Peugeot 508 Hybrid Dag (2012.5). Instruction - part 21

319

Press to display the audio settings

menu.

The settings available are:
-

Ambience,

Bass,

Treble,

- Loudness,
-

Distribution: Personalised or Driver,

Left / right balance,

- Fader

(front / rear balance),

Auto. volume.

AUDIO SETTINGS

SCREEN C

The distribution (or spatialisation using the Arkamys

system), is

an audio process which allows the sound quality to be improved

according to the setting chosen, corresponding to the position of the

listeners in the vehicle.

Select and confi rm " Other settings…"

to display the next setting in the list.

The Ambience, Treble and Bass audio settings are different and

independent for each sound source.

On-board Audio: Arkamys

Sound Staging.

With Sound Staging, the driver and passengers are immersed in an

"audio scene" recreating the natural atmosphere of an auditorium:

truly a part of the scene and its surroundings.
This new sensation is made possible by software in the audio

system which processes the digital signals from the media players

(radio, CD, MP3…) without changing the audio settings. This

processing takes account of the characteristics of the passenger

compartment to produce optimum results.
The Arkamys

software installed in your audio system processes

the digital signal from the media players (radio, CD, MP3, ...) and

recreates a natural musical scene, with harmonious placement of

instruments and voices in the space in front of passengers, level

with the windscreen.

320

SCREEN C

Multimedia

Media parameters

Choice of playback mode

Choice of track listing

Telephone

Call

Dial

Directory

Calls list

Voice mail box

Directory management

Consult an entry

Delete an entry

Delete all entries

Telephone management

Telephone status

Hang up

Normal

Random

Random all

Repeat

By folders

By artists

By genres

By playlists

Radio parameters

SCREEN MENU MAP

MAIN FUNCTION

Option A1

Option A2

OPTION A

OPTION B

321

07 SCREEN MENU MAP

Personalisation-

configuration

Choice of language

Display confi guration

Bluetooth connection

Connections management

Choice of units

Date and time adjustment

Display parameters

Brightness

Search for a device

322

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Fader, Left-Right Balance) to the middle position,

select the musical ambience "None" and set the

loudness correction to the "Active" position in CD

mode or to the "Inactive" position in radio mode.

When changing the

settings for treble and

bass, the ambience

setting is deselected.
When changing the

ambience setting, treble

and bass are reset to

zero.

Choosing an ambience imposes settings for treble and bass. Modifying

one without the other is not possible.

Modify the treble and bass settings or the

ambience setting to obtain the desired sound

quality.

When changing the

balance setting,

distribution is deselected.

Choosing a distribution setting imposes a balance setting. Modifying one

without the other is not possible.

Modify the balance setting or the distribution

setting to obtain the desired sound quality.

The following tables contain answers to the most frequently asked questions.

323

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 MHz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

The traffi c announcement

(TA) is displayed. I do

not receive any traffi c

information.

The radio station does not broadcast traffi c information.

Tune to a radio station which broadcasts traffi c

information.

The stored stations are

not found (no sound,

87.5 MHz is displayed...).

An incorrect waveband is selected.

Press the BAND button to return to the waveband

on which the stations are stored.

324

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

Check that the CD is inserted in the player the

right way up.

Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

The audio equipment's CD player does not

play DVDs.

Due to their quality level, certain writeable

CDs will not be played by the audio system.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio settings (bass, treble, ambience) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

The Bluetooth connection

is cut.

The battery of the peripheral may not be suffi ciently charged.

Recharge the battery of the peripheral device.

The message "USB

device error" is displayed

on the screen.

The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick (FAT 32).

325

QUESTION

ANSWER

SOLUTION

A telephone connects

automatically,

disconnecting another

telephone.

Automatic connection overrides manual connection.

Modify the telephone settings to remove automatic

connection.

The Apple

player is

not recognised when

connecting to the USB port.

The Apple

player is of a generation that is not compatible with the USB.

Connect the Apple

player to the AUX Jack socket

using a suitable cable (not supplied).

The hard disk or device

is not recognised when

connecting to the USB

port.

Some hard disks and devices need a power supply greater than is

provided by the audio system.

Connect the device to the 230 V socket, the 12 V

socket or an external power supply.
Caution : ensure that the device does not transmit

a voltage greater than 5 V (risk of destruction of

the system).

When streaming, the

sound cuts momentarily.

Some telephones prioritise connection of the "hands-free" profi le.

Delete the "hands-free" connection profi le to

improve streaming.

