Peugeot 508 Hybrid Dag (2012.5). Instruction

303

04 AUDIO

Radio text is information transmitted by the radio station related

to the current programme or song.

With the radio displayed on the screen,

press OK to display the contextual menu.

Select "RadioText (TXT) display" and

confi rm OK to save.

DISPLAY RADIO TEXT

The INFO function gives priority to TA alert messages. To be

active, this function needs good reception of a radio station that

transmits this type of message. When a message is transmitted,

the current audio source (Radio, CD, USB, ...) is interrupted

automatically to receive the INFO message. Normal play resumes

at the end of the message transmission.

Make a long press on TA INFO to

display the list of categories.

LISTENING TO INFO MESSAGES

Select or deselect categories to activate

or deactivate the reception of the

corresponding messages.

SCREEN C

304

04 AUDIO

AUDIO CD

Insert 12 cm diameter circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no refl ection on the

quality of the original player.
Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

To play a disc which has already been

inserted, press the SOURCE or SRC

button several times in succession and

select " CD".

Press one of the buttons to select a

track on the CD.

PLAYING A CD

Press LIST to display the list of tracks

on the CD.

Press and hold one of the buttons for

fast forward or backward.

305

04 AUDIO

CD, USB

INFORMATION AND ADVICE

On a single disc, the CD player can read up to 255 MP3 fi les spread

over 8 directory levels. However, it is recommended that this be kept

to 2 levels so as to limit the time taken to access and play the CD.
During play, the folder structure is not observed.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select standards ISO 9660 level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is

recommended.

Do not connect a hard disk or USB device other than audio players to

the USB port. This may cause damage to your installation.

The audio system will only play fi les with extension ".mp3" or ".wma"

and a compression rate that is constant or variable between 32 Kbps

and 320 Kbps.

It is advisable to restrict fi le names to 20 characters without using

special characters (e.g. " ? ; ù) to avoid any playing or displaying

problems.

The playlists accepted are types .m3u and .pls.
The number of fi les is limited to 5 000 in 500 directories on a

maximum of 8 levels.

306

CD, USB

AUDIO

PLAYING A COMPILATION

Insert an MP3 compilation in the CD player or

connect a memory stick to the USB port, directly or

via an extension lead.

The system creates playlists (temporary memory) the creation time

for which can take from a few seconds to several minutes.
The playlists are updated every time the ignition is switched off or a

USB memory stick is connected.
Play starts automatically after a period which depends on the

capacity of the USB memory stick.

At a fi rst connection, the order suggested is by folder.

When connecting again, the order previously chosen is

retained.

To play a disc or memory stick which

has already been inserted, press

SOURCE or SRC several times in

succession and select " CD" or "USB".

Press one of the buttons to select the

next or previous track.

Press one of the buttons to select the

next or previous folder in the order

chosen.

Press and hold one of the buttons for

fast forwards or backwards.

Press LIST to display the menu of

folders in the compilation.

307

Select a line in the list.

Select a track or a folder.

Skip a track.

Up a level in the menu.

AUDIO

USB MEMORY STICK - FILE CLASSIFICATION

Having selected the desired classifi cation

(" By folders", " By artists", " By genres",

"By playlists ") press OK.
Then confi rm OK to save the modifi cations.
-

By folders: all folders containing audio

fi les recognised on the peripheral device,

in alphabetical order without following the

folder structure.

By artists : all of the artist names defi ned

in the ID3 Tags, in alphabetical order.

By genres : all of the genres defi ned in the

ID3 Tags.

By playlists : if playlists have been saved.

Make a long press on LIST or press

MENU , select " Multimedia ", then "Media

parameters " and fi nally " Choice of

track listing " to display the different

classifi cations.

308

04 AUDIO

APPLE

PLAYERS or PORTABLE PLAYER

Management of the device is via the audio system controls.

The audio fi les on a Mass Storage portable player * can

be heard through the vehicle's speakers by connecting

it to the USB port (cable not supplied).

If the portable player is not recognised by the USB port,

connect it to the auxiliary Jack socket.

The Apple

player must be updated regularly for the best

connection.

