Peugeot 807 Dag (2007.5). Instruction

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

SOURCE

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

BAND

SOURCE

BAND

ESC

MENU

LIST

ESC

LIST

MENU

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

AUDIO/VIDEO

RADIO

SELECTING A STATION

Press the SOURCE button several

times in succession and select the

RADIO.

Press the BAND button to select a

waveband: FM1, FM2, FMast, AM.

Brieﬂy press one of the buttons to

carry out an automatic search of the

radio stations.

Press one of the buttons to carry out a

manual search of the radio stations.

Press the LIST button to display the

list of stations received locally

(60 maximum).

To update this list, press for more than

two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...) may block

reception, including in RDS mode. This is a normal effect of the way in which radio

waves are transmitted and does not indicate any failure of the audio equipment.

RDS

Select ACTIVATE FREQUENCY

FOLLOWING (RDS) then press OK.

RDS appears on the display.

Select the RADIO PREFERENCES

function then press OK.

Select AUDIO FUNCTIONS then

press OK.

Press the MENU button.

The RDS, if displayed, enables you to continue listening to the

same station by means of frequency following. However, in certain

conditions, this RDS station is not followed throughout the country

as radio stations do not cover 100 % of the territory. This explains

the loss of reception of the station during a journey.

RADIO PREFERENCES

ACTIVATE FREQUENCY FOLLOWING (RDS)

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

SOURCE

ESC

MENU

LIST

SOURCE

LIST

S
O
S

SOURCE

MODE

BAND

ESC

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

MENU

LIST

TA PTY

DARK

AUDIO/VIDEO

MP3 CD

INFORMATION AND ADVICE

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music ﬁles on a single disc.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select standards ISO 9660 level 1.2 or Joliet. If the

disc is recorded in another format, it may not be played correctly.

It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

The audio equipment will only play audio ﬁles with the extension

".mp3" with a sampling rate of 22.05 KHz or 44.1 KHz. No other type

of ﬁle (.wma, .mp4, m3u...) can be played.

It is advisable to restrict ﬁle names to 20 characters without using

special characters (e.g.: " " ? ; ù) to avoid any playing or displaying

problems.

PLAYING A CD OR AN MP3 COMPILATION

Insert circular compact discs only. Some anti-pirating

systems, on original discs or CDs copied using

a personal recorder, may generate malfunctions

regardless of the quality of the original player.

Insert an audio CD or an MP3 compilation in the player,

play begins automatically.

If the player already contains a disc,

press the SOURCE button several

times in succession and select CD to

listen to it.

Press one of the buttons to select a

track on the CD.

Press the LIST button to display

the list of tracks on the CD or of the

directories of the MP3 compilation.

The playing and displaying of an MP3 compilation may depend on

the recording programme and/or the parameter settings used. We

recommend use of the ISO 9660 recording standard.

S
O
S

SOURCE

MODE

BAND

ESC

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

MENU

LIST

TA PTY

DARK

ESC

LIST

MENU

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

COPY CD TO JUKEBOX

COMPLETE CD

CREATE ALBUM

Select COPY CD TO JUKEBOX and

press the dial to conﬁrm.

Select COMPLETE CD to copy

the entire CD and press the dial to

conﬁrm.

Select CREATE ALBUM and press

the dial to conﬁrm.

The AUTO CREATION tab automatically copies the CD by default

into an album of the type "album n°...".

The audio or MP3 CD is copied onto the hard disc. Copying may

take approximately 20 minutes depending on the duration of the CD.

During this copying phase, it is not possible to listen to the albums

previously recorded on the hard disc or the CDs.

Select the letters one by one and select

OK to conﬁrm.

If it is not an MP3 CD, the Jukebox automatically compresses

the CD in MP3 format. The compression may take approximately

20 minutes depending on the duration of the CD. During this

compression phase, it is possible to listen to the CD or to albums

previously recorded on the hard disc.

A long press on the SOURCE button starts the copying of the CD.

When copying an MP3 CD, the Jukebox only retains the last album

level. It is not possible to copy ﬁles from the Jukebox to a CD.

The STOP THE CD COPY action does not delete the ﬁles which

have already been transferred onto the jukebox hard disc.

Select AUDIO FUNCTIONS and press

the dial to conﬁrm.

Insert a CD or an MP3 compilation

and press the MENU button.

JUKEBOX FUNCTION

COPYING A CD ONTO THE HARD DISC

ESC

MENU

LIST

ESC

MENU

LIST

ESC

LIST

MENU

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

JUKEBOX

RENAME

JUKEBOX MANAGEMENT

JUKEBOX FUNCTION

RENAMING AN ALBUM

Press the MENU button.