In "Random all" play,

not all of the tracks are

played.

In "Random all" play, the system can only take into account up to

999 tracks.

With the engine off, the

audio system switches

off after a few minutes

of use.

When the engine is switched off, the audio system operating time

depends on the battery charge.
The switch-off is normal: the audio system switches to economy mode

and switches off to prevent discharging the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The message "the audio

system is overheated"

appears on the display.

In order to protect the installation if the surrounding temperature is too

high, the audio system switches to an automatic thermal protection mode

leading to a reduction of the volume or stopping of the playing of the CD.

Switch the audio system off for a few minutes to

allow the system to cool.

326

327

Alphabetical index

Accessories ..................................................214

Accessory socket, 12 volt ...............................77

Adjusting headlamps ....................................144

Adjusting head restraints .......................... 67, 70

Adjusting seat belt height..............................172

Adjusting the steering wheel...........................76

Airbags ............................................................32

Airbags, curtain ..................................... 176, 177

Airbags, front......................................... 174, 177

Airbags, lateral...................................... 176, 177

Air conditioning .........................................20, 89

Air conditioning, digital........................87, 90, 98

Air conditioning, manual ........................... 87, 88

Air conditioning, quad-zone............... 93, 96, 98

Air filter..........................................................

225

Air flow ............................................................20

Air vents ..........................................................86

Alarm ...............................................................53

Anti-theft........................................................102

Armrest............................................................77

Armrest, rear ...................................................

Assistance call ......................................166, 240

Audible warning ............................................166

Audio streaming (Bluetooth) .........284, 310, 312

Audio system (radio) .....................................297

Automatic illumination

of headlamps .......................................137, 141

Automatic operation of hazard

warning lamps.............................................165

Automatic rain sensitive

windscreen wipers.............................. 147, 149

Auxiliary socket.............................................309

Backup switching off .....................................

102

Battery.................................................. 204, 225

Battery, charging ...........................................204

Battery, remote control ............................. 50-52

Blind ................................................................61

Bluetooth (hands-free) .......................... 267, 311

Bluetooth (telephone)....................................267

Boot ........................................................... 57-59

Boot (opening).................................................46

Brake discs ....................................................226

Brake lamps ..........................................196, 197

Brake pads ....................................................226

Brakes ...........................................................226

Capacity, fuel tank ..........................................64

CD .................................................................304

CD MP3 ................................................ 305, 306

Central locking ................................................47

Changing a bulb .................... 191, 196, 197, 199

Changing a fuse............................................200

Changing a wheel .................................184, 185

Changing a wiper blade ........................150, 208

Changing the date..................................... 41, 42

Changing the remote control battery........50, 51

Changing the time..................................... 41, 42

Checking levels ..................................... 222-224

Checking the engine oil level ..........................37

Checking tyre pressures (using the kit) ........ 178

Checks .................................. 219-221, 225, 226

Children ......................................... 157, 161, 162

Child seats ...........................153, 154, 156, 159

Child seats, conventional......................156, 157

Closing the boot ..............................................57

Closing the doors............................................47

Connectors, audio ...........................79, 307, 309

Date (setting)............................................. 41, 42

Daytime running lamps .........139, 191, 193, 195

Deactivating ESP ..........................................170

Deactivating the passenger airbag............... 174

Deadlocking ....................................................48

Defrosting........................................................98

Diesel ..............................................................25

Diesel additive level ......................................224

Diesel engine pre-heat warning lamp .............25

Dimensions ...................................................236

Dipped beam ..................................136, 191-193

Dipstick....................................................37, 222

Directional lighting ................................145, 146

Direction indicators ........140, 165, 191, 195-197

Driving positions (memorising) .......................69

Dynamic emergency braking ........................103

Dynamic stability control (DSC) ..............30, 170

Coolant level ...........................................33, 223

Coolant temperature indicator ........................

Courtesy lamps ............................................. 151

Cruise control........................................ 127, 130

Cup holder.......................................................

Eco-driving .....................................................20

Eco-driving (advice) ........................................20

Economical driving .........................................20

Economy mode .............................................207

Electronic engine immobiliser.................

52, 102

Electronic stability control (ESC) ..................168

Emergency boot release .................................60

328

Alphabetical index

Filling with fuel ..........................................64, 66

Fitting a wheel ...............................................187

Fitting roof bars............................................. 213

Fittings, boot .............................................80, 81

Flashing indicators................................140, 165

Foglamps ......................................................191

Foglamps, rear..............................................