The playlists are those defi ned in the Apple

player.

The Apple

player must be generation 5 or later.

* Check your player's manual.

309

04 AUDIO

AUXILIARY SOCKET (AUX)

AUXILIARY JACK SOCKET

Do not connect a device to the USB port and to the auxiliary

Jack socket at the same time.

The auxiliary Jack socket permits the connection of a portable

non-mass storage device or an Apple

player if not recognised

by the USB port.

Connect the portable device to the auxiliary Jack socket using

a suitable cable (not supplied).

Press the SOURCE or SRC button

several times in succession and select

"AUX".

First adjust the volume on your portable device.

Then adjust the volume of the audio

system.

The display and management of controls is on the

portable device.

310

04 AUDIO

STREAMING - PLAYING AUDIO FILES

VIA BLUETOOTH

Depending on the compatibility of the phone

Pair/connect the telephone: see the "USING THE

TELEPHONE" section.

Streaming allows music fi les on a telephone to be heard via the

vehicle's speakers.
The telephone must support the appropriate bluetooth profi les

(Profi les A2DP / AVRCP).

Activate the streaming source by pressing SOURCE or

SRC . Control of playback is via the audio system. The

contextual information can be displayed in the screen.

In certain cases, playing of the audio fi les must be initiated from

the telephone.

The audio quality depends on the quality of the transmission from

the telephone.

PLAY MODE

The play modes available are:
-

Normal: the tracks are played in order, depending on the

classifi cation of the selected fi les.

Random: the tracks in an album or folder are played in a

random order.

Random all: all of the tracks saved in the media are played in

random order.

Repeat: the tracks played are only those from the current

album or folder.

Press OK for access to the contextual

menu.
or
Press MENU.

Select "Multimedia" and confi rm.

Select "Media parameters " and

confi rm.

Select "Read mode " and confi rm.

Select the desired play mode and

confi rm OK to save the modifi cations.

311

05 USING THE TELEPHONE

PAIRING A TELEPHONE
FIRST CONNECTION

The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.
Consult your telephone's manual and your operator to fi nd out which services are available to you.

Activate the telephone's Bluetooth function and

ensure that it is "visible to all" (refer to the telephone

user guide).

Press MENU.

A window is displayed "Search in progress…".

Select the telephone to be connected

from the list. Only one telephone can

be connected at a time.

Select " Search for a device".

For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile

telephone with the Bluetooth hands-free system of your audio system must be carried out with the vehicle stationary and the ignition on.
Visit www.peugeot.co.uk for more information (compatibility, additional help, ...).

Select " Bluetooth connection" and

confi rm.

312

Saisir code authentification

Del

USING THE TELEPHONE

A virtual keypad is displayed on the

screen: enter a code with at least

4 digits and conform with OK .

A message is displayed on the screen of the

telephone: enter the same code and confi rm.

A message appears in the screen to confi rm the result of the

connection.

Pairing can also be initiated from the telephone by searching for

detected Bluetooth devices.

Accept the connection to the telephone.

If pairing fails, try again; the number of attempts is not limited.

The directory and the calls list can be accessed after the

synchronisation period (if the telephone is compatible).
Automatic connection must be confi gured in the telephone to allow

the connection each time the vehicle is started.

In some cases, the reference number of the telephone or the

Bluetooth address may appear instead of the name of the telephone.

Pair/connect the telephone then listen: see the AUDIO section.

STREAMING - PLAYING AUDIO FILES

VIA BLUETOOTH

313

05 USING THE TELEPHONE

The telephone connection automatically includes hands free operation

and audio streaming.
The ability of the system to connect to just one profi le depends on the

telephone. Both profi les may connect by default.

Press MENU.

Select " Bluetooth connection" and

confi rm.

Indicates connection of the audio steaming profi le.

MANAGING CONNECTIONS

Select " Connections management"

and confi rm. The list of paired

telephones is displayed.

Select a telephone and confi rm.

Indicates connection of the hands-free profi le.

Then select and confi rm:
-

"Connect telephone" / " Disconnect

telephone ": to connect / disconnect

the telephone or the hands-free

connection only.

