Peugeot 508 Hybrid Dag (2012.5). Instruction - part 18

271

06 USING THE TELEPHONE

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display

in the screen.

"Yes" to accept the call is selected by

default.
Press " OK" to accept the call.
Select " No" and confi rm to reject the

call.

A short press on this button or TEL/SRC

accepts an incoming call.

A long press on this button or TEL/SRC

or a press on HANG UP rejects an

incoming call.

272

OPTIONS DURING A CALL *

During a call, press the MODE button

several times to select display of the

telephone screen, then press " OK " to

open the contextual menu.

Select " Private mode " and confi rm to

take the call on the handset.
Or select " Hands-free mode" and

confi rm to take the call via the vehicle's

speakers.

Select " Put call on hold" and confi rm to

put the current call on hold.
Or select " Resume the call" and

confi rm to resume the call on hold.

Select " DTMF ring tones " to use the

numerical keypad, so as to navigate

through the menu of an interactive vocal

server.

Select " Hang up " to end the call.

* Depending on the compatibility of the phone and your service plan.

it is possible to hold a 3-way conference

call by making 2 calls in succession*.

Select "Conference mode call" in the

contextual menu accessible using this

button.

Or make a short press on this button.

273

Press this button.

Select " List of the paired peripherals"

and confi rm.

It is possible to:
-

"Connect" or " Disconnect " the

selected telephone,

delete the pairing of the selected

telephone.

It is also possible to select all pairings.

USING THE TELEPHONE

MANAGING PAIRED TELEPHONES

CHANGING THE RING TONE

Press this button.

Select " Telephone options" and

confi rm.

Select " Ring options" and confi rm.

You can adjust the volume and the ring

tone used.

Select" Bluetooth functions ".

Select " OK " and confi rm to save the

changes.

274

07 DIRECTORY - ADDR BOOK

Access to the "CONTACTS" menu

""""""""

yyyyy

Directory of contacts

t t

""""""""

""""""""""

p y

sp ay co tacts

Display contacts

t t

""""""""""

( O

" "

" "I

t" "

" "

" "D l t

D l t

D l t ")

"))

Destination:
-

from the contacts in the mobile telephone and the SIM

card (depending on the synchronization options in the

Bluetooth menu and the compatibility of the telephone),

saved in the system.

Select a contact and confi rm.
Then select "Guide " and confi rm.

Telephone contacts:
-

from the mobile telephone and the SIM card

(depending on the synchronization options in the

Bluetooth menu and the compatibility of the telephone),

saved in the system.

Press ADDR BOOK.

Select a telephone contact and confi rm to start the call.

The sorting of the list of

contacts depends on the

telephone used.

275

DIRECTORY / SYNCHRONIZING CONTACTS

Press ADDR BOOK twice then select

"New contact" to enter a new contact.

Press ADDR BOOK twice then select

" Confi guration" and confi rm.

Select "Delete all contacts" to delete

the contacts saved in the system.

Select "Import all the entries " to import

all the contacts in the telephone and

save them in the system.

Select "Synchronization options " and

confi rm:
- No

synchronization: only the

contacts saved in the system

(always present).

Display telephone contacts: only the

contacts saved in the telephone.

- Display

SIM card contacts: only the

contacts saved on the SIM card.

- Display all phone contacts:

contacts on the SIM card and in the

telephone.

Press ADDR BOOK twice then select"

Contact mem. status" to see the

number of contacts saved in the system

or imported, and the free memory.

DIRECTORY - ADDR BOOK

276

MANAGING CONTACTS

Press ADDR BOOK twice then select"

Display contacts" and confi rm.

Select the desired contact and confi rm.

Select " Import" to copy one contact to

the system.

Select" Open " to view an external contact

or modify a contact saved in the system.

Select OK

Select " Delete" to delete a contact saved

in the system.

It is necessary to import an external contact to modify the record.

It will be saved in the system. It is not possible to modify or delete

contacts in the telephone or the SIM card via the Bluetooth

connection.

DIRECTORY - ADDR BOOK

press this button to exit this menu.

277

08 RADIO

Access to the "RADIO" menu

""""""""FM / AM band

FM / AM band

FM / AM b

d""""""""

Press or or use the rotary control to select the

previous or next station in the list.

This list can also be displayed by pressing LIST on the

steering mounted controls.

Go from the list to the menu (left/right).

A long press on LIST refreshes

the list of stations received.

Press RADIO.

278

08 RADIO

By alphabetical list
Press RADIO or LIST , select the station

of your choice and confi rm.

By automatic frequency search
Press

for a lower or higher radio frequency.
Or turn the thumb wheel at the steering

mounted controls.

By manual frequency search
Press or to adjust the radio

frequency step by step.

Press the button on the numerical

keypad to recall a preset station.
Or press then turn the thumb wheel at

the steering mounted controls.

SELECTING A STATION

The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.

This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio

system.

PRESETTING A STATION

After selecting a station, press one of

the buttons on the numerical keypad for

2 seconds to preset the current station.
An audible signal confi rms that the

station has been preset.

The quality of reception is represented

by the number of active waves in this

symbol.

279

Press RADIO .

ACTIVATE / DEACTIVATE RDS

RDS, if activated, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception of

the station during a journey.

Select "Guidance options" and confi rm.

Select "Activate / Deactivate RDS " and

confi rm.

RADIO

Select " Activate / Deactivate RDS".

Radio displayed, press "OK " to display the contextual menu.

