi lter around the vehicle of:

- 12

miles

(20 km) in urban areas,

- 30

miles

(50 km) on motorways.

9.23

06 TRAFFIC INFORMATION

PRINCIPAL TMC SYMBOLS

Red and yellow triangle: traffi c information, for example:

Black and blue triangle: general information, for example:

RECEIVING TA MESSAGES

The TA (Traffi c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffi c report

is transmitted, the current audio source (Radio, CD, USB, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

Press RADIO to display the "FM / AM

band " menu.

Select " Guidance options " then

confi rm.

Activate or deactivate " TA " then confi rm.

The volume setting for TA messages can be adjusted only during the

transmission of this type of alert.

Activate or deactivate the function at any time by pressing the button.
During a message, press the button to interrupt it.

9.25

07 USING THE TELEPHONE

Access to the "TELEPHONE" menu

"""""""

e ep o e

Telephone

T l

"""""""

Go from the list to the menu (left/right).

Press PHONE .

To make a call, select a number in the list and confi rm "OK"

to start the call.

Connecting a different telephone deletes the list of

recent calls.

No telephone connected.

Telephone connected.

Incoming call.

Outgoing call.

Synchronisation

of address book in

progress.
Telephone call in

progress.

In the top bar of the permanent

display

9.26

PAIRING A BLUETOOTH TELEPHONE
FIRST CONNECTION

For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the audio unit must be

carried out with the vehicle stationary.

Activate the telephone's Bluetooth

function and ensure that it is "shown to

all" (telephone confi guration).

Press this button.

Select the name of the desired

peripheral from the list of devices

detected then select "Connect " and

confi rm.

The system offers to connect the

telephone:
-

in "Hands-free mode" (telephone

only),

in "Audio" mode (streaming: playing

music fi les on the telephone),

or "All " (for selection of both

modes).

Select " OK " and confi rm.

Select " Bluetooth functions " and

confi rm.

Select "Peripherals search" and

confi rm.
The list of peripherals detected is

displayed. Wait until the " Connect"

button is available.

USING THE TELEPHONE

Visit www.peugeot.co.uk for more information (compatibility,

additional help, ...).

9.27

Enter the same code on the telephone then accept

the connection.

Then accept automatic connection on the telephone to allow the

telephone to reconnect automatically every time the vehicle is

started.

The ability of the system to connect in only one mode depends on

the telephone. The two modes may both connect by default.

USING THE TELEPHONE

The "Hands-free mode " should be used in preference if

"Streaming" is not desired.

The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services available to you.

Select a code for the connection then

confi rm "OK".

Depending on the type of telephone, the system will ask you to

accept or not the transfer of your contacts.

On return to the vehicle,the last telephone connected

automatically reconnects, within around 30 seconds after

switching on the ignition (Bluetooth activated and visible).
To modify the automatic connection mode, remove the pairing

and pair the telephone again with the desired mode.

9.28

07 USING THE TELEPHONE

DIRECTORY / SYNCHRONIZING CONTACTS

Press PHONE then select " Contacts

management " and confi rm.

Select "New contact " to enter a new

contact.

Select "Sort by Name/First name" to

choose the order in which they appear.

Select "Delete all contacts" to delete

the contacts saved in the system.

Selection "Synchronization options":
- No

synchronization: only the

contacts saved in the system

(always present).

Display telephone contacts: only the

contacts saved in the telephone.

- Display SIM card contacts: only the

contacts saved on the SIM card.

- Display all phone contacts:

contacts on the SIM card and in the

telephone.

Select "Import all the entries" to import

all the contacts in the telephone and

save them in the system.
Once imported, a contact remains visible

whatever telephone is connected.

Select "Contact mem. status" to see the

number of contacts saved in the system

or imported, and the free memory.

9.29

MANAGING CONTACTS

Press PHONE then select "Directory of

contacts" and confi rm.

Select the desired contact and confi rm.

Select " Import" to copy one contact to

the system.

Select " Call" to start the call.

Select " Open " to view an external contact

or modify a contact saved in the system.

Select OK

Select " Delete" to delete a contact saved

in the system.

It is necessary to import an external contact to modify the record.

It will be saved in the system. It is not possible to modify or delete

contacts in the telephone or the SIM card via the Bluetooth

connection.

USING THE TELEPHONE

press the back button to exit this menu.

9.30

07 USING THE TELEPHONE

Press PHONE twice.

Select " Dial" then confi rm.

Select " Directory of contacts" then

confi rm.

Dial the telephone number using the

virtual keypad selecting each number

in turn.
Confi rm " OK " to make the call.

Press TEL or twice on PHONE.

CALLING A NEW NUMBER CALLING

CONTACT

Select the desired contact and confi rm.
If access was via the PHONE button,

select "Call" and confi rm.

Select the number and confi rm to start

the call.

MAKING A CALL

Use of the telephone is not recommended while driving. We

recommended that you park safely or make use of the steering

mounted controls.

9.31

07 USING THE TELEPHONE

CALLING A RECENTLY ENTERED NUMBER

Press TEL, select "Call list" and

confi rm,

Select the desired number and confi rm.

To erase the calls log, press PHONE twice, select " Phone

functions" and confi rm then select " Delete calls log" and

confi rm.

ENDING A CALL

Press PHONE then select "OK" to end

the call.

Or make a long press on TEL at the

steering mounted controls.

Or make two short presses on TEL at

the steering mounted controls.

Or press the MODE button, as many

times as necessary, until the telephone

screen is displayed.

press PHONE to display the calls log.

Press "OK" to display the contextual

menu then select " Hang up" and

confi rm.

9.32

07 USING THE TELEPHONE

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

on the screen.

"Yes" to accept the call is selected by

default.
Press " OK" to accept the call.
Select " No" and confi rm to reject the

call.

A short press on TEL accepts an

incoming call.
A long press on TEL rejects an incoming

call.

9.33

OPTIONS DURING A CALL *

During a call, press the MODE button

several times to select display of the

telephone screen, then press " OK " to

open the contextual menu.

Select " Private mode " and confi rm to

take the call on the handset.
Or select " Hands-free mode" and

confi rm to take the call via the vehicle's

speakers.

Select " Put call on hold" and confi rm to

put the current call on hold.
Or select " Resume the call" and

confi rm to resume the call on hold.

Select " DTMF ring tones " to use the

numerical keypad, so as to navigate

through the menu of an interactive vocal

server.

Select " Hang up " to end the call.

* Depending on the compatibility of the phone and your service plan.

it is possible to hold a 3-way conference

call by making 2 calls in succession*.

Select "Conference mode call" in the

contextual menu accessible using this

button.

Or make a short press on this button.

9.34

Press PHONE twice.

Select " List of the paired peripherals"

and confi rm.

It is possible to:
-

"Connect" or " Disconnect " the

selected telephone,

delete the pairing of the selected

telephone.

It is also possible to select all pairings.

USING THE TELEPHONE

MANAGING PAIRED TELEPHONES

CHANGING THE RING TONE

Press PHONE twice.

Select " Phone functions " and confi rm.

Select " Ring options" and confi rm.

You can adjust the volume and the type

of ring tone.

Select " Bluetooth functions".

Select " OK " and confi rm to save the

changes.

9.36

08 RADIO

Access to the "RADIO" menu

""""""""FM / AM band

FM / AM band

FM / AM b

""""""""

Press

or or use the rotary control to select the

previous or next station in the list.

Go from the list to the menu (left/right).

Press RADIO.