"Connect media player" /

"Disconnect media player": to

connect / disconnect only streaming.

"Connect telephone + media

player" / "

Disconnect telephone +

media player ": to connect /

disconnect the telephone (hands-free

and streaming).

"Delete connection": to delete the

pairing.

Indicates that a device is connected.

314

05 USING THE TELEPHONE

To display the " TELEPHONE " menu:
- Make

along press on SOURCE or

SRC .

Or, press OK to display the contextual

menu. Select " Call " and confi rm.

Or, press MENU , select " Telephone"

and confi rm. Select "Call" and

confi rm.

Select "Dial " to enter a number and

confi rm.

To display the " TELEPHONE " menu:
-

Make a long press on SRC/TEL.

Or, press the dial to display the

contextual menu. Select " Call " and

confi rm.

Or, press MENU , select

" Telephone" and confi rm. Select

"Call " and confi rm.

Select OK and confi rm to start the

call.

Select "Calls list " and confi rm.

MAKING A CALL - DIALLING

Select numbers one at a time using

the

MAKING A CALL - RECENTLY CALLED

NUMBERS *

Select the number and confi rm

to start the call.

The calls list includes calls sent and received in the vehicle using

the connected telephone.

* Depending on the compatibility of the telephone.

Correction allows numbers to be deleted one at a time.

It is possible to make a call directly from the telephone; park the

vehicle fi rst as a safety measure.

315

05 USING THE TELEPHONE

To display the "TELEPHONE " menu:
-

Make a long press on SRC/TEL .

Or, press the dial to display the

contextual menu. Select " Call " and

confi rm.

Or, press MENU , select

"Telephone" and confi rm. Select

" Call " and confi rm.

Select "Directory " and confi rm.

An incoming call is announced by a ring and a superimposed display

in the multifunction screen.

Mobile
(depending on the information

available in the contact records of

the telephone connected).

"YES " to accept the call is selected

by default.
Press OK to accept the call.
Select " NO " and confi rm to reject the

call.
or
Press one of these buttons to accept

the call.

MAKING A CALL - FROM THE DIRECTORY

Select a contact then confi rm.

RECEIVING A CALL

Select the number and confi rm.

A long press on ESC or on TEL ,

SOURCE or SRC also rejects an

incoming call.

Business

Home

316

05 USING THE TELEPHONE

During a call, press OK to display the

contextual menu.

Hang up

In the contextual menu:
-

select " Micro OFF " to switch off the

microphone.

deselect " Micro OFF" to switch the

microphone on.

MANAGING CALLS

A long press on one of these buttons

also ends the call.

In the contextual menu, select

" Hang up" to end the call.

Secret - Mute
(so that the caller cannot hear)

317

In the contextual menu:
-

select "Telephone mode" to

transfer the call to the telephone.

deselect " Telephone mode " to

transfer the call to the vehicle.

In certain cases, the combined mode has to activated from the

telephone.
If the contact has been cut off, when you reconnect on returning to

the vehicle, the Bluetooth connection will be restored automatically

(depending on the compatibility of the telephone).

Combined mode
(to leave the vehicle without ending the call)

USING THE TELEPHONE

From the contextual menu, select

"DTMF tones " and confi rm to use

the digital keypad to navigate in the

interactive voice response menu.

From the contextual menu, select

"Switch" and conform to return to a call

left on hold.

Interactive voice response

Consultation call

318

05 USING THE TELEPHONE

DIRECTORY

The telephone directory is sent to the system, depending on the

compatibility of the telephone.
The directory is provisional and depends on the Bluetooth

connection.

Contacts imported from the telephone to the audio system directory

are saved in a permanent directory visible to all, whatever the

telephone connected.

To modify the contacts saved in the

system, press MENU then select

" Telephone" and confi rm.
Select "Directory management " and

confi rm.
You can:
-

"Consult an entry ",

"Delete an entry ",

"Delete all entries ".

Select "Directory " to see the list of

contacts.

Make a long press on SOURCE or SRC

for access to the directory
or press  OK, and
select "Call " and confi rm.

Peugeot 508 Hybrid Dag (2012.5). Instruction - part 20