Select AUDIO FUNCTIONS and

press the dial to conﬁrm.

Select the JUKEBOX function and

press the dial to conﬁrm.

Select the JUKEBOX MANAGEMENT

function and press the dial to conﬁrm.

Select the album to be renamed and

press the dial to conﬁrm.

Select the RENAME tab and press the

dial to conﬁrm.

Turn the dial and select the letters of

the album title one by one conﬁrming

each time by pressing the dial.

Use the alphanumeric keypad to enter the letters of the album title

one by one.

SOURCE

ESC

MENU

LIST

ESC

MENU

LIST

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

SOURCE

ESC

MENU

LIST

ESC

MENU

LIST

JUKEBOX FUNCTION

LISTENING TO THE JUKEBOX

Press the SOURCE button several

times in succession and select the

JUKEBOX function.

Press the LIST button.

Turn the dial to select the ﬁles.

Press the ESC button to return to the ﬁrst ﬁle level.

JUKEBOX

Select OK and press the dial to

conﬁrm.

To rename the tracks of an album, follow the same procedure,

selecting the tracks to be renamed.

Use the ESC button to exit from the list of tracks.

Select the DELETE function to delete an album or a

track from the Jukebox.

DELETE

SOURCE

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

SOURCE

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

SOURCE

ESC

MENU

LIST

100

Press the MENU button then select the CONFIGURATION function,

then SOUNDS, then ACTIVATE AUXILIARY SOURCE to activate

the auxiliary input of the RT4 GPS audio/telephone.

Connect the portable equipment (MP3

player…) to the audio sockets (white and

red, RCA type) located in the glove box

using a JACK/RCA audio cable.

Press the SOURCE button several

times in succession and select AUX.

CD CHANGER

PLAYING A CD (NOT MP3 COMPATIBLE)

Insert one or more CDs in the

changer.

Press the SOURCE button several

times in succession and select CD

CHANGER.

Press one of the buttons on the

alphanumeric keypad to select the

corresponding CD.

Press one of the buttons to select a

track on the CD.

The displaying and management of the commands takes place via

the portable equipment.

It is not possible to copy the ﬁles onto the hard disc from the auxiliary

input.

It is not possible to copy the ﬁles onto the hard disc from the CD

changer.

USING THE AUXILIARY INPUT (AUX)

JACK/RCA AUDIO CABLE NOT SUPPLIED

ESC

MENU

LIST

MENU

ESC

LIST

MENU

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

You can connect video equipment (camcorder, digital camera, DVD player...) to the

three audio/video sockets, located in the glove box.

Turn the dial and select the VIDEO

function.

After connecting the video equipment,

press the MENU button.

Turn the dial and select the

ACTIVATE VIDEO MODE function to

activate/deactivate the video.

Press the dial to conﬁrm the selection.

ACTIVATE VIDEO MODE

Press the dial to conﬁrm the selection.

Pressing the "SOURCE" button several times in succession permits

the selection of an audio source other than that of the video.

Pressing the "MODE" or "DARK" button disconnects the displaying

of the video.

Turn the dial and select the VIDEO

PARAMETERS function to set the

display format, the brightness, the

contrast and the colours.

Press the dial to conﬁrm the selection.

VIDEO MENU

VIDEO PARAMETERS

Videos can only be displayed when stationary.

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

ESC

MENU

LIST

ESC

MENU

LIST

ESC

MENU

LIST

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

102

TELEPHONE

INSTALLING YOUR SIM CARD

(NOT SUPPLIED)

ENTERING THE PIN CODE

Access the slot by pressing the button

using the tip of a pen.

Install the SIM card

in the holder and

then insert it in the

slot.

To remove the SIM card, repeat step 1.

Your SIM card must be installed and removed with the RT4 GPS

audio/telephone switched off and the ignition off.

Enter the PIN code on the keypad.

Conﬁrm the PIN code by pressing button #.

PIN CODE

When entering your PIN code, tick the STORE PIN tab to gain access to the

telephone without having to enter this code when it is used subsequently.

abc

jkl

tuv

def

mno

wxyz

ghi

pqrs

ESC

MENU

LIST

ESC

MENU

LIST

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

TELEPHONE

CALLING A CONTACT

Turn the dial and select the DIAL

function.

Press the PICK UP button to display

the superimposed telephone menu.

Press the dial to conﬁrm the selection.

Dial the telephone number of your

contact using the alphanumeric

keypad.

Press the PICK UP button to call the

number dialled.

Press the HANG UP button to end

the call.

ACCEPTING OR REFUSING A CALL

Press the PICK UP button to accept

a call.

Press the HANG UP button to refuse

a call.

DIAL

Press the end of the steering wheel stalk for more

than 2 seconds to access the telephone menu:

calls log, directory, voice mailbox.