138

Folding the rear seats .....................................72

Front foglamps ..............................138, 191, 194

Front seats ................................................ 67-69

Fuel............................................................20, 66

Fuel consumption............................................20

Fuel filler cap...................................................64

Fuel filler flap...................................................64

Fuel gauge ......................................................64

Fuel tank..........................................................64

Fusebox, dashboard .....................................200

Fuses .............................................................200

Halogen headlamps.............................. 191, 192

Hands-free kit........................................ 267, 311

Hazard warning lamps ............................83, 165

Head-up display ............................125, 128, 130

Headlamp adjustment ...................................144

Headlamps, directional .........................145, 191

Headlamp wash ............................................148

Headlamp wash reservoir.............................

223

Head restraints, front ................................ 67, 70

Head restraints, rear .......................................

Heated seats............................................. 67, 70

Heating......................................... 20, 88, 96, 99

Height and reach adjustment,

steering wheel ..............................................76

High load retaining net....................................84

Hill start assist...............................................124

Jack .......................................................184, 185

JACK socket..................................................309

JBL (audio system).................................... 7, 241

Identification plates.......................................237

Indicator lamps, status..............................25, 29

Indicators, direction ......................................165

Inflating accessories (using the kit) .............. 178

Inflating tyres ..................................................20

Inputs for audio system .................................309

Instrument panel .............................................22

Instrument panels ...........................................23

Instrument panel screen ......................... 23, 112

Intelligent Traction Control............................169

Interior fittings .................................................77

Interior mood lighting ....................................152

ISOFIX...........................................................161

ISOFIX child seats ................................ 160-162

ISOFIX mountings.........................................160

Keeping children

safe ......................153, 154, 157, 161, 162, 174

Key .......................................... 43-45, 47, 50, 52

Key, electronic ..................................... 43-47, 50

Keyless Entry and Starting .........44, 45, 52, 101

Key with remote control ................................102

Emergency call .....................................166, 240

Emergency warning lamps .....................83, 165

Energy economy mode .................................207

Engine, Diesel........ 66, 218, 220, 221, 230, 233

Engine, petrol..........................66, 219, 227, 228

Engine compartment............................. 219-221

Engine compartment fusebox.......................200

Engine oil level indicator .........................

37, 222

Engines .................................................227, 230

Environment ..............................................20, 51

ESC/ASR.......................................................168

G.P.S. ............................................................252

Gearbox, automatic .............................. 113, 226

Gearbox, electronic

gear control..................................117, 121, 226

Gearbox, manual ...................111, 112, 121, 226

Gear lever........................................................20

Gear lever, automatic gearbox ..................... 113

Gear lever, electronic gear

control gearbox ........................................... 117

Gear lever, manual gearbox ......................... 111

Gear shift indicator........................................ 112

Guidance ...............................................250, 258

Guide-me-home............................................ 141

329

Alphabetical index

Labels, identification.....................................237

Lamps, warning and indicator.............

23, 27, 28

Level, brake fluid...........................................222

Level, headlamp wash ..........................148, 223

Level, power steering fluid............................222

Levels and checks................................. 219-224

Lighting, guide-me home ...................... 140, 141

Lighting, interior ....................................

151, 152

Lighting bulbs

(replacement)...................... 191, 196, 197, 199

Lighting control stalk.............................136, 140

Lighting on reminder .....................................

138

Loading....................................................20, 213

Load reduction mode ....................................206

Load space cover............................................

Locating your vehicle ......................................49

Long objects, transporting ..............................79

Luggage retaining strap ............................80, 81

Main beam .............................136, 191-193, 195

Maintenance....................................................20

Map reading lamps ....................................... 151

Markings, identification .................................237

Massage function ...........................................71

Mat ..................................................................78

Menu, main ...................................................300

Mini fuel level ..................................................64

Mirror, rear view ..............................................76

Mirrors, door..............................................

74, 75

Motorised boot ..........................................58, 59

Motorway function

(direction indicators) ...................................165

Mountings for ISOFIX seats .........................160

MP3 CD ................................................ 305, 306

Music media players .....................................280

Navigation .............................................249, 250

Number plate lamps......................................199

Oil filter ..........................................................

225

Oil level....................................................37, 222

Opening the boot ................................43, 46, 57

Opening the doors ..........................................43

Opening the panoramic sunroof blind ............63

Operation indicator lamps.............23, 25, 27, 29

Radio .............................................277, 278, 301

Rear foglamp.........................................196, 197

Rear screen (demisting)..................................98

Recharging the battery .................................204

Reduction of electrical load ..........................206

Regeneration of the particle

emissions filter............................................