280

09 MUSIC MEDIA PLAYERS

Access to the "MUSIC MEDIA PLAYER" menu

""""""""MEDIA

MEDIA

MEDIA""""""""

This list can also be displayed by pressing LIST

at the steering mounted controls.

Go from the list to the menu (left/right).

Press MEDIA.

281

09 MUSIC MEDIA PLAYERS

CD, MP3 CD / USB PLAYER

The audio equipment will only play audio fi les with ".wma, .aac, .fl ac,

.ogg and .mp3" fi le extensions and with a bit rate of between 32 Kbps

and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of fi le (.mp4, .m3u...) can be played.
WMA fi les must be of the standard wma 9 type.
The sampling rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict fi le names to 20 characters, without using of

special characters (e.g.:" " ? ; ù) to avoid any playing and displaying

problems.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may not be played correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is

recommended.

INFORMATION AND ADVICE

The system supports USB mass storage or iPod

devices via the USB port (suitable cable not supplied).
Control of the peripheral device is with the audio

system controls.
Other peripherals, not recognised on connection, must

be connected to the auxiliary socket using a Jack cable

(not supplied).

In order to be read, a USB memory stick must be formatted FAT 16

or 32.

282

SOURCES

Insert the CD in the player, insert the USB memory

stick in the USB player or connect the USB

peripheral to the USB port using a suitable cable

(not supplied)
The system builds playlists (in temporary memory),

an operation which can take from a few seconds to

several minutes at the fi rst connection.
Reduce the number of non-music fi les and the

number of folders to reduce the waiting time.
The playlists are updated every time the ignition is

switched off or connection of a USB memory stick.

However, the system memorises these lists and

if they are not modifi ed, the loading time will be

shorter.
Play starts automatically after a period which

depends on the capacity of the USB memory stick.

SELECTION OF SOURCE

The SOURCE or SRC button on the steering mounted controls

allows a direct change to the next media source.

"CD / CD MP3 "

"USB, iPod"

"AUX "

"STREAMING "

"RADIO "

Press MEDIA to display the "MEDIA "

menu.

Select "Change media" and confi rm.

283

SELECTING A TRACK

MUSIC MEDIA PLAYERS

Previous track.

Next track.

Previous folder.

Next folder.

Fast forward.

Fast backward.

Pause: long press on SRC.

LIST: List of USB or CD tracks or

folders

Up or down in the list.

Confi rm, next menu level.

Up one menu level.

Long press

284

AUDIO STREAMING

Streaming allows audio fi les on your telephone to be played via the

vehicle's speakers.

Connect the telephone: see "USING THE TELEPHONE".
Select " Audio" or " All" profi le.

If play does not start automatically, it may be necessary to start the

audio playback from the telephone.
Control is from the peripheral device or by using the audio system

buttons.

Once connected in streaming mode, the telephone is considered to be

a media source.
It is recommended that you activate " Repeat" on the Bluetooth

peripheral.

MUSIC MEDIA PLAYERS

CONNECTING APPLE

PLAYERS

Connect the Apple

player to the USB port using a suitable cable

(not supplied).
Play starts automatically.

Control is via the audio system.

The classifi cations available are those of the portable device

connected (artists / albums / genres / playlists / audiobooks /

podcasts).
The default classifi cation used is by artist. To modify the classifi cation

used, return to the fi rst level of the menu then select the desired

classifi cation (playlists for example) and confi rm to go down through

the menu to the desired track.

The version of software in the audio system may not be compatible

with the generation of your Apple

player.

The list of devices compatible with software versions is available from

PEUGEOT dealers.

285

09 MUSIC MEDIA PLAYERS

USING THE AUXILIARY INPUT (AUX)
Cable not supplied

Connect the portable device (MP3 player…) to the auxiliary JACK

socket using an audio cable.

Press MEDIA to display the " MEDIA"

menu.

Select "Activate / Deactivate AUX

input " and confi rm.
First adjust the volume of your portable

device (to a high level). Then adjust the

volume of your audio system.

Display and management of the controls are via the portable device.

286

10 AUDIO SETTINGS

They are accessible by the MUSIC

button in the control panel or by a long

press on RADIO or MEDIA according to

the source in use.

- "

Equalizer" (choice of 6 musical ambiences)

- "

Bass"

- "

Treble "

"Loudness" (Activate/Deactivate)

"Distribution" (" Driver ", "

All passengers ")

"Le-Ri balance " (Left/Right)

" Fr-Re balance " (Front/Rear)

- "

Auto. Volume " depending on road speed (Activate/Deactivate)

The audio settings ( Equalizer,

r Bass , Treble and Loudness ) are

different and independent for each sound source.
The settings for distribution and balance are common to all sources.

The distribution (or spatialisation using the Arkamys

system) of sound

is an audio process that allows the audio quality to be adapted to the

number of listeners in the vehicle.

On-board Audio: Arkamys

Sound Staging.

With Sound Staging, the driver and passengers are immersed in an

"audio scene" recreating the natural atmosphere of an auditorium:

truly a part of the scene and its surroundings.
This new sensation is made possible by software in the audio system

which processes the digital signals from the media players (radio,

CD, MP3…) without changing the audio settings. This processing

takes account of the characteristics of the passenger compartment to

produce optimum results.
The Arkamys

software installed in your audio system processes the

digital signal from the media players (radio, CD, MP3, ...) and recreates

a natural musical scene, with harmonious placement of instruments and

voices in the space in front of passengers, level with the windscreen.

Content .. 16 17 18 19 ..