S
O
S

SOURCE

MODE

BAND

T PT

A Y

DARK

abc

jkl

tuv

def

mno

wxyz

ghi

pq s

ESC

MENU

LIST

ESC

MENU

LIST

104

EMERGENCY CALL

* On condition that the PEUGEOT Emergency contract has been signed.

This is free and of unlimited duration. Contact a PEUGEOT dealer.

In an emergency, press the SOS

button until an audible signal is

heard and a CONFIRMATION/

CANCELLATION screen is displayed

(if valid SIM card inserted).

A call is made to the emergency

services (112).

In certain countries*, this emergency

call is made directly by the PEUGEOT

Emergency team which locates the

vehicle and alerts the appropriate

emergency services as quickly as

possible.

PEUGEOT ASSISTANCE

CUSTOMER CONTACT CENTRE

When the PEUGEOT Emergency contract has been signed, it

is recommended that an initial call is made to the PEUGEOT

Emergency team.

CONSULTING THE SERVICES

Press the LION button to gain access

to the PEUGEOT services*.

Select CUSTOMER CONTACT

CENTRE to request any information

about the PEUGEOT marque.

Select PEUGEOT ASSISTANCE to

make a breakdown assistance call.

* These services and options are subject to conditions and availability.

106

A few deﬁnitions

Range: Displays the distance which can be travelled with the remaining fuel

detected in the tank, in relation to the average consumption over the last

few miles (kilometres).

This displayed value may vary signiﬁcantly following a change in the

vehicle speed or the relief of the route.

When the range falls below 20 miles (30 km), dashes are displayed. After

ﬁlling with at least 5 litres of fuel, the range is recalculated and is displayed

when it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of digits, contact

a PEUGEOT dealer.

Current consumption: only calculated and displayed above 20 mph

(30 km/h).

Average consumption: this is the average quantity of fuel consumed since

the last trip recorder zero reset.

Distance travelled: calculated since the last trip computer zero reset.

Distance remaining to the destination: calculated with reference to the

ﬁnal destination, entered by the user. If guidance is activated, the navigation

system calculates it as a current value.

Average speed: this is the average speed calculated since the last trip

computer zero reset (ignition on).

TRIP COMPUTER

With tab

"1" (route 1):

• the average speed, the average consumption and the distance

travelled calculated over route

"1".

Tab

"2" (route 2) with the same functions for a second route.

IMAGE A CREER,

DEMANDE DE

VISUEL A DDB

On-board computer

Instantaneous info.
Range

miles

mph

l/100

460

6.5

RADIO: selection of the previous stored station.

MP3/JUKEBOX: selection of the previous directory.

CD CHANGER: selection of the previous CD.

Selection of the previous item on a menu.

RADIO: selection of the next stored station.

MP3/JUKEBOX: selection of the next directory.

CD CHANGER: selection of the next CD.

Selection of the next item on a menu.

RADIO: automatic search for a higher frequency.

CD/MP3/JUKEBOX/CD CHANGER: selection of the

next track.

CD/CD CHANGER: continuous press: fast forwards

play.

RADIO: automatic search for a lower frequency.

CD/MP3/JUKEBOX/CD CHANGER: selection of the

previous track.

CD/CD CHANGER: continuous press: fast backwards

play.

- Change of sound source.

- Conﬁrmation of a selection.

- Pick up/Hang up the telephone.

- Press for more than 2 seconds:

access to the telephone menu.

Volume increase.

Volume decrease.

CONTROL SHORT-CUTS

STEERING WHEEL CONTROLS

Mute: by pressing the volume

increase and decrease

buttons simultaneously.

The sound is restored by

pressing one of the two

volume buttons.

MENU

ESC

LIST

MENU

Press the end of the lights stalk to start the voice

recognition.

Say the words one by one and wait for the audible

conﬁrmation signal between each word.

The list which follows is exhaustive.

VOICE COMMANDS

DISPLAYING THE LIST AND USING THEM

To display the list of available voice commands,

press the end of the lights stalk to start the voice

recognition, then say HELP or WHAT CAN I SAY.

For the same operation, press and

hold the MENU button and select the

function VOICE COMMANDS LIST.

VOICE COMMANDS LIST

LEVEL 1

display

call

changer

guide to

trafﬁc info

CD player/jukebox

navigation

radio

SMS/message

telephone

LEVEL 2

audio

guidance

navigation

trip computer

telephone

description

disc number

previous/next disc

random play

list

track number

previous/next track

repeat

scan

description

display

read

random play

list

track number

previous/next track

directory (MP3 CD)

scan

stop/resume

Peugeot 807 Dag (2007.5). Instruction - part 7