225

Reinitialising the remote control ...............50, 51

Remote control.............................. 43-45, 47, 52

Removable screen (snow shield).................. 211

Removing a wheel ........................................187

Removing the mat...........................................78

Repair kit, puncture.......................................178

Replacing bulbs .................... 191, 196, 197, 199

Replacing fuses ............................................200

Replacing the air filter ...................................

225

Replacing the oil filter ...................................

225

Replacing the passenger

compartment filter ......................................

225

Replacing wiper blades.........................150, 208

Resetting the service indicator .......................

Reversing lamp .....................................196, 197

Roof bars....................................................... 213

Roof blind ........................................................63

Routine checks .................................... 225, 226

Running out of fuel (Diesel) ..........................218

Safety for children.........................................164

Screen, colour and mapping ................. 247, 288

Screen, instrument panel ..........................23, 38

Screen, monochrome .......................... 300, 320

Screen, multifunction

(with audio equipment) ...............................300

Screen-wash reservoir..................................223

Screen menu map.................................288, 320

Paint colour code ..........................................237

Panoramic glass sunroof ................................

Parking brake ................................106, 110, 226

Parking brake, electric ..................................103

Parking lamps ...............................................140

Parking sensors, front ...................................133

Parking sensors, rear....................................

132

Parking space sensor ..................................134

Particle emission filter ..........................

223-225

Passenger compartment filter ......................

225

PEUGEOT CONNECT ASSISTANCE..........240

Peugeot Connect Navigation (RT6)..............243

PEUGEOT CONNECT SOS .........................240

Player, CD MP3.................................... 305, 306

Port, USB ................................................79, 307

Priming the fuel system ................................218

Programmable heating (Webasto) ..................99

Protecting

children ................ 153, 154, 157, 160-162, 174

Puncture........................................................178

330

Alphabetical index

Screenwash, front .........................................148

Screenwash fluid level ..........................148, 223

Seat adjustment ........................................ 67, 68

Seat belts ....................................... 156, 171-173

Seats, rear.......................................................

Serial number, vehicle ..................................237

Service indicator .............................................

Servicing .........................................................20

Setting the clock ....................................... 41, 42

Short-cut menus ...........................................248

Sidelamps ..............136, 140, 191, 193, 195-197

Side repeater.................................................195

Ski flap ............................................................79

Spare wheel .......................................... 184-186

Speed limiter .........................................

127, 128

Spotlamps, side ....................................143, 195

Starting the engine........................................102

Starting the vehicle ........................101, 113, 117

Steering mounted controls, audio ........ 246, 299

Stopping the vehicle ......................101, 113, 117

Stop & Start........................... 40, 64, 91, 94, 98,

121, 204, 217, 225

Storage..........................................77, 78, 80, 81

Storage wells.............................................80, 81

Storing driving positions .................................69

Stowing rings ............................................80, 81

Sunroof............................................................

Switching off the engine ...............................102

Synchronising the remote control.............50, 51

Synthesiser, voice.........................................261

System, navigation........................................250

Table of weights ................................... 228, 233

Tables of engines ..................................227, 230

Tables of fuses..............................................200

Technical data...................... 227, 228, 230, 233

Telephone .............................................267, 269

Temperature, coolant......................................33

Temperature control for heated seats ............70

Temporary tyre repair kit...............................178

Third brake lamp ...........................................199

TMC (Traffic info) ..........................................264

Tools......................................................184, 185

Towbar...........................................................

211

Towed loads ......................................... 228, 233

Towing another vehicle .................................209

Traction control (ASR) ....................................30

Traffic information (TA) ................ 265, 279, 302

Traffic information (TMC) ..................... 264, 265

Trailer ............................................................

211

Trip computer ............................................

38, 39

Tyre pressures ..............................................237

Tyres ................................................................20

Tyre under-inflation detection ............... 167, 186

Under-inflation (detection) ............................167

Unlocking ..................................................43, 44

Unlocking the boot ..........................................46

Updating the date ...................................... 41, 42

Updating the time ...................................... 41, 42

USB (Peugeot Connect) .................................79

Vehicle identification.....................................237

Ventilation ................................................. 86-88

Warning lamps ....................................25, 28, 29

Warning triangle..............................................83

Wash-wipe, rear............................................

148

Weights ................................................ 228, 233

Welcome function ...........................................69

Welcome lighting...........................................143

Wiper, rear.....................................................

148

Wiper control stalk ................................. 147-149

Wipers ............................................. 26, 147, 149

Xenon headlamps .........................................191

331

Visual search

Saloon Exterior

Remote control key / electronic

key

43-52

- opening

/ closing

- anti-theft protection

- starting

- battery

Welcome lighting 143
Door mirror spotlamps 143
Main directional

lighting

136-142, 145

Additional directional lighting 146
Headlamp height adjustment 144
Changing bulbs

191-195

- front

lamps

- foglamps

- direction indicator repeaters

Wipers 147-149
Changing a wiper blade

150, 208

Parking space sensors

134-135

Doors 44-52

- Keyless Entry and Starting

- opening / closing

- central

locking

- emergency control
Alarm

53-54

Electric windows

55-56

Fuel tank,

misfuel prevention

64-66

Sunroof 61-62
Roof bars

213

Accessories 214-215

ESC, ABS, EBA, ASR, DSC

168-170

Tyre under-inflation detection

167

Tyre pressures

237

Changing a wheel

184-190

- tools

- removing / refitting

Boot 57, 60

- opening / closing

- emergency release
Temporary puncture

repair kit

178-183

Changing bulbs

196, 199

- rear

lamps

- 3rd brake lamp

- number plate lamps

- foglamps

Parking sensors

132-133

Towbar 211-212
Towing 209-210

Door mirrors

74-75

332

Visual search

SW Exterior

Remote control key / electronic key 43-52

- opening / closing

- anti-theft protection

- starting

- battery

Welcome lighting 143
Door mirror spotlamps 143
Main directional

lighting

136-142, 145

Additional directional lighting 146
Headlamp adjustment

144

Changing bulbs

191-195

- front

lamps

- foglamps

- side

repeaters

Wipers 147-149
Changing a wiper blade

150, 208

Door mirrors

74-75

Doors 44-52

- Keyless Entry and Starting

- opening / closing

- central locking

- emergency control
Alarm 53-54
Wipers 55-56

Fuel tank,

misfuel prevention

64-66

Boot 57,

- opening / closing

- emergency

control

Motorised tailgate 58-59
Temporary puncture

repair kit

178-183

Changing bulbs

197-199

- rear

lamps

- 3

brake lamp

- number plate lamp

- fog lamps

Parking sensors

132-133

Towbar 211-212
Towing

209-210

Sunroof 61-62
Panoramic sunroof

Roof bars 213
Accessories

214-215

ESC: ABS, EBA, ASR, DSC

168-170

Under-inflation detection

167

Tyre pressures

237

Changing a wheel

184-190

- tools

- removing / refitting

Parking space sensors

134-135

333

Visual search

Interior

Saloon boot fittings 80

- rings, hooks, straps

- storage

box

- boxes, storage

- boot lamp

- floor
SW boot fittings 81

- rings hooks

- boot lamp

- floor

- 12 V accessory socket

- storage
SW luggage cover

SW high load net

84-85

Warning triangle 83

Conventional child seats

153-159

Electric child lock

164

Front seats

67-71

- head restraints

- heated

- electric

- welcome function

- manual

- massage

Rear armrest

Ski flap 79

Mats 78
Airbags

174-177

Interior fittings 77
Deactivating the passenger's front

airbag 154,

175

Seat belts

171-173

Rear seats

72-73

ISOFIX child seats

160-163

334

Visual search

Instruments and controls

Courtesy lamps

151

Seat belt / passenger's front airbag

warning lamps display 172,

175

Rear view mirror

Sunroof

61-62

SW panoramic sunroof 63

Door mirrors

74-75

Electric windows, deactivating 55-56

Manual parking brake

110

Heating, ventilation

86-87

Manual air conditioning 88-89
Dual-zone air conditioning 90-92
Quad-zone front

air conditioning 93-95

Demisting / defrosting 98

Peugeot Connect USB

Electric

parking brake

103-109

5/6-speed manual gearbox 111
Gear shift

indicator 112

Automatic gearbox

113-116

Electronic gear control

gearbox

117-120

Stop & Start 121-123
Hill start assist

124, 108

Fuses behind the glove box

202

Quad-zone rear

air conditioning 96-97

Peugeot Connect Navigation (RT6) 243-296
Setting the date/time 42

Audio system

297-325

Setting the date/time 41

Opening the bonnet

217

Dashboard fuses 200-201

Content .. 19 20 21 22 ..
